iKey 340-053-003 Product Data Sheet

2621 Ridgepoint Drive | Austin, TX 78754
512-837-0283

SLK-101

BACKLIT INDUSTRIAL KEYBOARD

iKey's SlimKeyTM SLK-101 keyboard provides full-sized
versatility in a rugged, compact design. It features red
LED backlit keys for use in areas with minimal lighting.
Engineered for NEMA 4X protection from dust, water and
corrosive liquids, the SlimKeyTM SLK-101 is ideal for use
in industrial, medical and material handling applications.
The large numeric pad on the SLK-101 allows for easy
data entry, while the robust polycarbonate case stands up
in the roughest of conditions. Features: 10-Key Numeric
Pad 12 Function Keys Integrated Backlighting MS
WindowsTM Function Keys Slim, Compact Design USB
and PS/2 configurations available

Product Code SLK-101

CERTIFICATIONS NEMA 4X UL60950, FCC Part 15 Class B
SHOCK 3x11 ms pulses of 50g on each of 3 axis
CABLE LENGTH: 10' straight (3 m) DESIGN: "Y" PS/2 or USB Cable

KEY SWITCH

MATERIAL: Industrial silicone rubber LIFE: 10 million cycles TRAVEL: 0.055 in. (1.4mm)
ACTUATION FORCE: 7.05 oz. +/- 1.06 oz. (200g +/- 30g) FEEDBACK: Tactile with mechanical
snap

VIBRATION

POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF

TEST PER AXIS: 3 hours
POWER PS/2: 210mA@5V (from Keyboard port) USB: 210mA@5V (from CPU port)
COMPATABILITY PS/2: All Windows Operating Systems USB: All Windows and Macintosh OS
TEMPERATURE RANGE STORAGE: -40C to +90C (-40F to +194F) OPERATING: -40C to +70C (-40F to +158F)
WEIGHT 1.5 lbs +/- 0.10 lbs (0.68 kg +/- 0.05 kg)
WARRANTY 1 Year Limited Warranty
HUMIDITY 100% Humidity Resistant
DIMENSIONS 14.60" x 5.55" x 0.92" (w-h-d) 370.8mm x 141mm x 23.4mm
MODEL NUMBERS SLK-101-PS2: With PS/2 cable SLK-101-USB: With USB cable
