iHome iH20, iH2O, iH20 IB User Manual

Model iH20

™

Water-Resistant

Shower Speaker

System For Your iPod

Questions? Visit www.ihomeaudio.com

Table of Contents

Controls and Indicators iH20 Quick Start Using the iH20 in the Shower Using the iH20 Connecting iH20 to AC Power Source Playing and Charging your iPod Using the Line-In and Headphone Jacks Batteries Installation A Consumer Guide to Product Safety Trouble Shooting Solución De Problemas Warranty Information

1 2 3 4 4 4 5 5 6 7 8 9

Package Contents

Congratulations on your iH20 home sound system for the iPod. Before you set up your unit, please check to see that the package contains the following items:

1 Main Unit 1 AC Adaptor 3 iPod Inserts 1 Audio Patch Cord

IMPORTANT SAFETY INFORMATION: IT IS THE USER'S RESPONSIBILITY TO USE THIS PRODUCT

PRUDENTLY, RESPONSIBLY AND IN A SAFE MANNER AT ALL TIMES.

DO NOT IMMERSE/SUBMERGE UNIT IN WATER DO NOT CONNECT TO AC OUTLET WHILE OPERATING IN SHOWER

Maintenance

• Place the unit on a level surface away from sources of direct sunlight or excessive heat.

• Protect your furniture when placing your unit on a natural wood and lacquered finish. A cloth or other protective material should be placed between it and the furniture.

• Clean your unit with a soft cloth moistened only with mild soap and water. Stronger cleaning agents, such as Benzine, thinner or similar materials can damage the surface of the unit.

Controls and Indicators

 Reverse Button

 Lower Volume

Side Panel

(under rubber tab)

Front Panel

 LED Light

 Raise Volume

 Forward Button

 Play / Pause Button (Hold 3 seconds for OFF)

Back Panel

 Loop Hanger

Inside Left Side Panel

 Line in Jack

SPULPU

Shower Rod Hook

 Headphone Jack

 AC Adaptor Jack

 Loop Hanger

Release Latch

iH20 Quick Start

MEN

1:Opening and closing iH20

OPEN

DC 7.5V

LOCK

To open the unit, use thumb to push the two sliding lock bars on either side UP to unlatch. To close cover, push lock bars back down.

Install iPod Insert

3:Inserts

Mini Insert

Use with

iPod Mini

iPod 4G 20 GB iPod Photo 20/30 GB * 5G iPodwith video 30 GB

Thin iPod Insert

Your iH20 comes with 3 removable inserts and a card with rubber pads to ensure your iPod fits properly in the iPod dock. Please see insert table to select the insert that fits

your iPod. Make sure you are using the correct insert for your iPod and that it is properly docked into the iH20. Failure to do so may damage your iPod.

To place an insert:

1. Select the insert for your iPod

2. Place the insert gently into docking bay.

3. Please note that iPod must not be in a case or “skin”.

Note: This device will not control or charge

the 3G iPod.

Thick iPod

(no Insert needed)

iPod 4G 40 GB iPod Photo 60 GB * 5G iPod with video 60/80 GB

2:Power: AC or batteries

RESET

TEST

To charge and play iPod, attach AC adaptor cable to jack on left of the iH20 (under rubber tab) and plug the other end into a working AC outlet. Does not charge batteries. For portable operation (in shower, etc.), open the battery door located inside the unit above the iPod dock. Install 4 AA batteries (match + and - polarity in diagram).

4:iPod

Insert iPod into dock with proper insert. Once iPod is docked, close the iH20. When running on AC power, the iPod will charge while docked. Press the Play Button on the iH20 to play your iPod.

Nano Insert

iPod Nano

2/4/8 GB

* To dock 5G iPod with video, replace rubber pads per instructions on the 5G rubber pad card included
