Ilsco CLNU-2 Data sheet
SureCrimp
Copper Compression Lugs
®
500kcmil
453G
L
1
R
0
-
2
6
9
TYPE
CLNU
Catalog Wire Alt Expanded* Color Die
Number Size Wire Size Wire Range A B D Code Index O.D. I.D.
CLNU-6 6 AWG #6 FLEX, #6 SOL - 3.000 1.130 0.760 Blue I-24 0.320 0.225
CLNU-4 4 AWG #4 SOL 4-6 AWG 3.000 1.130 0.760 White I-29 0.343 0.250
CLNU-3 3 AWG #4 FLEX 3-6 AWG 3.000 1.130 0.750 White I-29 0.375 0.275
CLNU-2 2 AWG #2 SOL 2-6 AWG 3.000 1.130 0.740 Brown I-33 0.421 0.312
CLNU-1 1 AWG #2 FLEX 1-6 AWG 3.000 1.380 0.740 Green I-37 0.468 0.359
CLNU-1/0 1/0 AWG #1 FLEX 1/0-6 AWG 3.000 1.500 0.740 Pink I-42 0.515 0.390
CLNU-2/0 2/0 AWG 1/0 FLEX 2/0-4 AWG 3.000 1.500 0.810 Black I-45 0.562 0.437
CLNU-3/0 3/0 AWG 2/0 FLEX 3/0-2 AWG 3.000 1.500 0.890 Orange I-50 0.609 0.484
CLNU-4/0 4/0 AWG 3/0 FLEX 4/0-1 AWG 3.000 1.500 1.000 Purple I-54 0.687 0.546
CLNU-250 250kcmil 4/0 FLEX 250kcmil-1/0 AWG 3.000 1.690 1.090 Yellow I-62 0.750 0.593
CLNU-300 300kcmil 250 G,H FLEX 300kcmil-2/0 AWG 3.000 2.000 1.190 White I-66 0.812 0.660
CLNU-350 350kcmil
CLNU-400 400kcmil
CLNU-500 500kcmil
CLNU-600 600kcmil
CLNU-650 650kcmil
CLNU-700 700kcmil
CLNU-750 750kcmil
CLNU-1000 1000kcmil
All wire sizes, unless noted otherwise, are American Wire Gauge (AWG)
* When installed with specified dieless tools
+ See pages 87 to 93 for complete tooling information.
For Bent Tangs add “-4” for 45 deg. or “-9” for 90 deg.
UL File E6207
Features
Manufactured from high strength seamless copper tubing
•
Electro-Tin plated
•
Chamfered entry
•
Color coded
•
Suitable for use in circuits rated 35KV or less, proper high
•
voltage spacing and insulation techniques must be used
UL Listed and CSA Certified with ILSCO and major
•
competitor’s compression tools
UL467 Listed 500 kcmil - 8 AWG , #8 - #2 SOL
•
Rated to 90˚ C
•
250 I,K,M FLEX
262.2 DLO
300 G,H,I,K,M FLEX
313.1 DLO
350 G,H,I,K,M FLEX
373.7 DLO
400 G,H,I,K,M FLEX
444.4 DLO
500 G,H,I,K,M FLEX
535.3 DLO
500 G,H,I,K,M FLEX
535.3 DLO
600 G,H,I,M FLEX
646.4 DLO
750 G,H,I FLEX
777.7 DLO
350kcmil-3/0 AWG 3.000 2.000 1.290 Red I-71 0.890 0.703
400kcmil-4/0 AWG 3.000 2.130 1.370 Blue I-76 0.937 0.750
500kcmil-250kcmil 3.000 2.250 1.530 Brown I-87 1.062 0.828
600kcmil-250kcmil 3.000 2.690 1.710 Green I-94 1.187 0.920
650kcmil-350kcmil 3.000 2.690 1.760 Pink I-99 1.217 0.958
700kcmil-350kcmil 3.000 2.690 1.820 Pink I-99 1.250 0.991
750kcmil-500kcmil 3.000 2.880 1.900 Black I-106 1.313 1.031
1000kcmil-750kcmil 3.000 3.000 2.170 White I-125 1.500 1.172
Benefits
Offers maximum conductivity and excellent crimping characteristics
•
Provides low contact resistance
•
For easy conductor insertion
•
Identifies the proper compression die
•
Application versatility
•
Reduces inventory requirements
•
For grounding and bonding applications
•
Dimensions
Die
A
