Lighting Equipment & Accessories
own
C-Stand with
Sliding Leg 40”
Silver model shown
er model sh
Thank you for choosing Impact.
The Impact LS-CS40M C-Stand with Sliding Leg 40” features a top leg
that slides up and down the main riser so you can set up your C-stand on
uneven ground—like stairs or a steep incline—or on furniture, sidewalk
curbs, or set pieces. The other two legs feature a locking mechanism
that allows them to swing out and lock into place for easy setup, and to
collapse fl at so you can store your c-stands side by side.
Often used in conjunction with a grip head and grip arm (sold separately,
see Recommended Accessories), you can use the Impact C-Stand to hold
lights and light modifi ers, such as fl ags, “cookies,” etc. The Impact C-stand
is ideal for mounting heavy items because the stand has a low center of
gravity, and it easily accepts saddlebag-style sand bags for additional
stability.
The Impact LS-CS40M C-Stand with Sliding Leg 40” is compatible with
other grip equipment available from Impact Studio Lighting. For more
information, refer to the Recommended Accessories chapter of this
pamphlet.
Specifi cations
Minimum height – 4.5’ (1.37 m)
Maximum height – 10.99’ (3.35 m)
Closed length – 53.94” (137 cm)
Footprint diameter – 39.37” (1 m)
Weight – 15 lb. (6.8 kg)
Maximum load capacity – 22 lb. (9.98 kg)
Attachment size – 5/8” male stud
Recommended Accessories
• Impact CT40M Turtle Base C-Stand, Silver
• Impact KCP-200 2.5” Grip Head, Silver
• Impact KCP-240 40” Extension Arm, Silver
• Impact CT40MB Turtle Base C-Stand, Black
• Impact KCP-200B 2.5” Grip Head, Black
• Impact KCP-240B 40” Extension Arm, Black
• Impact KCP-700B26 Super Clamp with 1/4”-20 Stud
• Impact LS-3S Two Section Backlight Stand
• Impact R1142 5-in-1 Collapsible Circular Refl ector Disc
• Impact SB-5B (5 lb.), SB-15B (15 lb.), SB-25B (25 lb.), and SB-35B
(35 lb.) Saddle Sandbags, available in Black or Orange
Visit our website at www.impactstudiolighting.com for more Impact
accessories.
Warnings ⚠
• Do not attempt to disassemble or repair the equipment—doing so will
void the warranty, and Impact Studio Lighting will not be responsible for
any damage.
• Handle the unit with care.
• Clean the unit with a soft dry cloth.
• Keep this unit away from children.
• Use only parts provided by the manufacturer.
• Make sure everything is secure before proceeding.
• Make sure the item is intact and that there are no missing parts.
• Do not exceed the maximum load capacity.
• All photos are for illustrative purposes only.
Limited One-Year Warranty
Impact provides a limited warranty that this product is free from defects in materials
and workmanship to the original purchaser under normal use for a period of one (1) year
from the original purchase date or thirty (30) days after replacement whichever occurs
later. Our responsibility with respect to this limited warranty shall be limited solely to
repair or replacement, at its option, of any product which fails during normal consumer
use. To obtain warranty coverage during the Warranty Period, contact your place of
purchase (“Seller”) to obtain a return merchandise authorization (“RMA”) number,
and return to Seller the defective product along with proof of purchase and the RMA
number. This warranty does not extend to damage or failure which results from misuse,
neglect, accident, alteration, abuse, improper installation or maintenance. EXCEPT AS
PROVIDED HEREIN, IMPACT MAKES NEITHER ANY EXPRESS WARRANTIES NOR ANY
IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. This warranty provides
you with specifi c legal rights, and you may also have additional rights which vary from
state to state.
© Copyright 2012 Gradus Group
