iHome iH55 User Manual
M
usic
Photos
E
xtras
S
ettings
Shuffle Songs
Backlight
Model iH55
The Home System
For Your iPod
®
Questions? Visit www.ihomeaudio.com
Table of Contents
Quick Start ........................................................................................................................................................................1
Controls and Indicators / iH55 Display ..........................................................................................................................2
Using the iH55 ...............................................................................................................................................................3-4
Replacing iH55 Backup Batteries....................................................................................................................................5
Install/Replace Backup Battery
Batteries information
Using the Remote Control Unit.......................................................................................................................................5
A Consumer Guide to Product Safety............................................................................................................................6
Troubleshooting ...............................................................................................................................................................7
Solucionando problemas ................................................................................................................................................9
Warranty Information .....................................................................................................................................................11
Package Contents
Package contains:
• iH55 home system
• Remote control
• AC adaptor
• AM antenna
• CD/MP3 Patch cord
• 3 dock inserts (for iPod nano and iPod with video 30 GB and iPod with video 60GB and 80GB)
• 2 switchable face panels
A consumer Guide to Product Safety
FCC Information
This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this
device does not cause harmful interference.
This equipment complies with the limits for a Class B digital device as specified in Part 15 of FCC Rules. These limits
provide reasonable protection against radio and TV interference in a residential area.
However, your equipment might cause TV or radio interference even when it is operating properly. To eliminate interference
you can try one or more of the following corrective measures:
• Reorient or relocate the receiving antenna.
• Increase the distance between the equipment and the radio or TV.
• Use outlets on different electrical circuits for the equipment and the radio or TV.
Consult your dealer or an experienced radio/television technician if the problem still exists.
Modifying or tampering with your system’s internal components can cause a malfunction and might invalidate the system’s
warranty and void your FCC authorization to operate it.
Maintenance
• Place the unit on a level surface away from sources of direct sunlight or excessive heat.
• Protect your furniture when placing your unit on a natural wood and lacquered finish. A cloth or other protective material should
be placed between it and the furniture.
• Clean your unit with a soft cloth moistened only with mild soap and water. Stronger cleaning agents, such as Benzine, thinner
or similar materials can damage the surface of the unit.
iH55 quick start
1:power 2:antenna 3:inserts
Attach AC adaptor cable to
jack on back of the iH55 and
plug the other end into a
wall socket.
NOTE: If you do not have an insert
for your iPod, please visit an Apple
store, www.ihomeaudio.com, or
call iHome toll free at 800-288-2792
to purchase one.
4:time
•Press & hold the Time Zone
button on back until display
flashes
•Turn the Set Wheel to select
your time zone
•Press the Time Zone
button again.
• Move the DST switch on back
of unit to +1 or -1 (adds or
subtracts an hour)
Use this insert
For this iPod
Snap AM antenna into provided
stand, then plug antenna cable
into socket on back of iH55.
Move antenna 12” away.
3rd Gen nano
3rd Gen nano
thin iPod with video (30 GB)
thin (30 GB) iPod with video
thin (80 GB) iPod classic
5:iPod
Insert iPod into dock (iPod® must
not be in a “skin” or case). Press
iPod Button on iH55. iPod will
charge while docked.
Select the dock insert for your
iPod® model from the chart
below and place insert in dock.
To avoid damage, never dock
your iPod without an insert .
iPod with video (60,80 GB)
thick (60,80 GB) iPod with video
thick (160 GB) iPod classic
6:radio
Press the Radio button. Press
AM/FM button to select your
band. Turn the Set Wheel to
tune in a station.
1
Controls and Indicators
AM/FM Select Button
Dock
Radio Button
Volume Wheel
iPod Button
Alarm On/Off Button
Alarm Set Button
Wake-To Button
AC Adaptor Jack
AM Loop Antenna socket
Snooze/Dimmer Button
Line Out Jack
volume
iPod radio am/fm sleep
alm. on/off alm. set wake-to alm. reset
Time Zone Button
DC 15V 1200mA
iH55 Display
snooze/dimmer
time zone clock adj.
am antenna
power off
Clock Adjust Button
DST
line inline out
+
-1
1
Sleep Button
Set Wheel
Alarm Reset/Power Off Button
DST Switch
Line in Jack
FM Antenna
Battery Low Indicator
Daylight Saving Time
Indicator
Time/Alarm Display
PM Indicator
2
Sleep Display
Alarm Armed
Wake To Indicator:
iPod, Radio, Buzzer,
iPod Indicator
Radio Frequency AM/FM Indicator
