KINO-690S1 Mini-ITX Motherboard
Page i
KINO-LUKE-R20 Half-size CPU Card
Date Version Changes
2008-08-15 1.10 Changed BIOS ID
Changed Address Mapping in the Appendix
2007-06-26 1.00 Initial release
KINO-690S1 Mini-ITX Motherboard
Revision
Page ii
KINO-690S1 Mini-ITX Motherboard
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
Copyright
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.
Page iii
KINO-LUKE-R20 Half-size CPU Card
NOTE:
If any of the components listed in the checklist below are missing,
please do not proceed with the installation. Contact the IEI reseller or
vendor you purchased the KINO-690S1 from or contact an IEI sales
representative directly. To contact an IEI sales representative, please
KINO-690S1 Mini-ITX Motherboard
Packing List
send an email to
The items listed below should all be included in the KINO-690S1 package.
1 x KINO-690S1 single board computer
1 x IDE cable
1 x I/O shielding
1 x SATA power cables
2 x SATA cables
1 x Dual RS-232 cable
1 x Mini jumper pack
1 x Utility CD
1 x 1 x QIG (quick installation guide)
Images of the above items are shown in Chapter 3.
sales@iei.com.tw.
Page iv
KINO-690S1 Mini-ITX Motherboard
Table of Contents
1 INTRODUCTION..................................................................................................... 1
1.1 OVERVIEW ................................................................................................................. 2
1.1.1 KINO-690S1 Features........................................................................................ 2
1.2 KINO-690S1 OVERVIEW........................................................................................... 2
1.2.1 KINO-690S1 Overview Photo............................................................................ 2
1.2.2 KINO-690S1 Peripheral Connectors and Jumpers ........................................... 4
1.2.3 Technical Specifications..................................................................................... 5
2 DETAILED SPECIFICATIONS............................................................................. 7
2.1 DIMENSIONS .............................................................................................................. 8
2.1.1 Board Dimensions.............................................................................................. 8
2.1.2 External Interface Panel Dimensions................................................................ 9
2.2 DATA FLOW................................................................................................................ 9
2.3 COMPATIBLE PROCESSORS ........................................................................................11
2.3.1 Supported Processors .......................................................................................11
2.3.2 DDR2 Memory Controller................................................................................11
2.3.3 Processor Electrical Interfaces........................................................................ 12
2.3.4 Processor Power Management........................................................................ 12
2.4 AMD 690G NORTHBRIDGE CHIPSET ....................................................................... 12
2.4.1 PCI Express Interface...................................................................................... 12
2.4.1.1 PCIe x1 Expansion.................................................................................... 12
2.4.2 PCIe GbE Ethernet.......................................................................................... 13
2.4.3 Acceleration Features...................................................................................... 14
2.4.4 Display Support ............................................................................................... 15
2.4.4.1 TV Out ...................................................................................................... 15
2.4.4.2 Multiple Display Features......................................................................... 16
2.4.4.3 DVI ........................................................................................................... 16
2.5 AMD SB600 SOUTHBRIDGE CHIPSET...................................................................... 16
2.5.1 CPU Interface.................................................................................................. 16
2.5.2 A-Link Xpress II interface to the Northbridge................................................. 16
2.5.3 PCI Host Bus Controller.................................................................................. 17
Page v
KINO-LUKE-R20 Half-size CPU Card
2.5.4 USB Controllers............................................................................................... 18
2.5.5 SMBus Controller ............................................................................................ 19
2.5.6 Interrupt Controller......................................................................................... 19
2.5.7 DMA Controller............................................................................................... 19
2.5.8 LPC host bus controller................................................................................... 19
2.5.9 SATA II AHCI Controller................................................................................. 20
2.5.10 IDE Controller............................................................................................... 21
2.5.11 AC Link interface ........................................................................................... 21
2.5.12 T imers............................................................................................................. 23
2.5.13 RTC (Real Time Clock).................................................................................. 24
2.5.14 Power Management....................................................................................... 24
2.5.15 Hardware Monitor ......................................................................................... 24
2.6 LPC BUS COMPONENTS........................................................................................... 25
2.6.1 LPC Bus Overview........................................................................................... 25
KINO-690S1 Mini-ITX Motherboard
2.6.2 BIOS Chipset: .................................................................................................. 25
2.6.3 TPM Module .................................................................................................... 26
2.6.4 Super I/O chipset.............................................................................................. 26
2.6.4.1 Super I/O LPC Interface ........................................................................... 27
2.6.4.2 Super I/O 16C550 UARTs ........................................................................ 27
2.6.4.3 Super I/O Enhanced Hardware Monitor................................................... 27
2.6.4.4 Super I/O Fan Speed Controller................................................................ 27
2.6.4.5 Super I/O Keyboard and Mouse Controller.............................................. 27
2.6.4.6 Super I/O Infrared..................................................................................... 28
2.6.5 Serial Port Chipset........................................................................................... 28
2.7 ENVIRONMENTAL AND POWER SPECIFICATIONS ....................................................... 28
2.7.1 System Monitoring........................................................................................... 28
2.7.2 Operating Temperature and Temperature Control........................................... 29
2.7.3 Power Consumption......................................................................................... 30
3 UNPACKING.......................................................................................................... 31
3.1 ANTI-STATIC PRECAUTIONS...................................................................................... 32
3.2 UNPACKING.............................................................................................................. 32
3.2.1 Unpacking Precautions.................................................................................... 32
3.3 UNPACKING CHECKLIST........................................................................................... 33
3.3.1 Package Contents............................................................................................. 33
Page vi
KINO-690S1 Mini-ITX Motherboard
3.4 OPTIONAL ITEMS...................................................................................................... 35
4 CONNECTOR PINOUTS...................................................................................... 37
4.1 PERIPHERAL INTERFACE CONNECTORS .................................................................... 38
4.1.1 KINO-690S1 Layout......................................................................................... 38
4.1.2 Peripheral Interface Connectors ..................................................................... 38
4.1.3 External Interface Panel Connectors............................................................... 40
4.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 40
4.2.1 ATX Power Connector ..................................................................................... 40
4.2.2 Digital Input/Output (DIO) Connector............................................................ 41
4.2.3 Fan Connector (+12V) .................................................................................... 42
4.2.4 Front Panel Connector (14-pin)...................................................................... 43
4.2.5 IDE Connector (40-pin)................................................................................... 45
4.2.6 Infrared Interface Connector (5-pin)............................................................... 46
4.2.7 PCI Slot............................................................................................................ 47
4.2.8 PCI Express x1 Slot.......................................................................................... 52
4.2.9 SATA Drive Connectors ................................................................................... 54
4.2.10 Serial Port Connector (COM3) ..................................................................... 55
4.2.11 Serial Port Connector (COM4)(RS-232, RS-422 or RS-485)........................ 56
4.2.12 Trusted Platform Module (TPM) Connector.................................................. 57
4.2.13 TV Out Connector.......................................................................................... 58
4.2.14 USB Connectors (Internal)............................................................................ 59
4.3 EXTERNAL PERIPHERAL INTERFACE CONNECTOR PANEL......................................... 60
4.3.1 Audio Connector .............................................................................................. 60
4.3.2 DVI and VGA Combo Connector..................................................................... 61
4.3.3 Keyboard/Mouse Connector............................................................................ 63
4.3.4 LAN Connectors............................................................................................... 64
4.3.5 Serial Port Connectors (COM1 and COM2 ).................................................. 66
4.3.6 USB Connector ................................................................................................ 66
5 INSTALLATION .................................................................................................... 68
5.1 ANTI-STATIC PRECAUTIONS...................................................................................... 69
5.2 INSTALLATION CONSIDERATIONS ............................................................................. 70
5.2.1 Installation Notices.......................................................................................... 70
5.2.2 Installation Checklist....................................................................................... 71
Page vii
KINO-LUKE-R20 Half-size CPU Card
5.3 UNPACKING.............................................................................................................. 72
5.3.1 Unpacking Precautions.................................................................................... 72
5.4 CPU, CPU COOLING KIT AND DIMM INSTALLATION ............................................. 73
5.4.1 AMD Socket S1 CPU Installation.................................................................... 73
5.4.2 Cooling Kit CF-479B-RS Installation.............................................................. 75
5.4.3 SO-DIMM Installation..................................................................................... 77
5.5 JUMPER SETTINGS.................................................................................................... 78
5.5.1 Clear CMOS Jumper........................................................................................ 79
5.5.2 COM 4 Function Select Jumper....................................................................... 80
5.6 CHASSIS INSTALLATION ........................................................................................... 81
5.6.1 Airflow.............................................................................................................. 81
5.6.2 Motherboard Installation................................................................................. 82
5.7 INTERNAL PERIPHERAL DEVICE CONNECTIONS........................................................ 82
5.7.1 Peripheral Device Cables................................................................................ 82
KINO-690S1 Mini-ITX Motherboard
5.7.2 ATA Flat Cable Connection ............................................................................. 83
5.7.3 Dual RS-232 Cable Connection....................................................................... 84
5.7.4 SATA Drive Connection ................................................................................... 85
5.7.5 USB Cable (Dual Port).................................................................................... 86
5.7.6 USB Cable (Four Port).................................................................................... 87
5.8 EXTERNAL PERIPHERAL INTERFACE CONNECTION................................................... 88
5.8.1 Audio Connection............................................................................................. 89
5.8.2 DVI Display Device Connection...................................................................... 89
5.8.3 LAN Connection (Single Connector)............................................................... 90
5.8.4 PS/2 Keyboard and Mouse Connection........................................................... 91
5.8.5 Serial Device Connection ................................................................................ 92
5.8.6 USB Connection (Dual Connector)................................................................. 93
5.8.7 VGA Monitor Connection ................................................................................ 94
6 BIOS SCREENS...................................................................................................... 96
6.1 INTRODUCTION ........................................................................................................ 97
6.1.1 Starting Setup................................................................................................... 97
6.1.2 Using Setup...................................................................................................... 97
6.1.3 Getting Help..................................................................................................... 98
6.1.4 Unable to Reboot After Configuration Changes.............................................. 98
6.1.5 BIOS Menu Bar................................................................................................ 98
Page viii
KINO-690S1 Mini-ITX Motherboard
6.2 MAIN ....................................................................................................................... 99
6.3 ADVANCED............................................................................................................. 100
6.3.1 CPU Configuration........................................................................................ 101
6.3.2 IDE Configuration......................................................................................... 102
6.3.2.1 IDE Master, IDE Slave........................................................................... 104
6.3.3 Super IO Configuration...................................................................................110
6.3.4 Hardware Health Configuration.....................................................................113
6.3.5 ACPI Configuration ........................................................................................114
6.3.6 T rusted Computing..........................................................................................115
6.3.7 Remote Access Configuration.........................................................................117
6.3.8 USB Configuration......................................................................................... 120
6.3.8.1 USB Mass Storage Device Configuration............................................... 122
6.4 PCI/PNP ................................................................................................................ 125
6.5 BOOT ..................................................................................................................... 131
6.5.1 Boot Settings Configuration........................................................................... 132
6.5.2 Boot Device Priority...................................................................................... 134
6.5.3 Hard Disk Drives........................................................................................... 135
6.5.4 CD/DVD Drives............................................................................................. 137
6.6 SECURITY............................................................................................................... 138
6.7 CHIPSET ................................................................................................................. 140
6.7.1 NorthBridge Chipset Configuration .............................................................. 141
6.7.2 ECC Configuration........................................................................................ 143
6.7.3 Internal Graphics Configuration................................................................... 145
6.7.4 SouthBridge Configuration............................................................................ 148
6.8 POWER................................................................................................................... 150
6.9 EXIT....................................................................................................................... 153
7 SOFTWARE DRIVERS....................................................................................... 156
7.1 AVAILABLE SOFTWARE DRIVERS ............................................................................ 157
7.2 DRIVER CD AUTO-RUN.......................................................................................... 157
7.3 AMD 690G CHIPSET DRIVER INSTALLATION......................................................... 159
7.4 BROADCOM LAN DRIVER (FOR GBE LAN) INSTALLATION .................................. 164
7.5 REALTEK AC`97 AUDIO DRIVER (ALC655) INSTALLATION .................................. 169
7.5.1 BIOS Setup..................................................................................................... 169
7.5.2 Driver Installation ......................................................................................... 169
Page ix
KINO-LUKE-R20 Half-size CPU Card
7.6 WEBPAM RAID UTILITY DRIVER INSTALLATION................................................. 174
A BIOS OPTIONS.................................................................................................... 180
B DIO INTERFACE................................................................................................. 185
B.1 DIO INTERFACE INTRODUCTION ........................................................................... 186
B.2 DIO CONNECTOR PINOUTS ................................................................................... 186
B.3 ASSEMBLY LANGUAGE SAMPLES........................................................................... 187
B.3.1 Enable the DIO Input Function..................................................................... 187
B.3.2 Enable the DIO Output Function.................................................................. 187
C WA TCHDOG TIME R.......................................................................................... 188
D ADDRESS MAPPING.......................................................................................... 191
D.1 ADDRESS MAP ...................................................................................................... 192
D.2 1ST MB MEMORY ADDRESS MAP ......................................................................... 194
KINO-690S1 Mini-ITX Motherboard
D.3 IRQ MAPPING TABLE............................................................................................ 195
E HAZARDOUS MATERIALS DISCLOSURE................................................... 196
E.1 HAZARDOUS MATERIAL DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY..................................... 197
F RAID SETUP ........................................................................................................ 200
F.1 INTRODUCTION ...................................................................................................... 201
F.1.1 Precautions .................................................................................................... 201
F.2 FEATURES AND BENEFITS....................................................................................... 202
F .3 ACCESSING THE AMD SB600 RAID UTILITY ....................................................... 202
G INDEX.................................................................................................................... 206
Page x
KINO-690S1 Mini-ITX Motherboard
List of Figures
Figure 1-1: KINO-690S1 Overview [Front View]..........................................................................3
Figure 1-2: External Peripheral Interface Connectors...............................................................3
Figure 2-1: KINO-690S1 Dimensions (mm).................................................................................8
Figure 2-2: External Interface Panel Dimensions (mm).............................................................9
Figure 2-3: Data Flow Block Diagram........................................................................................10
Figure 2-4: SO-DIMM Sockets ....................................................................................................11
Figure 2-5: PCIe x1 Expansion Slot...........................................................................................13
Figure 2-6: Broadcom PCI GbE Controllers..............................................................................14
Figure 2-7: PCI Expansion Slot..................................................................................................17
Figure 2-8: USB Connectors.......................................................................................................18
Figure 2-9: SATA Connectors ....................................................................................................20
Figure 2-10: IDE Connector........................................................................................................21
Figure 2-11: Audio Codec and Audio Jacks.............................................................................22
Figure 2-12: LPC BUS Components..........................................................................................25
Figure 4-1: Connector and Jumper Locations..........................................................................38
Figure 4-2: ATX Power Connector Pinout Locations...............................................................41
Figure 4-3: DIO Connector Connector Locations.....................................................................42
Figure 4-4: +12V Fan Connector Location................................................................................43
Figure 4-5: Front Panel Connector Pinout Locations (14-pin)................................................44
Figure 4-6: IDE Device Connector Locations ...........................................................................45
Figure 4-7: Infrared Connector Pinout Locations ....................................................................47
Figure 4-8: PCI Slot Location .....................................................................................................49
Figure 4-9: PCI Express x1 Slot Locations...............................................................................53
Figure 4-10: SATA Drive Connector Locations........................................................................54
Figure 4-11: Serial Connector Pinout Locations......................................................................55
Figure 4-12: RS-232/422/485 Serial Port Connector Location.................................................56
Figure 4-13: TPM Connector Pinout Locations........................................................................57
Figure 4-14: TV Connector Pinout Locations...........................................................................58
Page xi
KINO-LUKE-R20 Half-size CPU Card
Figure 4-15: USB Connector Pinout Locations........................................................................59
Figure 4-16: KINO-690S1 External Peripheral Interface Connector .......................................60
Figure 4-17: Audio Connector....................................................................................................61
Figure 4-18: DVI-D Connector Pinouts......................................................................................62
Figure 4-19: VGA Connector ......................................................................................................63
Figure 4-20: PS/2 Pinouts...........................................................................................................64
Figure 4-21: RJ-45 Ethernet Connector.....................................................................................65
Figure 4-22: Pinout Locations....................................................................................................66
Figure 5-1: Make sure the CPU socket retention screw is unlocked .....................................74
Figure 5-2: IEI CF-479B-RS Cooling Kit.....................................................................................75
Figure 5-3: Cooling Kit Support Bracket...................................................................................76
Figure 5-4: Connect the cooling fan cable................................................................................76
Figure 5-5: SO-DIMM Installation...............................................................................................77
KINO-690S1 Mini-ITX Motherboard
Figure 5-6: Clear CMOS Jumper ................................................................................................80
Figure 5-7: COM4 Function Select Jumper Location...............................................................81
Figure 5-8: IDE Cable Connection .............................................................................................83
Figure 5-9: Dual RS-232 Cable Installation...............................................................................84
Figure 5-10: SATA Drive Cable Connection..............................................................................85
Figure 5-11: SATA Power Drive Connection.............................................................................86
Figure 5-12: Dual USB Cable Connection.................................................................................87
Figure 5-13: Four Port USB Cable Connection.........................................................................88
Figure 5-14: Audio Connectors..................................................................................................89
Figure 5-15: DVI Connector........................................................................................................90
Figure 5-16: LAN Connection.....................................................................................................91
Figure 5-17: PS/2 Keyboard/Mouse Connector........................................................................92
Figure 5-18: Serial Device Connector........................................................................................93
Figure 5-19: USB Connector.......................................................................................................94
Figure 5-20: VGA Connector ......................................................................................................95
Figure 7-1: Introduction Screen.............................................................................................. 158
Figure 7-2: Available Drivers................................................................................................... 158
Figure 7-3: Chipset Driver Installation Program.................................................................... 159
Figure 7-4: Chipset Driver Installation Welcome Screen ..................................................... 160
Page xii
KINO-690S1 Mini-ITX Motherboard
Figure 7-5: Chipset Driver Installation License Agreement................................................. 160
Figure 7-6: Select Destination Folder..................................................................................... 161
Figure 7-7: Chipset Driver Installing Screen.......................................................................... 161
Figure 7-8: Welcome Screen ................................................................................................... 162
Figure 7-9: Chipset Driver Readme File Information ............................................................ 162
Figure 7-10: Chipset Driver Installation Complete................................................................ 163
Figure 7-11: Setup Complete................................................................................................... 164
Figure 7-12: Windows Control Panel...................................................................................... 165
Figure 7-13: System Icon......................................................................................................... 166
Figure 7-14: Device Manager Tab........................................................................................... 166
Figure 7-15: Device Manager List........................................................................................... 167
Figure 7-16: Search for Suitable Driver.................................................................................. 168
Figure 7-17: Locate Driver Files.............................................................................................. 168
Figure 7-18: Location Browsing Window............................................................................... 169
Figure 7-19: Select the Audio CODEC.................................................................................... 170
Figure 7-20: Locate the Setup Program Icon......................................................................... 171
Figure 7-21: Preparing Setup Screen..................................................................................... 171
Figure 7-22: InstallShield Wizard Welcome Screen.............................................................. 172
Figure 7-23: Audio Driver Software Configuration................................................................ 172
Figure 7-24: Audio Driver Digital Signal................................................................................. 173
Figure 7-25: Audio Driver Installation .................................................................................... 173
Figure 7-26: Restart the Computer......................................................................................... 174
Figure 7-27: Chipset Driver Installation Program.................................................................. 175
Figure 7-28: Chipset Drivers.................................................................................................... 175
Figure 7-29: RAID Utility Icon.................................................................................................. 176
Figure 7-30: SATA RAID Setup Program Icon....................................................................... 176
Figure 7-31: Welcome Screen ................................................................................................. 177
Figure 7-32: WebPAM License Agreement............................................................................ 177
Figure 7-33: Select WebPAM Installation Destination.......................................................... 178
Figure 7-34: WebPAM Ready to Install................................................................................... 178
Figure 7-35: WebPAM Installation .......................................................................................... 179
Figure 7-36: WebPAM Installation Complete......................................................................... 179
Page xiii
KINO-LUKE-R20 Half-size CPU Card
KINO-690S1 Mini-ITX Motherboard
List of Tables
Table 1-1: Technical Specifications.............................................................................................6
Table 2-1: Power Consumption..................................................................................................30
Table 3-1: Package List Contents..............................................................................................34
Table 3-2: Package List Contents..............................................................................................35
Table 4-1: Peripheral Interface Connectors..............................................................................39
Table 4-2: Rear Panel Connectors.............................................................................................40
Table 4-3: ATX Power Connector Pinouts ................................................................................41
Table 4-4: DIO Connector Connector Pinouts..........................................................................42
Table 4-5: +12V Fan Connector Pinouts....................................................................................43
Table 4-6: Front Panel Connector Pinouts (14-pin) .................................................................44
Table 4-7: IDE Connector Pinouts .............................................................................................46
Table 4-8: Infrared Connector Pinouts......................................................................................47
Table 4-9: PCI Slot.......................................................................................................................51
Table 4-10: PCI Express x1 Slot Pinouts...................................................................................54
Table 4-11: SATA Drive Connector Pinouts..............................................................................55
Table 4-12: Serial Connector Pinouts........................................................................................56
Table 4-13: RS-232/RS-485 Serial Port Connector Pinouts.....................................................57
Table 4-14: TPM Connector Pinouts..........................................................................................58
Table 4-15: TV Port Connector Pinouts.....................................................................................59
Table 4-16: USB Port Connector Pinouts..................................................................................60
Table 4-17: DVI-D Connector Pinouts........................................................................................62
Table 4-18: VGA Connector Pinouts..........................................................................................63
Table 4-19: PS/2 Connector Pinouts..........................................................................................64
Table 4-20: LAN Pinouts.............................................................................................................65
Table 4-21: RJ-45 Ethernet Connector LEDs............................................................................65
Table 4-22: RS-232 Serial Port Pinouts.....................................................................................66
Table 4-23: USB Port Pinouts.....................................................................................................67
Table 5-1: Jumpers......................................................................................................................78
Page xiv
KINO-690S1 Mini-ITX Motherboard
Table 5-2: Clear CMOS Jumper Settings...................................................................................79
Table 5-3: COM4 Function Select Jumper Settings.................................................................80
Table 5-4: IEI Provided Cables...................................................................................................82
Table 6-1: BIOS Navigation Keys...............................................................................................98
Page xv
KINO-LUKE-R20 Half-size CPU Card
KINO-690S1 Mini-ITX Motherboard
BIOS Menus
Menu 1: Main................................................................................................................................99
Menu 2: Advanced.................................................................................................................... 101
Menu 3: CPU Configuration..................................................................................................... 102
Menu 4: IDE Configuration ...................................................................................................... 103
Menu 5: IDE Master and IDE Slave Configuration................................................................. 105
Menu 6: Super IO Configuration ............................................................................................. 110
Menu 7: Hardware Health Configuration................................................................................ 113
Menu 8: ACPI Configuration.................................................................................................... 114
Menu 9: Trusted Computing.................................................................................................... 116
Menu 10: Remote Access Configuration [Advanced]........................................................... 117
Menu 11: USB Configuration................................................................................................... 121
Menu 12: USB Mass Storage Device Configuration.............................................................. 123
Menu 13: PCI/PnP Configuration ............................................................................................ 126
Menu 14: Boot........................................................................................................................... 132
Menu 15: Boot Settings Configuration................................................................................... 133
Menu 16: Boot Device Priority Settings................................................................................. 135
Menu 17: Hard Disk Drives...................................................................................................... 136
Menu 18: CD/DVD Drives......................................................................................................... 138
Menu 19: Security..................................................................................................................... 139
Menu 20: Chipset...................................................................................................................... 141
Menu 21:NorthBridge Chipset Configuration........................................................................ 142
BIOS Menu 22: ECC Configuration Chipset Configuration.................................................. 143
BIOS Menu 23: Internal Graphics Configuration................................................................... 146
Menu 24:SouthBridge Chipset Configuration ....................................................................... 149
Menu 25:Power ......................................................................................................................... 151
Menu 26:Exit.............................................................................................................................. 154
Page xvi
KINO-690S1 Mini-ITX Motherboard
Glossary
AC ’97 Audio Codec 97
ACPI Advanced Configuration and
Power Interface
APM Advanced Power Management
ARMD ATAPI Removable Media Device
ASKIR Shift Keyed Infrared
ATA Advanced Technology
Attachments
BIOS Basic Input/Output System
CFII Compact Flash Type 2
CMOS Complementary Metal Oxide
Semiconductor
CPU Central Processing Unit
Codec Compressor/Decompressor
COM Serial Port
DAC Digital to Analog Converter
DDR Double Data Rate
I/O Input/Output
ICH4 I/O Controller Hub 4
L1 Cache Level 1 Cache
L2 Cache Level 2 Cache
LCD Liquid Crystal Display
LPT Parallel Port Connector
LVDS Low Voltage Differential Signaling
MAC Media Access Controller
OS Operating System
PCI Peripheral Connect Interface
PIO Programmed Input Output
PnP Plug and Play
POST Power On Self Test
RAM Random Access Memory
SATA Serial ATA
S.M.A.R.T Self Monitoring Analysis and
Reporting Technology
DIMM Dual Inline Memory Module
DIO Digital Input/Output
DMA Direct Memory Access
EIDE Enhanced IDE
EIST Enhanced Int el SpeedStep
Technology
FDD Floppy Disk Drive
FDC Floppy Disk Connector
FFIO Flexible File Input/Output
FIFO First In/First Out
FSB Front Side Bus
IrDA Infrared Data Association
HDD Hard Disk Drive
IDE Integrated Data Electronics
SPD Serial Presence Detect
S/PDI Sony/Philips Digital Interface
SDRAM Synchronous Dynamic Random
Access Memory
SIR Serial Infrared
UART Universal Asynchronous
Receiver-transmitter
USB Universal Serial Bus
VGA Video Graphics Adapter
Page xvii
THIS PAGE IS INTENTIONALLY LEFT BLANK
Page xviii
KINO-690S1 Mini-ITX Motherboard
1 Introduction
Chapter
1
Page 1
1.1 Overview
The KINO-690S1 Mini-ITX form factor CPU card is an AMD Socket S1 processor platform.
Up to 4GB of DDR2 SO-DIMM SDRAM and up to four SATA II hard disk drives (HDD) are
supported. SATA drives can be installed in a RAID configuration. High-performance PCI
Express (PCIe) Gigabit Ethernet (GbE) connectivity is integrated into the system. Eight
USB 2.0 channels along with a PCI expansion slot enable system flexibility and
expansion. Multi-display interfaces and dual display functions ensure display versatility.
Support for a (optional) trusted platform module (TPM) provides additional system security
during system boot-up.™
1.1.1 KINO-690S1 Features
Some of the KINO-690S1 features are listed below.
KINO-690S1 Mini-ITX Motherboard
Supports the following AMD Socket S1 processors:
o AMD Turion™ 64 X2 dual-core mobile
o Mobile AMD Sempron™
Supports two 200-pin 400MHz, 533MHz or 667MHz DDR2 SO-DIMMs with a
maximum capacity of 2GB.
Four SATA II drives with transfer rates of 3.0Gb/s su pported
Two Ultra ATA 133, Ultra ATA 100, Ultra ATA 66 or Ultra ATA 33 IDE HDDs
supported
Eight USB 2.0 devices supported
Dual PCIe GbE Ethernet connectors
Mini-ITX form factor
RoHS compliant
Supports ATX power supplies
1.2 KINO-690S1 Overview
1.2.1 KINO-690S1 Overview Photo
Page 2
The KINO-690S1 has a wide variety of peripheral interface connectors. Figure 1-1 is a
labeled photo of the peripheral interface connectors on the KINO-690S1.
KINO-690S1 Mini-ITX Motherboard
Figure 1-1: KINO-690S1 Overview [Front View]
Figure 1-2 shows the external peripheral interface connectors (EPIC).
Figure 1-2: External Peripheral Interface Connectors
Page 3
KINO-690S1 Mini-ITX Motherboard
1.2.2 KINO-690S1 Peripheral Connectors and Jumpers
The KINO-690S1 has the following connectors on-board:
1 x ATX power connector
1 x Digital input/output connector
2 x Fan connectors
1 x Front panel connector
1 x IDE disk drive connector
1 x Infrared interface connector
1 x PCI slot
1 x PCIe slot
4 x Serial ATA II (SATA II) drive connectors
1 x RS-232 Serial port connector
1 x RS-232/422/485 Serial port connector
1 x TPM connector
1 x TV Out connector
2 x USB 2.0 connectors (support four USB 2.0 devices)
The KINO-690S1 has the following external peripheral interface connectors on the board
rear panel.
2 x Audio Jacks
2 x Ethernet connectors
1 x DVI-D connector
2 x PS/2 connectors
2 x Serial port connectors
4 x USB connectors
1 x VGA connector
The KINO-690S1 has the following on-board jumpers:
Clear CMOS
Page 4
RS-232/422/485 COM4 setup
KINO-690S1 Mini-ITX Motherboard
1.2.3 Technical Specifications
KINO-690S1 technical specifications are listed in Table 1-1. See Chapter 2 for details.
Specification KINO-690S1
Form Factor
System CPU
HyperTransport™
Technology
System Chipset
Memory
Super I/O
Mini-ITX
AMD Socket S1 Turion™ 64 X2
AMD Socket S1 Sempron™
Up to 1600 MHz HyperTransport™ interfaces supported
Northbridge: AMD 690G
Southbridge: AMD SB600
Two 200-pin DDR2 SO-DIMM sockets support two 400MHz,
533MHz, or 667MHz un-buffered DDR2 SO-DIMMs with a
maximum capacity of 2GB each
ITE8712F
VGA Integrated in the AMD® 690G with Radeon Xpress
1250 Graphic Core
Display Interface
BIOS
Audio
LAN
COM
Supports HDTV resolutions up to 1080i by component
interface
DVI by AMD® 690G with dual display support
AMI Flash BIOS
RealT ek AL C655 with AC’97 codec
Dual Broadcom PCIe GbE chipsets
Three RS-232 serial ports
One RS-232/422/485 serial port
Page 5
KINO-690S1 Mini-ITX Motherboard
USB2.0
IDE
SATA
Keyboard/mouse
Expansion
Digital I/O
Watchdog Timer
Infrared
Power Supply
Eight USB 2.0 devices supported
One 40-pin IDE connector connects to two Ultra
ATA33/66/100/133 devices
Four 3.0Gb/s SATA II drives supported
Two PS/2 connectors
One PCI slot
One PCIe x1 slot
One 8-bit digital input/output connector; 4-bit input/4-bit
output
Software programmable 1-255 sec. by super I/O
One IrDA connector by Super I/O
AT/ATX power
5.0V@3.65A AND 12V@1.12A
Power Consumption
Temperature
Humidity (operating)
Dimensions (LxW)
Weight (GW/NW)
Table 1-1: Technical Specifications
(AMD® Mobile Sempron 3500+ CPU with a 667MHz 512MB
DDR2 SO-DIMM)
0ºC – 60ºC (32ºF - 140ºF)
5%~95% non-condensing
170mm x 170mm
900g/342g
Page 6
KINO-690S1 Mini-ITX Motherboard
Chapter
2
2 Detailed Specifications
Page 7
2.1 Dimensions
2.1.1 Board Dimensions
The dimensions of the board are listed below:
Length: 170mm
Width: 170mm
KINO-690S1 Mini-ITX Motherboard
Page 8
Figure 2-1: KINO-690S1 Dimensions (mm)
KINO-690S1 Mini-ITX Motherboard
2.1.2 External Interface Panel Dimensions
External peripheral interface connector panel dimensions are shown in Figure 2-2.
Figure 2-2: External Interface Panel Dimensions (mm)
2.2 Data Flow
Figure 2-3 shows the data flow between the two on-board chipsets and other components
installed on the motherboard and described in the following sections of this chapter.
Page 9
KINO-690S1 Mini-ITX Motherboard
Figure 2-3: Data Flow Block Diagram
Page 10
KINO-690S1 Mini-ITX Motherboard
2.3 Compatible Processors
2.3.1 Supported Processors
The KINO-690S1 supports the following AMD Socket S1 processors
AMD Turion ™ 64 X2 dual-core mobile processor
Mobile AMD Sempro n™ processor
2.3.2 DDR2 Memory Controller
All processors supported by the KINO-690S1 CPU card have their own DDR2 memory
controller. The DDR2 controller has the following features:
Low-latency, high-bandwidth
667MHz 128-bit DDR2 SDRAM controller
Supports up to two un-buffered DDR2 SO-DIMM
Each SO-DIMM has a maximum capacity of 2GB
The DDR2 controller on the processor is interfaced to two SO-DIMM sockets on the
KINO-690S1.
Figure 2-4: SO-DIMM Sockets
Page 11
2.3.3 Processor Electrical Interfaces
The supported processors have the following electrical interfaces:
HyperTransport™ technology: LVDS-like differential, unidirectional
DDR2 SDRAM: SSTL_1.8 per JEDEC specification
Clock, reset, and test signals also use DDR2
SDRAM-like electrical specifications.
2.3.4 Processor Power Management
The supported processors have the following power management features:
Multiple low-power states including Deeper Sleep (C1E with AltVID)
System Management Mode (SMM)
KINO-690S1 Mini-ITX Motherboard
ACPI compliant, including support for processor performance states
AMD PowerNow!™ technology is designed to dynamically switch between
multiple low-power states based on application performance requirements.
2.4 AMD 690G Northbridge Chipset
2.4.1 PCI Express Interface
The AMD 690G PCIe bus is compliant with the PCI Express 1.1a. Three of the four AMD
690G lanes are implemented on the KINO-690S1 motherboard. One of these lanes is
interfaced to a PCIe x1 expansion slot. Two other PCIe x1 lanes are interfaced to two
Broadcom PCIe GbE controllers.
2.4.1.1 PCIe x1 Expansion
One PCIe x1 lane from the AMD 690G is interfaced to a PCIe x1 expansion slot. See
Figure 2-5. A standard PCIe x1 can be inserted into the slot to provide additional
functionality to the system.
Page 12
KINO-690S1 Mini-ITX Motherboard
Figure 2-5: PCIe x1 Expansion Slot
2.4.2 PCIe GbE Ethernet
Two PCIe x1 lanes from the AMD 690G Northbridge are interfaced to two Broadcom
BCM5787M PCIe GbE controllers shown in
Figure 2-6 below.
Page 13
KINO-690S1 Mini-ITX Motherboard
Figure 2-6: Broadcom PCI GbE Controllers
The Broadcom BCM5787M is a 10/100/1000BASE-T Ethernet LAN controller. The
BCM5787M combines a triple-speed IEEE 802.3 compliant Media Access Controller
(MAC) with a triple-speed Ethernet transceiver, a PCIe bus interface, and an on-chip
buffer memory. Some of the BCM5787 controller features are listed below:
Integrated 10/100/1000BASE-T transceiver
Automatic MDI crossover function
PCIe v1.0a
10/100/1000BASE-T full/half-duplex MAC
Wake on LAN support meeting the ACPI requirements
Statistics for SNMP MIB II, Ethernet-like MIB, and Ethernet MIB (802.3z,
clause 30)
Serial EEPROM or serial flash support
2.4.3 Acceleration Features
The AMD 690G has the following 2D acceleration features:
Page 14
Highly optimized 128-bit engine, capable or processing multiple pixels per
clock
KINO-690S1 Mini-ITX Motherboard
Supports a maximum resolution of 2048x1536 @ 32bpp
Game acceleration including support for Microsoft's Dire ctDraw
The AMD 690G also has the following 3D acceleration features:
Full DirectX 9.0 support
3D Texture support, including projective 3D textures
Anti-aliasing using multi-sampling algorithm with support for 2,4, and 6
samples
New generation rendering engine provides top 3D performance
Support for OpenGL format for Indirect Vertices in Vertex Wal ker
Motion video acceleration features on the AMD 690G include:
Enhanced MPEG-2 hardware decode acceleration
MPEG-4 decode support
Hardware acceleration for WMV9 playback
Supports top quality DVD and time-shifted SDTV/HDTV television playback
with low CPU usage
2.4.4 Display Support
The AMD 690G supports dual independent displays. The following display interface
connectors are on the KINO-690S1:
TV Out
DVI-D
VGA
2.4.4.1 TV Out
TV Out features include:
Integrated TV encoder from Xilleon products with int egrated Avivo™
Supports Macrovision 7.1 copy protection standard (requi red by DVD players)
Supports the formats of component, composite and S-video outputs
Page 15
KINO-690S1 Mini-ITX Motherboard
2.4.4.2 Multiple Display Features
The Multiple display features include
Dual independent displays including one digital outputs *
Resolution, refresh rates, and display data can be completely independent for
the two display paths
Supports both interlaced and non-interlaced displ ays
2.4.4.3 DVI
DVI support features include:
Supports a TMDS interface, enabling DVI <1650 Mbps/channel with 165 MHz
pixel clock rate per link
HDCP 1.1 support on data stream with on-chip key storage
2.5 AMD SB600 Southbridge Chipset
2.5.1 CPU Interface
The AMD SB600 Southbridge chipset supports the following AMD Socket S1 processors:
AMD Turion ™ 64 X2 dual-core mobile processor
Mobile AMD Sempro n™ processor
2.5.2 A-Link Xpress II interface to the Northbridge
The AMD SB600 Southbridge is connected to the AMD 690G Northbridge chipset through
an A-Link Xpress II interface. Some of the A-Link Xpress II interface features are listed
below:
1/2/4-lane A-Link Xpre ss II interface
Dynamic detection of lane configuration
High data transfer bandwidth
Page 16
KINO-690S1 Mini-ITX Motherboard
2.5.3 PCI Host Bus Controller
The PCI interface on the AMD SB600 Southbridge is compliant with the PCI Revision 2.3
implementation. Some of the features of the PCI interface are listed below.
PCI rev. 2.3 specifications
PCI bus at 33 MHz
Up to 6 master devices
40-bit addressing
Interrupt steering for plug-n-play devices
Concurrent PCI operations
Hiding of PCI devices by BIOS/hardware
Spread spectrum
The PCI bus is interfaced to a PCI expansion slot (see
Figure 2-7: PCI Expansion Slot
Figure 2-7).
Page 17
2.5.4 USB Controllers
Eight of the ten high-speed, full-speed or low-speed USB devices on the AMD SB600 are
implemented on the KINO-690S1. High-speed USB 2.0, with data transfers of up to
480MB/s, is enabled with the AMD SB600 integrated Enhanced Host Controller Interface
(EHCI) compliant host controller. USB full-speed and low-speed signaling are enabled
with the integrated Universal Host Controller Interface (UHCI) controllers.
The USB controller supports the following:
USB 1.1 (“Low Speed ”, “Full Speed”) and 2.0 (“High Speed”)
ACPI S1~S5
Legacy keyboard/mouse
USB debug port
KINO-690S1 Mini-ITX Motherboard
Port disable with individual control
Four of the eight USB ports are interfaced to two 8-pin headers on the KINO-690S1. Four
more USB ports are interfaced to four external USB connectors. See
Figure 2-8.
Page 18
Figure 2-8: USB Connectors
KINO-690S1 Mini-ITX Motherboard
2.5.5 SMBus Controller
The AMD SB600 southbridge chipset SMBus Controller is SMBus Rev. 2.0 compliant and
supports SMBALERT # signal / GPIO.
2.5.6 Interrupt Controller
The AMD SB600 southbridge interrupt controller supports the following:
IOAPIC/X-IO APIC mode for 24 channels of interrupts
8259 legacy mode for 15 interrupts
Programmable level/edge triggering on each channels
Serial interrupt on quiet and continuous modes
2.5.7 DMA Controller
The AMD SB600 southbridge has two cascaded 8237 DMA controllers that support the
following:
PC/PCI/DMA
LPC DMA
Type F DMA
2.5.8 LPC host bus controller
The AMD SB600 Southbridge LPC interface complies with the LPC 1.1 and LPC 1.2
specifications. The LPC bus from the Southbridge is connected to the following
components:
BIOS chipset
Super I/O chipset
TPM connector
Some of the features of the LPC bus are listed below.
Supports LPC based super I/O and flash devices
Supports two master/DMA devices
Supports TPM version 1.1/1.2 devices for enhanced security
Page 19
Supports SPI devices
2.5.9 SATA II AHCI Controller
The integrated SATA controllers on the AMD SB600 Southbridge supports four SATA II
drives on the KINO-690S1 with independent DMA operations. The SATA controller
supports the following:
Four SATA ports, complying with SATA 2.0 specifications
SATA II 3.0GHz PHY, with backward compatibility with 1.5GHz
RAID stripping (RAID 0) across all 4 ports
RAID mirroring (RAID 1) across all 4 ports
RAID 10 (4 ports needed)
Both AHCI mode and IDE mode
Advanced power management with AHCI mode
KINO-690S1 Mini-ITX Motherboard
The four SATA connectors are shown in
Figure 2-9: SATA Connectors
Figure 2-9.
Page 20
KINO-690S1 Mini-ITX Motherboard
2.5.10 IDE Controller
The AMD SB600 Southbridge IDE controller is interfaced to a single IDE connector. The
IDE controller has the following specifications.
Single P ATA channel support
Support PIO, multi-word DMA, and Ultra DMA 33/66/100/133 modes
32x32 byte buffers on each channel for buffering
Swap bay support by tri-state IDE signals
Supports Messages Signaled Interrupt (MSI)
Integrated IDE series resistor
The IDE connector is shown in
Figure 2-10: IDE Connector
Figure 2-10.
2.5.11 AC Link interface
The AMD SB600 southbridge AC Link interface has the following features:
Supports for both audio and modem Codecs
Compliant with AC-97 codec Rev. 2.3
Page 21
6/8 channel support on audio codec
Multiple functions for audio and modem Codec operations
Bus master logic
Supports up to 3 codecs simultaneou sly
Supports SDIF output
AC Link
KINO-690S1 Mini-ITX Motherboard
The AC Link Interface is connected to a 16-bit, full-duplex AC'97 Rev. 2.3 compatible
six-channel RealTek ALC655 audio CODEC. The ALC655 is then connected to three
externally accessible audio jacks. See
Figure 2-11.
Figure 2-11: Audio Codec and Audio Jacks
Page 22
Some of the features of the ALC655 are listed below:
Complies with PC99/2001 systems audio performance requirements
Complies with Microsoft WHQL/WLP 2.0 audio requirements
16-bit Stereo full-duplex CODEC with 48KHz sampling rate
Compliant with AC'97 Rev 2.3 specifications
o Front-Out, Surround-Out, MIC-In and LINE-In Jack Sensing
o 14.318MHz -> 24.576MHz PLL to eliminate crystal
KINO-690S1 Mini-ITX Motherboard
o 12.288MHz BITCLK input
o Integrated PCBEEP generator to save buzzer
o Interrupt capability
Three analog line-level stereo inputs with 5-bit volume control, LINE_IN, CD,
AUX
High-quality differential CD input
Two analog line-level mono inputs: PCBEEP, PHONE-IN
Dedicated Front-MIC input for front panel applications (software selectable)
Boost preamplifier for MIC input
LINE input shared with surround output; MIC input shared with Center and
LFE output
Built-in 50mW/20ohm amplifier for both Front-out and Surround-Out
External Amplifier Power Down (EAPD) capability
Power management and enhanced power saving features
Supports Power-Off CD function
Adjustable VREFOUT control
Supports 48KHz S/PDIF output, complying with AC'97 Rev 2.3 specifications
Supports 32K/44.1K/48KHz S/PDIF input
Power support: Digital: 3.3V; Analog: 3.3V/5V
EAX™ 1.0 & 2.0 compatible
Direct Sound 3D™ compatible
A3D™ compatible
I3DL2 compatible
HRTF 3D positional audio
10-band software equalizer
Voice cancellation and key shifting in Karaoke mode
AVRack® Media Player
2.5.12 Timers
The AMD SB600 south bridge has the following timers
Configuration Panel for improved user convenience
8254-compatible timer
Microsoft High Precision Event Timer (HPET)
ACPI power management timer
Page 23
2.5.13 RTC (Real Time Clock)
256 bytes of battery backed RAM is provided by the real time clock (RTC) integrated into
the AMD SB600. The RTC keeps track of the time and stores system data even when the
system is turned off. Some of the features of the RTC are listed below:
256-byte battery backed CMOS RAM
Hardware supported century rollover
RTC battery monitoring feature
2.5.14 Power Management
ACPI specification 3.0 compliant power management schemes on the AMD SB600
include:
Supports C2, C3, C4
KINO-690S1 Mini-ITX Motherboard
Supports C1e and C3 pop-up (AMD platform only)
Supports S0, S1, S2, S3, S4, and S4
Supports SpeedStep™
Full support for On-Now™
Supports CPU SMM, generating SMI# signal upon power management
events
GPIO supports on external wake up events
Supports CLKRUN# on PCI power management
Provides clock generator and CPU STPCLK# control
Hardware monitoring support
Support for ASF
2.5.15 Hardware Monitor
The AMD SB600 has the following hardware monitoring features:
Supports 3 Independent Fan Control output s
Supports 4 thermal diode temperature sensing functions
Page 24
Supports 1 AMDSI function
KINO-690S1 Mini-ITX Motherboard
2.6 LPC Bus Components
2.6.1 LPC Bus Overview
The LPC bus is connected to components listed below:
BIOS chipset
Super I/O chipset
Serial Port Chipset
TPM module connector
Figure 2-12: LPC BUS Components
2.6.2 BIOS Chipset:
The BIOS chipset has a licensed copy of AMI BIOS installed on the chipset. Some of the
BIOS features are listed below:
AMI Flash BIOS
Page 25
2.6.3 TPM Module
A TPM connector on the KINO-690S1 is interfaced to the AMD SB600 southbridge
through the LPC bus. The AMD SB600 Southbridge supports TPM version 1.1 and TPM
version 1.2 devices for enhanced security. Three TPM are available from IEI. The three IEI
TPM are listed below:
KINO-690S1 Mini-ITX Motherboard
SMIBIOS (DMI) compliant
Console redirection function support
PXE (Pre-boot Execution Environment) support
USB booting support
Infineon TPM module
Sinosun TPM module
Winbond TPM module
For more information about these modules please refer to Chapter 3 or contact the
KINO-690S1 reseller or vendor. Alternatively, please contact IEI at
sales@iei.com.tw.
2.6.4 Super I/O chipset
The iTE IT8712F Super I/O chipset is connected to the AMD SB600 southbridge through
the LPC bus. The iTE IT8712F is an LPC interface-based Super I/O device that comes
with Environment Controller integration. Some of the features of the iTE IT8712F chipset
are listed below:
PC98/99/2001, ACPI and LANDesk Co mpliant
Enhanced Hardware Monitor
Fan Speed Controller
Single +5V Power Supply
Two 16C550 UARTs for serial port control
One IEEE 1284 Parallel Port
Keyboard Controller
Page 26
Watchdog T i mer
Serial IRQ Support
Vbat & Vcch Support
KINO-690S1 Mini-ITX Motherboard
Single +5V Power Supply
Some of the Super I/O features are described in more detail below:
2.6.4.1 Super I/O LPC Interface
The LPC interface on the Super I/O complies with the AMD® Low Pin Count Specification
Rev. 1.0. The LPC interface supports both LDRQ# and SERIRQ protocols as well as PCI
PME# interfaces.
2.6.4.2 Super I/O 16C550 UARTs
The onboard Super I/O has two integrated 16C550 UARTs that can support the following:
Two standard serial ports
IrDa 1.0 and ASKIR protocols
2.6.4.3 Super I/O Enhanced Hardware Monitor
The Super I/O Enhanced Hardware Monitor monitors three thermal inputs, VBAT
internally, and eight voltage monitor inputs. These hardware parameters are reported in
the BIOS and can be read from the BIOS Hardware Health Configuration menu.
2.6.4.4 Super I/O Fan Speed Controller
The Super I/O fan speed controller enables the system to monitor the speed of the fan.
One of the pins on the fan connector is reserved for fan speed detection and interfaced to
the fan speed controller on the Super I/O. The fan speed is then reported in the BIOS.
2.6.4.5 Super I/O Keyboard and Mouse Controller
The Super I/O keyboard and mouse controller can execute the 8042 in struction set. Some
of the keyboard and mouse controller features are listed below:
The 8042 instruction is compatible with a PS/2 keyboard and PS/2 mouse
Gate A20 and Keyboard reset output
Supports multiple keyboard power on events
Supports mouse double-click and/or mouse move power on events
Page 27
2.6.4.6 Super I/O Infrared
The Super I/O has dedicated infrared (IrDA) pins that are interfaced to an IrDA connector.
The IrDA connector is compatible with the following standards:
ASKIR
SIR
2.6.5 Serial Port Chipset
The KINO-690S1 has a Fintek F81216DG chipset onboard enables the addition of two
additional UART serial ports (COM3 and COM4). UART includes 16-byte send/receive
FIFO. The Fintek serial port chipset is interfaced to the southbridge chipset through the
LPC bus. Some of the features of the Fintek chipset are listed below:
KINO-690S1 Mini-ITX Motherboard
Supports LPC interface
Provides UART (16550 asynchronous) ports
o 1 x Pure UART
o 1 x UART+IR
One Watch dog timer with WDTOUT# signal
One Frequency input 24/48MHz
Powered by 3Vcc
2.7 Environmental and Power Specifications
2.7.1 System Monitoring
Three thermal inputs on the KINO-690S1 Super I/O Enhanced Hardware Monitor monitor
the following temperatures:
CPU temperature
System temperature
Page 28
Five voltage inputs on the KINO-690S1 Super I/O Enhanced Hardware Monitor monitors
the following voltages:
CPU Core
KINO-690S1 Mini-ITX Motherboard
+1.20V
+3.3V
+5.0V
5VSB
VBAT
The KINO-690S1 Super I/O Enhanced Hardware Monitor also monitors the following fan
speeds:
CPU Fan speed
System Fan speed
The values for the above environmental parameters are all recorded in the BIOS
Hardware Health Configuration menu.
2.7.2 Operating Temperature and Temperature Control
The maximum and minimum operating temperatures for the KINO-690S1 are listed below.
Minimum Operating Temperature: 0ºC (32°F)
Maximum Operating Temperature: 60°C (140°F)
A cooling fan and heat sink must be installed on the CPU. Thermal paste must be
smeared on the lower side of the heat sink before it is mounted on the CPU. Heat sinks
are also mounted on the northbridge and southbridge chipsets to ensure the operating
temperature of these chips remain low.
Page 29
2.7.3 Power Consumption
Table 2-1 shows the power consumption parameters for the KINO-690S1 running with a
AMD Mobile Sempron 3500+ CPU and a 512MB 667MHz DDR2 SO-DIMM.
Voltage Current
+5.0V 3.65A
+12V 1.12A
Table 2-1: Power Consumption
KINO-690S1 Mini-ITX Motherboard
Page 30
KINO-690S1 Mini-ITX Motherboard
Chapter
3
3 Unpacking
Page 31
3.1 Anti-static Precautions
WARNING:
Failure to take ESD precautions during the installation of the
KINO-690S1 may result in permanent damage to the KINO-690S1 and
severe injury to the user.
Electrostatic discharge (ESD) can cause serious damage to electronic components,
including the KINO-690S1. Dry climates are especially susceptible to ESD. It is therefore
critical that whenever the KINO-690S1, or any other electrical component is handled, the
following anti-static precautions are strictly adhered to.
KINO-690S1 Mini-ITX Motherboard
Wear an anti-static wristband: - Wearing a simple anti-static wristband can
help to prevent ESD from damaging the board.
Self-grounding:- Before handling the board touch any grounded conducting
material. During the time the board is handled, frequently touch any
conducting materials that are connected to the ground.
Use an anti-static pad: When configuring the KINO-690S1, place it on an
antic-static pad. This reduces the possibility of ESD damaging the
KINO-690S1.
Only handle the edges of the PCB:-: When handling the PCB, hold the PCB
by the edges.
3.2 Unpacking
3.2.1 Unpacking Precautions
When the KINO-690S1 is unpacked, please do the following:
Follow the anti-static precautions outlined in Section 3.1.
Page 32
Make sure the packing box is facing upward s so the KINO-690S1 does not fall
out of the box.
Make sure all the components shown in Section 3.3 are present.
KINO-690S1 Mini-ITX Motherboard
3.3 Unpacking Checklist
NOTE:
If some of the components listed in the checklist below are missing,
please do not proceed with the installation. Contact the IEI reseller or
vendor you purchased the KINO-690S1 from or contact an IEI sales
representative directly. To contact an IEI sales representative, please
send an email to
sales@iei.com.tw.
3.3.1 Package Contents
The KINO-690S1 is shipped with the following components:
Quantity Item and Part Number Image
1 KINO-690S1
1 ATA 66/100 flat cable
(P/N: 32200-000052-RS)
1 I/O Shielding
(P/N:45014-0008C0-00-RS)
Page 33
1 Dual RS-232 cable
(P/N: 19800-000051-RS)
2 SATA cables
(P/N: 32000-062800-RS)
1 SATA power cables
KINO-690S1 Mini-ITX Motherboard
(P/N: 32100-088600-RS)
1 Mini jumper Pack
1 Quick Installation Guide
1 Utility CD
Table 3-1: Package List Contents
Page 34
KINO-690S1 Mini-ITX Motherboard
3.4 Optional Items
CPU cooler
(P/N: CF-479B-RS)
HDTV Output Cable
(P/N: 32000-083701-RS)
Dual RS-232 cable
(P/N: 32200-000077-RS)
Dual USB cable (w bracket)
(P/N:CB-USB02-RS)
4-port USB cable
(P/N: CB-USB14-RS)
Table 3-2: Package List Contents
Page 35
KINO-690S1 Mini-ITX Motherboard
Page 36
KINO-690S1 Mini-ITX Motherboard
Chapter
4
4 Connector Pinouts
Page 37
KINO-690S1 Mini-ITX Motherboard
4.1 Peripheral Interface Connectors
Section 4.1.2 shows peripheral interface connector locations. Section 4.1.2 lists all the
peripheral interface connectors seen in Section
4.1.2.
4.1.1 KINO-690S1 Layout
Figure 4-1 shows the on-board peripheral connectors, rear panel peripheral connectors
and on-board jumpers.
Figure 4-1: Connector and Jumper Locations
4.1.2 Peripheral Interface Connectors
Table 4-1 shows a list of the peripheral interface connectors on the KINO-690S 1. Detailed
descriptions of these connectors can be found below.
Page 38
KINO-690S1 Mini-ITX Motherboard
Connector Type Label
Audio connector 10-pin header FPAUDIO1
ATX power connector 20-pin ATX PWR1
Cooling fan connector, CPU 3-pin header CPU_FAN1
Cooling fan connector, System 3-pin header CPU_SYS1
Digital input/output connector 10-pin header DIO1
Front panel connector 14-pin header F_PANEL1
IDE Interface connector 40-pin box header IDE1
Infrared (IrDA) connector 5-pin header IR1
PCI expansion slot 124-pin PCI slot PCI1
PCIe x1 expansion slot 36-pin PCIe slot PCIE1
Serial ATA drive connector 7-pin SATA SATA 1
Serial ATA drive connector 7-pin SATA SATA 2
Serial ATA drive connector 7-pin SATA SATA 3
Serial ATA drive connector 7-pin SATA SATA 4
Serial port connector (COM3) 10-pin box header COM3
Serial port connector (COM4) 14-pin box header COM4
TPM connector 20-pin header TPM1
TV Out connector 16-pin header TV
USB connectors 8-pin header JUSB1
USB connectors 8-pin header JUSB2
Table 4-1: Peripheral Interface Connectors
Page 39
4.1.3 External Interface Panel Connectors
Table 4-2 lists the rear panel connectors on the KINO-690S1. Detailed descriptions of
KINO-690S1 Mini-ITX Motherboard
these connectors can be found in Section
Connector Type Label
DVI and VGA combo connector DVI and DB-15 VIDEO1
Ethernet and dual USB combo connector RJ-45 and two USB LAN/USB1
Ethernet and dual USB combo connector RJ-45 and two USB LAN/USB2
Mouse or keyboard connector PS/2 KB/MS1
Serial port connector (COM1) DB-9 (male) COM1
Serial port connector (COM2) DB-9 (male) COM2
Table 4-2: Rear Panel Connectors
4.2 Internal Peripheral Connectors
Internal peripheral connectors are found on the motherboard and are only accessible
4.3 on page 60.
when the motherboard is outside of the chassis. T his se ction h as complet e d esc ription s of
all the internal, peripheral connectors on the KINO-690S1.
4.2.1 ATX Power Connector
CN Label:
CN Type:
CN Location:
CN Pinouts:
The ATX connector is connected to an external ATX power supply. Power is provided to
the system, from the power supply through this connector.
Page 40
J2
20-pin A TX (2x10)
Figure 4-2
See
Table 4-3
See
KINO-690S1 Mini-ITX Motherboard
Figure 4-2: ATX Power Connector Pinout Locations
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 +3.3V 11 +3.3V
2 +3.3V 12 -12V
3 GND 13 GND
4 +5V 14 PS-ON
5 GND 15 GND
6 +5V 16 GND
7 GND 17 GND
8 PW-OK 18 N/C
9 +VCC5SB 19 +5V
10 +12V 20 +5V
Table 4-3: ATX Power Connector Pinouts
4.2.2 Digital Input/Output (DIO) Connector
CN Label:
CN Type:
DIO1
10-pin header (2x5)
Figure 4-3
CN Location:
CN Pinouts:
See
See
Table 4-4
Page 41
KINO-690S1 Mini-ITX Motherboard
The digital input/output connector is managed through a Super I/O chip. The DIO
connector pins are user programmable.
Figure 4-3: DIO Connector Connector Locations
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 2 VCC
3 Output 3 4 Output 2
5 Output 1 6 Output 0
7 Input 3 8 Input 2
9 Input 1 10 Input 0
Table 4-4: DIO Connector Connector Pinouts
4.2.3 Fan Connector (+12V)
CN Label:
CN Type:
CN Location:
CN Pinouts:
CPU_FAN1, SYS_FAN1
3-pin header
Figure 4-4
See
Table 4-5
See
Page 42
The cooling fan connector provides a 12V, 500mA current to a system cooling fan. The
connector has a "rotation" pin to get rotation signals from fans and notify the system so the
KINO-690S1 Mini-ITX Motherboard
system BIOS can recognize the fan speed. Please note that only specified fans can issue
the rotation signals.
Figure 4-4: +12V Fan Connector Location
PIN NO. DESCRIPTION
1 GND Rotation Signal
2 +12V
3 GND
Table 4-5: +12V Fan Connector Pinouts
4.2.4 Front Panel Connector (14-pin)
CN Label:
CN Type:
CN Location:
CN Pinouts:
F_PANEL1
12-pin header (2x6)
Figure 4-5
See
Table 4-6
See
The front panel connector connects to external switches and indicators to monitor and
controls the motherboard. These indicators and switches include:
Power LED
Page 43
Speaker
Power button
Reset
HDD LED
KINO-690S1 Mini-ITX Motherboard
Figure 4-5: Front Panel Connector Pinout Locations (14-pin)
FUNCTION PIN DESCRIPTION FUNCTION PIN DESCRIPTION
Power
LED
Button
1 LED+ 2 SPEAKER+
3 BLINK 4 N/C
5 GND 6 N/C
7 PWRBTSW+
9 GND 10 N/C
11 IDE LED+ 12 RESET+ HDD LED
13 IDE LED-
Speaker
8 SPEAKER - Power
Reset
14 GND
Table 4-6: Front Panel Connector Pinouts (14-pin)
Page 44
KINO-690S1 Mini-ITX Motherboard
4.2.5 IDE Connector (40-pin)
CN Label:
CN Type:
CN Location:
CN Pinouts:
IDE1
40-pin header (2x20)
Figure 4-6
See
Table 4-7
See
One 40-pin IDE device connector on the KINO-690S1 supports connectivity to two hard
disk drives.
Figure 4-6: IDE Device Connector Locations
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 RESET# 2 GROUND
3 DATA 7 4 DATA 8
5 DATA 6 6 DATA 9
7 DATA 5 8 DATA 10
9 DATA 4 10 DATA 11
11 DATA 3 12 DATA 12
13 DATA 2 14 DATA 13
15 DATA 1 16 DATA 14
17 DATA 0 18 DATA 15
Page 45
19 GROUND 20 N/C
21 IDE DRQ 22 GROUND
23 IOW# 24 GROUND
25 IOR# 26 GROUND
27 IDE CHRDY 28 GROUND
29 IDE DACK 30 GROUND–DEFAULT
31 INTERRUPT 32 N/C
33 SA1 34 N/C
35 SA0 36 SA2
37 HDC CS0# 38 HDC CS1#
39 HDD ACTIVE# 40 GROUND
Table 4-7: IDE Connector Pinouts
4.2.6 Infrared Interface Connector (5-pin)
KINO-690S1 Mini-ITX Motherboard
CN Label:
CN Type:
CN Location:
CN Pinouts:
IR1
5-pin header (1x5)
Figure 4-7
See
Table 4-8
See
The infrared interface connector supports both Serial Infrared (SIR) and Amplitude Shift
Key Infrared (ASKIR) interfaces.
Page 46
KINO-690S1 Mini-ITX Motherboard
Figure 4-7: Infrared Connector Pinout Locations
PIN NO. DESCRIPTION
1 VCC
2 NC
3 IR-RX
4 GND
5 IR-TX
Table 4-8: Infrared Connector Pinouts
4.2.7 PCI Slot
CN Label:
CN Type:
CN Location:
CN Pinouts:
The PCI slot enables a PCI expansion module to be connected to the board.
PCI1
PCI Slot
Figure 4-8
See
Table 4-9
See
Page 47
KINO-690S1 Mini-ITX Motherboard
Page 48
KINO-690S1 Mini-ITX Motherboard
Figure 4-8: PCI Slot Location
Page 49
KINO-690S1 Mini-ITX Motherboard
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
A1 TRST B1 -12V
A2 +12V B2 TCK
A3 TMS B3 GND
A4 TDI B4 TDO
A5 +5V B5 +5V
A6 INTA B6 +5V
A7 INTC B7 INTB
A8 +5V B8 INTD
A9 RESERVED3 B9 PRSNT1
A10 +5V B10 RESERVED1
A11 RESERVED4 B11 PRSNT2
A12 GND B12 GND
A13 GND B13 GND
A14 3.3V_AUX B14 RESERVED2
A15 RST B15 GND
A16 +5V B16 CLK
A17 GNT B17 GND
A18 GND B18 REQ
A19 PME B19 +5V
A20 AD30 B20 AD31
A21 +3.3V B21 AD29
A22 AD28 B22 GND
A23 AD26 B23 AD27
A24 GND B24 AD25
A25 AD24 B25 +3.3V
A26 IDSEL B26 C/BE3
A27 +3.3V B27 AD23
A28 AD22 B28 GND
Page 50
A29 AD20 B29 AD21
A30 GND B30 AD19
A31 AD18 B31 +3.3V
KINO-690S1 Mini-ITX Motherboard
A32 AD16 B32 AD17
A33 +3.3V B33 C/BE2
A34 FRAME B34 GND
A35 GND B35 IRDY
A36 TRDY B36 +3.3V
A37 GND B37 DEVSEL
A38 STOP B38 GND
A39 +3.3V B39 LOCK
A40 SDONE B40 PERR
A41 SBO B41 +3.3V
A42 GND B42 SERR
A43 PAR B43 +3.3V
A44 AD15 B44 C/BE1
A45 +3.3V B45 AD14
A46 AD13 B46 GND
A47 AD11 B47 AD12
A48 GND B48 AD10
A49 AD9 B49 GND
A52 C/BE0 B52 AD8
A53 +3.3V B53 AD7
A54 AD6 B54 +3.3V
A55 AD4 B55 AD5
A56 GND B56 AD3
A57 AD2 B57 GND
A68 AD0 B68 AD1
A59 +5V B59 +5V
A60 REQ64 B60 ACK64
A61 +5V B61 +5V
A62 +5V
B62 +5V
Table 4-9: PCI Slot
Page 51
4.2.8 PCI Express x1 Slot
KINO-690S1 Mini-ITX Motherboard
CN Label:
CN Type:
CN Location:
CN Pinouts:
PCIe x1 expansion devices can be inserted into the PCIe x1 slots.
PCIE_2, PCIE_3
10-pin header (2x5)
Figure 4-9
See
Table 4-10
See
Page 52
KINO-690S1 Mini-ITX Motherboard
Figure 4-9: PCI Express x1 Slot Locations
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
A11
A12
NC
+12v
+12v
GND
NC
NC
NC
NC
+3.3v
+3.3v
PCIE RST
GND
B1
B2
B3
B4
B5
B6
B7
B8
B9
B10
B11
B12
+12v
+12v
+12v
GND
SCLOCK
SDATA
GND
+3.3v
NC
+3.3v Dual
PCIE WAKEUP
NC
A13
A14
PCIE CLOCK+
PCIE CLOCK-
B13
B14
GND
GPP_TX3P
Page 53
KINO-690S1 Mini-ITX Motherboard
A15
A16
A17
A18
Table 4-10: PCI Express x1 Slot Pinouts
GND
GPP_RX3P
GPP_RX3N
GND
B15
B16
B17
B18
GPP_TX3N
GND
N/C
GND
4.2.9 SATA Drive Connectors
CN Label:
CN Type:
CN Location:
CN Pinouts:
The two SATA drive connectors are each connected to a first generation SATA drive. First
generation SATA drives transfer data at speeds as high as 150Mb/s. The SATA drives can
SATA1, SATA2, SATA3, and SATA4
7-pin SATA drive connectors
Figure 4-10
See
Table 4-11
See
be configured in a RAID configuration.
Page 54
Figure 4-10: SATA Drive Connector Locations
KINO-690S1 Mini-ITX Motherboard
PIN NO. DESCRIPTION
1 GND
2 TX+
3 TX4 GND
5 RX6 RX+
7 GND
Table 4-11: SATA Drive Connector Pinouts
4.2.10 Serial Port Connector (COM3)
CN Label:
CN Type:
CN Location:
CN Pinouts:
COM3
10-pin header (2x5)
Figure 4-11
See
Table 4-12
See
The 10-pin serial port connector provides a second RS-232 serial communications
channel. The COM3 serial port connector can be connected to external RS -23 2 serial p ort
devices.
Figure 4-11: Serial Connector Pinout Locations
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 Data Carrier Direct (DCD) 2 Data Set Ready (DSR)
Page 55
3 Receive Data (RXD) 4 Request To Send (RTS)
5 Transmit Data (TXD) 6 Clear To Send (CTS)
7 Data Terminal Ready (DTR) 8 Ring Indicator (RI)
9 Ground (GND) 10 Ground (GND)
KINO-690S1 Mini-ITX Motherboard
Table 4-12: Serial Connector Pinouts
4.2.11 Serial Port Connector (COM4)(RS-232, RS-422 or RS-485)
CN Label:
CN Type:
CN Location:
CN Pinouts:
COM4
14-pin header (2x7)
Figure 4-12
See
Table 4-13
See
The 14-pin serial port connector connects to the COM 2 serial communications channels.
COM 2 is a multi function channel. In default mode COM 2 is an RS-232 serial
communication channel but, with the COM 2 function select jumper, can be configured as
either an RS-422 or RS-485 serial communications channel.
Page 56
Figure 4-12: RS-232/422/485 Serial Port Connector Location
KINO-690S1 Mini-ITX Motherboard
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 DCD 2 NDSR2
3 RXD 4 NRTS2
5 TXD 6 NCTS2
7 DTR 8 NRI2
9 GND 10 GND
11 TXD85+ 12 TXD485#
13 RXD85+ 14 RXD485#
Table 4-13: RS-232/RS-485 Serial Port Connector Pinouts
4.2.12 Trusted Platform Module (TPM) Connector
CN Label:
CN Type:
CN Location:
CN Pinouts:
The Trusted Platform Module (TPM) connector secures the system on bootup. An optional
TPM (see packing list in Chapter 3) can be connected to the TPM connector.
TPM1
40-pin header (2x20)
Figure 4-14
See
Table 4-15
See
Figure 4-13: TPM Connector Pinout Locations
Page 57
KINO-690S1 Mini-ITX Motherboard
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 LCLK 2 GND2
3 LFRAME# 4 KEY
5 LRESET# 6 +5V
7 LAD3 8 LAD2
9 +3V 10 LAD1
11 LAD0 12 GND3
13 SCL 14 SDA
15 SB3V 16 SERIRQ
17 GND1 18 GLKRUN#
19 LPCPD# 20 LDRQ#
Table 4-14: TPM Connector Pinouts
4.2.13 TV Out Connector
CN Label:
CN Type:
CN Location:
CN Pinouts:
The 2x3 pin TV out connector connects to a TV output by using an S-Video or RCA
connector. The TV out connector makes displaying media data on a television easier.
TV1
6-pin header (2x3)
Figure 4-14
See
Table 4-15
See
Page 58
Figure 4-14: TV Connector Pinout Locations
KINO-690S1 Mini-ITX Motherboard
S-Video Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 2 Luminance (Y)
3 GND 4 Chrominance (Pr)
5 GND 6 Chrominance (Pb)
Table 4-15: TV Port Connector Pinouts
4.2.14 USB Connectors (Internal)
CN Label:
CN Type:
CN Location:
CN Pinouts:
JUSB1 and JUSB2
8-pin header (2x4)
Figure 4-15
See
Table 4-16
See
The 2x4 USB pin connectors each provide connectivity to two USB 1.1 or two USB 2.0
ports. Each USB connector can support two USB devices. Additional external USB ports
are found on the rear panel. The USB ports are used for I/O bus expansion.
Figure 4-15: USB Connector Pinout Locations
Page 59
KINO-690S1 Mini-ITX Motherboard
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 VCC 2 GND
3 DATAN- 4 DATAM+
5 DATAN+ 6 DATAM7 GND 8 VCC
Table 4-16: USB Port Connector Pinouts
4.3 External Peripheral Interface Connector Panel
Figure 4-16 shows the KINO-690S1 external peripheral interface connector (EPIC) panel.
The KINO-690S1 EPIC panel consists of the following:
3 x Audio jack connectors
1 x DVI connector
2 x PS/2 connectors
2 x RJ-45 LAN connectors
2 x RS-232 serial port connectors
4 x USB 2.0 connectors
1 x VGA connector
Figure 4-16: KINO-690S1 External Peripheral Interface Connector
4.3.1 Audio Connector
CN Label:
CN T ype:
Page 60
CN8
3 x audio jacks
KINO-690S1 Mini-ITX Motherboard
See
CN Location:
The three audio jacks on the external audio connector enable the KINO-690S1 to be
connected to external audio devices as specified below.
Line Out port (Lime): Connects to a headphone or a speaker. With
multi-channel configurations, this port can also connect to front speakers.
Microphone (Pink): Connects a microphone.
Figure 4-16
Figure 4-17: Audio Connector
4.3.2 DVI and VGA Combo Connector
CN Label:
CN T ype:
CN Location:
CN Pinouts:
A 24-pin Digital Visual Interface (DVI) connector and a female DB-15 VGA connector are
integrated into a single EPIC connector as shown in
The DVI connector connects to high-speed, high-resolution digital displays. The DVI-D
connector supports both digital and analog signals. The connector is show in
VIDEO1
DVI-D and DB-15
Figure 4-16
See
Table 4-17 (DVI-D)
See
Figure 4-16.
Figure 4-18
and the pinouts are shown in
Table 4-17.
Page 61
KINO-690S1 Mini-ITX Motherboard
Figure 4-18: DVI-D Connector Pinouts
PIN Signal Name Pin # Signal Name Pin # Signal Name
1 TMDS Data2-
2 TMDS Data2+
3 GND
4 N/C
5 N/C
6 DDC Clock [SCL]
7 DDC Data [SDA]
8 Analog vertical sync
C1 N/C
C2 N/C
C3 N/C
C4 N/C
C5 N/C
Table 4-17: DVI-D Connector Pinouts
9
10 TMDS Data1+ 18 TMDS Data0+
11 GND
12 NC
13 NC
14 PVDD1
15 GND
16 GND
--
--
--
--
--
TMDS Data1- 17 TMDS Data0-
--
--
--
--
--
19 GND
--
--
--
--
--
20 NC
21 NC
22 GND
23 TMDS Clock +
24 TMDS Clock -
--
--
--
--
--
The female DB-15 VGA connector connects to standard VGA displays. The connector is
show in
Page 62
Figure 4-19 and the pinouts are shown in Table 4-18.
KINO-690S1 Mini-ITX Motherboard
Figure 4-19: VGA Connector
PIN DESCRIPTION PIN DESCRIPTION
1 RED 2 GREEN
3 BLUE 4 NC
5 GND 6 GND
7 GND 8 GND
9 VCC / NC 10 GND
11 NC 12 DDC DAT
13 HSYNC 14 VSYNC
15 DDCCLK
Table 4-18: VGA Connector Pinouts
4.3.3 Keyboard/Mouse Connector
CN Label: CN1
CN Type: Dual PS/2
CN Location: See
CN Pinouts: See
The KINO-690S1 keyboard and mouse connectors are standard PS/2 connectors.
Figure 4-16
Figure 4-20
Page 63
KINO-690S1 Mini-ITX Motherboard
Figure 4-20: PS/2 Pinouts
PIN DESCRIPTION PIN DESCRIPTION
1 L_KDAT 7 L_MDAT
2 NC 8 NC
3 GND 9 GND
4 5V 10 5V
5 L_KCLK 11 L_MCLK
6 NC 12 NC
Table 4-19: PS/2 Connector Pinouts
4.3.4 LAN Connectors
CN Label:
J20 and J21
Page 64
CN Type:
RJ-45
KINO-690S1 Mini-ITX Motherboard
See
CN Location:
CN Pinouts:
Figure 4-16
Table 4-20
See
The KINO-690S1 is equipped with two built-in RJ-45 Ethernet controllers. The controllers
can connect to the LAN through two RJ-45 LAN connectors. There are two LEDs on the
connector indicating the status of LAN. The pin assignments are listed in the following
table:
PIN DESCRIPTION PIN DESCRIPTION
1 TXA+ 5 TXC2 TXA- 6 TXB-
3 TXB+ 7 TXD+
4 TXC+ 8 TXD-
Table 4-20: LAN Pinouts
Figure 4-21: RJ-45 Ethernet Connector
The RJ-45 Ethernet connector has two status LEDs, one green and one yello w. The green
LED indicates activity on the port and the yellow LED indicates the port is linked. See
Table 4-21.
STATUS
ORANGE
GREEN
Table 4-21: RJ-45 Ethernet Connector LEDs
DESCRIPTION STATUS DESCRIPTION
10/100 LAN
GbE LAN
YELLOW Linked
Page 65
KINO-690S1 Mini-ITX Motherboard
4.3.5 Serial Port Connectors (COM1 and COM2 )
CN Label:
CN Type:
CN Location:
CN Pinouts:
Two serial port connectors, COM1 and COM2, are externally accessible. The 9-pin DB-9
serial port connectors are connected to RS-232 serial communications devices.
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 DCD 6 DSR
2 RX 7 RTS
3 TX 8 CTS
4 DTR 9 RI
5 GND
Table 4-22: RS-232 Serial Port Pinouts
COM1 and COM2
DB-9 connectors
Figure 4-16 (see 2)
See
Table 4-22 and Figure 4-22
See
Figure 4-22: Pinout Locations
4.3.6 USB Connector
CN Label:
CN T ype:
CN Location: See
LAN/USB1 and LAN/USB2
USB port
Figure 4-16
Page 66
KINO-690S1 Mini-ITX Motherboard
See
CN Pinouts:
Table 4-23
The KINO-690S1 has four external USB 2.0 ports. The ports are integrated into two dual
USB and LAN combo connectors. The USB ports connect to both USB 2.0 and USB 1.1
devices.
PIN NO. DESCRIPTION
1 +5V
2 USB_PN
3 USB_PP
4 GND
Table 4-23: USB Port Pinouts
Page 67
KINO-690S1 Mini-ITX Motherboard
Chapter
5
5 Installation
Page 68
KINO-690S1 Mini-ITX Motherboard
5.1 Anti-static Precautions
WARNING:
Failure to take ESD precautions during the installation of the
KINO-690S1 may result in permanent damage to the KINO-690S1 and
severe injury to the user.
Electrostatic discharge (ESD) can cause serious damage to electronic components,
including the KINO-690S1. Dry climates are especially susceptible to ESD. It is therefore
critical that whenever the KINO-690S1, or any other electrical component is handled, the
following anti-static precautions are strictly adhered to.
Wear an anti-static wristband: - Wearing a simple anti-static wristband can
help to prevent ESD from damaging the board.
Self-grounding:- Before handling the board touch any grounded conducting
material. During the time the board is handled, frequently touch any
conducting materials that are connected to the ground.
Use an anti-static pad: When configuring the KINO-690S1, place it on an
antic-static pad. This reduces the possibility of ESD damaging the
KINO-690S1.
Only handle the edges of the PCB:-: When handling the PCB, hold the PCB
by the edges.
Page 69
5.2 Installation Considerations
NOTE:
The following installation notices and installation considerations should
be read and understood before the KINO-690S1 is installed. All
installation notices pertaining to the installation of the KINO-690S1
should be strictly adhered to. Failing to adhere to these precautions
may lead to severe damage of the KINO-690S1 and injury to the
person installing the motherboard.
5.2.1 Installation Notices
KINO-690S1 Mini-ITX Motherboard
WARNING:
The installation instructions described in this manual should be carefully
followed in order to prevent damage to the KINO-690S1, KINO-690S1
components and injury to the user.
Before and during the installation please DO the following:
Read the user manual:
o The user manual provides a complete description of the KINO-690S1
installation instructions and configuration options.
Wear an electrostatic discharge cuff (ESD):
o Electronic components are easily damaged by ESD. Wearing an ESD cuff
removes ESD from the body and helps prevent ESD damage.
Place the KINO-690S1 on an antistatic pad:
o When installing or configuring the motherboard, place it on an antistatic
Page 70
pad. This helps to prevent potential ESD damage.
Turn all power to the KINO-690S1 off:
KINO-690S1 Mini-ITX Motherboard
o When working with the KINO-690S1, make sure that it is disconnected
from all power supplies and that no electricity is being fed into the system.
Before and during the installation of the KINO-690S1 DO NOT:
Remove any of the stickers on the PCB board. These stickers are required for
warranty validation.
Use the product before verifying all the cables and power connectors are
properly connected.
Allow screws to come in contact with the PCB circuit, connector pins, or its
components.
5.2.2 Installation Checklist
The following checklist is provided to ensure the KINO-690S1 is properly installed.
All the items in the packing list are present
The CPU is installed
The CPU cooling kit is properly installed
A compatible memory module is properly inserted into the slot
The CF Type I or CF Type II card is properly installed into the CF socket
The jumpers have been properly configured
The KINO-690S1 is inserted into a chassis with adequate ventilation
The correct power supply is being used
The following devices are properly connected
o Primary and secondary IDE device
o SATA drives
o Audio kit
o Power supply
o USB cable
o Serial port cable
The following external peripheral devices are properly connected to the
chassis:
o DVI screen
o Keyboard
o Mouse
Page 71
o LAN
o VGA screen
5.3 Unpacking
5.3.1 Unpacking Precautions
When the KINO-690S1 is unpacked, please do the following:
Follow the anti-static precautions outlined in Section 5.1.
Make sure the packing box is facing upward s so the KINO-690S1 does not fall
out of the box.
Make sure all the components in the checklist shown in Chapter 3 are
present.
NOTE:
KINO-690S1 Mini-ITX Motherboard
If some of the components listed in the checklist in Chapter 3 are
missing, please do not proceed with the installation. Contact the IEI
reseller or vendor you purchased the KINO-690S1 from or contact an
IEI sales representative directly. To contact an IEI sales representative,
please send an email to
sales@iei.com.tw.
Page 72
KINO-690S1 Mini-ITX Motherboard
5.4 CPU, CPU Cooling Kit and DIMM Installation
WARNING:
A CPU should never be turned on without the specified cooling kit
being installed. If the cooling kit (heat sink and fan) is not properly
installed and the system turned on, permanent damage to the CPU,
KINO-690S1 and other electronic components attached to the system
may be incurred. Running a CPU without a cooling kit may also result
in injury to the user.
The CPU, CPU cooling kit and DIMM are the most critical components of the
KINO-690S1. If one of these components is not installed the KINO-690S1 cannot run.
5.4.1 AMD Socket S1 CPU Installation
WARNING:
CPUs are expensive and sensitive components. When installing the
CPU please be careful not to damage it in anyway. Make sure the CPU
is installed properly and ensure the correct cooling kit is properly
installed.
To install a AMD Socket S1 CPU onto the KINO-690S1, follow the steps below:
WARNING:
When handling the CPU, only hold it on the sides. DO NOT touch the
pins at the bottom of the CPU.
Page 73
Step 1: Unlock the CPU retention screw. When shipped, the retention screw of the
CPU socket should be in the unlocked position. If it is not in the unlocked
KINO-690S1 Mini-ITX Motherboard
position, use a screwdriver to unlock the screw. See
Figure 5-1: Make sure the CPU socket retention screw is unlocked
Figure 5-1.
Page 74
Step 2: Inspect the CPU socket. Make sure there are no bent pins and make sure the
socket contacts are free of foreign material. If any debris is found, remove it with
compressed air.
Step 3: Correctly Orientate the CPU. Make sure the IHS (integrated heat sink) side is
facing upwards.
Step 4: Correctly position the CPU. Match the Pin 1 mark with the cut edge on the
CPU socket. See
Step 5: Align the CPU pins. Carefully align the CPU pins with the holes in the CPU
socket.
Step 6: Insert the CPU. Gently insert the CPU into the socket. If the CPU pins are
properly aligned, the CPU should slide into the CPU socket smoothly.
Figure 5-1.
KINO-690S1 Mini-ITX Motherboard
Step 7: Lock the retention screw. Rotate the retention screw into the locked position.
Step 0:
5.4.2 Cooling Kit CF-479B-RS Installation
Figure 5-2: IEI CF-479B-RS Cooling Kit
An IEI AMD Socket S1 CPU cooling kit (
cooling kit comprises a CPU heat sink and a cooling fan.
Figure 5-2) can be purchased separately. The
WARNING:
Do not wipe off (accidentally or otherwise) the pre-sprayed layer of
thermal paste on the bottom of the [Fan model#] heat sink. The thermal
paste between the CPU and the heat sink is important for optimum
heat dissipation.
To install the CF-479B-RS cooling kit, please follow the steps below.
Step 1: Place the cooling kit onto the CPU. Make sure the CPU cooling fan cable
can be properly routed when the cooling kit is install ed.
Step 2: Properly align the cooling kit. Make sure its four spring screw fasteners can
pass through the pre-drilled holes on the PCB.
Step 3: Secure the cooling kit. From the solder side of the PCB, align the support
bracket to the screw threads on heat sink that were inserted through the PCB
Page 75
holes. (See Figure 5-3)
Figure 5-3: Cooling Kit Support Bracket
Step 4: Tighten the screws. Use a screwdriver to tighten the four screws. Tighten each
nut a few turns at a time and do not over-tighten the screws.
KINO-690S1 Mini-ITX Motherboard
Step 5: Connect the fan cable. Connect the cooling kit fan cable to the fan connector
on the motherboard. Carefully route the cable and avoid heat generating chips
and fan blades. See
Figure 5-4: Connect the cooling fan cable
Figure 5-4. Step 0:
Page 76
KINO-690S1 Mini-ITX Motherboard
5.4.3 SO-DIMM Installation
WARNING:
Using incorrectly specified SO-DIMMs may permanently damage the
KINO-690S1. Please make sure the purchased SO-DIMM complies
with the memory specifications of the KINO-690S1. SO-DIMM
specifications compliant with the KINO-690S1 are listed in Chapter 2.
To install a SO-DIMM into a SO-DIMM socket, please follow the steps below and refer to
Figure 5-5.
Figure 5-5: SO-DIMM Installation
Step 1: Locate the SO-DIMM socket. Place the KINO-690S1 on an anti-static pad with
the solder side facing up.
Step 2: Align the SO-DIMM with the socket. The SO-DIMM must be oriented in such a
way that the notch in the middle of the SO-DIMM must be aligned with the
plastic bridge in the socket.
Step 3: Insert the SO-DIMM. Push the SO-DIMM chip into the socket at an angle. (See
Figure 5-5)
Page 77
Step 4: Open the SO-DIMM socket arms. Gently pull the arms of the SO-DIMM socket
KINO-690S1 Mini-ITX Motherboard
out and push the rear of the SO-DIMM down. (See
Step 5: Secure the SO-DIMM. Release the arms on the SO-DIMM socket. They clip into
place and secure the SO-DIMM in the socket.Step 0:
5.5 Jumper Settings
NOTE:
A jumper is a metal bridge that is used to
close an electrical circuit. It consists of
two metal pins and a small metal clip
(often protected by a plastic cover) that
slides over the pins to connect them.
To CLOSE/SHORT a jumper means
connecting the pins of the jumper with
the plastic clip and to OPEN a jumper
Figure 5-5)
Jumper
means removing the plastic clip from a
jumper.
Before the KINO-690S1 is installed in the system, the jumpers must be set in accordance
with the desired configuration. The jumpers on the KINO-690S1 are listed in
Description Label Type
Clear CMOS J2 3-pin header
RS-232/485 Setup for COM4 J1 3-pin header
Table 5-1: Jumpers
Table 5-1.
Page 78
KINO-690S1 Mini-ITX Motherboard
5.5.1 Clear CMOS Jumper
Jumper Label:
Jumper Type:
Jumper Settings:
Jumper Location:
J2
3-pin header
Table 5-2
See
Figure 5-6
See
If the KINO-690S1 fails to boot due to improper BIOS settings, the clear CMOS jumper
clears the CMOS data and resets the system BIOS information. To do this, use the jumper
cap to close pins 2 and 3 for a few seconds then reinstall the jumper clip back to pins 1
and 2.
If the “CMOS Settings Wrong” message is displayed during the boot up process, the fault
may be corrected by pressing the F1 to enter the CMOS Setup menu. Do one of the
following:
Enter the correct CMOS setting
Load Optimal Defaults
Load Failsafe Defaults.
After having done one of the above, save the changes and exit the CMOS Setup menu.
The clear CMOS jumper settings are shown in
Jumper Select Description
Short 1 - 2 Keep CMOS Setup Default
Short 2 - 3 Clear CMOS Setup
Table 5-2.
Table 5-2: Clear CMOS Jumper Settings
The location of the clear CMOS jumper is shown in Figure 5-6 below.
Page 79
Figure 5-6: Clear CMOS Jumper
5.5.2 COM 4 Function Select Jumper
KINO-690S1 Mini-ITX Motherboard
Jumper Label: J1
Jumper Type:
Jumper Settings: See
Jumper Location: See
The COM4 Function Select jumper sets the communication protocol used by the second
serial communications port (COM4) as RS-232, RS-422 or RS-485. The COM4 Function
Select settings are shown in
COM 2 Function Select Description
Short 1-2 RS-232 Default
Short 2-3 RS-422/485
Table 5-3: COM4 Function Select Jumper Settings
The COM4 Function Select jumper location is shown in Figure 5-7.
3-pin header
Table 5-3
Figure 5-7
Table 5-3.
Page 80
KINO-690S1 Mini-ITX Motherboard
Figure 5-7: COM4 Function Select Jumper Location
5.6 Chassis Installation
5.6.1 Airflow
WARNING:
Airflow is critical to the cooling of the CPU and other onboard
components. The chassis in which the KINO-690S1 must have air
vents to allow cool air to move into the system and hot air to move out.
The KINO-690S1 must be installed in a chassis with ventilation holes on the sides allowing
airflow to travel through the heat sink surface. In a system with an individual power supply
unit, the cooling fan of a power supply can also help generate airflow through the board
surface.
Page 81
KINO-690S1 Mini-ITX Motherboard
NOTE:
IEI has a wide range of backplanes available. Please contact your
KINO-690S1 vendor, reseller or an IEI sales representative at
sales@iei.com.tw or visit the IEI website (http://www.ieiworld.com.tw)
to find out more about the available chassis.
5.6.2 Motherboard Installation
To install the KINO-690S1 motherboard into the chassis please refer to the reference
material that came with the chassis.
5.7 Internal Peripheral Device Connections
5.7.1 Peripheral Device Cables
The cables listed in Table 5-4 are shipped with the KINO-690S1.
Quantity Type
1 ATA 66/100 flat cable
1 I/O shield
1 Dual RS-232 cable
2 SATA drive cables
1 SATA drive power cables
1 USB cable
Table 5-4: IEI Provided Cables
Separately purchased optional IEI items that can be installed are listed below:
Page 82
Audio kit
FDD cable
