Ikelite IXY 3000 IS, SD990 IS, 6240.99 Supplemental Instructions
i
k
e
l
i
te
3
5
A
F
i
ke
l
i
t
e
A
U
T
O
F
L
A
S
H
3
4
6
5
7
1
2
8 9
Back View
Lanyard
Latch
ULTRA
compact
Made in USA
IKELITE
Mode Dial
Front View
Shutter
Release
Zoom
Power
Tray Mount
Tray Mount
Lens Port
[1] Print/Assign
[2] Playback
[3] ISO
[4] Macro
[5] Function/Set
[6] Flash
[7] Delete
[8] Menu
[9] Display
Ikelite Digital Housing
s u p p l e m e n t a l i n s t r u c t i o n s
or
f
#6240.99 Canon SD990 IS, IXUS 980 IS, IXY 3000 IS
ULTRAcompact Digital Housing
CCaammeerraa SSeettuupp
1. Turn camera mode dial to P/M
2. Use “P” Program mode. To rotate through camera modes when
the camera is in the housing, push and hold button #1, and then
left or right toggle using buttons #4 and #6 (page #3).
2. ISO can be set as low as 80
3. Set flash to “on” (lightning bolt only), using button #6.
:
NNOOTTEE:
If over-exposure occurs, turn on the “flower icon” macro
mode (button #4), which sets the aperture to f8. If overexposure continues, back away from the subject and zoom in.
IIkkeelliittee WW--2200 WWiiddee--AAnnggllee CCoonnvveerrssiioonn LLeennss ##66442200..4466
Your new Ikelite housing features a 46mm threaded port for
attachment of external 46mm accessory wet lenses such as the
Ikelite 46mm W-20 lens #6420.46. External wide angle conversion
lenses increase angle of coverage, so you can get much closer to
your subject while still fitting everything in the frame. Add the
kelite W-20 or other wide-angle lenses with an Ikelite accessory
I
port adapter for increased angle of coverage, color, and clarity.
NNOOTTEE::
No vignetting occurs when using the 46mm Ikelite W-20
Wide-Angle Conversion Lens.
##99330066..8811 6677mmmm TThhrreeaaddeedd AAddaappttoorr
Allows attaching Ikelite W-20, Epoque, and Type II Inon screw-on
lenses with 67mm threads. Includes larger size removable flash
deflector.
##99330066..7799 BBaayyoonneett MMoouunntt AAddaappttoorr
Allows attaching of the Inon UWL-105AD, UFL-165AD,
UWL-100AD, and macro bayonet style lenses. Includes larger size
removable flash deflector.
NNOOTTEE::
Vignetting may occur at widest angle camera lens setting
with wide-angle conversion lenses. Zoom in to eliminate, or crop
the image in post-processing. Also, slight edge softness around the
edges in some situations is normal.
2
HHoouussiinngg CCoonnttrroollss
3
AAFF3355 SSttrroobbee PPaacckkaaggee ##44003355
The AutoFlash AF35 kit is a great
compliment, and an effortless,
affordable way to add a flash to
your new Ikelite point-and-shoot
camera system. Everything you
need to get started is in the box.
Just attach it to the bottom of your
housing and start taking pictures!
AAFF3355 AAuuttooFFllaasshh kkiitt iinncclluuddeess::
AF35 strobe
Flex arm
AutoFlash sensor
Handle with rubber grip
Tray (single or dual)
Mounting hardware
SSttrroobbee CCoommppaattiibbiilliittyy NNoottee::
The DS-200 Substrobe is NOT compatible with this camera system.
Compatible strobes include the AF35, DS-51, DS-125, and DS-160.
wwwwww..iikkeelliittee..ccoomm
Go to
WWhheenn rreettuurrnniinngg pprroodduuccttss sseenndd ““aattttnn.. RReeppaaiirr DDeepptt..””
““ggeenneerraall qquueessttiioonnss”” ee--mmaaiill:: iikkeelliittee@@iikkeelliittee..ccoomm
UULLTTRRAAccoommppaacctt SSuupppplleemmeennttaall 66224400..9999--0022--00550099
for complete strobe and accessory info.
IIkkeelliittee UUnnddeerrwwaatteerr SSyysstteemmss
5500 WW 3333rrdd SSttrreeeett
IInnddiiaannaappoolliiss,, IINN 4466220088 UUSSAA
wwwwww..iikkeelliittee..ccoomm
331177--992233--44552233
