USER MANUAL
Thank you very much for choosing the iiyama
LCD monitor.
We recommend that you take a few minutes
to read carefully through this brief but
comprehensive manual before installing and
switching on the monitor. Please keep this
manual in a safe place for your
future reference.
ENGLISH
Page 2
ENGLISH
Page 3
Congratulations!
This product is TCO Certified
This product has been verified to meet all the criteria in TCO Certified, including:
Corporate Social Responsibility
Socially responsible production - working conditions and labor law in manufacturing country
Energy Efficiency
Energy efficiency of product and power supply. Energy Star compliant, where applicable
Environmental Management System
Manufacturer must be certified according to either ISO 14001 or EMAS
Minimization of Hazardous Substances
Limits on cadmium, mercury, lead & hexavalent chromium including requirements for mercury-free
products, halogenated substances and hazardous flame retardants
Design for Recycling
Coding of plastics for easy recycling. Limit on the number of different plastics used.
Product Lifetime, Product Take Back
Minimum one-year product warranty. Minimum three-year availability of spare parts. Product takeback
Packaging
Limits on hazardous substances in product packaging. Packaging prepared for recycling
Ergonomic, User-centered design
Visual ergonomics in products with a display. Adjustability for user comfort (displays, headsets)
Acoustic performance
Ergonomically designed keyboard (notebooks)
Electrical Safety, minimal electro-magnetic Emissions
Third Party Testing
All certified product models have been tested in an independent, accredited laboratory.
A detailed criteria set is available for download at www.tcodevelopment.com, where you can also
find a searchable database of all TCO Certified IT products.
TCO Development, the organization behind TCO Certified, has been an international driver in the
field of Sustainable IT for 20 years. Criteria in TCO Certified are developed in collaboration with
scientists, experts, users and manufacturers. Organizations around the world rely on TCO Certified
as a tool to help them reach their sustainable IT goals. We are owned by TCO, a non-profit
organization representing office workers. TCO Development is headquartered in Stockholm,
Sweden, with regional presence in North America and Asia.
TCO Certified is an international third party sustainability certification for
IT products. TCO Certified ensures that the manufacture, use and
recycling of IT products reflect environmental, social and economic
responsibility. Every TCO Certified product model is verified by an
accredited independent test laboratory.
protection against sound spikes (headsets) and fan noise (projectors, computers)
For more information, please visit
for Sustainable IT
www.tcodevelopment.com
ENGLISH
Page 4
CE MARKING DECLARATION OF CONFORMITY
This LCD monitor complies with the requirements of the EC/EU Directive 2004/108/EC “EMC
Directive”, 2006/95/EC “Low Voltage Directive”, 2009/125/EC “ErP Directive” and 2011/65/EU
“RoHS Directive”.
The electro-magnetic susceptibility has been chosen at a level that gives correct operation in
residential areas, business and light industrial premises and small-scale enterprises, inside as
well as outside of the buildings. All places of operation are characterised by their connection to
the public low voltage power supply system.
IIYAMA CORPORATION: Wijkermeerstraat 8, 2131 HA Hoofddorp, The Netherlands
ENGLISH
We reserve the right to change specifi cations without notice.
All trademarks used in this user manual are the property of their respective owners.
As an ENERGY STAR
for energy effi ciency.
®
Partner, iiyama has determined that this product meets the ENERGY STAR® guidelines
Page 5
TABLE OF CONTENTS
FOR YOUR SAFETY ..........................................................................1
SAFETY PRECAUTIONS ..............................................................1
SPECIAL NOTES ON LCD MONITORS .......................................3
CUSTOMER SERVICE .................................................................3
CLEANING ....................................................................................3
BEFORE YOU OPERATE THE MONITOR ........................................4
FEATURES ....................................................................................4
CHEKING THE CONTENTS OF THE PACKAGE .........................4
FITTING AND REMOVAL OF BASE : ProLite B1706S .................5
FITTING AND REMOVAL OF BASE : ProLite E1706S .................6
CONTROLS AND CONNECTORS : ProLite B1706S ...................7
CONTROLS AND CONNECTORS : ProLite E1706S ...................8
CONNECTING YOUR MONITOR : ProLite B1706S .....................9
CONNECTING YOUR MONITOR : ProLite E1706S ...................10
COMPUTER SETTING ...............................................................11
ADJUSTING THE VIEWING ANGLE : ProLite E1706S ..............11
ADJUSTING THE HEIGHT AND THE VIEWING ANGLE :
ProLite B1706S ...........................................................................12
PANEL ROTATION : ProLite B1706S ..........................................12
OPERATING THE MONITOR ...........................................................13
ADJUSTMENT MENU CONTENTS ............................................14
SCREEN ADJUSTMENTS ..........................................................20
POWER MANAGEMENT FEATURE ...........................................23
TROUBLE SHOOTING ....................................................................24
RECYCLING INFORMATION ...........................................................25
APPENDIX ......................................................................................26
SPECIFICATIONS : ProLite B1706S ..........................................26
SPECIFICATIONS : ProLite E1706S ..........................................27
DIMENSIONS : ProLite B1706S..................................................28
DIMENSIONS : ProLite E1706S..................................................28
COMPLIANT TIMING ..................................................................29
ENGLISH
We recommend recycling of used product. Please contact your dealer or iiyama
service center. Recycle information is obtained via the Internet, using the address:
http://www.iiyama.com
You can access the Web page of different countries from there.
Page 6
FOR YOUR SAFETY
SAFETY PRECAUTIONS
WARNING
STOP OPERATING THE MONITOR WHEN YOU SENSE TROUBLE
If you notice any abnormal phenomena such as smoke, strange sounds or fumes, unplug the
monitor and contact your dealer or iiyama service center immediately. Further use may be
dangerous and can cause fi re or electric shock.
NEVER REMOVE THE CABINET
High voltage circuits are inside the monitor. Removing the cabinet may expose you to the danger of
fi re or electric shock.
DO NOT PUT ANY OBJECT INTO THE MONITOR
Do not put any solid objects or liquids such as water into the monitor. In case of an accident, unplug
your monitor immediately and contact your dealer or iiyama service center. Using the monitor with
any object inside may cause fi re, electric shock or damage.
INSTALL THE MONITOR ON A FLAT, STABLE SURFACE
The monitor may cause an injury if it falls or is dropped.
DO NOT USE THE MONITOR NEAR WATER
Do not use where water may be splashed or spilt onto the monitor as it may cause fi re or electric
shock.
OPERATE UNDER THE SPECIFIED POWER SUPPLY
Be sure to operate the monitor only with the specifi ed power supply. Use of an incorrect voltage will
cause malfunction and may cause fi re or electric shock.
ENGLISH
PROTECT THE CABLES
Do not pull or bend the power cable and signal cable. Do not place the monitor or any other heavy
objects on the cables. If damaged, the cables may cause fi re or electric shock.
ADVERSE WEATHER CONDITIONS
It is advisable not to operate the monitor during a heavy thunder storm as the continual breaks in
power may cause malfunction. It is also advised not to touch the plug in these circumstances as it
may cause electric shock.
FOR YOUR SAFETY 1
Page 7
CAUTION
INSTALLATION LOCATION
Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or
smoky areas as it may cause fi re, electric shock or damage. You should also avoid areas where the
sun shines directly on the monitor.
DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION
The monitor may topple and cause injury if not suitably located. Please also ensure that you do not
place any heavy objects on the monitor, and that all cables are routed such that children may not
pull the cables and possibly cause injury.
MAINTAIN GOOD VENTILATION
Ventilation slots are provided to keep the monitor from overheating. Covering the slots may cause
fi re. To allow adequate air circulation, place the monitor at least 10 cm (or 4 inches) from any walls.
ENGLISH
Do not remove the tilt stand when operating the monitor. Ventilation slots on the back of the
cabinet will be blocked and the monitor may overheat if the stand is removed. This may cause fi re
or damage. Operating the monitor on its back, side, upside down or on a carpet or any other soft
material may also cause damage.
DISCONNECT THE CABLES WHEN YOU MOVE THE MONITOR
When you move the monitor, turn off the power switch, unplug the monitor and be sure the signal
cable is disconnected. If you do not disconnect them, it may cause fi re or electric shock.
UNPLUG THE MONITOR
If the monitor is not in use for a long period of time it is recommended that it is left unplugged to
avoid accidents.
HOLD THE PLUG WHEN DISCONNECTING
To disconnect the power cable or signal cable, always pull it by the plug. Never pull on the cable
itself as this may cause fi re or electric shock.
DO NOT TOUCH THE PLUG WITH WET HANDS
Pulling or inserting the plug with wet hands may cause electric shock.
WHEN YOU INSTALL THE MONITOR ON YOUR COMPUTER
Be sure the computer is strong enough to hold the weight of the monitor, otherwise, you may
damage your computer.
CAREFUL! PROTECT YOUR HANDS AND FINGERS
Be careful not to hurt your fi ngers or hands when you change the height or the angle.
Injury can occur if care is not taken to avoid fi nger contact with the displays base when adjusting
the height. (Just for height adjustable model.)
DO NOT USE THE MONITOR FOR 24-HOURS CONTINUOUSLY
The monitor is not designed to work for 24-hours continuously, do not use the monitor for 24-hours
continuously.
OTHERS
ERGONOMIC RECOMMENDATIONS
To eliminate eye fatigue, do not operate the monitor against a bright background or in a dark room.
For optimal viewing comfort, the monitor should be just below eye level and 40-60 cm (16-24 inches)
away from your eyes. When using the monitor over a prolonged time, a ten minute break every hour
is recommended as looking at the screen continuously can cause eye strain.
2 FOR YOUR SAFETY
Page 8
SPECIAL NOTES ON LCD MONITORS
The following symptoms are normal with LCD monitors and do not indicate a problem.
NOTE
When you fi rst turn on the LCD monitor, the picture may not fi t in the display area
because of the type of computer that is used. In this case, adjust the picture position
to the correct position.
Due to the nature of the backlight, the screen may fl icker during initial use. Turn off
the Power Switch and then turn it on again to make sure the fl icker disappears.
You may fi nd slightly uneven brightness on the screen depending on the desktop
pattern you use.
Due to the nature of the LCD screen, an afterimage of the previous screen may
remain after switching the image, when the same image is displayed for hours. In
this case, the screen is recovered slowly by changing the image or turning off the
Power Switch for hours.
Contact your dealer or iiyama service center for the backlight replacement when the
screen is dark, fl ickering or not lighting up. Never attempt to replace it by yourself.
CUSTOMER SERVICE
The fl uorescent light used in the LCD monitor may have to be periodically replaced.
NOTE
For the warranty coverage on this component, please check with local iiyama
service center.
If you have to return your unit for service and the original packaging has been
discarded, please contact your dealer or iiyama service center for advice or
replacement packaging.
ENGLISH
CLEANING
WARNING
CAUTION
NOTE
CABINET
LCD
SCREEN
If you drop any materials or liquids such as water into the monitor when cleaning,
unplug the power cable immediately and contact your dealer or iiyama service center.
For safety reasons, turn off the power switch and unplug the monitor before you
clean it.
To protect the LCD panel, do not scratch or rub the screen with a hard object.
Never use any of the following strong solvents. These will damage the cabinet and
the LCD screen.
Touching the cabinet with any product made from rubber or plastic for a long time
may cause degeneration or loss of paint on the cabinet.
Stains can be removed with a cloth lightly moistened with a mild detergent solvent.
Then wipe the cabinet with a soft dry cloth.
Periodic cleaning with a soft dry cloth is recommended.
Don't use tissue paper etc. because these will damage the LCD screen.
Thinner
Benzine
Abrasive cleaner
Spray-type cleaner
Wax
Acid or Alkaline solvent
FOR YOUR SAFETY 3
Page 9
BEFORE YOU OPERATE THE MONITOR
FEATURES
Supports Resolutions up to 1280 × 1024
High Contrast 1000:1 (Typical) , ACR Function Available / Brightness 250cd/m
(Typical) / Quick Response Time 5ms (Typical)
Digital Character Smoothing
Automatic Set-up
Stereo Speakers
2 × 1W Stereo Speakers
ENGLISH
Plug & Play VESA DDC2B Compliant
Windows
Power Management (ENERGY STAR
Ergonomic Design: TCO Certifi ed Compliant
VESA Mounting Standard (100mm×100mm) Compliant
Keyhole for Security Lock
CHEKING THE CONTENTS OF THE PACKAGE
The following accessories are included in your package. Check to see if they are enclosed with
the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional
iiyama offi ce.
Power Cable*
Audio Cable
Screw for stand fi xing*
CAUTION
®
XP/Vista/7/8 Compliant
®
VESA DPMS Compliant)
1
3
*1 The rating of the Power Cable enclosed in 120V area is 10A/125V. If you are using
a power supply higher than this rating, then a power cable with a rating of
10A/250V must be used.However, all guarantees and warranties are void for any
problems or damage caused by a power cable not supplied by iiyama.
2
*
Accessory for ProLite E1706S.
3
Accessory for ProLite B1706S.
*
D-Sub Signal Cable
Stand-Base
Safety Guide
DVI-D Cable
2
Stand*
Quick Start Guide
2
4 BEFORE YOU OPERATE THE MONITOR
Page 10
FITTING AND REMOVAL OF BASE : ProLite B1706S
The monitor is supplied complete with a stand-base. If you prefer to wall mount the monitor, please
follow the instructions below to remove the stand-base. Be sure to include the stand with the monitor
if it is necessary to return the unit.
CAUTION
<Installation>
Put a piece of soft cloth on the table beforehand to prevent the monitor from being scratched.
A
Lay the monitor fl at on a table with front face down.
Install the Stand-Base to the Monitor.
B
Fix the Monitor with the Stand by the screw fi rmly, and the knob of the screw push down.
C
Put the monitor on a stable surface. The monitor may cause injury or damage if it
falls or is dropped.
Do not give a strong impact to the monitor. It may cause damage.
Unplug the monitor before removal or installation to avoid electric shock or damage.
Stand-Base
Push-down knob
Screw for
Stand-Base fixing
ENGLISH
<Remove>
Put a piece of soft cloth on the table beforehand to prevent the monitor from being scratched.
A
Lay the monitor fl at on a table with front face down.
Pull up the knob of the screws, and remove the screw and the Stand-Base.
B
<Stopper pin>
Please stand the monitor and then remove the
stopper pin on the back of the stand slowly while
pushing top face of the stand before you install the
monitor. Careful attention is required as the monitor
is sprung loaded and may expand quickly when
removing it.
Stopper pin
BEFORE YOU OPERATE THE MONITOR 5
Page 11
FITTING AND REMOVAL OF BASE : ProLite E1706S
CAUTION
Install the stand on a stable surface. The monitor may cause injury or damage if it
falls or is dropped.
Do not give a strong impact to the monitor. It may cause damage.
Unplug the monitor before installation to avoid electric shock or damage.
<Installation>
Put a piece of soft cloth on the table beforehand to prevent the monitor from being scratched.
A
Lay the monitor fl at on a table with front face down.
Hold the monitor and push the Stand.
B
Hold the monitor and push the Stand-Base.
ENGLISH
C
Stand
Stand-Base
<Remove>
Put a piece of soft cloth on the table beforehand to prevent the monitor from being scratched.
A
Lay the monitor fl at on a table with front face down.
Press the stopper at the bottom of the stand and remove the Stand-Base from the stand.
B
Press the stopper at the back of the stand and remove the Stand from the monitor.
C
Stopper
6 BEFORE YOU OPERATE THE MONITOR
Stopper
Stand-Base
Stand
Page 12
CONTROLS AND CONNECTORS : ProLite B1706S
<Front>
Power Switch ( )
A
Menu / Select Button (MENU)
B
+ / Volume Button ( + )
C
- / ECO Button ( - )
D
Auto Button (AUTO)
E
Power Indicator
F
NOTE
Speakers
G
D-SUB mini 15pin Connector (D-SUB)
H
DVI-D 24pin Connector (DVI-D)
I
Cable Holder
J
Audio Connector (AUDIO IN)
K
AC Connector (AC IN)
L
Keyhole for Security Lock
M
NOTE
Blue: Normal operation
Orange: Power Management
You can fasten a security lock and cable to prevent the monitor from being removed
without your permission.
ENGLISH
<Back>
BEFORE YOU OPERATE THE MONITOR 7
Page 13
CONTROLS AND CONNECTORS : ProLite E1706S
ENGLISH
<Front>
Power Switch ( )
A
Menu / Select Button (MENU)
B
+ / Volume Button ( + )
C
- / ECO Button ( - )
D
Auto Button (AUTO)
E
Power Indicator
F
NOTE
Blue: Normal operation
Orange: Power Management
Speakers
G
D-SUB mini 15pin Connector (D-SUB)
H
DVI-D 24pin Connector (DVI-D)
I
Audio Connector (AUDIO IN)
J
AC Connector (AC IN)
K
Keyhole for Security Lock
L
NOTE
You can fasten a security lock and cable to prevent the monitor from being removed
without your permission.
<Back>
8 BEFORE YOU OPERATE THE MONITOR
Page 14
Power Cable
(Accessory)
Audio Cable (Accessory)
D-Sub Signal Cable
(Accessory)
DVI-D Signal Cable
(Accessory)
Computer
CONNECTING YOUR MONITOR : ProLite B1706S
Ensure that both the computer and the monitor are switched off.
A
Connect the computer to the monitor with the signal cable.
B
Connect the monitor to the audio equipment with the Audio Cable for computer when using the
C
audio features.
Connect the Power Cable to the monitor fi rst and then to the power supply.
D
Power of the monitor and the computer is turned on.
E
The signal cables used for connecting the computer and monitor may vary with the type of
NOTE
computer used. An incorrect connection may cause serious damage to both the monitor and
the computer. The cable supplied with the monitor is for a standard 15 pin D-Sub connector.
If a special cable is required please contact your local iiyama dealer or regional iiyama
offi ce.
For connection to Macintosh computers, contact your local iiyama dealer or regional
iiyama offi ce for a suitable adaptor.
Make sure you tighten the fi nger screws at each end of the signal cable.
[Example of Connection]
<Back>
ENGLISH
[ Collect Cables ]
Put the cables through the cable holder.
A
Collect cables at the back of the stand.
B
BEFORE YOU OPERATE THE MONITOR 9
Page 15
Power Cable
(Accessory)
Audio Cable (Accessory)
Computer
D-Sub Signal Cable
(Accessory)
DVI-D Signal Cable
(Accessory)
CONNECTING YOUR MONITOR : ProLite E1706S
Ensure that both the computer and the monitor are switched off.
A
Connect the computer to the monitor with the signal cable.
B
Connect the monitor to the audio equipment with the Audio Cable for computer when using the
C
audio features.
Connect the Power Cable to the monitor fi rst and then to the power supply.
D
Power of the monitor and the computer is turned on.
E
The signal cables used for connecting the computer and monitor may vary with the type of
NOTE
ENGLISH
computer used. An incorrect connection may cause serious damage to both the monitor and
the computer. The cable supplied with the monitor is for a standard 15 pin D-Sub connector.
If a special cable is required please contact your local iiyama dealer or regional iiyama
offi ce.
For connection to Macintosh computers, contact your local iiyama dealer or regional
iiyama offi ce for a suitable adaptor.
Make sure you tighten the fi nger screws at each end of the signal cable.
[Example of Connection]
<Back>
10 BEFORE YOU OPERATE THE MONITOR
Page 16
COMPUTER SETTING
Signal Timing
Change to the desired signal timing listed on page 29: COMPLIANT TIMING.
ADJUSTING THE VIEWING ANGLE : ProLite E1706S
For optimal viewing it is recommended to look at the full
face of the monitor.
Hold the stand so that the monitor does not topple when
you change the monitor’s angle.
You are able to adjust the monitor’s angle up to 20
degrees upward, 5 degrees downward.
In order to ensure a healthy and relaxed body position
when using the monitor at visual display workstations, it
is recommended that the adjusted tilt angle should not
exceed 10 degrees. Adjust the monitor’s angle to your
own preference.
Do not touch the LCD screen when you change
NOTE
the angle. It may cause damage or break the
LCD screen.
Careful attention is required not to catch your
fi ngers or hands when you change the angle.
20
5
ENGLISH
BEFORE YOU OPERATE THE MONITOR 11
Page 17
ADJUSTING THE HEIGHT AND THE VIEWING ANGLE : ProLite B1706S
For optimal viewing it is recommended to position
yourself directly opposite to the full face of the
monitor, then adjust the monitor’s height and
angle to your own preference.
Hold the panel so that the monitor does not
topple when you change the monitor’s height or
angle.
You are able to adjust the monitor's height up to
110mm, angle up to 170 degrees right and left,
20 degrees upward.
Do not touch the LCD screen when you
NOTE
ENGLISH
change the height or the angle. It
may cause damage or break the LCD
screen.
Careful attention is required not to
catch your fingers or hands when you
change the height or the angle.
Injury can occur if care is not taken to
avoid fi nger contact with the displays
base when adjusting the height.
Monitor
110mm
PANEL ROTATION : ProLite B1706S
Adjust the mother’s height.
A
Rotate the panel 90 degrees.
B
Portrait: Turn clockwise.
Landscape: Turn counter clockwise.
Attempting to rotate without fully extending
NOTE
upward may cause damage to stand.
Video card for portrait display will be required
for rotating the image on the screen.
Adjust the monitor’s angle to your preference.
C
12 BEFORE YOU OPERATE THE MONITOR
Stand
90°
Page 18
OPERATING THE MONITOR
To create the best picture, your iiyama LCD monitor has been preset at the factory
COMPLIANT TIMING shown on page 29. You are also able to adjust the picture by following
the button operation shown below. For more detailed adjustments, see page 20 for SCREEN
ADJUSTMENTS.
Press the MENU Button to start the On Screen Display feature. There are additional
Menu items which can be switched by using the + / - Buttons.
with the
Contrast
Brightness
Eco
Picture Mode
ACR
Select the Menu item which contains the adjustment icon relating to the adjustment
B
Luminance
50
50
Off
Standard
ON
you want to make. Press the MENU Button. Then, use the + / - Buttons to highlight
the desired adjustment icon.
Press the MENU Button again. Use the + / - Buttons to make the appropriate
C
adjustment or setting.
Press the AUTO Button to leave the menu, and the settings you just made would be
D
automatically saved.
For example, to correct for vertical position, select Menu item of Image Setup and then press
the MENU Button. Then, select V.Position by using the + / - Buttons.
An adjustment page appears after you press the MENU Button. Then, use the + / - Buttons
to change the vertical position settings. The vertical position of the overall display should be
changing accordingly while you are doing this.
Press the AUTO Button lastly, it ends, any changes are saved in the memory.
Image Setup
Clock
Phase
H.Position
V.Position
50
50
50
50
ENGLISH
NOTE
When button operations are aborted during adjustment, On-Screen Display disappears when the
time set for the Time out has passed. Also, the AUTO button can be used to return previous menu
and turn off the On-Screen Display.
Any changes are automatically saved in the memory when the On Screen Display
disappears.
Turning off the power should be avoided while using the Menu.
Adjustments for H. / V. Position, Clock and Phase are saved for each signal timing. Except for
these adjustments, all other adjustments have only one setting which applies to all signal timings.
OPERATING THE MONITOR 13
Page 19
ADJUSTMENT MENU CONTENTS
Direct
Direct
Luminance
Contrast
Brightness
Eco
Picture Mode
ACR
Luminance
50
50
Off
Standard
ON
Adjustment Item Problem / Option Button to Press
ENGLISH
Contrast
Brightness *
Too dull
Too intense
Too dark
Too bright
Off Normal
Eco
Picture Mode
ACR
NOTE
ACR adjusts brightness according to the image, and improve the contrast ratio during
Mode1 Brightness of back-light is reduced.
Mode2
Mode3
Standard
Text
Internet
Game
Movie
Sport
On
Off
Brightness of back-light is reduced more than Mode1.
Brightness of back-light is reduced more than Mode2.
For general windows environment and monitor
default setting.
For text editing and viewing in a word processing
environment.
For internet environment.
For PC game environment.
For movie and video environment.
For sport environment.
Increased Contrast Ratio
Typical Contrast Ratio
move playing.
Contrast, Brightness, sRGB, Eco and Picture Mode cannot be adjusted and selected
while ACR is active.
Adjust the Brightness when you are using the monitor in a dark room and feel the screen is too
*
bright.
You can skip the Menu items and display an adjustment scale directly by using the following button
operations.
ECO: Press the - Button when the Menu is not displayed.
14 OPERATING THE MONITOR
Page 20
Image Setup
Only Analog Input
Clock
Phase
H.Position
V.Position
Image Setup
50
50
50
50
Adjustment Item Problem / Option Button to Press
Clock*
Phase*
H. Position
V. Position
Too narrow
Too wide
To correct fl ickering text or lines
Too left
Too right
Too low
Too high
* See page 20 for SCREEN ADJUSTMENTS.
ENGLISH
OPERATING THE MONITOR 15
Page 21
Gamma
ENGLISH
Color Temp.
NOTE
Color Temp.
Gamma
Color Temp.
User-R
User-G
User-B
Color Temp.
Mode1
Warm
50
50
50
Adjustment Item Problem / Option Button to Press
NormalMode1
Mode2
Mode3
User
Cool
Normal
Warm
sRGB
sRGB is an international standard which defi nes and unifi es the difference of color
Dark
High contrast
User-R
User-G
User-B
Bluish white
Yellowish white
Greenish white
sRGB
Too weak
Too strong
appearance between equipment.
You can not adjust the Brightness, Contrast, Gamma and Eco during sRGB mode
because those settings are locked.
16 OPERATING THE MONITOR
Page 22
OSD Setup
H.Position
V.Position
Timeout
Language
OSD Setup
50
50
50
English
Adjustment Item Problem / Option Button to Press
H.Position
V.Position
Timeout
Language
OSD is too left
OSD is too right
OSD is too low
OSD is too high
You can set the OSD display duration time
between 5 and 60 seconds.
English
Deutsch
English
German
Italiano Italian
Français French
Español Spanish
Portuguese
Portuguese
ENGLISH
Simplifi ed Chinese
Russian
Japanese
OPERATING THE MONITOR 17
Page 23
Others
Direct
Direct
Reset
Signal Select
Information
Others
Yes
Auto
Resolution : 800(H)＊600(V)
H.Frequency : 38KHz
V.Frequency : 60Hz
Adjustment Item Problem / Option Button to Press
Yes
Factory-preset data is restored.
Reset
ENGLISH
Signal Select
NOTE
No
Auto Select the signal input automatically.
D-sub
DVI-D
At selected Auto, you can switch the input source by pressing and holding of the AUTO
Return to Menu.
Select the Analog input.
Select the Digital input.
Button for 2-3 seconds, However it will automatically be selected when just one source is
using.
In Power Management Mode input switching is disabled.
Input source is fi xed, not selected automatically when D-sub and DVI-D which are selected.
Displays information regarding the current input signal coming
Information
from the graphic card in your computer.
See your graphic card user guide for more information
NOTE
about changing the resolution and refresh.
You can skip the Menu items and display an adjustment scale directly by using the following button
operations.
Signal Select: Pressing and holding of the AUTO Button for 2-3 seconds when the Menu is not
displayed.
18 OPERATING THE MONITOR
Page 24
You can skip the Menu items and display an adjustment scale directly by using the following button
Direct
operations.
Volume: Press the + Button when the Menu is not displayed.
Adjustment Item Problem / Option Button to Press
Volume
Auto Adjust: Press the Auto Button when the Menu is not displayed.
Only Analog Input
Too soft
Too loud
Adjustment Item Problem / Option Button to Press
Auto Adjust *
* For best results, use the Auto Adjust in conjunction with the adjustment pattern. See page 20 for
SCREEN ADJUSTMENTS.
OSD Lock:
Hold the MENU button and turn on the monitor when the monitor is power-off, it will lock/unlock the
OSD Key Lock function.
Adjust H. / V. Position, Clock and Phase automatically.
ENGLISH
OPERATING THE MONITOR 19
Page 25
SCREEN ADJUSTMENTS
Adjust the image by following the procedure below to get the desired picture when selecting Analog input.
The screen adjustments described in this manual are designed to set image position and minimize
fl icker or blur for the particular computer in use.
The monitor is designed to provide the best performance at resolution of 1280 × 1024, but can not
provide the best at resolutions of less than 1280 × 1024 because the picture is automatically stretched
to fi t the full screen. It is recommended to operate at resolution of 1280 × 1024 in normal use.
Displayed text or lines will be blurred or irregular in thickness when the picture is stretched due to
the screen enlargement process.
It is preferable to adjust the image position and frequency with the monitor controls, rather than
the computer software or utilities.
ENGLISH
Perform adjustments after a warm-up period of at least thirty minutes.
Additional adjustments may be required after the Auto Adjust depending on the resolution or
signal timing.
The Auto Adjust may not work correctly when displaying the picture other than the screen
adjustment pattern. In this case, manual adjustments are required.
There are two ways to adjust the screen. One way is automatic adjustment for Position, Clock and
Phase. The other way is performing each adjustment manually.
Perform the Auto Adjust fi rst when the monitor is connected to a new computer, or resolution is
changed. If the screen has a flicker or blur, or the picture does not fit in the display area after
performing the Auto Adjust, manual adjustments are required. Both adjustments should be made by
using the screen adjustment pattern (Test.bmp) obtained via the IIYAMA web site (http://www.iiyama.
com).
Adjust the image by following the procedure below to get the desired picture.
This manual explains adjustment under Windows
®
OS.
Display the picture at the optimum resolution.
A
Enter the Test.bmp (screen adjustment pattern) to wallpaper.
B
Consult the appropriate documentation for doing this.
NOTE
Test.bmp is made at resolution of 1280 × 1024. Set the display position to center in
the wallpaper setting dialogue box.
[Adjustment pattern]
Zebra pattern
20 OPERATING THE MONITOR
Color bar
Picture frame
Page 26
Press the Auto Button. (Auto Adjust)
C
Adjust the image manually by following procedure below when the screen has a fl icker or
D
blur, or the picture does not fi t in the display area after performing the Auto Adjust.
Adjust the V.Position so that the top and bottom of the picture frame will fi t to the display
E
area.
1) Adjust the H.Position so that the left side of the picture frame will move to the left edge
F
of the display area.
ENGLISH
2) Stretch the right side of the picture frame to the right edge of the display area by
adjusting the Clock.
When the left side of the picture frame moves apart from the left edge of the display
NOTE
area during the Clock adjustment, adjust steps 1) and 2).
Another way to make the Clock adjustment is to correct the vertical wavy lines in the
zebra pattern.
The picture may fl icker during the Clock, H.Position and V.Position adjustment.
In case the picture frame is bigger or smaller than the data display area after the
Clock adjustment, repeat steps from C.
OPERATING THE MONITOR 21
Page 27
Adjust the Phase to correct horizontal wavy noise, fl icker or blur in the zebra pattern.
G
In case the strong fl icker or blurs remain on a part of the screen, repeat steps F and
NOTE
because the Clock may not be adjusted correctly. If the fl icker or blurs still remain,
G
set the refresh rate of computer to low (60Hz) and repeat steps from C again.
ENGLISH
Adjust the H.Position after the Phase adjustment if the horizontal position moves
during the adjustment.
Adjust the Brightness and Color to get the desired picture after you complete the Clock
H
and Phase adjustments.
Put back your favorite wallpaper.
22 OPERATING THE MONITOR
Page 28
POWER MANAGEMENT FEATURE
0 0.5W 100%
POWER
CONSUMPTION
Blue
Orange
Power Indicator
NORMAL MODE
POWER MANAGEMENT MODE
The power management feature of this product complies with power saving requirement of ENERGY
®
STAR
and VESA DPMS. When activated, it automatically reduces unnecessary power consumption
of the monitor when your computer is not in use.
To use the feature, the monitor needs to be connected to a VESA DPMS compliant computer.
There is a power management step the monitor takes as described below. The power management
function, including any timer settings is confi gured by the operating system. Check your operating
system manual for information on how this can be confi gured.
Power Management Mode
When the H-sync signal / V-sync signal / H and V sync signals from the computer are off, the
monitor enters into Power Management Mode which reduces the power consumption to less
than 0.5W. The screen becomes dark, and the power indicator turns to orange. From Power
Management Mode, the image reappears in several seconds when either the keyboard or the
mouse are touched again.
ENGLISH
NOTE
Even when using the power management mode, the monitor consumes electricity.
Turn off the Power Switch whenever the monitor is not in use, during the night and
weekends, to avoid unnecessary power consumption.
It is possible that the video signal from the computer may be on while the H or V sync
signal is missing. In this instance, the POWER MANAGEMENT feature may not work
properly.
OPERATING THE MONITOR 23
Page 29
TROUBLE SHOOTING
If the monitor fails to operate correctly, please follow the steps below for a possible solution.
1. Perform the adjustments described in OPERATING THE MONITOR, depending on the problem
you have. If the monitor does not get a picture, skip to 2.
2. Consult the following items if you cannot fi nd an appropriate adjustment item in OPERATING THE
MONITOR or if the problem persists.
3. If you are experiencing a problem which is not described below or you cannot correct the
problem, discontinue using the monitor and contact your dealer or iiyama service center for further
assistance.
Problem Check
The picture does
A
ENGLISH
not appear.
The Power Cable is fi rmly seated in the socket.
(Power indicator
does not light up.)
(Power indicator is
blue.)
(Power indicator is
orange.)
The screen is not
B
synchronized.
The Power Switch is turned ON.
The AC socket is live. Please check with another piece of equipment.
If the blank screen saver is in active mode, touch the keyboard or the
mouse.
Increase the Contrast and/or Brightness.
The computer is ON.
The Signal Cable is properly connected.
The signal timing of the computer is within the specifi cation of the monitor.
If the monitor is in power management mode, touch the keyboard or the
mouse.
The computer is ON.
The Signal Cable is properly connected.
The signal timing of the computer is within the specifi cation of the monitor.
The Signal Cable is properly connected.
The signal timing of the computer is within the specifi cation of the monitor.
The video output level of the computer is within the specifi cation of the
monitor.
The screen
C
position is not in
the center.
The screen is too
D
bright or too dark.
The screen is
E
shaking.
24 TROUBLE SHOOTING
The signal timing of the computer is within the specifi cation of the monitor.
The video output level of the computer is within the specifi cation of the
monitor.
The power voltage is within the specifi cation of the monitor.
The signal timing of the computer is within the specifi cation of the monitor.
Page 30
Problem Check
No sound.
F
The sound is too
G
loud or too quiet.
A strange noise is
H
heard.
The audio equipment (computer etc.) is ON.
The Audio Cable is properly connected.
The Volume is turned up.
The Mute is OFF.
The audio output level of the audio equipment is within the specifi cation of
the monitor.
The audio output level of the audio equipment is within the specifi cation of
the monitor.
The Audio Cable is properly connected.
ENGLISH
RECYCLING INFORMATION
For better environment protection please don't dispose your monitor.
Please visit our web site: www.iiyama.com/recycle for monitor recycling.
TROUBLESHOOTING / Recycling information 25
Page 31
APPENDIX
Design and specifi cations are subject to change without prior notice.
SPECIFICATIONS : ProLite B1706S
Size Category 17"
LCD Panel Driving system
Pixel pitch
Brightness
Contrast ratio
ENGLISH
Viewable angle
Response time
Display Colors
Sync Frequency
Maximum Resolution
Input Connector
Plug & Play
Input Sync Signal Separate sync: TTL, Positive or Negative
Input Video Signal
Input Audio Connector ø 3.5mm mini jack (Stereo)
Input Audio Signal
Speakers 1W × 2 (Stereo speakers)
Maximum Screen Size 337.9mm W × 270.3mm H / 13.3" W × 10.6" H
Power Source 100-240VAC, 50/60Hz, 1.5A
Dimensions / Net Weight 371.5 × 385.5-495.5 × 249.5mm / 14.6 × 15.2-19.5 × 9.8" (W×H×D)
Tilt Angle
Environmental
Considerations
Approvals
a-Si TFT Active Matrix
Diagonal: 17" (43cm)Size
0.264mm H × 0.264mm V
250cd/m
2
(Typical)
1000 : 1 (Typical), ACR Function Available
Right / Left : 85 degrees each, Up / Down: 80 degrees each (Typical)
5ms (Black, White, Black)
Approx.16.77M
Analog: Horizontal: 24.0-80.0kHz, Vertical: 55-75Hz
Digital: Horizontal: 30.0-80.0kHz, Vertical: 55-75Hz
1280 × 1024, 1.3 MegaPixels
D-Sub mini 15 pin, DVI-D 24 pin
VESA DDC2B
Analog: 0.7Vp-p (Standard), 75
TM
Positive
Digital: DVI (Digital Visual Interface Standard Rev.1.0) compliance
1.0Vrms maximum
18W typical, Power management mode: 0.5W maximum*Power Consumption
5.7kg / 12.6lbs
Upward: 20 degrees Left / Right: 170 degrees each
Operating: Temperature
Humidity
Storage:
Temperature
Humidity
5 to 35°C / 41 to 95°F
10 to 80% (No condensation)
-20 to 60°C / -4 to 140°F
5 to 85% (No condensation)
TCO Certifi ed, CE, TÜV-GS, VCCI-B
NOTE
26 APPENDIX
* Audio equipment is not connected.
Page 32
SPECIFICATIONS : ProLite E1706S
Size Category 17"
LCD Panel Driving system
Pixel pitch
Brightness
Contrast ratio
Viewable angle
Response time
Display Colors
Sync Frequency
Maximum Resolution
Input Connector
Plug & Play
Input Sync Signal Separate sync: TTL, Positive or Negative
Input Video Signal
Input Audio Connector ø 3.5mm mini jack (Stereo)
Input Audio Signal 1.0Vrms maximum
Speakers 1W × 2 (Stereo speakers)
Maximum Screen Size 337.9mm W × 270.3mm H / 13.3" W × 10.6" H
Power Source 100-240VAC, 50/60Hz, 1.5A
Dimensions / Net Weight 371.5 × 382.5 × 190.0mm / 14.6 × 15.1 × 7.5" (W×H×D)
Tilt Angle
Environmental
Considerations
Approvals
a-Si TFT Active Matrix
Diagonal: 17" (43cm)Size
0.264mm H × 0.264mm V
250cd/m
2
(Typical)
1000 : 1 (Typical), ACR Function Available
Right / Left : 85 degrees each, Up / Down: 80 degrees each (Typical)
5ms (Black, White, Black)
Approx.16.77M
Analog: Horizontal: 24.0-80.0kHz, Vertical: 55-75Hz
Digital: Horizontal: 30.0-80.0kHz, Vertical: 55-75Hz
1280 × 1024, 1.3 MegaPixels
D-Sub mini 15 pin, DVI-D 24 pin
VESA DDC2B
Analog: 0.7Vp-p (Standard), 75
TM
Positive
Digital: DVI (Digital Visual Interface Standard Rev.1.0) compliance
18W typical, Power management mode: 0.5W maximum*Power Consumption
3.5kg / 7.7lbs
Upward: 20 degrees Downward: 5 degrees
Operating: Temperature
Humidity
Storage:
Temperature
Humidity
TCO Certifi ed,
CE, TÜV-GS, VCCI-B
5 to 35°C / 41 to 95°F
10 to 80% (No condensation)
-20 to 60°C / -4 to 140°F
5 to 85% (No condensation)
ENGLISH
NOTE
* Audio equipment is not connected.
APPENDIX 27
Page 33
DIMENSIONS : ProLite B1706S
190.0mm/7.5"
382.5mm/15.1"
59.0mm/2.3"
323.0mm/12.7"
272.0mm/10.7"
371.5mm/14.6"
339.5mm/13.4"
371.5mm/14.6"
339.5mm/13.4"
59.0mm/2.3"
272.0mm/10.7"
323.0mm/12.7"
249.5mm/9.8"
385.5mm/15.2" (495.5mm/19.5")
ENGLISH
DIMENSIONS : ProLite E1706S
( ): Maximum adjustment range
28 APPENDIX
Page 34
COMPLIANT TIMING
Video Mode
VGA
SVGA
VESA
XGA
SXGA
Macintosh
PC9801
NOTE
* Digital input is not compliant.
640 × 480
800 × 600
1024 × 768
1280 × 1024
640 × 480
832 × 624
1024 × 768
640 × 400
Horizontal
Frequency
31.469kHz
37.500kHz
37.861kHz
35.156kHz
37.879kHz
46.875kHz
48.077kHz
48.363kHz
56.476kHz
60.023kHz
63.981kHz
79.976kHz
35.000kHz
49.725kHz
60.150kHz
24.827kHz
Vertical
Frequency
59.940Hz
75.000Hz
72.809Hz
56.250Hz
60.317Hz
75.000Hz
72.188Hz
60.004Hz
70.069Hz
75.029Hz
60.020Hz
75.025Hz
66.667Hz
74.500Hz
74.720Hz
56.424Hz
Dot Clock
25.175MHz
31.500MHz
31.500MHz
36.000MHz
40.000MHz
49.500MHz
50.000MHz
65.000MHz
75.000MHz
78.750MHz
108.000MHz
135.000MHz
30.240MHz
57.283MHz
80.000MHz
21.053MHz
ENGLISH
*
*
*
*
APPENDIX 29
M062B05
