Ikelite 6281.52 Supplemental Instructions
i
k
e
l
i
te
3
5
A
F
i
ke
l
i
t
e
A
U
T
O
F
L
A
S
H
Ikelite Digital Housing
1
2
3
4
56
7
8
9
Front View
Shutter
Button
Back View
Lanyard
Latch
Zooms Buttons
Power Button
ULTRA
compact
Made in USA
IKELITE
Tray Mount
Tray Mount
Lens Port
[1] Favorite Button
[2] Flash Mode
[3] Playback Button
[4] Self-Timer
[5] OK/Apply Button
[6] +/-
[7] Menu Button
[8] Macro
[9] Delete Button
s u p p l e m e n t a l i n s t r u c t i o n s
CCaammeerraa SSeettuupp
((NNiikkoonn SS552200))
1. Set camera to Macro Mode.
2 Set camera to Auto Mode (will see camera icon in LCD ).
3. Set ISO to 64
NNOOTTEE::
If over-exposure occurs, enable Macro Mode setting. If
over-exposure continues, back away from the subject and then
zoom in as necessary. Camera will focus far away even if Macro
Mode is on.
#6281.52 Nikon S520 ULTRAcompact Digital Housing
HHoouussiinngg CCoonnttrroollss
or
f
IIkkeelliittee WW--2200 WWiiddee--AAnnggllee CCoonnvveerrssiioonn LLeennss ##66442200..4466
Your new Ikelite housing features a 46mm threaded
port for attachment of external 46mm accessory
wet lenses such as the Ikelite 46mm W-20 lens
6420.46. External wide angle conversion lenses
#
increase angle of coverage, so you can get much
closer to your subject while still fitting everything in
the frame.
##99330066..8811 6677mmmm TThhrreeaaddeedd AAddaappttoorr
Allows attaching Ikelite W-20 #6420, Epoque, Type II Inon
screw-on lenses, and macro lenses or diopters with 67mm threads.
Includes larger size removable flash deflector.
##99330066..7799 BBaayyoonneett MMoouunntt AAddaappttoorr
Allows attaching of the Inon UWL-105AD, UFL-165AD,
UWL-100AD, and macro bayonet style lenses. Includes larger size
removable flash deflector.
NNOOTTEE::
Vignetting can occur at widest angle camera lens
setting with some wide-angle conversion lenses. Zoom in to
eliminate, or crop the image in post-processing. Also, slight edge
softness around the edges in some situations is normal.
2
AAFF3355 SSttrroobbee PPaacckkaaggee ##44003355
The AutoFlash AF35 kit is a great
compliment, and an effortless,
affordable way to add a flash to
your new Ikelite point-and-shoot
camera system. Everything you
need to get started is in the box.
Just attach it to the bottom of your
housing and start taking pictures!
AAFF3355 AAuuttooFFllaasshh kkiitt iinncclluuddeess::
AF35 strobe
Flex arm
AutoFlash sensor
Handle with rubber grip
Tray (single or dual)
Mounting hardware
3
SSttrroobbee CCoommppaattiibbiilliittyy NNoottee::
The DS-200 Substrobe is NOT compatible with this camera system.
Compatible strobes include the AF35, DS-51, DS-125, and DS-160.
wwwwww..iikkeelliittee..ccoomm
Go to
WWhheenn rreettuurrnniinngg pprroodduuccttss sseenndd ““aattttnn.. RReeppaaiirr DDeepptt..””
““ggeenneerraall qquueessttiioonnss”” ee--mmaaiill:: iikkeelliittee@@iikkeelliittee..ccoomm
for complete strobe and accessory info.
IIkkeelliittee UUnnddeerrwwaatteerr SSyysstteemmss
5500 WW 3333rrdd SSttrreeeett
IInnddiiaannaappoolliiss,, IINN 4466220088 UUSSAA
wwwwww..iikkeelliittee..ccoomm
331177--992233--44552233
UULLTTRRAAccoommppaacctt SSuupppplleemmeennttaall 66228811..5522--0022--00770099
