WASHING MACHINES

LM 8 - 11 - 14 - 18 - 23
LM 30 - 40 - 55 - 70 - 85

LM SERIES

THE WINNING
CHOICE!

IMESA LM series washing machine are the ideal laundry
solution for hotels, restaurants, hospitals, retirement homes,
Coin-op laundries, wellness centres, …

The new high spin washer is the result of important design
studies and uses the latest technologies to satisfy the custo­mer from any point of view: high machine reliability, high quality
results, ergonomics, simplicity of use.

Available in a wide model range, the IMESA LM Series is the

most exible on the market: the user can create by himself the

washing programs in a very simple way!

IMESA: A LIFE BY YOUR SIDE

IMESA: A LIFE BY YOUR SIDE

Imesa is a leading company in the production of laundry equipment. We achieved this goal thanks to more than 40 years of total

commitment to the continuing challenges to satisfy the growing technological expectation of human beings and meetings changes
in lifestyle.

Innovation, quality, safety, versatility, service and reliability: IMESA success is based on this six concepts. Innovation in

technology and proposal. Quality guranteed by an UNI EN ISO 9001 certied production system. Safety of products certied by
qualied operational organisation in various part of the world. Versatility and exibility which allows many possibilities of

customisation. Reliability thanks to the solid product structure.

Customer satisfaction is IMESA main achievement. Thanks to an international and professional net of distributor and to a well
trained service net, IMESA can assure a global service in Italy, in Europe and in all the world.

During the offer step, IMESA distributors offers a complete support in the correct equipment choice and complete the job with a

nancial analysis of the investment as well as with the project.

IMESA can deliver in a very short time thanks to equipment stock in many countries: Italy, Spain, French, Portugal, Algeria,
Hungary, …

IMESA S.p.A Via degli Olmi, 22 - 31040 Cessalto (TV) ITALIA + 39 0421 468011 [phone] [e-mail] - www.imesa.it

DISTRIBUITED BY

Studied to last: a reliable structure and high quality components! We are proud of
our product reliability in which we trust so much to grant the best warranty condition:

24 MONTHS TOTAL WARRANTY!

Superlative performances

100% Customer satisfaction

High stability: Thanks to the new IMESA Power Balance

System (PBS), the perfect balance is assured also with difcult

or partial loads.

Half load programs: The user can create also half load
programs, the washing machine is automatically adjusting the
water level and the detergent consumes to avoid wastes.

Preferred programs list: The most used 10 programs are
saved in a menu, so the user can start them very quickly.

Motorized door lock: once the door is set ajar, the system
block it at the program start.

GSM REMOTE SYSTEM: a modern system which allows to
update the software, to modify and to download new programs,
to make a machine check up from remote. This system allows
to reduce the intervention time!

The wide service net can assure a quick technical assistance in case of necessity and the spare parts can be easily purchased

in IMESA ofcial website.

Q130103B_ENG The manufacturer declines all responsibility for any inexactitudes contained in this catalogue. The manufacturer reserves the right to bring without warning any modications he might believe necessary, without changing the essential characteristic of the product.

LM SERIES

THE ATTENTION TO THE DETAIL
IS OUR STRENGTH

GSM remote system

Reduction of intervention time

IM8 Computer equipped with touch screen

Interaction with the washing machine is made easier
by the use of easy to understand icons.

USB Door on machine control panel

Easier data transfer from the PC to the machine
and from one machine to the others.

Ergonomic tilted control panel

No reections on the touch screen

HIGH LEVEL SAFETY ERGONOMICS AND RELIABILITY

QUALITY RESULTS

IMESA LM series washing machine uses the latest technology
to assure high quality results to the customer.

NO FABRICS STRESS

Thanks to the inverter use the drum speed can be controlled and
the spin acceleration is gradually made, in this way the
mechanical stress to the linen fabrics is avoided.

NO LINEN SHOCKS

Water is gradually heated in order to avoid thermal shocks to the
linen. Thanks to the “water balanced load”, the washing machine
loads cold alternate to hot water reaching the set temperature
in a very quick and precise way. Using the hot water coming
from the hydraulic system, the program length is shorter and the
energy consumes are reduced.

USER SAFE

IMESA pays a special attention to the user safety.

EMERGENCY STOP BUTTON

IMESA washing machines are equipped with an emergency stop
button which shuts off the machine when pressed.

MOTORIZED DOOR LOCK

IMESA Washing machines are equipped
with an innovative and automatic door
closing system, which recognizes the
door set ajar and locks it when the
program starts; until this moment the user
could open again the door to insert or take
out linen. While the program is running
the door is blocked and it can be opened
again at the end of the program when it is
automatically unlocked by the system.
The door stay locked if the
temperature inside the drum is higher
than the set safety values.

INNOVATIVE ERGONOMICS

IMESA LM series washing machine was designed to make
easier the user job.

HUGE LOAD DIAMETER

IMESA washing machines has a big loading diameter which
allows to easily load and unload also bulky linen.

AUTOMATIC DOOR OPENING

Door closing and opening ask for
a small user intervention, as this
operation are automatically controlled
by the machine.

TILTED CONTROL PANEL

The control panel angle was designed to avoid unpleasant

reections on the touch screen:

30°for LM 14, LM 18, LM 23 e 45° for LM 8 and LM 11.

STRONG RELIABILITY

IMESA LM series washing machine was designed paying
attention to each single detail and manufactured using only high
quality components: this machine has been made to last during
the time!

PBS SYSTEM: HIGH STABILITY

PBS is the IMESA exclusive shock absorber
system, studied to bear high stress mantaining

S

the machine balance even in the most critical
situation.

P

O

W

E

C

N

E

A

R

L

E

A

D

B

FRONTAL SEAL

The bearing house is equipped with a frontal seal in silicon
carbide which stops the water saving the bearing good working
for thousands cycles.

IMESA LM

THE STAINLESS STEEL DURABILITY

Side, above and frontal panels in stainless steel AISI 304.

LM SERIES

FREE-STANDING

No ground xing is requested to install the washing machines,

LAUNDRY

which can be correctly positioned just operating on the adjustable
rubber feet.

M

E

T

S

Y

Model

LM 8
LM 11
LM 14
LM 18
LM 23

Capacity

(1:10)

8 Kg
11 Kg
14 Kg
18 Kg
23 Kg

Available

heating

Electric

Direct steam / Indirect steam

Electric + Steam

No heated

STAR

LM 14 - LM 18 - LM 23 models are equipped with motorized door lock.

Control panel tilted to avoid unpleasant reex on the touch screen.

Removable below frontal panel

The below frontal panel can be removed to
make easier the drain valve and shock

M

E

T

S

Y

S

P

O

E

C

W

N

E

A

R

L

E

A

D

B

absorbers maintenance.

Power Balance System

Horizontal and vertical shock absorber: the machine
stability and the low noise level are assured.

Motorized door lock

High safety and ergonomics

Drum and outer drum in
Stainless steel AISI 304

No rust stains on the linen

Drain valve on machine front

The space between outer drum and drain valve
is reduced to the minimum, so water and
detergent wastes are avoided

IMESA washing machines are designed

in compliance with European Law in force.

IM8: SIMPLY TOUCH

IM8 is the new innovative control system which equips IMESA LM series washing
machine. It is not a simple microprocessor, but a real computer which enables the
LM series to easily suit the customer laudry needs and exigencies.

The machine is absolutely user
friendly thanks to the use of ICONS,
which can be easily understood and,
also, thanks to the IM8 ability to dialog
in more languages.

The user needs only to select the wi­shed application and then follow the
instructions displayed.

Thanks to the high resolution, the LCD can reproduce multimedia les, pictures,

advertisings, user notices, etc.
While the program is running, the screen shows all the operation in execution.
Touching the wished parameter, i.e. temperture, speed or water level, it is possible

to access the technical menu and change temporarily the parameters, modication

will not be permanently saved.
Also, selecting the suitable icon, it is possible to display the program progress bar
and from there to jump back to previouse cycles or fast forward to the following
cycles.

IMESA washing machines are respecting

the USA import standards.

AN ENDLESS LIST OF SOLUTIONS

IM8 allows to create, to modify, to name and to save up to 200 programs. The user,
anyway, can create own program in a very simple and intuitive way and he can choose
if the program must be saved or simply used and lost.
IM8 has an expandable memory: the program number, therefore, can be considerably
increased.

PREFERRED LIST

In order to avoid to scroll a very long program list, IM8 enables the user to compose
a preferred programs list: 5 are chosen by the user, 5 are chosen automatically by
the computer and are the most used.

HALF LOAD PROGRAM

During the program creation, it is possible to decide for the half load. In this case
the computer will optimize automatically the water level and the detergent consume
avoiding wastes.

EASY PROG

This application allows the user to create his own program answering to few simple
questions. The program can be named and saved to be used again later.

EXPERT PROG

This application allows the technician to compile the program line by line,
personalising each program parameters. Thanks to the expert program system

also the most hard request can be satised.

IMESA washing machines are respecting

the Russian import standards.

IMESA washing machines are respecting

the Water Regulation Advisory Scheme,

so they are suitable to UK Market.

EASY DATA TRANSFER

Thanks to the USB door, the total or partial program download form
the PC to the machine, or the data copy from machine to machine,
is very easy: a common USB stick is enough for an immediate data
transfer.

EASY MAINTENANCE

The washing machine is equipped with a self diagnostic system
which controls the correct machine working. Water loading/unloading
and heating operation must be done in a safety time set by the facto-

ry and modiable by the service centre.

IM8 computer anables the technician to dialog with the inverter and
proceed with possible necessary parameter changes directly from
the touch screen.
If something prevents the correct program running, the anomaly is
signalled on the screen. All the shown allarms are kept in memory to
make easier the technician diagnose.

GSM CONTROL

Thanks to the GSM Remote Assistance, the washing machine

contacts the technician by itself notying a maintenance request.

This system, also, anables the service centre to dialog with the
washing machine and to make a previous diagnosis, to up- and
download programs, to update the software.

IMESA:

WE ADD VALUE

TO YOUR JOB

Model

LM 30
LM 40
LM 55
LM 70
LM 85

Capacity

(1:10)

30 Kg
40 Kg
55 Kg
70 Kg
85 Kg

Direct steam / Indirect steam

Available

heating

Electric

Electric + Steam

No heated

Motorized door lock.

Option:
Detergent pumps: to grant a precise detergent measuring, the washing machine can be equipped with automatic detergent

­pumps.

Hard water: on request, the machine can be equipped with a third water inlet valve to manage hard water.

­Water recovery system: the water used in the last rinse can be used in the following cycle.

­No - overowing system: a sensor close the water inlet valve and open the drain valve if there is water on the ground.

-

GSM REMOTE
ASSISTANCE:

BECAUSE TIME
IS MONEY

The acceptance of the GSM remote system brings big advantages:

-

Shorter time of intervention means savings in laundry stop costs!

-

Customized programs can be up- and downloaded by remote: the intervention time is
quicker and the technician tryp is no more necessary.

-

The software updating can be made by remote: the latest technology is always
available.

-

The manufacturer warranty starts from the installation moment.
