Delivering the Moment
Installaon and Operaon Manual
OBS+OP+5050D / OPSS+OP+D
50/50 Splier / Protecon Switch
Edion B
175-000332-00
Publicaon Informaon
© 2014 Imagine Communicaons Corp. Proprietary and Condenal.
Imagine Communicaons considers this document and its contents to be proprietary and condenal. Except for
making a reasonable number of copies for your own internal use, you may not reproduce this publicaon, or any part
thereof, in any form, by any method, for any purpose, or in any language other than English without the wrien consent
of Imagine Communicaons. All others uses are illegal.
This publicaon is designed to assist in the use of the product as it exists on the date of publicaon of this manual, and
may not reect the product at the current me or an unknown me in the future. This publicaon does not in any way
warrant descripon accuracy or guarantee the use for the product to which it refers. Imagine Communicaons reserves
the right, without noce to make such changes in equipment, design, specicaons, components, or documentaon as
progress may warrant to improve the performance of the product.
Trademarks
6800+™, ADC™, CCS Navigator™, Channel ONE™, ChannelView™, ClipSync™, Delay™, D Series™, D Series DSX™, Deliver
the Moment™, Delivering the Moment™, FAME™, Farad™, G8™, G Scribe™, HView™, IconMaster™, IconLogo™, IconSta
-
on™, IconKey™, InfoCaster™, InfoCaster Creator™, InfoCaster Manager™, InfoCaster Player™, InstantOnline™, Invenio®,
Live Update™, mCAPTURE™, Magellan™, Magellan CCS Navigator™, Magellan Q SEE™, MulService SDN™, NetPlus™,
NetVX™, NewsForce™, Nexio® G8™, Nexio AMP® ChannelView™, Nexio® Channel ONE™, Nexio® ClipSync™, Nexio®
Delay™, Nexio® Digital Turnaround Processor™, Nexio® Farad™, Nexio® G Scribe™, Nexio® IconKey™, Nexio® IconLogo™,
Nexio® IconMaster™, Nexio® IconStaon™, Nexio® InfoCaster™, Nexio® InfoCaster Creator™, Nexio® InfoCaster Manag
-
er™, Nexio® InfoCaster Player™, Nexio® InfoCaster Trac™, Nexio® InstantOnline™, Nexio® mCAPTURE™, Nexio® NewsForce™, Nexio® NXIQ™, Nexio® Playlist™, Nexio® Remote™, Nexio®RTX Net™, Nexio® TitleMoon™, Nexio® TitleOne™,
Nexio® Velocity ESX™, Nexio® Velocity PRX™, Nexio® Velocity XNG™, Nexio® Volt™, OPTO+™, Panacea™, Planum™,
Playlist™, Predator II GRF™, Predator II GX™, Punctuate™, Remote™, RTX Net™, QuiC™, Q SEE™, SD STAR™, Selenio™,
Selenio 6800+™, SelenioNext™, Selenio X50™, Selenio X85™, Selenio X100™, TitleMoon™, TitleOne™, Velocity ESX™,
Velocity PRX™, Velocity XNG™, Versio™, Videotek® SD STAR™, X50™, and X85™ are trademarks of Imagine Communica
-
ons or its subsidiaries.
Altude Express®, Connectus®, Enabling PersonalizedTV®, ICE® Broadcast System, ICE Illustrate®, ICE Q® algorithms, ICE
-
PAC®, Imagine ICE®, Inscriber®, Inscriber® Connectus®, Invenio®, NEO®, Nexio®, Nexio AMP®, PersonalizedTV®, RouterWorks®, Videotek®, Videotek® ASI STAR®, Videotek® GEN STAR®, and Videotek® HD STAR® are registered trademarks of
Imagine Communicaons or its subsidiaries.
Microso® and Windows® are registered trademarks of Microso Corporaon. HD BNC is a trademark of Amphenol
Corporaon. Some products are manufactured under license from Dolby Laboratories. Dolby and the double D symbol
are registered trademarks of Dolby Laboratories. DTS Neural audio products are manufactured under license from DTS
Licensing Limited. DTS and the Symbol are registered trademarks & the DTS Logos are trademarks of DTS, Inc. © 2008
2010 DTS, Inc. All other trademarks and trade names are the property of their respecve companies.
Contact Informaon
Imagine Communicaons has oce locaons around the world. For locaons and contact informaon see:
hp://www.imaginecommunicaons.com/contact us/
Support Contact Informaon
For support contact informaon see:
▪ Support Contacts: hp://www.imaginecommunicaons.com/services/technical support/
▪ eCustomer Portal: hp://support.imaginecommunicaons.com
© 2014 Imagine Communicaons Corp. Proprietary and Condenal
OBS+OP+5050D
50/50 Splitter
OPSS+OP+D
Protection Switch
Installation and Operation Manual
Edition B
March 2007
OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual iii
Contents
Preface
Manual Information .................................................................................v
Revision History ...............................................................................v
Unpacking/Shipping Information ......................................................... vii
References ............................................................................................ viii
Safety Standards and Compliances ........................................................ ix
Chapter 1: Introduction
Product Description ..................................................................................2
Main Features ...................................................................................2
Module Descriptions ................................................................................3
Front Modules ...................................................................................3
Back Modules ...................................................................................4
Typical Fiber Transmission Configurations ............................................5
Signal Flow ..............................................................................................6
Typical Broadcast and Production Applications ......................................6
Chapter 2: Installation
Maximum FR6802+ Frame Power Ratings .............................................8
Unpacking the Module .............................................................................9
Preparing the Product for Installation ...............................................9
Checking the Packing List ................................................................9
Setting the Fiber Input Switch ...............................................................10
Installing and Removing the Modules ...................................................11
Installation Overview ......................................................................11
Back Module Installation ................................................................12
Front Module Installation ...............................................................13
Removing Modules .........................................................................15
iv OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual
Contents
Inspecting and Cleaning Fiber Optic Connections ................................ 16
Important Points ............................................................................. 16
Inspection and Cleaning Procedure ................................................ 18
Chapter 3: Operation
Operation Notes ..................................................................................... 22
Setting Parameters ................................................................................. 22
LEDs and Alarms .................................................................................. 23
LEDs .............................................................................................. 23
Alarms ............................................................................................ 24
Chapter 4: Specifications
Optical Specifications ........................................................................... 26
Power Consumption .............................................................................. 27
Start-Up Time ........................................................................................ 27
Temperature .......................................................................................... 27
Appendix A: Laser Safety Guidelines
Laser Safety ........................................................................................... 30
Precautions for Enclosed Systems ................................................. 30
Precautions for Unenclosed Systems ............................................. 31
Labels .................................................................................................... 32
Index
Keywords .............................................................................................. 33
OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual v
Preface
Manual Information
Purpose
This manual details the features, installation procedures, operational
procedures, and specifications of the OBS+OP+5050D 50/50 splitter
and OPSS+OP+D protection switch.
Audience
This manual is written for engineers, technicians, and operators
responsible for the installation, setup, and operation of the
OBS+OP+5050D 50/50 splitter and OPSS+OP+D protection switch
modules.
Revision History
Table P-1. Manual Revision History
Edition Date Revision History
A February 2007 Initial release
B
March 2007 Revised installation instructions
vi OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual
Preface
Writing Conventions
To enhance your understanding, the authors of this manual have
adhered to the following text conventions:
Obtaining Documents
Technical documents can be viewed or downloaded from our Web site
at
www.broadcast.harris.com/leitch (go to Support > Documentation).
Alternatively, contact your Customer Service representative to request a
document.
Table P-2. Manual Style and Writing Conventions
Term or
Convention
Description
Bold Indicates dialog boxes, property sheets, fields, buttons,
check boxes, list boxes, combo boxes, menus, submenus,
windows, lists, and selection names.
Italics Indicates email addresses, the names of books or
publications, and the first instances of new terms and
specialized words that need emphasis.
CAPS Indicates a specific key on the keyboard, such as ENTER,
TAB, CTRL, ALT, or DELETE.
Code
Indicates variables or command-line entries, such as a
DOS entry or something you type into a field.
> Indicates the direction of navigation through a hierarchy
of menus and windows.
hyperlink Indicates a jump to another location within the electronic
document or elsewhere
Internet address
Indicates a jump to a Web site or URL
NOTE
Indicates important information that helps to avoid and
troubleshoot problems.
OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual vii
Preface
Unpacking/Shipping Information
This product was carefully inspected, tested, and calibrated before
shipment to ensure years of stable and trouble-free service.
1. Check equipment for any visible damage that may have occurred
during transit.
2. Confirm that you have received all items listed on the packing list.
3. Contact your dealer if any item on the packing list is missing.
4. Contact the carrier if any item is damaged.
5. Remove all packaging material from the product and its associated
components before you install the unit.
Keep at least one set of original packaging, in the event that you need to
return a product for servicing.
In the unlikely event that your product fails to operate properly, please
contact Customer Service to obtain a Return Authorization (RA)
number, then send the unit back for servicing.
Keep at least one set of original packaging in the event that a product
needs to be returned for service. If the original package is not available,
you can supply your own packaging as long as it meets the following
criteria:
• The packaging must be able to withstand the product’s weight.
• The product must be held rigid within the packaging.
• There must be at least 2 in. (5 cm) of space between the product and
the container.
• The corners of the product must be protected.
Ship products back to us for servicing prepaid and, if possible, in the
original packaging material. If the product is still within the warranty
period, we will return the product prepaid after servicing.
viii OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual
Preface
References
ITU-T G.695
Optical Interfaces For CWDM (Coarse Wavelength Division
Multiplexing) Applications
ITU-T G.694.2
Spectral Grids for WDM Applications CWDM Wavelength Grid
ITU-T G.652
Characteristics of a Single-Mode Optical Fiber Cable
IEC 61754-4-1
Fiber Optic Connector Interfaces - Part 4-1: Type SC Connector
Family
- Simplified Receptacle SC-PC Connector Interfaces
IEC 60874-14-2
Detail Specification for Fiber Optic Connector Type SC-PC Tuned
Terminated to Single-Mode Fiber Type B1
IEC 60874-14-5
Detail Specification for Fiber Optic Connector Type SC-PC Untuned
Terminated to Single-Mode Fiber Type B1
FCC Code of Federal Regulations (CFR) 47, part 15
EN55103-1
EMC emission requirements applies to professional audio, video,
audio-visual and entertainment lighting control apparatus
EN55103-2
EMC immunity requirements applies to professional audio, video,
audio-visual and entertainment lighting control apparatus
OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual ix
Preface
Safety Standards and Compliances
See “Laser Safety” on page 30 to find the safety standards and
compliances for this OPTO+ series product. A 6800+ series safety
manual is shipped with every FR6802+ Frame Installation and
Operation Manual and can be downloaded from our Web site at
www.broadcast.harris.com/leitch. Alternatively, contact your Customer
Service representative for a copy of this safety manual.
Restriction on Hazardous Substances (RoHS) Directive
Directive 2002/95/EC—commonly known as the European Union (EU)
Restriction on Hazardous Substances (RoHS)—sets limits on the use of
certain substances found in electrical and electronic equipment. The
intent of this legislation is to reduce the amount of hazardous chemicals
that may leach out of landfill sites or otherwise contaminate the
environment during end-of-life recycling. The Directive took effect on
July 1, 2006, and it refers to the following hazardous substances:
• Lead (Pb)
• Mercury (Hg)
• Cadmium (Cd)
• Hexavalent Chromium (Cr-V1)
• Polybrominated Biphenyls (PBB)
• Polybrominated Diphenyl Ethers (PBDE)
According to this EU Directive, all products sold in the European Union
are fully RoHS-compliant and “lead-free.” (See our Web site,
www.broadcast.harris.com/leitch > company > environmental compliance, for more information on dates and deadlines for compliance.)
Spare parts supplied for the repair and upgrade of equipment sold
before July
1, 2006 are exempt from the legislation. Equipment that
complies with the EU directive are marked with a RoHS-compliant
emblem, as shown in
Figure P-1.
Figure P-1. RoHS Compliance Emblem
xOBS+OP+5050D and OPSS+OP+D Installation and Operation Manual
Preface
Waste from Electrical and Electronic Equipment
(WEEE) Directive
The European Union (EU) Directive 2002/96/EC on Waste from
Electrical and Electronic Equipment (WEEE) deals with the collection,
treatment, recovery, and recycling of electrical and electronic waste
products. The objective of the WEEE Directive is to assign the
responsibility for the disposal of associated hazardous waste to either
the producers or users of these products. Effective August 13, 2005,
producers or users are required to recycle electrical and electronic
equipment at end of its useful life, and may not dispose of the
equipment in landfills or by using other unapproved methods. (Some
EU member states may have different deadlines.)
In accordance with this EU Directive, companies selling electric or
electronic devices in the EU will affix labels indicating that such prod
ucts must be properly recycled. (See our Web site at:
www.broadcast.harris.com/leitch > company > environmental
compliance, for more information on dates and deadlines for compli-
ance.) Contact your local sales representative for information on returning these products for recycling. Equipment that complies with the EU
directive is marked with a WEEE-compliant emblem, as shown in
Figure P-2.
Figure P-2. WEEE Compliance Emblem
OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual xi
Preface
Safety Terms and Symbols
This product manual uses the following safety terms and symbols to
identify certain conditions or practices. See
“Laser Safety” on page 30
and the 6800+ Series Safety Instructions and Standards booklet for
more information.
WARNING
CAUTION
Table P-3. Safety Terms and Symbols
Identifies conditions or practices that can result in personal
injury or loss of life—high voltage is present. Uninsulated
dangerous voltage within the product’s enclosure may be
sufficient to constitute a risk of electric shock to persons.
Identifies conditions or practices that can result in damage
to the equipment or other property. Important operating and
maintenance (servicing) instructions are included in the
literature accompanying the product.
xii OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual
Preface
OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual 1
Chapter 1
Introduction
Overview
The OBS+OP+5050D and OPSS+OP+D products are fiber optic
Coarse Wavelength Division Multiplexing (CWDM) modules. The
OBS+OP+5050D is a 50/50 splitter; the OPSS+OP+D is a protection
switch. These products are designed to provide fiber link redundancy
protection.
The following topics are described in this chapter:
• “Product Description” on page 2
• “Module Descriptions” on page 3
• “Typical Fiber Transmission Configurations” on page 5
• “Signal Flow” on page 6
• “Typical Broadcast and Production Applications” on page 6
2OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual
Chapter 1: Introduction
Product Description
In fiber optic video and audio transportation networks, connectivity is
usually protected by feeding signals to both a primary fiber and a
standby or redundant fiber. In the event of link failure, an optical switch
at the receiver end switches from the working fiber to the redundant
protection fiber. The OPSS+OP+D switch provides this protection
either on an automatic basis, or as a manually-set device. The
OPSS+OP+D is protocol transparent and can be used in CWDM
optical networks.
Alternately, the OBS+OP+5050D is a totally passive device that
continually splits 50/50 the primary and standby fiber signals to provide
redundancy protection.
Main Features
These are the main features of the OBS+OP+5050D and OPSS+OP+D
products:
• Intelligent auto-switching and auto-changeover (OPSS+OP+D)
• Programmable switching threshold and changeover hysteresis
(OPSS+OP+D)
• Comprehensive signal and card status monitoring (OPSS+OP+D)
• Single mode fiber support
• Multiple wavelength acceptance (1260 nm to 1610 nm range)
• Standard SMPTE SC/PC optical connectors, supporting ST/PC and
FC/PC available options
1
• Front module hot-swapping capability with no fiber disconnection/
reconnection required
• Protocol transparency, supporting CWDM optical networks
• Capability of supporting single optical wavelengths at 1310 nm,
1550 nm, or up to 16 CWDM wavelengths (ITU-T G.694.2
compliant)
1
Contact your Harris sales representative to order ST/PC and FC/PC options.
OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual 3
Chapter 1: Introduction
Module Descriptions
Front Modules
Figure 1-1 shows the OBS+OP+5050D and OPSS+OP+D front
modules, respectively. These modules cannot be used in FR6800/7000
frames.
Figure 1-1. OBS+OP+5050D and OPSS+OP+D Front Modules
OBS+OP+5050D
OPSS
+OP+D
4OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual
Chapter 1: Introduction
Back Modules
Figure 1-2. OBS+OP+5050D and OPSS+OP+D Back Modules
OBS+OP+5050D
SC/PC in
SC/PC out 1
SC/PC out 2
SC/PC in 1
SC/PC in 2
SC/PC out
OPSS
+OP+D
OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual 5
Chapter 1: Introduction
Typical Fiber Transmission Configurations
Figure 1-3 and Figure 1-4 illustrate typical fiber transmission
configurations for unidirectional and bidirectional systems,
respectively.
Figure 1-3. Unidirectional Transmission System
Figure 1-4. Bidirectional Transmission System
6OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual
Chapter 1: Introduction
Signal Flow
Figure 1-5 shows the signal flow of the OPSS+OP+D module.
Figure 1-5. OPSS+OP+D Signal Flow
Typical Broadcast and Production Applications
OBS+OP+5050D and OPSS+OP+D products can be used in
broadcast, cable, production, educational, and auditorium applications.
Typical applications include sending signals from studios, remote
trucks, or other production facilities to the transmission site/facility.
Other applications include sending signals within one broadcast
organization with buildings remotely located across a large campus area
or across town.
Tap coupler
Tap coupler
Power
detector
Power
detector
Amplifier
Amplifier
A/D
converter
Micro
controller
Frame
communication
Switch
driver
OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual 7
Chapter 2
Installation
Overview
This chapter describes the installation procedure for the
OBS+OP+5050D and OPSS+OP+D modules, and it includes the
following topics:
• “Maximum FR6802+ Frame Power Ratings” on page 8
• “Unpacking the Module” on page 9
• “Setting the Fiber Input Switch” on page 10
• “Installing and Removing the Modules” on page 11
See the FR6802+ Frame Installation and Operation Manual for
information about installing and operating an FR6802+ frame and its
components.
OBS+OP+5050D and OPSS+OP+D modules cannot be installed in a
6800/7000 series frame.
CAUTION
Before installing this product, read the 6800+ Series Safety
Instructions and Standards Manual. This manual is shipped with
every FR6802
+
Frame Installation and Operation Manual, or is
downloadable from our Web site at:
www.broadcast.harris.com/
leitch.
Also see “Appendix A: Laser Safety Guidelines” on page 29 of this
manual.
8OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual
Chapter 2: Installation
Maximum FR6802+ Frame Power Ratings
OBS+OP+5050D and OPSS+OP+D modules operate only in fancooled FR6802+ frames, subject to the limitations shown in
Tabl e 2-1.
These modules cannot be installed in 6800/7000 series frames.
CAUTION
To maintain proper temperatures, ensure that the front panel is
closed at all times, and that the fan module is fully operational.
•0 W (OBS+OP+5050D)
• <2 W (OPSS+OP+D)
Table 2-1. Frame Power Ratings
6800+ Frame
Type
Power
Supply
Max. Frame
Power
Dissipation
Number of
Usable
Slots
*
Max. Power
Dissipation
Per Slot
OBS+OP+50-50D and
OPSS+OP+D
Requirements
FR6802+XF AC 120 W 20 6 W
FR6802+XF48 DC 105 W 20 5.25 W
FR6802+QXF AC or
DC
120 W 20 6 W
* Each front module requires two of these slots. Therefore, to calculate the maximum power dissipation
available per module, double the rating shown in the Max. Power Dissipation Per Slot column.
OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual 9
Chapter 2: Installation
Unpacking the Module
Preparing the Product for Installation
Before you install OBS+OP+5050D and OPSS+OP+D modules,
perform the following:
• Check the equipment for any visible damage that may have
occurred during transit.
• Confirm receipt of all items on the packing list. See “Checking the
Packing List” below for more information.
• Remove the anti-static shipping pouch, if present, and all other
packaging material.
• Retain the original packaging materials for possible re-use.
• Contact your Customer Service representative if parts are missing
or damaged.
See “Unpacking/Shipping Information” on page vii for information
about returning a product for servicing.
Checking the Packing List
• One OBS+OP+5050D front module
• One standard double-slot back module
•One OBS+OP+5050D and OPSS+OP+D
Installation and Operation Manual
•One OPSS+OP+D front module
• One standard double-slot back module
•One OBS+OP+5050D and OPSS+OP+D
Installation and Operation Manual
Table 2-2. OBS+OP+50-50D and OPSS+OP+D Packing List
Ordered Product Content Description
OBS+OP+5050D
OPSS+OP+D
10 OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual
Chapter 2: Installation
Setting the Fiber Input Switch
The OBS+OP+5050D and OPSS+OP+D modules have no jumpers to
set.
On the OPSS+OP+D, a single 3-position switch at the card edge (see
Figure 2-1) locally controls the fiber inputs, or sets the module to
remote control by CCS. The switch provides the following options:
• Port 1 Connected
• Automatic Mode (CCS remote control)
• Port 2 Connected
Figure 2-1. Fiber Input Switch
When you select Port 1 Connected or Port 2 Connected using the
switch, the module accepts the signal as it is received from the
designated port.
When you select Automatic Mode control, CCS control panels and
software are enabled. This makes it possible for you to either use
automatic selection (in which the module selects one of the two inputs,
based on light intensity), or manual selection.
When in automatic mode, the module selects the incoming source based
on the Signal Good Threshold and the Switch Threshold parameter
settings (see
“Setting Parameters” on page 22).
Local input switch
• Port 1 Connected
• Automatic Mode
• Port 2 Connected
OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual 11
Chapter 2: Installation
Installing and Removing the Modules
Installation Overview
Front and back modules in the OPTO+ series have plastic caps that
protect the fragile laser connections from damage. You must remove
these protective covers before you install the back and front modules
(see
Figure 2-2).
In addition, all fiber optic connections must be inspected and cleaned
before they are assembled. Carefully follow the inspection and cleaning
steps described in the next pages. Additional safety information begins
on
page 30.
CAUTION
Ensure that you remove the fiber optic protective covers from the
front and back modules before installation. Take care to avoid
touching the fiber optic connections. Thoroughly clean the
connections before installation. Remove power from the frame
before installing or removing back modules.
Figure 2-2. Protective Covers for Laser Connectors
Remove these protective
covers
Remove these
protective covers
12 OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual
Chapter 2: Installation
Back Module Installation
Follow these steps to install the back module into an FR6802+XF,
FR6802+XF48, or FR6802+QXF frame:
1. Power down the frame.
CAUTION
Although front modules can be hot-swapped, back modules can
only be safely installed or removed when the frame’s power is off.
Ensure the front module has been removed before you install the
back module.
2. Remove a blank back plate from the frame.
Do not discard the blank back plates. They may be needed for
future configurations.
3. On the side of the back module that inserts into the front module,
remove the inner protective cap from the fiber connection (see
Figure 2-2 on page 11).
CAUTION
Microscopic dust or other contaminants can seriously impair or
disable a fiber optic network. Observe strict cleaning procedures.
Do not touch the end of the fiber.
4. Follow the inspection and cleaning procedure that begins on
page 16.
5. Install the new back module by inserting the bottom lip into the
required frame slot, and then screwing it into place.
Ensure that the EMI gaskets on the right side of the back module
remains in place during the installation. The EMI gaskets fit tightly.
6. Apply the adhesive label to the back module if it is supplied
separately.
OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual 13
Chapter 2: Installation
Front Module Installation
OBS+OP+5050D and OPSS+OP+D modules have “locking” latches.
The two modules have similar mechanisms, but their latches face in the
opposite direction.
Figure 2-3 shows the locking latches of the OBS+OP+5050D and
OPSS+OP+D. On the left side of each illustration, the latch is in the
down (locked) position; the locking latch on the right is in the up
(unlocked) position.
Both front modules are hot-swappable and can be installed with the
power supply either turned on, or turned off.
Figure 2-3. Latch Operation
Procedure
Follow these steps to install the front modules:
1. Pull out the finger-release screws on the right and left side of the
front panel of the frame, and then open it.
2. Locate the front module slot that corresponds with the matching
back module.
Down (locked)
position
Up (unlocked)
position
OBS+OP+5050D
OPSS+OP+D
Down (locked)
position
Up (unlocked)
position
14 OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual
Chapter 2: Installation
3. Gently remove the outer and inner protective caps from the laser
connections. (see Figure 2-2 on page 11).
CAUTION
Microscopic dust or other contaminants can seriously impair or
disable a fiber optic network. Observe strict cleaning procedures.
Do not touch the end of the fiber.
4. Follow the fiber cleaning instructions that begin on page 16.
5. Ensure that your front module matches with a corresponding back
module of the same name.
6. With the locking latch in the up position, slide the module into the
guides on the frame floor.
7. When the module edge is flush with the guide, close the extractor
handle, and then slide the locking latch into the down position.
The module is properly seated when its edge is flush with the guide
edge and the extractor handle closes.
8. Close the front panel to ensure proper frame ventilation.
To prevent overheating, keep the front panel closed and all back
module plate slots covered during operation.
OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual 15
Chapter 2: Installation
Removing Modules
NOTE
The removal steps provided here are similar to those outlined in
your FR6802
+
Frame Installation and Operation Manual. Refer to
that manual for detailed information about installing and operating
an FR6802+ frame and its components.
Front Module
Follow these steps to remove a front module from an FR6802+ frame:
1. Pull out the finger-release screws on the right and left side of the
front panel of the frame, and then open it.
2. On the front module, pull the locking latch knob to the right (on the
OBS+OP+5050D) or to the left (on the OPSS+OP+D) to release
the module.
The latch should easily slide to its up, released position.
3. Grasp the extractor handle on the installed module, and then pull
the module out of its slot; use the handle as a lever.
4. Close the front panel to ensure proper frame ventilation.
Back Module
Follow these steps to remove a back module from an FR6802+ frame:
1. Turn off the frame.
2. Remove the front module, as described above.
CAUTION
Although front modules can be hot-swapped, back modules can
only be safely installed or removed when the frame’s power is off.
Always remove the front module before the back module.
3. Unscrew the top of the corresponding back module, and then tip it
towards you.
4. Pull the bottom lip of the back module from its slot.
5. Reinstall a new or blank back plate in the empty slot to ensure
proper frame ventilation.
6. Reinstall the front module and then repower the frame.
16 OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual
Chapter 2: Installation
Inspecting and Cleaning Fiber Optic
Connections
Small amounts of microscopic dust or other contaminants can seriously
impair or disable a fiber optic network. To ensure that your network
operates reliably, you must carefully inspect and clean each connection
when installing OPTO+ products.
Tabl e 2-3 lists some typical contaminants of a fiber optic connection.
The inspection and cleaning procedure begins on page 18.
Important Points
• Before you begin cleaning, always inspect the fiber connections.
• Inspect and clean both fiber ends every time you make a
connection.
• Keep a protective cap on unplugged fiber connectors.
• Do not touch the end of a fiber.
• Store unused protective caps in a clean resealable container, located
nearby for easy access.
• Do not reuse cleaning tissues or swabs.
• Do not allow alcohol or another wet cleaning agent to dry on a fiber
end.
Table 2-3. Typical Contaminants
Contaminant Comments
Dust particle, 1 micron Can block up to 1% of the light transmission,
creating a loss of 0.05 dB
Dust particle, 9 microns Although microscopic, the particle can completely
block the fiber core
Human hair Typically 50 to 75 microns in diameter
Oil Frequently caused by touching
Film residues Can accumulate from vapors or smoke
Powdery coatings Can be left behind after water or other solvents
evaporate
OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual 17
Chapter 2: Installation
• Never touch the dispenser tip of an alcohol bottle or any clean
portion of a tissue or swab.
• Use care when handling the fiber; do not twist or pull.
• Keep your cleaning fluids away from open flame or spark.
Figure 2-4 describes the acceptable limits of defects in a fiber
connection.
Figure 2-4. Fiber Optic Cross-Section
Zone 2
(20 to 50 micron diameter)
Maximum of 3 scratches <1.0 micron width is acceptable;
Maximum 1.0 micron dig is acceptable
Zone 1
(0 to 20 micron diameter)
No scratches or digs are allowed
Zone 3
(50 to 126 micron diameter)
Maximum 25 micron dig is acceptable;
Maximum scratch size of 1.0 micron is acceptable
Maximum 25 micron diameter dig is acceptable
Scratches and dust
18 OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual
Chapter 2: Installation
Inspection and Cleaning Procedure
Inspection
To inspect and clean the fibers, follow these steps:
1. Ensure the fiber is not “live.”
WARNING
Eye damage may occur if an optical instrument such as a
microscope, magnifying glass, or eye loupe is used to stare at an
energized fiber end.
2. Inspect the fiber endface with a fiberscope.
3. If the fiber endface is clean, return to the installation instructions on
page 12 (for the back module) or page 13 (for the front module).
If the connector is dirty, proceed to the dry cleaning instructions
below.
Dry Cleaning
If you are using cartridge or pocket-style dry cleaning tools, follow the
manufacturer’s directions. If you are using lint-free wipes, follow these
steps:
1. Fold the lint-free wipe four to eight times into a square, taking care
to avoid touching the cleaning surface of the wipe.
2. Lightly wipe the fiber tip in the central portion of the lint-free wipe.
CAUTION
Do not scrub the fiber. Excessive rubbing will leave scratches.
3. Repeat the wiping action on another clean section of the wipe or a
new wipe.
4. Inspect the connector again with the fiberscope.
5. If the connection is clean, return to the installation steps on page 12
(for the back module) or page 13 (for the front module).
If the connector is still dirty, proceed to the wet cleaning
instructions.
OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual 19
Chapter 2: Installation
Wet Cleaning
Using 99% isopropyl alcohol and lint-free wipes, follow these steps to
wet clean the fiber:
1. Fold the wipe into a square, about 4 to 8 layers thick.
2. Moisten one section of the lint-free wipe with one drop of 99%
alcohol, ensuring that a portion of the wipe remains dry.
3. Lightly wipe the fiber end in the alcohol-moistened portion of the
lint-free wipe.
4. Immediately repeat the wiping action on the dry section of the
wipe, removing any residual alcohol.
5. Inspect the fiber endface again, and if necessary, repeat the wet
cleaning with another clean section of the lint-free wipe.
CAUTION
Do not scrub the fiber. Excessive rubbing will leave scratches.
6. Dry clean any remaining residue and then inspect the connector
again.
7. If the contamination persists, repeat the dry and wet cleaning
procedure until the endface is clean.
If the fiber end still remains dirty after repeated cleaning attempts,
call Customer Service for further instructions.
If the fiber end is clean, return to the installation instructions on
page 12 (for the back module) or page 13 (for the front module).
20 OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual
Chapter 2: Installation
OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual 21
Chapter 3
Operation
Overview
This chapter describes how to operate OBS+OP+5050D and
OPSS+OP+D modules. See the following documents for information
on how to operate this product remotely:
• +Pilot Lite™ User Manual for serial control interface
• Installation and Operation Manuals for CCS™ Navigator™,
Pilot™, CoPilot™, NUCLEUS™, or other CCS-enabled control
products
The following topics are discussed in this chapter:
• “Operation Notes” on page 22
• “Setting Parameters” on page 22
• “LEDs and Alarms” on page 23
22 OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual
Chapter 3: Operation
Operation Notes
When changing the control parameters on the modules, the effect is
immediate. However, the module requires up to 20 seconds to save the
latest change. After 20 seconds, the new settings are saved and will be
restored if the module loses power and must be restarted.
Setting Parameters
On the OPSS+OP+D, the fiber input switch provides the only
card-edge control (see
“Setting the Fiber Input Switch” on page 10). No
card-edge controls are available on the OBS+OP+5050D module.
Tabl e 3-1 lists the parameters that are accessible using CCS-enabled
software applications and control panels. An asterisk (*) indicates the
default value or option. Parameters with the symbol [RO] are read-only.
• Forced
• Remote
• Manual
• Auto *
• Channel 1
• Channel 2
Table 3-1. OPSS+OP+D CCS Parameters
Parameter Name Function Options or Range
Switch Control [RO] Reads the status of the card-edge switch
Remote Switch Mode Sets the mode of the remote switch
Switch Position Selects the channel source input
(no default setting)
Signal Good Threshold Sets the threshold for an acceptable input signal level -40 to +25 dBm
(*-20 dBm)
Switch Threshold Sets the size of the difference between the two input
signal levels as the trigger for switching channels (the
module must be set to Auto in the Remote Switch
Mode)
1 to 16 dBm
(*2 dBm)
Channel 1 Power [RO] Monitors the power of input channel 1 -41 dBm to +25 dBm
Channel 2 Power [RO] Monitors the power of input channel 2 -41 dBm to +25 dBm
OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual 23
Chapter 3: Operation
LEDs and Alarms
LEDs
As shown in Figure 3-1, the OPSS+OP+D module displays the
following card-edge LEDs:
•Power
•Link Down
• Port 1 OK
• Port 2 OK
• Local Mode
• Port 1 Connected
• Port 2 Connected
Tabl e 3-2 on page 24 describes the meanings of these LEDs.
The OBS+OP+5050D module does not have card-edge LEDs.
Figure 3-1. OPSS+OP+D Card-Edge LEDs
Card-edge
LEDs
24 OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual
Chapter 3: Operation
Alarms
The OPSS+OP+D has two major alarms, both of which are only visible
in CCS-enabled control panels and software:
• Signal Loss in Current Channel
• Signal Loss in Both Channels
Either of these alarms will trigger the Link Down LED on the module’s
card-edge.
The OBS+OP+5050D module does not trigger alarms.
Table 3-2. OPSS+OP+D LEDs and Their Meanings
LED Color Meaning
Power Green The module is receiving power from the frame’s power supply.
None The module is not receiving power from the frame’s power supply.
Link Down
(Alarm)
Yellow The module output is below the threshold set for an acceptable signal (the
module may continue to function with low laser intensity levels).
None The module output is valid, according to the Signal Good Threshold parameter
setting.
Port 1 OK Green The Fiber 1 input signal is valid, according to the Signal Good Threshold
parameter setting (but may not be the selected source).
None The Fiber 1 input signal is below the acceptable threshold value.
Port 2 OK Green The Fiber 2 input signal is valid, according to the Signal Good Threshold
parameter setting (but may not be the selected source).
None The Fiber 2 input signal is below the acceptable threshold value.
Local Mode Green The module input switch is set to local control.
None The module input is under CCS network control.
Port 1
Connected
[RO]
Green The module is passing the Port 1 input to the output.
None The module is not passing the Port 1 input to the output.
Port 2
Connected
[RO]
Green The module is passing the Port 2 input to the output.
None The module is not passing the Port 2 input to the output .
OBS+OP+5050D and OPSS+OP+DInstallation and Operation Manual 25
Chapter 4
Specifications
Overview
The following specification information appears in this chapter:
• “Optical Specifications” on page 26
• “Power Consumption” on page 27
• “Start-Up Time” on page 27
• “Temperature” on page 27
Specifications and designs are subject to change without notice.
26 OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual
Chapter 4: Specifications
Optical Specifications
Table 4-1. OPSS+OP+D Optical Specifications
Item Specification
Number of inputs 2
Number of outputs 1
Operation wavelength 1260 nm to 1620 nm
Switch time <15 ms
Optical back reflection <–35 dB
Insertion loss <1.5 dB
Maximum input optical power <25 dBm
Minimal input optical power >–41 dBm
Absolute reported power error ± 3 dB
Reported relative power error of two
inputs
± 1 dB
Table 4-2. OBS+OP+5050D Optical Specifications
Item Specification
Number of inputs 1
Number of outputs 2
Operation wavelength 1260 nm to 1620 nm
Optical back reflection <–35 dB
Insertion loss 4 dB (typical)
Maximum input optical power <25 dBm
OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual 27
Chapter 4: Specifications
Power Consumption
Power consumption for the OPSS+OP+D module is less than 2 W. The
OBS+OP+5050D requires no power.
Start-Up Time
The start-up time for the OPSS+OP+D is approximately 10 seconds;
the OBS+OP+5050D requires no start-up time.
Temperature
Table 4-3. Temperature Specifications
Item Specification
Operating temperature 14° to 122°F (-10° to 50°C)
Performance temperature
(temperature at which
specifications are guaranteed)
32° to 104° F (0° to 40°C)
28 OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual
Chapter 4: Specifications
OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual 29
Appendix A
Laser Safety Guidelines
Overview
This section describes important safety considerations when using laser
modules.
The following topics are included:
• “Laser Safety” on page 30
• “Labels” on page 32
30 OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual
Appendix A: Laser Safety Guidelines
Laser Safety
WARNING
Use of controls, adjustments, and procedures other than those
specified in this document may result in hazardous laser radiation
exposure.
Optical fiber telecommunication systems use semiconductor laser
transmitters that emit infrared light that is normally not visible to the
human eye. Although a conventional laser produces a small beam of
light, the power density is very high, and it can cause damage to your
eyes.
If a beam of laser light enters the eye, the eye magnifies and focuses the
energy on the retina. The energy that reaches the retina can be as much
as 100,000 times more than at the cornea and, as a result, it can burn the
retina.
Laser transmission products are classified in four major groups (Class
1, 2, 3, and 4), according to their emissions and potential for causing
injury. Fiber optic transmitter modules in the OPTO+ series are
designated Class 1.
Precautions for Enclosed Systems
In its normal operating mode, an optical fiber communication system is
totally enclosed and presents no risk of eye injury. However, if the fiber
optic cables that interconnect various components of an optical fiber
disconnect or break, you may be exposed to laser emissions. Also,
technicians may be exposed to laser emissions during installation and
servicing.
Unlike some other laser designs, semiconductor lasers have a highly
divergent beam that decreases rapidly with distance. The greater the
distance, the less energy will enter the eye, and the less potential risk for
eye injury.
WARNING
Eye damage may occur if an optical instrument such as a
microscope, magnifying glass, or eye loupe is used to stare at the
energized fiber end.
OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual 31
Appendix A: Laser Safety Guidelines
Under normal operating conditions, optical fiber telecommunication
systems are completely enclosed; nonetheless, observe the following
precautions:
• Do not stare into optical connectors or broken fibers.
• Ensure technicians have satisfactorily completed an approved
training course before performing installation or maintenance.
• Ensure there are appropriate warning labels near the optical ports of
the modules.
Precautions for Unenclosed Systems
During service, maintenance, or restoration, an optical fiber
telecommunication system is considered unenclosed. Under these
conditions, follow these practices:
• Avoid exposing the eye to emissions from unterminated, energized
optical connectors at close distances.
• Ensure that only authorized, trained personnel use optical test
equipment during installation or servicing.
• Turn off all laser sources before scanning a fiber with an optical test
set.
• Keep all unauthorized personnel away from the immediate area of
the optical fiber systems during installation and service.
CAUTION
Only authorized, trained personnel shall be permitted to do service,
maintenance, and restoration.
For guidance on the safe use of optical fiber communication systems in
the workplace, consult ANSI Z136.2, American National Standard for
Safe Use of Lasers in the United States. Outside the U.S., IEC-60825,
Part 2 applies.
32 OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual
Appendix A: Laser Safety Guidelines
Labels
The label shown in Figure A-1 is applicable to Class 1 laser products.
Figure A-1. Label for Class 1 Laser Products
CLASS 1 LASER PRODUCT
IEC 60825-1:1993 + A1:1997 + A2:2001
CAUTION: INVISIBLE LASER RADIATION WHEN OPEN.
AVOID EXPOSURE TO THE BEAM.
OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual 33
Index
Keywords
A
Alarms 24
B
Back modules 4, 12, 15
Bidirectional transmission system 5
Block diagram 6
C
Cleaning an optical fiber 16–19
F
Features list 2
Fiber input switch 10
Front modules 3, 13–15
I
Input switch 10
Inspecting and cleaning an optical fiber 16–19
Installing a module 7–19
J
Jumper information 10
L
Laser precautions 11–14, 29–32
LEDs 23–24
Locking latches 13–15
M
Manual revision history v
Manual writing conventions vi
Modules
back 4, 12, 15
front 3, 13–15
installation 7–19
removal 15
O
Operation notes 22
P
Packing list 9
Parameters 22
Power consumption specifications 27
Power ratings 8
R
Removing a module 15
Revision history of manual v
RoHS directive ix
S
Safety
standards and compliances ix
symbols and terms xi
with lasers 30–32
Setting jumpers 10
Setting parameters 22
34 OBS+OP+5050D and OPSS+OP+D Installation and Operation Manual
Index
Shipping information vii
Signal flow diagram 6
Specifications 26–27
T
Transmission configurations 5
U
Unidirectional transmission system 5
Unpacking information vii, 9
W
Warranty information ii
WEEE directive x
Writing conventions of manual vi
