MODAT-550A Mobile Data Collector
Page i
Rev. 1.00 – September 11, 2018
MODEL:
MODAT-550A
5.5” Mobile Data Collector with Oct a-Core ARM® Cortex®-A53
1.5 GHz CPU, Android 7.0 OS, Capacitive Touchscreen,
Bluetooth 4.0 LE, 802.11a/b/g/n Wi-Fi, 1D/2D Barcode Scanner,
GPS, NFC, 13-Megapixel Camera, IP 65, RoHS Comp li ant
User Manual
MODAT-550A Mobile Data Collector
Page ii
Date Version Changes
September 11, 2018 1.00 Initial release
Revision
MODAT-550A Mobile Data Collector
Page iii
Copyright
COPYRIGHT NOTICE
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.
MODAT-550A Mobile Data Collector
Page iv
Manual Conventions
WARNING
Warnings appear where overlooked details may cause damage to the
equipment or result in personal injury. Warnings should be taken
seriously.
CAUTION
Cautionary messages should be heeded to help red uce the chance of
losing data or damaging the product.
NOTE
These messages inform the reader of essent ial but non-critical
information. These messages should be read carefully as any directions
or instructions contained therein can help av oid m aking mistakes.
HOT SURFACE
This symbol indicates a hot surface that shoul d not be touched without
taking care.
MODAT-550A Mobile Data Collector
Page v
Table of Contents
1 INTRODUCTION .......................................................................................................... 1
1.1 OVERVIEW .................................................................................................................. 2
1.2 MODEL VARIATIONS ................................................................................................... 2
1.3 FEATURES ................................................................................................................... 3
1.4 FRONT PANEL ............................................................................................................. 3
1.5 REAR PANEL ............................................................................................................... 4
1.6 SIDE PANELS .............................................................................................................. 5
1.7 TOP PANEL ................................................................................................................. 5
1.8 BOTTOM PANEL .......................................................................................................... 6
1.9 TECHNICAL SPECIFICATIONS ...................................................................................... 6
1.10 DIMENSIONS ............................................................................................................. 8
2 UNPACKING ................................................................................................................. 9
2.1 PACKING LIST ........................................................................................................... 10
2.2 OPTIONAL ITEMS ....................................................................................................... 11
3 INSTALLATION ......................................................................................................... 12
3.1 ANTI-STATIC PRECAUTIONS ...................................................................................... 13
3.2 INSTALLATION PRECAUTIONS ................................................................................... 13
3.3 CHARGING THE SYSTEM ........................................................................................... 14
3.4 SIM CARD INSTALLATION ........................................................................................ 16
3.5 MICROSD CARD INSTALLATION ................................................................................ 18
3.6 I/O CONNECTORS ..................................................................................................... 19
3.6.1 Headset Jack .................................................................................................... 19
3.6.2 Micro USB Connector ...................................................................................... 19
3.7 SYSTEM MAINTENANCE ........................................................................................... 21
4 USING THE MODAT-550A ........................................................................................ 22
4.1 POWERING ON/OFF .................................................................................................. 23
4.2 HOME SCREEN ......................................................................................................... 24
4.2.1 Adding a Home Screen ..................................................................................... 24
MODAT-550A Mobile Data Collector
Page vi
4.2.2 Switching between Home Screens .................................................................... 25
4.2.3 Favorites Tray .................................................................................................. 26
4.2.4 Adding Shortcuts .............................................................................................. 27
4.2.5 Arranging the Home Screen ............................................................................. 28
4.3 NAVIGATION BUTTONS ............................................................................................. 29
4.4 STATUS BAR ............................................................................................................. 30
4.5 SETTINGS ................................................................................................................. 32
4.5.1 Wireless & Networks ........................................................................................ 32
4.5.1.1 More Settings ............................................................................................ 33
4.5.2 Barcode ............................................................................................................ 35
4.5.3 Display ............................................................................................................. 36
4.5.4 Notifications ..................................................................................................... 38
4.5.1 Sound ................................................................................................................ 39
4.5.2 Apps .................................................................................................................. 40
4.5.3 Storage ............................................................................................................. 41
4.5.4 Battery .............................................................................................................. 42
4.5.5 Memory ............................................................................................................ 43
4.5.6 Users ................................................................................................................ 44
4.5.7 DuraSpeed ........................................................................................................ 45
4.5.8 Location ........................................................................................................... 46
4.5.9 Security ............................................................................................................ 47
4.5.10 Accounts ......................................................................................................... 49
4.5.11 Language & Input .......................................................................................... 50
4.5.12 Backup & Reset .............................................................................................. 51
4.5.13 Date & Time ................................................................................................... 52
4.5.14 Accessibility ................................................................................................... 53
4.5.15 Printing .......................................................................................................... 55
4.5.1 Scheduled Power On & Off .............................................................................. 56
4.5.2 About Phone ..................................................................................................... 57
4.6 CAMERA ................................................................................................................... 59
A REGULATORY COMPLIANCE .............................................................................. 60
B SAFETY PRECAUTIONS ......................................................................................... 62
B.1 SAFETY PRECAUTIONS ............................................................................................. 63
B.1.1 General Safety Precautions ............................................................................. 63
MODAT-550A Mobile Data Collector
Page vii
B.1.2 Anti-static Precautions .................................................................................... 64
B.1.3 Product Disposal ............................................................................................. 65
B.2 MAINTENANCE AND CLEANING PRECAUTIONS ........................................................ 65
B.2.1 Maintenance and Cleaning .............................................................................. 66
B.2.2 Cleaning Tools ................................................................................................. 66
C HAZARDOUS MATERIALS DISCLOSURE ......................................................... 67
MODAT-550A Mobile Data Collector
Page viii
List of Figures
Figure 1-1: MODAT-550A ............................................................................................................... 2
Figure 1-2: Front Panel .................................................................................................................. 3
Figure 1-3: Rear Panel .................................................................................................................... 4
Figure 1-4: Side Panels .................................................................................................................. 5
Figure 1-5: Top Panel ..................................................................................................................... 5
Figure 1-6: Bottom Panel ............................................................................................................... 6
Figure 1-7: Dimensions (units in mm) .......................................................................................... 8
Figure 3-1: Connecting the Micro USB Cable to the MODAT-550A ......................................... 14
Figure 3-2: Connecting the Power Plug ..................................................................................... 15
Figure 3-3: Connecting the MODAT-550A to the Power Adapter ............................................ 15
Figure 3-4: Battery Cover Retention Screws ............................................................................. 16
Figure 3-5: Removing the Battery ............................................................................................... 17
Figure 3-6: SIM Card Installation ................................................................................................. 17
Figure 3-7: microSD Card Slot .................................................................................................... 18
Figure 3-8: MODAT-550A Headset Jack ..................................................................................... 19
Figure 3-9: USB for File Transfer ................................................................................................ 20
Figure 3-10: USB Connection Option Screen ............................................................................ 21
Figure 4-1: Power Button ............................................................................................................. 23
Figure 4-2: Power Off Menu ......................................................................................................... 23
Figure 4-3: Adding a Home Screen ............................................................................................. 24
Figure 4-4: Multiple Home Screens ............................................................................................. 25
Figure 4-5: Favorites Tray ............................................................................................................ 26
Figure 4-6: All Apps/WIDGETS Page .......................................................................................... 27
Figure 4-7: Trash an Item on Home Screen ............................................................................... 28
Figure 4-8: Navigation Buttons ................................................................................................... 29
Figure 4-9: Status Bar .................................................................................................................. 30
Figure 4-10: Notification List and System Status ...................................................................... 31
Figure 4-11: Wireless and Networks Settings ........................................................................... 32
Figure 4-12: More Settings Menu ................................................................................................ 33
Figure 4-13: Barcode Menu ......................................................................................................... 35
Figure 4-14: Display Menu ........................................................................................................... 36
MODAT-550A Mobile Data Collector
Page ix
Figure 4-15: Notifications Menu .................................................................................................. 38
Figure 4-16: Sound Menu ............................................................................................................. 39
Figure 4-17: Apps Menu ............................................................................................................... 40
Figure 4-18: Storage Menu .......................................................................................................... 41
Figure 4-19: Battery Menu ........................................................................................................... 42
Figure 4-20: Memory Menu .......................................................................................................... 43
Figure 4-21: Users Menu .............................................................................................................. 44
Figure 4-22: DuraSpeed Menu ..................................................................................................... 45
Figure 4-23: Location Menu ......................................................................................................... 46
Figure 4-24: Security Menu .......................................................................................................... 47
Figure 4-25: Accounts Menu ....................................................................................................... 49
Figure 4-26: Language & Input Menu ......................................................................................... 50
Figure 4-27: Backup & Reset Menu ............................................................................................ 51
Figure 4-28: Date & Time Menu ................................................................................................... 52
Figure 4-29: Accessibility Menu .................................................................................................. 53
Figure 4-30: Printing Menu .......................................................................................................... 55
Figure 4-31: Scheduled Power On & Off Menu .......................................................................... 56
Figure 4-32: About Phone Menu ................................................................................................. 57
Figure 4-33: Camera Application ................................................................................................ 59
MODAT-550A Mobile Data Collector
Page x
List of Tables
Table 1-1: Model Variations ........................................................................................................... 2
Table 1-2: Technical Specifications .............................................................................................. 7
Table 2-1: Packing List ................................................................................................................. 11
Table 2-2: Optional Items ............................................................................................................. 11
Table 4-1: Navigation Buttons ..................................................................................................... 29
MODAT-550A Mobile Data Collector
Page 1
Chapter
1
1 Introduction
MODAT-550A Mobile Data Collector
Page 2
1.1 Overview
Figure 1-1: MODAT-550A
The MODAT-550A is an Android-based mobile data collector with a 5.5” touchscreen. At
the heart of the system is the octa-core ARM
communication technologies include 802. 11a/b/ g/n Wi-Fi, B l uetooth 4.0 LE and 4G. Other
peripherals include a 13-megapixel camera, a 1D/2D barcode scanner, a microSD card
slot, a Micro USB port, a headset jack and a speaker.
1.2 Model Variations
Model System Barcode Scanner
MODAT-550A-OA53
MODAT-550A-OA53-ET
Table 1-1: Model Variations
®
Cortex®-A53 1.5 GHz CPU. Wireless
Octa-core 64-bit ARM®
Cortex®-A53 1.5 GHz CPU,
2 GB LPDDR3, 16 GB eMMC
1D/2D imager scan engine
No
MODAT-550A Mobile Data Collector
Page 3
Figure 1-2: Front Panel
1.3 Features
Some of the MODAT-550A features include:
5.5” LCD with capacitive touchscreen
Octa-core ARM
Android 7.0 OS
13-megapixel camera with flashlight
Bluetooth 4.0 LE, 802.11a/b/g/n Wi-Fi and 4G wireless communication
technologies
Built-in GPS with internal antenna
Optional 1D/2D barcode scanner
IP 65 protection
RoHS compliant
1.4 Front Panel
®
Cortex®-A53 1.5 GHz CPU
The front panel of the MODAT-550A has a 5.5” LCD with capacitive touchscreen, a
receiver, a microphone and a LED indicator.
MODAT-550A Mobile Data Collector
Page 4
1.5 Rear Panel
The rear panel consists of a 13-megapixel camera with flashlight, a speaker, a
microphone and the NFC area.
Figure 1-3: Rear Panel
MODAT-550A Mobile Data Collector
Page 5
1.6 Side Panels
The side panels contain a power button, two barcode trigger buttons and a Micro USB
port.
Figure 1-4: Side Panels
1.7 Top Panel
The top panel contains a 1D/2D barcode scanner and a headset jack.
Figure 1-5: Top Panel
MODAT-550A Mobile Data Collector
Page 6
1.8 Bottom Panel
The bottom panel has a docking connector.
Figure 1-6: Bottom Panel
1.9 Technical Specifications
The MODAT-550A technical specifications are listed in the tabl e below.
Display
LCD Size
Brightness (cd/m2)
Max. Resolution
Viewing Angle
Touchscreen
System
CPU
Operating System
Memory
Storage
Communication
Wi-Fi
Bluetooth
5.5”
300
1080 (H) x 1920 (V)
80/80/80/80 degree
5-point capacitive
Octa-core 64-bit ARM® Cortex®-A53 1.5 GHz
Android 7.0
16 GB eMMC
2 GB LPDDR3
1 x microSD card slot
802.11a/b/g/n
Bluetooth 4.0 LE
GPS
GPS/GLONASS
MODAT-550A Mobile Data Collector
Page 7
TDD (Band 38, 39, 40, 41b)
GSM (850, 900, 1800, 1900)
WCDMA (Band 1, 2, 5, 8)
Modem (Optional)
Data Collection
TDS-CDMA (Band 34, 39)
LTE FDD (Band 1, 2, 3, 4, 5, 7, 8, 20)
Barcode
Camera
NFC
Indicator and Buttons
LED Indicator
Buttons
I/O Interface
Audio
USB
Power
Power Adapter
Battery
1D/2D imager scan engine (MODAT-550A-OA53 only)
13-megapixel AF rear camera
Yes
Green/red
Power button
2 x Barcode trigger buttons
1 x Headset jack
2 x Microphone
1 x Receiver
1 x Speaker (0.5 W)
1 x High-speed Micro USB 2.0 port
5V, 3A
4000 mAh
Environment
Operating Temperature
Storage Temperature
Humidity
Drop Survival
Environment Protection
Physical Characteristics
Dimensions (LxWxH)
Weight
Table 1-2: Technical Specifications
-10ºC ~ 50ºC
-20ºC ~ 60ºC
10% ~ 95%, non-condensing
1.5 m
IP 65
160.9 mm x 85.4 mm x 28.85 mm
380 g
MODAT-550A Mobile Data Collector
Page 8
1.10 Dimensions
Figure 1-7: Dimensions (units in mm)
MODAT-550A Mobile Data Collector
Page 9
Chapter
2
2 Unpacking
MODAT-550A Mobile Data Collector
Page 10
installation. The plastic layer protects the monitor surface during
was purchased from or contact an IEI sales
To unpack the MODAT-550A, follow the steps below:
WARNING!
Only remove the protective plastic cover stuck to the front screen after
installation process.
Step 1: Carefully cut the tape sealing the box. Only cut deep enough to break the tape.
Step 2: Open the box.
Step 3: Lift the MODAT-550A out of the box.
Step 4: Make sure all the components listed in the packing list are present. Step 0:
2.1 Packing List
NOTE:
If any of the components listed in the checklist below are missing, do
not proceed with the installation. Contact the IEI reseller or vendor the
MODAT-550A
representative directly by sending an email to sales@ieiworld.com.
The MODAT-550A is shipped with the following components:
Quantity Item Image
1 MODAT-550A
MODAT-550A Mobile Data Collector
Page 11
Quantity Item Image
1 Power adapter
(P/N: 63040-480015-001-RS)
1 Micro USB cable
(P/N: 32001-014300-200-RS)
1 Hand strap
(P/N: 46035-000300-RS)
Table 2-1: Packing List
2.2 Optional Items
The following are optional components which m ay be separately purchased:
Item Image
Charging cradle
(P/N: MODAT-531A-CR01-R10)
Leather case
(P/N: 7Z000-MODAT531APOUCH)
Table 2-2: Optional Items
MODAT-550A Mobile Data Collector
Page 12
Chapter
3
3 Installation
MODAT-550A Mobile Data Collector
Page 13
Failure to take ESD precautions during the maintenance of the
3.1 Anti-static Precautions
WARNING:
MODAT-550A may result in permanent damage to the MODAT-550A
and severe injury to the user.
Electrostatic discharge (ESD) can cause serious damage to electronic components,
including the MODAT-550A. Dry climates are especially susc eptib le t o ES D. I t i s the refor e
critical that whenever the MODAT-550A is accessed internally, or any other electrical
component is handled, the following anti-stat i c precautions are strictly adhered to.
Wear an anti-static wristband: - Wearing a simple anti-static wristband can
help to prevent ESD from damaging the board.
Self-grounding: - Before handling the board touch a ny grounded conducting
material. During the time the board is handled, f requently touch any
conducting materials that are connected to the ground.
Use an anti-static pad: - When configuring the MODAT-550A, place it on an
antic-static pad. This reduces the possibility of ESD damaging the
MODAT-550A.
3.2 Installation Precautions
When installing the MODAT-550A, please follow the precautions listed below:
Power turned off: When installing the MODAT-550A, make sure the power is
off. Failing to turn of f the power may cause severe injury to the body and/or
damage to the system.
Certified Engineers: Only certified engineers should install and modify
onboard functionalities.
Anti-static Discharge: If a user open the rear panel of the MODAT-550A, to
configure the jumpers or plug in added peripheral dev ices, ground themselves
first and wear and anti-static wristband.
MODAT-550A Mobile Data Collector
Page 14
WARNING:
Danger of explosion if battery is incorrectly replaced. Replace only with the
same or equivalent type recommended by the manufacturer.
Disposal of a battery into fire or a hot ove n, or mechanically crushing or
cutting of a battery, that can result in an explosion.
Leaving a battery in an extremely high temperature surrounding
environment that can result in an explosion or the leakage of flammable
liquid or gas.
A battery subjected to extremely low air pressure that may result in an
explosion or the leakage of flammable liquid or gas.
3.3 Charging the System
To start using the MODAT-550A, the user must charge the MODAT-550A by the power
adapter. To charge the MODAT-550A, please follow the steps below.
Step 1: Open the protective rubber cover to expose the Micro USB port.
Step 2: Connect the Micro USB plug of the Micro USB cable to the Micro USB connector
of the MODAT-550A (Figure 3-1).
Figure 3-1: Connecting the Micro USB Cable to the MODAT-550A
MODAT-550A Mobile Data Collector
Page 15
Step 3: Pick the power plug that suits the user’s territory, and secure it to the power
adapter (Figure 3-2).
Figure 3-2: Connecting the Power Plug
Step 4: Connect the other end of the Micro USB cable to the USB connector of the
power adapter (Figure 3-3).
Then plug the power adapter to a power source.
OR connect the Micro USB cable directly to a computer.
Figure 3-3: Connecting the MODAT-550A to the Power Adapter
Step 5: The LED indicator on the front panel lights up in red to indicat e that the battery is
charging. When the battery is fully charged, the LED indicator turns green.
Step 0:
MODAT-550A Mobile Data Collector
Page 16
3.4 SIM Card Installation
Follow the steps below to install a SIM card.
Step 1: Release the six retention screws that secure the battery cover to the
MODAT-550A.
WARNING:
Before removing the battery cover, make sure that the syste m power is
turned off and all power to the system has been disconnected. Failing
to do so may cause severe damage to the MODAT-550A and injury to
the user.
Figure 3-4: Battery Cover Retention Screws
Step 2: Lift the battery cover up to remove.
MODAT-550A Mobile Data Collector
Page 17
Step 3: Remove the battery (Figure 3-5).
Figure 3-5: Removing the Battery
Step 4: Locate the SIM card slot and insert a SIM card into it (Figure 3-6).
Figure 3-6: SIM Card Installation
MODAT-550A Mobile Data Collector
Page 18
3.5 microSD Card Installation
This section covers the installation of a microSD card.
Step 1: Refer to Step 1 ~ Step 2 in Section 3.4 to remove the battery cover.
Step 2: Locate the microSD card slot and insert a microSD card into it.
Figure 3-7: microSD Card Slot
MODAT-550A Mobile Data Collector
Page 19
Figure 3-8: MODAT-550A Headset Jack
3.6 I/O Connectors
The I/O connectors are protected by a rubber cover. Open the rubber cover before
connecting any peripheral devices to the MODAT-550A.
3.6.1 Headset Jack
The headset jack on the top panel enables the MODAT-550A to be connected to a
headset. Open the protective rubber cover to ex pose the headset jack before connection.
3.6.2 Micro USB Connector
The MODAT-550A is equipped with a Micro USB connector that allows connection to a
computer or the supplied power ad apte r. Refer to Step 1 ~ Step 3 in Section 0 to connect
the MODAT-550A to a computer or power adapter b y using the supplied Micro USB cable.
After connecting the MODAT-550A to a computer, follow the steps below to allow
transferring files between the computer and MODAT-550A.
Step 1: Swipe down from the top of the screen, then tap USB for file transfer
(Figure 3-9).
MODAT-550A Mobile Data Collector
Page 20
Figure 3-9: USB for File Transfer
Step 2: The screen in Figure 3-10 should be displayed. Tap Transfer files to allow the
connected computer to recognize the MODAT-550A. Then the user can tran sf er
files between them.
MODAT-550A Mobile Data Collector
Page 21
Figure 3-10: USB Connection Option Screen
3.7 System Maintenance
If the components of the MODAT-550A fail, they must be replaced. Please contact the
system reseller or vendor to purchase the replacement parts.
NOTE:
A user cannot replace a motherboard. If the motherboard fails it must
be shipped back to IEI to be replaced. Please contact the system
vendor, reseller or an IEI sales person directly .
MODAT-550A Mobile Data Collector
Page 22
Chapter
4
4 Using the MODAT-550A
MODAT-550A Mobile Data Collector
Page 23
4.1 Powering On/Off
To power on/off the MODAT-550A, please follow the steps below:
Powering On: Press the power button until the start-up screen displays.
Figure 4-1: Power Button
Powering Off: Press and hold the power button until the Power of f menu as shown in
Figure 4-2 appears. Tap Power off to turn off the MODAT-550A.
Figure 4-2: Power Off Menu
NOTE:
When the MODAT-550A is powered on, press the power button once
to suspend the MODAT-550A or to resume from the suspend mode.
MODAT-550A Mobile Data Collector
Page 24
4.2 Home Screen
The MODAT-550A has mult iple home screen s allowing users to customize the screen with
widgets, apps and shortcuts. The following sections describe the basic technique to
manage the home screen.
4.2.1 Adding a Home Screen
To add a home screen, touch and hold an app/widget icon. A icon (Figure 4-3)
appears, indicating that a new home screen is available. Drag and release the icon to the
new home screen.
Figure 4-3: Adding a Home Screen
MODAT-550A Mobile Data Collector
Page 25
4.2.2 Switching between Home Screens
Swipe right or left to switch between home screens.
Figure 4-4: Multiple Home Screens
MODAT-550A Mobile Data Collector
Page 26
4.2.3 Favorites Tray
The Favorites tray at the bottom of each home screen allows users to keep the most
important or frequently used shortcuts.
Tap the (All Apps) button at the center of the Favorites Tray to access the All Apps
page.
Figure 4-5: Favorites Tray
MODAT-550A Mobile Data Collector
Page 27
4.2.4 Adding Shortcuts
To add app or widget shortcuts on the home s cr een, follow the steps below.
Step 1: To add an app shortcut, tap the All Apps button on the home screen to access
the All Apps page.
To add a widget shortcut, touch and hold the backg round of a home screen, then
tap WIDGETS.
Step 2: Touch and hold an app/widget icon and drag it t o the home screen.
Figure 4-6: All Apps/WIDGETS Page
MODAT-550A Mobile Data Collector
Page 28
4.2.5 Arranging the Home Screen
The items on the home screen can be moved and deleted. Touch and hold an item on the
home screen and drag it where you want. To trash the item on the screen, drag it to the
Remove icon. Release the icon when it turns red.
Figure 4-7: Trash an Item on Home Screen
MODAT-550A Mobile Data Collector
Page 29
4.3 Navigation Buttons
The three navigation buttons shown in Figure 4-8 can always be found at the bottom of
every screen.
Figure 4-8: Navigation Buttons
Buttons Description
Back Tap to return to the previous screen.
Home Tap to return to the home screen.
Recents Tap to display all the recently used applications.
Table 4-1: Navigation Buttons
MODAT-550A Mobile Data Collector
Page 30
4.4 Status Bar
The status bar on the top of the screen (Figure 4-9) displays system status, such as
battery level or signal strength.
Figure 4-9: Status Bar
Swipe down from the status bar to view notificat ion and st atus details (Figure 4-10).
MODAT-550A Mobile Data Collector
Page 31
Figure 4-10: Notification List and System Status
MODAT-550A Mobile Data Collector
Page 32
4.5 Settings
The Settings menu allows configuration to the MODAT-550A, such as Wi-Fi, volume,
display brightness, etc. To enter the Settings menu, tap Settings on the All Apps page.
4.5.1 Wireless & Networks
Figure 4-11: Wireless and Networks Settings
In the Wireless & networks field, the user can turn on/o ff the Wi-Fi and Bluetooth functions,
and view the SIM card and data usage status.
Wi-Fi:
Allows the user to turn on or off the Wi-Fi function and manage the access
points. The user can tap to configure advanced Wi-Fi settings.
MODAT-550A Mobile Data Collector
Page 33
Bluetooth:
Allows the user to turn on or off the Bluetooth function and manage the
Bluetooth connections.
Data usage:
Allows the user to view data usage status.
4.5.1.1 More Settings
Figure 4-12: More Settings Menu
After tapping More in the Wireless & networks field, the user can configure the following
settings.
Airplane mode:
Allows the user to turn on or off the airplane mode.
MODAT-550A Mobile Data Collector
Page 34
NFC:
Allows the user to turns on or off t he NFC function and configure the data
exchange modes.
Wi-Fi calling:
Enables or disables Wi-Fi calling function.
Tethering & portable hotspot:
Allows the user to set this device as a portable Wi-Fi hotspot, conf igure the
hotspot settings and turn on or off the USB/Bluetooth tethering function.
VPN:
Sets up and manages Virtual Privat e Networks (VPNs).
Cellular networks:
Configures the cellular network settings.
MODAT-550A Mobile Data Collector
Page 35
4.5.2 Barcode
The barcode menu allows powering on/off the barcode reader and configuring its settings.
The barcode settings can also be set through the Barcode Reader application in the
application page.
Figure 4-13: Barcode Menu
Barcode on/off:
Turns on or off the barcode reader.
Scan mode:
Sets up the scan mode.
Output mode:
Sets up the output mode.
MODAT-550A Mobile Data Collector
Page 36
4.5.3 Display
Figure 4-14: Display Menu
Use the Display menu to configure the following items.
Brightness level:
Adjusts the screen brightness.
Adaptive brightness:
Turns on this function to optimize brightness level for available light.
Wallpaper:
Sets up the wallpaper.
Sleep:
Sets up the time of inactivity after which the screen turns to sleep mode.
MODAT-550A Mobile Data Collector
Page 37
Press power button twice for camera:
Enable or disable to quickly open camera without unl ocking screen.
Screen saver:
Configures the screensaver settings.
Font size:
Sets up the font size.
Display size:
Sets up the item size on the screen.
When device is rotated:
Allows the user to select to rotate the contents of the screen when the
MODAT-550A is rotated.
Cast:
Allows the user to turn on or of f the wireless displ ay function and manages the
wireless display devices.
MODAT-550A Mobile Data Collector
Page 38
4.5.4 Notifications
The Notifications menu allows the user to configure the notification settings of each app.
Figure 4-15: Notifications Menu
MODAT-550A Mobile Data Collector
Page 39
4.5.5 Sound
Use the Sound menu to configure sound volume, ringtone and sound enhancement
settings.
Figure 4-16: Sound Menu
MODAT-550A Mobile Data Collector
Page 40
4.5.6 Apps
The Apps menu displays the applications installed in the device, and allows users to
manage them.
Figure 4-17: Apps Menu
MODAT-550A Mobile Data Collector
Page 41
4.5.7 Storage
The Storage menu displays the status of the internal storage and the inserted microSD
card, and allows users to manage the data stored in them.
Figure 4-18: Storage Menu
MODAT-550A Mobile Data Collector
Page 42
4.5.8 Battery
The Battery menu displays the battery status and allows enabling the battery saver
function.
Figure 4-19: Battery Menu
MODAT-550A Mobile Data Collector
Page 43
4.5.9 Memory
The Memory menu displays the average memory use and m emory used by apps.
Figure 4-20: Memory Menu
MODAT-550A Mobile Data Collector
Page 44
4.5.10 Users
The Users menu allows you to add a new user profile and emergency information.
Figure 4-21: Users Menu
MODAT-550A Mobile Data Collector
Page 45
4.5.11 DuraSpeed
Use the DuraSpeed menu to enable or disable the DuraSpeed function which helps boost
the foreground app by restricting background apps.
Figure 4-22: DuraSpeed Menu
MODAT-550A Mobile Data Collector
Page 46
4.5.12 Location
Use the Location menu to turn on the location access function so that the apps can obtain
the user’s location information. When this function is turned on, the user can decide the
method to determine the user’s location.
Figure 4-23: Location Menu
MODAT-550A Mobile Data Collector
Page 47
4.5.13 Security
Figure 4-24: Security Menu
Use the Security menu to configure the following items.
Screen lock:
Sets up the way to unlock the screen.
Encrypt phone:
Once this item is enabled, the user will need to enter the numeric PIN,
password or pattern that have been set up to decrypt the MODAT-550A each
time when powering on.
Make passwords visible:
Enables to show password when typing.
MODAT-550A Mobile Data Collector
Page 48
Device administrators:
Views or deactivates the device administrators.
Unknown sources:
Enables to allow installation of applications from unknown sources.
Data protection:
Taps to protect the selected data from u nwanted access.
Credential storage:
In the Credential storage field, the user can manage the CA certificates and
install certificates from the phone storage.
Trust agents:
Taps to view or deactivate trust agents.
Screen pinning:
When this function is turned on, the user can keep t he current screen in view
until the user disables this function.
Apps with usage access:
Taps to manage the apps with usage acce ss.
MODAT-550A Mobile Data Collector
Page 49
4.5.14 Accounts
Tap Add account to start setting up an e-mail or corporate account.
Figure 4-25: Accounts Menu
MODAT-550A Mobile Data Collector
Page 50
4.5.15 Language & Input
Figure 4-26: Language & Input Menu
Use the Language & input menu to configure the following items.
Language:
Sets up the language for MODAT-550A.
Spell checker:
Allows the user to enable the spell checking function and to configure its
settings.
Personal dictionary:
Configures the user dictionary.
Keyboard & input methods:
Sets up the input methods.
MODAT-550A Mobile Data Collector
Page 51
Text-to-speech output:
Configures the text-to-speech settings.
Pointer speed:
Sets up the pointer speed.
4.5.16 Backup & Reset
Figure 4-27: Backup & Reset Menu
Use the Back & reset menu to configure the following items.
Back up my data:
Enable or disable to back up app data, Wi-Fi passwords and other settings to
Google server.
Network settings reset:
Resets all network settings, including Wi-Fi, Cellul ar data and Bluetooth.
MODAT-550A Mobile Data Collector
Page 52
DRM reset:
Factory data reset:
4.5.17 Date & Time
Deletes all the DRM licenses on the MODAT-550A.
Erases all data from the internal storage of the MODAT-550A.
Figure 4-28: Date & Time Menu
Use the Date & time menu to configure the following items.
Automatic date & time:
Turns on to use the net work-provided or GPS-provided time.
Automatic time zone:
Turns on to use the net work-provided time zone.
MODAT-550A Mobile Data Collector
Page 53
Set date:
Sets up the system date. This item is av ailable only when the Automatic date
& time item is set to Off.
Set time:
Sets up the system time. This item is available only when the Automatic date
& time item is set to Off.
Select time zone:
Sets up the time zone. This item is av ailable only when the Automatic time
zone item is disabled.
Use 24-hour format:
Turns on to use the 24-hour format.
4.5.18 Accessibility
Figure 4-29: Accessibility Menu
MODAT-550A Mobile Data Collector
Page 54
Use the Accessibility menu to configure the following items.
Services:
Displays the accessibility services that have been installed.
Captions:
Turns on/off the caption function and configures its settings.
Magnification gestures:
Enables to zoom in and out by triple-tapping the screen.
Font size:
Sets up the font size.
Display size:
Sets up the item size on the screen.
Click after pointer stops moving:
Turns on or off the automatic click function.
High contrast text:
Turns on to display text in high contrast level.
Power button ends call:
Turns on to set the power button to end calls.
Auto-rotate screen:
Turns on or off the auto-rotate function of the screen.
Speak passwords:
Turns on or off the speak password function.
Large mouse pointer:
Turns on or off the large mouse pointer.
Mono audio:
Enable or disable to combine channels when playi ng audio.
Accessibility shortcut:
Turns on to allow quickly enabling the accessibility features.
Text-to-speech output:
Configures the text-to-speech settings.
Touch & hold delay:
Configures the touch & hold delay settings.
Color inversion:
Turns on or off the color inversion function.
MODAT-550A Mobile Data Collector
Page 55
4.5.19 Printing
The Printing menu allows managing the printing services instal led on the MODAT-550A.
Color correction:
Turns on or off the color correction function.
Figure 4-30: Printing Menu
MODAT-550A Mobile Data Collector
Page 56
Figure 4-31: Scheduled Power On & Off Menu
4.5.20 Scheduled Power On & Off
The Scheduled power on & off menu allows the user to set up a power-on/off schedule.
MODAT-550A Mobile Data Collector
Page 57
4.5.21 About Phone
Figure 4-32: About Phone Menu
Use the About phone menu to check for new versions of system software and display the
following items.
System update:
Taps to check for new version of system software.
Status:
Taps to display the status of batteries, network, signal, etc.
Legal information:
Taps to display the legal information.
Model number:
Displays the model number.
MODAT-550A Mobile Data Collector
Page 58
CPU model:
Displays the CPU model.
Android version:
Displays the Android OS version.
Android security patch level:
Displays the Android security patch level.
GSM Baseband version:
Displays the GSM baseband version.
CDMA Baseband version:
Displays the CDMA bas eb and version.
Kernel version:
Displays the kernal version.
Build number:
Displays the build number.
Custom build version:
Displays the custom build version.
MODAT-550A Mobile Data Collector
Page 59
4.6 Camera
The MODAT-550A equips with a 13-megapixel camera with flashlight. Tap Camera on the
application page to launch it.
Figure 4-33: Camera Application
MODAT-550A Mobile Data Collector
Page 60
Appendix
A
A Regulatory Compliance
MODAT-550A Mobile Data Collector
Page 61
other devices in the equipment, the CE conformity
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this
DECLARATION OF CONFORMITY
This equipment has be en tested and f ound to com ply with specifi cations f or CE marking.
If the user modifies and/or installs
declaration may no longer apply.
FCC WARNING
This equipment complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
This device may not cause harmful interference, and
This device must accept any interference receiv ed, including interference
that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class A digital
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This
equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
MODAT-550A Mobile Data Collector
Page 62
Appendix
B
B Safety Precautions
MODAT-550A Mobile Data Collector
Page 63
The precautions outlined in this chapter should be strictly followed.
WARNING:
Failure to follow these precautions may result in permanent damage to
the MODAT-550A.
B.1 Safety Precautions
Please follow the safety precautions out l i ned i n the sections that follow:
B.1.1 General Safety Precautions
Please ensure the following safety precautions are adhered to at all times.
Follow the electrostatic precautions outlined below whenever the
MODAT-550A is opened.
Make sure the power is turned off and the power cord is disconnected
whenever the MODAT-550A is being installed, moved or modified.
Do not apply voltage levels that exceed the specified voltage range.
Doing so may cause fire and/or an electrical shock.
Electric shocks can occur if the MODAT-550A chassis is opened when the
MODAT-550A is running.
Do not drop or insert any objects into the ventilation openings of the
MODAT-550A.
If considerable amounts of dust, water, or fluids enter the MODAT-550A,
turn off the power supply immediat ely, unplug the pow er cord, and cont act the
MODAT-550A vendor.
DO NOT:
o Drop the MODAT-550A against a hard surface.
o Strike or exert excessive force onto the LCD panel .
o Touch any of the LCD panels with a sharp object
o In a site where the ambient temperature excee ds the rated temperature
MODAT-550A Mobile Data Collector
Page 64
Failure to take ESD precautions during the installation of the
B.1.2 Anti-static Precautions
WARNING:
MODAT-550A may result in permanent damage to the MODAT-550A
and severe injury to the user.
Electrostatic discharge (ESD) can cause serious damage to electronic components,
including the MODAT-550A. Dry climates are especially susc eptib le t o ES D. I t i s the refor e
critical that whenever the MODAT-550A is opened and any of the electrical components
are handled, the following anti-static prec autions are strictly adhered to.
Wear an anti-static wristband: Wearing a simple anti-static wristband can
help to prevent ESD from damaging any electrical component.
Self-grounding: Before handling any electrical component , touch any
grounded conducting material. During the ti m e the electrical component is
handled, frequently touch any conducting materials that are connected to the
ground.
Use an anti-static pad: When configuring or working with an electrical
component, place it on an antic-static pad. Thi s reduces the po ssibility of ESD
damage.
Only handle the edges of the electrical component: When handling the
electrical component, hold the electrical component by its edges.
MODAT-550A Mobile Data Collector
Page 65
Risk of explosion if battery is replaced by an incorrect type. Only
and local
B.1.3 Product Disposal
CAUTION:
certified engineers should replace the on-board bat tery.
Dispose of used batteries according to instructions
regulations.
Outside the European Union–If you wish to dispose of used electrical and
electronic products outside the Europea n Union, please contact your local
authority so as to comply with the correct dispo sal m ethod.
Within the European Union–The device that produces less waste and is
easier to recycle is classified as electronic device in terms of the E uropean
Directive 2012/19/EU (WEEE), and must not be disposed of as domestic
garbage.
EU-wide legislation, as implemented in each Membe r State, require s that
waste electrical and electronic products carrying the mark (left) must be
disposed of separately from normal household waste. This includes
monitors and electrical accessories, such as signal cables or power
cords. When you need to dispose of your display products, please follow
the guidance of your local authority, or ask the shop where you purchased the product.
The mark on electrical and electronic products only applie s to t he current Europ ean Unio n
Member States.
Please follow the national guidelines for elect rical and electronic product disposal.
B.2 Maintenance and Cleaning Precautions
When maintaining or cleaning the MODAT-550A, please follow the guideli nes below.
MODAT-550A Mobile Data Collector
Page 66
B.2.1 Maintenance and Cleaning
Prior to cleaning any part or component of the MODAT-550A, please read the details
below.
Except for the LCD panel, never spray or squirt li quids directly onto any other
components. To clean the LCD panel, gently wipe it with a piece of soft dry
cloth or a slightly moistened cloth.
The interior of the MODAT-550A does not require cleaning. Keep fluids away
from the MODAT-550A interior.
Be cautious of all small removable component s when vacuuming the
MODAT-550A.
Turn the MODAT-550A off before cleaning the MODAT-550A.
Never drop any objects or liquids through the openings of the MODAT-550A.
Be cautious of any possible allergic reactions t o solvents or chemicals used
when cleaning the MODAT-550A.
Avoid eating, drinking and smoking within vicinity of the MODAT-550A.
B.2.2 Cleaning Tools
Some components in the MODAT-550A may only be cleaned using a product specifically
designed for the purpose. In such case, the product will be explicitly mentioned in the
cleaning tips. Below is a list of items to use when cleaning the MODAT-550A.
Cloth – Although paper towels or tissues can be used, a soft, clean piece of
cloth is recommended when cleaning the MODAT-550A.
Water or rubbing alcohol – A cloth moistened with water or rubbing alcohol
can be used to clean the MODAT-550A.
Using solvents – T he use of solvents is not recomm ended when cleaning the
MODAT-550A as they may damage the plastic parts.
Vacuum cleaner – U sing a vacuum specifically designed for computers is
one of the best methods of cleaning the MODAT-550A. Dust and dirt can
restrict the airflow in the MODAT-550A and cause its circuitry to corrode.
Cotton swabs - Cotton swaps moistened with rubbing alcohol or water are
excellent tools for wiping hard to reach areas.
Foam swabs - Whenever possible, it is best to use lint free swabs such as
foam swabs for cleaning.
MODAT-550A Mobile Data Collector
Page 67
Appendix
C
C Hazardous Materials
Disclosure
MODAT-550A Mobile Data Collector
Page 68
The details provided in this appendix are to ensure that the product is compliant with the
Peoples Republic of China (China) RoHS standards. The table below acknowledges the
presences of small quantities of certain material s in the product, and is applicable t o China
RoHS only.
A label will be placed on each product to indicate the estimated “Environmentally Friendly
Use Period” (EFUP). This is an estimate of the number of years that these substances
would “not leak out or undergo abrupt change.” This product may contain replaceable
sub-assemblies/components which have a shorter EFUP such as batteries and lamps.
These components will be separately marked.
Please refer to the table on the next page.
Part Name Toxic or Hazardous Substances and Elements
Lead
(Pb)
Housing
Display
Printed Circuit
Board
Metal Fasteners
Cable Assembly
Fan Assembly
Power Supply
Assemblies
Battery
O: This toxic or hazardous substance is contained in all of the homogeneous materials for the part is below th e li m it
requirement in SJ/T11363-2006 (now replaced by GB/T 26572-2011).
X: This toxic or hazardous substance is contained in at least one of the homogeneous materials for this part is above
O O O O O O
O O O O O O
O O O O O O
O O O O O O
O O O O O O
O O O O O O
O O O O O O
O O O O O O
Mercury
(Hg)
Cadmium
(Cd)
Hexavalent
Chromium
(CR(VI))
Polybrominated
Biphenyls
(PBB)
Polybrominated
Diphenyl Ethers
(PBDE)
the limit requirement in SJ/T11363-2006 (now replaced by GB/T 26572-2011).
MODAT-550A Mobile Data Collector
Page 69
此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符
合中国 RoHS 标准规定的限量要求。
本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的
年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元
件将会单独标示出来。
部件名称
壳体
显示
印刷电路板
金属螺帽
电缆组装
风扇组装
电力供应组装
电池
有毒有害物质或元素
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(CR(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
O O O O O O
O O O O O O
O O O O O O
O O O O O O
O O O O O O
O O O O O O
O O O O O O
O O O O O O
O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11363-2006 (现由 GB/T 26572-2011 取代)
标准规定的限量要求以下。
X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11363-2006 (现由 GB/T 26572-2011
取代) 标准规定的限量要求。
Loading...
