Ikegami ECO-BC36 Specsheet

ECOSERIESECOSERIES

ECO BC36ECO BC36

meet

the

stringent

demands

of

today s

CCTV

Professional

p

Lens

3.6 mm, F2.0, angle of view 53º

g

)

g

()

‐

‐

ColorMiniBulletCamera

Our high resolution low illumination color mini bullet camera was designed by industry specialists to

'

The newest addition to our quality line of cameras, is the ECO‐BC36acompactDay/Nightbulletcamera
with external controls, with only Ø0.9 x 2.96 inch dimensions.

ECO‐BC36 with its 1/3” 960H technology CCD sensor provides Day/Night capacities at 750 TVL high
resolution, while consuming low power feed by 12V DC in a fully robust weather resistant IP67 housing
making it suitable for indoor and outdoor environments were weather protection is a must.

Specifications

Signal System NTSC
Image Sensor 1/3” 960H SONY EXview HAD CCD II
Scanning System 2:1 Interlace
Horizontal Resolution 750TV Lines
Scanning Frequency 15.734 KHz x 59.94 Hz (H x V)
Total Pixels | Effective Pixels 1020 x 508 (H x V) | 976 x 494 (H x V)
Synchronization Internal

.

Lens Type Fixed Board Lens
S/N More than 50dB (AGC Off)
Gamma r = 0.45
Min. Illumination 0.1 Lux
Shutter Speed 1/60 ~ 1/100,000 sec
Day & Night Digital Day & Night
Day & Night Function Auto, Color, B/W
IP Ratin
Video Output Level 1.0 Vp-p Composite (75 0)
On-Screen Display (OSD) Built-in with Joystick
BLC Off, BLC, HLC
DNR 2D DNR
ATR On / Off (Level Adjustable)
White Balance ATW, Push, User1, User2, Anti CR, Manual, Push-lock
Privacy Masking 4 Zones
Mirror On / Off
Motion Detection 4 Zones
Other Function Brightness, Contrast, Sharpness, Hue, Gain
Language Option English, Japanese, German, French, Russian, Portuguese, Spanish
Operating Temperature 14 °F ~ 122 °F (-10 °C ~ 50 °C)
Storage Temperature -4 °F ~ 140 °F (-20 °C ~ 60 °C)
Humidity Less than 80% RH
Power Supply DC 12 V (±10%), Max. 83 mA
Dimension | Weight Ø0.9 x 2.96 inch (Ø23 x 75.2 mm) | 0.15 lbs (68 g)

IP67 (Water Resistant

Dimensions: (inch)

DesignandspecificationsaresubjecttoChangewithoutnotice.
