iHome iH69 User Manual

Model iH69

Computer Speaker

System for your iPod®

Questions? Visit www.ihomeaudio.com

Table of Contents

Quick Start
Controls and Indicators
Using iH69
Charging your iPod
Listening to your iPod
Listening to Computer Audio
Listening to non-docking iPod or other audio devices
Listening to Headphones
Syncing your iPod to a Computer through iH69
Using the Optional Remote Control
Install/Replace the Remote Control Battery
A Consumer Guide to Product Safety
Trouble Shooting
Solución De Problemas
Warranty Information

and are registered trademarks of SRS Labs, Inc.

TruBass and WOW technologies are incorporated under license from SRS Labs, Inc.

1
2
3
3
3
3
4
4
4
5
5
6
7
8
9

Maintenance

• Place the unit on a level surface away from sources of direct sunlight or excessive heat.

• Protect your furniture when placing your unit on a natural wood and lacquered finish. A cloth or other protective material
should be placed between it and the furniture.

• Clean your unit with a soft cloth moistened only with mild soap and water. Stronger cleaning agents, such as Benzene,
thinner or similar materials can damage the surface of the unit.

FCC Information

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.

Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and , if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.
Shielded cables must be used with this unit to ensure compliance with the Class B FCC limits

SDI Technologies Inc.

1299 Main Street,

Rahway

NJ 07065

Tel. No.: [phone]

Getting Started

Thank you for purchasing the iHome iH69 Computer Speaker System for your iPod. Designed
specifically to work with your Computer and iPod, this system provides high quality audio
performance that brings out the best in your music.
Please read this instruction book carefully before operating the iH69 and keep it for future reference.

Check for iPod compatibility

iH69 is an advanced system and supports most updated iPod features. To make sure your iPod works properly with iH69,
please update your iPod firmware with the latest version via iTunes.

Quick Start: Connections

2:connections

RESET

RESET

TEST

TEST

DC 7.5V, 2.5A

3:inserts1:power

1) Connect the left and right speaker

DC 7.5V, 2.5A

using the included speaker cable.
The arrows on the plugs should face
downward to match arrows on unit.

2) Connect the USB cable to the left
Attach the AC adaptor cable to
the jack on the back of the left
speaker and plug the other end
into a working wall socket.

speaker and a powered USB port
on your computer.

3) Connect the computer audio cable

to the audio out jack on your
computer and to the computer jack
(marked “to computer”) on the iH69

Select the dock insert for your
iPod model from the table below
and place insert in dock.

Never dock an iPod without an
insert in place.

to listen to computer audio.

Use this insert

For this iPod

thin iPod with video (30 GB)
Insert 9

thin (30 GB) iPod with video
thin (80GB) iPod classic

iPod with video (60,80 GB)
Insert 10

thick (60, 80 GB) iPod with video
thick (160 GB) iPod classic

3rd Gen nano
insert 13

3rd Gen nano

NOTE: If the insert for your iPod isn’t listed, please visit an Apple store or www.ihomeaudio.com

to purchase the proper insert.

4:iPod

Insert iPod into dock with
proper insert (iPod must not
be in a skin or case). iPod
will charge while docked.
Press the Power button on
the iH69 then press
play/pause button on your
iPod to play the iPod.

5:stand

The iH69 has pull out
“feet” (stands) on the
back of each speaker
for added stability. Grip
the stands and pull
outward for use. Press
back under speaker
body when not
needed.

iPod Touch
insert 14

iPod Touch

1
