Impact ME-100 User manual

ME-100 ATOM CL AMP INSTRUCTIONS

Thank you for choosing Impact

Congratulations on the purchase of your new
Impact Atom Clamp. The Impact Atom Clamp is
ideal for mounting threaded accessories to poles
and at surfaces. Made of durable and light­weight aluminum with a textured non-slip rubber
jaw grip, the Impact Atom Clamp also features an
easily adjustable handle that may be repositioned
without loosening or tightening the clamp.

Contents

• Atom Clamp

• One-Year Limited Warranty

Specications

• Load capacity 7kg (15.4 lbs)

• Thread sizes 3/8” and 1/4”

• Fits round poles with diameters
15mm-35mm (.59”-1.37”)

• Fits at surfaces up to 35mm (1.37”)

• Weight 106g (4 oz)

Mounting the Clamp

1. With the handle of the Atom Clamp facing
you, loosen the clamp by turning the handle
counterclockwise.

1/4”-20

15.4lbs Max.3/8”

2. Identify the male thread on the item you wish to
mount to the Atom Clamp, and match it up with
the corresponding 3/8” or 1/4” female thread on
the Atom Clamp. Mount the item by screwing it
in clockwise until it is secure.

3. Set the jaw grip of the Atom Clamp around
the surface to which you want to mount it,
and tighten the clamp by turning the handle
clockwise.

Repositioning the Handle

1. To reposition the handle without loosening
or tightening the clamp, hold the body of the
Atom Clamp steady with one hand.

2. Using your other hand to hold onto the base
of the handle, pull the handle away from the
body of the Atom Clamp.

3. While still pulling the handle away from the
body of the clamp, rotate the handle to the
desired position and then release.

Note: Make sure everything is secure before
proceeding.

1. With the handle of the Atom Clamp facing
you, loosen the clamp by turning the handle
counterclockwise.
