Ikelite 6148.72 User Manual
Product Registration
Please register your product at ikelite.com within 15 days of purchase.
Our product registration database is the best way for us to contact you
in the event of a product update.
Underwater Housing for Canon SX720 HS
Product Number 6148.72
2
About this Product
Thank you for your purchase of Ikelite equipment. Please read this
instruction manual completely before attempting to operate or dive
with this product. Please visit ikelite.com to register your product
to receive information on any updates or notices pertaining to your
equipment.
Included in the Box
• Housing
• Port Cover
• Accessory Packet including 1cc Silicone Lubricant
Specifications
• 200 ft (60m) depth rating
• Controls for all camera controls except Wi-Fi Button and Framing
Assist - Seek Button
• Near neutral buoyancy in fresh water
• 1/4-20 thread tray mounting with 3-inch (76mm) spacing
• Weight 2.8 lb (1.3 kg)
• Dimensions 5.0 x 6.3 x 6.8” (12.7 x 15.0 x 17.3 mm)
• 3.9 inch diameter glass lens port
3
Important Notices
» To prevent salt build-up and sticking controls, submerge the
empty housing in clean, freshwater. Operate the controls
several times each while underwater to ush out any residue.
» Never leave a housing in a rinse tank, even if it is the only
system in the tank. Most catastrophic oods happen when the
user walks away from a housing while it is in the rinse tank.
» Do not use alcohol, cleaning agents, spray lubricants, Rain-X,
or other solvents on the housing or lens port. Use of an
incompatible chemical compound can damage the plastic and
o-rings, and may result in leaking.
Accessory Port
» Do not remove the Accessory Port Hole Plug unless you are
installing a compatible accessory.
Your housing features an Accessory Port which may be used for
attachment of factory optional or aftermarket housing accessories.
The Accessory Port is 1/2-20 threaded.
Visit ikelite.com for information on optional accessories.
4
Contents
Product Registration 1
About this Product 2
Included in the Box 2
Specications 2
Important Notices 3
Accessory Port 3
Getting to Know Your Housing 5
Getting to Know Your Housing - continued 6
Installing an Accessory in the Accessory Port 7
Setting Up Your Camera 7
Pre-Installation Checklist & Initial Camera Settings 7
Setting Up Your Housing 8
Opening the Housing 8
Inserting the Camera 8
Closing the Housing 9
Attaching a Fiber Optic Strobe 10
Zoom function 11
Final Check 11
Entering the Water 11
Maintenance 12
Post-Dive 12
Travel and Storage 12
Spare Parts 13
Troubleshooting 13
Limited Warranty 15
Service and Repairs 15
Contact Us 16
5
Getting to Know Your Housing
Tray Mounts
Lens Port
Fiber Optic Ports
Lid Snap
Accessory Port
Hole Plug
Power Button ON/OFF
Zoom Lever
Shutter Button
Movie Button
