IGNIS CF100 User Manual
GB
1. Lid handle
2. Lock (if provided)
3. Seal
4. Defrost water drain plug (if present)
5. Control panel
6. Basket (if present)
7. Condenser (located at the rear)
Climatic Class Amb. T. (°C) Amb. T. (°F)
SN From 10 to 32 From 50 to 90
N From 16 to 32 From 61 to 90
ST From 16 to 38 From 61 to 100
T From 16 to 43 From 61 to 110
INSTALLATION
• Please refer to the chapter "BEFORE USING THE
APPLIANCE".
• Unpack the appliance.
• Remove the 4 protection pieces inserted between
lid and appliance.
• Ensure that the defrosting water drainage plug (if
provided) is correctly positioned (4).
• For best operation of the appliance and in order to
avoid damage when the lid is opened, leave a space of
at least 7 cm from the rear wall and 7 cm at the sides.
• Fit the accessories (if provided).
INSTRUCTIONS FOR USE
1. Thermostat: it can be used to adjust the internal
temperature of the appliance.
2. Red LED (if provided): Indicates that the appliance
temperature is not sufficiently low.
3. Green LED (if provided): indicates that the appliance is on.
4. Yellow/orange illuminated button (if provided):
activates/deactivates the fast freeze function.
The exact configuration of the controls may vary
according to the model.
Switching on the appliance
• The appliance is factory set for optimum operation at a
temperature of -18°C.
• Plug in the appliance.
• The green LED lights up (if provided).
• Also the red LED (if provided) will switch on because the
temperature inside the appliance is not yet sufficiently low
for food storage. The red LED will normally switch off
within the first six hours after the appliance is switched on.
• After connecting the appliance to the mains supply and when
the optimal temperature has been reached (this phase takes
about 1 hour during which the lid will not open), ensure that
the fast freeze button is not pressed (the yellow LED, if
provided, is off).
• Place food inside the product only when the red LED (if
provided) has switched off.
• Thanks to the efficient lid seal, the appliance lid will not reopen easily immediately after closing. Wait a few minutes
before re-opening the lid of the appliance.
Temperature Adjustment
Use the thermostat to select the ideal storage temperature. To
adjust the internal temperature, proceed as follows:
• Turn the thermostat knob to 1 for a storage temperature
that is less cold.
• Turn the thermostat knob to 6 for a colder storage
temperature.
• For partial loads, or when the load indicator is below the "e"
symbol inside the appliance (if present), it is advisable to
move the thermostat to the lower position (on "e", if present
on the thermostat scale).
CO Small
INSTRUCTIONS FOR USE
BEFORE USING THE APPLIANCE
Your new appliance is designed exclusively for domestic use
and for storing frozen food, freezing fresh food and making
ice cubes.
Regulations require that the appliance is earthed.
The manufacturer declines all liability for injury to
persons or animals and for damage to property
resulting from failure to observe the above
procedures and reminders.
1. After unpacking, make sure that the appliance is
undamaged and that the lid closes perfectly tight. Any
damage must be reported to your dealer within 24
hours after delivery of the appliance.
FREEZING FOOD
Preparation of fresh food for freezing
• Before freezing, wrap and seal fresh food in: aluminium
foil, cling film, air and water-tight plastic bags,
polyethylene containers with lids, provided they are
suitable for freezing foods.
• Food must be fresh, mature and of prime quality in order
to obtain high quality frozen food.
• Fresh vegetables and fruit should preferably be frozen as
soon as they are picked to maintain the full original
nutritional value, consistency, colour and flavour.
• Always leave hot food to cool before placing in the
appliance.
Freezing fresh food
• Place foods to be frozen in direct contact with the walls
of appliance:
A) - foods to be frozen,
B) - foods already frozen.
2. Wait at least two hours before switching the appliance
on in order to ensure the refrigerant circuit is fully
efficient.
3. Installation of the appliance and electrical connections
must be carried out by a qualified electrician, in
accordance with the manufacturer's instructions and
local safety regulations.
4. Clean the inside of the appliance before using it.
• Before connecting the appliance to the mains supply,
ensure that the voltage corresponds to that given on the
rating plate located on the rear of the appliance.
• Electrical connections must be made in accordance
with local regulations.
• Avoid placing foods to be
frozen in direct contact with
food already frozen.
• For best and fastest freezing,
foods should be split into small
portions; this will also be useful
when the frozen items are to
be used.
1.At least 24 hours before
storing fresh food in the
appliance, press the fast freeze
button.
2.Place the food to be frozen
and keep the lid of the
appliance closed for 24 hours. The fast freeze function
automatically deactivates after about 50 hours.
FOOD STORAGE
Refer to the table on the appliance (if provided).
Classification of frozen
foods
Put the frozen products
into the appliance and
classify them; The storage
date should be indicated on
the packs, to allow use
within expiry dates.
Advice for storing frozen
food
When purchasing frozen food products:
• Ensure that the packaging is not damaged (frozen food in
damaged packaging may have deteriorated). If the
package is swollen or has damp patches, it may not have
been stored under optimal conditions and defrosting may
have already begun.
MONTHS
FOOD
• When shopping, leave frozen food purchases until last
and transport the products in a thermally insulated cool
bag.
• Once at home, place the frozen foods immediately in the
appliance.
• Avoid, or reduce temperature variations to the
minimum. Respect the best-before date on the package.
• Always observe the storage information on the package.
Note:
Eat fully or partially defrosted foods immediately.
Do not refreeze unless the food is cooked after it has
thawed. Once cooked, the thawed food can be refrozen.
If there is a long power failure:
• Do not open the appliance lid except to place ice packs
(if provided) over the frozen foods on the right and left
of the appliance. This will slow down the rise in
temperature.
