Contact: +49 421 4865-0
MPR-1 - Page: 1
MPR-1
Order No.: 21.2010
EUR 94,90
RRP *
PRODUCTINFOS
1-channel microphone preamplifier,
with switchable phantom power.
1 microphone input, XLR, bal. or 6.3 mm jack, bal.
Gain control: up to 50 dB max.
Clip LED
30 V phantom power, can be activated as required
TECHNICAL SPECIFICATIONS
MPR-1
Type microphone preamplifier
Frequency range 10-30,000 Hz
MPR-1
Input signal
3.5 mV (XLR, bal.)
16 mV (jack, bal.)
Input impedance 10 kΩ
Output signal 1 V
Contact: +49 421 4865-0
MPR-1 - Page: 2
Gain
50 dB (with bal. connection)
44 dB (with unbal. connection)
S/N ratio 58 dB
THD 0.1%
Admiss. ambient temp. 0-40 °C
Power supply
via suppl.
plug-in PSU
Dimensions 113 x 92 x 40 mm
Weight 345 g
Inputs
Outputs
* Important Notice: The retail prices shown here are non-binding recommendations that retailers can charge their customers. They are not
part of any specific offer or advertisement. These prices include all charges as well as VAT, but do not cover any additional delivery and
shipping costs. Our latest price lists for the retail market include all applicable delivery and payment terms for retailers.
1 x XLR,
1 x 6.3 mm jack
1 x XLR,
1 x 6.3 mm jack
