MPX-1/BK
Order No.: 20.2170
EUR 119,90
RRP *
PRODUCTINFOS
Stereo DJ mixer
2 stereo input channels, each with gain control and 2-way equalizer, switchable phono/line
DJ microphone channel with talkover, manually selectable
Pre-fader listening (PFL) to the stereo input channels via adjustable headphone output
Replaceable crossfader for crossfading between the two input channels
Especially easy-sliding high-quality faders with additional guides
Stereo LED level display
TECHNICAL SPECIFICATIONS
MPX-1/BK
No. of channels 2
No. of inputs 4
Page 2
MPX-1/BK
Mic input 1.5 mV, 49 dB, 1 x 6.3 mm jack
Line input 150 mV, 61 dB, 2 x RCA L/R
Phono input 3 mV, 2 x RCA L/R
Master output 1 V/600 Ω, 1 x RCA L/R
Record output 0.5 V/600 Ω, 1 x RCA L/R
Headphones ≥ 8 Ω, 1 x 6.3 mm jack
Frequency range 20–20,000 Hz
THD 0.1%
Equalizer bass ±12 dB/50 Hz
Equalizer treble ±12 dB/10 kHz
Talkover -16 dB
Contact: +49 421 4865-0
MPX-1/BK - Page: 2
Crossfader yes
Power supply
via
encl. plug-in power supply
Admiss. ambient temp. 0–40 °C
Width 164 mm
Height 218 mm
Depth 77 mm
Weight 1.2 kg
