Iiyama PROLITE B2280HS User Manual
USER MANUAL
ENGLISH
Thank you very much for choosing the iiyama LCD monitor.
We recommend that you take a few minutes to read carefully through this brief but comprehensive manual before installing and switching on the monitor. Please keep this manual in a safe place for your future reference.
ENGLISH
Congratulations!
This display is designed for both you and the planet!
The display you have just purchased carries the TCO Certified label. This ensures that your display is designed, manufactured and tested according to some of the strictest quality and environmental requirements in the world. This makes for a high performance product, designed with the user in focus that also minimizes the impact on the climate and our natural environment.
TCO Certified is a third party verified program, where every product model is tested by an accredited impartial test laboratory. TCO Certified represents one of the toughest certifications for displays worldwide.
Some of the Usability features of the TCO Certified for displays:
•Visual ergonomics for good image quality is tested to ensure top performance and reduce sight and strain problems. Important parameters are luminance, contrast, resolution, black level, gamma curve, colour and luminance uniformity and colour rendering
•Products are tested according to rigorous safety standards at impartial laboratories
•Electric and magnetic fields emissions as low as normal household background levels
•Low acoustic noise emissions (When applicable)
Some of the Environmental features of the TCO Certified for displays:
•The brand owner demonstrates corporate social responsibility and has a certified environmental management system (EMAS or ISO 14001)
•Very low energy consumption both in onand standby mode minimize climate impact
•Restrictions on chlorinated and brominated flame retardants, plasticizers, plastics and heavy metals such as cadmium, mercury and lead (RoHS compliance)
•Both product and product packaging is prepared for recycling
•The brand owner offers take-back options
The requirements can be downloaded from our web site. The requirements included in this label have been developed by TCO Development in co-operation with scientists, experts, users as well as manufacturers all over the world. Since the end of the 1980s TCO has been involved in influencing the development of IT equipment in a more user-friendly direction. Our labeling system started with displays in 1992 and is now requested by users and IT-manufacturers all over the world. About 50% of all displays worldwide are TCO certified.
For more information, please visit
www.tcodevelopment.com
ENGLISH
ENGLISH
CE MARKING DECLARATION OF CONFORMITY
This LCD monitor complies with the requirements of the EC Directive 2004/108/EC “EMC Directive” , 2006/95/EC “Low Voltage Directive” and 2009/125/EC “ErP Directive”.
The electro-magnetic susceptibility has been chosen at a level that gives correct operation in residential areas, business and light industrial premises and small-scale enterprises, inside as well as outside of the buildings. All places of operation are characterised by their connection to the public low voltage power supply system.
IIYAMA CORPORATION: Breguetlaan 8, 1438BC Oude Meer The Netherlands
An approved power cord greater or equal to H05VVF, 3G, 0.75mm2 must be used.
For displays with glossy bezels the user should consider the placement of the display as the bezel may cause disturbing reflections from surrounding light and bright surfaces.
We recommend recycling of used product. Please contact your dealer or iiyama service center. Recycle information is obtained via the Internet, using the address: http://www.iiyama.com
You can access the Web page of different countries from there.
We reserve the right to change specifications without notice.
All trademarks used in this user manual are the property of their respective owners.
As an ENERGY STAR® Partner, iiyama has determined that this product meets the ENERGY STAR® guidelines for energy efficiency.
TABLE OF CONTENTS |
|
FOR YOUR SAFETY.......................................................................... |
1 |
SAFETY PRECAUTIONS.............................................................. |
1 |
SPECIAL NOTES ON LCD MONITORS ....................................... |
3 |
CUSTOMER SERVICE ................................................................. |
3 |
CLEANING .................................................................................... |
3 |
BEFORE YOU OPERATE THE MONITOR ........................................ |
4 |
FEATURES.................................................................................... |
4 |
CHEKING THE CONTENTS OF THE PACKAGE......................... |
4 |
WALL MOUNTING ........................................................................ |
5 |
FITTING AND REMOVAL OF BASE : ProLite B2280HS............... |
6 |
FITTING AND REMOVAL OF BASE : ProLite E2280HS............... |
7 |
CONTROLS AND CONNECTORS : ProLite B2280HS................. |
8 |
CONTROLS AND CONNECTORS : ProLite E2280HS................. |
9 |
CONNECTING YOUR MONITOR : ProLite B2280HS ................ |
10 |
CONNECTING YOUR MONITOR : ProLite E2280HS ................ |
11 |
COMPUTER SETTING ............................................................... |
12 |
ADJUSTING THE HEIGHT AND THE VIEWING ANGLE : |
|
ProLite E2280HS......................................................................... |
12 |
ADJUSTING THE HEIGHT AND THE VIEWING ANGLE : |
|
ProLite B2280HS......................................................................... |
13 |
PANEL ROTATION : ProLite B2280HS ....................................... |
13 |
OPERATING THE MONITOR........................................................... |
14 |
ADJUSTMENT MENU CONTENTS ............................................ |
15 |
SCREEN ADJUSTMENTS .......................................................... |
21 |
POWER MANAGEMENT FEATURE........................................... |
24 |
TROUBLE SHOOTING .................................................................... |
25 |
RECYCLING INFORMATION........................................................... |
26 |
APPENDIX ...................................................................................... |
27 |
SPECIFICATIONS : ProLite B2280HS ........................................ |
27 |
SPECIFICATIONS : ProLite E2280HS ........................................ |
28 |
DIMENSIONS : ProLite B2280HS............................................... |
29 |
DIMENSIONS : ProLite E2280HS............................................... |
29 |
COMPLIANT TIMING .................................................................. |
30 |
ENGLISH
FOR YOUR SAFETY
SAFETY PRECAUTIONS
WARNING
STOP OPERATING THE MONITOR IF YOU ARE AWARE OF ANY PROBLEMS
If you notice any abnormal phenomena such as smoke, strange sounds or fumes, unplug the monitor and contact your dealer or iiyama service center immediately. Further use may be dangerous and can cause fire or electric shock.
NEVER REMOVE THE CABINET
High voltage circuits are inside the monitor. Removing the cabinet may expose you to the danger of fire or electric shock.
DO NOT PUT ANY OBJECT INTO THE MONITOR
Do not put any solid objects or liquids such as water into the monitor. In case of an accident, unplug your monitor immediately and contact your dealer or iiyama service center. Using the monitor with any object inside may cause fire, electric shock or damage.
INSTALL THE MONITOR ON A FLAT, STABLE SURFACE
The monitor may cause an injury if it falls or is dropped.
DO NOT USE THE MONITOR NEAR WATER
Do not use where water may be splashed or spilt onto the monitor as it may cause fire or electric shock.
OPERATE UNDER THE SPECIFIED POWER SUPPLY
Be sure to operate the monitor only with the specified power supply. Use of an incorrect voltage will cause malfunction and may cause fire or electric shock.
PROTECT THE CABLES
Do not pull or bend the power cable and signal cable. Do not place the monitor or any other heavy objects on the cables. If damaged, the cables may cause fire or electric shock.
ADVERSE WEATHER CONDITIONS
It is advisable not to operate the monitor during a heavy thunder storm as the continual breaks in power may cause malfunction. It is also advised not to touch the plug in these circumstances as it may cause electric shock.
ENGLISH
FOR YOUR SAFETY 1
ENGLISH
CAUTION
INSTALLATION LOCATION
Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fire, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor.
DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION
The monitor may topple and cause injury if not suitably located. Please also ensure that you do not place any heavy objects on the monitor, and that all cables are routed such that children may not pull the cables and possibly cause injury.
MAINTAIN GOOD VENTILATION
Ventilation slots are provided to keep the monitor from overheating. Covering the slots may cause fire. To allow adequate air circulation, place the monitor at least 10 cm (or 4 inches) from any walls.
Do not remove the tilt stand when operating the monitor. Ventilation slots on the back of the cabinet will be blocked and the monitor may overheat if the stand is removed. This may cause fire or damage. Operating the monitor on its back, side, upside down or on a carpet or any other soft material may also cause damage.
DISCONNECT THE CABLES WHEN YOU MOVE THE MONITOR
When you move the monitor, turn off the power switch, unplug the monitor and be sure the signal cable is disconnected. If you do not disconnect them, it may cause fire or electric shock.
UNPLUG THE MONITOR
If the monitor is not in use for a long period of time it is recommended that it is left unplugged to avoid accidents.
HOLD THE PLUG WHEN DISCONNECTING
To disconnect the power cable or signal cable, always pull it by the plug. Never pull on the cable itself as this may cause fire or electric shock.
DO NOT TOUCH THE PLUG WITH WET HANDS
Pulling or inserting the plug with wet hands may cause electric shock.
WHEN YOU INSTALL THE MONITOR ON YOUR COMPUTER
Be sure the computer is strong enough to hold the weight of the monitor, otherwise, you may damage your computer.
CAREFUL! PROTECT YOUR HANDS AND FINGERS
Be careful not to hurt your fingers or hands when you change the height or the angle.
Injury can occur if care is not taken to avoid finger contact with the displays base when adjusting the height. (Just for height adjustable model.)
DO NOT USE THE MONITOR FOR 24-HOURS CONTINUOUSLY
The monitor is not designed to work for 24-hours continuously, do not use the monitor for 24-hours continuously.
OTHERS
ERGONOMIC RECOMMENDATIONS
To eliminate eye fatigue, do not operate the monitor against a bright background or in a dark room. For optimal viewing comfort, the monitor should be just below eye level and 40-60 cm (16-24 inches) away from your eyes. When using the monitor over a prolonged time, a ten minute break every hour is recommended as looking at the screen continuously can cause eye strain.
2 FOR YOUR SAFETY
SPECIAL NOTES ON LCD MONITORS
The following symptoms are normal with LCD monitors and do not indicate a problem.
NOTE When you first turn on the LCD monitor, the picture may not fit in the display area because of the type of computer that is used. In this case, adjust the picture position to the correct position.
Due to the nature of the backlight, the screen may flicker during initial use. Turn off the Power Switch and then turn it on again to make sure the flicker disappears.
You may find slightly uneven brightness on the screen depending on the desktop pattern you use.
Due to the nature of the LCD screen, an afterimage of the previous screen may remain after switching the image, when the same image is displayed for hours. In this case, the screen can be recovered slowly by changing the image or turning off the Power Switch for some hours.
Contact your dealer or iiyama service center for the backlight replacement when the screen is dark, flickering or not lighting up. Never attempt to replace it by yourself.
ENGLISH
CUSTOMER SERVICE
NOTE If you have to return your unit for service and the original packaging has been discarded, please contact your dealer or iiyama service center for advice or replacement packaging.
CLEANING
WARNING
CAUTION
NOTE
CABINET
LCD SCREEN
If you drop any materials or liquids such as water into the monitor when cleaning, unplug the power cable immediately and contact your dealer or iiyama service center.
For safety reasons, turn off the power switch and unplug the monitor before you clean it.
To protect the LCD panel, do not scratch or rub the screen with a hard object. Never use any of the following strong solvents. These will damage the cabinet and
the LCD screen.
Thinner |
Spray-type cleaner |
Benzine |
Wax |
Abrasive cleaner |
Acid or Alkaline solvent |
Touching the cabinet with any product made from rubber or plastic for a long time may cause degeneration or loss of paint on the cabinet.
Stains can be removed with a cloth lightly moistened with a mild detergent solvent. Then wipe the cabinet with a soft dry cloth.
Periodic cleaning with a soft dry cloth is recommended.
Don't use tissue paper etc. because these will damage the LCD screen.
FOR YOUR SAFETY 3
ENGLISH
BEFORE YOU OPERATE THE MONITOR
FEATURES
Supports Resolutions up to 1920 × 1080
High Contrast 1000:1 (Typical), ACR Function Available / Brightness 250cd/m2 (Typical) / Quick Response Time 5ms (Typical)
Digital Character Smoothing
Automatic Set-up
Stereo Speakers
2 × 1W Stereo Speakers
Plug & Play VESA DDC2B Compliant
Windows® 95/98/2000/Me/XP/Vista/7 Compliant
Power Management (ENERGY STAR® VESA DPMS Compliant)
Ergonomic Design TCO Certified
VESA Mounting Standard (100mm×100mm) Compliant
Keyhole for Security Lock
CHEKING THE CONTENTS OF THE PACKAGE
The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama office.
Power Cable*1 |
D-Sub Signal Cable |
DVI-D Signal Cable |
Audio Cable |
Stand-Base |
Stand*2 |
■ Screw for stand fixing*3 |
Cable Holder |
Safety Guide |
Quick Start Guide
CAUTION |
*1 |
The rating of the Power Cable enclosed in 120V area is 10A/125V. If you are using |
|
|
a power supply higher than this rating, then a power cable with a rating of 10A/250V |
|
|
must be used. However, all guarantees and warranties are void for any |
|
|
problems or damage caused by a power cable not supplied by iiyama. |
*2 |
Accessory for ProLite E2280HS. |
|
*3 |
Accessory for ProLite B2280HS. |
|
4 BEFORE YOU OPERATE THE MONITOR
WALL MOUNTING
WARNING When you use with the wall mounting, in consideration of thickness of the mounting stage, tighten the M4 Screw with washer which “L” length is 7mm to fasten the monitor. Using the screw longer than this may cause electric shock or damage because it may contact with the electrical parts inside the monitor.
Please check if the wall or ceiling can support the weight of the monitor before mounting it.
|
Screw |
|
Mounting Stage |
L |
Chassis |
|
ENGLISH
BEFORE YOU OPERATE THE MONITOR 5
ENGLISH
FITTING AND REMOVAL OF BASE : ProLite B2280HS
CAUTION Put the monitor on a stable surface. The monitor may cause injury or damage if it falls or is dropped.
Do not give a strong impact to the monitor. It may cause damage.
Unplug the monitor before removal or installation to avoid electric shock or damage.
<Installation>
Put a piece of soft cloth on the table beforehand to prevent the monitor from being scratched. Lay the monitor flat on a table with front face down.
Install the Stand-Base to the Monitor.
Fix the Monitor to the Stand by the screw firmly and the push-down knob.
Place the Cable Holder.
Push-down knob
Screw for Stand-Base fixing
Stand-Base |
Cable-Holder |
Stand-Base |
<Remove>
Put a piece of soft cloth on the table beforehand to prevent the monitor from being scratched. Lay the monitor flat on a table with front face down.
Pull up the knob, then remove the screws and the Stand-Base.
6 BEFORE YOU OPERATE THE MONITOR
