I-Inc iH-191 User Manual

iH191

User’s Manual

Before operating the monitor, please read this manual thoroughly. This manual should be retained for future reference.

FCC Class B Radio Frequency Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

 Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

 Consult the dealer or an experienced radio/TV technician for help.

The device complies with Parts 15 of the FCC Rule. Operation is subject to the following two

conditions﹕ (1) this device may not cause harmful interference﹔ and (2) this device must accept any

interference received, including interference that may cause undesired operations.

CANADA

This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulation.

This device complies with requirement of EMC directive 2004/108/EC with regard to Electromagnetic Compatibility, and 73/23/EEC and 93/68/EEC with regard to Low Voltage directive.

Socket-outlet shall be near the equipment and shall be accessible.

User’s Manual

TABLE OF CONTENTS

SAFETY NOTICE .................................................................................................. 4

PRECAUTIONS................................................................................................. 4

SPECIAL NOTES ON LCD MONITORS ...................................................... 5

BEFORE YOU OPERATE THE MONITOR ...................................................... 6

FEATURES......................................................................................................... 6

CHECKING THE CONTENTS OF THE PACKAGE .................................. 6

INSTALLATION INSTRUCTIONS ................................................................ 7

POWER............................................................................................................... 7

SETTING THE MONITOR ON THE WALL ................................................ 8

MAKING CONNECTIONS.............................................................................. 9

ADJUSTING THE VIEWING ANGLE......................................................... 10

OPERATING INSTRUCTIONS ..........................................................................11

GENERAL INSTRUCTIONS..........................................................................11

FRONT PANEL CONTROL .......................................................................... 12

HOW TO ADJUST A SETTINGS .................................................................. 14

PLUG AND PLAY............................................................................................ 17

TECHNICAL SUPPORT (FAQ) ......................................................................... 18

Q & A FOR GENERAL PROBLEMS ........................................................... 18

ERROR MESSAGE & POSSIBLE SOLUTIONS ....................................... 20

APPENDIX ............................................................................................................ 22

SPECIFICATIONS.......................................................................................... 22

User’s Manual

SAFETY NOTICE

1. The changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

2. Shielded interface cables and AC power cord, if any, must be used in order to comply with the emission limits.

3. The manufacturer is not responsible for any radio or TV interference caused by unauthorized modification to this equipment. It is the responsibilities of the user to correct such interference.

4. Only use attachments/accesories specified by the manufacturer.

WARNING:

To prevent fire or shock hazard, do not expose the monitor to rain or moisture. Dangerously high voltages are present inside the monitor. Do not open the cabinet. Refer servicing to qualified personnel only.

PRECAUTIONS

• Do not use the monitor near water, e.g. near a bathtub, washbowl, kitchen sink, laundry tub,

swimming pool or in a wet basement.

• Do not place the monitor on an unstable cart, stand, or table. If the monitor falls, it can injure a

person and cause serious damage to the appliance. Use only a cart or stand recommended by the manufacturer or sold with the monitor. If you mount the monitor on a wall or shelf, use a mounting kit approved by the manufacturer and follow the kit instructions.

• Slots and openings in the back and bottom of the cabinet are provided for ventilation. To ensure

reliable operation of the monitor and to protect it from overheating, be sure these openings are not blocked or covered. Do not place the monitor on a bed, sofa, rug, or similar surface. Do not place the monitor near or over a radiator or heat register. Do not place the monitor in a bookcase or cabinet unless proper ventilation is provided.

• The monitor should be operated only from the type of power source indicated on the label. If you

are not sure of the type of power supplied to your home, consult your dealer or local power company.

• Unplug the unit during a lighting storm or when it will not be used for long period of time. This

will protect the monitor from damage due to power surges.

• Do not overload power strips and extension cords. Overloading can result in fire or electric shock.

• Never push any object into the slot on the monitor cabinet. It could short circuit parts causing a

fire or electric shock. Never spill liquids on the monitor.

• Do not attempt to service the monitor by yourself; opening or removing covers can expose you to

dangerous voltages and other hazards. Please refer all servicing to qualified service personnel.

• The wall socket shall be installed near the equipment and shall be easily accessible.

User’s Manual

SPECIAL NOTES ON LCD MONITORS

The following symptoms are normal with LCD monitor and do not indicate a problem.

• Due to the nature of the fluorescent light, the screen may flicker during initial use. Turn off the

Power Switch and then turn it on again to make sure the flicker disappears.

• You may find slightly uneven brightness on the screen depending on the desktop pattern you use.

• The LCD screen has effective pixels of 99.99% or more. It may include blemishes of 0.01% or

less such as a missing pixel or a pixel lit all of the time.

• Due to the nature of the LCD screen, an afterimage of the previous screen may remain after

switching the image, when the same image is displayed for hours. In this case, the screen is recovered slowly by changing the image or turning off the Power Switch for hours.

• If the screen suddenly flashes erratically or the backlighting fails, please contact your dealer or

service center for repair. Do not attempt to repair the monitor yourself.

Lamp Disposal

LAMP(S) INSIDE THIS PRODUCT CONTAIN MERCURY AND MUST BE RECYCLED OR DISPOSED OF ACCORDING TO LOCAL, STATE OR FEDERAL LAWS. FOR MORE INFORMATION, CONTACT THE ELECTRONIC INDUSTRIES ALLIANCE AT FOR LAMP SPECIFIC DISPOSAL INFORMATION CHECK

WWW.LAMPRECYCLE.ORG.

WWW.EIAE.ORG.

User’s Manual

BEFORE YOU OPERATE THE MONITOR

FEATURES

• 19” TFT Color LCD Monitor

• Crisp, Clear Display for Windows

• EPA ENERGY STAR

• GP Green Product

• Ergonomic Design

• Space Saving, Compact Case Design

CHECKING THE CONTENTS OF THE PACKAGE

The product package should include the following items:

LCD Monitor

Cables and User manual

Power Cord Warranty Card Quick Start Guide

User’s Manual VGA Cable

User’s Manual

INSTALLATION INSTRUCTIONS

INSTALL REMOVE

Figure.1. Installing and Removing the Base

INSTALLATION:

1. Align the monitor with the opening in the base.

2. Note that the longer section of the base points forward.

3. Snap the monitor into its base. A clear click sound will affirm that the base is connected

correctly.

4. Verify that the monitor is securely attached to the base by looking at the bottom of the base and

making sure that the clips are fully engaged in the base.

REMOVAL:

1. Flip over the monitor so that it is upside down.

2. Press the 2 clips on the base that holds the monitor in place.

3. Gently press and hold the 2 clips while pulling the base from the monitor unit they are

unattached.

POWER

POWER SOURCE:

1. Make sure that the power cord is the correct type required in your area.

2. This LCD monitor has an Internal universal power supply that allows operation in either

100/120V AC or 220/240V AC voltage area (No user adjustment is required.)

3. Connect the AC-power cord one end to your LCD monitor’s AC-input socket, the other end to

wall-outlet.
