iHome iH10, iH14 User Manual

Model iH10/iH14

AM/FM for your iPod

NOTE: THIS UNIT WILL NOT CHARGE 3G iPod

Questions? Visit www.ihomeaudio.com

Table of Contents

Quick Start ........................................................................................................................................................................1

Controls and Indicators ...................................................................................................................................................2

Using your iHome.............................................................................................................................................................3

A Consumer Guide to Product Safety............................................................................................................................4

Troubleshooting ...............................................................................................................................................................5

Solucionando problemas ................................................................................................................................................6

Warranty Information .......................................................................................................................................................7

A Consumer Guide to Product Safety

This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this

device does not cause harmful interference.

This equipment complies with the limits for a Class B digital device as specified in Part 15 of FCC Rules. These limits provide reasonable protection against radio and TV interference in a residential area.

However, your equipment might cause TV or radio interference even when it is operating properly. To eliminate interference you can try one or more of the following corrective measures:

• Reorient or relocate the receiving antenna.

• Increase the distance between the equipment and the radio or TV.

• Use outlets on different electrical circuits for the equipment and the radio or TV. Consult your dealer or an experienced radio/television technician if the problem still exists.

Modifying or tampering with your system’s internal components can cause a malfunction and might invalidate the system’s warranty and void your FCC authorization to operate it.

Maintenance

• Place the unit on a level surface away from sources of direct sunlight or excessive heat.

• Protect your furniture when placing your unit on a natural wood and lacquered finish. A cloth or other protective material should be placed between it and the furniture.

• Clean your unit with a soft cloth moistened only with mild soap and water. Stronger cleaning agents, such as Benzine, thinner or similar materials can damage the surface of the unit.

quick start

1:power 2:antenna

Attach AC adaptor plug to jack on back of the unit and plug the other end into a wall socket.

NOTE: If you do not have an insert for your iPod, please visit an Apple store, www.ihomeaudio.com, or call iHome toll free at 800-288-2792 to purchase one.

4:iPod

Snap AM antenna into provided stand, then plug antenna cable into socket on back of unit. Move antenna 12” away.

iPod nano Insert 8

iPod nano

5:radio

3:inserts

Select the dock insert for your iPod® model from the table below and place insert in dock.

Never dock an iPod without an insert in place.

iPod with video (30 GB) Insert 9

thin (30 GB) iPod with video

iPod with video (60,80 GB) Insert 10

thick (60,80 GB) iPod with video

Insert an iPod® into the dock with proper insert (iPod must not be in a skin or case). The iPod will charge while docked. Turn the Function knob to iPod and press play on your iPod to play it .

Turn the Function knob to AM or FM to select AM or FM radio band. Turn the Tuning knob to desired radio station.
