uIBX-230-BT Embedded System
Page i
MODEL:
Fanless Em bedd ed S ystem with In tel® Ce le ron ® N2930 1.83 GHz,
Rev. 1.00 – 11 Novem ber 2014
,
uIBX-230-BT Series
VGA , GbE, One USB 3.0, Three US B 2.0,
One COM and RoHS Compliant
User Manual
uIBX-230-BT Embedded System
Page ii
Date Version Changes
11 November 2014 1.00 Initial release
Revision
uIBX-230-BT Embedded Syste m
Page iii
Copyright
COP YRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliabilit y, design a nd functi on and d oes not r epresent a com mitm ent on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, e lectronic, or
other means in any form without prior w ritten permission of the manufacturer.
TRADEMARKS
All registered tradem ark s and produc t nam es ment ioned here in are us ed for identif icatio n
purposes only and m ay be trademarks and/or registe red trademarks of their respecti ve
owners.
uIBX-230-BT Embedded System
Page iv
Ta ble of Contents
1 INTRODUCTION .......................................................................................................... 1
1.1 OVERVIEW .................................................................................................................. 2
1.2 MODEL VARIATIONS ................................................................................................... 2
1.3 FEATURES ................................................................................................................... 3
1.4 TECHNICAL SPECIFICATIONS ...................................................................................... 3
1.5 FRONT PANEL ............................................................................................................. 4
1.6 REAR PANEL ............................................................................................................... 5
1.7 DIMENSIONS ............................................................................................................... 6
2 UNPACKING ................................................................................................................. 7
2.1 ANTI-STATIC PRECAUTIONS ........................................................................................ 8
2.2 UNPACKING PRECAUTIONS ......................................................................................... 8
2.3 PACKING LIST ............................................................................................................. 9
3 INSTALLATION ......................................................................................................... 10
3.1 INSTALLATION PRECAUTIONS .................................................................................... 11
3.2 INST ALLATION AND CONFIGURATION STEPS .............................................................. 11
3.3 HARD DISK DRIVE (HDD) INSTALLATION ................................................................. 11
3.4 AT/ATX MODE SELECTION ...................................................................................... 14
3.4.1 AT Power Mode ................................................................................................ 15
3.4.2 ATX Power Mode ............................................................................................. 15
3.5 RESET THE SYSTEM .................................................................................................. 15
3.6 POWERING ON THE SYSTEM ..................................................................................... 16
3.7 MOUNT THE SYSTEM ................................................................................................ 16
3.8 EXTERNAL PERIPHERAL INTERFACE CONNECTORS ................................................... 17
3.8.1 Audio Connection ............................................................................................. 18
3.8.2 LAN Connection ............................................................................................... 19
3.8.3 RS-232Serial Port Connection ......................................................................... 19
3.8.4 USB Device Connection ................................................................................... 20
3.8.5 VGA Monitor Connection ................................................................................ 21
uIBX-230-BT Embedded Syste m
Page v
4 SYSTEM MOTHERBOARD ..................................................................................... 23
4.1 OVERVIEW ................................................................................................................ 24
4.1.1 Layout .............................................................................................................. 24
4.2 INTERNAL PERIPHERAL CONNECTORS ...................................................................... 24
4.2.1 AT/ATX Mode Select Switch ............................................................................. 25
4.2.2 Audio Connector .............................................................................................. 26
4.2.3 Battery Connector ............................................................................................ 27
4.2.4 BIOS FW Connector ........................................................................................ 28
4.2.5 Buzzer Connector ............................................................................................. 29
4.2.6 Clear CMOS Button ......................................................................................... 29
4.2.7 CPU Fan Connector ........................................................................................ 30
4.2.8 DDR3L SO-DIMM Slot .................................................................................... 31
4.2.9 Display Port Connector ................................................................................... 32
4.2.10 EC FW Connector .......................................................................................... 33
4.2.11 Front Panel Connector ................................................................................... 34
4.2.12 LAN LED Connector ...................................................................................... 34
4.2.13 Power Button Connector ................................................................................ 35
4.2.14 Reset Button Connector ................................................................................. 36
4.2.15 RS-232 Serial Port Connector ....................................................................... 37
4.2.16 SATA 3Gb/s Drive Connector ........................................................................ 38
4.2.17 SATA Power Connector .................................................................................. 39
4.2.18 USB Connector .............................................................................................. 40
4.3 EXTERNAL INTERFACE PANEL CONNECTORS ............................................................ 40
4.3.1 LAN Connector ................................................................................................ 41
4.3.2 Power Connector ............................................................................................. 42
4.3.3 USB Connectors ............................................................................................... 42
4.3.1 VGA Connector ................................................................................................ 43
5 BIOS .............................................................................................................................. 44
5.1 INTRODUCTION ......................................................................................................... 45
5.1.1 Starting Setup ................................................................................................... 45
5.1.2 Using Setup ...................................................................................................... 45
5.1.3 Getting Help ..................................................................................................... 46
5.1.4 Unable to Reboot after Configuration Changes .............................................. 46
5.1.5 BIOS Menu Bar ................................................................................................ 46
uIBX-230-BT Embedded System
Page vi
5.2 MAIN ........................................................................................................................ 47
5.3 ADVANCED ............................................................................................................... 48
5.3.1 ACPI Settings ................................................................................................... 49
5.3.2 IT8528 Super IO Configuration ....................................................................... 50
5.3.2.1 Serial Port 1 Configuration ....................................................................... 50
5.3.3 Hardware Monitor ........................................................................................... 51
5.3.3.1 Smart Fan Mode Configuration ................................................................ 52
5.3.4 RTC Wake Settings ........................................................................................... 55
5.3.5 Serial Port Console Redirection ...................................................................... 56
5.3.5.1 Console Redirection Settings .................................................................... 57
5.3.6 CPU Configuration .......................................................................................... 60
5.3.7 IDE Configuration ........................................................................................... 61
5.3.8 USB Configuration ........................................................................................... 62
5.4 CHIPSET ................................................................................................................... 63
5.4.1 North Bridge Configuration ............................................................................. 64
5.4.1.1 Intel IGD Configuration ............................................................................ 64
5.4.2 Southbridge Configuration .............................................................................. 66
5.5 SECURITY ................................................................................................................. 68
5.6 BOOT ........................................................................................................................ 69
5.7 EXIT ......................................................................................................................... 71
A SAFETY PRECAUTIONS ......................................................................................... 73
A.1 SAFETY PRECAUTIONS ............................................................................................ 74
A.1.1 General Safety Precautions ............................................................................. 74
A.1.2 Anti-static Precautions .................................................................................... 74
A.1.3 Product Disposal ............................................................................................. 75
A.2 MAINTENANCE AND CLEANING PRECAUTIONS ........................................................ 76
A.2.1 Maintenance and Cleaning .............................................................................. 76
A.2.2 Cleaning T ools ................................................................................................. 76
B BIOS MENU OPTIONS ............................................................................................. 78
C WA TCHDOG TIMER ................................................................................................ 81
D HAZARDOUS MATERIALS DISCLOSURE ......................................................... 84
D.1 HAZARDOUS MATERIALS DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY ....................................... 85
uIBX-230-BT Embedded Syste m
Page vii
List of Figures
Figure 1-1: uIBX-230-BT ................................................................................................................. 2
Figure 1-2: uIBX-230-BT Front Panel
Figure 1-3: uIBX-230-BT Rear Panel
Figure 1-4: Physical Dimensions (mm)
Figure 3-1: Retention Screws Removal
Figure 3-2: HDD Bracket
Figure 3-3: HDD Retention Screws
Figure 3-4: HDD Retention Screws
Figure 3-5: AT/ATX Switch Location
Figure 3-6: Reset Button Location
Figure 3-7: Power Button Location
Figure 3-8: Mounting Bracket
Figure 3-9: Audio Connector
Figure 3-10: LAN Connection
Figure 3-11: DB-9 Serial Port Connector
Figure 3-12: USB Device Connection
Figure 3-13: VGA Connector
Figure 4-1: System Motherboard
............................................................................................ 5
............................................................................................. 5
........................................................................................ 6
......................................................................................12
..............................................................................................................12
.............................................................................................13
.............................................................................................14
...........................................................................................14
..............................................................................................16
.............................................................................................16
......................................................................................................17
.......................................................................................................18
......................................................................................................19
....................................................................................20
.........................................................................................21
.......................................................................................................22
................................................................................................24
Figure 4-2: AT/ATX Mode Select Switch Location
Figure 4-3: Audio Connector Location
Figure 4-4: Battery Connector Location
Figure 4-5: BIOS FW Connector Location
Figure 4-6: Buzzer Connector Location .....................................................................................29
Figure 4-7: Clear CMOS Button Location
Figure 4-8: CPU Fan Connector Location
Figure 4-9: DDR3L SO-DIMM Slot Location
Figure 4-10: Display Port Connector Location
Figure 4-11: EC FW Connector Location
Figure 4-12: Front Panel Connector Location
Figure 4-13: LAN LED Connector Location
....................................................................26
.......................................................................................27
.....................................................................................28
..................................................................................28
...................................................................................30
..................................................................................31
...............................................................................32
..........................................................................32
....................................................................................33
...........................................................................34
...............................................................................35
uIBX-230-BT Embedded System
Page viii
Figure 4-14: Power Button Connector Location ........................................................................36
Figure 4-15: Reset Button Connector Locati o n
Figure 4-16: RS-232 Serial Port Connector Location
Figure 4-17: SATA 3Gb/s Drive Connector Location
Figure 4-18: SATA Power Connector Locatio n
Figure 4-19: USB Connector Location
Figure 4-20: LAN Connector
Figure 4-21: VGA Connector
.........................................................................37
................................................................38
................................................................39
.........................................................................39
........................................................................................40
........................................................................................................41
.......................................................................................................43
uIBX-230-BT Embedded Syste m
Page ix
List of Tables
Table 1-1: Model Variations ........................................................................................................... 2
Table 1-2: Technical Specifications
Table 2-1: Package List Contents
Table 4-1: Peripheral Interface Connectors
Table 4-2: AT/ATX Mode Select Switch Settings
Table 4-3: Audio Connector Pinouts
Table 4-4: Battery Connector Pinouts
Table 4-5: BIOS FW Connector Pinouts
Table 4-6: Buzzer Connector Pinouts
Table 4-7: Clear CMOS Button Settings
Table 4-8: CPU Fan Connector Pinouts
Table 4-9: Display Port Connector Pinouts
Table 4-10: EC FW Connector Pinouts
Table 4-11: Front Panel Connector Pinouts
Table 4-12: LAN LED Connector Pinouts
Table 4-13: Power Button Connector Pinouts
Table 4-14: Reset Button Connector Pinouts
Table 4-15: RS-232 Serial Port Connector Pinouts
.............................................................................................. 4
................................................................................................. 9
...............................................................................25
.......................................................................26
..........................................................................................27
........................................................................................28
.....................................................................................29
.........................................................................................29
.....................................................................................30
.....................................................................................31
...............................................................................33
.......................................................................................34
...............................................................................34
...................................................................................35
...........................................................................36
............................................................................37
...................................................................38
Table 4-16: SATA Power Connector Pinouts
Table 4-17: USB Connector Pinouts
Table 4-18: Rear Panel Connectors
Table 4-19: LAN Pinouts
Table 4-20: Connector LEDs
Table 4-21: Power Connector Pinouts
Table 4-22: USB 2.0 & USB 3.0 Port Pinouts
Table 4-23: VGA Connector Pinouts
Table 5-1: BIOS Navigation Keys
.............................................................................39
...........................................................................................40
............................................................................................41
..............................................................................................................41
........................................................................................................41
........................................................................................42
.............................................................................42
...........................................................................................43
................................................................................................46
uIBX-230-BT Embedded Syste m
Page 1
Chapter
1
1 Introduction
uIBX-230-BT Embedded System
Page 2
1.1 Overview
Figure 1-1: uIBX-230-BT
The uIBX-230-BT embedded system is a fanless system with one VGA por t for d is pla y. It
accepts an Intel® Celeron® N2930 1.83 GHz quad core processor and supports one
204-pin DDR3L 1.35V SO-DIMM module up to 8 GB. The uIBX-230-BT supports a 2.5”
SATA HDD with up to 3 Gb/s data transfer rate. One serial port, one USB 3.0 port and
three USB 2.0 ports ensure simplified connectivity to a variety of external peripheral
devices.
1.2 Mode l Variations
The model variations of the uIBX-230-BT series are list ed below.
Models CPU Memory
uIBX-230-BT-N2-R10 Intel® Celeron® N2930 w/o mem o ry
uIBX-230-BT-N2/2G-R10 Intel® Celeron® N2930 2GB DDR3L pre-installed memory
Table 1-1: Model Variations
uIBX-230-BT Embedded Syste m
Page 3
1.3 Features
The uIBX-230-BT features are listed below:
Ultra compact size embedded system
Intel® Celeron® processor N2930 1.83 GHz 7.5W on-board
1 x 2.5'' SATA 3Gb/s HDD/SSD drive bay
DDR3L SO-DIMM for low power consumption
1.4 Technical Specifications
The uIBX-230-BT technical specifications are listed in Table 1-2.
Chassis
Color
Dimensions (WxDxH)
System Fan
Chassis Construction
Motherboard
CPU
Chipset
System Memory
Storage
Hard Drive
I/O Interfaces
USB 3.0
USB 2.0
Silver
137 x 102.8 x 52 (mm)
Fanless
Extruded aluminum alloys
Intel® Celeron® N2930 1.83 GHz
SoC
One 204-pin DDR3L 1.35V SO-DIMM 2GB pre-installed (system
max capacity 8G)
1 x 2.5'' SATA 3Gb/s HDD/SSD Bay
1 x USB 3.0 port
3 x USB 2.0 ports
Ethernet
RS-232
Display
1 x RJ-45
1 x PCIe GbE by Intel® I210
1 x DB-9
1 x VGA
uIBX-230-BT Embedded System
Page 4
Resolution
Audio
Power
Power Input
Power Consumption
Reliability
Mounting
Operating Temperature
Operating Shock
Operating Vibration
Weight (Net/Gross)
Safety/EMC
2560 x 1600
1 x Line-out, 1 x Mic-in
DC Jack: 12 V DC
12 V@1.8 A (Intel® Celeron® Processor N2930 with 2 GB memory)
Wall mount
-20°C ~60°C with air flow (SSD),
5% ~ 95%, non-condensing
Half-sine wave shock 5G, 11ms, 3 shocks per axis
MIL-STD-810F 514.5-1 (HDD),
MIL-STD-810F 514.5 C-2 (SSD)
470 g/1.4 kg
CE/FCC
OS
Supported OS
Table 1-2: Technical Specifications
Microsoft® Windows® 8,
Microsoft® Windows® Embedded Standard 7 E
1.5 Front Panel
The front panel of the uIBX-230-BT has the following features (Figure 1-2):
1 x HDD LED
1 x Line out
1 x Mic
1 x Power button
1 x Reset button
1 x RS-232 serial port connector
2 x USB 2.0 connectors
uIBX-230-BT Embedded Syste m
Page 5
Figure 1-2: uIBX-230-BT Front Panel
1.6 Rear Panel
The rear panel of the uIBX-230-BT has the following features (Figure 1-3):
1 x AT/ATX Switch
1 x RJ-45 LAN connector
1 x USB 3.0 connector
1 x USB 2.0 connector
1 x 12 V DC IN
1 x VGA port
Figure 1-3: uIBX-230-BT Rear Panel
uIBX-230-BT Embedded System
Page 6
1.7 Dimensions
The physical dimensions are shown below:
Figure 1-4: Physi c al Dimensions (mm)
uIBX-230-BT Embedded Syste m
Page 7
Chapter
2
2 Unpacking
uIBX-230-BT Embedded System
Page 8
2.1 Anti-static Precautions
WARNING:
Failure to take ESD precautions during installation may result in
permanent damage to the uIBX-230-BT and severe injury to the user.
Electrostatic discharge (ESD) can cause serious damage to electronic components,
including the uIBX-230-BT. Dry climates are especiall y susceptibl e to ESD. It is theref ore
critical that whenever t he uIBX-230-BT or any other electrical com ponent is handled, the
following anti-static precautions are strictly adhered to.
Wear an anti-static wristband: Wearing a simple anti-static wristband can
help to prevent ESD from damaging the board.
Self-grounding: Before handling the board, touch any grounded conducting
material. During the time the board is handled, frequently touch any
conducting materials that are connected to the ground.
Use an anti-static pad: When configuring the uIBX-230-BT, place it on an
antic-static pad. This reduces the possibility of ESD damaging the
uIBX-230-BT.
2.2 Unpacking Precautions
When the uIBX-230-BT is unpacked, please do the following:
Follow the anti-static precautions outlined in Section 2.1.
Make sure the packing box is facing upwards so the uIBX-230-BT does not
fall out of the box.
Make sure all the components shown in Section 2.3 are present.
uIBX-230-BT Embedded Syste m
Page 9
2.3 Packing List
NOTE:
If some of the components listed in the checklist below are missing,
please do not proceed with the installation. Contact the IEI resel ler or
vendor you purchas ed the uIBX-230-BT from or contact an IEI sales
representative direct ly. To contact an IEI s ales representati ve, please
send an email to
The uIBX-230-BT is shipped with the following components:
Quantity Item and Part Number Im a g e
1 uIBX-230-BT
1 1 x Power Adapter
(P/N: 63000-FSP036RAB608-RS)
1 1 x Power Cord
(P/N: 32702-000401-100-RS)
1 1 x Mounting Bracket
sales@iei.com.tw.
Table 2-1: Package List Contents
(P/N: 41020-0403C2-00-RS)
Loading...
