PCISA-MARK CPU Card
0-1
1
Page 2
PCISA-MARK CPU Card
REVISION HISTORY
Model Name PCISA-MARK CPU Card
Revision Number Description Date of Issue
1.0 Initial release December 2006
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event is the manufacturer liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
Product names mentioned herein are used for identification purposes only and may be
trademarks and/or registered trademarks of their respective owners.
2
Page 3
PCISA-MARK CPU Card
Table of Contents
1 INTRODUCTION................................................................................................... 15
1.1 PCISA-MARK CPU CARD OVERVIEW................................................................... 16
1.1.1 PCISA-MARK Models...................................................................................... 16
1.1.2 PCISA-MARK Benefits..................................................................................... 16
1.1.3 PCISA-MARK Features ................................................................................... 17
1.2 PCISA-MARK OVERVIEW...................................................................................... 18
1.2.1 PCISA-MARK Connectors ............................................................................... 20
1.2.2 Technical Specifications................................................................................... 21
2 DETAILED SPECIFICATIONS ........................................................................... 23
2.1 OVERVIEW ............................................................................................................... 24
2.2 COMPATIBLE IEI BACKPLANES ................................................................................ 24
2.3 BOARD DIMENSIONS ................................................................................................ 24
2.4 CPU SUPPORT.......................................................................................................... 24
2.5 VIA VT82C686B SYSTEM CHIPSET ........................................................................ 25
2.6 DATA FLOW.............................................................................................................. 26
2.7 LCD AND FLAT PANEL DISPLAY SUPPORT................................................................ 27
2.7.1 High Screen Resolution Display Support......................................................... 27
2.8 MEMORY SUPPORT................................................................................................... 28
2.9 PCI BUS INTERFACE SUPPORT ................................................................................. 28
2.10 E
2.11 DRIVE INTERFACES ................................................................................................ 30
THERNET.............................................................................................................. 28
2.10.1 Ethernet Controller Overview........................................................................ 28
2.10.2 Ethernet Controller Features......................................................................... 29
2.11.1 SATA Drives.................................................................................................... 30
2.11.2 IDE HDD Interfaces....................................................................................... 30
2.11.3 Floppy Disk Drive (FDD) .............................................................................. 30
2.11.4 Compact Flash ............................................................................................... 30
2.12 SERIAL PORTS ........................................................................................................ 31
2.13 A
UDIO CODEC ........................................................................................................ 31
2.13.1 Audio Codec Overview................................................................................... 31
2.13.2 Audo Codec Features..................................................................................... 31
0-3
3
Page 4
PCISA-MARK CPU Card
2.14 R
EAL TIME CLOCK................................................................................................. 32
2.15 SYSTEM MONITORING............................................................................................ 32
2.16 BIOS ..................................................................................................................... 33
2.17 INFRARED DATA ASSOCIATION (IRDA) INTERFACE ................................................ 33
2.18 USB INTERFACES................................................................................................... 33
2.19 OPERATING TEMPERATURE AND TEMPERATURE CONTROL..................................... 33
2.20 POWER CONSUMPTION........................................................................................... 33
2.21 PACKAGED CONTENTS AND OPTIONAL ACCESSORY ITEMS..................................... 35
2.21.1 Package Contents........................................................................................... 35
2.21.2 Optional Accessory Items............................................................................... 35
3 CONNECTORS AND JUMPERS ......................................................................... 37
3.1 PERIPHERAL INTERFACE CONNECTORS .................................................................... 38
3.1.1 PCISA-MARK Layout ...................................................................................... 38
3.1.2 Peripheral Interface Connectors ..................................................................... 39
3.1.3 External Peripheral Interface Connectors....................................................... 40
3.1.4 On-board Jumpers ........................................................................................... 41
3.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 41
3.2.1 Audio CD In Connector ................................................................................... 41
3.2.2 Audio Connector (Line out, Line in & MIC in)................................................ 43
3.2.3 Battery Connector............................................................................................ 44
3.2.4 Compact Flash® Connector ............................................................................. 45
3.2.5 CPU Fan Connector ........................................................................................ 48
3.2.6 Digital Input/Output (DIO) Connector............................................................ 49
3.2.7 DIMM socket.................................................................................................... 51
3.2.8 External LED Connector ................................................................................. 53
3.2.9 Floppy Disk Connector .................................................................................... 54
3.2.10 IDE Connector (Primary) .............................................................................. 56
3.2.11 IDE Connector (Secondary)........................................................................... 58
3.2.12 Inverter Connector......................................................................................... 60
3.2.13 IrDA Interface Connector .............................................................................. 62
3.2.14 Keyboard/Mouse Connector .......................................................................... 63
3.2.15 LVDS LCD Connector ................................................................................... 65
3.2.16 Parallel Port Connector ................................................................................ 67
3.2.17 Power Button Connector................................................................................ 68
3.2.18 Power Connector ........................................................................................... 70
4
Page 5
PCISA-MARK CPU Card
3.2.19 PS-ON Connector .......................................................................................... 72
3.2.20 Reset Button Connector ................................................................................. 73
3.2.21 RS-232 Serial Port (COM1 & COM2) Connectors ....................................... 75
3.2.22 Serial ATA Drive Connectors......................................................................... 76
3.2.23 TFT LCD Connector ...................................................................................... 78
3.2.24 USB Connectors (8-pin and 4-pin) ................................................................ 80
3.3 E
XTERNAL PERIPHERAL INTERFACE CONNECTOR PANEL ......................................... 82
3.3.1 LAN Connectors............................................................................................... 83
3.3.2 Mini-DIN 6 PS/2 Connector .......................................................................... 84
3.3.3 USB Connector ................................................................................................ 85
3.3.4 VGA connector................................................................................................. 86
4 INSTALLATION .................................................................................................... 89
4.1 ANTI-STATIC PRECAUTIONS...................................................................................... 90
4.2 INSTALLATION CONSIDERATIONS ............................................................................. 90
4.2.1 Installation Notices .......................................................................................... 90
4.3 UNPACKING.............................................................................................................. 91
4.3.1 Unpacking Precautions.................................................................................... 91
4.3.2 Checklist........................................................................................................... 92
4.4 PCISA-MARK CPU CARD INSTALLATION ............................................................. 93
4.4.1 Preinstalled Component................................................................................... 93
4.4.2 Components to Install ...................................................................................... 93
4.4.3 DIMM Module Installation .............................................................................. 94
4.5 PERIPHERAL DEVICE CONNECTION .......................................................................... 96
4.5.1 IDE Disk Drive Connectors ............................................................................. 96
4.5.2 COM1-COM2 RS-232 Serial Port Installation................................................ 98
4.5.3 LCD Backlight Installation .............................................................................. 98
4.5.4 Power Connection............................................................................................ 98
4.5.5 TFT LVDS LCD Installation ............................................................................ 98
4.5.6 TFT TTL LCD Installation ............................................................................... 99
UMPER SETTINGS .................................................................................................... 99
4.6 J
4.6.1 CF Card Function Setup Jumper................................................................... 101
4.6.2 Clear CMOS Jumper...................................................................................... 101
4.6.3 Flat Panel Power Select................................................................................. 102
4.6.4 PCI VIO Voltage Select Jumper ..................................................................... 103
4.7 I
NSTALLING A COMPACT FLASH® CARD ................................................................. 103
0-5
5
Page 6
PCISA-MARK CPU Card
4.8 I
NSERTING THE CPU CARD.................................................................................... 104
4.9 REAR PANEL CONNECTORS .................................................................................... 105
4.9.1 Keyboard and Mouse Connection.................................................................. 105
4.9.2 Ethernet Connection ...................................................................................... 105
4.9.3 USB Connection............................................................................................. 105
4.9.4 VGA Port Installation .................................................................................... 105
5 BIOS SETTINGS .................................................................................................. 107
5.1 INTRODUCTION ...................................................................................................... 108
5.1.1 Starting Setup................................................................................................. 108
5.1.2 Using Setup .................................................................................................... 108
5.1.3 Getting Help................................................................................................... 109
5.1.4 Unable to Reboot After Configuration Changes............................................ 109
5.1.5 Main BIOS Menu ............................................................................................110
5.2 STANDARD CMOS FEATURES .................................................................................112
5.2.1 IDE Primary Master/Slave .............................................................................115
5.3 ADVANCED BIOS FEATURES...................................................................................118
5.4 ADVANCED CHIPSET FEATURES.............................................................................. 127
5.5 INTEGRATED PERIPHERALS .................................................................................... 136
5.6 POWER MANAGEMENT SETUP................................................................................ 144
5.6.1 Power Management ....................................................................................... 147
5.6.2 Wake Up Events.............................................................................................. 150
5.7 PNP/PCI CONFIGURATIONS ................................................................................... 156
5.8 PC HEALTH STATU S ............................................................................................... 161
REQUENCY /VOLTAGE CONTROL .......................................................................... 163
5.9 F
6 DRIVER INSTALLATION.................................................................................. 165
6.1 AVAILABLE SOFTWARE DRIVERS ............................................................................ 166
6.2 VIA 4 IN 1 CHIPSET DRIVER INSTALLATION (VIA SERVICE PACK V4.3) ................ 166
6.3 REALTEK AUDIO DRIVER INSTALLATION ................................................................ 174
6.3.1 LAN Driver Installation ................................................................................. 182
AH – 6FH Sub-function:.............................................................................................. 192
INDEX............................................................................................................................ 221
6
Page 7
PCISA-MARK CPU Card
List of Figures
Figure 1-1: PCISA-MARK Overview...........................................................................18
Figure 1-2: PCISA-MARK Overview (Solder Side) ...................................................19
Figure 2-1: Data Flow Block Diagram........................................................................26
Figure 3-1: Connector and Jumper Locations .........................................................38
Figure 3-2: Audio CD In Connector Location ...........................................................42
Figure 3-3: Audio Connector Location......................................................................43
Figure 3-4: Battery Connector Location ...................................................................45
Figure 3-5: Compact Flash® Connector Location ....................................................46
Figure 3-6: CPU Fan Connector Location.................................................................48
Figure 3-7: Digital I/O Connector Location...............................................................50
Figure 3-8: DIMM Socket Location ............................................................................52
Figure 3-9: External LED Connector Location .........................................................53
Figure 3-10: 34-pin FDD Connector Location...........................................................55
Figure 3-11: Primary IDE Device Connector Location.............................................57
Figure 3-12: Secondary IDE Device Connector Location........................................59
Figure 3-13: Inverter Connector Location ................................................................61
Figure 3-14: IrDA Connector Location ......................................................................62
Figure 3-15: Keyboard/Mouse Connector Location.................................................64
Figure 3-16: LVDS LCD Connector Location............................................................66
Figure 3-17: Parallel Port Connector Location.........................................................67
Figure 3-18: Power Button Connector Location ......................................................69
Figure 3-19: Power Connector Location...................................................................70
Figure 3-20: PS-ON Signal Connector Location ......................................................72
Figure 3-21: Reset Button Connector Location .......................................................74
Figure 3-22: RS-232 Serial Port Connectors Location ............................................76
Figure 3-23: SATA Drive Connector Locations........................................................77
Figure 3-24: TFT LCD TTL Connector Location .......................................................78
Figure 3-25: 8-pin USB Connector Location ............................................................81
Figure 3-26: External Peripheral Interface Connector Panel ..................................82
0-7
7
Page 8
PCISA-MARK CPU Card
Figure 3-27: RJ-45 Ethernet Connector ....................................................................84
Figure 3-28: Mini-DIN 6 PS/2 Connector ...................................................................85
Figure 3-29: VGA Connector ......................................................................................86
Figure 4-1: Installing the DIMM Module ....................................................................94
Figure 4-2: Connection of 44-Pin IDE Connector.....................................................97
Figure 4-3: Connection of 40-Pin IDE Connector.....................................................97
Figure 4-4: Jumper Locations................................................................................. 100
Figure 4-5: CompactFlash® Card Installation........................................................ 104
Figure 6-1: Access the 1-4in1 Folder ..................................................................... 167
Figure 6-2: Setup Utility Icon .................................................................................. 167
Figure 6-3: VIA Chipset Driver Installation Welcome Screen .............................. 168
Figure 6-4: Readme Information ............................................................................. 169
Figure 6-5: VIA Chipset Driver Installation Type................................................... 170
Figure 6-6: Driver Selection .................................................................................... 171
Figure 6-7: VIA PCI IDE Bus Driver Selection ....................................................... 172
Figure 6-8: AGP Driver Selection............................................................................ 173
Figure 6-9: Restart the Computer ........................................................................... 174
Figure 6-10: Access the Audio Driver Folder ........................................................ 175
Figure 6-11: Setup Utility Icon ................................................................................ 175
Figure 6-12: Audio Driver Install Shield Wizard Starting ..................................... 175
Figure 6-13: Audio Driver Setup Preparation ........................................................ 176
Figure 6-14: Audio Driver Welcome Screen .......................................................... 177
Figure 6-15: Audio Driver Software Configuration ............................................... 178
Figure 6-16: Audio Driver Digital Signal ................................................................ 179
Figure 6-17: Audio Driver Installation Begins ....................................................... 180
Figure 6-18: Audio Driver Installation Complete................................................... 181
Figure 6-19: Access the LAN Driver Folder........................................................... 182
Figure 6-20: Setup Utility Icon ................................................................................ 182
8
Figure 6-21: LAN Driver Welcome Screen ............................................................. 183
Figure 6-22: LAN Driver Installation Complete ..................................................... 184
Page 9
PCISA-MARK CPU Card
Figure D-1: Sound Effect Manager con.................................................................. 201
Figure D-2: Sound Effect Manager Icon [Task Bar] ........................................... 202
Figure D-3: Sound Effect Manager Icon [Control Panel]...................................... 202
Figure D-4: Sound Effects Manager (ALC655) ...................................................... 203
0-9
9
Page 10
PCISA-MARK CPU Card
List of Tables
Table 1-1: PCISA-MARK Model Specifications ........................................................16
Table 1-2: Technical Specifications ..........................................................................22
Table 2-1: CRT and Panel Screen Resolutions Supported .....................................28
Table 2-2: Power Consumption for VIA Mark 800 MHz............................................34
Table 2-3: Power Consumption for VIA Mark 533 MHz............................................34
Table 3-1: Peripheral Interface Connectors..............................................................40
Table 3-2: External Peripheral Interface Connectors ..............................................40
Table 3-3: On-board Jumpers ....................................................................................41
Table 3-4: Audio CD In Connector Pinouts ..............................................................42
Table 3-5: Audio Connector Pinouts.........................................................................44
Table 3-6: Battery Connector Pinouts.......................................................................45
Table 3-7: Compact Flash® Connector Pinouts........................................................47
Table 3-8: CPU Fan Connector Pinouts ....................................................................49
Table 3-9: Digital I/O Connector Pinouts ..................................................................50
Table 3-10: External LED Connector Pinouts...........................................................54
Table 3-11: 34-pin FDD Connector Pinouts ..............................................................56
Table 3-12: Primary IDE Connector Pinouts.............................................................58
Table 3-13: Secondary IDE Connector Pinouts........................................................60
Table 3-14: Inverter Connector Pinouts....................................................................61
Table 3-15: IrDA Connector Pinouts..........................................................................63
Table 3-16: Keyboard/Mouse Connector Pinouts....................................................64
Table 3-17: LVDS LCD Connector Pinouts ...............................................................66
Table 3-18: Parallel Port Connector Pinouts ............................................................68
Table 3-19: Power Button Connector Pinouts..........................................................69
10
Table 3-20: Power Connector Pinouts ......................................................................71
Table 3-21: Primary IDE Connector Pinouts.............................................................71
Table 3-22: PS-ON Signal Connector Pinouts..........................................................73
Table 3-23: Reset Button Connector Pinouts...........................................................74
Table 3-24: RS-232 Serial Port Connectors Pinouts................................................76
Page 11
PCISA-MARK CPU Card
Table 3-25: SATA Drive Connector Pinouts .............................................................77
Table 3-26: TFT LCD TTL Connector Pinouts ..........................................................79
Table 3-27: CN23 USB Port Connector Pinouts .......................................................81
Table 3-28: CN24 USB Port Connector Pinouts .......................................................81
Table 3-29: LAN Pinouts.............................................................................................83
Table 3-30: RJ-45 Ethernet Connector LEDs............................................................84
Table 3-31: Mini-DIN 6 PS/2 Connector.....................................................................85
Table 3-32: USB Port Pinouts ....................................................................................86
Table 3-33: VGA Connector Pinouts .........................................................................87
Table 4-1: IEI Provided Cables...................................................................................96
Table 4-2: CF Card Function Setup Jumper Settings........................................... 101
Table 4-3: Clear CMOS Jumper Settings ............................................................... 102
Table 4-4: Flat Panel Select Jumper Settings ....................................................... 102
Table 4-5: PCI VIO Voltage Jumper Settings......................................................... 103
Table 5-1: BIOS Navigation Keys............................................................................ 109
0-11
11
Page 12
PCISA-MARK CPU Card
List of BIOS Menus
BIOS Menu 1: AwardBIOS CMOS Setup Utility ..................................................... 110
BIOS Menu 2: Standard CMOS Features ............................................................... 112
BIOS Menu 3: IDE Primary Master.......................................................................... 115
BIOS Menu 4: Advanced BIOS Features................................................................ 118
BIOS Menu 5: Advanced Chipset Features ........................................................... 127
BIOS Menu 6: Integrated Peripherals..................................................................... 136
BIOS Menu 7: Power Management Setup.............................................................. 144
BIOS Menu 8: Power Management ......................................................................... 148
BIOS Menu 9: Wake Up Events............................................................................... 151
BIOS Menu 10: IRQs Activity Monitoring............................................................... 155
BIOS Menu 11: PnP/PCI Configurations ................................................................ 156
BIOS Menu 12: IRQ Resources ............................................................................... 158
BIOS Menu 13: DMA Resources ............................................................................. 159
BIOS Menu 14: PC Health Status............................................................................ 161
BIOS Menu 15: Frequency/Voltage Control........................................................... 163
12
Page 13
PCISA-MARK CPU Card
Glossary
AC ’97 Audio Codec 97
ACPI Advanced Configuration and
Power Interface
APM Advanced Power Management
ARMD ATAPI Removable Media Device
ASKIR Amplitude Shift Keyed Infrared
ATA Advanced Technology
Attachments
BIOS Basic Input/Output System
CFII CompactFlash
CMOS Complementary Metal Oxide
Semiconductor
CPU Central Processing Unit
Codec Compressor/Decompressor
COM Serial Port
DAC Digital to Analog Converter
DDR Double Data Rate
Type 2
ICH4 I/O Controller Hub 4
L1 Cache Level 1 Cache
L2 Cache Level 2 Cache
LCD Liquid Crystal Display
LPT Parallel Port Connector
LVDS Low Voltage Differential Signaling
MAC Media Access Controller
OS Operating System
PCI Peripheral Connect Interface
PIO Programmed Input Output
PnP Plug and Play
POST Power On Self Test
RAM Random Access Memory
SATA Serial ATA
S.M.A.R.T Self Monitoring Analysis and
Reporting Technology
SPD Serial Presence Detect
DIMM Dual Inline Memory Module
DIO Digital Input/Output
DMA Direct Memory Access
EIDE Enhanced IDE
EIST Enhanced Intel SpeedStep
Technology
FDD Floppy Disk Drive
FDC Floppy Disk Connector
FFIO Flexible File Input/Output
FIFO First In/First Out
FSB Front Side Bus
IrDA Infrared Data Association
HDD Hard Disk Drive
IDE Integrated Data Electronics
I/O Input/Output
S/PDI Sony/Philips Digital Interface
SDRAM Synchronous Dynamic Random
Access Memory
SIR Serial Infrared
UART Universal Asynchronous
Receiver-transmitter
USB Universal Serial Bus
VGA Video Graphics Adapter
0-13
13
Page 14
PCISA-MARK CPU Card
THIS PAGE IS INTENTIONALLY LEFT BLANK
Page 14
IEI® Technology, Corp.
Page 15
PCISA-MARK CPU Card
Chapter
1
1 Introduction
Page 15
Page 16
PCISA-MARK CPU Card
1.1 PCISA-MARK CPU Card Overview
The PCISA form factor PCISA-MARK is fully equipped with advanced multi-mode I/Os.
The PCISA-MARK is designed for system manufacturers, integrators, and VARs that want
performance, reliability, and quality at a reasonable price.
1.1.1 PCISA-MARK Models
The PCISA-MARK series has two models:
PCISA-MARK-533-R10
PCISA-MARK-800-R10
The specifications for the two models are shown in Table 1-1.
PCISA-MARK 533-R10 800-R10
CPU Speed 533MHz 800MHz
128 MB PC133MHz onboard memory YES YES
CRT/TFT/LVDS YES YES
Dual LAN YES YES
Audio YES YES
Dual SATA-150 YES YES
Table 1-1: PCISA-MARK Model Specifications
1.1.2 PCISA-MARK Benefits
Some of the PCISA-MARK benefits include:
High performance, cost-effective, energy efficient
Flexible display options
Multiple storage option integration including
o
40-pin IFM or 3.5” HDD
Page 16
o 34-pin floppy disk drive (FDD) support
o IDE channel CFII socket for embedded OS
o Dual SATA ports with ALI M5283 RAID 0 and RAID 1 support
IEI® Technology, Corp.
Page 17
PCISA-MARK CPU Card
1.1.3 PCISA-MARK Features
Some of the PCISA-MARK features are listed below:
Complies with PCISA form factor
Complies with RoHS
Contains an embedded VIA Mark CoreFusion™ processor
Contains onboard 128MB PC133MHz memory
Supports a 168-pin PC100/133MHz SDRAM DIMM with a maximum capacity
of 512MB
Supports CRT, 24-bit TFT/18-bit LVDS displays
Supports IDE, dual LAN, five USB 1.1 devices, and two RS-232 serial port
connectors
Supports two SATA channels with transfer rates up to 150Mb/s
Page 17
Page 18
PCISA-MARK CPU Card
1.2 PCISA-MARK Overview
Figure 1-1: PCISA-MARK Overview
Page 18
IEI® Technology, Corp.
Page 19
PCISA-MARK CPU Card
Figure 1-2: PCISA-MARK Overview (Solder Side)
Page 19
Page 20
PCISA-MARK CPU Card
1.2.1 PCISA-MARK Connectors
The PCISA-MARK has the following connectors onboard:
1 x 4-pin AT/ATX power connector
1 x 168-pin DDR DIMM socket
1 x Audio CD In connector
1 x Audio connector
1 x Battery connector
1 x Compact Flash
1 x CPU fan connector
1 x Digital I/O connector
1 x External LED connector
card socket
1 x Floppy connector
2 x IDE interface connectors (1 x 40-pin and 1 x 44-pin)
1 x Inverter connector
1 x Infrared connector
1 x Keyboard / mouse connector
1 x LCD LVDS interface connector (dual-channel)
1 x LCD TTL interface connector
1 x Parallel port connector
1 x PS-ON connector
1 x Power button switch
1 x Reset button switch
2 x RS-232 serial port connectors
2 x Serial ATA connectors
2 x USB 1.1 connectors
The PCISA-MARK has the following external peripheral interface connectors:
Page 20
2 x Ethernet connectors
1 x PS/2 keyboard/mouse connector
1 x USB 1.1 connector
1 x VGA connector
IEI® Technology, Corp.
Page 21
PCISA-MARK CPU Card
The PCISA-MARK has the following onboard jumpers:
CF card function setup
Clear CMOS
Flat panel power select
PCI VIO voltage select
The location of these connectors on the CPU card can be seen in Figure 1-1. These
connectors are fully described in Chapter 3.
1.2.2 Technical Specifications
PCISA-MARK technical specifications are listed in Table 1-2. Detailed descriptions of
each specification can be found in Chapter 2.
SPECIFICATION DESCRIPTION
CPUs Supported VIA MARK 533/800 MHz
FSB 133 MHz
North Bridge Chipset VIA MARK
South Bridge Chipset VIA VT82C686B
Memory 128MB PC133/MHz onboard memory
One 168-pin PC133/100MHz SDRAM DIMM up to 512 MB
Supports 640MB maximum memory
Digital I/O 4 input / 4output by super I/O
Super I/O VIA VT82C686B
Display CRT / 24-bit TFT / dual channel 18-bit LVDS integrated in
VIA MARK
Power Support AT/ATX power support
Page 21
Page 22
PCISA-MARK CPU Card
SPECIFICATION DESCRIPTION
Power Consumption +5V @ 2.52A (VIA Mark 533MHz / PC133MHz 512MB)
+5V @ 2.94A (VIA Mark 800MHz / PC133MHz 512MB) 3D
Mark
Watchdog Timer Software programmable
1~255 sec. system reset
IrDA One integrated IrDA connector supports either a Serial
Infrared (SIR) or an Amplitude Shift Keyed IR (ASKIR)
interface
IDE Interface Two IDE channels support four Ultra ATA 100/66/33 devices
Serial ATA (SATA) Two SATA channels with 150Mb/s transfer rates
Supports RAID 0, 1 with ALI M5283
Floppy Disk Drive (FDD) Supports one FDD
SSD Compact Flash® (CF) II
USB Interfaces Supports four USB 1.1 devices
Serial Ports Two RS-232 COM ports
Audio Interface Realtek ALC655 with AC 97 codec
Ethernet Dual Realtek 10/100 Base-T RTL8100C
BIOS AWARD
Physical Dimensions 185mm x 127.6mm
Operating Temperature Minimum: 0ºC (32°F) - Maximum: 60°C (140°F)
Operating Humidity Minimum: 5% - Maximum: 95% non-condensing
Page 22
Weight GW: 1.0Kg
Table 1-2: Technical Specifications
IEI® Technology, Corp.
Page 23
PCISA-MARK CPU Card
2
Chapter
2
Detailed Specifications
Page 23
Page 24
PCISA-MARK CPU Card
2.1 Overview
This chapter describes the specifications and onboard features of the PCISA-MARK CPU
card in detail.
2.2 Compatible IEI Backplanes
The PCISA-MARK CPU card is compatible with all IEI PCI backplanes. For more
information on these backplanes, please visit the IEI website or contact your CPU card
reseller or vendor.
2.3 Board Dimensions
The dimensions of the board are listed below:
Length: 185mm
Width: 127.6mm
2.4 CPU Support
The PCISA-MARK has a preinstalled 800MHz or 533MHz, ultra low voltage (ULV) VIA®
MARK processor. The VIA Mark CoreFusion™ processor platform offers power efficiency,
native x86 performance and advanced hardware based security combined with legacy
support. Based on the 'Nehemiah' core and 0.13u process technology, the VIA Mark
CoreFusion™ processor platform is scalable to 800MHz with a maximum TDP of just 8
watts facilitating silent, fanless designs.
Some of the VIA MARK features are listed below:
Rich Integration:- Combining the VIA 'Nehemiah' processor core architecture
with a feature rich Northbridge in a single package, the VIA Mark
CoreFusion™ processor platform has rich x86 integration, offers full legacy
Page 24
support advanced integrated graphics, a military-grade hardware security
engine and unparalleled connectivity.
S3 Graphics Unichrome Pro Graphics Core:- Integrating the S3 Graphics
ProSavage4 graphics core, the VIA Mark CoreFusion™ processor platform
boasts dual independent display support, an integrated LVDS/DVI transmitter,
a video capture port and display resolutions of up to 1600 x 1200 pixels.
IEI® Technology, Corp.
Page 25
PCISA-MARK CPU Card
VIA PadLock Security Engine:- Utilizing the advanced native security
feature set of the VIA 'Nehemiah' processor core architecture named the VIA
PadLock Security Engine, the VIA Mark CoreFusion™ processor platform
offers developers a real-time military-grade security engine that integrates a
AES cipher engine and quantum based random number generator to help
protect data exchanged and stored.
2.5 VIA VT82C686B System Chipset
The system chipset is the VIA VT82C686B. For more information on the VIA VT82C686B,
refer to the VIA website.
Page 25
Page 26
PCISA-MARK CPU Card
2.6 Data Flow
Figure 2-1 shows the data flow between the system chipset, the CPU and other I/O
interfaces that can connect to the PCISA-MARK CPU card.
Figure 2-1: Data Flow Block Diagram
Page 26
IEI® Technology, Corp.
Page 27
PCISA-MARK CPU Card
2.7 LCD and Flat Panel Display Support
Mark CoreFusion™ processor supports a wide variety of DSTN or TFT panels through a
36-bit CMOS interface. This includes support for VGA, SVGA, XGA, and SXGA+ TFT
color panels with 9-bit, 12-bit, 18-bit (both 1 pixel/clock and 2 pixels/clock), and 24-bit
CMOS interfaces. Enhanced STN hardware with 256 gray scale support and advanced
frame rate control to provide up to 16.7 million colors. In addition, the integrated 2-channel
LVDS interface can support 18-bit color panels. All resolutions are supported up to
SXGA+ (1400x1050). The integrated ZV-Port allows display of video from an external
source.
2.7.1 High Screen Resolution Display Support
Table 2-1 shows the CRT and panel screen resolutions supported by the VIA Mark
CoreFusion™ processor.
SYSTEM MEMORY FRAME BUFFER SIZE
RESOLUTIONS SUPPORTED 8 MB 16/32 MB
640x480x8/16/32
800x600x8/16/32
1024x768x8/16/32
1280x1024x8
1280x1024x16
1280x1024x32
1600x1200x8
1600x1200x16
Page 27
Page 28
PCISA-MARK CPU Card
SYSTEM MEMORY FRAME BUFFER SIZE
RESOLUTIONS SUPPORTED 8 MB 16/32 MB
1600x1200x32
1920x1440x8
1920x1440x16
Table 2-1: CRT and Panel Screen Resolutions Supported
2.8 Memory Support
The PCISA-MARK features onboard 128MB PC133MHz memory and a 168-pin SDRAM
DIMM socket that supports PC100 / 133MHz memory up to 512MB.
2.9 PCI Bus Interface Support
The PCI bus on the PCISA-MARK has the following features:
PCI 2.2 compliant, 32-bit 3.3V PCI interface with 5V tolerant inputs
Supports up to five PCI masters
PCI to system memory data streaming support
Delay transaction from PCI master accessing DRAM
Symmetric arbitration between Host/PCI bus for optimized system
performance
2.10 Ethernet
2.10.1 Ethernet Controller Overview
The RTL8100C is enhanced with an ACPI (Advanced Configuration Power Interface)
management function for PCI in order to provide efficient power management for
advanced operating systems with OSPM (Operating System Directed Power
Management). The RTL8100C also supports remote wake-up (including AMD Magic
Packet
maintenance and management.
™
and Microsoft® Wake-up frame) to increase cost-efficiency in network
Page 28
IEI® Technology, Corp.
Page 29
PCISA-MARK CPU Card
2.10.2 Ethernet Controller Features
The Realtek RTL8100C Ethernet controller features are listed below.
128-pin PQFP/LQFP (PQFP package pin-to-pin compatible with Realtek
RTL8110S-32 Single-Chip Gigabit Ethernet Controller)
Supports PCI/mini-PCI interfaces
Integrates Fast Ethernet MAC, physical chip, and transceiver onto a single
chip
10Mbps and 100Mbps operation
Supports 10Mbps and 100Mbps N-way auto-negotiation
Supports 25MHz Crystal or 25MHz OSC as the internal clock source
Complies with PC99/PC2001 standards
Supports ACPI power management
Provides PCI bus master data transfer
Provides PCI memory space or I/O space mapped data transfer
Supports PCI clock speed of 16.75MHz-40MHz
Advanced power saving mode
Supports Wake-on-LAN and remote wake-up (AMD Magic Packet
™
, Link
Change, and Microsoft® Wake-up frame)
Half/Full duplex capability
Supports Full Duplex Flow Control (IEEE 802.3x)
Provides interface to 93C46 EEPROM to store resource configuration and ID
parameters
Provides PCI clock run pin
Provides LED pins for network operation status indication
2.5/3.3V power supply with 5V tolerant I/Os
0.25µm CMOS process
Page 29
Page 30
PCISA-MARK CPU Card
2.11 Drive Interfaces
The PCISA-MARK can support the following drive interfaces.
2 x SATA drives
4 x IDE devices
1 x FDD
1 x Compact Flash (CF) card
2.11.1 SATA Drives
The PCISA-MARK supports two first generation SATA drives with transfer rates of up to
150Mb/s.
2.11.2 IDE HDD Interfaces
The PCISA-MARK system chipset IDE controller supports up to four HDDs with the
following specifications:
Supports PIO IDE transfers up to 16MB/s
Supports the following Ultra ATA devices:
o Ultra ATA/133, with data transfer rates up to 133MB/s
o Ultra ATA/100, with data transfer rates up to 100MB/s
2.11.3 Floppy Disk Drive (FDD)
The PCISA-MARK supports a single FDD. The following FDD formats are compatible with
the board.
5.25”: 360KB and 1.2MB
3.5”: 720KB, 1.44MB and 2.88MB
Standard CF-II cards can be inserted into the compact flash slot on the solder side of the
PCISA-MARK PCB.
Page 30
2.11.4 Compact Flash
IEI® Technology, Corp.
Page 31
PCISA-MARK CPU Card
2.12 Serial Ports
The PCISA-MARK has two high-speed UART serial ports, configured as CN13 and CN14.
Both ports can be configured as RS-232. The serial ports have the following
specifications.
16C550 UART with 16-byte FIFO buffer
115.2Kbps transmission rate
2.13 Audio Codec
2.13.1 Audio Codec Overview
The PCISA-MARK has an integrated REALTEK ALC655 CODEC. The ALC655 CODEC is
a 16-bit, full-duplex AC'97 Rev. 2.3 compatible six-channel audio CODEC designed for PC
multimedia systems, including host/soft audio and AMR/CNR-based designs.
2.13.2 Audo Codec Features
Some of the features of the REALTEK ALC655 CODEC are listed below.
Meets performance requirements for audio on PC99/2001 systems
Meets Microsoft WHQL/WLP 2.0 audio requirements
16-bit Stereo full-duplex CODEC with 48KHz sampling rate
Compliant with AC'97 Rev 2.3 specifications
Front-Out, Surround-Out, MIC-In and LINE-In Jack Sensing
14.318MHz -> 24.576MHz PLL to eliminate crystal
12.288MHz BITCLK input
Integrated PCBEEP generator to save buzzer
Interrupt capability
Three analog line-level stereo inputs with 5-bit volume control, LINE_IN, CD,
AUX
High-quality differential CD input
Two analog line-level mono inputs: PCBEEP, PHONE-IN
Two software selectable MIC inputs
Dedicated Front-MIC input for front panel applications (software selectable)
Boost preamplifier for MIC input
Page 31
Page 32
PCISA-MARK CPU Card
LINE input shared with surround output; MIC input shared with Center and
LFE output
Built-in 50mW/20ohm amplifier for both Front-out and Surround-Out
External Amplifier Power Down (EAPD) capability
Power management and enhanced power saving features
Supports Power-Off CD function
Adjustable VREFOUT control
Supports 48KHz S/PDIF output, complying with AC'97 Rev 2.3 specifications
Supports 32K/44.1K/48KHz S/PDIF input
Power support: Digital: 3.3V; Analog: 3.3V/5V
Standard 48-pin LQFP package
EAX™ 1.0 & 2.0 compatible
Direct Sound 3D™ compatible
A3D™ compatible
I3DL2 compatible
HRTF 3D positional audio
10-band software equalizer
Voice cancellation and key shifting in Karaoke mode
AVRack® Media Player
Configuration Panel for improved user convenience
2.14 Real Time Clock
256-byte battery backed CMOS RAM
2.15 System Monitoring
The PCISA-MARK CPU card is capable of self-monitoring various aspects of its operating
status including:
CPU, chipset, and battery voltage, +3.3V, +5V, and +12V
Page 32
CPU and board temperatures (by the corresponding embedded sensors)
IEI® Technology, Corp.
Page 33
PCISA-MARK CPU Card
2.16 BIOS
The PCISA-MARK uses a licensed copy of Phoenix Award BIOS. The features of the flash
BIOS used are listed below:
SMIBIOS (DMI) compliant
Console redirection function support
PXE (Pre-Boot Execution Environment) support
USB booting support
2.17 Infrared Data Association (IrDA) Interface
The PCISA-MARK IrDA supports the following interfaces:
Serial Infrared (SIR)
Shift Keyed Infrared (ASKIR)
2.18 USB Interfaces
The PCISA-MARK has one external USB interface and two internal USB connectors. The
board supports a total of five USB devices. The USB interfaces support USB 1.1.
2.19 Operating Temperature and Temperature Control
The maximum and minimum operating temperatures for the PCISA-MARK CPU card are
listed below.
Minimum Operating Temperature: 0ºC (32°F)
Maximum Operating Temperature: 60°C (140°F)
A cooling heat sink is installed on the CPU. Thermal paste is smeared on the lower side of
the heat sink before it is mounted on the CPU.
2.20 Power Consumption
Table 2-2 shows the power consumption parameters for the PCISA-MARK for the VIA
Mark 800MHz when 512MB of PC133MHz SDRAM is installed in the system.
Page 33
Page 34
PCISA-MARK CPU Card
Voltage Current
+5V 2.52A
Table 2-2: Power Consumption for VIA Mark 800 MHz
Table 2-2 shows the power consumption parameters for the PCISA-MARK for the VIA
Mark 533MHz when 512MB of PC133MHz SDRAM is installed in the system.
Voltage Current
+5V 2.94A
Table 2-3: Power Consumption for VIA Mark 533 MHz
Page 34
IEI® Technology, Corp.
Page 35
PCISA-MARK CPU Card
2.21 Packaged Contents and Optional Accessory Items
2.21.1 Package Contents
When you unpack the PCISA-MARK CPU card, you should find the following components.
1 x PCISA-MARK single board computer
1 x ATA66/100 HDD cable
2 x SATA cable
1 x SATA Power cable
1 x KB/MS Y cable
1 x RS232 cable
1 x Audio cable
1 x Mini jumper pack
1 x Utility CD
1 x QIG (quick installation guide)
2.21.2 Optional Accessory Items
The following are optional accessory items purchased separately.
FDD cable
LPT cable
Page 35
Page 36
PCISA-MARK CPU Card
THIS PAGE IS INTENTIONALLY LEFT BLANK
Page 36
IEI® Technology, Corp.
Page 37
PCISA-MARK CPU Card
Chapter
3
3
Connectors and
Jumpers
Page 37
Page 38
PCISA-MARK CPU Card
3.1 Peripheral Interface Connectors
Section 3.1.1 shows peripheral interface connector locations. Section 3.1.2 lists all the
peripheral interface connectors seen in Section 3.1.1.
3.1.1 PCISA-MARK Layout
Figure 3-1 shows the on-board peripheral connectors and on-board jumpers.
Page 38
Figure 3-1: Connector and Jumper Locations
IEI® Technology, Corp.
Page 39
PCISA-MARK CPU Card
3.1.2 Peripheral Interface Connectors
Table 3-1 shows a list of the peripheral interface connectors on the PCISA-MARK.
Detailed descriptions of these connectors can be found in Section 3.2.
Connector
Audio CD In connector 4-pin header CN17
Audio connector
(Line out, Line in & MIC in)
Battery connector 2-pin wafer connector CN28
Compact Flash connector (solder side) 50-pin header CN32
CPU Fan connector 3-pin wafer connector CN7
Digital I/O connector 10-pin box header CN11
DIMM socket 168-pin DIMM socket CN16
External LED connector 6-pin wafer connector CN5
Floppy connector 34-pin box header CN12
Inverter connector 5-pin wafer connector CN6
Type Label
10-pin box header CN15
IrDA connector 5-pin header CN18
Keyboard/Mouse connector 6-pin wafer connector CN31
LVDS LCD connector 30-pin crimp connector CN26
Parallel Port connector 26-pin box header CN9
Power button switch 2-pin wafer connector CN3
Power connector 4-pin wafer connector CN1
Primary IDE connector 40-pin box header CN10
PS-ON connector 3-pin wafer connector CN2
Reset button switch 2-pin wafer connector CN4
Page 39
Page 40
PCISA-MARK CPU Card
Connector
RS-232 COM1 serial port connector 10-pin header CN13
RS-232 COM2 serial port connector 10-pin header CN14
Secondary IDE connector 44-pin box header CN8
Serial ATA connector 7-pin SATA connector CN20
Serial ATA connector 7-pin SATA connector CN21
TFT LCD connector 40-pin crimp connector CN27
USB 1.1 connector 8-pin header CN23
USB 1.1 connector 4-pin header CN24
Table 3-1: Peripheral Interface Connectors
Type Label
3.1.3 External Peripheral Interface Connectors
Table 3-2 lists the external peripheral interface connectors on the PCISA-MARK. Detailed
descriptions of these connectors can be found in Section 3.3.
Connector Type Label
Ethernet connector RJ-45 connector CN25
Ethernet connector RJ-45 connector CN29
Keyboard/mouse connector MINI-DIN connector CN30
USB connector USB 2.0 connector CN22
VGA connector HD-D-sub 15 female connector CN19
Table 3-2: External Peripheral Interface Connectors
Page 40
IEI® Technology, Corp.
Page 41
PCISA-MARK CPU Card
3.1.4 On-board Jumpers
Table 3-3 lists the on-board jumpers. Detailed descriptions of these jumpers can be found
in Section 4.6.
Description Label Type
CF card function setup JP2 2-pin header
Clear CMOS JP3 3-pin header
Flat panel power select JP4 3-pin header
PCI VIO voltage select JP5 3-pin header
Table 3-3: On-board Jumpers
3.2 Internal Peripheral Connectors
Internal peripheral connectors are found on the CPU card and are only accessible when
the CPU card is outside of the chassis. This section has complete descriptions of all the
internal peripheral connectors on the PCISA-MARK.
3.2.1 Audio CD In Connector
CN Label: CN17
CN Type:
CN Location: See Figure 3-2
CN Pinouts: See Table 3-4
The AC’97 codec supports several audio functions. The audio CD in connector facilitates
4-pin header
“CD in” audio connections.
Page 41
Page 42
PCISA-MARK CPU Card
Figure 3-2: Audio CD In Connector Location
PIN NO. DESCRIPTION
1 CD SIGNAL (Left)
2 GROUND
3 GROUND
4 CD SIGNAL (Right)
Table 3-4: Audio CD In Connector Pinouts
Page 42
IEI® Technology, Corp.
Page 43
PCISA-MARK CPU Card
3.2.2 Audio Connector (Line out, Line in & MIC in)
CN Label: CN15
CN Type:
CN Location: See Figure 3-3
CN Pinouts: See Table 3-5
The 10-pin audio connector is connected to external audio devices including speakers and
microphones for the input and output of audio signals to and from the system.
10-pin box header
Figure 3-3: Audio Connector Location
Page 43
Page 44
PCISA-MARK CPU Card
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 Line Out (Right) 2 Line In (Right)
3 GROUND 4 GROUND
5 Line Out (Left) 6 Line In (Left)
7 GROUND 8 GROUND
9 MIC In 10 NC
Table 3-5: Audio Connector Pinouts
3.2.3 Battery Connector
CN Label: CN28
CN Type:
2-pin wafer connector
CN Location: See Figure 3-4
CN Pinouts: See Table 3-6
Page 44
IEI® Technology, Corp.
Page 45
PCISA-MARK CPU Card
Figure 3-4: Battery Connector Location
PIN NO. DESCRIPTION
1 Battery+
2 Battery-
Table 3-6: Battery Connector Pinouts
3.2.4 Compact Flash® Connector
CN Label: CN32 (solder side)
CN Type:
CN Location: See Figure 3-5
50-pin header
CN Pinouts: See Table 3-7
Page 45
Page 46
PCISA-MARK CPU Card
Page 46
Figure 3-5: Compact Flash® Connector Location
IEI® Technology, Corp.
Page 47
PCISA-MARK CPU Card
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GROUND 26 CFD2
2 SDD3 27 SDD11
3 SDD4 28 SDD12
4 SDD5 29 SDD13
5 SDD6 30 SDD14
6 SDD7 31 SDD15
7 SDCS1# 32 SDCS3#
8 GROUND 33 N/C
9 GROUND 34 SDIOR#
10 GROUND 35 SDIOW#
11 GROUND 36 VCC
12 GROUND 37 IRQ15
13 VCC 38 VCC
14 GROUND 39 MASTER/SLAVE
15 GROUND 40 N/C
16 GROUND 41 RESET#
17 GROUND 42 SIORDY
18 SDA2 43 SDDREQ
19 SDA1 44 SDDACK#
20 SDA0 45 HD_LED2
21 SDD0 46 PDIAG#
22 SDD1 47 SDD8
23 SDD2 48 SDD9
24 N/C 49 SDD10
25 CFD1 50 GROUND
Table 3-7: Compact Flash® Connector Pinouts
Page 47
Page 48
PCISA-MARK CPU Card
3.2.5 CPU Fan Connector
CN Label: CN7
CN Type:
CN Location: See Figure 3-6
CN Pinouts: See Table 3-8
The cooling fan connector provides a 5V, 500mA current to a CPU cooling fan. The
connector has a "rotation" pin to get rotation signals from fans and notify the system so the
system BIOS can recognize the fan speed. Please note that only specified fans can issue
the rotation signals.
3-pin wafer
Figure 3-6: CPU Fan Connector Location
Page 48
IEI® Technology, Corp.
Page 49
PCISA-MARK CPU Card
PIN NO. DESCRIPTION
1 GROUND
2 +5V
3 Rotation Signal
Table 3-8: CPU Fan Connector Pinouts
3.2.6 Digital Input/Output (DIO) Connector
CN Label:
CN Type:
CN Location: See Figure 3-7
CN Pinouts: See Table 3-9
The digital IO port of PCISA-MARK is 5V CMOS level. Internal pull-up exists on the
output.
CN11
10-pin header
Page 49
Page 50
PCISA-MARK CPU Card
Figure 3-7: Digital I/O Connector Location
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GROUND 2 +5V
3 OUTPUT 0 4 OUTPUT 1
5 OUTPUT 2 6 OUTPUT 3
7 INPUT 0 8 INPUT 1
9 INPUT 2 10 INPUT 3
Table 3-9: Digital I/O Connector Pinouts
Page 50
IEI® Technology, Corp.
Page 51
PCISA-MARK CPU Card
3.2.7 DIMM socket
CN Label: CN16
CN Type:
CN Location: See Figure 3-8
PCISA-MARK has a 168-pin DIMM socket that supports 3.3V non-buffered
PC100/133MHz SDRAM up to 512MB.
168-pin DIMM socket
Page 51
Page 52
PCISA-MARK CPU Card
Figure 3-8: DIMM Socket Location
Page 52
IEI® Technology, Corp.
Page 53
PCISA-MARK CPU Card
3.2.8 External LED Connector
CN Label: CN5
CN Type:
CN Location: See Figure 3-9
CN Pinouts: See Table 3-10
6-pin wafer connector
Figure 3-9: External LED Connector Location
Page 53
Page 54
PCISA-MARK CPU Card
PIN NO. DESCRIPTION
1 +5V
2 GND
3 +5V
4 GND
5 +5V
6 HD_LED
Table 3-10: External LED Connector Pinouts
3.2.9 Floppy Disk Connector
CN Label: CN12
CN Type:
34-pin box header
CN Location: See Figure 3-10
CN Pinouts: See Table 3-11
The floppy disk connector connects to a floppy disk drive.
Page 54
IEI® Technology, Corp.
Page 55
PCISA-MARK CPU Card
Figure 3-10: 34-pin FDD Connector Location
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GROUND 2 DEN0
3 GROUND 4 N/C
5 GROUND 6 DEN1
7 GROUND 8 INDEX-
9 GROUND 10 MTR0-
11 GROUND 12 DISKSEL1-
13 GROUND 14 DISKSEL0-
15 GROUND 16 MTR1-
17 GROUND 18 DIR-
19 GROUND 20 STEP-
21 GROUND 22 WDATA-
23 GROUND 24 WGATE-
25 GROUND 26 TRAK0-
Page 55
Page 56
PCISA-MARK CPU Card
27 GROUND 28 WRTPRT-
29 GROUND 30 RDATA-
31 GROUND 32 HDSEL-
33 GROUND 34 DSKCHG-
Table 3-11: 34-pin FDD Connector Pinouts
3.2.10 IDE Connector (Primary)
CN Label: CN10
CN Type:
CN Location: See Figure 3-11
CN Pinouts: See Table 3-12
One 40-pin primary IDE device connector on the PCISA-MARK CPU card supports
connectivity to Ultra ATA/133 IDE devices with data transfer rates up to 133MB/s.
40-pin box header
Page 56
IEI® Technology, Corp.
Page 57
PCISA-MARK CPU Card
Figure 3-11: Primary IDE Device Connector Location
PIN DESCRIPTION PIN DESCRIPTION
1 -IDERST 2 GROUND
3 PDD7 4 PDD8
5 PDD6 6 PDD9
7 PDD5 8 PDD10
9 PDD4 10 PDD11
11 PDD3 12 PDD12
13 PDD2 14 PDD13
15 PDD1 16 PDD14
17 PDD0 18 PDD15
19 GROUND 20 N/C
21 PDDREQ 22 GROUND
23 -PDIOW 24 GROUND
25 -PDIOR 26 GROUND
27 PIORDY 28 (PULL LOW TO GND)
29 -PDDACK 30 GROUND
31 IRQ14 32 N/C
33 PDA1 34 PD33_-36
Page 57
Page 58
PCISA-MARK CPU Card
35 PDA0 36 PDA2
37 -PDCS1 38 -PDCS3
39 HD_LED1 40 GROUND
Table 3-12: Primary IDE Connector Pinouts
3.2.11 IDE Connector (Secondary)
CN Label: CN8
CN Type:
CN Location: See Figure 3-12
CN Pinouts: See Table 3-13
One 44-pin secondary IDE device connector on the PCISA-MARK CPU card supports
connectivity to Ultra ATA/133 IDE devices with data transfer rates up to 133MB/s.
44-pin box header
Page 58
IEI® Technology, Corp.
Page 59
PCISA-MARK CPU Card
Figure 3-12: Secondary IDE Device Connector Location
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 RESET# 2 GROUND
3 DATA 7 4 DATA 8
5 DATA 6 6 DATA 9
7 DATA 5 8 DATA 10
9 DATA 4 10 DATA 11
11 DATA 3 12 DATA 12
13 DATA 2 14 DATA 13
15 DATA 1 16 DATA 14
17 DATA 0 18 DATA 15
19 GROUND 20 N/C
21 DRQ 22 GROUND
23 IOW# 24 GROUND
25 IOR# 26 GROUND
27 CHRDY 28 (PULL LOW TO GND)
Page 59
Page 60
PCISA-MARK CPU Card
29 DACK# 30 GROUND
31 INTERRUPT 32 N/C
33 SA1 34 N/C
35 SA0 36 SA2
37 HDC CS1# 38 HDC CS3#
39 HDD ACTIVE# 40 GROUND
41 +5V 42 +5V
43 GROUND 44 N/C
Table 3-13: Secondary IDE Connector Pinouts
3.2.12 Inverter Connector
CN Label: CN6
CN Type:
5-pin wafer connector
CN Location: See Figure 3-13
CN Pinouts: See Table 3-14
The inverter connector is connected to the LCD backlight.
Page 60
IEI® Technology, Corp.
Page 61
PCISA-MARK CPU Card
Figure 3-13: Inverter Connector Location
PIN NO. DESCRIPTION
1 Ground
2 Ground
3 +12V
4 Ground
5 LCD Enable
Table 3-14: Inverter Connector Pinouts
Page 61
Page 62
PCISA-MARK CPU Card
3.2.13 IrDA Interface Connector
CN Label: CN18
CN Type: 5-pin header
CN Location:
CN Pinouts:
The integrated infrared (IrDA) connector supports both Serial Infrared (SIR) and Amplitude
Shift Key Infrared (ASKIR) interfaces.
See Figure 3-14
See Table 3-15
Figure 3-14: IrDA Connector Location
Page 62
IEI® Technology, Corp.
Page 63
PCISA-MARK CPU Card
PIN NO. DESCRIPTION
1 VCC
2 N/C
3 IR-RX
4 Ground
5 IR-TX
Table 3-15: IrDA Connector Pinouts
3.2.14 Keyboard/Mouse Connector
CN Label: CN31
CN Type:
6-pin wafer connector
CN Location: See Figure 3-15
CN Pinouts: See Table 3-17
The keyboard and mouse connector can be connected to a standard PS/2 cable or PS/2
Y-cable to add keyboard and mouse functionality to the system.
Page 63
Page 64
PCISA-MARK CPU Card
Figure 3-15: Keyboard/Mouse Connector Location
PIN NO. DESCRIPTION
1 +5V
2 MOUSE DATA
3 MOUSE CLOCK
4 KEYBOARD DATA
5 KEYBOARD CLOCK
6 GROUND
Table 3-16: Keyboard/Mouse Connector Pinouts
Page 64
IEI® Technology, Corp.
Page 65
PCISA-MARK CPU Card
3.2.15 LVDS LCD Connector
CN Label: CN26
CN Type:
CN Location: See Figure 3-16
CN Pinouts: See Table 3-17
This connector is connected to a TFT LCD LVDS display device.
30-pin crimp connector
Page 65
Page 66
PCISA-MARK CPU Card
Figure 3-16: LVDS LCD Connector Location
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GROUND 2 GROUND
3 LVDSA_Y0+ 4 LVDSA_Y0-
5 LVDSA_Y1+ 6 LVDSA_Y1-
7 LVDSA_Y2+ 8 LVDSA_Y2-
9 LVDSA_CLK+ 10 LVDSA_CLK-
11 N/C 12 N/C
13 GROUND 14 GROUND
15 LVDSB_Y0+ 16 LVDSB_Y0-
17 LVDSB_Y1+ 18 LVDSB_Y1-
19 LVDSB_Y2+ 20 LVDSB_Y2-
21 LVDSB_CLK+ 22 LVDSB_CLK-
23 N/C 24 N/C
25 GROUND 26 GROUND
27 VCC_LVDS 28 VCC_LVDS
Page 66
29 VCC_LVDS 30 VCC_LVDS
Table 3-17: LVDS LCD Connector Pinouts
IEI® Technology, Corp.
Page 67
PCISA-MARK CPU Card
3.2.16 Parallel Port Connector
CN Label: CN9
CN Type:
26-pin box header
CN Location: See Figure 3-17
CN Pinouts: See Table 3-18
The 26-pin box header can be connected to a parallel port connector interface or some
other parallel port device such as a printer.
Figure 3-17: Parallel Port Connector Location
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 STROBE# 2 AUTO FORM FEED #
3 DATA 0 4 ERROR#
5 DATA 1 6 INITIALIZE
Page 67
Page 68
PCISA-MARK CPU Card
7 DATA 2 8 PRINTER SELECT LN#
9 DATA 3 10 GROUND
11 DATA 4 12 GROUND
13 DATA 5 14 GROUND
15 DATA 6 16 GROUND
17 DATA 7 18 GROUND
19 ACKNOWLEDGE 20 GROUND
21 BUSY 22 GROUND
23 PAPER EMPTY 24 GROUND
25 PRINTER SELECT 26 N/C
Table 3-18: Parallel Port Connector Pinouts
3.2.17 Power Button Connector
CN Label: CN3
CN Type:
CN Location: See Figure 3-18
CN Pinouts: See Table 3-19
The power button connector is connected to the power button on the external chassis.
2-pin wafer connector
Page 68
IEI® Technology, Corp.
Page 69
PCISA-MARK CPU Card
Figure 3-18: Power Button Connector Location
PIN NO. DESCRIPTION
1 PWR-BTN
2 Ground
Table 3-19: Power Button Connector Pinouts
Page 69
Page 70
PCISA-MARK CPU Card
3.2.18 Power Connector
CN Label: CN1
CN Type:
CN Location: See Figure 3-19
CN Pinouts: See Table 3-20
The power connector is connected to a power source that powers the system.
4-pin wafer connector
Figure 3-19: Power Connector Location
Page 70
IEI® Technology, Corp.
Page 71
PCISA-MARK CPU Card
PIN NO. DESCRIPTION
1 +5v
2 Ground
3 Ground
4 +12v
Table 3-20: Power Connector Pinouts
PIN DESCRIPTION PIN DESCRIPTION
1 -IDERST 2 GROUND
3 PDD7 4 PDD8
5 PDD6 6 PDD9
7 PDD5 8 PDD10
9 PDD4 10 PDD11
11 PDD3 12 PDD12
13 PDD2 14 PDD13
15 PDD1 16 PDD14
17 PDD0 18 PDD15
19 GROUND 20 N/C
21 PDDREQ 22 GROUND
23 -PDIOW 24 GROUND
25 -PDIOR 26 GROUND
27 PIORDY 28 (PULL LOW TO GND)
29 -PDDACK 30 GROUND
31 IRQ14 32 N/C
33 PDA1 34 PD33_-36
35 PDA0 36 PDA2
37 -PDCS1 38 -PDCS3
39 HD_LED1 40 GROUND
Table 3-21: Primary IDE Connector Pinouts
Page 71
Page 72
PCISA-MARK CPU Card
3.2.19 PS-ON Connector
CN Label: CN2
CN Type:
CN Location: See Figure 3-20
CN Pinouts: See Table 3-22
The PS-ON connector connects to an ATX power supply.
3-pin wafer connector
Figure 3-20: PS-ON Signal Connector Location
Page 72
IEI® Technology, Corp.
Page 73
PCISA-MARK CPU Card
PIN NO. DESCRIPTION
1 Ground
2 PS-ON
3 +5V Standby
Table 3-22: PS-ON Signal Connector Pinouts
3.2.20 Reset Button Connector
CN Label: CN4
CN Type:
CN Location: See Figure 3-21
CN Pinouts: See Table 3-23
The reset button connector is connected to the reset button on the external chassis.
2-pin wafer connector
Page 73
Page 74
PCISA-MARK CPU Card
Figure 3-21: Reset Button Connector Location
PIN NO. DESCRIPTION
1 RST_BTN
2 Ground
Table 3-23: Reset Button Connector Pinouts
Page 74
IEI® Technology, Corp.
Page 75
PCISA-MARK CPU Card
3.2.21 RS-232 Serial Port (COM1 & COM2) Connectors
CN Label: CN13 and CN14
CN Type:
CN Location: See Figure 3-22
CN Pinouts: See Table 3-24
The serial port connectors connect to RS-232 serial port devices.
10-pin header
Page 75
Page 76
PCISA-MARK CPU Card
Figure 3-22: RS-232 Serial Port Connectors Location
PIN DESCRIPTION PIN DESCRIPTION
1 2 DATA SET READY (DSR)
DATA CARRIER DETECT (DCD)
3
RECEIVE DATA (RXD) 4 REQUEST TO SEND (RTS)
5 TRANSMIT DATA (TXD) 6 CLEAR TO SEND (CTS)
7 DATA TERMINAL READY (DTR) 8 RING INDICATOR (RI)
9 GROUND (GND) 10 GROUND (GND)
Table 3-24: RS-232 Serial Port Connectors Pinouts
3.2.22 Serial ATA Drive Connectors
CN Label: CN20 and CN21
CN Type:
CN Location: See Figure 3-23
CN Pinouts: See Table 3-25
The two SATA drive connectors are connected to two first generation SATA drives. First
generation SATA drives transfer data at speeds as high as 150Mb/s.
7-pin SATA drive connector
Page 76
IEI® Technology, Corp.
Page 77
PCISA-MARK CPU Card
Figure 3-23: SATA Drive Connector Locations
PIN NO. DESCRIPTION
1 GND
2 S_TXP
3 S_TXN
4 GND
5 S_RXN
6 S_RXP
7 GND
Table 3-25: SATA Drive Connector Pinouts
Page 77
Page 78
PCISA-MARK CPU Card
3.2.23 TFT LCD Connector
CN Label: CN27
CN Type:
CN Location: See Figure 3-24
CN Pinouts: See Table 3-26
This connector is connected to a TFT LCD TTL display device.
40-pin crimp connector
Figure 3-24: TFT LCD TTL Connector Location
Page 78
IEI® Technology, Corp.
Page 79
PCISA-MARK CPU Card
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 VCC_FP 2 VCC_FP
3 GROUND 4 GROUND
5 VCC_FP 6 VCC_FP
7 I2CDATA 8 GROUND
9 FPD0 10 FPD1
11 FPD2 12 FPD3
13 FPD4 14 FPD5
15 FPD6 16 FPD7
17 FPD8 18 FPD9
19 FPD10 20 FPD11
21 FPD12 22 FPD13
23 FPD14 24 FPD15
25 FPD16 26 FPD17
27 FPD18 28 FPD19
29 FPD20 30 FPD21
31 FPD22 32 FPD23
33 GROUND 34 GROUND
35 FPCLK 36 FPVS
37 FPDEN 38 FPHS
39 12CCLK 40 ENVEE
Table 3-26: TFT LCD TTL Connector Pinouts
Page 79
Page 80
PCISA-MARK CPU Card
3.2.24 USB Connectors (8-pin and 4-pin)
CN Label: CN23 and CN24
CN Type:
CN Location: See Figure 3-25
CN Pinouts: See Table 3-27 for CN23 pinouts
The 8-pin and 4-pin USB connectors provide connectivity to USB 1.1 ports. The 8-pin USB
connector can support two USB devices. The 4-pin USB connector can support one USB
device. An additional USB port is found on the rear panel. The USB ports are used for I/O
bus expansion.
8-pin and 4-pin header
See Table 3-28for CN24 pinouts
Page 80
IEI® Technology, Corp.
Page 81
PCISA-MARK CPU Card
Figure 3-25: 8-pin USB Connector Location
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 VCC 2 GROUND
3 DATA3- 4 DATA4+
5 DATA3+ 6 DATA4-
7 GROUND 8 VCC
Table 3-27: CN23 USB Port Connector Pinouts
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 N/C 2 GROUND
3 N/C 4 DATA2+
5 N/C 6 DATA2-
7 N/C 8 VCC
Table 3-28: CN24 USB Port Connector Pinouts
Page 81
Page 82
PCISA-MARK CPU Card
3.3 External Peripheral Interface Connector Panel
Figure 3-26 shows the PCISA-MARK external peripheral interface connector panel. The
peripheral connectors are connected to external devices when the PCISA-MARK is
installed in a chassis. The peripheral connectors on the panel are:
1 x PS/2 keyboard and mouse mini-DIN connector
2 x RJ-45 GbE connectors
1 x USB connector
1 x VGA connector
NOTE:
Figure 3-26 shows the PCISA-MARK external peripheral
interface connector panel with a standard HD-D-sub-15
female VGA connector (labeled number 4).
Figure 3-26: External Peripheral Interface Connector Panel
Page 82
IEI® Technology, Corp.
Page 83
PCISA-MARK CPU Card
3.3.1 LAN Connectors
CN Label: CN25 and CN29
CN Type:
RJ-45
CN Location: See Figure 3-26 (labeled number 2)
CN Pinouts: See Table 3-29
The PCISA-MARK is equipped with two built-in GbE Ethernet controllers. The controllers
can connect to the LAN through two RJ-45 LAN connectors. There are two LEDs on the
connector indicating the status of LAN. The pin assignments are listed in the following
table:
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 TX+ 8 N/C
2 GROUND 9 ACT_LED-
3 TX- 10 ACT_LED+
4 RX+ 11 LINK_LED -
5 GROUNG 12 LINK_LED+
6 RX- 13 GROUND
7 N/C 14 GROUND
Table 3-29: LAN Pinouts
Page 83
Page 84
PCISA-MARK CPU Card
Figure 3-27: RJ-45 Ethernet Connector
The RJ-45 Ethernet connector has two status LEDs, one green and one yellow. The green
LED indicates activity on the port and the yellow LED indicates the port is linked. See
Table 3-30.
STATUS DESCRIPTION STATUS DESCRIPTION
GREEN Activity YELLOW Linked
Table 3-30: RJ-45 Ethernet Connector LEDs
3.3.2 Mini-DIN 6 PS/2 Connector
CN Label: CN30
CN Type:
CN Location: See Figure 3-26 (labeled number 1)
CN Pinouts: See Table 3-31
The PCISA-MARK CPU card has a mini-DIN 6 PS/2 connector on the mounting bracket
for easy connection to a PS/2 keyboard or PS/2 mouse. The card comes with a cable to
convert the mini-DIN 6 PS/2 into two mini-DIN 6 PS/2 connectors for keyboard and mouse
connection.
Mini-DIN 6 PS/2
Page 84
IEI® Technology, Corp.
Page 85
PCISA-MARK CPU Card
Figure 3-28: Mini-DIN 6 PS/2 Connector
PIN NO. DESCRIPTION
1 KEYBOARD DATA
2 MOUSE DATA
3 GROUND
4 +5V
5 KEYBOARD CLOCK
6 MOUSE CLOCK
Table 3-31: Mini-DIN 6 PS/2 Connector
3.3.3 USB Connector
CN Label: CN22
CN Type:
CN Location: See Figure 3-26 (labeled number 3)
CN Pinouts: See Table 3-32
USB port
The PCISA-MARK has a one rear panel USB port. This port connects to USB 1.1 devices.
Page 85
Page 86
PCISA-MARK CPU Card
PIN NO. DESCRIPTION
1 VCC
2 DATA1-
3 DATA1+
4 GROUND
Table 3-32: USB Port Pinouts
3.3.4 VGA connector
CN Label: CN19
CN Type:
CN Location: See Figure 3-26 (labeled number 4)
CN Pinouts: See Table 3-33
A 15-pin VGA connector connects to standard displays.
HD-D-sub 15 female connector
Figure 3-29: VGA Connector
Page 86
IEI® Technology, Corp.
Page 87
PCISA-MARK CPU Card
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 RED 2 GREEN
3 BLUE 4 N/C
5 GROUND 6 GROUND
7 GROUND 8 GROUND
9 N/C 10 GROUND
11 N/C 12 DDC DAT
13 HSYNC 14 VSYNC
15 DDCCLK
Table 3-33: VGA Connector Pinouts
Page 87
Page 88
PCISA-MARK CPU Card
THIS PAGE IS INTENTIONALLY LEFT BLANK
Page 88
IEI® Technology, Corp.
Page 89
PCISA-MARK CPU Card
Chapter
4
4
Installation
Page 89
Page 90
PCISA-MARK CPU Card
4.1 Anti-static Precautions
Electrostatic discharge (ESD) can cause serious damage to electronic components,
including the PCISA-MARK. (Dry climates are especially susceptible to ESD.) It is
therefore critical that whenever the PCISA-MARK (or any other electrical component) is
handled, the following anti-static precautions are strictly adhered to.
Wear an anti-static wristband: - Wearing a simple anti-static wrist band can
help to prevent ESD from damaging the board.
Self-grounding: - Before handling the board touch any grounded conducting
material. During the time the board is handled, frequently touch any
conducting materials that are connected to the ground.
4.2 Installation Considerations
NOTE:
The following installation notices and installation
considerations should be read and understood before the
CPU card is installed. All installation notices pertaining to the
installation of the CPU card should be strictly adhered to.
Failing to adhere to these precautions may lead to severe
damage of the CPU card and injury to the person installing the
CPU card.
4.2.1 Installation Notices
Before and during the installation of the PCISA-MARK CPU card, do the following:
Read the user manual
o The user manual provides a complete description of the PCISA-MARK
Page 90
CPU card, installation instructions, and configuration options.
Wear an electrostatic discharge cuff (ESD)
IEI® Technology, Corp.
Page 91
PCISA-MARK CPU Card
o Electronic components are easily damaged by ESD. Wearing an ESD cuff
removes ESD from the user’s body and helps to prevent ESD damage.
Place the CPU card on an antistatic pad
o When the CPU card is installed and configured, place it on an antistatic
pad. This helps to prevent potential ESD damage.
Turn off all power to the PCISA-MARK CPU card
o When working with the CPU card, make sure that it is disconnected from
all power supplies and that no electricity is being fed into the system.
Before and during the installation of the PCISA-MARK CPU card DO NOT:
remove any of the stickers on the PCB board. These stickers are required for
warranty validation.
use the product before all the cables and power connectors are properly
connected.
allow screws to come in contact with the PCB circuit, connector pins, or its
components.
4.3 Unpacking
NOTE:
If any of the items listed below are missing when the
PCISA-MARK is unpacked, do not proceed with the
installation. Contact the reseller or vendor the CPU card was
purchased from.
4.3.1 Unpacking Precautions
Some components on PCISA-MARK are very sensitive to static electricity and can be
damaged by a sudden rush of power. To protect it from being damaged during the
unpacking process, follow these precautions:
Page 91
Page 92
PCISA-MARK CPU Card
Users should ground themselves to remove any static charge before touching
the PCISA-MARK. To ground themselves, users can wear a grounded wrist
strap at all times or frequently touching any conducting materials that is
connected to the ground.
Handle the PCISA-MARK by its edges. Do not touch the IC chips, leads or
circuitry unnecessarily.
Do not place a PCB on top of an anti-static bag. Only the inside of the bag is safe from
static discharge.
4.3.2 Checklist
When PCISA-MARK is unpacked make sure the package contains the following items.
1 x PCISA-MARK single board computer
1 x ATA66/100 HDD cable
2 x SATA cable
1 x SATA Power cable
1 x KB/MS Y cable
1 x RS232 cable
1 x Audio cable
1 x Mini jumper pack
1 x Utility CD
1 x QIG (quick installation guide)
If one or more of these items are missing, contact the reseller or vendor PCISA-MARK
was purchased from and do not proceed any further with the installation.
Page 92
IEI® Technology, Corp.
Page 93
PCISA-MARK CPU Card
4.4 PCISA-MARK CPU Card Installation
WARNING!
Note that the installation instructions described in this manual
should be carefully followed in order to avoid damage to the
PCISA-MARK components and injury to the user.
WARNING!
When installing electronic components onto the PCISA-MARK
always take anti-static precautions in order to prevent ESD
damage to the PCISA-MARK and other electronic
components like the CPU and DIMM modules.
4.4.1 Preinstalled Component
The component listed below is preinstalled on the PCISA-MARK.
CPU
4.4.2 Components to Install
To install the PCISA-MARK, the following components must be installed or connected to
the PCISA-MARK:
DIMM module
Peripheral devices
Page 93
Page 94
PCISA-MARK CPU Card
4.4.3 DIMM Module Installation
4.4.3.1 Purchasing the Memory Module
When purchasing DIMM modules, the following considerations should be taken into
account:
The DIMM module can support a 168-pin PC100/133 MHz SDRAM with a
maximum size of 512MB
The DIMM can be either single-sided or dual-sided.
4.4.3.2 DIMM Module Installation
The PCISA-MARK CPU card has one DDR SDRAM DIMM socket. To install a DIMM
module, follow the instructions below and refer to Figure 4-1.
Step 1: Make sure the two handles of the DIMM socket are in the "open" position,
leaning outward (Figure 4-1).
Figure 4-1: Installing the DIMM Module
Page 94
IEI® Technology, Corp.
Page 95
PCISA-MARK CPU Card
Step 2:
Step 3:
Slowly slide the DIMM module along the plastic guides on both ends of the
socket. Press the DIMM module down into the socket until it clicks into position
and the two handles have automatically locked the memory module into place.
To remove the memory module, push both handles outward, and the memory
module is ejected by the mechanism in the socket. Step 0:
Page 95
Page 96
PCISA-MARK CPU Card
4.5 Peripheral Device Connection
Cables provided by IEI that connect peripheral devices to the board are listed in Table
4-1. Cables not included in the kit must be separately purchased.
Quantity Type
1 ATA 66/100 HDD cable
1 Audio cable
1 RS-232 cable
1 KB/MS Y cable
2 SATA cables
1 SATA power cable
Table 4-1: IEI Provided Cables
4.5.1 IDE Disk Drive Connectors
The cable used to connect the CPU board to the IDE HDD is a standard 44-pin or 40-pin
ATA flat cable. To connect an IDE HDD to the motherboard, follow the instructions below.
44-pin IDE cable connection is illustrated in Figure 4-2 and 40-pin cable connection is
illustrated in Figure 4-3.
Step 1:
Step 2:
Find the ATA 66/100 flat cable in the kit that came with the motherboard.
Connect one end of the cable to the PIDE1 connector on the motherboard. A
keyed pin on the IDE connectors prevents it from being connected incorrectly.
Step 3:
Step 4:
Page 96
Locate the red wire on the other side of the cable that corresponds to the pin 1
connector.
Connect the other side of the cable to the HDD making sure that the pin 1 cable
corresponds to pin 1 on the connector.Step 0:
IEI® Technology, Corp.
Page 97
PCISA-MARK CPU Card
Figure 4-2: Connection of 44-Pin IDE Connector
Figure 4-3: Connection of 40-Pin IDE Connector
NOTE:
When two EIDE disk drives are connected together, back-end jumpers on
the drives must be used to configure one drive as a master and the other as
a slave.
Page 97
Page 98
PCISA-MARK CPU Card
4.5.2 COM1-COM2 RS-232 Serial Port Installation
The cable used to connect the CPU card to an RS-232 serial port is a 10-pin header to
male D-sub 9 connector. To connect an RS-232 serial port to the CPU card, follow the
instructions below.
Step 1:
Step 2:
Step 3:
Find the RS-232 cable in the kit that came with the CPU card.
Connect the 10-pin connector end of the cables to the COM1 /COM2 box
headers on the CPU card. Be sure to align the red wire on the connector to pin 1
on the box header.
Connect the other end of the cables to standard female D-sub 9 connectors.
4.5.3 LCD Backlight Installation
To connect an LCD backlight (inverter) to the CPU card, follow the instruction below.
Step 1:
Connect the 5-pin connector end of the LCD backlight cable to the CN6 header
on the CPU card. A keyed pin on the connector prevents it from being connected
incorrectly.Step 0:
4.5.4 Power Connection
Step 0:
To connect the CPU card to a power supply, follow the instruction below.
Step 1:
To connect a TFT LVDS LCD to the CPU card, follow the instructions below.
Step 1:
Page 98
Connect a 4-pin AT/ATX power connector from a power supply to the CN1
power connector on the CPU card.
4.5.5 TFT LVDS LCD Installation
Connect the 20-pin connector end of a TTL LCD cable to the CN26 miniature
crimping connector on the CPU card. A keyed pin on the connector prevents it
from being connected incorrectly.Step 0:
IEI® Technology, Corp.
Page 99
PCISA-MARK CPU Card
4.5.6 TFT TTL LCD Installation
To connect a TFT TTL LCD to the CPU card, follow the instructions below.
Step 1: Connect the 40-pin connector end of a TFT TTL LCD cable to the CN27
miniature crimping connector on the CPU card. A keyed pin on the connector
prevents it from being connected incorrectly.
4.6 Jumper Settings
NOTE:
A jumper is a metal bridge
that is used to close an
electrical circuit. It consists of
two metal pins and a small
metal clip (often protected by
a plastic cover) that slides
over the pins to connect
them. To CLOSE/SHORT a
jumper means connecting the pins of the jumper with the
plastic clip and to OPEN a jumper means removing the plastic
clip from a jumper.
Jumper
Page 99
Page 100
PCISA-MARK CPU Card
Before the PCISA-MARK is installed in the system, the jumpers must be set in accordance
with the desired configuration. The PCISA-MARK CPU card has four on-board jumpers.
Description Label Type
CF card function setup JP2 2-pin header
Clear CMOS JP3 3-pin header
Flat panel power select JP4 3-pin header
PCI VIO voltage select JP5 3-pin header
Figure 4-4 shows the PCISA-MARK jumper locations.
Figure 4-4: Jumper Locations
Page 100
IEI® Technology, Corp.
