Imation CD-R MEDIA User Manual

Imation 52x CD-R Media
Whether it’s music mastering, multimedia production or
digital imaging, Imation CD-R discs store data swiftly
and permanently with write speeds up to 52x, and
cannot be erased or overwritten. Featuring the fastest
write speeds available, Imation CD-Rs are the optimal
media due to their distribution capabilities, huge install
meet Imation’s exacting standards to protect against
the toughest environmental conditions. Imation CDs
also go through a high-quality dye layer test that
ensures lower failure rates. These discs also feature an
enhanced dye layer for maximum data reliability and
longevity. Available in a variety of options, including
gold, silver, thermal, white printable and neon colors.
Ideal Applications
• Storing digital movies, customizing music mixes
• Saving precious digital photo memories
• Document imaging
• Creating multimedia productions and recordings
• Data exchange
• Computer data backup and archiving
• Storing digital video creations
Applications for CD-R Music
• Music mastering
• Music archiving
• Music duplicating
Imation
CD-R Media
CD-R 52x, CD-R Music, CD-R Mini (80mm) and CD-R Neon
Product UPC Jewel Case Discs/Unit Units/Carton Discs Total
5-Pack Retail 0-51122-17284-2 Standard 5 5 25
10-Pack Retail 0-51122-17332-2 Slim 10 6 60
20-Pack Retail 0-51122-17259-6 Slim 20 4 80
CD-R discs store your data swiftly and permanently with write speeds from 1x–52x, and cannot be erased or overwritten.
Product UPC Jewel Case Discs/Unit Units/Carton Discs Total
25-Pack Spindle Retail 0-51122-17333-9 None 25 8 200
30-Pack Spindle Retail 0-51122-17298-3 None 30 4 120
50-Pack Spindle Retail 0-51122-17301-0 None 50 4 200
100-Pack Spindle Retail 0-51122-17262-6 None 100 2 200
Product UPC Jewel Case Discs/Unit Units/Carton Discs Total
1-Pack Retail 0-51122-17331-6 Standard 1 10 10
1-Pack Retail 0-51122-16627-5 Slim 1 20 20
Product UPC Jewel Case Discs/Unit Units/Carton Discs Total
5-Pack Puck 0-51122-17525-1 None 5 48 240
Standard
50-Pack Spindle 0-51122-17304-2 None 50 4 200
White Inkjet Printable
50-Pack Spindle 0-51122-17300-3 None 50 4 200
Gold Thermal Printable
100-Pack Spindle 0-51122-17274-1 None 100 4 400
White Thermal Printable
100-Pack 0-51122-17276-9 None 100 6 600
Shrink Wrap
Silver Thermal Printable
CD-R Silver
Imation CD-R Media
The same high-performance, high-capacity CD-R media available in five bright neon colors!
Product UPC Jewel Case Discs/Unit Units/Carton Discs Total
10-Pack Retail 0-51122-15794-3 Slim 10 3 30
25-Pack Retail 0-51122-41431-2 Slim 25 2 50
25-Pack 0-51122-01939-5 None 25 4 100
Spindle
50-Pack 0-51122-15808-7 None 50 4 200
Spindle Retail
100-Pack 0-51122-01941-8 None 100 2 200
Spindle Retail
Product UPC Jewel Case Discs/Unit Units/Carton Discs Total
5-Pack Puck 0-51122-17429-2 None 5 48 240
10-Pack Retail 0-51122-41487-9 Pop-Out 10 3 30
25-Pack Retail 0-51122-41486-2 Pop-Out 25 2 50
CD-R Neon
Neon Infusion
(Solid color
on both sides)
These business card shaped CD-Rs are compatible with all standard CD-ROM drives and tray-based CD-R/RW drives, and hold up to 50MB of digital information. Ideal for sales presentations, portfolios, catalogs, Web sites and more.
CD-R Business Card
Product UPC Jewel Case Discs/Unit Units/Carton Discs Total
20-Pack Retail 0-51122-42224-9 None 20 10 200
CD-R Music
CD-R Music discs are especially designed for music lovers who record on digital audio home systems. The recordable digital audio discs can be used to record up to 80 minutes of audio using any recorder bearing the “Compact Disc Audio Recordable” logo.
Product UPC Jewel Case Discs/Unit Units/Carton Discs Total
5-Pack Retail 0-51122-41179-3 Standard 5 5 25
25-Pack 0-51122-17523-4 None 25 4 100
Spindle Retail
Product UPC Jewel Case Discs/Unit Units/Carton Discs Total
5-Pack Neon Retail 0-51122-41482-4 Slim 5 5 25
25-Pack 0-51122-42334-5 None 25 8 200
Retail Spindle
CD-R Mini (80mm)
These tiny CD-Rs can hold up to 202MB of information: 23 minutes uncompressed audio or up to six hours compressed audio formats. For use with standard CD-ROM equipped computers or tray-style CD players.
CD-R 52x CD-R Mini 202MB CD-R Music CD-R Neon
General Information
Capacity
1
700MB/80 minutes 202MB/23 minutes 700MB/80 minutes 700MB/80 minutes
Transfer rate, maximum 6MB/sec 2.4MB/sec 6MB/sec 6MB/sec
Disc Format
International standards CD-audio/IEC 908 CD-audio/IEC 908 CD-audio/IEC 908 CD-audio/IEC 908
CD-ROM/ISO 10149 CD-ROM/ISO 10149 CD-ROM/ISO 10149 CD-ROM/ISO 10149
Orange Book, Part II Orange Book, Part II Orange Book, Part II Orange Book, Part II
Track configuration Spiral Spiral Spiral Spiral
Diameter of user area 44.7mm to 118mm 44.7mm to 78mm 44.7mm to 118mm 44.7mm to 118mm
Track pitch 1.6 +/- 0.1 microns 1.6 +/- 0.1 microns 1.6 +/- 0.1 microns 1.6 +/- 0.1 microns
Direction of rotation CCW (from recording side) CCW (from recording side) CCW (from recording side) CCW (from recording side)
Mechanical
Thickness 1.2mm 1.2mm 1.2mm 1.2mm
Outer dimension 120mm diameter 80mm diameter 120mm diameter 120mm diameter
Center hole diameter 15mm 15mm 15mm 15mm
Material Polycarbonate Polycarbonate Polycarbonate Polycarbonate
Operating Environment
Temperature +5°C to +55°C +5°C to +55°C +5°C to +55°C +5°C to +55°C
Relative Humidity
2
5% to 95% 5% to 95% 5% to 95% 5% to 95%
Storage Environment
Temperature -5°C to +30°C -5°C to +30°C -5°C to +30°C -5°C to +30°C
Relative Humidity
2
5% to 60% 5% to 60% 5% to 60% 5% to 60%
1 Actual storage capacity will vary depending on recording software and hardware used.
2 Maximum wet bulb temperature = 29°C. No condensation of moisture on the disc is permitted.
Specifications subject to change without notice.
Product Specifications
For 50 years, Imation’s Data Storage and Information Management business has been a worldwide leader in developing and
manufacturing a full line of offerings to help its customers manage, store and share data for the desktop and mobile, network
and data center environments. Our diverse portfolio includes the broadest range of removable data storage media and
accessories, including DVD, CD and CD-RW media. With our industry-specific knowledge, experience and proven
problem-solving capabilities, Imation continues to provide the imaginative storage solutions you need.
© Imation Corp 2004 52-0001-5780-1 (Rev. August 2004)
Imation and the Imation logo are trademarks of Imation Corp.
What does it take to make the perfect duplicate? At Imation, we have answers. Our comprehensive line-up of CDs offer solutions for your every need. To ensure proper use, consult the chart below.
Compatibility Guide
Imation Enterprises Corp. 1 Imation Place Oakdale, MN 55128-3414 651 704 4000 888 466 3456 phone 800 5374675 fax www.imation.com info@imation.com
Imation Canada Inc. P.O. Box/C.P. 5440 London, Ontario N6A 5Z6 Canada 888 466 3456 phone
(tél)
888 864 2260 fax
(télec)
Imation Corp. Latin America/ Africa Regional Offices 6205 Blue Lagoon Drive Suite 600 Miami, FL 33126 305 460 7999 phone 305 460 7998 fax
Drives CD Media
CD-R CD-RW CD-ROM CD-R Music
Read ✔✔
Write Read ✔✔
Write Read ✔✔✔✔
Write Read ✔✔ Write ✔✔ Read ✔✔
✔✔
Write ✔✔
Read ✔✔ Write
CD-ROM Drive
CD Audio Drive
Multi-Read Drive
CD-R Drive
CD-RW Drive
Audio CD-Recorder Drive
‡ 1x-4x CD-RW discs are write-compatible with most standard first generation CD-RW drives, or drives featuring the High Speed or Ultra Speed logo.
4x-10x High Speed CD-RW discs are write-compatible only with CD-RW drives featuring the High Speed or Ultra Speed logo. 10x-24x Ultra Speed CD-RW discs are write-compatible only with CD-RW drives featuring the Ultra Speed logo.
NOTE: Newer drives being introduced are becoming more and more compatible with multiple media types. Compatibility depends on drive.
Check with drive manufacturers for compatibility and speed.
