Iiyama Pro Lite PLH430 User Manual

USER MANUAL

Thank you very much for choosing the iiyama
LCD monitor.
We recommend that you take a few minutes to
read carefully through this brief but
comprehensive manual before installing and
switching on the monitor. Please keep this
manual in a safe place for your future
reference.

ENGLISH

Congratulations!

You have just purchased a TCO’99 approved and labelled

product! Your choice has provided you with a product developed

for professional use. Your purchase has also contributed to

reducing the burden on the environment and also to the further

development of environmentally adapted electronics products.

Why do we have environmentally labelled computers?

In many countries, environmental labelling has become an established method for encouraging the adaptation

of goods and services to the environment. The main problem, as far as computers and other electronics

ENGLISH

ENGLISH

equipment are concerned, is that environmentally harmful substances are used both in the products and during

their manufacture. Since it is not so far possible to satisfactorily recycle the majority of electronics equipment,

most of these potentially damaging substances sooner or later enter nature.

There are also other characteristics of a computer, such as energy consumption levels, that are important

from the viewpoints of both the work (internal) and natural (external) environments. Since all methods of

electricity generation have a negative effect on the environment (e.g. acidic and climate-influencing emissions,

radioactive waste), it is vital to save energy. Electronics equipment in offices is often left running continuously

and thereby consumes a lot of energy.

What does labelling involve?

This product meets the requirements for the TCO’99 scheme which provides for international and environmental

labelling of personal computers. The labelling scheme was developed as a joint effort by the TCO (The Swedish

Confederation of Professional Employees), Svenska Naturskyddsforeningen (The Swedish Society for Nature

Conservation) and Statens Energimyndighet (The Swedish National Energy Administration).

Approval requirements cover a wide range of issues: environment, ergonomics, usability, emission of electric

and magnetic fields, energy consumption and electrical and fire safety.

The environmental demands impose restrictions on the presence and use of heavy metals, brominated and

chlorinated flame retardants, CFCs (freons) and chlorinated solvents, among other things. The product must

be prepared for recycling and the manufacturer is obliged to have an environmental policy which must be

adhered to in each country where the company implements its operational policy.

The energy requirements include a demand that the computer and/or display, after a certain period of

inactivity, shall reduce its power consumption to a lower level in one or more stages. The length of time to

reactivate the computer shall be reasonable for the user.

Labelled products must meet strict environmental demands, for example, in respect of the reduction of

electric and magnetic fields, physical and visual ergonomics and good usability.

Below you will find a brief summary of the environmental requirements met by this product. The complete

environmental criteria document may be ordered from:

TCO Development

SE-114 94 Stockholm, Sweden

Fax: [phone]

Email (Internet): [email protected]

Current information regarding TCO’99 approved and labelled products may also be

obtained via the Internet, using the address: http://www.tco-info.com/

Environmental requirements

Flame retardants

Flame retardants are present in printed circuit boards, cables, wires, casings and housings. Their purpose is to

prevent, or at least to delay the spread of fire. Up to 30% of the plastic in a computer casing can consist of

flame retardant substances. Most flame retardants contain bromine or chloride, and those flame retardants are

chemically related to another group of environmental toxins, PCBs. Both the flame retardants containing

bromine or chloride and the PCBs are suspected of giving rise to severe health effects, including reproductive

damage in fish-eating birds and mammals, due to the bio-accumulative

been found in human blood and researchers fear that disturbances in foetus development may occur.

The relevant TCO’99 demand requires that plastic components weighing more than 25 grams must not contain

flame retardants with organically bound bromine or chlorine. Flame retardants are allowed in the printed circuit

boards since no substitutes are available.

*

processes. Flame retardants have

ENGLISH

ENGLISH

Cadmium

**

Cadmium is present in rechargeable batteries and in the colour-generating layers of certain computer displays.

Cadmium damages the nervous system and is toxic in high doses. The relevant TCO’99 requirement states

that batteries, the colour-generating layers of display screens and the electrical or electronics components

must not contain any cadmium.

**

Mercury

Mercury is sometimes found in batteries, relays and switches. It damages the nervous system and is toxic

in high doses. The relevant TCO’99 requirement states that batteries may not contain any mercury. It also

demands that mercury is not present in any of the electrical or electronics components associated with the

labelled unit.

CFCs (freons)

The relevant TCO’99 requirement states that neither CFCs nor HCFCs may be used during the manufacture

and assembly of the product. CFCs (freons) are sometimes used for washing printed circuit boards. CFCs

break down ozone and thereby damage the ozone layer in the stratosphere, causing increased reception on

earth of ultraviolet light with e.g. increased risks of skin cancer (malignant melanoma) as a consequence.

**

Lead

Lead can be found in picture tubes, display screens, solders and capacitors. Lead damages the nervous

system and in higher doses, causes lead poisoning. The relevant TCO’99 requirement permits the inclusion of

lead since no replacement has yet been developed.

* Bio-accumulative is defined as substances which accumulate within living organisms

** Lead, Cadmium and Mercury are heavy metals which are Bio-accumulative.

FCC DECLARATION OF CONFORMITY

Model Number: PLH430

Trade Name: iiyama

Responsible party: IIYAMA North America, Inc.

Address: 65 West Street Road, Suite 101B, Warminster, PA 18974 U.S.A.

Telephone number: 215-682-9050

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)

This device may not cause harmful interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

This device has been tested and found to comply with the limits for Class B Personal Computers and

ENGLISH

ENGLISH

peripherals, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference when the device is operated in a residential environment. This device generates,

uses and can radiate radio frequency energy, and if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If you determine the device does cause harmful interference to radio

or television reception (this may be determined by monitoring the interference while turning the device off and

on), you are encouraged to try to correct the interference by one of the following measures:

n Reorient or relocate the receiving antenna.

n Increase the separation between the device and receiver.

n Connect the device into an outlet on a circuit different from that to which the receiver

is connected.

n Consult the dealer or an experienced radio or TV technician for help.

To meet the FCC requirements, you should use a signal cable with ferrite core at both ends.

CAUTION Changes or modifications not expressly approved by iiyama could void the users authority

to operate the device under FCC compliance regulations.

CANADIAN DEPARTMENT OF COMMUNICATIONS COMPLIANCE
STATEMENT

This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as

set out in the radio interference regulation of the Canadian department of communications.

CE MARKING DECLARATION OF CONFORMITY

This LCD monitor complies with the requirements of the EC Directive 89/336/EEC “EMC Directive” and 73/23/

EEC “Low Voltage Directive” as amended by Directive 93/68/EEC.

The electro-magnetic susceptibility has been chosen at a level that gives correct operation in residential areas,

business and light industrial premises and small-scale enterprises, inside as well as outside of the buildings.

All places of operation are characterised by their connection to the public low voltage power supply system.

n We reserve the right to change specifications without notice.

n All trademarks used in this user manual are the property of their respective owners.

n As an ENERGY STAR

energy efficiency.

®

Partner, iiyama has determined that this product meets the ENERGY STAR® guidelines for

TABLE OF CONTENTS

FOR YOUR SAFETY .............................................................................. 1

SAFETY PRECAUTIONS ................................................................. 1

SPECIAL NOTES ON LCD MONITORS ............................................. 3

CUSTOMER SERVICE ...................................................................... 3

CLEANING ....................................................................................... 3

BEFORE YOU OPERATE THE MONITOR ................................................ 4

FEATURES ....................................................................................... 4

CHECKING THE CONTENTS OF THE PACKAGE ............................. 5

OPTIONAL PARTS ........................................................................... 5

CONTROLS AND CONNECTORS .................................................... 6

CONNECTING YOUR MONITOR ...................................................... 7

COMPUTER SETTING....................................................................... 8

HOW TO USE THE INFORMATION CD ............................................. 9

ADJUSTING THE HEIGHT AND THE VIEWING ANGLE ................... 10

PANEL ROTATION ............................................................................ 10

OPERATING THE MONITOR ................................................................... 11

ADJUSTMENT MENU CONTENTS .................................................... 12

SCREEN ADJUSTMENTS ................................................................. 18

POWER MANAGEMENT FEATURE .................................................. 20

TROUBLE SHOOTING ............................................................................ 21

APPENDIX A ........................................................................................... 22

SPECIFICATIONS ............................................................................. 22

DIMENSIONS .................................................................................... 23

COMPLIANT TIMING ......................................................................... 23

CONNECTOR PIN ASSIGNMENT ...................................................... 24

APPENDIX B ........................................................................................... 25

ENGLISH

ENGLISH

FOR YOUR SAFETY

SAFETY PRECAUTIONS

WARNING

STOP OPERATING THE MONITOR WHEN YOU SENSE TROUBLE

If you notice any abnormal phenomena such as smoke, strange sounds or fumes, unplug the monitor
and contact your dealer or iiyama service center immediately. Further use may be dangerous and
can cause fire or electric shock.

NEVER REMOVE THE CABINET

High voltage circuits are inside the monitor. Removing the cabinet may expose you to the danger of

ENGLISH

ENGLISH

fire or electric shock.

DO NOT PUT ANY OBJECT INTO THE MONITOR

Do not put any solid objects or liquids such as water into the monitor. In case of an accident, unplug
your monitor immediately and contact your dealer or iiyama service center. Using the monitor with
any object inside may cause fire, electric shock or damage.

INSTALL THE MONITOR ON A FLAT, STABLE SURFACE

The monitor may cause an injury if it falls or is dropped.

DO NOT USE THE MONITOR NEAR WATER

Do not use where water may be splashed or spilt onto the monitor as it may cause fire or electric
shock.

OPERATE UNDER THE SPECIFIED POWER SUPPLY

Be sure to operate the monitor only with the specified power supply. Use of an incorrect voltage will
cause malfunction and may cause fire or electric shock.

PROTECT THE CABLES

Do not pull or bend the power cable and signal cable. Do not place the monitor or any other heavy
objects on the cables. If damaged, the cables may cause fire or electric shock.

ADVERSE WEATHER CONDITIONS

It is advisable not to operate the monitor during a heavy thunder storm as the continual breaks in
power may cause malfunction. It is also advised not to touch the plug in these circumstances as it
may cause electric shock.

1 FOR YOUR SAFETY

CAUTION

INSTALLATION LOCATION

Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky
areas as it may cause fire, electric shock or damage. You should also avoid areas where the sun
shines directly on the monitor.

DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION

The monitor may topple and cause injury if not suitably located. Please also ensure that you do not
place any heavy objects on the monitor, and that all cables are routed such that children may not pull
the cables and possibly cause injury.

MAINTAIN GOOD VENTILATION

Ventilation slots are provided to keep the monitor from overheating. Covering the slots may cause
fire. To allow adequate air circulation, place the monitor at least 10 cm (or 4 inches) from any walls.
Do not remove the tilt stand when operating the monitor. Ventilation slots on the back of the cabinet
will be blocked and the monitor may overheat if the stand is removed. This may cause fire or damage.
Operating the monitor on its back, side, upside down or on a carpet or any other soft material may
also cause damage.

DISCONNECT THE CABLES WHEN YOU MOVE THE MONITOR

When you move the monitor, turn off the power switch, unplug the monitor and be sure the signal
cable is disconnected. If you do not disconnect them, it may cause fire or electric shock.

UNPLUG THE MONITOR

If the monitor is not in use for a long period of time it is recommended that it is left unplugged to avoid
accidents.

HOLD THE PLUG WHEN DISCONNECTING

To disconnect the power cable or signal cable, always pull it by the plug. Never pull on the cable itself
as this may cause fire or electric shock.

DO NOT TOUCH THE PLUG WITH WET HANDS

Pulling or inserting the plug with wet hands may cause electric shock.

WHEN YOU INSTALL THE MONITOR ON YOUR COMPUTER

Be sure the computer is strong enough to hold the weight of the monitor, otherwise, you may damage
your computer.

ENGLISH

ENGLISH

OTHERS

ERGONOMIC RECOMMENDATIONS

To eliminate eye fatigue, do not operate the monitor against a bright background or in a dark room. For
optimal viewing comfort, the monitor should be just below eye level and 40-60 cm (16-24 inches)
away from your eyes. When using the monitor over a prolonged time, a ten minute break every hour
is recommended as looking at the screen continuously can cause eye strain.

FOR YOUR SAFETY 2

SPECIAL NOTES ON LCD MONITORS

The following symptoms are normal with LCD monitors and do not indicate a problem.

NOTE

ENGLISH

ENGLISH

When you first turn on the LCD monitor, the picture may not fit in the display area

n

because of the type of computer that is used. In this case, adjust the picture
position to the correct position.
Due to the nature of the backlight, the screen may flicker during initial use. Turn off

n

the Power Switch and then turn it on again to make sure the flicker disappears.
You may find slightly uneven brightness on the screen depending on the desktop

n

pattern you use.

n

Due to the nature of the LCD screen, an afterimage of the previous screen may
remain after switching the image, when the same image is displayed for hours. In
this case, the screen is recovered slowly by changing the image or turning off the
Power Switch for hours. There is the possibility that the previous screen has been
fixed. Pay attention sufficient when you use LCD Monitor.

n

Contact your dealer or iiyama service center for the backlight replacement when the
screen is dark, flickering or not lighting up. Never attempt to replace it by yourself.

CUSTOMER SERVICE

n

NOTE

The fluorescent light used in the LCD monitor may have to be periodically replaced.
For the warranty coverage on this component, please check with local iiyama
service center.
If you have to return your unit for service and the original packaging has been

n

discarded, please contact your dealer or iiyama service center for advice or
replacement packaging.

CLEANING

WARNING

CAUTION

NOTE To protect the LCD panel, do not scratch or rub the screen with a hard object.

CABINET

LCD

SCREEN

3 FOR YOUR SAFETY

If you drop any materials or liquids such as water into the monitor when cleaning,

n

unplug the power cable immediately and contact your dealer or iiyama service center.

For safety reasons, turn off the power switch and unplug the monitor before you clean it.

n

n

Never use any of the following strong solvents. These will damage the cabinet and

n

the LCD screen.

Thinner
Benzine
Abrasive cleaner

Touching the cabinet with any product made from rubber or plastic for a long time

n

may cause degeneration or loss of paint on the cabinet.

Stains can be removed with a cloth lightly moistened with a mild detergent solvent. Then
wipe the cabinet with a soft dry cloth.

Periodic cleaning with a soft dry cloth is recommended.
Don't use tissue paper etc. because these will damage the LCD screen.

Spray-type cleaner
Wax
Acid or Alkaline solvent

BEFORE YOU OPERATE THE MONITOR

The monitor functions as a hub when connected to a USB compliant computer and USB peripherals.
However, with older operating systems and/or BIOS settings in your computer, the USB hub may not
operate. In this case, please contact your computer dealer first for advice.

FEATURES

u 43cm (17.0") TFT Color LCD Monitor

u Supports Resolutions up to 1280 × 1024

u Wide Viewing Angle and High Contrast

u Economy Mode

Reduced Power Consumption

u Multi-Color Control

Supports sRGB International Standard

u Gamma Control

Clear Display for Moving Pictures & Photographs

u Digital Character Smoothing

u Automatic Set-up

u Plug & Play VESA DDC1/2B (Analog) , DDC2B (Digital) Compliant

®

Windows

u Power Management (ENERGY STAR® and VESA DPMS Compliant)

u Ergonomic Design

TCO ’99 and MPR 3 Approved

u Digital Input (DVI-D) for Clear Display

u USB Hub Function

u 90° Panel Rotation Design

u VESA Mounting Standard (100mm×100mm) Compliant

95/98/2000/Me/XP Compliant

ENGLISH

ENGLISH

BEFORE YOU OPERATE THE MONITOR 4

CHECKING THE CONTENTS OF THE PACKAGE

The following accessories are included in your package. Check to see if they are enclosed with the monitor.
If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama office.

n Power Cable* n D-Sub Signal Cable n DVI-D Signal Cable
n USB Cable n Information CD n Quick Start Guide
n Sample: Pivot® & Liquid View® software (CD)

Pivot®: This software enables to rotate the orientation of the screen to display in portrait or

Liquid View®: This software enables to scale icons up.
Consult english.txt in CD-ROM for installation.

landscape mode.

CAUTION

ENGLISH

ENGLISH

* TO USERS IN 120V AREA

The rating of the Power Cable enclosed in 120V area is 10A/125V. If you are using
a power supply higher than this

250V must be used.
However, all guarantees and warranties are void for any problems or damage

caused by a power cable not supplied by iiyama.

rating, then a power cable with a rating of 10A/

OPTIONAL PARTS

Optional parts as below are available for your LCD monitor. Please contact your local iiyama dealer or
regional iiyama office for them. The Speaker is attached to the monitor to output a sound from the computer
or the audio equipment. The Video Adapter enables you to connect the video equipment to the
monitor. The Protection Sheet is attached to LCD panel surface to protect it from stains or scratches.

n Speaker

ProLite H430: OSP1-2 (Bottom, Monoral) ProLite H430-B: OSP1-2B (Bottom, Monoral)

OSP2-2 (Right/Left, Stereo) OSP2-2B (Right/Left, Stereo)

n Video Adapter OVA1-3
n Protection Sheet (Parts No. 832Z001-02)

5 BEFORE YOU OPERATE THE MONITOR

CONTROLS AND CONNECTORS

<Front> <Back>

Power Indicator

A

NOTE

Power Switch (POWER)

B

Auto set-up Button (AUTO)

C

+ / Brightness Button (+ / )

D

– / Contrast Button (– / )

E

Menu Button (MENU)

F

Input Button (INPUT)

G
H Main Power Switch

AC Connector (AC IN)

I

USB-UP

J

Connect with a USB compliant computer by the USB Cable attached to the monitor.
USB-DOWN

K

Connect any cables from USB compliant peripherals such as mouse, keyboard, etc.
D-Sub mini 15pin Connector (D-SUB)

L

DVI-D 24pin Connector (DVI-D)

M

Optional Video Adapter Slot (OPTIONAL VIDEO INPUT)

N

Optional Speaker Connector (DC OUT)

O

Keyhole for Security Lock

P

NOTE

Green: Normal operation (Pro Lite H430)
Blue: Normal operation (Pro Lite H430-B)
Orange: Power Management

The monitor enters into power management mode which reduces the power
consumption to less than 5W when receiving no horizontal and/or vertical
sync signal.

You can fasten a security lock and cable to prevent the monitor from being removed
without your permission.

ENGLISH

ENGLISH

BEFORE YOU OPERATE THE MONITOR 6

CONNECTING YOUR MONITOR

Ensure that both the computer and the monitor are switched off.

A

Connect the computer to the monitor with the signal cable. (See page 24 for CONNECTOR PIN

B

ASSIGNMENT.)
Connect the monitor to the USB compliant computer with the USB Cable when using the USB hub

C

features.
Connect the Power Cable to the monitor first and then to the power supply.

D

NOTE n The signal cables used for connecting the computer and monitor vary by the type of computer

used. An incorrect connection may cause serious damage to both the monitor and the
computer. The cable supplied with the monitor is for a standard 15 pin D-Sub connector. If a

ENGLISH

ENGLISH

special cable is required please contact your local iiyama dealer or regional iiyama office.

n For connection to Macintosh computers, contact your local iiyama dealer or regional

iiyama office for a suitable adaptor.

n Make sure you tighten the finger screws at each end of the signal cable.
n Cables are connected easily by rotating the panel 90 degrees. (See page 10 for PANEL

ROTATION.)

n Cables can be bundled together inside the cover at the back of the stand. See next page

for cable wiring.

[Example of Connection]

< Back >

Power Cable (Accessory)

Keyboard

7 BEFORE YOU OPERATE THE MONITOR

Mouse

Printer

Video Adapter OVA1-3 (Optional)

DVI-D Signal Cable (Accessory)
or
D-Sub Signal Cable (Accessory)

USB Cable (Accessory)

to DVI connector
of computer

to D-Sub connector of
computer

Computer

[Cable Wiring]

Remove the cover at the back of the stand by

A

sliding it upward.

Collect cables at the back of the stand.

B

Replace the cover by inserting the tabs into guide

C

holes and then sliding the cover downward.

COMPUTER SETTING

n Signal Timing

Change to the desired signal timing listed on page 23: COMPLIANT TIMING.

n Windows 95/98/2000/Me/XP Plug & Play

The iiyama LCD monitor complies with DDC1/2B (Analog) and DDC2B (Digital) of VESA standard.
The Plug & Play function runs on Windows 95/98/2000/Me/XP by connecting the monitor to DDC1/
2B or DDC2B compliant computer with the Signal Cable supplied.
For installation on Windows 95/98/2000/Me/XP: The monitor Information File for iiyama monitors
may be necessary. For installing procedure, see “Driver File” on the Information CD.

ENGLISH

ENGLISH

NOTE

n Monitor Drivers are not required in most cases for Macintosh or Unix operating systems.

For further information, please contact your computer dealer first for advice.

BEFORE YOU OPERATE THE MONITOR 8

HOW TO USE THE INFORMATION CD

l Windows

The Information CD runs automatically when you insert the CD into your computer.

l Macintosh

The Information CD will not run automatically when you insert the CD into your computer. Please
click the file “INDEX.HTML” on the Information CD.

l Software Requirements

n The Information CD is optimized for Microsoft® Internet Explorer (version 5.5 or greater)
n The contents may not be displayed properly with Netscape or other web browsers.
n The Information CD is not guaranteed to run under the Linux OS. Please read the file

ENGLISH

ENGLISH

“FOR_LINUX.TXT” for more information.

n Press the [Alt] &[Tab] keys together to display the [Monitor Check] screen if the menu page does

not appear in front of the test pattern when using the Adjustment Program.

n You will not see the opening image if Macromedia® Flash Player™ is not installed on your

computer. For full functionality please download the latest version from:

http://www.macromedia.com/downloads

n You will not be able to read the user manual if Adobe® Acrobat® Reader™ is not installed on your

computer. Instructions to install the Reader can be found on the Information CD by clicking on
the “User Manual” tab and reading “Get Acrobat Reader”.

l Language Selection

The Menu is in English on start-up. Select your language from “Select your language” pull-down
menu.

Linux is written and distributed under the GNU General Public License and its source code is freely-distributed and
available to the general public.

9 BEFORE YOU OPERATE THE MONITOR

ADJUSTING THE HEIGHT AND THE VIEWING ANGLE

n For optimal viewing it is recommended to look at

the full face of the monitor, then adjust the monitor’s
height and angle to your own preference.

n Hold the panel so that the monitor does not topple

when you change the monitor’s height or angle.

n You are able to adjust the monitor’s height up to 85

mm, angle up to 35 degrees right and left, 40
degrees upward.

NOTE n Do not touch the LCD screen when you

40˚

change the height or the angle. It may
cause damage or break the LCD screen.

n Careful attention is required not to catch

your fingers or hands when you change
the height or the angle.

PANEL ROTATION

85mm

35˚35˚

ENGLISH

ENGLISH

Adjust the monitor’s height to the maximum.

A

Rotate the panel 90 degrees.

B

Portrait: Turn clockwise.
Landscape: Turn counter clockwise.

NOTE n Attempting to rotate without fully

extending upward may cause
damage to stand.

n Please use attached Pivot

software for rotating the image
on the screen.

Adjust the monitor’s angle to your

C

preference.

90˚

®

BEFORE YOU OPERATE THE MONITOR 10

OPERATING THE MONITOR

To create the best picture, your iiyama LCD monitor has been preset at the factory

with the COMPLIANT
TIMING shown on page 23. You are also able to adjust the picture by following the button operation
shown below. For more detailed adjustments, see page 18 for SCREEN ADJUSTMENTS.

Press the Menu Button to start the On Screen Display feature. There are

(

additional Menu pages which can be switched by using the +/– Buttons.

Displayed while sRGB is active.

ENGLISH

ENGLISH

Current horizontal frequency,

Select the Menu page which contains the adjustment icon relating to the

B

Economy Mode

presently selected.

Adjustment icon

vertical refresh rate

and resolution

H: 80.0KHz V: 75.0Hz

1280 × 1024

Displayed while Lockout is active.
Signal select presently selected.

Menu: 1

Page no.

adjustment you want to make. Press the Menu Button again. Then, use the
+/– Buttons to highlight the desired adjustment icon. Press the Menu Button
again.

Use the +/– Buttons to make the appropriate adjustment or setting.

C

For example, to correct for vertical position, select Menu page number 1 and then press the Menu
Button. Then, select (V-Position) by using the +/– Buttons.

Menu: 1

V-Position

An adjustment scale appears after you press the Menu Button. Use the +/– Buttons to change the
vertical position settings. The vertical position of the overall display should be changing accordingly
while you are doing this.

V-Position

The bar shows

the progress of the

adjustment being made.

–

+

NOTE

The On Screen Display disappears several seconds after you stop pressing the buttons while

n

performing an adjustment.

Any changes are automatically saved in the memory when the On Screen Display

n

disappears.

Turning off the power should be avoided while using the Menu.

n

Adjustments for Clock, Phase and Position are saved for each signal timing. Except for these
adjustments, all other adjustments have only one setting which applies to all signal timings.

11 OPERATING THE MONITOR

ADJUSTMENT MENU CONTENTS

Direct

You can skip the Menu pages and display an adjustment scale directly by using the
following button operations.

l Brightness: Press the Brightness Button when the Menu is not displayed.

l Contrast: Press the Contrast Button when the Menu is not displayed.

l Auto Set-up: Press the Auto Set-up Button.

l Signal Select: Press the Input Button.

NOTE

SWITCHING BRIGHTNESS / CONTRAST ADJUSTMENT

To switch between Brightness and Contrast adjustments, press the Menu Button within 10
seconds after pressing the Brightness Button or the Contrast Button during the direct
adjustments above.

SIGNAL SELECT (D-SUB / DVI)

Select either D-SUB or DVI for the signal input when both of the signal inputs are connected
to a signal source. Switch D-SUB and DVI whenever pressing the Input Button.

ENGLISH

ENGLISH

OPERATING THE MONITOR 12

Analog Input

Menu : 1
(Analog)

ENGLISH

ENGLISH

Menu: 1

H: 80.0KHz V: 75.0Hz

1280 × 1024

Adjustment Item Problem / Option Button to Press

Brightness *

Contrast

2

Clock *

Phase *

2

H-Position

V-Position

1

Direct

Direct

Too dark
Too bright

Too dull
Too intense

To correct flickering text or lines

To correct flickering text or lines

Too far to the left
Too far to the right

Too low
Too high

Return to Menu Highlight “Menu : 1” again.

*1Adjust the Brightness or the Economy Mode when you are using the monitor in a dark room

and feel the screen is too bright.

*2See page 18 for SCREEN ADJUSTMENTS.

Direct

13 OPERATING THE MONITOR

See page 12 for Direct.

Menu : 2
(Analog)

Auto Set-up *

Direct

Menu: 2

H: 80.0KHz V: 75.0Hz

1280 × 1024

Problem / Option Button to PressAdjustment Item

No
Yes

Return to Menu.
Adjust Clock, Phase, H-Position and V-Poshition
automatically.

NOTE

NOTE

NOTE

n The screen becomes dark for approximately five seconds during the adjustment.

Color Temp.

n sRGB is an international standard which defines and unifies the difference of color

appearance between equipment.

n You can not adjust the Brightness, Contrast, Sharpness and Gamma in sRGB mode

because those settings are locked.

n is displayed while sRGB is active.

Sharpness

Gamma

Auto Balance

n Approximately three seconds during the adjustment.

1
2
3
s

User

1 2 3 4 5

Adjust the picture quality at resolutions of less than 1280 × 1024.
You can change the picture quality from 1 to 5 (sharp to soft).
Press the + Button to change the picture quality in numerical
order. Press the – Button to change the picture quality in reverse
numerical order.

Off Normal
Mode1 High contrast
Mode2

No
Yes

Color 1: 9300K
Color 2: 7500K
Color 3: 6500K
sRGB

R

Too weak

G

Too strong

B

Dark
Return to Menu.
Adjust the Red, Green and Blue to suitable colors

automatically.

ENGLISH

ENGLISH

Return to Menu Highlight “Menu : 2” again.

* For best results, use the Auto Set-up in conjunction with the adjustment pattern.

(See page 18 for SCREEN ADJUSTMENTS.)

Direct

See page 12 for Direct.

OPERATING THE MONITOR 14

Menu : 3
(Analog)

Menu: 3

H: 80.0KHz V: 75.0Hz

1280 × 1024

ENGLISH

ENGLISH

NOTE

NOTE

Adjustment Item

OSD Position

Problem / Option Button to Press

1 2 3 4 5
You can move the OSD display area

to any one of the following 5 positions
within the overall display:

Press the + Button to move the OSD in numerical order. Press
the – Button to move the OSD in reverse numerical order.

ENG

Language

GER
FRE
ITA
SPA
JPN

Economy Mode *

Off
Eco 1 Brightness of back-light is reduced.

Eco 2

n is displayed while Off is active.
n is displayed while Eco 1 is active.

1

n is displayed while Eco 2 is active.

2

Lockout

No

Yes

n is displayed while Yes is active.

English
German
French
Italian
Spanish
Japanese

Normal

Brightness of back-light is reduced more than Eco 1.

Lockout is canceled.
All adjustment items except this function are

locked out.

NOTE

Reset

Signal Select

No

Yes

D-SUB Select the analog input.

Direct

n is displayed while D-SUB is active.

Return to Menu.

Factory-preset data is restored.

Select the digital input.DVI

n is displayed while DVI is active.

Return to Menu

Highlight “Menu : 3” again.

* Adjust the Brightness or the Economy Mode when you are using the monitor in a dark room

and feel the screen is too bright.

Direct

15 OPERATING THE MONITOR

See page 12 for Direct.

Digital Input

Menu : 1
(Digital)

H: 80.0KHz V: 75.0Hz

1280 × 1024

Adjustment Item Problem / Option Button to Press

NOTE

Brightness *

Direct

Contrast

Direct

Color Temp.

n sRGB is an international standard which defines and unifies the difference of color

appearance between equipment.

n You can not adjust the Brightness, Contrast, Sharpness and Gamma in sRGB mode

because those settings are locked.

n is displayed while sRGB is active.

Too dark
Too bright

Too dull
Too intense

1
2
3
s

User

Color 1: 9300K
Color 2: 7500K
Color 3: 6500K
sRGB

Menu: 1

R

Too weak

G

Too strong

B

ENGLISH

ENGLISH

Sharpness

Gamma

Return to Menu

* Adjust the Brightness or the Economy Mode when you are using the monitor in a dark room

and feel the screen is too bright.

Direct

See page 12 for Direct.

1 2 3 4 5

Adjust the picture quality at resolutions of less than 1280 × 1024.
You can change the picture quality from 1 to 5 (sharp to soft).
Press the + Button to change the picture quality in numerical
order. Press the – Button to change the picture quality in reverse
numerical order.

Off Normal
Mode1 High contrast
Mode2

Highlight “Menu : 1” again.

Dark

OPERATING THE MONITOR 16

Menu : 2
(Digital)

Menu: 2

H: 80.0KHz V: 75.0Hz

1280 × 1024

ENGLISH

ENGLISH

NOTE

NOTE

Adjustment Item

OSD Position

Problem / Option Button to Press

1 2 3 4 5
You can move the OSD display area

to any one of the following 5 positions
within the overall display:

Press the + Button to move the OSD in numerical order. Press
the – Button to move the OSD in reverse numerical order.

ENG

Language

GER
FRE
ITA
SPA
JPN

Economy Mode *

Off
Eco 1 Brightness of back-light is reduced.

Eco 2

n is displayed while Off is active.
n is displayed while Eco 1 is active.

1

n is displayed while Eco 2 is active.

2

Lockout

No

Yes

n is displayed while Yes is active.

English
German
French
Italian
Spanish
Japanese

Normal

Brightness of back-light is reduced more than Eco 1.

Lockout is canceled.
All adjustment items except this function are locked

out.

NOTE

Reset

Signal Select

No

Yes

D-SUB Select the analog input.

Direct

n is displayed while D-SUB is active.

Return to Menu.

Factory-preset data is restored.

Select the digital input.DVI

n is displayed while DVI is active.

Return to Menu

Highlight “Menu : 2” again.

* Adjust the Brightness or the Economy Mode when you are using the monitor in a dark room

and feel the screen is too bright.

Direct

17 OPERATING THE MONITOR

See page 12 for Direct.

SCREEN ADJUSTMENTS

n The screen adjustments described in this manual are designed to set image position and minimize

flicker or blur for the particular computer in use.

n The monitor is designed to provide the best performance at resolution of 1280 × 1024, but can not

provide the best at resolutions of less than 1280 × 1024 because the picture is automatically
stretched to fit the full screen. It is recommended to operate at resolution of 1280 × 1024 in normal use.

n Displayed text or lines will be blurred or irregular in thickness when the picture is stretched due to

the screen enlargement process.

n It is preferable to adjust the image position and frequency with the monitor controls, rather than the

computer software or utilities.

n Perform adjustments after a warm-up period of at least thirty minutes.
n Additional adjustments may be required after the Auto Set-up depending on the resolution or signal

timing.

n The Auto Set-up may not work correctly when displaying the picture other than the screen

adjustment pattern. In this case, manual adjustments are required.

There are two ways to adjust the screen. One way is automatic adjustment for Position, Clock and
Phase. The other way is performing each adjustment manually.
Perform the Auto Set-up first when the monitor is connected to a new computer, or resolution is
changed. If the screen has a flicker or blur, or the picture does not fit in the display area after
performing the Auto Set-up, manual adjustments are required. Both adjustments should be made by
using the screen adjustment patterns in the Adjustment Program on the Information CD.

This manual explains adjustment under Windows 95/98/2000/Me/XP.

Start “Adjustment Program” in the Information CD.

A
B Select the resolution for your monitor - the adjustment pattern then appears.

ENGLISH

ENGLISH

[Adjustment pattern]

Zebra pattern

16-level gray scale

Color bar

Picture frame

OPERATING THE MONITOR 18

C Press the Auto Set-up Button.

D Adjust the image manually by following procedure below when the screen has a

flicker or blur, or the picture does not fit in the display area after performing the Auto

Set-up.

E Stretch the right side of the picture frame to the right edge of the display area by

adjusting the Clock.

ENGLISH

ENGLISH

F Adjust the Phase to correct horizontal wavy noise, flicker or blur in the zebra pattern.

G Select “Position” in the Adjustment Program and adjust the H-Position and V-Position

so that the frame of the cross-hatch pattern fits into the display area.

NOTE n When the left side of the picture frame moves away from the left edge of the display

area during the Clock adjustment, adjust Clock and H-Position alternately.

n Another way to make the Clock adjustment is to correct the vertical wavy lines in the

zebra pattern.

n The picture may flicker during the Clock, H-Position and V-Position adjustment.
n In case the picture frame is bigger or smaller than the data display area after the Clock

adjustment, repeat steps from C.

n In the case that a strong flicker or blurs remain on a part of the screen, repeat the

adjustments from E to readjust the Clock. If the flicker or blurs still remain then set the
refresh rate to 60Hz and repeat the adjustments from step C.

n Adjust the H-Position after the Phase adjustment if the horizontal position moves

during the adjustment.

19 OPERATING THE MONITOR

H Select “Brightness” in the Adjustment Program and adjust the Brightness and

Contrast so that all 16 levels of gray in the grayscale pattern are visible.

Click on “FINISH” to close the Adjustment Program.

POWER MANAGEMENT FEATURE

The power management feature of this product complies with every power saving requirement of
ENERGY STA R® and VESA DPMS. When activated, it automatically reduces unnecessary power
consumption of the monitor when your computer is not in use.
To use the feature, the monitor needs to be connected to a VESA DPMS compliant computer. There
is a power management step the monitor takes as described below. The power management function,
including any timer settings is configured by the operating system. Check your operating system
manual for information on how this can be configured.

Power Management Mode

When the H-sync signal / V-sync signal / H and V sync signals from the computer are off, the
monitor enters into Power Management Mode which reduces the power consumption to less than
5W. The screen becomes dark, and the power indicator turns to orange. From Power Management
Mode, the image reappears in several seconds when either the keyboard or the mouse are
touched again.

Power Indicator

NORMAL MODE

POWER MANAGEMENT MODE

Green/

Blue

Orange

ENGLISH

ENGLISH

NOTE

POWER
CONSUMPTION

Even when using the power management mode, the monitor consumes electricity. Turn

n

0 5 W 100%

off the Power Switch whenever the monitor is not in use, during the night and weekends,
to avoid unnecessary power consumption.
It is possible that the video signal from the computer may be on while the H or V sync

n

signal is missing. In this instance, the POWER MANAGEMENT feature may not work
properly.

OPERATING THE MONITOR 20

TROUBLE SHOOTING

If the monitor fails to operate correctly, please follow the steps below for a possible solution.

Perform the adjustments described in OPERATING THE MONITOR, depending on the problem you

1.

have. If the monitor does not get a picture, skip to 2.

2. Consult the following items if you cannot find an appropriate adjustment item in OPERATING THE

MONITOR or if the problem persists.

3.

If you are experiencing a problem which is not described below or you cannot correct the
problem, discontinue using the monitor and contact your dealer or iiyama service center for
further assistance.

Problem Check

The picture does

A

ENGLISH

ENGLISH

not appear.

(Power indicator
does not light up.)

The Power Cable is firmly seated in the socket.o

o

The Power Switch is turned ON.

o The AC socket is live. Please check with another piece of equipment.

(Power indicator
is green/blue.)

(Power indicator
is orange.)

The screen is not

B

synchronized.

The screen

C

position is not in
the center.

The screen is

D

too bright or too
dark.

The screen is

E

shaking.

o If the blank screen saver is in active mode, touch the keyboard or the

mouse.

o

Increase the Contrast and/or Brightness.
The computer is ON.

o
o

The Signal Cable is properly connected.

o The signal timing of the computer is within the specification of the monitor.

o

If the monitor is in power management mode, touch the keyboard or the
mouse.
If the input video signal selection is different, switch the Signal Select.

o

The computer is ON.

o
o

The Signal Cable is properly connected.

o

The signal timing of the computer is within the specification of the monitor.

o The Signal Cable is properly connected.
o The signal timing of the computer is within the specification of the monitor.

The video output level of the computer is within the specification of the

o

monitor.

The signal timing of the computer is within the specification of the monitor.

o

The video output level of the computer is within the specification of the

o

monitor.

o The power voltage is within the specification of the monitor.
o

The signal timing of the computer is within the specification of the monitor.

21 TROUBLE SHOOTING

APPENDIX A

SPECIFICATIONS

LCD Panel

Display Colors
Sync Frequency

Driving system
Size
Pixel pitch
Brightness
Contrast ratio
Viewable angle
Response time

a-Si TFT Active Matrix
Diagonal: 43cm / 17.0"

0.26mm H × 0.26mm V
250cd/m2 (Typical)
500 : 1 (Typical)
Right / Left / Up / Down: 85 degrees each (Typical)
25ms (Black, white, black)
Approx. 16.2 million
Analog: Horizontal 24.8-80.0kHz, Vertical 56-75Hz

Digital: Horizontal 31.0-80.0kHz, Vertical 56-75Hz
Dot Clock
Maximum Resolution

135MHz maximum

1280 × 1024 maximum, 1.3 MegaPixels
Input Connector D-Sub mini 15 pin

DVI-D 24pin
Plug & Play Analog: VESA DDC1/2B
Input Sync Signal

Separate sync: TTL, Positive or Negative

TM

, Digital: VESA DDC2B

Composite sync: TTL, Positive or Negative

Sync on green: 0.3Vp-p, Negative

Input Video Signal

Analog: 0.7Vp-p (Standard), 75Ω, Positive

Digital: DVI (Digital Visual Interface standard Rev.1.0) compliance
Maximum Screen Size 337.9mm W × 270.3mm H / 13.3" W × 10.6" H
USB Standard

Connectors
Number of USB Ports

Rev. 1.1 compliance Self-powered hub

Upstream: Series B, Downstream: Series A

1 Upstream (For computer), 4 Downstream (For peripherals)

Power Source 100-230VAC, 50/60Hz, 0.8-0.3A

55W maximum, Power management mode: 5W maximum*Power Consumption
Dimensions

Net Weight

Tilt Angle
Environmental
Considerations

397.4× 366.5-451.5 × 212.4mm / 15.6 × 14.4-17.8 × 8.4" (W×H×D)

6.2kg / 13.7lbs

Right / Left: 35 degrees each, Up: 40 degrees

Operative temperature:

Storage temperature:

5 to 35°C / 41 to 95°F

-20 to 60°C / -4 to 140°F

Humidity (-20 to under 50°C / -4 to under 122°F) :

20 to 85% (No condensation)

Approvals

Humidity (50 to 60°C / 122 to 140°F) :

TCO ’99, CE, TÜV-GS / MPR3(prEN50279) / ISO 13406-2, FCC-B,

20 to 55% (No condensation)

UL / C-UL, VCCI-B

ENGLISH

ENGLISH

TM

NOTE

* Condition: USB peripherals or optional speakers are not connected.

APPENDIX A 22

DIMENSIONS

397.4mm/15.6"

339.9mm/13.4"

272.3mm/10.7"

321.5mm/12.7"

ENGLISH

ENGLISH

309.2mm/12.2"

COMPLIANT TIMING

Video Mode

VGA

SVGA

VESA

XGA

1024 × 768

1152 × 864

SXGA

1280 × 1024

VGA TEXT

Macintosh

1024 × 768
PC9801
Work Station

SUN66 1152 × 900

1280 × 1024SGI

640 × 480

800 × 600

720 × 400
640 × 480
832 × 624

640 × 400

53.3mm/2.1"

(451.5mm/17.8")

366.5mm/14.4"

( ): Maximum adjustment range

Horizontal

Frequency

31.469kHz

37.861kHz

37.500kHz

35.156kHz

37.879kHz

48.077kHz

46.875kHz

48.363kHz

56.476kHz

60.023kHz

67.500kHz

63.981kHz

79.976kHz

31.469kHz

35.000kHz

49.725kHz

60.150kHz

24.827kHz

76.968kHz

61.846kHz

Vertical

Frequency

59.940Hz

72.809Hz

75.000Hz

56.250Hz

60.317Hz

72.188Hz

75.000Hz

60.004Hz

70.069Hz

75.029Hz

75.000Hz

60.020Hz

75.025Hz

70.087Hz

66.667Hz

74.500Hz

74.720Hz

56.424Hz

72.000Hz

66.004Hz

Dot Clock

25.175MHz

31.500MHz

31.500MHz

36.000MHz

40.000MHz

50.000MHz

49.500MHz

65.000MHz

75.000MHz

78.750MHz

108.000MHz

108.000MHz

135.000MHz

28.322MHz

30.240MHz

57.283MHz

80.000MHz

21.053MHz

130.076MHz

94.500MHz

212.4mm/8.4"

*
*
*

NOTE

* DVI input is not compliant.

23 APPENDIX A

CONNECTOR PIN ASSIGNMENT

n D-Sub mini 15pin Connector

Pin

1

Red video

2

Green video / Sync on green
Blue video

3
4

NC

5

NC

6

Red video ground

7

Green video ground

8

Blue video ground

DVI-D 24pin Connectorn

Pin Input Signal

1
2

3
4

5
6

7
8
9

10
11
12

Input Signal

1
9

17

T.M.D.S Data 2–
T.M.D.S Data 2+

T.M.D.S Data 2/4 Ground

Clock line (SCL) *
Data line (SDA) *

T.M.D.S Data 1–
T.M.D.S Data 1+

T.M.D.S Data 1/3 Ground

Pin

+5V

9

10

Ground

11

NC

12

Data line (SDA)*
H-Sync

13

V-Sync

14
15

Clock line (SCL)*

DVI-D

Pin

13
14
15
16
17

18
19

20
21

22
23

24

Input Signal

* Compliant to VESA DDC.

8
16
24

Input Signal

+5V
Ground

Hot Plug Detect
T.M.D.S Data 0–

T.M.D.S Data 0+
T.M.D.S Data 0/5 Ground

T.M.D.S Clock Ground
T.M.D.S Clock +
T.M.D.S Clock –

ENGLISH

ENGLISH

* Compliant to VESA DDC.

APPENDIX A 2 4

APPENDIX B

Optional Video Input

This OSD Menu is available only when the optional video adapter is installed in the monitor.

Video input is not selected automatically from Analog or Digital input. Switch to video input by “Signal
Select” on OSD Menu or the Input Button. Under the power management mode, “Signal Select” page
is displayed directly by pressing the Menu Button when the Menu is not displayed.

Direct

You can skip the Menu pages and display an adjustment scale directly by using the
following button operations.

l Brightness: Press the Brightness Button when the Menu is not displayed.

l Contrast: Press the Contrast Button when the Menu is not displayed.

ENGLISH

ENGLISH

l Signal Select: Press the Input Button.

SWITCHING BRIGHTNESS / CONTRAST ADJUSTMENT

NOTE

To switch between Brightness and Contrast adjustments, press the Menu Button within 10
seconds after pressing the Brightness Button or the Contrast Button during the direct
adjustments above.

SIGNAL SELECT (D-SUB / DVI / CV / SV)

D-SUB / DVI / CV / SV signal is switched as follows by pressing the input Button successively
when all of the signal inputs are connected to a signal source.

D-SUB DVI CV SV

25 APPENDIX B

Menu : 1
(Video)

Menu: 1

H: 15.7KHz V: 60.0Hz

NTSC

Adjustment Item Problem / Option Button to Press

NOTE

Brightness *

Direct

Contrast

Direct

Color Temp.

n sRGB is an international standard which defines and unifies the difference of color

appearance between equipment.

n You can not adjust the Brightness, Contrast, Sharpness and Gamma in sRGB mode

because those settings are locked.

n is displayed while sRGB is active.

Sharpness

Too dark
Too bright

Too dull
Too intense

1
2
3
s

User

1 2 3 4 5

Color 1: 9300K
Color 2: 7500K
Color 3: 6500K
sRGB

R
G
B

Too weak
Too strong

ENGLISH

ENGLISH

Adjust the picture quality at resolutions of less than 1280 × 1024.
You can change the picture quality from 1 to 5 (sharp to soft).
Press the + Button to change the picture quality in numerical
order. Press the – Button to change the picture quality in reverse
numerical order.

Gamma

Hue

Return to Menu

* Adjust the Brightness or the Economy Mode when you are using the monitor in a dark room

and feel the screen is too bright.

Direct

See page 25 for Direct.

Off Normal
Mode1 High contrast
Mode2

Purplish
Greenish

Highlight “Menu : 1” again.

Dark

APPENDIX B 26

Menu : 2
(Video)

Menu: 2

ENGLISH

ENGLISH

NOTE

NOTE

H: 15.7KHz V: 60.0Hz

NTSC

Adjustment Item

OSD Position

Problem / Option Button to Press

1 2 3 4 5
You can move the OSD display area

to any one of the following 5 positions
within the overall display:

Press the + Button to move the OSD in numerical order. Press
the – Button to move the OSD in reverse numerical order.

ENG

Language

GER
FRE
ITA
SPA
JPN

Economy Mode *

Off
Eco 1 Brightness of back-light is reduced.

Eco 2

n is displayed while Off is active.
n is displayed while Eco 1 is active.

1

n is displayed while Eco 2 is active.

2

Lockout

No

Yes

n is displayed while Yes is active.

English
German
French
Italian
Spanish
Japanese

Normal

Brightness of back-light is reduced more than Eco 1.

Lockout is canceled.
All adjustment items except this function are

locked out.

Reset

Signal Select

Direct

No

Yes
D-SUB Select the analog input.

CV Select the video input.

Return to Menu.

Factory-preset data is restored.

Select the digital input.DVI

SV Select the s-video input.

NOTE

n is displayed while D-SUB is active. n is displayed while CV is active.
n is displayed while DVI is active. n is displayed while SV is active.

Return to Menu

Highlight “Menu : 2” again.

* Adjust the Brightness or the Economy Mode when you are using the monitor in a dark room

and feel the screen is too bright.

Direct

27 APPENDIX B

See page 25 for Direct.

POWER MANAGEMENT FEATURE

The monitor can provide the POWER MANAGEMENT feature while the video input is available by
using the video adapter.
When the signal from the video equipment is off, the monitor enters into Power Management Mode
which reduces the power consumption to less than 5W and the power indicator turns to orange.
From Power Management Mode, the image reappears in several seconds when the signal is input
from the video equipment.

Specifications for Optional Video Input

Input Connector

Input Video Signal

NOTE

* Not all broadcast systems are supported.

RCA pin jack
S-Video terminal

Video*: NTSC, PAL, SECAM

ENGLISH

ENGLISH

APPENDIX B 28
