Cost-Effective High Resolution, Security Surveillance
15-inch TFT Color LCD Monitor
LCD-15
Features
High Resolution Panel 1024x768pixels
Front LCD Protection Glass
Deinterlace
Contrast Ratio 500:1, Brightness 250cd/m2
Composite In/Out(BNC), HDMI In, S-Video In and PC In
Fast Response Time 8msec.
Auto Source Sequencing
Optional Rackmount Adaptor IK-RMK-08
Power AC 90V ~ 264V (with AC adaptor)
All Safety Standards (FCC, CE, RoHS)
LCD-15 High Resolution Security Surveillance Color LCD Monitor
m
Specifications
Type: 15 inch TFT LCD
Color: 16.8M colors
Pixel Pitch: 0.297mm x 0.297mm
Screen Aspect Ratio: 4:3
GENERAL
INTERFACE
SPEAKER
FRONT SW
TEMPERATURE
POWER
PHYSICAL
REGULATIONS
STANDARD
ACCESSORIES
Contrast Ratio: 500:1 (Typical)
Luminance:
Response Time: 8msec (Typical)
Video Impedance: 75 Ohms
Resolution: XGA (1024 x 768)
Viewing Angle (L/R/T/B): 75°, 75°, 70°, 60°
Active Area: 304.128mm x 228.096mm
Video System: NTSC / PAL
Panel Lamp Life: 40,000 hours
Connectors:
PC Sync:
Built-in Speaker 1W x2
MENU, INPUT/SELECTION, POWER
Operating Temperature:
Power Input:
Power Consumption: Maximum 30Watts
Net Weight: Approx 2.49Kg.
Net Dimensions (WHD): Approx. 362 x 325 x 190mm (362 x 282 x 59mm without Stand)
VESA Mount Size: 75mm x 75mm
250cd/
Composite BNC In/Out x1, S-Video In x1
Video Audio L/R x1, PC Audio x1
HDMI In x1
D-Sub 15P In (PC) x1
H Sync Frequency: 31 ~ 60KHz
V Sync Frequency: 55 ~75Hz
0 ~ 40qC
DC12V/3A
AC Adaptor AC90V ~ 264V (50/60Hz)
FCC, CE, RoHS2
Power Code (USA Type, Length 1.8m)
AC Adaptor (12V, 3.5A)
Installation/Operation Manual
²
External Appearance
Specifications are subject to change without notice.
