ProLite E2003WS-1
iiyama’s most recent addition to the widescreen monitor portfolio, the E2003WS 20.1” panel is aimed at the user
who appreciates the higher 1680x1050 screen resolution but lacks space for a 22”. Improved features include an
even faster 2ms response time for excellent results in gaming and video playback, increased brightness of 300
cd/m² and a sharp 2000:1 Dynamic Contrast Ratio delivering crisp, vivid images in any application. The smart black
casing incorporates stereo speakers and the access controls for the On Screen Display Menu and has both
analogue and digital input connectors. The ProLite E2003WS has been tested to meet all of the technical
requirements to be Certified for Windows Vista™.
Panel TN
Diagonal 20"
Display area h x w 270.9 x 433.4 mm
Response time 2 ms
Contrast ratio 2000 : 1 DCR
Brightness 300 cd/m² typical
Viewing zone horizontal/vertical: 170°/170°; right/left: 85°/85°; up/down: 85/85°
Display colour 16.7 million
Pixel pitch h x v 0.258 x 0.258 mm
Native resolution 1680 x 1050 (1,8 megapixel)
Horizontal sync 31 - 83 KHz
Vertical sync 56 - 75 Hz
Bandwidth 165 MHz
Analog input connector D-Sub
Digital input connector DVI-D
Output connector headphone socket
Synchronization Separate Sync
Plug & Play VESA DDC2B™
Speakers 2 x 1 W (Stereo)
Included accessories power cable, D-Sub signal cable, DVI-D signal cable, audio cable, user manual, stand
Apple - Mac All iiyama monitors are compatible with Apple-Macintosh computers.
Controls On-Screen-Display in 10 languages (GB, F, D, I, ESP, JP, NL, PL, RU, CH) and 6 Front controls (Auto,
Exit/Volume, Scroll down/Contrast, Scroll up/Brightness, Menu/Select, Power)
User controls auto adjust, luminance (brightness, contrast), geometry (clock, phase, V-position, H-position), colour
temperature, OSD language, OSD position, OSD time out, recall, miscellaneous (sharpness, DDC/CI,
display information, DCR, OD), input select, volume
Driver Windows 95 / 98 / 2000 / ME / XP / Vista
Ergonomics TCO '03, CE, MPR 3 (prEN50279), ISO 13406-2
Safety TÜV GS, FCC-B, UL / C-UL, VCCI-B, GOST-R, CB
Power supply AC 100 - 240 V, 50 / 60 Hz
Power Supply Unit internal
Power usage max. 49 W in normal use; max. 2 W in Power management mode
Power management VESA DPMS, ENERGY STAR®
Anti-theft-device Kensington-lock™ prepared
VESA mounting 100 mm
Tilt angle 22° up; 2° down
Dimensions w x h x d 480 x 399 x 188 mm
Weight 4.4 kg
Aspect ratio 16 : 10
All trademarks and registered trademarks acknowledged. E & O E. Specification subject to change without notice. All LCD's comply with ISO-13406-2 in
connection with pixel defects.
