Contents

Safety information 4
Product description 5
Daily use 6
Helpful hints and tips 7
Care and cleaning 8

Subject to change without notice.

What to do if… 8
Technical information 9
Installation 9
Environment concerns 10
IKEA GUARANTEE 11

Safety information

For your safety and correct operation

of the appliance, read this manual
carefully before installation and use. Always
keep these instructions with the appliance
even if you move or sell it. Users must fully
know the operation and safety features of
the appliance.

Correct use

• Do not leave the appliance unattended

during operation.

• The appliance is designed exclusively for

domestic use.

• The appliance must not be used as a

work surface or as a storage surface.

• Do not place or store flammable liquids,

highly inflammable materials or fusible
objects (e.g. plastic film, plastic, alumini­um) in or near the appliance.

• Watch out when connecting electric ap-

pliances to sockets nearby. Do not allow
connecting leads to come into contact
with or to catch underneath the appli­ance or hot cookware.

• Do not do repairs yourself to prevent in-

jury and damage to the appliance. Al­ways contact your local After Sales Serv­ice (refer to the Service chapter).

Child safety

• Only adults can use this appliance. Chil-

dren must get supervision to make sure
that they do not play with the appliance.

• Keep all packaging away from children.

There is a risk of suffocation.

• Keep children away from the appliance

when it is on.

Warning! Activate the child safety
device to avoid small children and pets

unintentionally switching the appliance on.

General safety

• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge, un­less they have been given supervision or
instruction concerning use of the appli­ance by a person responsible for their
safety.

Installation

• Make sure that the appliance is not dam­aged because of transport. Do not con­nect a damaged appliance. If necessary,
contact the After Sales Service (refer to
the Service chapter).

• Only an authorized service engineer can
install, connect or repair this appliance.
Use only original spare parts.

• Built-in appliances can only be used after
they are built into suitable built-in units
and work surfaces that meet standards.

• Do not change the specifications or modi­fy this product. Risk of injury and damage
to the appliance.

Warning! Carefully obey the
instructions for electrical and gas

connections.

• Do not install the appliance if it is dam­aged during the transportation.

Safety during use

• Remove all packaging, stickers and film
from the appliance before the first use.

ENGLISH 5

• Warning! Fire hazard! Overheated fats

and oils can ignite very quickly.

• Switch the cooking zones off after each
use.

• Risk of burns! Do not place objects made
of cuttlery or saucepan lids on the cook­ing surface, as they can get hot.

Warning! If the surface is cracked,

switch off the appliance to avoid
possibility of an electric shock and call the
After Sales Service (refer to the Service
chapter).

Warning! Do not operate the

appliance with wet hands and keep
control panel surface dry. Lot of water on
control panel keys will make them no longer
operable.

How to avoid damage to the appliance

• The glass ceramic can be damaged by

objects falling onto it, or knocked by the
cookware.

Product description

Cooking surface layout

1

2

• Cookware made of cast iron, cast alumi­num or with damaged bottoms can
scratch the glass ceramic if slid on the
surface.

• To avoid damaging cookware and glass
ceramics, do not allow saucepans or fry­ing pans to boil dry.

• Do not use the cooking zones with empty
cookware or without cookware.

• Never line any part of the appliance with
aluminium foil. Never place plastic or any
other material which may melt in or on
the appliance.

Information on acrylamides
Important! According to the latest scientific

knowledge, intensive browning of food,
especially in products containing starch, can
constitute a health risk due to acrylamides.
Therefore, we recommend cooking at the
lowest possible temperatures and not
browning foods too much.

145 mm

210 mm

180 mm

145 mm

4 35

Single cooking zone 1200 W

1

Single cooking zone 1800 W

2

Single cooking zone 1200 W

3

Control panel

4

Single cooking zone 2300 W

5

ENGLISH 6

Control panel layout

1 2 43

to switch the hob on or off

1

to activate and deactivate the Lock

2

or the Child safety device

to increase , or to decrease the

3

heat settings
A heat setting display:

4

Touch Control sensor fields and displays

You operate the hob by touching sensor
fields.

Heat setting dis-

play

Cooking zone is
switched off

-

Heat setting is set
A malfunction occur-

red

, from to

Description

Heat setting dis-

play

Residual heat indicator

Warning! Risk of burns from residual

heat! After you switch the appliance
off, the cooking zones need some time to
cool down. Look at the residual heat

indicator
Use residual heat for melting and keeping

food warm.

.

Description

A cooking zone is still
hot

The Child Safety De­vice is on

The Automatic Switch
off is on

Daily use

Switching on and off

Touch
ance on or off.

Adjusting the heat setting

Set the heat setting with

for 2 seconds to switch the appli-

to increase.

Set the heat setting with to decrease.

Touch and of a respective cooking
zone simultaneously to switch off the cook-

ing zone. The settings will reverse to

.

ENGLISH 7

•

Lock

When the cooking zones operate, you can
lock the control panel, but not
vents an accidental change of the heat set­ting.
First set the heat setting.
To start this function touch

comes on for 4 seconds.

To stop this function touch
ting that you set before comes on.
When you stop the appliance, you also stop
this function.

The child safety device

This function prevents an accidental opera­tion of the appliance.

To activate the child safety device

•

Activate the appliance with
set the heat settings.

•

Touch
comes on.

•

Deactivate the appliance with

To deactivate the child safety device

•

Activate the appliance with
set the heat settings. Touch
onds. The symbol

•

Deactivate the appliance with

To override the child safety device for
only one cooking time

•

Activate the appliance with
bol

for 4 seconds. The symbol

comes on.

comes on.

. It pre-

. The symbol

. The heat set-

. Do not

.

. Do not

for 4 sec-

.

. The sym-

Touch
ting in 10 seconds. You can operate the
appliance.

• When you deactivate the appliance with

again.

Automatic Switch off
The function switches the hob off

automatically if:

• all cooking zones are switched off.

• you do not set the heat setting after

switching on the hob.

• you cover any sensor field with objects (a

pan, a cloth, etc.) for longer than approx.
10 seconds.

• you do not switch a cooking zone off af-

ter a certain time, or you do not modify
the heat setting, or if the overheating oc­curs (e.g. when a pan boils dry). The sym-

bol
must set the cooking zone to

Heat setting Automatic switch off af-

for 4 seconds. Set the heat set-

, the child safety device operates

lights up. Before using again, you

.

ter

-

-

-

6 hours
5 hours
4 hours

1.5 hours

Helpful hints and tips

When a cooking zone is switched on, it

may hum briefly. This is a characteristic
of all ceramic glass cooking zones and does
not impair either the function or the life of
the appliance.

Energy saving

• If possible, always place lids on the pans.

• Place cookware on the cooking zone be­fore you switch it on.

• The bottom of the cookware should be as
thick and flat as possible.

ENGLISH 8

• Switch cooking zones off before the end
of the cooking time, to take advantage of
residual heat

Care and cleaning

Warning! Switch the appliance off and

let it cool down before you clean it.
Warning! For safety reasons, do not

clean the appliance with steam

blasters or high-pressure cleaners.

Warning! Sharp objects and abrasive

cleaning agents will damage the
appliance. Clean the appliance and
remove the residues with water and
washing up liquid after each use. Remove
also the remnants of the cleaning agents!

Scratches or dark stains on the glass

ceramic that cannot be removed do
not affect the functioning of the appliance.

What to do if…

Problem Possible cause Remedy

The cooking zones will
not switch on or are not
functioning.

The residual heat indi­cator is not displaying
anything.

symbol plus a num­ber appears on the
heat setting display.

If there is a fault, first try to find a solution to
the problem yourself. If you cannot find a
solution to the problem yourself, contact
your dealer or the After Sales Service.

More than 10 seconds passed
since you switched on the hob.

The child safety device is on
.

The cooking zone was only on
for a short time and is there­fore not hot.

Electronics fault. Disconnect the appliance from

• Bottom of pans and cooking zones should
be the same size.

Removing the residues and stubborn
residues:

1. Food containing sugar, plastics, tin foil

residues should be removed at once,
best tool for cleaning glass surface is a
scraper (not included with the appli­ance). Place a scraper on the glass ce­ramic surface at an angle and remove
residues by sliding the blade over the
surface. Wipe the appliance with a
damp cloth and a little washing up liq­uid. Finally, rub the appliance dry using
a clean cloth.

2. Limescale rings, water rings, fat

splashes, shiny metallic discolorations
should be removed after the appliance
has cooled down using cleaner for
glass ceramic or stainless steel.

Switch the appliance on again.

Deactivate the child safety de­vice (See the section “Child
safety device ”).

If the cooking zone is supposed
to be hot, call the After Sales
Service.

the electrical supply for a few
minutes (Take the fuse out of
the house’s electric system) If

after switching on again,
displayed again, call the cus­tomer service department.

If you operated the appliance wrongly,

or the installation was not carried out
by a registered engineer, the visit from the
customer service technician or dealer may

is

ENGLISH 9

not take place free of charge, even during
the warranty period.

Technical information

Rating Plate

Made in Germany

© Inter IKEA Systems B.V. 1999

102.228.21

PQM

The graphic above represents the rating
plate of the appliance (without serial num­ber which is generated dynamically during
the production process), which is located at
its underneath surface of the casing.

Installation

Manufacturer is not responsible for any in­jury to persons and pets or damage to
property caused by failure to comply fol­lowing requirements.

Caution! To proceed with the
installation refer to the assembly

instructions.

Warning! Installation process must

follow the laws, ordinances, directives
and standards (electrical safety rules and
regulations, proper recycling in accordance
with the regulations, etc.) in force in the
country of use!

Warning! The appliance must be

earthed!

Warning! Risk of injury from electrical

current.

21552

Model BARMHÄRTIG Typ 58 HAD 54 AO 6,5kW

PNC 949 594 311 00 S NO ............... 220V-240V AC 50-60 Hz

230 V

DGT

Dear Customer, please apply here aside
the sticker you can find in the dedicate
plastic bag inserted inside the hob packag­ing. This will allow us to assist you better, by
identifying precisely your hob, in case you
will need in future our assistance. Thank you
for your help!

• The electrical mains terminal is live.

• Make electrical mains terminal free of
voltage.

• Loose and inappropriate plug and socket
connections can make the terminal over­heat.

• Have the clamping connections correctly
installed.

• Use strain relief clamp on cable.

• Follow the connection diagram (it is loca­ted on the underneath surface of the
casting of the hob).

Important! You must observe the minimum
distances to other appliances and furniture
cabinets or other units according to
Assembly Instruction.
If there is no oven beneath the hob insert a
dividing panel at a minimum distance of 20
mm from the bottom of the hob.

ENGLISH 10

Do not use silicon sealant between the ap­pliance and the worktop. Avoid installing
the appliance next to doors and under win­dows as hot cookware may be knocked off
the rings when doors and windows are
opened.
Only an authorized service engineer can in­stall, connect or repair this appliance. Use
only original spare parts.

Electrical connection

Before connecting, check that the nominal
voltage of the appliance stated on the rat­ing plate, corresponds to the available sup­ply voltage. Also, check the power rating of
the appliance and ensure that the wire is
suitably sized to suit the appliance power
rating (refer to the Technical data chapter).
The rating plate is located on the lower cas­ing of the hob.
The appliance is not provided with mains
cable. Buy the right one from specialized
dealer. Single-phase or two-phase connec­tion requires the mains cable of type H05
BB-F/H05V2V2-F Tmax 90°C (equal or
higher).
The appliance works perfectly on AC 230 V,
AC220V~ or AC240V~ 50Hz electrical net­work.

You must have the means for disconnection
incorporated in the fixed wiring. Have the
appliance connected to the mains using a
device that allows the appliance to be dis­connected from the mains at all poles with a
contact opening width of at least 3 mm, eg.
automatic line protecting cut-out, earth
leakage trips or fuse.
You must have the connection and the con­necting links carried out as shown in the
connection diagram (it is located on the un­derneath surface of the casting of the hob).
The earth lead is connected to terminal

marked with the symbol
longer than leads carrying electric current.
Tighten the terminal screws securely! Finally,
secure the connecting cable with the mains
cable cleat and the covering closed by
pressing firmly (lock into place).

Warning! Once connected to the

mains supply check that all cooking
zones are ready for use by briefly setting
each to maximum power.

and must be

Environment concerns

The symbol on the product or on its
packaging indicates that this product may
not be treated as household waste. Instead
it should be taken to the appropriate
collection point for the recycling of electrical
and electronic equipment. By ensuring this
product is disposed of correctly, you will
help prevent potential negative
consequences for the environment and
human health, which could otherwise be
caused by inappropriate waste handling of
this product. For more detailed information
about recycling of this product, please
contact your local council, your household

waste disposal service or the shop where
you purchased the product.

Packaging materials

The materials with the symbol
clable. Dispose the packaging in a suitable
collection containers to recycle it.

Before disposal of appliance

Warning! Do these steps to dispose

the appliance:

• Pull the mains plug out of the mains sock-

et.

• Cut off the mains cable and discard it.

are recy-

ENGLISH 11

IKEA GUARANTEE

How long is the IKEA guarantee valid?

This guarantee is valid for five (5) years
from the original date of purchase of Your
appliance at IKEA, unless the appliance is
named LAGAN in which case two (2) years
of guarantee apply. The original sales re­ceipt is required as proof of purchase. If
service work is carried out under guarantee,
this will not extend the guarantee period for
the appliance,

Which appliances are not covered by the
IKEA five (5) years guarantee?

The range of appliances named LAGAN
and all appliances purchased in IKEA be­fore 1st of August 2007

Who will execute the service?

IKEA service provider will provide the serv­ice through its own service operations or
authorized service partner network.

What does this guarantee cover?

The guarantee covers faults of the appli­ance, which have been caused by faulty
construction or material faults from the date
of purchase from IKEA. This guarantee ap­plies to domestic use only. The exceptions
are specified under the headline “What is
not covered under this guarantee?” Within
the guarantee period, the costs to remedy
the fault e.g. repairs, parts, labour and trav­el will be covered, provided that the appli­ance is accessible for repair without special
expenditure. On these conditions the EU
guidelines (Nr. 99/44/EG) and the respec­tive local regulations are applicable. Re­placed parts become the property of IKEA.

What will IKEA do to correct the problem?

IKEA appointed service provider will exam­ine the product and decide, at its sole dis­cretion, if it is covered under this guarantee.
If considered covered, IKEA service provider
or its authorized service partner through its
own service operations, will then, at its sole
discretion, either repair the defective prod­uct or replace it with the same or a compa­rable product.

What is not covered under this
guarantee?

• Normal wear and tear.

• Deliberate or negligent damage, dam-

age caused by failure to observe operat­ing instructions, incorrect installation or by
connection to the wrong voltage, dam­age caused by chemical or electro-chem­ical reaction, rust, corrosion or water
damage including but not limited to dam­age caused by excessive lime in the wa­ter supply, damage caused by abnormal
environmental conditions.

• Consumable parts including batteries

and lamps.

• Non-functional and decorative parts

which do not affect normal use of the ap­pliance, including any scratches and pos­sible color differences.

• Accidental damage caused by foreign

objects or substances and cleaning or un­blocking of filters, drainage systems or
soap drawers.

• Damage to the following parts: ceramic

glass, accessories, crockery and cutlery
baskets, feed and drainage pipes, seals,
lamps and lamp covers, screens, knobs,
casings and parts of casings. Unless such
damages can be proved to have been
caused by production faults.

• Cases where no fault could be found dur-

ing a technician’s visit.

• Repairs not carried out by our appointed

service providers and/or an authorized
service contractual partner or where non­original parts have been used.

• Repairs caused by installation which is

faulty or not according to specification.

• The use of the appliance in a non-domes-

tic environment i.e. professional use.

ENGLISH 12

• Transportation damages. If a customer
transports the product to their home or
other address, IKEA is not liable for any
damage that may occur during transport.
However, if IKEA delivers the product to
the customer's delivery address, then
damage to the product that occurs during
this delivery will be covered by this guar­antee.

• Cost for carrying out the initial installation
of the IKEA appliance. However, if an
IKEA service provider or its authorized
service partner repairs or replaces the
appliance under the terms of this guaran­tee, the service provider or its authorized
service partner will re-install the repaired
appliance or install the replacement, if
necessary.

This restriction do not apply to fault-free
work carried out by a qualified specialist
using our original parts in order to adapt
the appliance to the technical safety specifi­cations of another EU country.

How country law applies

The IKEA guarantee gives You specific legal
rights, which covers or exceed local de­mands. However these conditions do not
limit in any way consumer rights described
in the local legislation

Area of validity

For appliances which are purchased in one
EU country and taken to another EU coun­try, the services will be provided in the
framework of the guarantee conditions nor­mal in the new country. An obligation to
carry out services in the framework of the
guarantee exists only if the appliance com­plies and is installed in accordance with:

• the technical specifications of the country
in which the guarantee claim is made;

• the Assembly Instructions and User Man­ual Safety Information;

The dedicated After Sales Service for
IKEA appliances:

Please do not hesitate to contact IKEA After
Sales Service to:

1. make a service request under this guar-

antee;

2. ask for clarification on installation of the
IKEA appliance in the dedicated IKEA
kitchen furniture. The service won’t pro­vide clarifications related to:
– the overall IKEA kitchen installation;
– connections to electricity (if machine

comes without plug and cable), to
water and to gas since they have to
be executed by an authorized serv­ice engineer.

3. ask for clarification on user manual con­tents and specifications of the IKEA ap­pliance.

To ensure that we provide you with the best
assistance, please read carefully the As­sembly Instructions and/or the User Manual
section of this booklet before contacting us.

How to reach us if You need our service

Please refer to the last page of this manual
for the full list of IKEA appointed contacts
and relative national phone numbers.

Important! In order to provide You with a
quicker service, we recommend that You
use the specific phone numbers listed at the
end of this manual. Always refer to the
numbers listed in the booklet of the specific
appliance You need an assistance for.
Before calling us, assure that You have to
hand the IKEA article number (8 digit code)
for the appliance of which you need our
assistance.

Important! SAVE THE SALES RECEIPT! It is
Your proof of purchase and required for the
guarantee to apply. Note that the receipt
reports also the IKEA article name and
number (8 digit code) for each of the
appliances you have purchased.

ENGLISH 13

Do You need extra help?

For any additional questions not related to
After Sales of your appliances, please con-

tact our nearest IKEA store call centre. We
recommend you read the appliance docu­mentation carefully before contacting us.

DEUTSCH 14

Inhalt

Sicherheitshinweise 14
Gerätebeschreibung 16
Täglicher Gebrauch 17
Praktische Tipps und Hinweise 18
Reinigung und Pflege 18

Änderungen vorbehalten.

Was tun, wenn … 19
Technische Daten 20
Montage 20
Umwelttipps 21
IKEA GARANTIE 22

Sicherheitshinweise

Zur Gewährleistung der Sicherheit und

der richtigen Bedienung des Geräts le­sen Sie diese Anleitung vor der Installation
und Verwendung sorgfältig durch. Bewah­ren Sie diese Bedienungsanleitung in der
Nähe des Geräts auf, auch wenn Sie dieses
anderswo aufstellen oder verkaufen. Alle
Benutzer müssen mit der Bedienung und
den Sicherheitseigenschaften des Geräts
vertraut sein.

Bestimmungsgemäße Verwendung

• Lassen Sie das Gerät bei Betrieb nicht

unbeaufsichtigt.

• Das Gerät ist ausschließlich zur Verwen-

dung im Haushalt bestimmt.

• Das Gerät darf nicht als Arbeits- oder

Abstellfläche verwendet werden.

• Brennbare Flüssigkeiten, leicht entzündli-

che Materialien oder schmelzbare Mate­rialien (z.B. Folien, Kunststoff, Aluminium)
dürfen nicht auf dem Gerät oder in des­sen Nähe abgestellt oder gelagert wer­den.

• Vorsicht bei Anschluss von Elektrogeräten

an Steckdosen in Gerätenähe. Die An­schlussleitungen dürfen nicht unter dem
Gerät oder heißem Kochgeschirr einge­klemmt werden oder damit in Berührung
kommen.

• Versuchen Sie nicht, selbst Reparaturen

auszuführen. Andernfalls besteht Unfall­gefahr und das Gerät könnte beschädigt
werden. Wenden Sie sich stets an Ihren
lokalen Kundendienst (siehe hierzu den
Abschnitt "Wartung").

Sicherheit von Kindern

• Nur Erwachsene dürfen dieses Gerät be­dienen. Kinder müssen beaufsichtigt wer­den, so dass sie nicht mit dem Gerät spie­len können.

• Halten Sie das Verpackungsmaterial von
Kindern fern. Andernfalls besteht Ersti­ckungsgefahr.

• Halten Sie Kinder von dem Gerät fern,
wenn es in Betrieb ist.

Warnung! Aktivieren Sie die

Kindersicherung, um ein
versehentliches Einschalten durch
Kleinkinder und Haustiere zu verhindern.

Allgemeine Sicherheit

• Personen (einschließlich Kinder), die auf-

grund ihrer physischen, sensorischen oder
geistigen Fähigkeiten oder ihrer Unerfah­renheit oder Unkenntnis nicht in der Lage
sind, das Gerät sicher zu bedienen, soll­ten dieses Gerät nicht ohne Aufsicht oder
Anweisung durch eine verantwortliche
Person benutzen.

Aufstellung

• Vergewissern Sie sich, dass das Gerät

beim Transport nicht beschädigt wurde.
Schließen Sie ein beschädigtes Gerät
nicht an. Wenden Sie sich bei Bedarf an
den Kundendienst (siehe hierzu den Ab­schnitt "Wartung").

•Dieses Gerät darf nur von einem autori-

sierten Servicetechniker installiert, ange­schlossen oder repariert werden. Ver­wenden Sie nur Originalersatzteile.

DEUTSCH 15

• Einbaugeräte dürfen nur nach dem Ein­bau in normgerechte, passende Einbau­schränke und Arbeitsplatten betrieben
werden.

• Nehmen Sie weder technische noch an­derweitige Modifikationen am Gerät vor.
Andernfalls besteht Unfallgefahr und das
Gerät könnte beschädigt werden.

Warnung! Beachten Sie genau die
Anweisungen zu den elektrischen und

Gasanschlüssen.

• Das Gerät niemals installieren, wenn es
während des Transports beschädigt wur­de.

Sicherheit während der Benutzung

• Entfernen Sie das gesamte Verpackungs­material sowie alle Etiketten und Folien
vom Gerät, bevor Sie es in Betrieb neh­men.

• Achtung! Brandgefahr! Überhitzte Fette
und Öle entzünden sich sehr schnell.

• Schalten Sie nach jedem Gebrauch die
Kochzonen aus.

• Verbrennungsgefahr! Gegenstände aus
Metall, wie z.B. Messer, Gabeln und Löf­fel und Topddeckel nicht auf das Koch­feld legen, da sie heiß werden können.

Warnung! Schalten Sie das Gerät

sofort ab, wenn Sie Risse auf der
Glaskeramikfläche feststellen, um die
Gefahr eines Stromschlags zu vermeiden,
und wenden Sie sich an den Kundendienst
(siehe hierzu den Abschnitt "Wartung").

Warnung! Benutzen Sie das Gerät

nicht mit nassen Händen und achten

Sie darauf, dass die Oberfläche des
Bedienfelds stets trocken ist. Die
Bedienelemente am Bedienfeld verlieren
ihre Funktionstüchtigkeit, wenn sie mit viel
Wasser in Berührung kommen.

Vermeidung von Schäden am Gerät

• Die Glaskeramik kann durch herabfallen­de Gegenstände oder durch das Koch­geschirr beschädigt werden.

• Kochgeschirr aus Gusseisen, Aluguss oder
mit beschädigten Böden können beim
Verschieben die Glaskeramik verkratzen.

• Das Leerkochen von Töpfen und Pfannen
vermeiden. Es kann Beschädigungen am
Kochgeschirr oder der Glaskeramik ver­ursachen.

• Benutzen Sie die Kochzonen nicht mit lee­rem oder ohne Kochgeschirr.

• Legen Sie nie einen Teil des Gerätes mit
Alu-Folie aus. Legen Sie keine Gegen­stände aus Kunststoff oder aus anderem
Material, das schmelzen kann, in oder
auf auf das Gerät.

Hinweis zu Acrylamid
Wichtig! Nach neuesten wissenschaftlichen

Erkenntnissen kann eine intensive Bräunung
von Lebensmitteln, speziell bei
stärkehaltigen Produkten, eine
gesundheitliche Gefährdung durch
Acrylamid verursachen. Daher empfehlen
wir, möglichst bei niedrigen Temperaturen
zu garen und die Speisen nicht zu stark zu
bräunen.

DEUTSCH 16

Gerätebeschreibung

Kochfeldanordnung

1

145 mm

210 mm

Bedienfeldanordnung

1 2 43

180 mm

145 mm

4 35

2

Einkreis-Kochzone 1200 W

1

Einkreis-Kochzone 1800 W

2

Einkreis-Kochzone 1200 W

3

Bedienfeld

4

Einkreis-Kochzone 2300 W

5

Zum Ein- und Ausschalten des Koch-

1

felds

Zum Ein- und Ausschalten der Tas-

2

tenverriegelung oder Kindersicherung

Zum Erhöhen oder Senken der

3

Kochstufen
Kochstufenanzeige:

4

, von bis

Touch Control-Sensorfelder und Anzeigen

Das Kochfeld wird durch Berühren der Sen­sorfelder bedient.

Kochstufenanzei-

ge

-

Beschreibung

Die Kochzone ist
ausgeschaltet

Die Kochstufe ist ein­gestellt

Es ist eine Störung
aufgetreten

Eine der Kochzonen
ist noch warm
