Thank you for choosing the Impact Digital Light Shed.
This tabletop shooting enclosure features a highquality translucent fabric housing, making it ideal for
photographing jewelry, glassware, and other highly
reective objects. It’s also perfect for generating
consistently illuminated images for use in catalogs or
e-commerce. The translucent material will dramatically
reduce unwanted reections and give you soft, nearly
shadowless lighting. The shed can be lit with electronic
strobe, uorescent, tungsten, or LED light sources.
With the ability to be lit from all sides and the added
convenience of the included white and black sweeps, the
Impact Digital Light Shed is the perfect platform for small
item photography.
SpecicationsDLS-GDLS-J
Dimensions35˝ × 35˝ × 35˝
(90 × 90 × 90 cm)
Weight3.5 lbs (1.5 kg)6.25 lbs (2.8 kg)
47˝ × 47˝ × 47˝
(120 × 120 × 120 cm)
2
Page 3
Features
• Lighting is made simple and efcient, taking less time
to erect than conventional lighting solutions
• Portable with easy setup and takedown
• Dual zippered front and top panels for camera lens
positioning
• Front panel peels back on all four sides for easy
positioning of objects inside
Box Contents:
• Shooting enclosure
• White fabric sweep
• Black fabric sweep
• Storage bag
• User manual
3
Page 4
Instructions
Setting Up Your Digital Shed Light
1. Remove the digital light shed
from its storage bag.
2. Holding it away from your body,
unfold the light shed from its
folded, stacked form.
3. The sides of the light shed are
folded together into layers. Lift
one of the layers from the other
as if you were opening a book.
4
4. With the rst layer lifted 90°,
grab a corner from inside the
layers and pull it out. The light
shed will pop open.
5. Peel the touch-fastener cover
away from the front opening.
This opening gives you access
to set up the scene inside the
shed.
Page 5
6. Your kit also includes white and
black sweeps, providing more
background choices. They can
be secured to the shed with the
touch-fastener corners.
7. You can shoot through the
zipper in the front panel
or remove the front panel
altogether. With the front panel
removed you can rotate the
Digital Light Shed and place it
over your scene.
8. Additionally, positioning the
shed with the top zipper on
the side gives you the ability
to shoot your scene from many
different angles.
9. The dual zippers allow you to
place the camera high, low, or
in the middle of the light shed.
10. Keep the openings closed to
minimize reections.
5
Page 6
Folding for Storage
1. Remove and store the
background sweep.
2. Grab a corner and fold it into
its opposite, creating an L
shape.
3. Be sure the metal support
frames are not twisted before
folding. The light shed will not
properly collapse if any of the
frames are twisted. You can
straighten a twisted support
frame and continue to fold the
light shed.
6
4. Fold the light shed at.
5. Grasp the light shed as shown.
Note that your thumbs should
be on opposite sides of the
unit.
Page 7
6. Twist the light shed into a
gure-eight shape.
7. Continue twisting and pull the
sides together as shown. The
sides will pass one in front of
the other until they are stacked
together.
7
Page 8
One-Year Limited Warranty
This IMPACT product is warranted to the original purchaser to be free from
defects in materials and workmanship under normal consumer use for a period of
one (1) year from the original purchase date or thirty (30) days after replacement,
whichever occurs later. The warranty provider’s responsibility with respect
to this limited warranty shall be limited solely to repair or replacement, at the
provider’s discretion, of any product that fails during normal use of this product in
its intended manner and in its intended environment. Inoperability of the product
or part(s) shall be determined by the warranty provider. If the product has been
discontinued, the warranty provider reserves the right to replace it with a model
of equivalent quality and function.
This warranty does not cover damage or defect caused by misuse, neglect,
accident, alteration, abuse, improper installation or maintenance. EXCEPT AS
PROVIDED HEREIN, THE WARRANTY PROVIDER MAKES NEITHER ANY EXPRESS
WARRANTIES NOR ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED
TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. This warranty provides you with specic legal rights, and
you may also have additional rights that vary from state to state.
To obtain warranty coverage, contact the Impact Customer Service Department
to obtain a return merchandise authorization (“RMA”) number, and return the
defective product to Impact along with the RMA number and proof of purchase.
Shipment of the defective product is at the purchaser’s own risk and expense.
For more information or to arrange service, visit www.impactstudiolighting.com
or call Customer Service at 212-594-2353.
Product warranty provided by the Gradus Group.
www.gradusgroup.com
IMPACT is a registered trademark of the Gradus Group.
