Page 1
PSB10
Presto Soft Boxes for 1 x 1 LED Lights
Quick Start Guide
What’s Included
1 x Soft box
1 x Egg crate
1 x Storage pouch
Page 2
Getting Started
Thank you for buying the Presto Soft Box from Ikan. Please carefully read the instructions and guide before operating the products. The guide includes
product usage and maintenance. When you operate the product, please make sure that you have read the instructions carefully. All the content of the
manual is based on up-to-date information; technical data subject to change without notice.
Step-by-Step Guide to preparing and installing your Presto Soft Box
Step 1: Remove the Presto soft box from the
carrying pouch. (Note: be careful that the box
doesn’t spring open when removing it from
carrying pouch.)
Step 4: Check the inside of the soft box to make
sure that all of the material is fully expanded
and there are no cuts or openings.
Step 2: Gently allow the frame of the soft box
to open and take shape. This allows the box to
take shape and start forming the frame.
Step 5: Placing the soft box on the light and
fitting it into place. The soft box will slip over
the barn doors and slid around the edges of the
light. The back flaps will fit around the light and
the hook straps will attach to the loop patches
on the side flaps.
Step 3: Straighten the rods at each corner of
the box. Allow the magnets to attach and form a
solid rod locking the box in open position.
Step 6: Once the back flaps have been set take
the two long elastic straps and attach them over
the back of the light. (Note: Pushing the barn
doors out from the front of the box through the
diffusion will allow the box to stay on better.)
Step 7: (Optional) The included egg crate can
be placed on the soft box to allow the soft light
to be more controlled with less light spill.
Page 3
Compatibility
The PSB10 Presto Soft Box is compatible with the following Ikan lights:
LB10
LBX10
LW10
LWX10
RB10
RBX10
RW10
RWX10
Lyra Bi-Color 1 x 1 LED Panel
Lyra Bi-Color 1 x 1 LED Panel w/ DMX Control
Lyra Daylight 1 x 1 LED Panel
Lyra Daylight 1 x 1 LED Panel w/ DMX Control
Rayden Bi-Color 1 x 1 LED Panel
Rayden Bi-Color 1 x 1 LED Panel w/ DMX Control
Rayden Daylight 1 x 1 LED Panel
Rayden Daylight 1 x 1 LED Panel w/ DMX Control
Specifications
Shipping Weight 3 lb
Shipping Dimensions 10 x 10 x 4 in
Product Weight 2 lb
Operational Dimensions 21 x 21 x 8 in
Build Material Canvas, Metal, Rayon
Learn More
More dynamic information at official website: www.ikancorp.com
Support
Contact email: [email protected]
CONDITIONS OF WARRANTY SERVICE
• Free service for one year from the day of purchase if the problem is caused by manufacturing errors.
• The components and maintenance service fee will be charged if the warranty period is expired.
Free Service will not be Provided in the Following Situations:(*Even if the product is still within the warranty period.)
• Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company.
• Damage caused by natural disaster, abnormal voltage, and environmental factors, etc.
©2019 Ikan International. All rights reserved.
