Page 1
USER’S GUIDE
V:1242-0406-11
For the most up-to-date version of this User’s Guide, go to www.ilive.net
ITP231B
2.1 Speaker Bar for Any TV
Page 2
iLive2
WARNING: Lithium batteries, like all rechargeable batteries
are recyclable and should be recycled or disposed of in
normal household waste. Contact your local government
for disposal or recycling practices in your area. They should
never be incinerated since they might explode.
WARNING: Shock hazard - Do Not Open.
AVIS: RISQUE DE CHOC ÉLECTRIQUE - NE PAS OUVRIR
Mains Plug or Direct plug-in adapter is used as disconnect
device and it should remain readily operable during
intended use. In order to disconnect the apparatus from the
mains completely, the Mains Plug or Direct plug-in adapter
should be disconnected from the mains socket outlet
completely.
La che d’alimentation ou adaptateur de courant est utilisé
comme dispositif de déconnexion et doit rester accessible
pendant l’utilisation. Pour mettre l’appareil hors tension, la
che ou adaptateur de courant doit être débranché de la prise
de courant.
Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc), or rechargeable
(ni-cad, ni-mh, etc) batteries.
No mezcle baterías viejas y nuevas.
No mezcle baterías alcalinas, estándar (carbono-zinc) o
recargables (ni-cad, ni-mh, etc.).
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE
BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
WARNING: To reduce the risk of re or electric shock, do
not expose this apparatus to rain or moisture.
AVERTISSEMENT: Pour réduire le risque d’incendie ou de
choc électrique, ne pas exposer cet appareil sous la pluie et
l’humidité.
CAUTION: Use of any controls or adjustments or
performance of procedures other than those herein
specied may result in hazardous radiation exposure.
WARNING: Changes or modications to this unit not
expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
WARNING: Do not place the unit on top of any soft, porous,
or sensitive surfaces to avoid damaging the surface. Use a
protective barrier between the unit and surface to protect
the surface.
WARNING: Use of this unit near uorescent lighting may
cause interference regarding use of the remote. If the unit is
displaying erratic behavior move away from any uorescent
lighting, as it may be the cause.
CAUTION: Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent type.
PRÉCAUTION: Danger d’explosion si les piles sont remplacées
de façon incorrect. Remplacer les piles seulement par le même
type de pile ou l’équivalent.
WARNING: There is a danger of explosion if you attempt
to charge standard Alkaline batteries in the unit. Only use
rechargeable NiMH batteries.
WARNING: The battery, batteries, and battery pack shall
not be exposed to excessive heat such as sunshine, re, or
the like.
The lightning ash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of
sufcient magnitude to constitute a risk of electric
shock to persons.
WARNING: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USERSERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
ATTENTION
RISQUE D' ÉLECTROCUTION
NE PAS OUVRIR
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
Warnings and Precautions
Page 3
Customer Support: 1-888-999-4215 iLive 3
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualied service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally,
or has been dropped.
1. Read these Instructions.
2. Keep these Instructions.
3. Heed all Warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding - type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety.
When the provided plug does not t into your outlet,
consult an electrician for replacement of the obsolete
outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11. Only use attachments/accessories specied by the
manufacturer.
12.
This symbol indicates that this product
incorporates double insulation between
hazardous mains voltage and user
accessible parts.
Use only with a cart, stand, tripod,
bracket, or table specied by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
Important Safety Instructions
Special note: When placing your unit on a lacquered or
natural nish, protect your furniture with a cloth or other
protective material.
WARNING: Changes or modications to this unit not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
The apparatus shall not be exposed to dripping or
splashing and that no objects lled with liquids, such as
vases, shall be placed on apparatus.
L’appareil ne doit pas être exposé aux écoulements ou aux
éclaboussures et aucun objet ne contenant de liquide, tel
qu’un vase, ne doit être placé sur l’objet.
Battery shall not be exposed to excessive heat such as
sunshine, re or the like.
Les piles ne doivent pas être exposées à de forte chaleur,
tel qu’à la lumière du soleil, au feu ou autres choses de
semblable.
Caution marking is located at the rear or back of the
apparatus.
Attention marquage est situé à l’arrière ou à l’arrière de
l’appareil
The marking information is located at the rear or back of
apparatus.
Les informations de marquage est situé à l’arrière ou à
l’arrière de l’appareil.
FCC Warnings
Additional Warnings
Page 4
iLive4
2.1 Speaker Bar for Any TV
• Powered 2.1 channel
speaker system with built-in
subwoofer
• Motorized dock plays &
charges iPod & iPhone
• FM radio with 20 station
presets
• RCA audio input
• 3.5mm Audio Input
• Composite video input
• Composite video output
• Component video output
• Subwoofer output
• Advanced remote control
• 37” length
• Wall mountable
• Treble & bass controls
• 5 EQ presets
• Digital clock
• Wake to iPod/iPhone or radio
• Gradual wake
• Sleep timer
• AC power: built-in AC power
cord
• Remote control: requires 2
AAA batteries (included)
• Docking brackets for iPhone/
iPod (5)
• AV cable (RCA)
• Wall-mount hardware
Features
Includes
Setup
AC power: built-in AC power cable Requires 2 AAA batteries (included)
Power Remote
Page 5
Customer Support: 1-888-999-4215 iLive 5
Table of Contents
Warnings and Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.1 Speaker Bar for Any TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
iPod and iPhone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
FM Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Clock, Alarm, and Sleep Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Audio Inputs and Subwoofer Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Basic Connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Video Inputs and Video Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Mounting to a Wall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Company Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Page 6
iLive6
POWER
Press to turn the bar
speaker o or on.
VOLUME
Press to adjust the volume.
SOURCE
Press to switch between iPod,
Tuner, Line, and AV modes.
PLAY/PAUSE
Press to play or pause a
docked iPhone or iPod.
iPod DRAWER
Press to open and close the
iPod docking drawer.
LINE INPUT (3.5mm)
Use to connect an MP3
player or other audio source
to the bar speaker.
RCA AUDIO INPUT
AC POWER CABLE
RESET
Press using a paperclip or like
object to reset the bar speaker to
it’s original settings.
FM ANTENNA
SUBWOOFER
OUTPUT
COMPOSITE
VIDEO INPUT
COMPOSITE
VIDEO
OUTPUT
COMPONENT
VIDEO
OUTPUT
Introduction
Page 7
Customer Support: 1-888-999-4215 iLive 7
VIDEO
MUTE
Press to mute the volume.
ALARM
With the power o, press to
set the alarm.
CLOCK
With the power o, press to
set the clock.
SLEEP
Press repeatedly to set the
sleep timer.
VIDEO
Press to switch between
Component and Composite
video output modes.
BASS
With the EQ set to FLAT, press
to adjust the levels of bass.
REV/FWD/MIN/HR
Press to rewind or fast
forward a docked iPhone or
iPod. Press to adjust the hour
and minute when setting the
clock or alarm.
MENU
Press skip through menus on
a docked iPhone or iPod.
TUN/SKIP
Press to skip between tracks
on a docked iPhone or iPod.
Press to tune the radio.
ALBUM/CHAPTER/PLAYLIST
Press to skip through albums,
chapters, or playlists on a
docked iPhone or iPod.
SOURCE
Press to switch between iPod,
Tuner, Line, and AV modes.
NUMBER KEYPAD
REPEAT
Press to repeat a single track
or entire album on a docked
iPhone or iPod.
TREBLE
With the EQ set to FLAT, press
to adjust the levels of treble.
MENU UP/DN
Press to navigate up and
down in menus on a docked
iPhone or iPod.
SELECT
Press to make selections on a
docked iPhone or iPod.
SHUFFLE
Press to play songs from a
docked iPhone or iPod in a
random order.
EQ
Press to adjust the EQ.
VOLUME
Press to adjust the volume.
PLAY/PAUSE
Press to play or pause a
docked iPhone or iPod.
STOP
Press to stop a docked iPhone
or iPod during play.
MEMORY
Press to cycle through saved
radio stations.
iPod
Press to switch to iPhone/
iPod mode.
STANDBY/ON
Press to turn the bar
speaker o or on.
DISPLAY
Press to view the clock on
the display.
iPod DRAWER
Press to open or close
the motorized dock for
iPhone/iPod.
MEM
Press to save a radio
station to the bar
speaker’s memory.
Page 8
iLive8
iPod and iPhone
FM Radio
1. Press the POWER button to
turn the bar speaker on.
2. Press the SOURCE button (iPod button on
the remote) to switch to iPhone/iPod mode.
3. Press the iPod DRAWER button to open the
MOTORIZED DOCK FOR iPhone/iPod
4. Locate the numbered bracket that ts the
iPhone/iPod model that will be docked.
Each included bracket has a number on it,
indicating which iPhone/iPod model that bracket
is compatible with. See the separate bracket
chart page to identify which bracket is needed.
5. Snap the bracket into place over the iPhone/
iPod connector in the motorized dock.
6. Connect the iPhone or iPod to the connector
inside the Dock for iPhone/iPod.
When the speaker is plugged in, using AC power,
the docked iPhone or iPod will charge.
After docking an iPod or iPhone, the bar speaker will
automatically switch to composite video output mode.
1. Follow the instructions for Docking an iPod or
iPhone.
2. Press the PLAY/PAUSE button to begin playing
music from the docked iPhone or iPod.
Adjust the built-in FM Wire Antenna to improve FM
radio reception.
1. Press the POWER button to
turn the bar speaker on.
2. Press the SOURCE button to
switch to Tuner mode.
3. Press the TUN/SKIP buttons on the
remote to tune the FM radio.
1. Follow the instructions for
Saving a Radio Station.
2. Press the MEMORY buttons on the remote
to cycle through saved radio stations.
1. Follow the instructions for Tuning the FM Radio.
2. After tuning to the desired station,
press the MEM button.
3. Press the MENU UP or MENU DN buttons
on the remote to select a preset.
4. Press the MEM button to save the current
radio station to the selected preset.
Up to 20 stations can be saved to
the bar speaker’s memory.
Docking an iPod or iPhone
Playing a Docked iPod or iPhone
FM Antenna
Tuning the FM Radio
Listening to a Saved Radio Station
Saving a Radio Station
Page 9
Customer Support: 1-888-999-4215 iLive 9
Clock, Alarm, and Sleep Timer
1. Press the POWER button to turn the power o.
2. Press the CLOCK button on the remote control.
3. The time on the display will begin blinking.
4. Press the REV/MIN and FWD/HR buttons on the
remote to adjust the minute and hour.
5. Wait 5 seconds to nish setting the clock.
1. Press the POWER button to turn the power on.
2. Press the SOURCE button on the bar speaker to
switch to the desired sleep timer source.
3. Press the SLEEP button repeatedly to set the
sleep timer.
4. After the set sleep time has expired, the bar
speaker will automatically power o.
1. Press the POWER button to turn the power on.
2. Adjust the volume to the desired level.
3. Press the POWER button to turn the power o.
4. Press the ALARM button on the remote control.
5. The alarm time on the display will begin blinking.
6. Press the REV/MIN and FWD/HR buttons on the
remote to adjust the minute and hour.
7. Press the SOURCE button on the bar speaker to
switch to the desired alarm source.
8. Wait 5 seconds to nish setting the alarm.
9. ALARM will appear on the display when the
alarm is set.
10. Press the ALARM button to cancel the alarm.
Setting the Clock
Setting the Sleep Timer
Setting the Alarm
Audio Inputs and Subwoofer Output
1. Connect a 3.5mm Audio Input cable (not
included) to the 3.5MM AUDIO INPUT on the
bar speaker and an audio source.
2. Press the POWER button to turn the bar speaker
on.
3. Press the SOURCE button to switch to LINE
mode.
4. Use the native controls on the connected audio
device to begin playing music through the
connected bar speaker.
1. Use an RCA cable (included) to connect an
external subwoofer to the SUBWOOFER
OUTPUT.
2. When audio is played through any source, the
bar speaker will automatically use the connected
subwoofer.
1. Connect an RCA cable (included) to the
AUXILIARY INPUTS on the bar speaker and an
audio source.
2. Press the POWER button to turn the bar speaker
on.
3. Press the SOURCE button to switch to AV mode.
4. Use the native controls on the connected audio
device to begin playing music through the
connected bar speaker.
Using the 3.5mm Audio Input Using the Subwoofer Output
Using the RCA Audio Input
Page 10
iLive10
DVD PLAYER
DIGITAL CABLE or SATELLITE TUNER
VCR
GAMING CONSOLE
SUBWOOFER TELEVISION
Basic Connectivity
This is a basic ow chart of how
you can connect your home
entertainment devices to the
bar speaker, and in turn how
the bar speaker connects to
them.
For optimal performance, always
connect video sources such as a
DVD players, gaming consoles
or set-top boxes directly to your
television.
Video Inputs and Video Output
For optimal performance, always connect video
sources such as a DVD players, gaming consoles
or set-top boxes directly to your television.
1. Connect an RCA cable (included) to the
COMPOSITE VIDEO INPUT and a video source.
2. Follow the instructions for Using a
Composite Video Output or Using
the Component Video Output
3. Press the POWER button to
turn the bar speaker on.
4. Press the VIDEO button on the remote
to switch between Composite and
Component video output modes.
5. Use the native controls on the connected
video device to control video that
runs through the bar speaker.
1. Connect an RCA cable (included) to the
COMPOSITE VIDEO OUTPUT and a television.
2. Adjust the connected television
to the proper input setting.
3. Press the VIDEO button on the remote
to switch between Composite and
Component video output modes.
4. Video from a docked iPhone/iPod,
or a connected DVD player can now
be played through the bar speaker
to the connected television.
The Component Video Output will only output
video from a docked iPod or iPhone. It cannot
output video from the composite video input.
1. Connect a component video cable
(not included) to the COMPONENT
VIDEO OUTPUT and a television.
2. Adjust the connected television
to the proper input setting.
3. Press the VIDEO button on the remote
to switch between Composite and
Component video output modes.
4. Video from a docked iPhone/iPod,
or a connected DVD player can now
be played through the bar speaker
to the connected television.
Using the Composite Video Input
Using the Composite Video Output
Using the Component Video Output
Page 11
Customer Support: 1-888-999-4215 iLive 11
Mounting to a Wall
We recommend having this bar speaker
professionally mounted.
The included spacers should be used at your
discretion to extend the face of the bar speaker
farther from the wall. These are typically used when
mounting the bar speaker under a television, and
the face of the bar speaker needs to be ush with the
face of the television.
1. Use the Tape Measure to decide how high you’d
like to hang the bar speaker on the wall.
2. The bar speaker must be hung within 6 feet of an
AC power outlet for the attached AC power cable
to reach.
3. Use the Stud Finder to locate 2 parallel wooden
studs to screw the mounting brackets into.
4. Mark the wall at the center of the studs using the
Pencil.
5. Line the Level up on both of your marks to make
sure they are level. If they’re not, adjust the
marks as needed to make them level.
6. After you’ve double checked your markings, drill
through the top hole on both mounting brackets
directly into the marks you’ve made on the wall.
7. If you are using the brackets only and no spacers,
use the included short screws. If you are using
any of the spacers or combination of the spacers,
use the long screws.
8. Use the Level to level each of the hanging
brackets, then drill the second screw into the
bottom hole on both mounting brackets.
9. Slide the bar speaker onto the mounting
brackets, and make sure there is a rm and stable
connection before letting go of the bar speaker.
10. Finally, use the Level to conrm that the bar
speaker is level.
• Manual or Power Screwdriver
• Stud Finder
• Pencil
• Tape Measure
• Level
• (2) Wall Mount Brackets
• (4) Long Screws
• (4) Short Screws
• (2) 1/4” Spacers
• (2) 1/2” Spacers
• (2) 3/4” Spacers
• (4) Drywall anchors
Important Notes
Getting Started
Required Tools
Included Hardware
16”
ITP231B
ITP231B
screws
studs
mounting
bracket
spacer
Page 12
Copyright © 2011 Digital Products International (DPI, Inc.) | All other trademarks appearing herein are the property of their respective owners.
Specications are subject to change without notice
To download this User’s Guide in English, Spanish, or
French, visit the support section at www.ilive.net.
Para transferir esta guía de usuario en inglés,
español, o francés, visite la sección de la ayuda en
www.ilive.net.
Pour télécharger ce guide de l’utilisateur en anglais,
espagnol, ou français, visitez la section de soutien
chez www.ilive.net.
Phone: 1-888-999-4215
Email: [email protected]
Parts Email: [email protected]
Website: www.ilive.net
International Support
Contact Information
Company Information
Loading...
