Impact HSSG-24 User manual

Grid for Hexi 24 Speedlight Softbox

Grid for Quikbox

INSTRUCTIONS

INSTRUCTIONS

Introduction

Thank you for choosing the Impact Grid for Hexi 24
Speedlight Softbox. This special effects accessory
is perfect for focusing light onto a specic area
of a subject. The grid narrows the beam spread
from your softbox and controls the light spill and
directionality. The touch-fastener surface and
included carrying case make the grid extremely

easy to setup and transport.

Precautions ⚠⚡

• Please read and follow these instructions and keep this
manual in a safe place.

• Keep this product away from water and any ammable
gases or liquids.

• Handle this product with care.

• Clean this product with only a soft, dry cloth.

• Keep this product away from children.

• All photos are for illustrative purposes only.

Instructions

1. Remove the grid from
its case and unfold it by
holding it in front of you.

2. With the softbox
assembled, align the grid
corners with those of the
softbox using the correct

by the forward facing
arrows on the grid).

3. Attach the grid to the
outer area of the touch­fastener surface on the
inside rim of the softbox
mouth.

orientation (as indicated

Specications HSS-24

Angle 40°

Dimensions 24˝ × 24˝ × 1.3˝ (60.9 × 60.9 × 3.3 cm)

Weight 1.6 oz. (45 g)
