Page 1
USER’S GUIDE
V:1230-0817-11
For the most up-to-date version of this User’s Guide, go to www.ilive.net
ISP301B
Speaker System for iPod + iPhone
Meijer.com
Page 2
2
• CAUTION: TO PREVENT ELECTRIC SHOCK,
MATCH WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
•
WARNING:To reduce the risk of re or electric shock,
do not expose this apparatus to rain or moisture.
• AVERTISSEMENT: Pour réduire le risque d’incendie
ou de choc électrique, ne pas exposer cet appareil sous la
pluie et l’humidité.
• CAUTION: Use of any controls or adjustments or
performance of procedures other than those herein
specied may result in hazardous radiation exposure.
• WARNING: Changes or modications to this unit
not expressly approved by the party responsible for
compliance could void the user’s authority to operate the
equipment.
• WARNING: Do not place the unit on top of any soft,
porous, or sensitive surfaces to avoid damaging the
surface. Use a protective barrier between the unit and
surface to protect the surface.
• WARNING: Shock hazard - Do Not Open.
• AVIS: RISQUE DE CHOC ÉLECTRIQUE - NE PAS
OUVRIR
Mains Plug or Direct plug-in adapter is used as disconnect
device and it should remain readily operable during intended
use. In order to disconnect the apparatus from the mains
completely, the Mains Plug or Direct plug-in adapter should
be disconnected from the mains socket outlet completely.
La che d’alimentation ou adaptateur de courant est utilisé
comme dispositif de déconnexion et doit rester accessible
pendant l’utilisation. Pour mettre l’appareil hors tension, la
che ou adaptateur de courant doit être débranché de la prise
de courant.
Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc), or rechargeable
(ni-cad, ni-mh, etc) batteries.
No mezcle baterías viejas y nuevas.
No mezcle baterías alcalinas, estándar (carbono-zinc) o
recargables (ni-cad, ni-mh, etc.).
Warnings and Precautions
The lightning ash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of
sufcient magnitude to constitute a risk of electric
shock to persons.
WARNING: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USERSERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
ATTENTION
RISQUE D' ÉLECTROCUTION
NE PAS OUVRIR
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
WARNING: The remote control supplied with this
product contains a button-cell battery that could be
accidentally ingested by children. Do not leave button-cell
batteries accessible to children. If swallowed, promptly
see doctor and call (202) 625-3333.
Meijer.com
Page 3
Customer Support: 1-888-999-4215 3
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualied service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally,
or has been dropped.
WARNING: Changes or modications to this unit not expressly
approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
• The apparatus shall not be exposed to dripping or splashing and
that no objects lled with liquids, such as vases, shall be placed on
apparatus.
L’appareil ne doit pas être exposé aux écoulements ou aux
éclaboussures et aucun objet ne contenant de liquide, tel qu’un vase,
ne doit être placé sur l’objet.
• Battery shall not be exposed to excessive heat such as sunshine, re
or the like.
Les piles ne doivent pas être exposées à de forte chaleur, tel qu’à la
lumière du soleil, au feu ou autres choses de semblable.
• Caution marking is located at the rear or back of the apparatus.
Attention marquage est situé à l’arrière ou à l’arrière de l’appareil
• The marking information is located at the rear or back of apparatus.
Les informations de marquage est situé à l’arrière ou à l’arrière de
l’appareil.
FCC Warnings
Additional Warnings
1. Read these Instructions.
2. Keep these Instructions.
3. Heed all Warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding - type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety.
When the provided plug does not t into your outlet,
consult an electrician for replacement of the obsolete
outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11. Only use attachments/accessories specied by the
manufacturer.
12.
Important Safety Instructions
This symbol indicates that this product
incorporates double insulation between
hazardous mains voltage and user
accessible parts.
Use only with a cart, stand, tripod,
bracket, or table specied by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
Special note: When placing your unit on a
lacquered or natural nish, protect your furniture
with a cloth or other protective material.
Meijer.com
Page 4
4
• Made for iPod and iPhone
• Plays and charges docked iPod and
iPhone
• iPod and iPhone authentication IC
• Composite video output
• 3.5mm audio input
• Blue LED light eects
• Built-in speaker
• Last volume settings memory
• Cloth speaker grill
• Remote Control
• DC power input: requires an AC/DC
power adapter (included)
• AC/DC power adapter
• Remote control: requires a CR2025
battery (pre-installed)
Speaker System for iPod + iPhone
Features
Included
Meijer.com
Page 5
Customer Support: 1-888-999-4215 5
Table of Contents
Speaker System for iPod + iPhone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Features
Included
Table of Contents
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Introduction
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Setup
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Power
Remote
iPod and iPhone
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Docking an iPod or iPhone
Playing a Docked iPod or iPhone
Rotating a Docked iPod or iPhone
3.5mm Audio Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Using the 3.5mm Audio Input
Composite Video Output
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Using the Composite Video Output
Company Information
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
International Support
Contact Information
Green Initiative
Meijer.com
Page 6
6
Introduction
Power
Press to turn the
speaker o or on.
Volume
Press to adjust
the volume on
the speaker.
Dock for iPod
and iPhone
Dimmer
Use to adjust the
light eects to
Hi, Low, or O.
Composite
Video Output
3.5MM Audio Input
DC Power Input
Requires an AC/
DC power adapter
(included)
Meijer.com
Page 7
Customer Support: 1-888-999-4215 7
Power
Press to turn the
speaker o or on.
Select
Press to make
selections on
a docked iPod
or iPhone.
Menu
Press to move
through the menus
on a docked iPod
or iPhone.
Skip
Press to skip between
tracks on a docked
iPod or iPhone.
Repeat
Press to repeat a
track on a docked
iPod or iPhone.
Video Out
Press to output
video from a docked
iPhone or iPod Touch.
Menu Up/Down
Press to scroll
through selections
on a docked iPod
or iPhone.
Volume
Press to adjust
the volume on
the speaker.
Shue
Press to activate or
deactivate the shue
mode on a docked
iPod or iPhone.
Play/Pause
Press to play or
pause a docked
iPod or iPhone.
Meijer.com
Page 8
8
Setup
DC Power Input: Requires an AC/DC power
adapter (included)
Power
LITHIUM BATTERY
CR 2025
3V
CR2025
PUSH
OPEN
LITHIUM BATTERY
CR 2025
3V
CR2025
PUSH
OPEN
Requires 1 CR2025 battery (pre- installed)
Remote
Meijer.com
Page 9
Customer Support: 1-888-999-4215 9
Docking an iPod or iPhone
Rotating a Docked iPod or iPhone
1. Connect the iPod or iPhone to the
connector inside the Dock for iPod and
iPhone.
2. When the speaker is plugged in, using
AC power, the docked iPod or iPhone
will charge.
1. Follow the directions for Docking an
iPod or iPhone.
2. After your iPod or iPhone is docked,
the dock on the speaker can be rotated
90˚.
Playing a Docked iPod or iPhone
1. Follow the instructions for Docking an
iPod or iPhone.
2. Press the Power button to turn the
speaker on.
3. Use the native controls on the docked
iPod or iPhone to begin playing music
through the connected speaker.
iPod and iPhone
Meijer.com
Page 10
10
3.5mm Audio Input
Using the 3.5mm Audio Input
Requires a 3.5mm audio cable (not
included)
1. Connect a 3.5mm audio cable to the
3.5MM Audio Input on the speaker
and an audio output on an MP3 player
or other audio source.
Playing music from a docked iPod or
iPhone is disabled when a 3.5mm audio
cable is connected to the speaker.
2. The speaker will automatically switch
to line input mode.
3. Use the native controls on the
connected MP3 player or other audio
source to play and control audio
played through the speaker.
Meijer.com
Page 11
Customer Support: 1-888-999-4215 11
Using the Composite Video Output
Requires an RCA composite video cable
(not included)
1. Connect the RCA composite video
cable to the Composite Video Output
on the speaker and a composite video
input on a television.
2. Press the Video Out button on the
remote.
Video Out button only compatible with
iPhone and iPod touch. For all other
models, locate the TV Out setting in iPod
Settings to turn the feature on or o.
3. Adjust the TV OUT settings on the
docked iPod to OK.
4. Videos played from the docked iPod or
iPhone will now play on the connected
television.
Composite Video Output
Meijer.com
Page 12
Copyright © 2010 Digital Products International (DPI, Inc.) | All other trademarks appearing herein are the property of their respective
owners. Specications are subject to change without notice
Environmental Commitment to ‘Protect for
Today and Sustain for Tomorrow’
2009 marked the ocial launch of
DPI, Inc.’s corporate campaign for
a greener and cleaner world. DPI is
building upon environmental initiatives
introduced at all of their facilities to
help formulate and sustain signicant
and important conservation eorts
within its manufacturing and marketing
communities. In addition to targeting and
selecting energy ecient product features,
and structuring ‘green oce’ procedures,
other initial program eorts include:
• Reduction of all packaging sizes
• Recyclable plastics for clamshell
packages, with a plan to eventually
replace plastic with recyclable paper
• Recycled ber board in place of the
polyfoam in packing boxes
• Recycled plastics in place of the virgin
material in product construction
To download this User’s Guide in English,
Spanish, or French, visit the support section
at www.ilive.net.
Para transferir esta guía de usuario en
inglés, español, o francés, visite la sección
de la ayuda en www.ilive.net.
Pour télécharger ce guide de l’utilisateur
en anglais, espagnol, ou français, visitez la
section de soutien chez www.ilive.net.
Phone: 1-888-999-4215
Email: [email protected]
Parts Email: [email protected]
Website: www.ilive.net
Green InitiativeInternational Support
Contact Information
Company Information
Meijer.com
Loading...
