PICMG 1.3 Socket M Intel® Core™ 2 Duo CPU Card
with VGA, Dual PCIe GbE, SATA and USB2.0
PCIE-9452
Quick Installation Guide
Version 1.2
Dec. 31, 2007
Package List
PCIE-9452 package includes the following items:
1 x PCIE-9452 single board computer
1 x Mini Jumper Pack
1 x ATA 66/100 flat cable
2 x SATA Power cable
1 x USB cable
1 x QIG (Quick Installation Guide)
4 x SATA cable
1 x Dual RS-232 cable
1 x Utility CD
©2006 Copyright by IEI Technology corp.
All rights reserved.
1
Specifications
CPU: Socket M Intel® Core™2 Duo, Core™ Duo, Core™ Solo,
Celeron® M Mobile Processor with 533/667MHz FSB
System Chipset: Intel® 945GME + ICH7R
BIOS: AMI Flash BIOS
System memory:
Two 240-pin 667/533/400 MHz dual-channel DDR2 SDRAM
DIMM supported (system max. 4GB).
Ethernet
Dual PCIe GbE Broadcom BCM5787M chipsets
I/O Interface
2 x RS-232
8 x USB 2.0
(2 by Pin header (CPU Board) + 2 by bracket + 4 by Pin
header(backplane) )
4 x SATA with Intel RAID 0,1,5 and 10
1 x IDE
1 x FDD
1 x KB (by pin header)
1 x MS (by pin header)
Digital I/O: 8-bit digital l /O, 4-bit input/ 4-bit output
IrDA: 1 x IrDA by pin header
Super I/O: ITE IT8712F
Display Interface:
:
VGA / 18-bit dual channel LVDS integrated in Intel 945GME
Support HDTV resolution up to 1080i by component interface
Audio:
5.1 channel AC’97 Audio Kit with Realtek ALC655 codec
7.1 channel HD Audio Kit with Realtek ALC883 support dual
audio streams
SSD: CF type II
WDT: Software programmable supports 1-255 sec. System reset
Power supply: ATX Power
Power Consumption
5V@4.14A, 12V@2.9A, 3.3V@ 0.72A
(Intel Core 2 Duo T7200 2.06GHz/667 MHz CPU with 1GB
2
DDRII 667MHz)
Temperature: Operation:0~60°C (32~140°F)
Humidity: Operation: 5%~95% non-condensing
Dimension: 338 mm x 126 mm
Weight: GW: 1100 g / NW: 380 g
Ordering Information
PCIE-9452-R12:
PICMG 1.3 Socket M Intel® Core™ 2 Duo CPU Card With VGA,
Dual PCIe GbE, SATA and USB 2.0
CF-479B-RS
SDVO-100VGA-R10:
SDVO-100DVI-R10:
AC-KIT883HD-R10
7.1 Channel HD Audio Kit with Realtek ALC883 support dual audio
streams
AC-KIT08R-R10
: CPU cooler
PCIe x16 VGA Output SDVO Card supports dual display (IEI CPU
board only)
PCIe x16 DVI Output SDVO Card supports dual display (IEI CPU
board only)
32000-000066-RS
KB/MS cable with bracket
19800-000049-RS
32200-000017-RS
:
: 5.1 Channel AC'97 Audio Kit with Realtek ALC655
:
: LPT cable
: FDD cable
Jumpers setting and Connectors
J_CMOS1: Clear CMOS Setup
J_CMOS1 DESCRIPTION
1-2
(Default)
2-3 Clear CMOS Setup
Keep CMOS Setup
(Normal Operation)
J_VLVDS1: Set The Panel Voltage
J_LVDS1 DESCRIPTION
1-2
(Default)
2-3 Set The Voltage Level Of
Set The Voltage Level Of
Panel To VCC3 (+3.3V)
Panel To VCC (+5V)
J_CF1: CF Card Setup
J_CF1 DESCRIPTION
1-2
(Default)
2-3 Master
Slave
3
KB1:
5-pin Wafer Keyboard
Connector
PIN DESCRIPTION
1 Keyboard Clock
2 Keyboard Data
3 NC
4 GND
5 VCC
MS1:
5-pin Wafer Mouse Connector
PIN DESCRIPTION
1 Mouse Clock
2 Mouse Data
3 NC
4 GND
5 VCC
USB_01: Internal USB Connectors
PIN DESCRIPTION PIN DESCRIPTION
1 VCC 2 GND
3 DATA - 4 DATA +
5 DATA + 6 DATA 7 GND 8 VCC
COM1, COM2: External Serial Port Connector
PIN DESCRIPTION PIN DESCRIPTION
1
DCD#
6 DSR#
2 RXD 7 RTS#
3 TXD 8 CTS#
4 DTR# 9 RI#
5 GND 10 NC
LPT1: Parallel Port Connector
PIN DESCRIPTION PIN DESCRIPTION
1 STROBE# 14 AUTO FORM FEED #
2 DATA0 15 ERROR#
3 DATA1 16 INITIALIZE#
4 DATA2 17 PRINTER SELECT LN#
5 DATA3 18 GND
6 DATA4 19 GND
7 DATA5 20 GND
8 DATA6 21 GND
9 DATA7 22 GND
10 ACKNOWLEDGE# 23 GND
11 BUSY 24 GND
12 PAPER EMPTY 25 GND
13 PRINTER SELECT 26 NC
4
J_AUDIO1: Audio Source Connector
A
TV1: S-Video Connector
PIN DESCRIPTION
1 GND
2 AGREEN_Y
3 GND
4 ARED_C
RCA Connector (only video signal)
5 GND
6 ABLUE_CVBS
DIO1: Digital Input / Output Connector
PIN DESCRIPTION PIN DESCRIPTION
1 Ground 2 VCC
3 Output 3 4 Output 2
5 Output 1 6 Output 0
7 Input 3 8 Input 2
9 Input 1 10 Input 0
TXCTL1:
Backplane Power Connector
PIN DESCRIPTION
1 Ground
2 PS_ON
3 5VSB
F_PANEL1: External Switches and Indicators panel
Power
LED
PIN DESCRIPTION PIN DESCRIPTION
1
3 AC97_SDOUT 4 AC97_PCBEEP
5 AC97_SDIN 6 AC97_RST#
7 AC97_VCC 8 AC97_GND
9 AC97_12V 10 AC97_GND
PIN DESCRIPTION PIN DESCRIPTION
AC97_SYNC
1 VCC 2 VCC
3 N/C 4 N/C
5 GROUND 6 N/C
2 AC97_BITCLK
CPU_FAN1: CPU Fan Connector
PIN DESCRIPTION
1 Ground
2 +12V
3 Rotation Signal
4 Control
INVERTER1:
Panel Power Supply
PIN DESCRIPTION
1 BRIGHTNESS
2 GND
3 12V
4 GND
5 BL_EN
IR1:IrDA connector
PIN DESCRIPTION
1 VCC
2 NC
3 IR-RX
4 GND
5 IR-TX
Speaker
PWRBTN
HDDLED
7 PWRBTN+ 8 Speaker
9 PWRBTN- 10 N/C
11 VCC 12 Reset13 HDLED- 14 GND
RESET
5
LVDS1: LVDS Connector
PIN DESCRIPTION PIN DESCRIPTION
1 GND 2 GND
3 LVDSA_DATA0 4 LVDSA_DATA#0
5 LVDSA_DATA1 6 LVDSA_DATA#1
7 LVDSA_DATA2 8 LVDSA_DATA#2
9 LVDSA_CLK 10 LVDSA_CLK#
11 LVDSA_DATA0 12 LVDSA_DATA#3
13 GND 14 GND
15 LVDSB_DATA0 16 LVDSB_DATA#0
17 LVDSB_DATA1 18 LVDSB_DATA#1
19 LVDSB_DATA2 20 LVDSB_DATA#2
21 LVDSB_CLK 22 LVDSB_CLK#
23 LVDSB_DATA3 24 LVDSB_DATA#3
25 GND 26 GND
27 VCC/VCC3 28 VCC/VCC3
29 VCC/VCC3 30 VCC/VCC3
IDE1: IDE Interface Connector
PIN DESCRIPTION PIN DESCRIPTION
1 RESET# 2 GND
3 DATA 7 4 DATA 8
5 DATA 6 6 DATA 9
7 DATA 5 8 DATA 10
9 DATA 4 10 DATA 11
11 DATA 3 12 DATA 12
13 DATA 2 14 DATA 13
15 DATA 1 16 DATA 14
17 DATA 0 18 DATA 15
19 GND 20 N/C
21 IDE DRQ 22 GND
23 IOW# 24 GND
25 IOR# 26 GND
27 IDE CHRDY 28 BALE – DEFAULT
29 IDE DACK 30 GND
31 INTERRUPT 32 N/C
33 SA1 34 PDIAG#
35 SA0 36 SA2
37 HDC CS0# 38 HDC CS1#
39 HDD ACTIVE# 40 GND
6
Board Layout: Jumper and Connector Locations
7
