User Manual

TANK-800 Embedded System

MODEL:

TANK-800

Fanless Embedded System with Intel® Atom™ D525

Dual Core CPU, VGA, Two Gigabit Ethernet, Four USB,

RS-232/422/485, RoHS Compliant

Rev. 1.15 – September 10, 2015

Page i

TANK-800 Embedded System

Revision

Date Version Changes

September 10, 2015 1.15 Updated memory spec September 2, 2013 1.14 Updated Section 3.4: System Fan Installation April 2, 2013 1.13 Added the maximum dimensions of an expansion card in

Section February 5, 2013 1.12 Updated the optional system fan P/N May 10, 2012 1.11 Updated Section 1.7: Backplane Options December 5, 2011 1.10 Updated Section 2.3: Unpacking Checklist

Updated Section

Updated Appendix A: One Key Recovery November 3, 2011 1.00 Initial release

1.7

3.7.9: RJ-45 RS-422/485 Serial Ports

Page ii

TANK-800 Embedded System

The information in this document is subject to change without prior notice in order to

improve reliability, design and function and does not represent a commitment on the part

of the manufacturer.

In no event will the manufacturer be liable for direct, indirect, special, incidental, or

consequential damages arising out of the use or inability to use the product or

documentation, even if advised of the possibility of such damages.

This document contains proprietary information protected by copyright. All rights are

reserved. No part of this manual may be reproduced by any mechanical, electronic, or other means in any form without prior written permission of the manufacturer.

TRADEMARKS

All registered trademarks and product names mentioned herein are used for identification

purposes only and may be trademarks and/or registered trademarks of their respective

owners.

Page iii

TANK-800 Embedded System

WARNING

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and(2) this device must accept any interference received, including interference that may cause u ndesired operation.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

—

Reorient or relocate the receiving antenna.

—

Increase the separation between the equipment and receiver.

—

Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

—

Consult the dealer or an experienced radio/ TV technician for help.

You are cautioned that any change or modifications to the equipment not expressly approve by the party responsible for compliance could void your authority to operate such equipment.

IMPORTANT NOTE:

FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body

Page iv

TANK-800 Embedded System

Manual Conventions

WARNING

Warnings appear where overlooked details may cause damage to the

equipment or result in personal injury. Warnings should be taken

seriously.

CAUTION

Cautionary messages should be heeded to help reduce the chance of

losing data or damaging the product.

NOTE

These messages inform the reader of essential but non-critical

information. These messages should be read carefully as any directions

or instructions contained therein can help avoid making mistakes.

HOT SURFACE

This symbol indicates a hot surface that should not be touched without taking care.

Page v

TANK-800 Embedded System

Table of Contents

1 INTRODUCTION.......................................................................................................... 1

1.1 OVERVIEW.................................................................................................................. 2

1.2 MODEL VARIATIONS ................................................................................................... 3

1.3 FEATURE S................................................................................................................... 3

1.4 TECHNICAL SPECIFICATIONS ...................................................................................... 4

1.5 CONNECTOR PANEL.................................................................................................... 6

1.6 LED INDICATORS ....................................................................................................... 7

1.7 BACKPLANE OPTIONS ................................................................................................ 8

1.8 DIMENSIONS............................................................................................................. 10

2 UNPACKING................................................................................................................11

2.1 ANTI-STATIC PRECAUTIONS...................................................................................... 12

2.2 UNPACKING PRECAUTIONS....................................................................................... 12

2.3 UNPACKING CHECKLIST ........................................................................................... 13

3 INSTALLATION ......................................................................................................... 16

3.1 INSTALLATION PRECAUTIONS................................................................................... 17

3.2 CF CARD INSTALLATION .......................................................................................... 17

3.3 HARD DISK DRIVE (HDD) INSTALLATION................................................................ 19

3.4 SYSTEM FAN INSTALLATION..................................................................................... 22

3.5 PLUGGABLE DC-IN TERMINAL BLOCK INSTALLATION ............................................. 25

3.6 MOUNTING THE SYSTEM WITH MOUNTING BRACKETS ............................................ 26

3.7 EXTERNAL PERIPHERAL INTERFACE CONNECTORS................................................... 27

3.7.1 ACC Mode Selection ........................................................................................ 28

3.7.2 AT/ATX Power Mode Selection........................................................................ 28

3.7.3 Audio Connector .............................................................................................. 29

3.7.4 CompactFlash® Type II................................................................................... 29

3.7.5 Digital Input/Output Connector....................................................................... 29

3.7.6 LAN Connectors............................................................................................... 30

3.7.7 Power Input, 3-pin Terminal Block.................................................................. 32

Page vi

TANK-800 Embedded System

3.7.8 Power Input, 4-pin DIN Connector ................................................................. 32

3.7.9 RJ-45 RS-422/485 Serial Ports........................................................................ 33

3.7.10 RS-232 Serial Port Connectors...................................................................... 35

3.7.11 USB Connectors............................................................................................. 37

3.7.12 VGA Connector.............................................................................................. 38

3.8 POWERING ON/OFF THE SYSTEM ............................................................................. 40

3.9 REDUNDANT POWER ................................................................................................ 40

3.9.1 ACC ON ........................................................................................................... 41

3.9.1.1 Boot-up ..................................................................................................... 42

3.9.1.2 Switch to Backup Power........................................................................... 42

3.9.1.3 Shutdown .................................................................................................. 43

3.9.2 ACC OFF......................................................................................................... 44

3.9.2.1 Boot-up ..................................................................................................... 44

3.9.2.2 Switch to Backup Power........................................................................... 44

3.9.2.3 Shutdown .................................................................................................. 45

4 BIOS.............................................................................................................................. 46

4.1 INTRODUCTION......................................................................................................... 47

4.1.1 Starting Setup................................................................................................... 47

4.1.2 Using Setup...................................................................................................... 47

4.1.3 Getting Help..................................................................................................... 48

4.1.4 Unable to Reboot After Configuration Changes.............................................. 48

4.1.5 BIOS Menu Bar................................................................................................ 48

4.2 MAIN........................................................................................................................ 49

4.3 ADVANCED............................................................................................................... 50

4.3.1 ACPI Settings................................................................................................... 51

4.3.2 CPU Configuration.......................................................................................... 52

4.3.3 IDE Configuration........................................................................................... 53

4.3.4 USB Configuration........................................................................................... 55

4.3.5 Super IO Configuration ................................................................................... 56

4.3.5.1 Serial Port n Configuration....................................................................... 57

4.3.6 H/W Monitor.................................................................................................... 63

4.3.7 Serial Port Console Redirection...................................................................... 64

4.3.8 iEi Feature........................................................................................................ 66

4.4 CHIPSET ................................................................................................................... 67

Page vii

4.4.1 Host Bridge Configuration .............................................................................. 68

4.4.2 South Bridge Configuration............................................................................. 68

4.4.3 Intel IGD SWSCI OpRegion............................................................................. 70

4.5 BOOT........................................................................................................................ 71

4.6 SECURITY................................................................................................................. 72

4.7 EXIT......................................................................................................................... 74

A REGULATORY COMPLIANCE.............................................................................. 76

B SAFETY PRECAUTIONS.........................................................................................81

B.1 SAFETY PRECAUTIONS............................................................................................. 82

B.1.1 General Safety Precautions............................................................................. 82

B.1.2 Anti-static Precautions.................................................................................... 83

B.1.3 Product Disposal............................................................................................. 84

B.2 MAINTENANCE AND CLEANING PRECAUTIONS ........................................................ 84

TANK-800 Embedded System

B.2.1 Maintenance and Cleaning.............................................................................. 84

B.2.2 Cleaning Tools................................................................................................. 85

C DIGITAL I/O INTERFACE....................................................................................... 86

C.1 INTRODUCTION........................................................................................................ 87

C.2 ASSEMBLY LANGUAGE SAMPLE 1............................................................................ 88

C.3 ASSEMBLY LANGUAGE SAMPLE 2............................................................................ 88

D HAZARDOUS MATERIALS DISCLOSURE......................................................... 89

D.1 HAZARDOUS MATERIALS DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS

ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY ....................................... 90

Page viii

TANK-800 Embedded System

List of Figures

Figure 1-1: TANK-800.....................................................................................................................2

Figure 1-2: TANK-800 Peripheral Connectors.............................................................................6

Figure 1-3: TANK-800 LED Indicators...........................................................................................7

Figure 1-4: TANK-800-D525/1GB/2P1E-R10 Backplane (HPE-3S6) ...........................................8

Figure 1-5: TANK-800-D525/1GB/1P2E-R10 Backplane (HPE-3S7) ...........................................8

Figure 1-6: Physical Dimensions (millimeters)..........................................................................10

Figure 3-1: CF Card Slot ..............................................................................................................18

Figure 3-2: CF Card Slot Cover...................................................................................................18

Figure 3-3: CF Card Installation..................................................................................................19

Figure 3-4: Unscrew the Cover....................................................................................................20

Figure 3-5: Remove the Cover from TANK-800.........................................................................20

Figure 3-6: HDD Installation ........................................................................................................21

Figure 3-7: HDD Retention Screws.............................................................................................21

Figure 3-8: Remove the HDD Bracket from the Cover..............................................................22

Figure 3-9: Remove the Fan Bracket from the Cover ...............................................................23

Figure 3-10: Remove the Temporary Retaining Bracket..........................................................23

Figure 3-11: Secure the System Fan to the Fan Bracket..........................................................24

Figure 3-12: Reinstall the Fan Bracket.......................................................................................24

Figure 3-13: Pluggable DC-in Terminal Block Installation .......................................................25

Figure 3-14: Mounting Bracket Retention Screws ....................................................................26

Figure 3-15: ACC Mode Switch ...................................................................................................28

Figure 3-16: AT/ATX Power Mode Switch ..................................................................................28

Figure 3-17: Audio Connector.....................................................................................................29

Figure 3-18: DIO Connector Pinout Location ............................................................................30

Figure 3-19: LAN Connection......................................................................................................31

Figure 3-20: RJ-45 Ethernet Connector......................................................................................31

Figure 3-21: 3-pin Terminal Block Pinout Location ..................................................................32

Figure 3-22: Power Input Connector...........................................................................................33

Figure 3-23: RJ-45 RS-422/485 Serial Device Connection........................................................34

Figure 3-24: RJ-45 RS-422/485 Serial Port Pinout Location.....................................................34

Page ix

Figure 3-25: DB-9 Connector Pinout Location ..........................................................................35

Figure 3-26: Serial Device Connector.........................................................................................36

Figure 3-27: Serial Port Pinout Location....................................................................................36

Figure 3-28: USB Device Connection.........................................................................................37

Figure 3-29: VGA Connector .......................................................................................................39

Figure 3-30: VGA Connector .......................................................................................................39

Figure 3-31: Power Button...........................................................................................................40

Figure 3-32: Power Connectors ..................................................................................................41

Figure 3-33: ACC On: AT Mode...................................................................................................42

Figure 3-34: ACC On: ATX Mode.................................................................................................42

Figure 3-35: ACC On: Switch Between PWR1 and PWR2 ........................................................43

Figure 3-36: ACC On: Shutdown.................................................................................................43

Figure 3-37: ACC Off: AT Mode...................................................................................................44

Figure 3-38: ACC Off: ATX Mode ................................................................................................44

TANK-800 Embedded System

Figure 3-39: ACC Off: Switch Between PWR1 and PWR2........................................................45

Figure 3-40: ACC Off: Shutdown.................................................................................................45

Page x

TANK-800 Embedded System

List of Tables

Table 1-1: TANK-800 Model Variations.........................................................................................3

Table 1-2: Technical Specifications..............................................................................................5

Table 1-3: Supported Signals........................................................................................................8

Table 1-4: Rated Voltage and Current ..........................................................................................9

Table 3-1: DIO Connector Pinouts..............................................................................................30

Table 3-2: LAN Pinouts ................................................................................................................31

Table 3-3: RJ-45 Ethernet Connector LEDs...............................................................................32

Table 3-4: Power Input Pinouts...................................................................................................33

Table 3-5: RJ-45 RS-422/485 Serial Port Pinouts ......................................................................34

Table 3-6: DB-9 Connector Pinouts............................................................................................35

Table 3-7: Serial Port Pinouts......................................................................................................36

Table 3-8: USB Port Pinouts........................................................................................................38

Table 3-9: VGA Connector Pinouts.............................................................................................39

Table 4-1: BIOS Navigation Keys................................................................................................48

TANK-800

Page xi

TANK-800 Embedded System

Chapter

1 Introduction

Page 1

1.1 Overview

TANK-800 Embedded System

Page 2

Figure 1-1: TANK-800

The TANK-800 Series embedded system is a fanless system for wide range temperature

environments. It is powered by the Intel® Atom D525 dual core processor, uses the

Intel® ICH8M chipset and has 1.0 GB of DDR3 memory. The TANK-800 Series includes

one VGA port, two PCIe GbE LAN, four USB 2.0 ports, and six COM ports.

TANK-800 Embedded System

1.2 Model Variations

The model variations of the TANK-800 Series are listed below.

Model No. CPU Expansion Slots

TANK-800-D525/1GB/2P1E-R10

TANK-800-D525/1GB/1P2E-R10

Table 1-1: TANK-800 Model Variations

1.3 Features

The TANK-800 features are listed below:

 Intel® Atom D525 1.8 GHz dual core processor

 On-board 1.0 GB DDR3 memory

 Redundant dual DC input

 Flexible PCI/PCIe expansion slots

 Two Gigabit Ethernet ports

 Four USB 2.0 ports

 Four RS-232 serial ports

Intel® Atom D525 1.8 GHz dual core

Two PCI slots One PCIe x16 slot

One PCI slot One PCIe x4 slot One PCIe x16 slot

 Two RJ-45 RS-422/485 serial ports

 One VGA port

 One Line-out and one Mic-in audio jacks

 One CompactFlash® Type II socket

 AT/ATX power mode supported

 RoHS compliant

Page 3

1.4 Technical Specifications

The TANK-800 technical specifications are listed in Table 1-2.

Specifications System

TANK-800 Embedded System

CPU Chipset Memory

Ethernet Controller I/O and Indicators Ethernet RS-232 RS-422/RS-485 USB Interfaces VGA Audio Connector

Digital I/O

1.8 GHz Intel® Atom D525 dual core CPU

Intel® ICH8M

On-board 1.0 GB DDR3 memory

1 x 204-pin DDR3 SDRAM SO-DIMM slot (system max. 3.0 GB)

Dual Realtek RTL8111E PCIe GbE controllers with ASF 2.0 support

2 x RJ-45 GbE ports

4 x RS-232 serial ports (DB-9)

2 x RS-422/485 serial ports (RJ-45)

4 x USB 2.0 ports

1 x VGA port (2048x1536)

1 x Line-out port

1 x Mic-in port

1 x DIO port (8 bits)

LED Indicators

Storage SATA CompactFlash®

Page 4

AT power mode LED

ATX power mode LED

CPU temperature alert LED

HDD LED

Power 1 LED

Power 2 LED

Support one 2.5” SATA HDD

One CompactFlash® Type II socket

TANK-800 Embedded System

Specifications Power Power Supply

Power Consumption Power Button Power Mode Environmental and Mechanical Operating Temperature Storage Temperature Mounting Color Physical Dimensions Table 1-2: Technical Specifications

Redundant dual DC input 9V~36V

Power 1 (terminal block): 9 V (+/-0.3 V) ~ 36 V

Power 2 (DC jack): 10.5 V (+/-0.3 V) ~ 36 V

33 W (without add-on card)

One power button

AT or ATX power mode (selectable by AT/ATX mode switch)

-20°C~70°C

-30°C~80°C

Desktop, wall mount

Black C + Silver

136 mm x 219 mm x 188 mm (W x D x H)

Page 5

1.5 Connector Panel

All external peripheral interface connectors are located on the rear panel of the TANK-800.

TANK-800 Embedded System

The peripheral interface connectors are shown in

Figure 1-2.

Page 6

Figure 1-2: TANK-800 Peripheral Connectors

Connectors and buttons on the rear panel include the following.

 1 x 4-pin power DC jack for 10.5V (+/-0.3V) ~ 36V power input

 1 x Power terminal block for 9V (+/-0.3V) ~ 36V power input

 1 x Mic-in port (pink)

TANK-800 Embedded System

 1 x Line-out port (green)

 4 x RS-232 serial ports

 2 x RJ-45 RS-422/485 serial ports

 2 x Gigabit Ethernet ports

 4 x USB ports

 1 x Reset button  6 x LED indicators (Section

 1 x Power button

 1 x CompactFlash® Type II socket

 1 x VGA output

 1 x To earth

 3 x Expansion slots

 1 x DIO port

 1 x ACC mode switch

 1 x AT/ATX power mode switch

1.6 LED Indicators

There are several indicators on the rear panel of the TANK-800 as shown in Figure 1-3.

1.6)

Figure 1-3: TANK-800 LED Indicators

WARNING:

The CPU Temperature Alert LED turns red when the CPU temperature

is too high. If this situation occurs, lower the environment temperature

or close some running applications to cool down the CPU.

Page 7

1.7 Backplane Options

The backplane options of the TANK-800 are shown below.

Figure 1-4: TANK-800-D525/1GB/2P1E-R10 Backplane (HPE-3S6)

TANK-800 Embedded System

Page 8

Figure 1-5: TANK-800-D525/1GB/1P2E-R10 Backplane (HPE-3S7)

The supported signals of the backplane slots are listed below.

Backplane Slot Signal

HPE-3S6 (2P1E)

HPE-3S7 (1P2E)

Table 1-3: Supported Signals

PCI PCI

PCIe x16 PCIe x4

PCI PCI

PCIe x4 PCIe x1

PCIe x16 PCIe x2

TANK-800 Embedded System

The rated voltage and current of the backplanes are listed below.

Rated Voltage Rated Current

+5 V 7 A

+12 V 3.75 A

-12 V 0.1 A

+3.3 V 8 A

Table 1-4: Rated Voltage and Current

WARNING:

The system default power is 96 W. The maximum total power of the

backplane to support expansion cards is 45 W. The power of the

selected expansion cards can not exceed the max. power (45 W),

otherwise, the system may fail.

NOTE:

When using an expansion card with high power consumption, it is

recommended to install an external power supply to the 12V power

input connector on the backplane.

The maximum dimensions of the expansion card should be 190 mm in

length and 111 mm in width.

Page 9

1.8 Dimensions

The physical dimensions are shown below:

TANK-800 Embedded System

Page 10

Figure 1-6: Physical Dimensions (millimeters)

TANK-800 Embedded System

Chapter

2 Unpacking

Page 11

2.1 Anti-static Precautions

WARNING:

Failure to take ESD precautions during installation may result in

permanent damage to the TANK-800 and severe injury to the user.

Electrostatic discharge (ESD) can cause serious damage to electronic components,

including the TANK-800. Dry climates are especially susceptible to ESD. It is therefore

critical that whenever the TANK-800 or any other electrical component is handled, the

following anti-static precautions are strictly adhered to.

 Wear an anti-static wristband: Wearing a simple anti-static wristband can

help to prevent ESD from damaging the board.

TANK-800 Embedded System

 Self-grounding: Before handling the board touch any grounded conducting

material. During the time the board is handled, frequently touch any

conducting materials that are connected to the ground.

 Use an anti-static pad: When configuring the TANK-800, place it on an

anti-static pad. This reduces the possibility of ESD damaging the TANK-800.

2.2 Unpacking Precautions

When the TANK-800 is unpacked, please do the following:

 Follow the anti-static precautions outlined in Section

 Make sure the packing box is facing upwards so the TANK-800 does not fall

out of the box.

 Make sure all the components shown in Section

2.1.

2.3 are present.

Page 12

TANK-800 Embedded System

2.3 Unpacking Checklist

NOTE:

If some of the components listed in the checklist below are missing,

please do not proceed with the installation. Contact the IEI reseller or

vendor you purchased the TANK-800 from or contact an IEI sales

representative directly. To contact an IEI sales representative, please

send an email to

The TANK-800 is shipped with the following components:

Quantity Item and Part Number Image Standard

1 TANK-800 Series

1 Power adapter

(P/N: 63040-010090-020-RS)

sales@ieiworld.com.

1 Power cord

(P/N: 32702-000401-100-RS)

1 Power transfer cable

(P/N: 32000-089400-RS)

Page 13

Quantity Item and Part Number Image Standard

2 Mounting bracket

(P/N: 41020-0308C2-00-RS)

4 Mounting bracket screw

(P/N: 44033-040062-RS)

4 HDD screw

(P/N: 44043-030051-RS)

8 Rubber foot pad screw

TANK-800 Embedded System

(P/N: 44005-030061-RS)

4 Rubber foot pad

(P/N: 46007-001500-RS)

2 RJ-45 to DB-9 COM port cable

(P/N: 32005-000200-200-RS)

1 Pluggable DC-in terminal block

(P/N: 33502-000007-RS)

1 One Key Recovery CD

(P/N: 7B000-000724-RS)

Page 14

1 User manual and driver CD

(P/N: 7B000-000731-RS)

TANK-800 Embedded System

The following table lists the optional items that can be purchased separately.

Optional

System fan (P/N: 31100-000333-RS)

OS: Win CE 6.0 (128MB CF Card) (P/N: TANKCF-800-D525-CE060-128M-R10)

OS: Win XPE (2GB CF Card) (P/N: TANKCF-800-D525-XPE-2G-R10)

OS: Win XPE (4GB CF Card) (P/N: TANKCF-800-D525-XPE-4G-R10)

OS: Linux (2GB CF Card) (P/N: TANKCF-800-D525-LNX-2G-R10)

OS: Win 7 Embedded (4GB CF Card) (P/N: TANKCF-800-D525-WES7E-4G-R10)

Page 15

TANK-800 Embedded System

Chapter

3 Installation

Page 16

TANK-800 Embedded System

3.1 Installation Precautions

During installation, be aware of the precautions below:

 Read the user manual: The user manual provides a complete description of

the TANK-800, installation instructions and configuration options.

 DANGER! Disconnect Power: Power to the TANK-800 must be

disconnected during the installation process, or before any attempt is made to

access the rear panel. Electric shock and personal injury might occur if the

rear panel of the TANK-800 is opened while the power cord is still connected

to an electrical outlet.

 Qualified Personnel: The TANK-800 must be installed and operated only by

trained and qualified personnel. Maintenance, upgrades, or repairs may only

be carried out by qualified personnel who are familiar with the associated

dangers.

 Air Circulation: Make sure there is sufficient air circulation when installing the

TANK-800. The TANK-800’s cooling vents must not be obstructed by any

objects. Blocking the vents can cause overheating of the TANK-800. Leave at

least 5 cm of clearance around the TANK-800 to prevent overheating.

 Grounding: The TANK-800 should be properly grounded. The voltage feeds

must not be overloaded. Adjust the cabling and provide external overcharge

protection per the electrical values indicated on the label attached to the back

of the TANK-800.

3.2 CF Card Installation

To install the CF card, please follow the steps below:

Step 1: Locate the CF card slot, and then loosen the thumbscrew (

Figure 1-2).

Page 17

Figure 3-1: CF Card Slot

TANK-800 Embedded System

Step 2: Open the CF card slot cover (

Figure 3-2: CF Card Slot Cover

Figure 3-2).

Page 18

TANK-800 Embedded System

Step 3: Correctly align the CF card with the socket and insert the CF card into the socket

Figure 3-3).

(

Figure 3-3: CF Card Installation

Step 4: Reinstall the cover.

3.3 Hard Disk Drive (HDD) Installation

To install the hard drive, please follow the steps below:

Step 1: Loosen the thumbscrew, slide the cover inwards (

cover up gently.

Figure 3-4), and then lift the

Page 19

TANK-800 Embedded System

Figure 3-4: Unscrew the Cover

Step 2: Unplug the SATA signal and power cables connected to the TANK-800, and then

put the cover on a flat surface (

Figure 3-5).

Page 20

Figure 3-5: Remove the Cover from TANK-800

TANK-800 Embedded System

Step 3: Attach the HDD to the HDD bracket, and then slide the HDD to connect the HDD

to the SATA connector (

Figure 3-6: HDD Installation

Figure 3-6).

Step 4: Secure the HDD with the HDD bracket by four retention screws (

Figure 3-7: HDD Retention Screws

Figure 3-7).

Page 21

Step 5: Reconnect the SATA signal and power cables to the TANK-800.

Step 6: Reinstall the cover.

3.4 System Fan Installation

To install the optional system fan, please follow the steps below:

TANK-800 Embedded System

Step 1: Loosen the thumbscrew, slide the cover inwards (

cover up gently.

Step 2: Unplug the SATA signal and power cables connected to the TANK-800, and then

place the cover on a flat surface (

Step 3: Unscrew the four retention screws that secure the HDD bracket to the cover.

Figure 3-8). Remove the HDD bracket from the cover.

(

Figure 3-5).

Figure 3-4), and then lift the

Page 22

Figure 3-8: Remove the HDD Bracket from the Cover

Step 4: Unscrew the four retention screws that secure the fan bracket to the cover.

Figure 3-9). Remove the fan bracket from the cover.

(

TANK-800 Embedded System

Figure 3-9: Remove the Fan Bracket from the Cover

Step 5: Remove the temporary retaining bracket (

Figure 3-10: Remove the Temporary Retaining Bracket

Step 6: Attach the system fan to the fan bracket and secure it by four retention screws

Figure 3-11).

(

Figure 3-10).

Page 23

Figure 3-11: Secure the System Fan to the Fan Bracket

TANK-800 Embedded System

Step 7: Reinstall the fan bracket with the system fan installed (

Figure 3-12: Reinstall the Fan Bracket

Step 8: Reinstall the HDD bracket to the cover.

Step 9: Connect the system fan cable to the CPU_FAN1 connector on the motherboard

Figure 3-12).

Page 24

of TANK-800.

Step 10: Reconnect the SATA signal and power cables to the TANK-800.

Step 11: Reinstall the cover.

TANK-800 Embedded System

3.5 Pluggable DC-In Terminal Block Installation

To install the pluggable DC-in terminal block, please follow the steps below:

Step 1: Locate the DC-in terminal block connector. The location of the connector is

shown in

Step 2: Align the pluggable DC-in terminal block with the DC-in terminal block connector

on the TANK-800.

Step 3: Once aligned, insert the pluggable DC-in terminal block into the DC-in terminal

block connector.

Step 4: Secure the pluggable DC-in terminal block to the external interface by tightening

the two retention screws on either side of the terminal block (

Figure 1-2.

Figure 3-13).

Figure 3-13: Pluggable DC-in Terminal Block Installation

Page 25

TANK-800 Embedded System

3.6 Mounting the System with Mounting Brackets

To mount the embedded system onto a wall or some other surface using the two mounting

brackets, please follow the steps below.

Step 1: Turn the embedded system over or to the left side panel.

Step 2: Align the two retention screw holes in each bracket with the corresponding

retention screw holes on the bottom surface or the left side panel (

Bottom Surface

Left Side Panel

Figure 3-14).

Page 26

Figure 3-14: Mounting Bracket Retention Screws

TANK-800 Embedded System

Step 3: Secure the brackets to the system by inserting two retention screws into each

bracket (

Step 4: Drill holes in the intended installation surface.

Step 5: Align the mounting holes in the sides of the mounting brackets with the predrilled

holes in the mounting surface.

Step 6: Insert four retention screws, two in each bracket, to secure the system to the

wall.

Figure 3-14).

3.7 External Peripheral Interface Connectors

The TANK-800 has the following connectors. Detailed descriptions of the connectors can

be found in the subsections below.

 Audio

 CompactFlash® Type II

 DIO

 Ethernet

 Power button

 Power input

 Reset button

 RS-232

 RS-422/485

 USB

 VGA

Page 27

3.7.1 ACC Mode Selection

The TANK-800 allows turning the ACC mode on or off. The setting can be made through

the ACC mode switch on the external peripheral interface panel as shown below.

TANK-800 Embedded System

Figure 3-15: ACC Mode Switch

3.7.2 AT/ATX Power Mode Selection

The TANK-800 supports AT and ATX power modes. The setting can be made through the

AT/ATX power mode switch on the external peripheral interface panel as shown below.

Page 28

Figure 3-16: AT/ATX Power Mode Switch

TANK-800 Embedded System

3.7.3 Audio Connector

CN Label: CN Type: CN Location:

The audio jacks connect to external audio devices.

 Line Out port (Green): Connects to a headphone or a speaker. With

multi-channel configurations, this port can also connect to front speakers.

 Microphone (Pink): Connects a microphone.

Figure 3-17: Audio Connector

Line out and Mic

Audio jack See Figure 1-2

3.7.4 CompactFlash® Type II

The TANK-800 has one CF Type II socket. The location of the socket is shown in

Figure 1-2. To install the CF card, refer to Section 3.2.

3.7.5 Digital Input/Output Connector

CN Label: DIO x 8 CN Type: CN Location: CN Pinouts:

The digital I/O connector provides programmable input and output for external devices.

The pinouts for the digital I/O connector are listed in the table below.

DB-9 female connector

Figure 1-2

See

Table 3-1 and Figure 3-18

See

Page 29

Pin Description Pin Description

1 DIN0 6 DOUT2 2 DOUT0 7 DIN3 3 DIN1 8 DOUT3 4 DOUT1 9 VCC5 5 DIN2

TANK-800 Embedded System

Table 3-1: DIO Connector Pinouts

Figure 3-18: DIO Connector Pinout Location

3.7.6 LAN Connectors

CN Label: RJ45 CN Type: CN Location: CN Pinouts:

The LAN connectors allow connection to an external network.

RJ-45

Figure 1-2

See

Table 3-2

See

Page 30

Step 1: Locate the RJ-45 connectors. The locations of the RJ-45 connectors are

shown in

Figure 1-2.

Step 2: Align the connectors. Align the RJ-45 connector on the LAN cable with one of

the RJ-45 connectors on the TANK-800. See

Figure 3-19.

TANK-800 Embedded System

Figure 3-19: LAN Connection

Step 3: Insert the LAN cable RJ-45 connector. Once aligned, gently insert the LAN

cable RJ-45 connector into the on-board RJ-45 connector.

Pin Description Pin Description

1 TRD1P0 5 TRD1P2 2 TRD1N0 6 TRD1N2

3. TRD1P1 7 TRD1P3

4. TRD1N1 8 TRD1N3

Table 3-2: LAN Pinouts

Figure 3-20: RJ-45 Ethernet Connector

The RJ-45 Ethernet connector has two status LEDs, one green and one yellow. The green

LED indicates activity on the port and the yellow LED indicates the port is linked. See

Table 3-3.

Page 31

Activity/Link LED Speed LED

TANK-800 Embedded System

STATUS

Off No link Off 10 Mbps connection Yellow Linked Green 100 Mbps connection Blinking TX/RX activity Orange 1 Gbps connection

Table 3-3: RJ-45 Ethernet Connector LEDs

DESCRIPTION STATUS DESCRIPTION

3.7.7 Power Input, 3-pin Terminal Block

CN Label: POWER 1 CN Type: CN Location: CN Pinouts:

Connect the leads of a 9V~36V DC power supply into the terminal block. Make sure that

the power and ground wires are attached to the correct sockets of the connector.

3-pin terminal block

Figure 1-2

See

Figure 3-21

See

Figure 3-21: 3-pin Terminal Block Pinout Location

3.7.8 Power Input, 4-pin DIN Connector

CN Label: POWER 2

4-pin DIN connector

Figure 1-2

See

Table 3-4 and Figure 3-22

See

Page 32

CN Type: CN Location: CN Pinouts:

The power connector connects to the 10.5V~36V DC power adapter.

TANK-800 Embedded System

Figure 3-22: Power Input Connector

Pin Description Pin Description

1 +12V 3 +12V 2 GND 4 GND

Table 3-4: Power Input Pinouts

3.7.9 RJ-45 RS-422/485 Serial Ports

CN Label: RS422/485 CN Type: CN Location: CN Pinouts:

RS-422/485 serial port devices can be attached to the RJ-45 RS-422/485 serial ports on

the rear panel.

Step 1: Locate the RJ-45 RS-422/RS485 connectors. The locations of the RJ-45

RJ-45

Figure 1-2

See

Table 3-5 and Figure 3-24

See

RS-422/RS-485 connectors are shown in

Step 2: Insert the RJ-45 connector. Insert the RJ-45 connector on the RJ-45 to DB-9

COM port cable to one of the RJ-45 RS-422/485 connectors on the TANK-800.

Figure 3-23.

See

Figure 1-2.

Page 33

TANK-800 Embedded System

Figure 3-23: RJ-45 RS-422/485 Serial Device Connection

Step 3: Insert the serial connector. Insert the DB-9 connector of a serial device into

the DB-9 connector on the RJ-45 to DB-9 COM port cable.

Step 4: Secure the connector. Secure the serial device connector to the external

interface by tightening the two retention screws on either side of the connector.

Figure 3-24: RJ-45 RS-422/485 Serial Port Pinout Location

Pin Description (RS-422) Description (RS-485)

1 N/A N/A 2 ITXD422# ITXD485# 3 N/A N/A 4 ITXD422+ ITXD485# 5 GND GND 6 IRXD422# N/A 7 N/A N/A 8 IRXD422+ N/A

Page 34

Table 3-5: RJ-45 RS-422/485 Serial Port Pinouts

TANK-800 Embedded System

Figure 3-25: DB-9 Connector Pinout Location

Pin Description (RS-422) Description (RS-485)

1 IRXD422+ N/A 2 IRXD422# N/A 3 ITXD422+ ITXD485+ 4 ITXD422# ITXD485# 5 GND GND 6 N/A N/A 7 N/A N/A 8 N/A N/A 9 N/A N/A

Table 3-6: DB-9 Connector Pinouts

3.7.10 RS-232 Serial Port Connectors

CN Label:

COM1, COM2, COM3 and COM4 CN Type: CN Location: CN Pinouts:

DB-9 connectors

Figure 1-2

See

Table 3-7 and Figure 3-27

See

RS-232 serial port devices can be attached to the DB-9 ports on the rear panel.

Step 1: Locate the DB-9 connector. The locations of the DB-9 connectors are shown

Figure 1-2.

Step 2: Insert the serial connector. Insert the DB-9 connector of a serial device into

the DB-9 connector on the external peripheral interface. See

Figure 3-26.

Page 35

TANK-800 Embedded System

Figure 3-26: Serial Device Connector

Step 3: Secure the connector. Secure the serial device connector to the external

interface by tightening the two retention screws on either side of the connector.

Pin Description Pin Description

1 DCD 6 DSR 2 RX 7 RTS 3 TX 8 CTS 4 DTR 9 RI 5 GND

Table 3-7: Serial Port Pinouts

Page 36

Figure 3-27: Serial Port Pinout Location

TANK-800 Embedded System

3.7.11 USB Connectors

CN Label: USB CN Type: CN Location: CN Pinouts:

The USB ports are for connecting USB peripheral devices to the system.

Step 1: Locate the USB connectors. The locations of the USB connectors are shown

Figure 1-2.

Step 2: Align the connectors. Align the USB device connector with one of the

connectors. See

USB port

Figure 1-2

See

Table 3-8

See

Figure 3-28.

Figure 3-28: USB Device Connection

Step 3: Insert the device connector. Once aligned, gently insert the USB device

connector into the on-board connector.

Page 37

Pin Description Pin Description

1 VCC 5 VCC 2 DATA- 6 DATA3 DATA+ 7 DATA+ 4 GROUND 8 GROUND

Table 3-8: USB Port Pinouts

3.7.12 VGA Connector

CN Label: VGA

TANK-800 Embedded System

CN Type: CN Location: CN Pinouts:

15-pin Female

Figure 1-2

See

Figure 3-30 and Table 3-9

See

The VGA connector connects to a monitor that accepts VGA video input.

Step 1: Locate the female DB-15 connector. The location of the female DB-15

connector is shown in

Figure 1-2.

Step 2: Align the VGA connector. Align the male DB-15 connector on the VGA screen

cable with the female DB-15 connector on the external peripheral interface.

Step 3: Insert the VGA connector. Once the connectors are properly aligned with,

insert the male connector from the VGA screen into the female connector on the

TANK-800. See

Figure 3-29.

Page 38

TANK-800 Embedded System

Figure 3-29: VGA Connector

Step 4: Secure the connector. Secure the DB-15 VGA connector from the VGA

monitor to the external interface by tightening the two retention screws on either

side of the connector.

Figure 3-30: VGA Connector

Pin Description Pin Description

1 RED 2 GREEN 3 BLUE 4 NC 5 GND 6 GND 7 GND 8 GND 9 VCC / NC 10 GND 11 NC 12 DDC DAT 13 HSYNC 14 VSYNC 15 DDCCLK

Table 3-9: VGA Connector Pinouts

Page 39

3.8 Powering On/Off the System

WARNING:

Make sure a power supply with the correct input voltage is being fed into

the system. Incorrect voltages applied to the system may cause damage to

the internal electronic components and may also cause injury to the user.

 Power on the system: press the power button for 3 seconds  Power off the system: press the power button for 6 seconds

TANK-800 Embedded System

Figure 3-31: Power Button

3.9 Redundant Power

The TANK-800 is a system that supports redundant power. The redundant power input

increases the reliability of the system and prevents data loss and system corruption from

sudden power failure. The system can instantly and uninterruptedly switch to the second

power input when the main power is unavailable or in low voltage capacity.

There are two power connectors on the rear panel. Power 1 connector is a 3-pin terminal

block that supports ACC On signal. Power 2 connector is a DIN connector that can directly

connect to a power adapter. The supported power input voltages are:

Page 40

TANK-800 Embedded System

 Power 1 (terminal block): 9 V (+/-0.3 V) ~ 36 V  Power 2 (DC jack): 10.5 V (+/-0.3 V) ~ 36 V

Figure 3-32: Power Connectors

When the system is in ACC On mode, the main power input is from Power 1 connector;

when the system is in ACC Off mode, the main power input is from Power 2 connector. The ACC on/off mode is selected by the ACC mode switch on the rear panel (

The following sections describe how the redundant power works in ACC On mode and

ACC Off mode.

Figure 3-15).

3.9.1 ACC ON

NOTE:

In ACC On mode, the Power 1 connector must connect to ACC on

signal to be able to control the system power.

The ACC On mode is designed for vehicle applications. When the TANK-800 is in ACC

On mode, the main power input is Power 1 connector and the backup power is from Power

2 connector.

Page 41

3.9.1.1 Boot-up

When both power connectors are connected to power source with over 9 V power input, the two power LEDs on the front panel remain off until the ACC ON signal jump from low to high. The user can choose to use AT power mode or ATX power mode to control

the system. The following flow diagrams show the boot-up process and the LED status in

AT and ATX power modes.

Figure 3-33: ACC On: AT Mode

TANK-800 Embedded System

Figure 3-34: ACC On: ATX Mode

3.9.1.2 Switch to Backup Power

During the operation, the system power will switch from Power 1 to Power 2 automatically

when the following situations occur:

 Power 1 < 9V and Power 2 > 10.5V

 Power 1 > 9V, but the ACC ON signal jump from high to low

 Power 1 is unplugged and Power 2 > 10.5V

The following flow diagram shows how the power is switched between Power 1 and

Power 2 and their LED statuses.

Page 42

TANK-800 Embedded System

Figure 3-35: ACC On: Switch Between PWR1 and PWR2

3.9.1.3 Shutdown

The system will shutdown in the following situations:

 Power 1 < 9V and Power 2 < 10.5V

 Power 1 > 9V, Power 2 < 10.5V and ACC ON signal jump from high to low

 Press Power button for 6 seconds

The following flow diagram shows the system shutdown process and the LED statuses.

Figure 3-36: ACC On: Shutdown

NOTE:

To turn on the system in the ATX power mode, press the Power button

for three seconds. Press the Power button for six seconds to turn off

the system.

Page 43

3.9.2 ACC OFF

When the TANK-800 is in ACC Off mode, the main power input is Power 2 connector and

the backup power is from Power 1 connector.

3.9.2.1 Boot-up

When both power connectors are connected to power source with over 9 V power input,

the two power LEDs on the front panel turn on. The user can choose to use AT power

mode or ATX power mode to control the system. The following flow diagrams show the

boot-up process and the LED status in AT and ATX power modes.

TANK-800 Embedded System

Figure 3-37: ACC Off: AT Mode

Figure 3-38: ACC Off: ATX Mode

3.9.2.2 Switch to Backup Power

During the operation, the system power will switch from Power 2 to Power 1 automatically

when the following situations occur:

 Power 2 < 10.5V and Power 1 > 9V

 Power 2 is unplugged and Power 1 > 9V

Page 44

The following flow diagram shows how the power is switched between Power 2 and

Power 1 and their LED statuses.

TANK-800 Embedded System

Figure 3-39: ACC Off: Switch Between PWR1 and PWR2

3.9.2.3 Shutdown

The system will shutdown in the following situations:

 Power 2 < 10.5V and Power 1 < 9V

 Press Power buttons for 6 seconds

The following flow diagram shows the system shutdown process and the LED statuses.

Figure 3-40: ACC Off: Shutdown

NOTE:

The power LED turns off when the power cable is unplugged from the

system.

Page 45

TANK-800 Embedded System

Chapter

4 BIOS

Page 46

TANK-800 Embedded System

4.1 Introduction

The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to

certain system settings. This chapter outlines the options that can be changed.

4.1.1 Starting Setup

The UEFI BIOS is activated when the computer is turned on. The setup program can be

activated in one of two ways.

1. Press the DEL or F2 key as soon as the system is turned on or

2. Press the DEL or F2 key when the “Press DEL or F2 to enter SETUP”

message appears on the screen.

If the message disappears before the DEL or F2 key is pressed, restart the computer and

try again.

4.1.2 Using Setup

Use the arrow keys to highlight items, press ENTER to select, use the PageUp and PageDown keys to change entries, press F1 for help and press E

keys are shown in.

Key Function

Up arrow Move to previous item

Down arrow Move to next item

Left arrow Move to the item on the left hand side

Right arrow Move to the item on the right hand side

+ Increase the numeric value or make changes

- Decrease the numeric value or make changes

Page Up key Increase the numeric value or make changes

Page Dn key Decrease the numeric value or make changes

SC to quit. Navigation

Page 47

Key Function

Esc key Main Menu – Quit and not save changes into CMOS

F1 General help, only for Status Page Setup Menu and Option

F2 Previous values

F3 Load optimized defaults

F4 Save changes and Exit BIOS

Table 4-1: BIOS Navigation Keys

4.1.3 Getting Help

TANK-800 Embedded System

Status Page Setup Menu and Option Page Setup Menu --

Exit current page and return to Main Menu

Page Setup Menu

When F1 is pressed a small help window describing the appropriate keys to use and the possible selections for the highlighted item appears. To exit the Help Window press E the F1 key again.

4.1.4 Unable to Reboot After Configuration Changes

If the computer cannot boot after changes to the system configuration is made, CMOS

defaults. Use the jumper described in Chapter 3.

4.1.5 BIOS Menu Bar

The menu bar on top of the BIOS screen has the following main items:

 Main – Changes the basic system configuration.

 Advanced – Changes the advanced system settings.

 Chipset – Changes the chipset settings.

 Boot – Changes the system boot configuration.

 Security – Sets User and Supervisor Passwords.

SC or

Page 48

 Save & Exit – Selects exit options and loads default settings.

The following sections completely describe the configuration options found in the menu

items at the top of the BIOS screen and listed above.

TANK-800 Embedded System

4.2 Main

The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information.

Main Advanced Chipset Boot Security Save & Exit

BIOS Information BIOS Vendor American Megatrends Core Version 4.6.4.0 0.20 Compliency UEFI 2.0 Project Version SA37AR10.ROM Build Date and Time 08/09/2011 11:53:40

System Date [Tue 08/09/2011] System Time [15:10:27]

Access Level Administrator

Set the Date. Use Tab to switch between Data elements.

----------------------

ÅÆ

: Select Screen

↑ ↓: Select Item Enter Select + - Change Opt. F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save & Exit ESC Exit

BIOS Menu 1: Main

Î Sy stem Overview

The BIOS Information lists a brief summary of the BIOS. The fields in BIOS Information

cannot be changed. The items shown in the system overview include:

 BIOS Vendor: Installed BIOS vendor  Core Version: Current BIOS version  Project Version: the board version  Build Date and Time: Date and time the current BIOS version was made

The System Overview field also has two user configurable fields:

Î Sy stem Date [xx/xx/xx]

Use the System Date option to set the system date. Manually enter the day, month and

year.

Page 49

Î Sy stem Time [xx:xx:xx]

Use the System Time option to set the system time. Manually enter the hours, minutes

and seconds.

4.3 Advanced

Use the Advanced menu (BIOS Menu 2) to configure the CPU and peripheral devices

through the following sub-menus:

WARNING!

Setting the wrong values in the sections below may cause the system

to malfunction. Make sure that the settings made are compatible with

the hardware.

TANK-800 Embedded System

Main Advanced Chipset Boot Security Save & Exit

> ACPI Settings > CPU Configuration > IDE Configuration > USB Configuration > Super IO Configuration > H/M Monitor > Serial Port Console Redirection > iEi Feature

BIOS Menu 2: Advanced

System ACPI Parameters

----------------------

ÅÆ

↑ ↓: Select Item Enter Select + - Change Opt. F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save & Exit ESC Exit

: Select Screen

Page 50

TANK-800 Embedded System

4.3.1 ACPI Settings

The ACPI Settings menu (BIOS Menu 3) configures the Advanced Configuration and

Power Interface (ACPI) options.

Advanced

ACPI Sleep State [S1 (CPU Stop Clock)]

elect the highest ACPI sleep state the system will enter when the SUSPEND button is pressed.

----------------------

ÅÆ

: Select Screen

↑ ↓: Select Item Enter Select + - Change Opt. F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save & Exit ESC Exit

BIOS Menu 3: ACPI Configuration

Î ACPI Sleep State [S1 (CPU Stop Clock)]

Use the ACPI Sleep State option to specify the sleep state the system enters when it is

not being used.

Suspend Disabled

S1 (CPU Stop Clock)

S3 (Suspend to RAM)

DEFAULT

The system enters S1(POS) sleep state. The

system appears off. The CPU is stopped; RAM is

refreshed; the system is running in a low power

mode.

The caches are flushed and the CPU is powered

off. Power to the RAM is maintained. The

computer returns slower to a working state, but

more power is saved.

Page 51

TANK-800 Embedded System

4.3.2 CPU Configuration

Use the CPU Configuration menu (BIOS Menu 4) to view detailed CPU specifications

and configure the CPU.

Advanced

CPU Configuration

Processor Type Intel(R) Atom(TM) CPU D525 @ 1.80GHz EMT64 Supported Processor Speed 1800 MHz System Bus Speed 800 MHz Ratio Status 9 Actual Ratio 9 Processor Stepping 106CA Microcode Revision 263 L1 Cache RAM 2x56 K L2 Cache RAM 2x512 K Processor Core Dual Hyper-Threading Supported

Hyper-Threading [Enabled]

Enabled for Windows XP

nd Linux (OS optimized

for Hyper-Threading

echnology) and Disabled for other OS (OS not optimized for Hyper-Threading Technology).

----------------------

ÅÆ

: Select Screen

↑ ↓: Select Item Enter Select + - Change Opt. F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save & Exit ESC Exit

Page 52

BIOS Menu 4: CPU Configuration

The CPU Configuration menu (

 Processor Type: Lists the brand name of the CPU being used

 EMT64: Indicates if the EM64T is supported by the CPU.

 Processor Speed: Lists the CPU processing speed

 System Bus Speed: Lists the system bus

 Ratio Status: List the maximum FSB divisor

 Actual Ratio: Lists current FSB divisor

 Processor Stepping: Lists the CPU processing stepping

 Microcode Revision: Lists the microcode revision

 L1 Cache RAM: Lists the CPU L1 cache size

 L2 Cache RAM: Lists the CPU L2 cache size

 Processor Core: Lists the number of the processor core

BIOS Menu 4) lists the following CPU details:

TANK-800 Embedded System

 Hyper-Threading: Indicates if the Intel Hyper-Threading Technology is

supported by the CPU.

Î Hyper-Threading [Enabled]

Use the Hyper-Threading BIOS option to enable or disable the Intel Hyper-Threading

Technology.

Disabled

Enabled DEFAULT

Disables the Intel Hyper-Threading Technology.

Enables the Intel Hyper-Threading Technology.

4.3.3 IDE Configuration

Use the IDE Configuration menu (BIOS Menu 5) to change and/or set the configuration

of the SATA devices installed in the system.

Advanced

PATA Master Not Present PATA Slave Not Present

SATA Port0 Not Present SATA Port1 Not Present SATA Port2 Not Present SATA Port3 Not Present

ATA/IDE Configuration [Enhanced]

Configure SATA as [IDE]

Select ATA or IDE Configuration.

---------------------

ÅÆ

: Select Screen

↑ ↓: Select Item Enter Select + - Change Opt. F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save & Exit ESC Exit

BIOS Menu 5: IDE Configuration

Î ATA/IDE Configuration [Enhanced]

Use the ATA/IDE Configuration option to configure the ATA/IDE controller.

Disabled

Disables the on-board ATA/IDE controller.

Page 53

TANK-800 Embedded System

Compatible

Enhanced DEFAULT

Î Configure SATA as [IDE]

Use the Configure SATA as option to configure SATA devices as normal IDE devices.

IDE DEFAULT

AHCI

Configures SATA devices as normal IDE device.

Configures SATA devices as AHCI device.

Configures the on-board ATA/IDE controller to be in

compatible mode. In this mode, a SATA channel will

replace one of the IDE channels. This mode supports

up to 4 storage devices.

Configures the on-board ATA/IDE controller to be in

Enhanced mode. In this mode, IDE channels and SATA

channels are separated. This mode supports up to 6

storage devices. Some legacy OS do not support this

mode.

Page 54

TANK-800 Embedded System

4.3.4 USB Configuration

Use the USB Configuration menu (BIOS Menu 6) to read USB configuration information

and configure the USB settings.

Advanced

USB Configuration

USB Devices: 1 Keyboard

Legacy USB Support [Enabled]

Enables Legacy USB support. AUTO option

isables legacy support if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications.

---------------------

ÅÆ

: Select Screen

↑ ↓: Select Item Enter Select + - Change Opt. F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save & Exit ESC Exit

BIOS Menu 6: USB Configuration

Î USB Devices

The USB Devices field lists the USB devices that are enabled on the system

Î Legacy USB Support [En abled]

Use the Legacy USB Support BIOS option to enable USB mouse and USB keyboard

support. Normally if this option is not enabled, any attached USB mouse or USB keyboard

does not become available until a USB compatible operating system is fully booted with all

USB drivers loaded. When this option is enabled, any attached USB mouse or USB

keyboard can control the system even when there is no USB driver loaded onto the

system.

Enabled DEFAULT

Legacy USB support enabled

Page 55

TANK-800 Embedded System

Disabled

Auto

Legacy USB support disabled

Legacy USB support disabled if no USB devices are

connected

4.3.5 Super IO Configuration

Use the Super IO Configuration menu (BIOS Menu 7) to set or change the

configurations for the serial ports.

Advanced

Super IO Configuration

> Serial Port 1 Configuration > Serial Port 2 Configuration > Serial Port 3 Configuration > Serial Port 4 Configuration > Serial Port 5 Configuration > Serial Port 6 Configuration

et Parameters of Serial Port 1 (COMA)

---------------------

ÅÆ

: Select Screen

↑ ↓: Select Item Enter Select + - Change Opt. F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save & Exit ESC Exit

Page 56

BIOS Menu 7: Super IO Configuration

TANK-800 Embedded System

4.3.5.1 Serial Port n Configuration

Use the Serial Port n Configuration menu (BIOS Menu 8) to configure the serial port n.

Advanced

Serial Port n Configuration

Serial Port [Enabled]

Device Settings IO=3F8h; IRQ=4

Change Settings [Auto]

nable or Disable Serial Port (COM)

---------------------

ÅÆ

: Select Screen

↑ ↓: Select Item Enter Select + - Change Opt. F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save & Exit ESC Exit

BIOS Menu 8: Serial Port n Configuration Menu

4.3.5.1.1 Serial Port 1 Configuration

Î Serial Port [Enabled]

Use the Serial Port option to enable or disable the serial port.

Disabled

Enabled DEFAULT

Î Change Settings [Auto]

Use the Change Settings option to change the serial port IO port address and interrupt

address.

Auto DEFAULT

Disable the serial port

Enable the serial port

The serial port IO port address and interrupt address

are automatically detected.

IO=3F8h; IRQ=4

Serial Port I/O port address is 3F8h and the interrupt

address is IRQ4

Page 57

TANK-800 Embedded System

IO=3F8h; IRQ=3, 4

IO=2F8h; IRQ=3, 4

IO=2C0h; IRQ=3, 4

IO=2C8h; IRQ=3, 4

4.3.5.1.2 Serial Port 2 Configuration

Î Serial Port [Enabled]

Use the Serial Port option to enable or disable the serial port.

Disabled

Serial Port I/O port address is 3F8h and the interrupt

address is IRQ3, 4

Serial Port I/O port address is 2F8h and the interrupt

address is IRQ3, 4

Serial Port I/O port address is 2C0h and the interrupt

address is IRQ3, 4

Serial Port I/O port address is 2C8h and the interrupt

address is IRQ3, 4

Disable the serial port

Enabled DEFAULT

Î Change Settings [Auto]

Use the Change Settings option to change the serial port IO port address and interrupt

address.

Auto DEFAULT

IO=2F8h; IRQ=3

IO=3F8h; IRQ=3, 4

IO=2F8h; IRQ=3, 4

IO=2C0h;

Enable the serial port

The serial port IO port address and interrupt address

are automatically detected.

Serial Port I/O port address is 2F8h and the interrupt

address is IRQ3

Serial Port I/O port address is 3F8h and the interrupt

address is IRQ3, 4

Serial Port I/O port address is 2F8h and the interrupt

address is IRQ3, 4

Serial Port I/O port address is 2C0h and the interrupt

Page 58

IRQ=3, 4

address is IRQ3, 4

TANK-800 Embedded System

IO=2C8h; IRQ=3, 4

4.3.5.1.3 Serial Port 3 Configuration

Î Serial Port [Enabled]

Use the Serial Port option to enable or disable the serial port.

Disabled

Enabled DEFAULT

Î Change Settings [Auto]

Use the Change Settings option to change the serial port IO port address and interrupt

address.

Auto DEFAULT

Serial Port I/O port address is 2C8h and the interrupt

address is IRQ3, 4

Disable the serial port

Enable the serial port

The serial port IO port address and interrupt address

are automatically detected.

IO=3E8h; IRQ=10

IO=3E8h; IRQ=10, 11

IO=2E8h; IRQ=10, 11

IO=2D0h; IRQ=10, 11

IO=2D8h; IRQ=10, 11

Serial Port I/O port address is 3E8h and the interrupt

address is IRQ10

Serial Port I/O port address is 3E8h and the interrupt

address is IRQ10, 11

Serial Port I/O port address is 2E8h and the interrupt

address is IRQ10, 11

Serial Port I/O port address is 2D0h and the interrupt

address is IRQ10, 11

Serial Port I/O port address is 2D8h and the interrupt

address is IRQ10, 11

Page 59

4.3.5.1.4 Serial Port 4 Configuration

Î Serial Port [Enabled]

Use the Serial Port option to enable or disable the serial port.

TANK-800 Embedded System

Disabled

Enabled DEFAULT

Î Change Settings [Auto]

Use the Change Settings option to change the serial port IO port address and interrupt

address.

Auto DEFAULT

IO=2E8h; IRQ=10

IO=3E8h; IRQ=10, 11

IO=2E8h; IRQ=10, 11

Disable the serial port

Enable the serial port

The serial port IO port address and interrupt address

are automatically detected.

Serial Port I/O port address is 2E8h and the interrupt

address is IRQ10

Serial Port I/O port address is 3E8h and the interrupt

address is IRQ10, 11

Serial Port I/O port address is 2E8h and the interrupt

address is IRQ10, 11

IO=2D0h; IRQ=10, 11

IO=2D8h; IRQ=10, 11

Î Device Mode [RS42 2/485]

Use the Device Mode option to enable or disable the serial port.

Normal

RS422/485 DEFAULT

Page 60

Serial Port I/O port address is 2D0h and the interrupt

address is IRQ10, 11

Serial Port I/O port address is 2D8h and the interrupt

address is IRQ10, 11

Sets the serial port mode to normal.

Enables serial port RS-422/485 support.

TANK-800 Embedded System

4.3.5.1.5 Serial Port 5 Configuration

Î Serial Port [Enabled]

Use the Serial Port option to enable or disable the serial port.

Disabled

Enabled DEFAULT

Î Change Settings [Auto]

Use the Change Settings option to change the serial port IO port address and interrupt

address.

Auto DEFAULT

IO=2C0h; IRQ=10

IO=2C0h; IRQ=10, 11

IO=2C8h; IRQ=10, 11

Disable the serial port

Enable the serial port

The serial port IO port address and interrupt address

are automatically detected.

Serial Port I/O port address is 2C0h and the interrupt

address is IRQ10

Serial Port I/O port address is 2C0h and the interrupt

address is IRQ10, 11

Serial Port I/O port address is 2C8h and the interrupt

address is IRQ10, 11

IO=2D0h; IRQ=10, 11

IO=2D8h; IRQ=10, 11

IO=2E0h; IRQ=10, 11

4.3.5.1.6 Serial Port 6 Configuration

Î Serial Port [Enabled]

Use the Serial Port option to enable or disable the serial port.

Serial Port I/O port address is 2D0h and the interrupt

address is IRQ10, 11

Serial Port I/O port address is 2D8h and the interrupt

address is IRQ10, 11

Serial Port I/O port address is 2E0h and the interrupt

address is IRQ10, 11

Page 61

TANK-800 Embedded System

Disabled

Enabled DEFAULT

Î Change Settings [Auto]

Use the Change Settings option to change the serial port IO port address and interrupt

address.

Auto DEFAULT

IO=2E0h; IRQ=10

IO=2C0h; IRQ=10, 11

IO=2C8h; IRQ=10, 11

Disable the serial port

Enable the serial port

The serial port IO port address and interrupt address

are automatically detected.

Serial Port I/O port address is 2E0h and the interrupt

address is IRQ10

Serial Port I/O port address is 2C0h and the interrupt

address is IRQ10, 11

Serial Port I/O port address is 2C8h and the interrupt

address is IRQ10, 11

IO=2D0h; IRQ=10, 11

IO=2D8h; IRQ=10, 11

IO=2E0h; IRQ=10, 11

Serial Port I/O port address is 2D0h and the interrupt

address is IRQ10, 11

Serial Port I/O port address is 2D8h and the interrupt

address is IRQ10, 11

Serial Port I/O port address is 2E0h and the interrupt

address is IRQ10, 11

Page 62

TANK-800 Embedded System

4.3.6 H/W Monitor

The H/W Monitor menu (BIOS Menu 9) shows the operating temperature, fan speeds

and system voltages.

Advanced

PC Health Status

CPU Temperature :+45 C Accuracy: 1. (-5~+10) degree around 100 degree.

2. (-10~+15) degree around 50 degree. SYS Temperature :+40 C CPU FAN Speed :N/A VCC3V :+3.312 V V_Core :+1.152 V V1.05S :+1.005 V Vcc3S :+3.312 V Vcc5V :+5.312 V VSB3V :+3.328 V VBAT :+3.216 V

---------------------

ÅÆ

: Select Screen

↑ ↓: Select Item Enter Select + - Change Opt. F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save & Exit ESC Exit

BIOS Menu 9: H/W Monitor

Î PC Health Status

The following system parameters and values are shown. The system parameters that are

monitored are:

 System Temperatures:

o CPU Temperature o System Temperature

 Fan Speeds:

o CPU Fan Speed

 Voltages:

o VCC3V o Vcore o Vcc o V1.05S

Page 63

TANK-800 Embedded System

o Vcc3S o Vcc5V o VSB3V o VBAT

4.3.7 Serial Port Console Redirection

The Serial Port Console Redirection menu (BIOS Menu 10) allows the console

redirection options to be configured. Console redirection allows users to maintain a

system remotely by re-directing keyboard input and text output through the serial port.

Advanced

COM1

Console Redirection [Disabled]

> Console Redirection Settings

COM2

Console Redirection [Disabled]

> Console Redirection Settings

COM3

Console Redirection [Disabled]

> Console Redirection Settings

COM4

Console Redirection [Disabled]

> Console Redirection Settings

COM5

Console Redirection [Disabled]

> Console Redirection Settings

COM6

Console Redirection [Disabled]

> Console Redirection Settings

Console Redirection Enable or Disable

---------------------

ÅÆ

: Select Screen

↑ ↓: Select Item Enter Select +/-: Change Opt. F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save & Exit ESC Exit

BIOS Menu 10: Serial Port Console Redirection

Î Console Redirection [Dis abled]

Use Console Redirection option to enable or disable the console redirection function.

Disabled DEFAULT

Page 64

Disabled the console redirection function

TANK-800 Embedded System

Enabled

Î Terminal Type [VT-100+]

Use the Terminal Type option to specify the remote terminal type.

VT100

VT100+

VT-UTF8

ANSI DEFAULT

Î Bits per second [115200]

Use the Bits per second option to specify the serial port transmission speed. The speed

must match the other side. Long or noisy lines may require lower speeds.

9600

Enabled the console redirection function

The target terminal type is VT100

The target terminal type is VT100+

The target terminal type is VT-UTF8

The target terminal type is ANSI

Sets the serial port transmission speed at 9600.

19200

38400

57600

115200 DEFAULT

Sets the serial port transmission speed at 19200.

Sets the serial port transmission speed at 38400.

Sets the serial port transmission speed at 57600.

Sets the serial port transmission speed at 115200.

Page 65

TANK-800 Embedded System

4.3.8 iEi Feature

Use the iEi Feature menu (BIOS Menu 11) to configure the iEi features.

Advanced

iEi Feature

Auto Recovery Function [Disabled]

Auto Recovery Function Reboot and recover system automatically within 10 min, when OS crashes. Please install Auto Recovery API

ervice before enabling this function.

---------------------

ÅÆ

: Select Screen

↑ ↓: Select Item Enter Select + - Change Opt. F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save & Exit ESC Exit

BIOS Menu 11: iEi Feature

Î Auto Recovery Function [Disabled]

Use Auto Recovery Function option to enable or disable the auto recovery function.

Disabled DEFAULT

Enabled

Disabled the auto recovery function

Enabled the auto recovery function

Page 66

TANK-800 Embedded System

4.4 Chipset

Use the Chipset menu (BIOS Menu 12) to access the Northbridge and Southbridge

configuration menus.

WARNING!

Setting the wrong values for the Chipset BIOS selections in the Chipset

BIOS menu may cause the system to malfunction.

Main Advanced Chipset Boot Security Save & Exit

> Host Bridge > South Bridge > Intel IGD SWSCI OpRegion

North Bridge Parameters

---------------------

ÅÆ

↑ ↓: Select Item Enter Select + - Change Opt. F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save & Exit ESC Exit

: Select Screen

BIOS Menu 12: Chipset

Page 67

TANK-800 Embedded System

4.4.1 Host Bridge Configuration

Tthe Host Bridge Configuration menu (BIOS Menu 13) shows the memory frequency

and memory capacity.

Chipset

******* Memory Information ******* Memory Frequency 800 Mhz

Total Memory 1024 MB

DIMM#0 1024 MB

---------------------

ÅÆ

: Select Screen

↑ ↓: Select Item Enter Select + - Change Opt. F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save & Exit ESC Exit

BIOS Menu 13: Host Bridge Chipset Configuration

4.4.2 South Bridge Configuration

Use the South Bridge Configuration menu (BIOS Menu 14) to configure the

Southbridge chipset.

Chipset

Auto Power Button Function [Disabled]

Restore AC Power Loss [Last State] HD Audio Controller [Enabled] USB Function [Enabled] USB 2.0(EHCI) Support [Enabled] Set Spread Spectrum function [Disabled]

Restore AC Power Loss help

---------------------

ÅÆ

: Select Screen

↑ ↓: Select Item Enter Select + - Change Opt. F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save & Exit ESC Exit

Page 68

BIOS Menu 14: South Bridge Chipset Configuration

TANK-800 Embedded System

Î Restore AC Power Loss [Last State]

Use the Restore AC Power Loss BIOS option to specify what state the system returns to

if there is a sudden loss of power to the system.

Power Off

Power On

Last State DEFAULT

Î HD Audio Controller [Enabled]

Use the HD Audio Controller option to enable or disable the High Definition Audio

controller.

Enabled DEFAULT

Disabled

Î USB Function [Enabled ]

Use the USB Function BIOS option to enable or disable USB function support.

The system remains turned off

The system turns on

The system returns to its previous state. If it was on, it

turns itself on. If it was off, it remains off.

The onboard High Definition Audio controller

automatically detected and enabled

The onboard High Definition Audio controller is disabled

Disabled

Enabled DEFAULT

Î USB 2.0 (EHCI) Support [Enabled]

Use the USB 2.0 (EHCI) Support BIOS option to enable or disable USB 2.0 support.

Enabled DEFAULT

Disabled

Î Set Spread Spectrum Function [Disabled]

The Set Spread Spectrum Function option can help to improve CPU EMI issues.

USB function support disabled

USB function support enabled

USB 2.0 (EHCI) support enabled

USB 2.0 (EHCI) support disabled

Page 69

TANK-800 Embedded System

Disabled DEFAULT

Enabled

The spread spectrum mode is disabled

The spread spectrum mode is enabled

4.4.3 Intel IGD SWSCI OpRegion

Use the Intel IGD SWSCI OpRegion menu (BIOS Menu 15) to configure the video device

connected to the system.

Chipset

Intel IGD SWSCI OpRegion Configuration

DVMT Mode Select [DVMT Mode] DVMT/Fixed Memory [Maximum]

Select DVMT Mode/Fixed Mode

---------------------

ÅÆ

: Select Screen

↑ ↓: Select Item Enter Select + - Change Opt. F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save & Exit ESC Exit

BIOS Menu 15: Intel IGD SWSCI OpRegion Configuration

Î DVMT Mode Select [DVMT Mode]

Use the DVMT Mode Select option to select the Intel Dynamic Video Memory Technology

(DVMT) operating mode.

Fixed Mode

DVMT Mode DEFAULT

Î DVMT/FIXED Memory [Maximum]

Use the DVMT/FIXED Memory option to specify the maximum amount of memory that

can be allocated as graphics memory. Configuration options are listed below.

A fixed portion of graphics memory is reserved as

graphics memory.

Graphics memory is dynamically allocated according

to the system and graphics needs.

Page 70

TANK-800 Embedded System

 128 MB

 256 MB  Maximum Default

4.5 Boot

Use the Boot menu (BIOS Menu 16) to configure system boot options.

Main Advanced Chipset Boot Security Save & Exit

Boot Configuration Bootup NumLock State [On]

Quiet Boot [Enabled] Launch PXE OpROM [Disabled]

Boot Option Priorities

Select the keyboard NumLock state

---------------------

ÅÆ

↑ ↓: Select Item Enter Select + - Change Opt. F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save & Exit ESC Exit

: Select Screen

BIOS Menu 16: Boot

Î Bootup NumLock State [On]

Use the Bootup NumLock State BIOS option to specify if the number lock setting must

be modified during boot up.

On DEFAULT

Allows the Number Lock on the keyboard to be

enabled automatically when the computer system

boots up. This allows the immediate use of the

10-key numeric keypad located on the right side of

the keyboard. To confirm this, the Number Lock LED

light on the keyboard is lit.

Page 71

TANK-800 Embedded System

Off

Î Quiet Boot [Enabled]

Use the Quiet Boot BIOS option to select the screen display when the system boots.

Disabled

Enabled DEFAULT

Î Launch PXE OpROM [Disabled]

Use the Launch PXE OpROM option to enable or disable boot option for legacy network

Does not enable the keyboard Number Lock

automatically. To use the 10-keys on the keyboard,

press the Number Lock key located on the upper

left-hand corner of the 10-key pad. The Number

Lock LED on the keyboard lights up when the

Number Lock is engaged.

Normal POST messages displayed

OEM Logo displayed instead of POST messages

devices.

Disabled DEFAULT

Enabled

4.6 Security

Use the Security menu (BIOS Menu 17) to set system and user passwords.

Ignore all PXE Option ROMs

Load PXE Option ROMs.

Page 72

TANK-800 Embedded System

Main Advanced Chipset Boot Security Save & Exit

Password Description

If ONLY the Administrator’s password is set, then this only limits access to Setup and is only asked for when entering Setup. If ONLY the User’s password is set, then this is a power on password and must be entered to boot or enter Setup. In Setup the User will have Administrator rights. The password must be 3 to 20 characters long.

Administrator Password

User Password

BIOS Menu 17: Security

Î Administrator Password

Password

---------------------

ÅÆ

↑ ↓: Select Item Enter Select + - Change Opt. F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save & Exit ESC Exit

et Setup Administrator

: Select Screen

Use the Administrator Password to set or change an administrator password.

Î User Password

Use the User Password to set or change a user password.

Page 73

TANK-800 Embedded System

4.7 Exit

Use the Exit menu (BIOS Menu 18) to load default BIOS values, optimal failsafe values

and to save configuration changes.

Main Advanced Chipset Boot Security Save & Exit

Save Changes and Reset

Discard Changes and Reset

Restore Defaults Save as User Defaults Restore User Defaults

Exit the system after saving the changes.

---------------------

ÅÆ

↑ ↓: Select Item Enter Select + - Change Opt. F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save & Exit ESC Exit

: Select Screen

BIOS Menu 18:Exit

Î Save Changes and Rese t

Use the Save Changes and Reset option to save the changes made to the BIOS options

and to exit the BIOS configuration setup program.

Î Discard Cha nges and Reset

Use the Discard Changes and Reset option to exit the system without saving the

changes made to the BIOS configuration setup program.

Î Restore De f aults

Use the Restore Defaults option to load the optimal default values for each of the parameters on the Setup menus. F3 key can be used for this operation.

Page 74

TANK-800 Embedded System

Î Save as User Defaults

Use the Save as User Defaults option to save the changes done so far as user defaults.

Î Restore User Defaults

Use the Restore User Defaults option to restore the user defaults to all the setup options.

Page 75

TANK-800 Embedded System

Appendix

A Regulatory Compliance

Page 76

TANK-800 Embedded System

DECLARATION OF CONFORMITY

This equipment is in conformity with the following EU directives:

 EMC Directive 2004/108/EC

 Low-Voltage Directive 2006/95/EC

 RoHS II Directive 2011/65/EU

 Ecodesign Directive 2009/125/EC

If the user modifies and/or install other devices in the equipment, the CE conformity

declaration may no longer apply.

If this equipment has telecommunications functionality, it also complies with the

requirements of the R&TTE Directive 1999/5/EC.

English

IEI Integration Corp declares that this equipment is in compliance with the essential

requirements and other relevant provisions of Directive 1999/5/EC.

Български [Bulgarian]

IEI Integration Corp. декларира, че този оборудване е в съответствие със

съществените изисквания и другите приложими правила на Директива 1999/5/ЕС.

Česky [Czech]

IEI Integration Corp tímto prohlašuje, že tento zařízení je ve shodě se základními

požadavky a dalšími příslušnými ustanoveními směrnice 1999/5/ES.

Dansk [Danish]

IEI Integration Corp erklærer herved, at følgende udstyr overholder de væsentlige krav og

øvrige relevante krav i direktiv 1999/5/EF.

Deutsch [German]

IEI Integration Corp, erklärt dieses Gerät entspricht den grundlegenden Anforderungen

und den weiteren entsprechenden Vorgaben der Richtlinie 1999/5/EU.

Eesti [Estonian]

IEI Integration Corp deklareerib seadme seadme vastavust direktiivi 1999/5/EÜ

põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele.

Page 77

Español [Spanish]

IEI Integration Corp declara que el equipo cumple con los requisitos esenciales y

cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE.

Ελληνική [Greek]

IEI Integration Corp ΔΗΛΩΝΕΙ ΟΤΙ ΕΞΟΠΛΙΣΜΟΣ ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ

ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ

1999/5/ΕΚ.

Français [French]

IEI Integration Corp déclare que l'appareil est conforme aux exigences essentielles et aux

autres dispositions pertinentes de la directive 1999/5/CE.

Italiano [Italian]

IEI Integration Corp dichiara che questo apparecchio è conforme ai requisiti essenziali ed

alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE.

Latviski [Latvian]

TANK-800 Embedded System

IEI Integration Corp deklarē, ka iekārta atbilst būtiskajām prasībām un citiem ar to

saistītajiem noteikumiem Direktīvas 1999/5/EK.

Lietuvių [Lithuanian]

IEI Integration Corp deklaruoja, kad šis įranga atitinka esminius reikalavimus ir kitas

1999/5/EB Direktyvos nuostatas.

Nederlands [Dutch]

IEI Integration Corp dat het toestel toestel in overeenstemming is met de essentiële eisen

en de andere relevante bepalingen van richtlijn 1999/5/EG.

Malti [Maltese]

IEI Integration Corp jiddikjara li dan prodott jikkonforma mal-ħtiġijiet essenzjali u ma

provvedimenti oħrajn relevanti li hemm fid-Dirrettiva 1999/5/EC.

Magyar [Hungarian]

IEI Integration Corp nyilatkozom, hogy a berendezés megfelel a vonatkozó alapvetõ

követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak.

Polski [Polish]

IEI Integration Corp oświadcza, że wyrobu jest zgodny z zasadniczymi wymogami oraz

Page 78

pozostałymi stosownymi postanowieniami Dyrektywy 1999/5/EC.

Português [Portuguese]

IEI Integration Corp declara que este equipamento está conforme com os requisitos

essenciais e outras disposições da Directiva 1999/5/CE.

TANK-800 Embedded System

Româna [Romanian]

IEI Integration Corp declară că acest echipament este in conformitate cu cerinţele

esenţiale şi cu celelalte prevederi relevante ale Directivei 1999/5/CE.

Slovensko [Slovenian]

IEI Integration Corp izjavlja, da je ta opreme v skladu z bistvenimi zahtevami in ostalimi

relevantnimi določili direktive 1999/5/ES.

Slovensky [Slovak]

IEI Integration Corp týmto vyhlasuje, že zariadenia spĺňa základné požiadavky a všetky

príslušné ustanovenia Smernice 1999/5/ES.

Suomi [Finnish]

IEI Integration Corp vakuuttaa täten että laitteet on direktiivin 1999/5/EY oleellisten

vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen.

Svenska [Swedish]

IEI Integration Corp förklarar att denna utrustningstyp står I överensstämmelse med de

väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv

1999/5/EG.

Page 79

TANK-800 Embedded System

FCC WARNING

This equipment complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions:

 This device may not cause harmful interference, and

 This device must accept any interference received, including interference

This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with the instruction

manual, may cause harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful interference in which case the

user will be required to correct the interference at his own expense.

that may cause undesired operation.

Federal Communication Commission Interference Statement

This equipment has been assembled with components that comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not occur

in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one of the following measures:

 Reorient or relocate the receiving antenna.

 Increase the separation between the equipment and receiver.

 Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

 Consult the dealer or an experienced radio/TV technician for help.

Page 80

TANK-800 Embedded System

B Safety Precautions

Appendix

Page 81

B.1 Safety Precautions

WARNING:

The precautions outlined in this appendix should be strictly followed.

Failure to follow these precautions may result in permanent damage to

the TANK-800.

Please follow the safety precautions outlined in the sections that follow:

B.1.1 General Safety Precautions

Please ensure the following safety precautions are adhered to at all times.

TANK-800 Embedded System

 Make sure the power is turned off and the power cord is disco nnected

when moving, installing or modifying the system.

 Do not apply voltage levels that exceed the specified voltage range.

Doing so may cause fire and/or an electrical shock.

 Electric shocks can occur if opened while still powered on.  Do not drop or insert any objects into the ventilation openings.  If considerable amounts of dust, water, or fluids enter the system, turn

off the power supply immediately, unplug the power cord, and contact the

system vendor.

 DO NOT:

o Drop the system against a hard surface. o Strike or exert excessive force onto the LCD panel. o Touch any of the LCD panels with a sharp object o In a site where the ambient temperature exceeds the rated temperature

Page 82

TANK-800 Embedded System

B.1.2 Anti-static Precautions

WARNING:

Failure to take ESD precautions during the installation of the TANK-800

may result in permanent damage to the TANK-800 and severe injury to

the user.

Electrostatic discharge (ESD) can cause serious damage to electronic components,

including the TANK-800. Dry climates are especially susceptible to ESD. It is therefore

critical that whenever the TANK-800 is opened and any of the electrical components are

handled, the following anti-static precautions are strictly adhered to.

 Wear an anti-static wristband: Wearing a simple anti-static wristband can

help to prevent ESD from damaging any electrical component.

 Self-grounding: Before handling any electrical component, touch any

grounded conducting material. During the time the electrical component is

handled, frequently touch any conducting materials that are connected to the

ground.

 Use an anti-static pad: When configuring or working with an electrical

component, place it on an anti-static pad. This reduces the possibility of ESD

damage.

 Only handle the edges of the electrical component: When handling the

electrical component, hold the electrical component by its edges.

Page 83

B.1.3 Product Disposal

CAUTION:

Risk of explosion if battery is replaced by an incorrect type. Only

certified engineers should replace the on-board battery.

Dispose of used batteries according to instructions and local

regulations.

 Outside the European Union - If you wish to dispose of used electrical and

electronic products outside the European Union, please contact your local

authority so as to comply with the correct disposal method.

TANK-800 Embedded System

 Within the European Union:

EU-wide legislation, as implemented in each Member State, requires that

waste electrical and electronic products carrying the mark (left) must be

disposed of separately from normal household waste. This includes

monitors and electrical accessories, such as signal cables or power cords.

When you need to dispose of your display products, please follow the

guidance of your local authority, or ask the shop where you purchased the product. The

mark on electrical and electronic products only applies to the current European Union

Member States.

Please follow the national guidelines for electrical and electronic product disposal.

B.2 Maintenance and Cleaning Precautions

When maintaining or cleaning the TANK-800, please follow the guidelines below.

B.2.1 Maintenance and Cleaning

Page 84

Prior to cleaning any part or component of the TANK-800, please read the details below.

 The interior of the TANK-800 does not require cleaning. Keep fluids away

from the TANK-800 interior.

TANK-800 Embedded System

 Be cautious of all small removable components when vacuuming the

TANK-800.

 Turn the TANK-800 off before cleaning the TANK-800.

 Never drop any objects or liquids through the openings of the TANK-800.

 Be cautious of any possible allergic reactions to solvents or chemicals used

when cleaning the TANK-800.

 Avoid eating, drinking and smoking within vicinity of the TANK-800.

B.2.2 Cleaning Tools

Some components in the TANK-800 may only be cleaned using a product specifically

designed for the purpose. In such case, the product will be explicitly mentioned in the cleaning tips. Below is a list of items to use when cleaning the TANK-800.

 Cloth – Although paper towels or tissues can be used, a soft, clean piece of

cloth is recommended when cleaning the TANK-800.

 Water or rubbing alcohol – A cloth moistened with water or rubbing alcohol

can be used to clean the TANK-800.

 Using solvents – The use of solvents is not recommended when cleaning the

TANK-800 as they may damage the plastic parts.

 Vacuum cleaner – Using a vacuum specifically designed for computers is

one of the best methods of cleaning the TANK-800. Dust and dirt can restrict

the airflow in the TANK-800 and cause its circuitry to corrode.

 Cotton swabs - Cotton swaps moistened with rubbing alcohol or water are

excellent tools for wiping hard to reach areas.

 Foam swabs - Whenever possible, it is best to use lint free swabs such as

foam swabs for cleaning.

Page 85

TANK-800 Embedded System

Appendix

C Digital I/O Interface

Page 86

TANK-800 Embedded System

C.1 Introduction

The DIO connector on the TANK-800 is interfaced to GPIO ports on the Super I/O chipset.

The DIO has both 4-bit digital inputs and 4-bit digital outputs. The digital inputs and digital

outputs are generally control signals that control the on/off circuit of external devices or

TTL devices. Data can be read or written to the selected address to enable the DIO

functions.

NOTE:

For further information, please refer to the datasheet for the Super I/O

chipset.

The BIOS interrupt call INT 15H controls the digital I/O.

INT 15H:

AH – 6FH

Sub-function:

AL – 8 :Set the digital port as INPUT AL :Digital I/O input value

Page 87

C.2 Assembly Language Sample 1

MOV AX, 6F08H ;setting the digital port as input INT 15H ;

AL low byte = value

AH – 6FH

Sub-function:

AL – 9 :Set the digital port as OUTPUT BL :Digital I/O input value

C.3 Assembly Language Sample 2

TANK-800 Embedded System

MOV AX, 6F09H ;setting the digital port as output MOV BL, 09H ;digital value is 09H INT 15H ;

Digital Output is 1001b

Page 88

TANK-800 Embedded System

D Hazardous Materials

Appendix

Disclosure

Page 89
