USER’S GUIDE |
V: 883-01 |
ITB283B |
Bluetooth 32” HD Sound Bar |
For the most up-to-date version of this User’s Guide, go to www.iLiveElectronics.com |
Warnings and Precautions
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
AVERTISSEMENT: Pour réduire le risque d’incendie ou de choc électrique, ne pas exposer cet appareil sous la pluie et l’humidité.
CAUTION: Use of any controls or adjustments or performance of procedures other than those herein specified may result in hazardous radiation exposure.
|
|
|
WARNING: TO REDUCE THE RISK OF |
|
CAUTION |
||
|
RISK OF ELECTRIC SHOCK |
|
ELECTRIC SHOCK, DO NOT REMOVE |
|
DO NOT OPEN |
|
COVER (OR BACK). NO USER- |
|
|
|
|
|
|
|
SERVICEABLE PARTS INSIDE. REFER |
|
ATTENTION |
|
|
|
RISQUE D' ÉLECTROCUTION |
|
SERVICING TO QUALIFIED SERVICE |
|
NE PAS OUVRIR |
|
PERSONNEL. |
|
|
|
|
|
|
|
|
|
|
|
The lightning flash with arrowhead symbol, within |
|
|
|
an equilateral triangle, is intended to alert the user |
|
|
|
to the presence of uninsulated "dangerous voltage" |
|
|
|
within the product's enclosure that may be of |
|
|
|
sufficient magnitude to constitute a risk of electric |
|
|
|
shock to persons. |
WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
WARNING: Do not place this unit directly onto furniture surfaces with any type of soft, porous, or sensitive finish. As with any rubber compound made with oils, the feet could cause marks or staining where the feet reside. We recommend using a protective barrier such as a cloth or a piece of glass between the unit and the surface to reduce the risk of damage and/or staining.
WARNING: Use of this unit near fluorescent lighting may cause interference regarding use of the remote. If the unit is displaying erratic behavior move away from any fluorescent lighting, as it may be the cause.
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.
PRÉCAUTION: Danger d’explosion si les piles sont remplacées de façon incorrect. Remplacer les piles seulement par le même type de pile ou l’équivalent.
WARNING: The battery, batteries, and battery pack shall not be exposed to excessive heat such as sunshine, fire, or the like.
WARNING: Lithium batteries, like all rechargeable batteries are recyclable and should be recycled or disposed of in normal household waste. Contact your local government for disposal or recycling practices in your area. They should never be incinerated since they might explode.
WARNING: Shock hazard - Do Not Open.
AVIS: RISQUE DE CHOC ÉLECTRIQUE - NE PAS OUVRIR
Mains Plug or Direct plug-in adapter is used as disconnect device and it should remain readily operable during intended use. In order to disconnect the apparatus from the mains completely, the Mains Plug or Direct plug-in adapter should be disconnected from the mains socket outlet completely.
La fiche d’alimentation ou adaptateur de courant est utilisé comme dispositif de déconnexion et doit rester accessible pendant l’utilisation. Pour mettre l’appareil hors tension, la fiche ou adaptateur de courant doit être débranché de la prise de courant.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
2
Important Safety Instructions
1.Read these Instructions.
2.Keep these Instructions.
3.Heed all Warnings.
FCC Warnings
WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
4.Follow all instructions.
5.Do not use this apparatus near water.
6.Clean only with a dry cloth.
7.Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8.Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9.Do not defeat the safety purpose of the polarized or grounding - type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. When the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10.Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
11.Only use attachments/accessories specified by the manufacturer.
12.Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13.Unplug this apparatus during lightning storms or when unused for long periods of time.
14.Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
WARNING: Do not place this unit directly onto furniture surfaces with any type of soft, porous, or sensitive finish. As with any rubber compound made with oils, the feet could cause marks or staining where the feet reside. We recommend using a protective barrier such as a cloth or a piece of glass between the unit and the surface to reduce the risk of damage and/or staining.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Additional Warnings
The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on apparatus.
L’appareil ne doit pas être exposé aux écoulements ou aux éclaboussures et aucun objet ne contenant de liquide, tel qu’un vase, ne doit être placé sur l’objet.
Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
Les piles ne doivent pas être exposées à de forte chaleur, tel qu’à la lumière du soleil, au feu ou autres choses de semblable.
Caution marking is located at the rear or bottom of the apparatus.
Attention marquage est situé sur le paneau arrière ou inférieur de l’unité.
The marking information is located at the rear or bottom of apparatus.
Le marquage est situé sur le paneau arrière ou inférieur de l’unité.
This symbol indicates that this product incorporates double insulation between hazardous mains voltage and user accessible parts.
Customer Support: 1-888-999-4215 |
3 |
ITB283B
Features |
|
|
Includes |
||
• |
37” length |
• |
RCA stereo audio inputs |
• Remote control: requires a |
|
• |
Supports Bluetooth v2.0 |
• |
LED source indicators |
|
CR2025 battery (pre-installed) |
• Supports Enhanced Data Rate |
• |
LED pairing indicator |
• RCA stereo audio cable |
||
|
(EDR) |
• |
LED power indicator |
• |
Wall-mount hardware and |
• |
Supports profile A2DP |
• |
Wall mountable |
|
instructions |
|
(Advanced Audio Distribution |
• |
Wireless range: 33 feet |
• |
AC/DC power adapter |
|
Profile) |
• |
Built-in stereo speakers |
|
|
• |
Digital volume control |
• |
Cloth speaker grill |
|
|
• |
Remote |
• AC power input: requires |
|
|
|
• Optical digital audio input |
|
an AC/DC power adapter |
|
|
|
• |
3.5mm audio input |
|
(included) |
|
|
Setup
Power
AC power input: requires an AC/DC power adapter (included)
Remote
Requires a CR2025 battery (pre-installed)
CR2025
|
OPEN |
|
|
|
PUSH |
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Y |
ER |
3V |
|
|
|
||
|
|
|
|
||||
|
T |
|
|
|
|||
|
T2025 |
|
|
|
|||
|
|
|
CRBA |
|
|
|
|
|
|
|
|
UM |
|
||
|
|
|
LITH |
I |
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
Y |
|
|
TER |
|
|
|
T |
|
|
|
BA |
|
|
|
2025 |
|
|
|
LITHIUM |
3V |
|
|
CR |
|
OPEN |
|
|
|
|
|
PUSH
LED Indicators
Status |
Indicator |
Power Off |
Red Light |
|
|
Optical Mode |
Amber Light |
|
|
Aux In Mode |
White light |
|
|
Line In Mode |
Green Light |
|
|
Bluetooth Ready |
Flashing Blue Light |
|
|
Bluetooth Connected |
Blue Light |
|
|
Mounting
We recommend having this bar speaker professionally mounted.
