Ignis EB3600 User Manual

EB3600

IGNIS

Ethanol Burner

User’s Manual

Installation Instructions

What’s in the box:

IGNIS

EB3600 Burner 1pc
Control Tool 1pc
Lighter 1pc
Funnel 1pc
User’s Manual 1pc

www.ignisproducts.com

EB3600 - User’s Manual

IGNIS

Installation Instructions

The Ignis Ethanol Burner can be fitted into a firebox that has minimum clearances
as outlined below.

Custom made fireboxes must be made out of a non-combustible material such as
stainless steel, stone, wonderboard.

Front
Clearance
(A)

2in
5cm

Rear
Clearance
(B)

1-1/2in
4cm

Side
Clearance
(C)

4in
10cm

Overhead
Clearance
(D)

30in
76cm

Nearest
Combustible
Radius

24in
61cm

Cut-Out Dimensions

Length Width Depth

36in

91.4cm

8in

20.3cm

4-1/2in

11.4cm

www.ignisproducts.com

Operation Instruction

IGNIS

1. Open the burner lid using the included tool. Fill the burner with ethanol fireplace
fuel. Watch carefully untill you reach the “MAX” level line. Do not overfill or spill.

CAUTION: Any spilled ethanol must be immediately removed with an absorbent tissue
and cleaned with water to prevent ignition outside the burner reservoir.

Fuel must be kept in safe distance (min. 1 meter / 40 inches) from the fireplace. Do
not place fuel in front of the fireplace.

2. Use a long match or a long lighter to ignite. When igniting, keep a safe distance at
arm’s length. Do not stand over the burner.

CAUTION: Fuel will burn low at first. Please allow 10-15 minutes to reach the optimal
temperature and flame height.
Avoid drafts for long burning time.

Always maintain a safe distance of at least 40 inches from the fireplace when lit.

Extinguishing

1. Let the fuel burn out completely if possible. This prevents alcohol left in the burner
from evaporating and deflagration when reigniting.

2. If you wish to extinguish the fire before fuel has completely burned out, please use
the control tool to fully close the cover of the burner in a fast motion.

3. In case the flame is not extinguished immediately repeat the above instructions
until the flame is fully extinguished.

4. Do not touch the fireplace while burning. Please allow at least 20 minutes to cool
down before touching the fireplace after flame is extinguished.

5. It is urgently recommended that you keep a Class B fire extinguisher at hand close
to the device in case of fire.
