1
Table of Contents
1. Hardware .................................................................................... 2
Hardware Connection ....................................................................................... 2
Connecting Touch Panel (Optional) .................................................................. 3
Connection Diagram ......................................................................................... 4
DIP Switch Settings ........................................................................................... 5
36 & 10 PIN Button Layout................................................................................ 6
Solving Ticket SSR Error ................................................................................... 6
Reset ................................................................................................................. 7
2. Bookkeeping & Adjustment .................................................... 10
Access Flow Chart .......................................................................................... 10
System Settings .............................................................................................. 11
Chance Settings .............................................................................................. 12
Touch Screen Calibration ................................................................................ 12
3. Introduction ............................................................................. 13
Features .......................................................................................................... 13
Main Game ...................................................................................................... 13
Shuffle Feature ................................................................................................ 14
Catrina Feature ............................................................................................... 15
Scatter Game .................................................................................................. 16
Bonus Game ................................................................................................... 17
Free Game ...................................................................................................... 18
Double Game .................................................................................................. 19
Win Rules ........................................................................................................ 20
Encouraging Higher Play ................................................................................ 20
Odds Table ...................................................................................................... 20
Line Chart ........................................................................................................ 21
2
1. Hardware
Hardware Connection
36-
Pin Connector
Audio Jack
SD Card Slot
10-
Pin Connector
A. RS-232
Connects to optional Citizen printer/ticket dispenser.
* Use Belkin #F2L044 (serial printer cable/null modem) for Citizen printer.
B. RS-232
Connects to Micro Touch
compatible touch screen
+5V
+5V Power output
DIP Sw 1
DIP Sw 2
VGA port
Connects to screen
3
Connecting Touch Panel (Optional)
Type A
Refer to the diagram below to connect the touch screen.
After the connection, remember to adjust the Pin 1 of
DIP SW2
to ON to enable
touch mode.
Power +5V Connector
(Female)
Monitor Connector
(15PIN Female)
4
Connection Diagram
36 Pins (6 Buttons)
10 Pins (6 Buttons)
PARTS SIDE
SOLDER SIDE
PARTS SIDE
SOLDER SIDE
1
GND 1
GND
SPEAKER_R 2
GND 2
GND
SPEAKER_L 3
GND
+5V 3
+5V
4
+5V 4
+5V
5
+12V 5
+12V
6
HOP-VCC 6
TICKET OUT 7
TICKET SSR 7
TICKET SWITCH 8
START / ALL STOP 9
8
STOP4/SMALL/HELP 10
GND 9
GND
STOP5/PLAY 11
GND 10
GND
STOP1/TAKE 12
STOP3/DOUBLE/SELECT LINE 13
14
15
STOP2/BIG/HOLD PAIR 16
17
COIN A 18
KEY IN
19
COIN C
RECORD 20
TEST
21
KEY OUT/PRINTER OUT
22
COIN A METER 23
KEY IN METER 24
25
COIN C METER 26
OUT METER
27
28
LAMP: START/ALL STOP
29
LAMP: STOP4/SMALL/HELP
30
LAMP: STOP5/PLAY
31
LAMP: COUNT
LAMP: STOP1/TAKE
32
LAMP:
STOP3/
DOUBLE/SELECT
LINE
33
LAMP: STOP2/BIG/HOLD PAIR
34
35
GND
36
GND
5
DIP Switch Settings
DIP SWITCH 1 1 2 3 4 5 6 7 8
SLAVE ID
1 OFF OFF OFF OFF OFF
2 ON OFF OFF OFF OFF
3 OFF ON OFF OFF OFF
4 ON ON OFF OFF OFF
5 OFF OFF ON OFF OFF
6 ON OFF ON OFF OFF
7 OFF ON ON OFF OFF
8 ON ON ON OFF OFF
9 OFF OFF OFF ON OFF
10 ON OFF OFF ON OFF
11 OFF ON OFF ON OFF
12 ON ON OFF ON OFF
13 OFF OFF ON ON OFF
14 ON OFF ON ON OFF
15 OFF ON ON ON OFF
16 ON ON ON ON OFF
17 OFF OFF OFF OFF ON
18 ON OFF OFF OFF ON
19 OFF ON OFF OFF ON
20 ON ON OFF OFF ON
21 OFF OFF ON OFF ON
22 ON OFF ON OFF ON
23 OFF ON ON OFF ON
24
ON ON ON OFF ON
OFF OFF OFF ON ON
ON OFF OFF ON ON
OFF ON OFF ON ON
ON ON OFF ON ON
OFF OFF ON ON ON
ON OFF ON ON ON
OFF ON ON ON ON
ON ON ON ON ON
LINK
MODE
SINGLE
OFF
LINK
ON
6
DIP SWITCH 2 1 2 3 4 5 6 7 8
TOUCH
NO OFF
YES ON
36 & 10 PIN Button Layout
6 Buttons
TAK E
STO P1
BIG
STO P 2
(HOLD)
DO UBLE
STO P 3
(SELECT
LINE)
SM ALL
STO P 4
(HELP)
STA RT
ALL STOP
TAKE
PLAY
STOP 5
Solving Ticket SSR Error
After powering on the machine, if the ticket dispenser keeps working and can’t be
stopped, it could be that the Ticket SSR’s jump setting is incorrect.
How to solve:
1. Locate the Ticket SSR jump (JP5) on the PC board. Then identify current
TICKET SSR
is at
HIGH ACTIVE
or
LOW ACTIVE
.
2. Change to use the alternative JP5 setting.
JP5
Low Active
3 2 1
Short pins 1-2
High Active (Default)
3 2 1
Short pins 2-3
7
Reset
1. Power off the machine and then power on.
2. Press and hold the
【【【【
TEST
】】】】
button until the game enters the
CHECKING
SYSTEM
page.
3. Enter the
「「「「
TEST
」」」」
page.
4. Press the
【【【【
PLAY
】】】】
button to enter the
「「「「
TEST 2
」」」」
PAGE (PAGE 2).
8
5. Press the
【【【【
STOP3
】】】】
button to enter the
「「「「
RESET
」」」」
page.
6. Press the
【【【【
PLAY
】】】】
button to
RESET
the game to default value.
9
7. Press the
【【【【
PLAY
】】】】
button again to confirm
RESET
or press
ANY
button to
EXIT.
8. After
RESET
is completed, it displays
SYSTEM RESET COMPLETED
on
the screen.
9. Power off the machine and then power on to complete the Reset procedure.
10
2. Bookkeeping & Adjustment
Access Flow Chart
[STOP2]
LAST HAND
Enter
Password
[RECORD]
[STOP3]
SHORT-TERM
Default password:
Press [START] 8 times
[STOP4]
SYSTEM
CURRENT
DATA
LAST
DATA
[STOP2]
MAIN GAME
[STOP3]
DOUBLE GAME
[STOP2]
MAIN GAME
[STOP4]
ADJUSTMENT
[STOP1]
INTERFACE
[STOP2]
SYSTEM
[STOP3]
CHANCE
[STOP4]
TIME
[STOP1]
VOLUME
[STOP2]
PRINTER
[STOP3]
TOUCH
[STOP2]
TOUCH CALIBRATE
[STOP3]
TOUCH REVERSE
[STOP3]
DOUBLE GAME
11
System Settings
ITEMS SETTING SELECTION DEFAULT
MAX. LINE PLAY 2, 4, 8, 10, 15, 20 20
MIN. PLAY(TOTAL) 1, 5, 10, 15, 25, 50, 75, 100, 125, 150 25
MIN. PLAY FOR
JACKPOT
1, 5, 10, 15, 25 25
JACKPOT MAX
15000, 20000, 50000, 70000, 100000, 150000,
200000
50000
COIN RATE
1,4,5,10,15,20,25,50,75,100,200,375,500,1000
25
KEY IN RATE 100
KEY OUT RATE 100
TICKET RATE 500
GAME TICKET 1,2,3,4,5,8,10, CONTINUOUS CONTINUOUS
INTERFACE DISPENSER , PRINTER ,ATTENDANT PRINTER
PRINTER COMMAND
CBM1 , ESC/POS , ESC/POS2 , STAR CBM1
DISPLAY CREDIT, 1C, 5C, 10C, 20C, 25C, 50C, $1 CREDIT
SYSTEM LIMIT NO, YES NO
AUTO TICKET NO, YES NO
DEMO MUSIC NO, YES YES
NON-STOP NO, YES NO
PASSWORD NO, YES NO
ODDS TABLE NO, YES YES
SCORE BOX NO, YES, 10X NO
PLAY SCORE NO, YES YES
HAND COUNT NO, YES NO
HOLD PLAY NO, YES YES
AUTO PLAY NO, YES YES
DOUBLE GAME NO, YES YES
JACKPOT MODE PROGRESSIVE, RANDOM PROGRESSIVE
12
Chance Settings
ITEMS SETTING SELECTION DEFAULT
MAIN GAME LEVEL
LEVEL1(Easiest), LEVEL2,LEVEL3,
LEVEL4,LEVEL5,LEVEL6(Hardest)
LEVEL 6
DOUBLE GAME LEVEL
85%, 90%, 95% 95%
Touch Screen Calibration
1. If a touch screen is connected,
press
[RECORD]>
[SYSTEM]>[INTERFACE]>
[TOUCH]
and follow the on-screen
prompts to enter the calibration
screen.
2. Touch center of the cross on the
screen for 3 seconds.
3. Follow the cross when it moves till
the calibration is completed.
13
3. Introduction
Features
25 Lines.
Win paid from left to right and right to left to increase the winning possibility.
Max. Win up to 500,000.
Touch screen / Auto play support.
Hold Pair Feature: When there is no win in a game, a player can press Hold
Pair button to keep the desired symbol and then re-spin again with the same
played amount
Main Game
DAY OF THE DEAD is a 5 Reels & 25 Lines game
3 sets of
Jackpots
25 Lines
Credit Symbol Zone
14
Shuffle Feature
Shuffle feature is randomly triggered.
Once triggered, various combinations appear and a new one will replace the
current result to give bigger prizes.
15
Catrina Feature
Catrina Feature will be triggered when appears in a game.
When it triggers, and the selected symbols will respin which may have
a chance to turn them into WILDs.
After respin, the Catrina feature will be triggered again when appears
again.
The Catrina feature ends when turns into WILD.
16
Scatter Game
3 or more symbols can trigger Scatter Game.
Players can select to play
Bonus Game
or
Free Game
.
17
Bonus Game
3 award 3 spin times in the Bonus Game.
4 award 4 spin times in the Bonus Game.
5 award 5 spin times in the Bonus Game.
Each spin players win the prize pointed by the indicator.
After each spin, winning grid and the grids next to winning grid will be added
the winning points before next spin.
The Bonus Game ends after running out the spin times.
18
Free Game
3 award 5 free games.
4 award 7 free games.
5 award 10 free games.
During the Free Games, Catrina Feature may trigger more frequently.
19
Double Game
After winning in a game, a player can press
[DOUBLE]
button to play Double
Game.
Press
[START]
button to select or .
Double your wins if your guess is correct. The game ends if your guess is
wrong.
20
Win Rules
Encouraging Higher Play
MIN. PLAY JACKPOT
25 100%
Odds Table
21
Line Chart
