IEI Technology PM-BT, PM-BT-E38451W2, PM-BT-J19001, PM-BT-N28071, PM-BT-E38251W2 User Manual

PM-BT SBC

Page i

MODEL:

PM-BT

PC/104-Plus SBC with Intel® Celeron®/Atom™

Rev. 1.00 – May 31, 2018

On-board SoC, DDR3L, VGA, LVDS, GbE, USB 2.0,

SATA 3Gb/s, RS-232/422/485, 5 V DC Input and RoHS

User Manual

PM-BT SBC

Page ii

Date Version Changes

Revision

May 31, 2018

1.00 Initial release

PM-BT SBC

Page iii

Copyright

COPYRIGHT NOTICE

The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.

In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibil ity of such damages.

This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.

TRADEMARKS

All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

PM-BT SBC

Page iv

Manual Conventions

WARNING

Warnings appear where overlooked details may cause damage to the
equipment or result in personal injury. Warnings should be taken
seriously.

CAUTION

Cautionary messages should be heeded to help red uce the chance of
losing data or damaging the product.

NOTE

These messages inform the reader of essent ial but non-critical
information. These messages should be read carefully as any directions
or instructions contained therein can help av oid m aking mistakes.

PM-BT SBC

Page v

Table of Contents

1 INTRODUCTION .......................................................................................................... 1

1.1 INTRODUCTION ........................................................................................................... 2

1.2 MODEL VARIATIONS ................................................................................................... 2

1.3 FEATURES ................................................................................................................... 3

1.4 CONNECTORS ............................................................................................................. 4

1.5 DIMENSIONS ............................................................................................................... 5

1.6 DATA FLOW ................................................................................................................ 6

1.7 TECHNICAL SPECIFICATIONS ...................................................................................... 7

2 PACKING LIST ........................................................................................................... 10

2.1 ANTI-STATIC PRECAUTIONS ....................................................................................... 11

2.2 UNPACKING PRECAUTIONS ........................................................................................ 11

2.3 PACKING LIST ........................................................................................................... 12

2.4 OPTIONAL ITEMS ...................................................................................................... 13

3 CONNECTORS ........................................................................................................... 14

3.1 PERIPHERAL INTERFACE CONNECTORS ..................................................................... 15

3.1.1 PM-BT Layout .................................................................................................. 15

3.1.1 Peripheral Interface Connectors ..................................................................... 16

3.2 INTERNAL PERIPHERAL CONNECTORS ...................................................................... 17

3.2.1 Battery Connector ............................................................................................ 17

3.2.1 Buzzer Connector ............................................................................................. 18

3.2.2 DDR3L SO-DIMM Socket ................................................................................ 19

3.2.3 Digital I/O Connector ...................................................................................... 20

3.2.4 Front Panel Connector .................................................................................... 21

3.2.1 LAN Connector ................................................................................................ 22

3.2.1 LVDS LCD Connector ..................................................................................... 23

3.2.2 LVDS Backlight Inverter Connector ................................................................ 24

3.2.1 PC/104-Plus Connector, ISA ............................................................................ 25

3.2.1 PC/104-Plus Connector, PCI ........................................................................... 26

PM-BT SBC

Page vi

3.2.1 PC/104-Plus Power Connector ........................................................................ 28

3.2.2 PCIe Mini Slot .................................................................................................. 29

3.2.1 Power Input Connector .................................................................................... 31

3.2.2 RS-232/422/485 Serial Port Connectors ......................................................... 32

3.2.3 SATA 3Gb/s Drive Connector .......................................................................... 34

3.2.1 SATA Power Connector .................................................................................... 35

3.2.2 SPI Flash Connector ........................................................................................ 36

3.2.3 USB 2.0 Connectors ......................................................................................... 37

3.2.1 VGA Connector ................................................................................................ 38

4 INSTALLATION ......................................................................................................... 39

4.1 ANTI-STATIC PRECAUTIONS ...................................................................................... 40

4.2 INSTALLATION CONSIDERATIONS .............................................................................. 40

4.3 SO-DIMM INSTALLATION ....................................................................................... 42

4.4 FULL-SIZE PCIE MINI CARD INSTALLATION ............................................................. 43

4.5 SYSTEM CONFIGURATION ......................................................................................... 44

4.5.1 AT/ATX Power Mode Setting ........................................................................... 44

4.5.1 LVDS Panel Resolution Select Switch ............................................................. 45

4.5.1 LVDS Voltage Selection ................................................................................... 46

4.5.2 PCI Voltage Setup ............................................................................................ 47

4.6 AVAILABLE DRIVERS ................................................................................................ 48

4.6.1 Driver Download ............................................................................................. 48

4.7 OS INSTALLATION .................................................................................................... 50

5 BIOS .............................................................................................................................. 51

5.1 INTRODUCTION ......................................................................................................... 52

5.1.1 Starting Setup ................................................................................................... 52

5.1.2 Using Setup ...................................................................................................... 52

5.1.3 Getting Help ..................................................................................................... 53

5.1.4 Unable to Reboot after Configuration Changes .............................................. 53

5.1.5 BIOS Menu Bar ................................................................................................ 53

5.2 MAIN ........................................................................................................................ 54

5.3 ADVANCED ............................................................................................................... 55

5.3.1 Trusted Computing ........................................................................................... 56

5.3.2 ACPI Settings ................................................................................................... 57

PM-BT SBC

Page vii

5.3.3 F81866 Super IO Configuration ...................................................................... 58

5.3.3.1 Serial Port n Configuration ....................................................................... 58

5.3.4 F81866 H/W Monitor ....................................................................................... 61

5.3.5 RTC Wake Settings ........................................................................................... 62

5.3.6 Serial Port Console Redirection ...................................................................... 63

5.3.7 iEi Feature ....................................................................................................... 66

5.3.8 CPU Configuration .......................................................................................... 67

5.3.9 IDE Configuration ............................................................................................ 68

5.3.10 USB Configuration ......................................................................................... 69

5.4 CHIPSET ................................................................................................................... 70

5.4.1 North Bridge .................................................................................................... 71

5.4.1.1 Intel IGD Configuration ............................................................................ 72

5.4.2 South Bridge ..................................................................................................... 74

5.4.2.1 PCI Express Configuration ....................................................................... 75

5.5 SECURITY ................................................................................................................. 76

5.6 BOOT ........................................................................................................................ 77

5.7 SAVE & EXIT ............................................................................................................ 79

A REGULATORY COMPLIANCE .............................................................................. 81

B PRODUCT DISPOSAL .............................................................................................. 83

C BIOS OPTIONS .......................................................................................................... 85

D DIGITAL I/O INTERFACE ....................................................................................... 88

D.1 INTRODUCTION ........................................................................................................ 89

D.2 ASSEMBLY LANGUAGE SAMPLE 1 ............................................................................ 90

D.3 ASSEMBLY LANGUAGE SAMPLE 2 ............................................................................ 90

E WATCHDOG TIMER ................................................................................................. 91

F HAZARDOUS MATERIALS DISCLOSURE .......................................................... 94

PM-BT SBC

Page viii

List of Figures

Figure 1-1: PM-BT ........................................................................................................................... 2

Figure 1-2: Connectors .................................................................................................................. 4

Figure 1-3: PM-BT Dimensions (mm) ............................................................................................ 5

Figure 1-4: Data Flow Diagram ...................................................................................................... 6

Figure 3-1: Peripheral Interface Connectors (Front Side) ........................................................ 15

Figure 3-2: Peripheral Interface Connectors (Solder Side) ...................................................... 15

Figure 3-3: Battery Connector Location ..................................................................................... 18

Figure 3-4: Buzzer Connector Location ..................................................................................... 19

Figure 3-5: DDR3L SO-DIMM Socket Locations ........................................................................ 19

Figure 3-6: Digital I/O Connector Location ................................................................................ 20

Figure 3-7: Front Panel Connector Location ............................................................................. 21

Figure 3-8: LAN Connector Location .......................................................................................... 22

Figure 3-9: LAN Cable .................................................................................................................. 22

Figure 3-10: LVDS Connector Location...................................................................................... 23

Figure 3-11: Backlight Inverter Connector Location ................................................................. 24

Figure 3-12: PC/104 Slot Location .............................................................................................. 25

Figure 3-13: PCI-104 Connector Location .................................................................................. 27

Figure 3-14: PC/104-Plus Power Connector Pinouts ................................................................ 28

Figure 3-15: PCIe Mini Slot Location .......................................................................................... 29

Figure 3-16: Power Connector Location .................................................................................... 31

Figure 3-17: RS-232/422/485 Serial Port Connector Locations ................................................ 32

Figure 3-18: SATA 3Gb/s Drive Connector Location ................................................................ 34

Figure 3-19: SATA Power Connector Location ......................................................................... 35

Figure 3-20: SPI Flash Connector Location ............................................................................... 36

Figure 3-21: USB 2.0 Connector Locations ............................................................................... 37

Figure 3-22: VGA Connector Location ....................................................................................... 38

Figure 3-23: VGA Cable ................................................................................................................ 38

Figure 4-1: SO-DIMM Installation ................................................................................................ 42

Figure 4-2: Removing the Retention Screw ............................................................................... 43

Figure 4-3: Inserting the Full-size PCIe Mini Card into the Slot at an Angle .......................... 43

PM-BT SBC

Page ix

Figure 4-4: Securing the Full-size PCIe Mini Card .................................................................... 44

Figure 4-5: AT/ATX Power Mode Switch Location .................................................................... 44

Figure 4-6: LVDS Panel Resolution Select Switch Location .................................................... 45

Figure 4-7: LVDS Voltage Selection Jumper Locations ........................................................... 46

Figure 4-8: PCI Voltage Jumper Location .................................................................................. 47

Figure 4-9: IEI Resource Download Center ................................................................................ 48

Figure 4-10: BIOS Option–OS Selection .................................................................................... 50

PM-BT SBC

Page x

List of Tables

Table 1-1: Model Variations ........................................................................................................... 2

Table 1-2: PM-BT Specifications ................................................................................................... 8

Table 2-1: Packing List ................................................................................................................. 13

Table 2-2: Optional Items ............................................................................................................. 13

Table 3-1: Peripheral Interface Connectors ............................................................................... 16

Table 3-2: Battery Connector Pinouts ........................................................................................ 18

Table 3-3: Buzzer Connector Pinouts ......................................................................................... 19

Table 3-4: Digital I/O Connector Pinouts .................................................................................... 20

Table 3-5: Front Panel Connector Pinouts ................................................................................. 21

Table 3-6: LAN Connector Pinouts ............................................................................................. 22

Table 3-7: LVDS Connector Pinouts ........................................................................................... 23

Table 3-8: Backlight Inverter Connector Pinouts ...................................................................... 24

Table 3-9: PC/104 Slot Connector Pinouts ................................................................................. 26

Table 3-10: PCI-104 Connector Pinouts ..................................................................................... 28

Table 3-11: PC/104-Plus Power Connector Pinouts .................................................................. 29

Table 3-12: PCIe Mini Slot Pinouts .............................................................................................. 30

Table 3-13: Power Connector Pinouts ........................................................................................ 31

Table 3-14: RS-232 Serial Port Connector Pinouts ................................................................... 32

Table 3-15: DB-9 RS-232/422/485 Pinouts .................................................................................. 33

Table 3-16: SATA 3Gb/s Drive Connector Pinouts .................................................................... 34

Table 3-17: SATA Power Connector Pinouts ............................................................................. 35

Table 3-18: SPI Flash Connector Pinouts .................................................................................. 36

Table 3-19: USB 2.0 Connector Pinouts ..................................................................................... 37

Table 3-20: VGA Connector Pinouts ........................................................................................... 38

Table 4-1: AT/ATX Power Mode Switch Settings ....................................................................... 45

Table 4-2: LVDS Panel Resolution Selection ............................................................................. 45

Table 4-3: LVDS Voltage Selection Jumper Settings ................................................................ 46

Table 4-4: PCI Voltage Jumper Settings..................................................................................... 47

Table 5-1: BIOS Navigation Keys ................................................................................................ 53

PM-BT SBC

Page xi

BIOS Menus

BIOS Menu 1: Main ....................................................................................................................... 54

BIOS Menu 2: Advanced .............................................................................................................. 55

BIOS Menu 3: Trusted Computing .............................................................................................. 56

BIOS Menu 4: ACPI Configuration .............................................................................................. 57

BIOS Menu 5: F81866 Super IO Configuration .......................................................................... 58

BIOS Menu 6: Serial Port n Configuration Menu ....................................................................... 58

BIOS Menu 7: F81866 H/W Monitor ............................................................................................. 61

BIOS Menu 8: RTC Wake Settings .............................................................................................. 62

BIOS Menu 9: Serial Port Console Redirection ......................................................................... 63

BIOS Menu 10: iEi Feature ........................................................................................................... 66

BIOS Menu 11: CPU Configuration ............................................................................................. 67

BIOS Menu 12: IDE Configuration ............................................................................................... 68

BIOS Menu 13: USB Configuration ............................................................................................. 69

BIOS Menu 14: Chipset ................................................................................................................ 71

BIOS Menu 15: North Bridge ....................................................................................................... 71

BIOS Menu 16: Intel IGD Configuration ...................................................................................... 72

BIOS Menu 17: South Bridge ....................................................................................................... 74

BIOS Menu 18: PCI Express Configuration ............................................................................... 75

BIOS Menu 19: Security ............................................................................................................... 76

BIOS Menu 20: Boot ..................................................................................................................... 77

BIOS Menu 21: Save & Exit .......................................................................................................... 79

PM-BT SBC

Page 1

Chapter

1

1 Introduction

PM-BT SBC

Page 2

(2 GHz, quad-core, 2 MB cache, TDP=10 W)

(1.58 GHz, dual-core, 2 MB cache, TDP=4.5 W)

(1.91 GHz, quad-core, 2 MB cache, TDP=10 W)

(1.33 GHz, dual-core, 1 MB cache, TDP=6 W)

*Production by order, MOQ 100 pcs/lot

1.1 Introduction

Figure 1-1: PM-BT

The PC/104-Plus form factor PM-BT is a highly integrated embedded computer
specifically optimized for multi-media applications requiring minimum installation space.
The PM-BT is particularly suitable for low power and fan-less applicat ions. The PM-BT
supports a full range of functions for an industrial computer in a space-saving 96 mm x
90 mm profile. The PM-BT is equipped with an on -board low-power consumption and high
performance 22nm Intel® Celeron® or Atom™ processor. It also supports a single 204-pin
1333/1066 MHz DDR3L SO-DIMM (up to 8 GB).

1.2 Model Variations

The model variations for the PM-BT series are listed in Table 1-1.

Model On-board SoC Operating Temp.

PM-BT-J19001

PM-BT-N28071

PM-BT-E38451W2*

PM-BT-E38251W2*

Intel® Celeron® processor J1900

Intel® Celeron® processor N2807

Intel® Atom™ processor E3845

Intel® Atom™ processor E3825

-20ºC ~ 60ºC

-20ºC ~ 60ºC

-40ºC ~ 85ºC

-40ºC ~ 85ºC

Table 1-1: Model Variations

PM-BT SBC

Page 3

1.3 Features

Some of the PM-BT motherboard features are listed below:

 PC/104-Plus (ISA and P CI signal) function support
 5V DC input solution
 On-board 22nm Intel® Atom™ or Celeron® processor
 One 204-pin 1333/1066 MHz single-channel DDR3L SDRAM SO-DIMM slot

 VGA and LVDS interfaces for dual independent display
 One GbE connector
 One SATA 3Gb/s connector with 5 V SATA power connector

supports up to 8 GB of memory (for J1900, E3845 and E3825 SKUs)
or

One 204-pin 1333/1066 MHz single-channel DDR3L SDRAM SO-DIMM slot
supports up to 4 GB of memory (for N2807 SKU)

 One full-size PCIe Mini card expansion slot
 Three USB 2.0 ports
 Two RS-232/422/485 serial ports
 On-board SSD (optional)
 RoHS compliant

PM-BT SBC

Page 4

1.4 Connectors

The connectors on the PM-BT are shown in the figure below.

Figure 1-2: Connectors

PM-BT SBC

Page 5

1.5 Dimensions

The main dimensions of the PM-BT are shown in the diagram bel ow.

Figure 1-3: PM-BT Dimensions (mm)

PM-BT SBC

Page 6

1.6 Data Flow

Figure 1-4 shows the data flow between the system chipset, the CPU and other

components installed on the motherboard.

Figure 1-4: Data Flow Diagram

PM-BT SBC

Page 7

1.7 Technical Specifications

The PM-BT technical specifications are listed below.

Specification/Model PM-BT
Form Factor

SoC

Memory

PC/104-Plus
 Standard

o Intel® Celeron® processor J1900

(2 GHz, quad-core, 2 MB cache, TDP=10 W)

o Intel® Celeron® processor N2807

(1.58 GHz, dual-core, 2 MB cache, TDP=4.5 W)

 By request (MOQ 100)

o Intel® Atom™ processor E3845

(1.91 GHz, quad-core, 2 MB cache, TDP=10 W)

o Intel® Atom™ processor E3825

(1.33 GHz, dual-core, 1 MB cache, TDP=6 W)

For J1900, E3845 and E3825 SKUs:
One 204-pin 1333/1066 MHz single-channel DDR3L SDRAM
SO-DIMM slot supports up to 8 GB of memory

For N2807 SKU:
One 204-pin 1333/1066 MHz single-channel DDR3L SDRAM

Graphics Engine

Display Output

Ethernet Controllers
BIOS
Super I/O Controller
Watchdog Timer

SO-DIMM slot supports up to 4 GB of memory
Intel® HD Graphics Gen7 with 4 execution units, supporting DirectX

11.1, OpenCL 1.2 and OpenGL 4.2
Supports dual independent display

One VGA (up to 2560x1600@60Hz)
One 18-bit/24-bit single-channel LVDS

Intel® I210 PCIe controller
UEFI BIOS
Fintek F81866
Software programmable supports 1~255 sec. sy st em reset

PM-BT SBC

Page 8

One full-size PCIe Mini card slot (supports mSATA)

Expansions

Storage
I/O Interface Connectors
Digital I/O
Ethernet

Front Panel

Serial ATA
Serial Ports
USB 2.0
Environmental and Power Specifications
Power Supply

One PC/104-Plus (ISA + PCI)
* The ISA function is limited. Please refer to page 8 for details.

On-board SSD (optional)

8-bit digital I/O
One GbE port
One 10-pin header (power LED, HDD LED, power bu tton and reset

button)
One SATA 3Gb/s connector with 5 V SAT A power connector
Two RS-232/422/485 via internal 10-pin headers
Three USB 2.0 ports via internal pin headers

5 V DC input
12 V for fan, L VDS and PC/104-Plus
3 V / 5 V jumper for add-in modules
Support A T/A TX mode
ErP/EuP Compliant

Power Consumption

Operating
Temperature

Storage Temperature
Operating Humidity
Safety
Physical Specifications
Dimensions
Weight (GW/NW)
Table 1-2: PM-BT Specifications

5 V @ 1.70 A (2 GHz Intel® Celeron® processor J1900 with one 8 GB
1333 MHz DDR3L memory)

-20ºC ~ 60ºC (for J1900/N2807 SKUs)

-40ºC ~ 85ºC (for E38xx SKUs)

-40ºC ~ 85ºC
5% ~ 95% (non-condensing)
CE, FCC

96 mm x 90 mm
500 g / 120 g

PM-BT SBC

Page 9

NOTE:

ISA Limitation of PM-BT

Due to the limitation of Intel® Bay Trail processors, the PM-BT does
not support the following features:

 Bus Master Cycles
 DMA
 LPC Memory Mapped Transactions
 IRQ0, IRQ1, IRQ2, IRQ8, IRQ9, IRQ13, IRQ14
 ISA Enable (IE) Bit
 PnP

PM-BT SBC

Page 10

Chapter

2

2 Packing List

PM-BT SBC

Page 11

2.1 Anti-static Precautions

WARNING!

Static electricity can destroy certain elect ronics. Make sur e to follow the
ESD precautions to prevent damage to the product, and injury to the
user.

Make sure to adhere to the following guidelines:

 Wear an anti-static wristband: Wearing an anti-static wristband can prevent

electrostatic discharge.

 Self-grounding: Touch a grounded conductor every few minutes to discharge

any excess static buildup.

 Use an anti-static pad: When configuring any circuit board, place it on an

anti-static mat.

 Only handle the edges of the PCB: Don't touch the surface of the

motherboard. Hold the motherboard by the edges when handling.

2.2 Unpacking Precautions

When the PM-BT is unpacked, please do the following:

 Follow the anti-static guidelines above.
 Make sure the packing box is facing upwards when opening.
 Make sure all the packing list items are present .

PM-BT SBC

Page 12

was purchased from or contact an IEI sales representative

2.3 Packing List

NOTE:

If any of the components listed in the checklist below are missing, do
not proceed with the installation. Contact the IEI reseller or vendor the
PM-BT
directly by sending an email to [e-mail].

The PM-BT is shipped with the following components:

Quantity Item and Part Number Image

1 PM-BT single board computer

1 SATA and power cable

1 Power cable

1 COM port cable

1 LAN cable

1 Single-port USB cable

PM-BT SBC

Page 13

Quantity Item and Part Number Image

1 VGA cabl e

1 Quick installation guide

Table 2-1: Packing List

2.4 Optional Items

The following are optional components which may be separately purchased:

Item and Part Number Image

PC/104-Plus press-fit socket, 120-pin, p=2.0mm
(P/N: 33403-000015-RS)

PC/104-Plus press-fit socket, 64+40-pin, p=2.54mm
(P/N: 33403-000016-RS)

Table 2-2: Optional Items

PM-BT SBC

Page 14

Chapter

3

3 Connectors

PM-BT SBC

Page 15

3.1 Peripheral Interface Connectors

This chapter details all the peripheral interface connectors.

3.1.1 PM-BT Layout

The figure below shows all the peripheral interface connectors.

Figure 3-1: Peripheral Interface Connectors (Front Side)

Figure 3-2: Peripheral Interface Connectors (Solder Side)

PM-BT SBC

Page 16

3.1.1 Peripheral Interface Connectors

The table below lists all the connectors on the board.

Connector Type Label

Battery connector 2-pin wafer BAT1
Buzzer connector 2-pin wafer SP1

DDR3L SO-DIMM socket

Digital I/O connector 10-pin header DIO1
Front panel connector 10-pin header F_PANEL1
LAN connector 14-pin header LAN1
LVDS connector 20-pin crimp LVDS1
LVDS backlight inverter connector 6-pin wafer INV_CN1
PC/104-Plus connector, ISA PC/104 CN1
PC/104-Plus connector, PCI PCI-104 PC104_PLUS1
PC/104-Plus power connector 3-pin header ISA_P_CN1
PCIe Mini slot PCIe Mini slot M_PCIE1
Power input connector 3-pin terminal block PWR1
RS-232/422/485 serial ports 10-pin header COM1, COM2
SATA 3Gb/s drive connector 7-pin SATA connector SATA1

204-pin DDR3L

DIMM1

SO-DIMM socket

SATA power connector 2-pin wafer SATA_PWR1
SPI flash connector 6-pin wafer JSPI1
USB 2.0 connectors 4-pin wafer USB1, USB2, USB3
VGA connector 10-pi n header VGA_CON1

Table 3-1: Peripheral Interface Connectors

PM-BT SBC

Page 17

Dispose of used batteries according to instructions and local

3.2 Internal Peripheral Connectors

The section describes all of the connectors on the PM-BT.

3.2.1 Battery Connector

CAUTION:

Risk of explosion if battery is replaced by an incorrect type. Only
certified engineers should replace the on-board battery.

regulations.

NOTE:

It is recommended to attach the RTC battery onto the system chassis
in which the PM-BT is installed.

CN Label: BAT1
CN Type:
CN Location:
CN Pinouts:

A system battery is placed in the battery holder. The batt ery prov ide s power t o the system
clock to retain the time when power is turned off.

2-pin wafer, p=1.25 mm
See Figure 3-3
See Table 3-2

PM-BT SBC

Page 18

Figure 3-3: Battery Connector Location

Pin Description

1 Battery+
2 Ground

Table 3-2: Battery Connector Pinouts

3.2.1 Buzzer Connector

NOTE:

If you cannot find a good place to put a buzzer on the PM-BT, it is
recommended to attach the buzzer onto the system chassis in which
the PM-BT is installed.

CN Label: SP1
CN Type:
CN Location:
CN Pinouts:

The buzzer connector is connected to a buzzer.

2-pin wafer, p=1.25 mm
See Figure 3-4
See Table 3-3

PM-BT SBC

Page 19

Figure 3-4: Buzzer Connector Location

Pin Description

1 BU_PWR
2 PC_BEEP

Table 3-3: Buzzer Connector Pinouts

3.2.2 DDR3L SO-DIMM Socket

CN Label: DIMM1
CN Type:
CN Location:

The SO-DIMM slots are for installing the DDR3L SO-DIMMs.

Figure 3-5: DDR3L SO-DIMM Socket Locations

204-pin DDR3L SO-DIMM socket
See Figure 3-5

PM-BT SBC

Page 20

Figure 3-6: Digital I/O Connector Location

3.2.3 Digital I/O Connector

CN Label: DIO1
CN Type:
CN Location:
CN Pinouts:

The digital I/O connector provides programmable input and output for external devices.

10-pin header, p=2.00 mm
See Figure 3-6
See Table 3-4

Pin Description Pin Description

1 GND 2 VCC5V
3 Output 3 4 Output 2
5 Output 1 6 Output 0
7 Input 3 8 Input 2
9 Input 1 10 Input 0

Table 3-4: Digital I/O Connector Pinouts

PM-BT SBC

Page 21

3.2.4 Front Panel Connector

CN Label: F_PANEL1
CN Type:
CN Location:
CN Pinouts:

10-pin header, p=2.00 mm
See Figure 3-7
See Table 3-5

The front panel connector connects to the indicator LEDs and buttons on the computer's
front panel.

Figure 3-7: Front Panel Connector Location

Function Pin Description Function Pin Description

Power LED

HDD LED 5 HDD_LED+ 10 RESET-

1 VCC HDD LED 6 HDD_LED­2 GND

Power Button

3 PWR_LED+ 8 PWR_BTN­4 PWR_LED-

Reset

7 PWR_BTN+

9 RESET+

Table 3-5: Front Panel Connector Pinouts

PM-BT SBC

Page 22

3.2.1 LAN Connector

CN Label: LAN1
CN Type:
CN Location:
CN Pinouts:

14-pin header, p=2.00 mm
See Figure 3-8
See Table 3-6

Use the LAN cable to connect to the LAN1 connector to provide gigabit LAN connection.

Figure 3-8: LAN Connector Location

Pin Description Pin Description

1 MDX0+ 2 MDX0­3 MDX1+ 4 MDX1­5 MDX2+ 6 MDX2­7 MDX3+ 8 MDX3­9 GND 10 GND
11 LINKLED+ 12 LINKLED­13 SPEEDLED 14 SPEEDLED2

Table 3-6: LAN Connector Pinouts

Figure 3-9: LAN Cable

PM-BT SBC

Page 23

3.2.1 LVDS LCD Connector

CN Label: LVDS1
CN Type:
CN Location:
CN Pinouts:

20-pin crimp, p=1.25 mm
See Figure 3-10
See Table 3-7

The LVDS connector is for an LCD panel connecte d to the board.

Figure 3-10: LVDS Connector Location

Pin Description Pin Description

1 GND 2 GND
3 LVDSA_DATA1- 4 LVDSA_DATA0­5 LVDSA_DATA1+ 6 LVDSA_DATA0+
7 GND 8 GND
9 LVDSA_CLK- 10 LVDSA_DATA2­11 LVDSA_CLK+ 12 LVDSA_DATA2+
13 GND 14 GND
15 LVDSA_DATA3- 16 N/C
17 LVDSA_DATA3+ 18 +VCC_LCD
19 GND 20 +VCC_LCD

Table 3-7: LVDS Connector Pinouts

PM-BT SBC

Page 24

3.2.2 LVDS Backlight Inverter Connector

CN Label: INV_CN1
CN Type:
CN Location:
CN Pinouts:

6-pin wafer, p=2.00 mm
See Figure 3-11
See Table 3-8

The backlight inverter connector provide s power to an LCD panel.

Figure 3-11: Backlight Inverter Connector Location

Pin Description

1 +12 V
2 +12 V
3 BACKLIGHT ENABLE
4 BRIGHTNESS
5 GND
6 GND

Table 3-8: Backlight Inverter Connector Pinouts

PM-BT SBC

Page 25

3.2.1 PC/104-Plus Connector, ISA

CN Label: CN1
CN Type:
CN Location:
CN Pinouts:

PC/104 Connector
See Figure 3-12
See Table 3-9

This PC/104-Plus connector supports ISA bus.

Figure 3-12: PC/104 Slot Location

Pin Row A Row B Row C Row D

1 IOCHK- GROUND GROUND GROUND
2 SD7 RSTDRV SBHE- MEMCS16­3 SD6 +5 V LA23 IOCS16­4 SD5 IRQ9 LA22 IRQ10
5 SD4 -5 V LA21 IRQ11
6 SD3 DREQ2 LA20 IRQ12
7 SD2 -12 V LA19 IRQ15
8 SD1 NOWS- LA18 IRQ14
9 SD0 +12 V LA17 DACK0­10 IOCHRDY GROUND MEMR- DRQ0
11 AEN SMEMW- MEMW- DACK5­12 SA19 SMEMR- SD8 DRRQ5
13 SA18 IOW- SD9 DACK6­14 SA17 IOR- SD10 DRQ6
15 SA16 DACK3- SD11 DACK7-

PM-BT SBC

Page 26

Pin Row A Row B Row C Row D

16 SA15 DRQ3 SD12 DRQ7
17 SA14 DACK1- SD13 +5 V
18 SA13 DRQ1 SD14 MASTER­19 SA12 REFRESH- SD15 GROUND
20 SA11 SYSCLK NC GROUND
21 SA10 IRQ7
22 SA9 IRQ6
23 SA8 IRQ5
24 SA7 IRQ4
25 SA6 IRQ3
26 SA5 DACK2-
27 SA4 TC
28 SA3 BALE
29 SA2 +5 V
30 SA1 ISA_OSC
31 SA0 GROUND
32 GROUND GROUND

Table 3-9: PC/104 Slot Connector Pinouts

3.2.1 PC/104-Plus Connector, PCI

CN Label: PC104_PLUS1
CN Type:
CN Location:
CN Pinouts:

This PC/104-Plus connector supports PCI bus, and provides either 3.3V or 5V signaling
level (configured by jumper, see Section 4.5.2).

PCI-104 connector
See Figure 3-13
See Table 3-10

PM-BT SBC

Page 27

Figure 3-13: PCI-104 Connector Location

Pin Row A Row B Row C Row D

1 GND SERIRQ_PCI +5 V AD00
2 +PIO_VCC AD02 AD01 +5 V
3 AD05 GND AD04 AD03
4 C/BE0 AD07 GND AD06
5 GND AD09 AD08 GND
6 AD11 +PIO_VCC AD10 GND
7 AD14 AD13 GND AD12
8 +3.3 V C/BE1 AD15 +3.3 V
9 -SERR GND SB0 PAR
10 GND -PERR +3.3 V SDONE
11 -STOP +3.3 V -LOCK GND

12
13 -FRAME GND -IRDY +3.3 V
14 GND AD16 +3.3 V C/BE2
15 AD18 +3.3 V AD17 GND
16 AD21 AD20 GND AD19

+3.3 V -TRDY GND -DEVSEL

17 +3.3 V AD23 AD22 +3.3 V
18 IDSEL0 GND IDSEL1 IDSEL2
19 AD24 C/BE3 +PIO_VCC IDSEL3

PM-BT SBC

Page 28

Pin Row A Row B Row C Row D

20 GND AD26 AD25 GND
21 AD29 +5 V AD28 AD27
22 +5 V AD30 GND AD31
23 REQ0 GND REQ1 +PIO_VCC
24 GND REQ2 +5 V GNT0
25 GNT1 +PIO_VCC GNT2 GND
26 +5 V CLK0 GND CLK1
27 CLK2 +5 V CLK3 GND
28 GND -PIRQD +5 V RST­29 +12 V -PIRQA -PIRQB -PIRQC
30 -12 V PREQ-3 PGNT-3 GND

Table 3-10: PCI-104 Connector Pinouts

3.2.1 PC/104-Plus Power Connector

CN Label: PC104_PWR1
CN Type:
CN Location:
CN Pinouts:

The PC/104-Plus power connector provides extra power to PC/104 modules.

Figure 3-14: PC/104-Plus Power Connector Pinouts

3-pin wafer (1x3)
See Figure 3-14
See Table 3-11

PM-BT SBC

Page 29

Pin Description

1 -12 V
2 GND
3 -5 V

Table 3-11: PC/104-Plus Power Connector Pinouts

3.2.2 PCIe Mini Slot

CN Label: M_PCIE1
CN Type:
CN Location:
CN Pinouts:

Full-size PCIe Mini slot
See Figure 3-15
See Table 3-12

The PCIe Mini slot supporting PCIe and USB signals is for installing a full-size mSATA
module.

Figure 3-15: PCIe Mini Slot Location

Pin Description Pin Description

1 PCIE_WAKE# 2 VCC3
3 N/C 4 GND

5 N/C 6 1.5V
7 N/C 8 N/C
9 GND 10 N/C
11 PCIE_CLK- 12 N/C
13 PCIE_CLK+ 14 N/C
15 GND 16 N/C

PM-BT SBC

Page 30

Pin Description Pin Description

17 N/C 18 GND
19 N/C 20 N/C
21 GND 22 PCIRST#
23 PCIE_RXN 24 VCC3
25 PCIE_RXP 26 GND
27 GND 28 1.5V
29 GND 30 SMBCLK
31 PCIE_TXN 32 SMBDATA
33 PCIE_TXP 34 GND
35 GND 36 USBD­37 GND 38 USBD+
39 VCC3 40 GND
41 VCC3 42 N/C
43 N/C 44 N/C
45 N/C 46 N/C
47 N/C 48 1.5V
49 N/C 50 GND
51 mSATA_DET# 52 VCC3

Table 3-12: PCIe Mini Slot Pinouts

PM-BT SBC

Page 31

3.2.1 Power Input Connector

CN Label: PWR1
CN Type:
CN Location:
CN Pinouts:

The PWR1 connector connects to the power source to provide main power to the system.

Figure 3-16: Power Connector Location

3-pin terminal block connector
See Figure 3-16
See Table 3-13

Pin Description

1 +12 V
2 GND
3 +5 V

Table 3-13: Power Connector Pinouts

PM-BT SBC

Page 32

Table 3-14: RS-232 Serial Port Connector Pinouts

3.2.2 RS-232/422/485 Serial Port Connectors

CN Label: COM1, COM2
CN Type:
CN Location:
CN Pinouts:

Each of these connectors provides RS-232/422/485 connections.

Figure 3-17: RS-232/422/485 Serial Port Connector Locations

10-pin header, p=2.00 mm
See Figure 3-17
See Table 3-14

Pin Description Pin Description

1 DCD 2 DSR
3 RX 4 RTS
5 TX 6 CTS
7 DTR 8 RI
9 GND 10 GND

PM-BT SBC

Page 33

BIOS option to configure the

NOTE:

The communication protocol of COM1 and COM2 serial ports is set thro ugh
the BIOS menu in “Advanced  F81866 Super IO Configuration Serial Port
Configuration”. Use the Transfer Mode
correspondent serial ports (refer to Sections 5.3.3.1.1 and Section 5.3.3.1.2
for detailed information).

The DB-9 connector pinouts of the COM port cable are listed below.

RS-232 Pinouts RS-422 Pinouts RS-485 Pinouts

Table 3-15: DB-9 RS-232/422/485 Pinouts

Figure 3-18: COM Port Cable

PM-BT SBC

Page 34

3.2.3 SATA 3Gb/s Drive Connector

CN Label: SATA1
CN Type:
CN Location:
CN Pinouts:

7-pin SATA drive connector
See Figure 3-18
See Table 3-16

The SATA drive connector can be connected to SATA drives and supports up to 3Gb/s
data transfer rate.

Figure 3-19: SATA 3Gb/s Drive Connector Location

Pin Description Pin Description

1 GND 2
3
5
7 GND

SATA_TXN
SATA_RXN

4 GND
6

SATA_TXP

SATA_RXP

Table 3-16: SATA 3Gb/s Drive Connector Pinouts

PM-BT SBC

Page 35

3.2.1 SATA Power Connector

CN Label: SATA_PWR1
CN Type:
CN Location:
CN Pinouts:

Use the SATA Power Connector to connect to SATA device power connections.

Figure 3-20: SATA Power Connector Location

2-pin wafer, p=2.00 mm
See Figure 3-19
See Table 3-17

Pin Description

1 +5V
2 GND

Table 3-17: SATA Power Connector Pinouts

PM-BT SBC

Page 36

3.2.2 SPI Flash Connector

CN Label: JSPI1
CN Type:
CN Location:
CN Pinouts:

6-pin wafer , p=1.25 mm
See Figure 3-20
See Table 3-18

The SPI flash connector is used to flash the SPI ROM.

Figure 3-21: SPI Flash Connector Location

Pin Description

1 +3.3V
2 SPI_CS
3 SPI_SO
4 SPI_CLK
5 SPI_SI
6 GND

Table 3-18: SPI Flash Connector Pinouts

PM-BT SBC

Page 37

3.2.3 USB 2.0 Connectors

CN Label: USB1, USB2, USB3
CN Type:
CN Location:
CN Pinouts:

The USB 2.0 connectors connect to USB 2.0/1.1 devices.

Figure 3-22: USB 2.0 Connector Locations

4-pin wafer, p=1.25 mm
See Figure 3-21
See Table 3-19

Pin Description

1 VCC
3 DATA­5 DATA+
7 GND

Table 3-19: USB 2.0 Connector Pinouts

PM-BT SBC

Page 38

3.2.1 VGA Connector

CN Label: VGA_CON1
CN Type:
CN Location:
CN Pinouts:

The VGA connector connects to a monitor through the VGA cable that came with the
PM-BT.

Figure 3-23: VGA Connector Location

10-pin header, p=2.00 mm
See Figure 3-22
See Table 3-20

Pin Description Pin Description

1 RED 2 5 V_DDCDA
3 GREEN 4 5 V_DDCLK
5 BLUE 6 GND
7 5HSYNC 8 GND
9 5VSYNC 10 GND

Table 3-20: VGA Connector Pinouts

Figure 3-24: VGA Cable

PM-BT SBC

Page 39

Chapter

4

4 Installation

PM-BT SBC

Page 40

4.1 Anti-static Precautions

WARNING:

Failure to take ESD precautions during the installation of the PM-BT
may result in permanent damage to the PM-BT and s evere injury to the
user.

Electrostatic discharge (ESD) can cause serious damage to electronic components,
including the PM-BT. Dry climates are especially susceptible to ESD. It i s therefore critical
that whenever the PM-BT or any other electrical component is handled, the following
anti-static precautions are strictly adhered to.

 Wear an anti-static wristband: - Wearing a simple anti-static wristband can

help to prevent ESD from damaging the board.

 Self-grounding:- Before handling the board touch any grounded conducting

material. During the time the board is handled, f requently touch any
conducting materials that are connected to the ground.

 Use an anti-static pad: When configuring the PM-BT, place it on an

anti-static pad. This reduces the possibility of ESD damaging the PM-BT.

 Only handle the edges of the PCB:-: When handling t he PCB, h old t he P CB

by the edges.

4.2 Installation Considerations

NOTE:

The following installation notices and installation considerations should
be read and understood before installation. All instal l ation notices must
be strictly adhered to. Failing to adhere to these precautions may lead
to severe damage and injury to the person performing the installation.

PM-BT SBC

Page 41

The installation instructions described in this manual should be

WARNING:

carefully followed in order to prevent damage to the components and
injury to the user.

Before and during the installation please DO the following:

 Read the user manual:

o The user manual provides a complete description of the PM-BT

installation instructions and configuration opt i ons.

 Wear an electrostatic discharge cuff (ESD):

o Electronic components are easily damaged by ESD. Wearing a n ESD cuff

removes ESD from the body and helps prevent ESD damage.

 Place the PM-BT on an anti-static pad:

o When installing or configuring the motherboa rd, pl ace it on an anti-static

pad. This helps to prevent potential ESD damage.

 Turn all power to t he PM-BT off:

o When working with the PM-BT, make sure that it is disconn ect ed from all

power supplies and that no electricity is being fed into the system.

Before and during the installation of the PM-BT, DO NOT:

 Remove any of the stickers on the PCB board. These stickers a re requir ed for

warranty validation.

 Use the product before verifying all the cables and power connectors are

properly connected.

 Allow screws to come in contact with the PCB circuit, connector pins, or its

components.

PM-BT SBC

Page 42

4.3 SO-DIMM Installation

To install a SO-DIMM, please follow the steps below and refer to Figure 4-1.

Figure 4-1: SO-DIMM Installation

Step 1: Locate the SO-DIMM socket. Place the board on an anti-static mat.

Step 2: Align the SO-DIMM with the socket. Al ign the notch on the memory with the

notch on the memory socket.

Step 3: Insert the SO-DIMM. Push the memory in at a 20º angle. (See Figure 4-1)

Step 4: Seat the SO-DIMM. Gently push downwards and the arms clip into place. (See

Figure 4-1) Step 0:

PM-BT SBC

Page 43

4.4 Full-size PCIe Mini Card Installation

The PCIe Mini card slot allows installat ion of a f ull-size PCIe Mini card. To install a full-size
PCIe Mini card, please follow the steps below.

Step 1: Locate the PCIe Mini card slot. See Chapter 3.

Step 2: Remove the retention scr ew. Remove the retent ion screw as shown i n Figure 4-2.

Figure 4-2: Removing the Retention Screw

Step 3: Insert into the socket at an angle. Line up the notch on the card with the notch

on the slot. Slide the PCIe Mini card into the socket at an angle of about 20º
(Figure 4-3).

Figure 4-3: Inserting the Full-size PCIe Mini Card into the Slot at an Angle

PM-BT SBC

Page 44

Step 4: Secure the full-size PCIe Mini card. Secure the full-size PCIe Mini card with

the retention screw previously removed (Figure 4-4). Step 0:

Figure 4-4: Securing the Full-size PCIe Mini Card

4.5 System Configuration

The system configuration should be performed before installation.

4.5.1 AT/ATX Power Mode Setting

The AT and ATX power mode selection is made through the AT/ATX power mod e switc h
which is shown in Figure 4-5.

Figure 4-5: AT/ATX Power Mode Switch Location

PM-BT SBC

Page 45

Setting Description

Short A-B ATX power mode (default)
Short B-C AT power mode

Table 4-1: AT/ATX Power Mode Switch Settings

4.5.1 LVDS Panel Resolution Select Switch

Jumper Label: SW1
Jumper Type:
Jumper Settings:
Jumper Location:

Selects the resolution of the LCD panel connected to the LVDS connector.

* ON=0, OFF=1; Single=S

SW1 (4-3-2-1) Description

0000 800x600 18-bit S (default)
0001 1024x768 18-bit S
0010 1024x768 24-bit S

DIP switch
See Table 4-2
See Figure 4-6

0011 1280x768 18-bit S
0100 1280x800 18-bit S
0101 1280x960 18-bit S
0111 1366x768 18-bit S
1000 1366x768 24-bit S

Table 4-2: LVDS Panel Resolution Selection

Figure 4-6: LVDS Panel Resolution Select Switch Location

PM-BT SBC

Page 46

4.5.1 LVDS Voltage Selection

WARNING:

Incorrect voltages can destroy the LCD panel. Make sure to select a
voltage that matches the voltage required by the LCD panel.

Jumper Label: J_VLVDS1
Jumper Type:
Jumper Settings:
Jumper Location:

The LCD voltage selection jumper sets the voltage of the power supplied of the LCD
panel.

Setting Description

Short 1-3 Backlight Enable +3.3 V
Short 2-4 Set the voltage level of panel to +3.3 V
Short 3-5 Backlight E nable +5 V
Short 4-6 Set the voltage level of panel to +5 V

Table 4-3: LVDS Voltage Selection Jumper Settings

6-pin header, p=2.00 mm
See Table 4-3
See Figure 4-7

Figure 4-7: LVDS Voltage Selection Jumper Locations

PM-BT SBC

Page 47

4.5.2 PCI Voltage Setup

Jumper Label: PCI_P_CN1
Jumper Type:
Jumper Settings:
Jumper Location:

This jumper selects the voltage supplied t o the add-in module.

Setting Description

Short 1-2 +5.0 V (Default)
Short 2-3 +3.3 V

Table 4-4: PCI Voltage Jumper Settings

3-pin header, p=2.00 mm
See Table 4-4
See Figure 4-8

Figure 4-8: PCI Voltage Jumper Location

PM-BT SBC

Page 48

4.6 Available Drivers

All the drivers for the PM-BT are available on IEI Resource Download Center
(https://download.ieiworld.com
software, utilities, and documentation.

Figure 4-9: IEI Resource Download Center

). Type PM-BT and press Enter to find all the relevant

4.6.1 Driver Download

To download drivers from IEI Resource Download Center, follow the steps below.

Step 1: Go to https://download.ieiworld.com

Step 2: All product-related software, utilities, and documentation will be listed. You can

choose Driver to filter the result.

. Type PM-BT and press Enter.

PM-BT SBC

Page 49

Step 3: Click the driver file name on the page and you will be prompted with the

following window. You can download the entire ISO file (
arrow to find an individual driver and click the fil e name to download (

), or click the small

).

NOTE:

To install software from the downloaded ISO image file in Windows 8,

8.1 or 10, double-click the ISO file to mount it as a virtual drive to view
its content. On Windows 7 system, an additional tool (such as Virtual
CD-ROM Control Panel from Microsoft) i s needed to mount the file.

PM-BT SBC

Page 50

4.7 OS Installation

WARNING:

Before installing the operating system, the user must enter the Boot
BIOS menu first and choose which operating system will be installed.
Otherwise, the OS installation may fail. Please refer t o Figure 4-10 and

Section 5.6.

Figure 4-10: BIOS Option–OS Selection

PM-BT SBC

Page 51

Chapter

5

5 BIOS

PM-BT SBC

Page 52

Some of the BIOS options may vary throughout the life cycle of the

5.1 Introduction

The BIOS is programmed onto the BIOS chip. The BI OS setup pro gram allows changes to
certain system settings. This chapter outli nes t he options that can be changed.

NOTE:

product and are subject to change without prior notice .

5.1.1 Starting Setup

The UEFI BIOS is activated when the computer is turned on. The setup program can be
activated in one of two ways.

1. Press the DEL or F2 key as soon as the system is turned on or

2. Press the DEL or F2 key when the “Press DEL or F2 to enter SETUP”
message appears on the screen.

If the message disappears before the DEL or F2 key is pres sed, restart the computer and
try again.

5.1.2 Using Setup

Use the arrow keys to highlight items, press ENTER to select, use the PageUp and
PageDown keys to change entries, press F1 for help and press E
keys are shown in the following table.

Key Function

Up arrow Move to previous item
Down arrow Move to next item
Left arrow Move to the item on the left hand side

SC to quit. Navigation

Right arrow Move to the item on the right hand side
+ Increase the numeric value or m ake changes

- Decrease the numeric value or make change s

PM-BT SBC

Page 53

Key Function

Page Up Move to the previous page
Page Dn Move to the next page
Esc Main Menu – Quit and not save changes into CMOS

Status Page Setup Menu and Option Page Setup Menu -- Exit
current page and return to Main Menu

F1 General help, only for Status Page Setup Menu and Option Page

Setup Menu
F2 Load previous values
F3 Load optimized defaults
F4 Save changes and Exit BIOS

Table 5-1: BIOS Navigation Keys

5.1.3 Getting Help

When F1 is pr essed, a small help window describing the appropriate keys to use and the
possible selections for the highlighted item appears. To exit the Help Window, press E

5.1.4 Unable to Reboot after Configuration Changes

If the computer cannot boot after changes to the system configuration is made, CMOS
defaults. Use the clear CMOS button described in Chapter 4.

5.1.5 BIOS Menu Bar

The menu bar on top of the BIOS screen has the foll owing main items:

 Main – Changes the basic system configuration.
 Advanced – Changes the advanced system settings.
 Chipset – Changes the chipset settings.
 Security – Sets User and Supervisor Passwords.
 Boot – Changes the system boot configuration.
 Save & Exit – Selects exit options and loads default settings

SC.

The following sections completely describe the configuration options found in the menu
items at the top of the BIOS screen and listed above.

PM-BT SBC

Page 54

Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc.

Main

Advanced

Chipset

Security

Boot

Save & Exit

Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.

5.2 Main

The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered.
The Main menu gives an overview of the basic syste m i nformation.

BIOS Information
BIOS Vendor American Megatrends
Core Version 5.009
Compliancy UEFI 2.3; PI 1.2
Project Version B472AM10.ROM
Build Date and Time 04/30/2018 15:52:19

CPU Configuration
Microcode Patch 836
BayTrail SoC C0 Stepping

Memory Information
Total Memory 4096 MB (LPDDR3)

TXE Information
Sec RC Version 00.05.00.00
TXE FW Version 01.00.02.1060

System Date [Fri 01/01/2010]
System Time [00:10:27]

Access Level Administrator

BIOS Menu 1: Main

Set the Date. Use Tab to
switch between Date
elements.

----------------------



: Select Screen

↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit

The Main menu has two user configurable fields:

 System Date [xx/xx/xx]

Use the System Date option to set the system date. Manually enter the day, month and
year.

 System Time [xx:xx:xx]

Use the System Time option to set the system time. Manually enter the hours, minutes
and seconds.

PM-BT SBC

Page 55

Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc.

Main

Advanced

Chipset

Security

Boot

Save & Exit

Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.

5.3 Advanced

Use the Advanced menu (BIOS Menu 2) to configure the CPU and peripheral devices
through the following sub-menus:

WARNING!

Setting the wrong values in the sections below may cause the system
to malfunction. Make sure that the settings made are compatible with
the hardware.

> Trusted Computing
> ACPI Settings
> F81866 Super IO Configuration
> iWDD H/M Monitor
> RTC Wake Settings
> Serial Port Console Redirection
> iEi Feature
> CPU Configuration
> IDE Configuration
> USB Configuration

BIOS Menu 2: Advanced

System ACPI Parameters

----------------------



: Select Screen

↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit

PM-BT SBC

Page 56

Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc.

Advanced

ESC: Exit

Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.

5.3.1 Trusted Computing

Use the Trusted Computing menu (BIOS Menu 3) to configure settings related to the
Trusted Computing Group (TCG) Trusted P l atform Module (TPM).

Configuration
Security Device Support [Disable]

NO Security Device Found

BIOS Menu 3: Trusted Computing

 Security Device Support [Disable]

Use the Security Device Support option to configu re support for the TPM.

Enables or Disables BIOS
support for security
device. O.S. will not
show Security Device.
TCG EFI protocol and
INT1A interface will not
be available.

----------------------



: Select Screen

↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit



Disable DEFAULT



Enable

TPM support is disabled.
TPM support is enabled.

PM-BT SBC

Page 57

Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc.

Advanced

Select the highest ACPI

ESC: Exit

Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.

(Suspend to

off. Power to the RAM is maintained. The
computer returns slower to a working state, but

5.3.2 ACPI Settings

The ACPI Settings menu (BIOS Menu 4) configures the Advanced Configuration and
Power Interface (ACPI) options.

ACPI Settings

ACPI Sleep State [S3 (Suspend to RAM]

sleep state the system
will enter when the
SUSPEND button is
pressed.

----------------------



: Select Screen

↑ ↓: Select Item
Enter Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit

 ACPI Sleep State [S3 only (Suspend to RAM)]

The fields in ACPI Sleep State option cannot be changed.

BIOS Menu 4: ACPI Configuration



S3
RAM)

DEFAULT

The caches are flushed and the CPU is powered

more power is saved.

PM-BT SBC

Page 58

Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc.

Advanced

Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.

Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc.

Advanced

ESC: Exit

Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.

5.3.3 F81866 Super IO Configuration

Use the F81866 Super IO Configuration menu (BIOS Menu 5) to set or change the
configurations for the serial ports and parallel port.

F81866 Super IO Configuration

F81866 Super IO Chip F81866

> Serial Port 1 Configuration
> Serial Port 2 Configuration

BIOS Menu 5: F81866 Super IO Configuration

5.3.3.1 Serial Port n Configuration

Use the Serial Port n Configuration menu (BIOS Menu 6) to configure the s erial port n.

Set Parameters of Serial
Port 1 (COMA)

---------------------



: Select Screen

↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit

Serial Port n Configuration

Serial Port [Enabled]

Device Settings IO=3F8h; IRQ=4

Change Settings [Auto]
Transfer Mode [RS232]

BIOS Menu 6: Serial Port n Configuration Menu

Enable or Disable Serial
Port (COM)

---------------------



: Select Screen

↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit

PM-BT SBC

Page 59

5.3.3.1.1 Serial Port 1 Configuration

 Serial Port [Enabled]

Use the Serial Port option to enable or disable the serial port.



Disabled



Enabled DEFAULT

 Change Settings [Auto]

Use the Change Settings option to change the serial port IO port address and interrupt
address.



Auto DEFAULT







IO=3F8h;
IRQ=4

IO=3F8h;
IRQ=3, 4

IO=2F8h;
IRQ=3, 4

Disable the serial port
Enable the serial port

The serial port IO port address and int err upt add re ss
are automatically detected.

Serial Port I/O port address is 3F8h and the interrupt
address is IRQ4

Serial Port I/O port address is 3F8h and the interrupt
address is IRQ3, 4

Serial Port I/O port address is 2F8h and the interrupt
address is IRQ3, 4





IO=3E8h;
IRQ=3, 4

IO=2E8h;
IRQ=3, 4

Serial Port I/O port address is 3E8h a nd the i nter rupt
address is IRQ3, 4

Serial Port I/O port address is 2E8h a nd the i nter rupt
address is IRQ3, 4

PM-BT SBC

Page 60

 Transfer Mo d e [RS232]

Use the Transfer Mode option to select the Serial Port 1 signaling mode.



RS422



RS232 DEFAULT



RS485

5.3.3.1.2 Serial Port 2 Configuration

 Serial Port [Enabled]

Use the Serial Port option to enable or disable the serial port.



Disabled



Enabled DEFAULT

 Change Settings [Auto]

Use the Change Settings option to change the serial port IO port address and interrupt
address.

Serial Port 1 signaling mode is RS-422
Serial Port 1 signaling mode is RS-232
Serial Port 1 signaling mode is RS-485

Disable the serial port
Enable the serial port



Auto DEFAULT



IO=2F8h;
IRQ=3



IO=3F8h;
IRQ=3, 4



IO=2F8h;
IRQ=3, 4



IO=3E8h;
IRQ=3, 4



IO=2E8h;
IRQ=3, 4

The serial port IO port address and int err upt add re ss
are automatically detected.

Serial Port I/O port address is 2F8h and the interrupt
address is IRQ3

Serial Port I/O port address is 3F8h and the interrupt
address is IRQ3, 4

Serial Port I/O port address is 2F8h and the interrupt
address is IRQ3, 4

Serial Port I/O port address is 3E8h a nd the interrupt
address is IRQ3, 4

Serial Port I/O port address is 2E8h a nd the i nter rupt
address is IRQ3, 4

PM-BT SBC

Page 61

Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc.

Advanced

ESC: Exit

Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.

 Transfer Mo d e [RS232]

Use the Transfer Mode option to select the Serial Port 2 signaling mode.



RS422



RS232 DEFAULT



RS485

Serial Port 2 signaling mode is RS-422
Serial Port 2 signaling mode is RS-232
Serial Port 2 signaling mode is RS-485

5.3.4 F81866 H/W Monitor

The F81866 H/W Monitor menu (BIOS Menu 7) displays operating temperature, fan
speeds and system voltages..

PC Health Status

CPU temperature : +46ºC
System temperature : +46ºC
CPU_CORE : +0.744 V
+5V : +4.750 V
+12V : N/A
DDR : +1.355 V
+5VSB : +4.704 V
+3.3V : +3.296 V
+3.3VSB : +3.296 V

---------------------



: Select Screen

↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit

BIOS Menu 7: F81866 H/W Monitor

 PC Health Status

The following system parameters and values are shown. The system parameters that are
monitored are:

 System Temperatures:

o CPU Temperature
o System Temperature

 Voltages:

PM-BT SBC

Page 62

Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc.

Advanced

ESC Exit

Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.

The real time clock (RTC) cannot generate a wake

o CPU_CORE
o +5V
o +12V
o DDR
o +5VSB
o +3.3V
o +3.3VSB

5.3.5 RTC Wake Settings

The RTC Wake Settings menu (BIOS Menu 8) conf igure s RTC wake event .

Wake system with Fixed Time [Disabled]

BIOS Menu 8: RTC Wake Settings

 Wake system with Fixed Time [Disabled]

Use the Wake system with Fixed Time option to enable or disable the system wake on

Enable or disable System
wake on alarm event. When
enabled, System will
wake on the
date::hr::min::sec
specified

----------------------



: Select Screen

↑ ↓: Select Item
Enter Select
F1 General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save

alarm event.



Disabled D



Enabled

EFAULT

event
If selected, the Wake up every day option appears

PM-BT SBC

Page 63

every day at the specified time. Besides, the

appear with values that can be

Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc.

Advanced

Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.

5.3.6 Serial Port Console Redirection

The Serial Port Console Redirection menu (BIOS Menu 9) allows the console

allowing you to enable to disable the sy st em t o wake

following options
selected:

Wake up date
Wake up hour
Wake up minute
Wake up second
After setting the alarm, the computer turns itself on

from a suspend state when the alarm goes off.

redirection options to be configured. Console redirection allows users to maintain a
system remotely by re-directing keyboard input and text output through the serial port.

COM1

Console Redirection [Disabled]

> Console Redirection Settings

COM2

Console Redirection [Disabled]

> Console Redirection Settings

BIOS Menu 9: Serial Port Console Redirection

Console Redirection
Enable or Disable

---------------------



: Select Screen

↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit

PM-BT SBC

Page 64

 Console Redirection [Disabled]

Use Console Redirection option to enable or disable the con sole redirection function.



Disabled DEFAULT



Enabled

The following options are available in the Console Redirection Settings submenu when
the Console Redirection option is enabled.

 Terminal Type [ANSI]

Use the Terminal Type option to specify the remote termi nal type.



VT100



VT100+



VT-UTF8



ANSI DEFAULT

 Bits per second [115200]

Disabled the console redirection function
Enabled the console redirection function

The target terminal type is VT100
The target terminal type is VT100+
The target terminal type is VT-UTF8
The target terminal type is ANSI

Use the Bits per second option to specify the serial port transmission speed. The speed
must match the other side. Long or noisy lines may require lower speeds.



9600



19200



38400



57600



115200 DEFAULT

 Data Bits [8]

Use the Data Bits option to specify the number of data bits.



7



8 DEFAULT

Sets the serial port transmission speed at 9600.
Sets the serial port transmission speed at 19200.
Sets the serial port transmission speed at 38400.
Sets the serial port transmission speed at 57600.
Sets the serial port transmission speed at 115200.

Sets the data bits at 7.
Sets the data bits at 8.

PM-BT SBC

Page 65

The parity bit is always 1. This option does not

 Parity [None]

Use the Parity option to specify the parity bit that can be sent with the data bits for
detecting the transmission errors.



None DEFAULT



Even



Odd



Mark



Space

 Stop Bits [1]

Use the Stop Bits option to specify the number of stop bits used to indicate the end of a
serial data packet. Communication with slow devices may require more than 1 stop bit.



1 DEFAULT

No parity bit is sent with the data bits.
The parity bit is 0 if the number of ones in the data

bits is even.
The parity bit is 0 if the number of ones in the data

bits is odd.

provide error detection.
The parity bit is always 0. This option does not

provide error detection.

Sets the number of stop bits at 1.



2

Sets the number of stop bits at 2.

PM-BT SBC

Page 66

Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc.

Advanced

crashes. Please install

service before enabling

ESC: Exit

Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.

5.3.7 iEi Feature

Use the iEi Feature menu (BIOS Menu 10) to configure One Key Recovery function.

iEi Feature

Auto Recovery Function [Disabled]

BIOS Menu 10: iEi Feature

 Auto Recovery Function [Disabled]

Auto Recovery Function
Reboot and recover
system automatically
within 10 min, when OS

Auto Recovery API

this function.

---------------------



: Select Screen

↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit

Use the Auto Reco very Function BIOS option to enable or disable the auto recovery
function of the IEI One Key Recovery.



Disabled DEFAULT



Enabled

Auto recovery function disabled
Auto recovery function enabled

PM-BT SBC

Page 67

Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc.

Advanced

When enabled, a VMM can

Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.

5.3.8 CPU Configuration

Use the CPU Configuration menu (BIOS Menu 11) to view detailed CPU specifications
or enable the Intel Virtualization Technology.

CPU Information

Intel(R) Celeron(R) CPU N2807 @ 1.58GHz
CPU Signature 30678
Microcode Patch 836
Max CPU Speed 1580 MHz
Min CPU Speed 500 MHz
Processor Cores 2
Intel HT Technology Not Supported
Intel VT-x Technology Supported

L1 Data Cache 24 kB x 2
L1 Code Cache 32 kB x 2
L2 Cache 1024 kB x 1
L3 Cache Not Present
64-bit Supported

Intel Virtualization Technology [Disabled]
EIST [Enabled]
CPU C state Report [Disabled]

utilize the additional
hardware capabilities
provided by Vanderpool
Technology.

----------------------



: Select Screen

↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit

 Intel Virtualization Technology [Disabled]

Use the Intel Virtualization Technology option to enable or disable virtualization on the
system. When combined with third party software, Intel® Virtualization technology allows
several OSs to run on the same system at the same time.

BIOS Menu 11: CPU Configuration



Disabled DEFAULT



Enabled

Disables Intel Virtualizatio n Technology.
Enables Intel Virtualization Technology .

PM-BT SBC

Page 68

Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc.

Advanced

Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.

 EIST [Enabled]

Use the EIST optio n to enable o r disable the Enhanced Intel® SpeedStep Technology (EIST).



Disabled



Enabled DEFAULT

 CPU C State Report [Disabled]

Use the CPU C State Report option to enable or disable CPU power management which
allows CPU to go to C states when it is not 100% utilized.



Disabled DEFAULT



Enabled

5.3.9 IDE Configuration

Use the IDE Configuration menu (BIOS Menu 12) to change and/or s et the conf igurati on
of the SATA devices installed in the system.

Disables Enhanced Intel® SpeedSt ep Technology
Enables Enhanced Intel® S peedStep Technology

Disables CPU power management
Enables CPU power management

IDE Configuration

Serial-ATA (SATA) [Enabled]
SATA Mode [AHCI Mode]

SATA1
SM651GE8 BB (7.9GB)

SATA2
Not Present

BIOS Menu 12: IDE Configuration

Enable or disable SATA
Device.

---------------------



: Select Screen

↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit

PM-BT SBC

Page 69

Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc.

Advanced

disables legacy support

ESC: Exit

Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.

 Serial-ATA (SATA) [Enabled]

Use the Serial-ATA (SATA) option to configure the SATA controller.



Enabled DEFAULT



Disabled

 SATA Mode [AHCI Mode]

Use the SATA Mode option to configure SATA devices as n ormal IDE devices.



IDE Mode



AHCI Mode DEFAULT

5.3.10 USB Configuration

Use the USB Configuration menu (BIOS Menu 13) to read USB configuration
information and configure the USB settin gs.

Enables the on-board SATA controller.
Disables the on-board SATA controller.

Configures SATA devices as normal IDE device.
Configures SATA devices as AHCI device.

USB Configuration

USB Devices:
1 Keyboard, 1 Hub

Legacy USB Support [Enabled]

BIOS Menu 13: USB Configuration

Enables Legacy USB
support. AUTO option

if no USB devices are
connected. DISABLE
option will keep USB
devices available only
for EFI applications.

---------------------



: Select Screen

↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit

PM-BT SBC

Page 70

 USB Devices

The USB Devices field lists the USB devices that are enabled on the system

 Legacy USB Support [Enabled]

Use the Legacy USB Support BIOS option to enable USB mouse and USB keyboard
support. Normally if this option is not enabled, any attached USB mouse or USB keyboard
does not become available until a USB compatible operating system is fully booted with all
USB drivers loaded. When this option is enabled, any attached USB mouse or USB
keyboard can control the system even when there is no USB driver loaded onto the system.



Enabled DEFAULT



Disabled



Auto

5.4 Chipset

Use the Chipset menu (BIOS Menu 14) to access the North Bridge and South Bridge
configuration menus.

Legacy USB support enabled
Legacy USB support disabled
Legacy USB support disabled if no USB devices are

connected

WARNING!

Setting the wrong values for the Chipset B IOS selections in the C hipset
BIOS menu may cause the system to malfunction.

PM-BT SBC

Page 71

Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc.

Main

Advanced

Chipset

Security

Boot

Save & Exit

Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.

Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc.

Chipset

ESC: Exit

Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.

> North Bridge
> South Bridge

BIOS Menu 14: Chipset

5.4.1 North Bridge

Use the North Bridge menu (BIOS Menu 15) to configure the north bridge parameters.

North Bridge Parameters

---------------------



: Select Screen

↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit

> Intel IGD Configuration

Memory Information

Total Memory 4096 MB (LPDDR3)

DIMM1 4096 MB (LPDDR3)

BIOS Menu 15: North Bridge

Configure Intel IGD
Settings.

---------------------



: Select Screen

↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit

PM-BT SBC

Page 72

Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc.

Chipset

Select which of IGD/PCI

Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.

MB of memory used by internal graphics

5.4.1.1 Intel IGD Configuration

Use the Intel IGD Configuration submenu (BIOS Menu 16) to configure the graphics
settings.

Intel IGD Configuration

Primary Display [Auto]
DVMT Pre-Allocated [256M]
DVMT Total Gfx Mem [Max]

Primary IGFX Boot Display [VBIOS Default]

LVDS non Installed

Graphics device should
be Primary Display.

---------------------



: Select Screen

↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit

 Primary Display [Auto]

Use the Primary Display option to select the display device used by the system when it
boots. Configuration options are listed below.

 DVMT Pre-Allocated [256M]

Use the DVMT Pre-Allocated option to specify the amount of system memory that can be
used by the internal graphics device.

BIOS Menu 16: Intel IGD Configuration

 Auto D
 IGD
 PCI



64M



128M

EFAULT

64 MB of memory used by internal grap hics device
128

device

PM-BT SBC

Page 73

MB of memory used by internal graphics

internal graphics



256M DEFAULT



512M

 DVMT Total Gfx Mem [Max]

Use the DVMT Total Gfx Mem option to specify the maximum amount of memory that can
be allocated as graphics memory. Configurati on options are listed below.

 128MB
 256MB
 Max D

 Primary IGFX Boot Display [VBIOS Default]

Use the Primary IGFX Boot Display option to select the display device used by the
system when it boots. Configuration options are listed below.

EFAULT

256
device

512 MB of memory used by
device

 VBIOS Default
 CRT
 LVDS

DEFAULT

PM-BT SBC

Page 74

Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc.

Chipset

applied

Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.

5.4.2 South Bridge

Use the South Bridge menu (BIOS Menu 17) to configure the south bridge parameters.

Auto Power Button Status [Disabled (ATX)]

Restore AC Power Loss [Last State]

> PCI Express Configuration

Audio Configuration

Audio Controller [Enabled]
XHCI Mode [Auto]

BIOS Menu 17: South Bridge

 Restore on AC Power Loss [Last State ]

Use the Restore on AC Power Loss BIOS option to specify what state the system
returns to if there is a sudden loss of power to the system.

Select AC power state
when power is re­after a power failure.

---------------------



: Select Screen

↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit



Power Off



Power On



Last State DEFAULT

 Audio Controller [Enabled]

Use the Audio Controller BIOS option to enable or disable the High Definition Audio
controller.



Disabled



Enabled DEFAULT

The system remains turned of f
The system turns on
The system returns to its previous state. If it was on, it

turns itself on. If it was off, it remains off.

The High Definition Audio controller is disabled.
The High Definition Audio controller is enabled.

PM-BT SBC

Page 75

Allow the use of USB 3.0 devices prior to OS boot.

Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc.

Chipset

Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.

 XHCI Mode [Auto]

Use the XHCI Mode BIOS option to configure the USB xHCI (USB 3.0) controller.



Enabled



Disabled



Auto DEFAULT

Enable the xHCI controller.
Disable the xHCI controller.

USB 3.0 ports function as USB 3.0 ports even du ring a
reboot.

5.4.2.1 PCI Express Configuration

Use the PCI Express Configuration submenu (BIOS Menu 18) to configure the PCIe
Mini slot.

PCI Express Configuration

M_PCIE1

Speed [Auto]

Configure PCIe Port
Speed.

---------------------



: Select Screen

↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit

BIOS Menu 18: PCI Express Configuration

PM-BT SBC

Page 76

Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc.

Main

Advanced

Chipset

Security

Boot

Save & Exit

Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.

 Speed [Auto]

Use the Speed option to configure the speed of PCIe Mini slot.

 Auto D
 Gen 2
 Gen 1

EFAULT

5.5 Security

Use the Security menu (BIOS Menu 19) to set system and user passwords.

Password Description

If ONLY the Administrator’s password is set,
then this only limits access to Setup and is
only asked for when entering Setup.
If ONLY the User’s password is set, then this
is a power on password and must be entered to
boot or enter Setup. In Setup the User will
have Administrator rights.
The password length must be:
Minimum length 3
Maximum length 20

Administrator Password
User Password

HDD Security Configuration:

P0:SM651GE8 BB

Set Administrator
Password

---------------------



: Select Screen

↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit

BIOS Menu 19: Security

 Administrator Password

Use the Administrator Password to set or change a administrator password.

 User Password

Use the User Password to set or change a user pass word.

PM-BT SBC

Page 77

Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc.

Main

Advanced

Chipset

Security

Boot

Save & Exit

Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.

Allows the Number Lock on the keyboard to be
enabled automatically when the computer system
boots up. This allows the immediate use of the

the keyboard. To confirm this, the Number Lock LED

Does not enable the keyboard Number Lock

press the Number Lock key located on the upper

key pad. The Number

Lock LED on the keyboard lights up when the

5.6 Boot

Use the Boot menu (BIOS Menu 20) to configure system boot options.

Boot Configuration

Bootup NumLock State [On]
Quiet Boot [Enabled]
UEFI Boot [Disabled]
OS Selection [Window 7]

Launch PXE OpROM [Disabled]
Option ROM Messages [Force BIOS]

Boot Option Priorities

Boot Option #1 [P0:SM651GE8 BB …]

Hard Drive BBS Priorities

BIOS Menu 20: Boot

 Bootup NumLock State [On]

Use the Bootup NumLock State BIOS option to specify if the number lock setting must
be modified during boot up.

Select the keyboard
NumLock state

---------------------



: Select Screen

↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit



On DEFAULT



Off

10-key numeric keypad located on the right side of

light on the keyboard is lit.

automatically. To use the 10-keys on the keyboard,

left-hand corner of the 10-

Number Lock is engaged.

PM-BT SBC

Page 78

The system will be installed with Windows 8.x

The system will be installed with Android operating

Windows 7

 Quiet Boot [Enabled]

Use the Quiet Boot BIOS option to select the scre en display when the system boots.



Disabled



Enabled DEFAULT

 UEFI Boot [Disabled]

Use the UEFI Boot option to enable or disable to boot f rom the UEFI devices.



Enabled



Disabled DEFAULT

 OS Selection [Windows 7]

Use the OS Selection BIOS option to select an operating system (OS) before installing
OS.



Windows

8.x

Normal POST messages displayed
OEM Logo displayed instead of POST m essages

Boot from UEFI devices is enabled.
Boot from UEFI devices is disabled.

operating system.



Android

system.



Windows 7 DEFAULT

The system will be installed with
operating system.

WARNING:

Before installing the operating system, the user must enter the Boot
BIOS menu and choose which operating system will be installed.
Otherwise, the OS installation may fail.

PM-BT SBC

Page 79

Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc.

Main

Advanced

Chipset

Security

Boot

Save & Exit

Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.

 Launch PXE OpROM [Disabled]

Use the Launch PXE OpROM option to enable or disable boot option for legacy network
devices.



Disabled DEFAULT



Enabled

 Option ROM Messages [Force BIOS]

Use the Option ROM Messages option to set the Option ROM display mode.





Force
BIOS

Keep
Current

DEFAULT

5.7 Save & Exit

Use the Safe & Exit menu (BIOS Menu 21) to load default BIOS values, optimal failsafe
values and to save configuration changes.

Ignore all PXE Option ROMs
Load PXE Option ROMs.

Sets display mode to force BIOS.

Sets display mode to current.

Save Changes and Reset

Discard Changes and Reset

Restore Defaults
Save as User Defaults
Restore User Defaults

BIOS Menu 21: Save & Exit

Exit the system after
saving the changes.

---------------------



: Select Screen

↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit

PM-BT SBC

Page 80

 Save Changes and Reset

Use the Save Changes and Reset option to save the changes made to the BIOS options
and reset the system.

 Discard Changes and Reset

Use the Discard Changes and Reset option to exit the system without saving the
changes made to the BIOS configuration setup program.

 Restore Defaults

Use the Restore Defaults option to load the optimal default values for each of the
parameters on the Setup menus. F3 key can be used for this operation.

 Save as User Defaults

Use the Save as User Defaults option to save the changes done so far as user defaults.

 Restore User Defaults

Use the Restore User Defaults option to restore the user defaults to all the setup options.

PM-BT SBC

Page 81

Appendix

A

A Regulatory Compliance

PM-BT SBC

Page 82

If the user modifies and/or installs other devices in the equipment, the CE conformity

5 of the FCC Rules. Operation is subject to the

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this

DECLARATION OF CONFORMITY

This equipment has been t ested and fou nd to comply with specifi cations for CE marking.

declaration may no longer apply.

FCC WARNING

This equipment complies with Part 1
following two conditions:

 This device may not cause harmful interference, and
 This device must accept any interference received, including interference

that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class A digital

reasonable protection against harmful interference when the equipment is operated in a

equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.

PM-BT SBC

Page 83

B Product Disposal

Appendix

B

PM-BT SBC

Page 84

Dispose of used batteries according to instructions and local

CAUTION:

Risk of explosion if battery is replaced by an incorrect type. Only
certified engineers should replace the on-board battery.

regulations.

 Outside the European Union–If you wish to dispose of used electrical and

electronic products outside the Europea n Union, please contact your local
authority so as to comply with the correct dispo sal m ethod.

 Within the European Union–The device that produc es less waste and is

easier to recycle is classified as electronic devi ce in terms of the European
Directive 2012/19/EU (WEEE), and must not be di sposed of as domestic
garbage.

EU-wide legislation, as implemented in each Membe r State, require s that
waste electrical and electronic products carrying the mark (left) must be
disposed of separately from normal household waste. This includes
monitors and electrical accessories, such as signal cables or power

cords. When you need to dispose of your device, please follow the
guidance of your local authority, or ask the shop where you purchased the product. The
mark on electrical and electronic products only applies to the current European Union
Member States.

Please follow the national guidelines for elect rical and electronic product disposal.

PM-BT SBC

Page 85

Appendix

C

C BIOS Options

PM-BT SBC

Page 86



































































Below is a list of BIOS configuration options in the B IOS chapter.

System Date [xx/xx/xx] ........................................................................................................ 54

System Time [xx:xx:xx] ....................................................................................................... 54

Security Device Support [Disable] ..................................................................................... 56

ACPI Sleep State [S3 only (Suspend to RAM)] ................................................................. 57

Serial Port [Enabled] ............................................................................................................ 59

Change Settings [Auto] ....................................................................................................... 59

Transfer Mode [RS232] ........................................................................................................ 60

Serial Port [Enabled] ............................................................................................................ 60

Change Settings [Auto] ....................................................................................................... 60

Transfer Mode [RS232] ........................................................................................................ 61

PC Health Status .................................................................................................................. 61

Wake system with Fixed Time [Disabled] .......................................................................... 62

Console Redirection [Disabled] ......................................................................................... 64

Terminal Type [ANSI] ........................................................................................................... 64

Bits per second [115200] ..................................................................................................... 64

Data Bits [8] .......................................................................................................................... 64

Parity [None] ......................................................................................................................... 65

Stop Bits [1] .......................................................................................................................... 65

Auto Recovery Function [Disabled] ................................................................................... 66

Intel Virtualization Technology [Disabled] ........................................................................ 67

EIST [Enabled] ...................................................................................................................... 68

CPU C State Report [Disabled] ........................................................................................... 68

Serial-ATA (SATA) [Enabled] .............................................................................................. 69

SATA Mode [AHCI Mode] .................................................................................................... 69

USB Devices ......................................................................................................................... 70

Legacy USB Support [Enabled] .......................................................................................... 70

Primary Display [Auto] ........................................................................................................ 72

DVMT Pre-Allocated [256M] ................................................................................................ 72

DVMT Total Gfx Mem [Max] ................................................................................................. 73

Primary IGFX Boot Display [VBIOS Default] ..................................................................... 73

Restore on AC Power Loss [Last State] ............................................................................ 74

Audio Controller [Enabled] ................................................................................................. 74

XHCI Mode [Auto] ................................................................................................................ 75

PM-BT SBC

Page 87





























Speed [Auto] ......................................................................................................................... 76

Administrator Password ..................................................................................................... 76

User Password ..................................................................................................................... 76

Bootup NumLock State [On] ............................................................................................... 77

Quiet Boot [Enabled] ........................................................................................................... 78

UEFI Boot [Disabled] ........................................................................................................... 78

OS Selection [Windows 7] ................................................................................................... 78

Launch PXE OpROM [Disabled] ......................................................................................... 79

Option ROM Messages [Force BIOS] ................................................................................. 79

Save Changes and Reset .................................................................................................... 80

Discard Changes and Reset ............................................................................................... 80

Restore Defaults .................................................................................................................. 80

Save as User Defaults ......................................................................................................... 80

Restore User Defaults ......................................................................................................... 80

PM-BT SBC

Page 88

Appendix

D

D Digital I/O Interface
