IEI Technology ICECARE-10W, ICECARE-10W-CE-R10, ICECARE-10W-CE-ET-R10, ICECARE-10W-17-R10, ICECARE-10W-17-ET-R10 User Manual

Download

ICECARE-10W Mobile Sales Assistant

MODEL:

ICECARE-10W Series

10.1” Mobile Sales Assistant with

Intel® Core i7/Celeron® CPU, DDR3 SDRAM,

802.11b/g/n Wireless, Bluetooth, RFID, USB, Micro HDMI,

MSR, SCR, RoHS Compliant, IP 54 Compliant Front Panel

User Manual

Rev. 1.02 – October 3, 2014

Page i

ICECARE-10W Mobile Sales Assistant

Revision

Date Version Changes

October 3, 2014 1.02 Removed Intel® Atom N2600 end-of-life processor

information.

April 2, 2014 1.01 Modified the CPU specifications of the model with Intel®

Celeron® processor. Modified Section 3.7: Testing Smart Card Reader

December 18, 2013 1.00 Initial release

Page ii

ICECARE-10W Mobile Sales Assistant

In no event will the manufacturer be liable for direct, indirect, special, incidental, or

consequential damages arising out of the use or inability to use the product or

documentation, even if advised of the possibility of such damages.

This document contains proprietary information protected by copyright. All rights are

reserved. No part of this manual may be reproduced by any mechanical, electronic, or

other means in any form without prior written permission of the manufacturer.

TRADEMARKS

Copyright

All registered trademarks and product names mentioned herein are used for identification

purposes only and may be trademarks and/or registered trademarks of their respective

owners.

Page iii

ICECARE-10W Mobile Sales Assistant

WARNING

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and(2) this device must accept any interference received, including interference that may cause u ndesired operation.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

—

Reorient or relocate the receiving antenna.

—

Increase the separation between the equipment and receiver.

—

Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

—

Consult the dealer or an experienced radio/ TV technician for help.

You are cautioned that any change or modifications to the equipment not expressly approve by the party responsible for compliance could void your authority to operate such equipment.

IMPORTANT NOTE:

FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body

Page iv

ICECARE-10W Mobile Sales Assistant

1 INTRODUCTION.......................................................................................................... 1

1.1 OVERVIEW.................................................................................................................. 2

1.2 FEATURES................................................................................................................... 3

1.3 MODEL VARIATIONS................................................................................................... 3

1.4 FRONT PANEL............................................................................................................. 4

1.4.1 Status Indicators ................................................................................................ 4

1.5 REAR PANEL............................................................................................................... 6

1.6 SIDE PANELS .............................................................................................................. 6

1.7 TOP PANEL ................................................................................................................. 7

1.8 TECHNICAL SPECIFICATIONS ...................................................................................... 7

1.9 DIMENSIONS............................................................................................................... 9

2 UNPACKING............................................................................................................... 10

2.1 UNPACK THE SYSTEM................................................................................................11

2.2 PACKING LIST............................................................................................................11

3 HARDWARE INSTALLATION................................................................................. 13

3.1 INSTALLATION CONSIDERATIONS.............................................................................. 14

3.2 CHARGE THE SYTEM ................................................................................................ 15

POWER-UP THE SYSTEM ........................................................................................... 16

3.3

3.4 USING RFID READER............................................................................................... 17

3.5

USING BARCODE SCANNER...................................................................................... 20

3.5.1 Barcode Setting................................................................................................ 25

3.6 USING MAGNETIC STRIPE READER .......................................................................... 29

3.7 TESTING SMART CARD READER............................................................................... 33

4 DRIVER INSTALLATION......................................................................................... 35

4.1 AVAILABLE SOFTWARE DRIVERS .............................................................................. 36

4.2 INTEL® CHIPSET DRIVER......................................................................................... 36

4.3 INTEL® GRAPHICS DRIVER ...................................................................................... 38

4.4 AUDIO DRIVER......................................................................................................... 39

Page v

BLUETOOTH DRIVER................................................................................................ 41

4.5

ICECARE-10W Mobile Sales Assistant

4.6 WIRELESS LAN DRIVER .......................................................................................... 43

4.7 RFID DRIVER .......................................................................................................... 45

5 BIOS SETUP................................................................................................................ 48

5.1 INTRODUCTION......................................................................................................... 49

5.1.1 Starting Setup................................................................................................... 49

5.1.2 Using Setup...................................................................................................... 49

5.1.3 Getting Help..................................................................................................... 50

5.1.4 BIOS Menu Bar................................................................................................ 50

5.2 MAIN........................................................................................................................ 51

5.3

ADVANCED............................................................................................................... 52

5.3.1 ACPI Settings................................................................................................... 53

5.3.2 RTC Wake Settings........................................................................................... 54

5.3.3 T rusted Computing........................................................................................... 55

5.3.4 CPU Configuration.......................................................................................... 56

5.3.5 SATA Configuration ......................................................................................... 57

5.3.6 Intel(R) Rapid Start Technology....................................................................... 58

5.3.7 USB Configuration........................................................................................... 59

5.3.8 iWDD Serial Ports Configuration ................................................................... 60

5.3.8.1 Serial Port 1 Configuration....................................................................... 61

5.3.8.2 Serial Port 2 Configuration....................................................................... 62

5.3.9 H/W Monitor.................................................................................................... 63

5.3.10 Serial Port Console Redirection.................................................................... 63

5.3.11 IEI Feature..................................................................................................... 64

CHIPSET ................................................................................................................... 65

5.4

5.4.1 PCH-IO Configuration .................................................................................... 66

5.4.2 System Agent (SA) Configuration .................................................................... 69

5.4.2.1 Graphics Configuration............................................................................. 69

5.4.2.2 Memory Configuration ............................................................................. 71

5.5 BOOT........................................................................................................................ 72

5.6 SECURITY................................................................................................................. 74

5.7 EXIT......................................................................................................................... 74

A SAFETY PRECAUTIONS.........................................................................................76

Page vi

ICECARE-10W Mobile Sales Assistant

SAFETY PRECAUTIONS ............................................................................................ 77

A.1

A.1.1 General Safety Precautions............................................................................. 77

A.1.2 Anti-static Precautions.................................................................................... 78

A.1.3 Product Disposal............................................................................................. 79

A.2 MAINTENANCE AND CLEANING PRECAUTIONS........................................................ 79

A.2.1 Maintenance and Cleaning.............................................................................. 79

A.2.2 Cleaning Tools................................................................................................. 80

B BIOS OPTIONS .......................................................................................................... 82

C TERMINOLOGY ....................................................................................................... 85

D WATCHDOG TIMER ................................................................................................ 89

E HAZARDOUS MATERIALS DISCLOSURE ......................................................... 92

E.1

HAZARDOUS MATERIALS DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS

ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY....................................... 93

Page vii

ICECARE-10W Mobile Sales Assistant

List of Figures

Figure 1-1: ICECARE-10W Series..................................................................................................2

Figure 1-2: Front Panel ..................................................................................................................4

Figure 1-3: Front Panel LED Indicators........................................................................................4

Figure 1-4: Rear Panel....................................................................................................................6

Figure 1-5: Side Panels..................................................................................................................6

Figure 1-6: Top Panel.....................................................................................................................7

Figure 1-7: Dimensions (units in mm)..........................................................................................9

Figure 3-1: Power Input Connector and Power LED Indicator.................................................15

Figure 3-2: Windows Embedded 7 Power Management Screen..............................................16

Figure 3-3: Power Button and Power LED Location.................................................................16

Figure 3-4: PcscTool Location....................................................................................................18

Figure 3-5: NXP PCSC Tool Screen............................................................................................18

Figure 3-6: NXP PCSC Tool – Mode Selection...........................................................................19

Figure 3-7: NXP PCSC Tool – Reader Selection........................................................................19

Figure 3-8: NXP PCSC Tool – Select the Reader.......................................................................19

Figure 3-9: NXP PCSC Tool – Read RFID Card..........................................................................20

Figure 3-10: RFID Reader Location.............................................................................................20

Figure 3-11: Barcode Scanner Program Location.....................................................................21

Figure 3-12: EasySet InstallShield Wizard.................................................................................22

Figure 3-13: Menu Button and Barcode Status Indicator.........................................................22

Figure 3-14: EasySet Window .....................................................................................................23

Figure 3-15: EasySet – Communication.....................................................................................23

Figure 3-16: Device Selection Window.......................................................................................24

Figure 3-17: Communication – Disconnect ...............................................................................24

Figure 3-18: Barcode Information Display Area........................................................................25

Figure 3-19: Barcode Parameters...............................................................................................26

Figure 3-20: Symbologies............................................................................................................27

Figure 3-21: Operating Settings..................................................................................................27

Figure 3-22: Scanning/Triggering...............................................................................................28

Figure 3-23: Beeps/Green Indicator LED ...................................................................................28

Page viii

ICECARE-10W Mobile Sales Assistant

Figure 3-24: Check COM Port Information for MSR..................................................................30

Figure 3-25: 3DesHeadV1.3 Demo Program Location ..............................................................30

Figure 3-26: 3DesHeadV1.3 – Open COM...................................................................................31

Figure 3-27: 3DesHeadV1.3 – Data Read....................................................................................31

Figure 3-28: Swipe a Magnetic Stripe Card................................................................................32

Figure 3-29: Magnetic Stripe Card Information.........................................................................32

Figure 3-30: Insert Smart Card....................................................................................................33

Figure 3-31: Smart Card Reader Testing 1.................................................................................33

Figure 3-32: Smart Card Reader Testing 2.................................................................................34

Figure 4-1: Chipset Driver Location............................................................................................37

Figure 4-2: Intel® Chipset Device Software...............................................................................37

Figure 4-3: Graphics Driver Location.........................................................................................38

Figure 4-4: Intel® Graphics Driver InstallShield Wizard...........................................................39

Figure 4-5: Speaker and Microphone Driver Location..............................................................40

Figure 4-6: Realtek HD Audio Driver InstallShield Wizard .......................................................41

Figure 4-7: Bluetooth Driver Location........................................................................................42

Figure 4-8: Bluetooth Driver InstallShield Wizard.....................................................................43

Figure 4-9: Wireless LAN Driver Location .................................................................................44

Figure 4-10: Bluetooth Driver InstallShield Wizard...................................................................45

Figure 4-11: RFID Driver Location ..............................................................................................46

Figure 4-12: RFID Driver Folder ..................................................................................................46

Figure 4-13: RFID Driver Installation ..........................................................................................47

Page ix

ICECARE-10W Mobile Sales Assistant

List of Tables

Table 1-1: Model Variations...........................................................................................................3

Table 1-2: Status Indicators...........................................................................................................5

Table 1-3: Technical Specifications..............................................................................................8

Table 2-1: Packing List.................................................................................................................12

Table 5-1: BIOS Navigation Keys................................................................................................50

Page x

ICECARE-10W Mobile Sales Assistant

BIOS Menus

BIOS Menu 1: Main.......................................................................................................................51

BIOS Menu 2: Advanced..............................................................................................................52

BIOS Menu 3: ACPI Configuration..............................................................................................53

BIOS Menu 4: RTC Wake Settings..............................................................................................54

BIOS Menu 5: Trusted Computing..............................................................................................55

BIOS Menu 6: CPU Configuration...............................................................................................56

BIOS Menu 7: SATA Configuration.............................................................................................57

BIOS Menu 8: Intel(R) Rapid Start Technology .........................................................................58

BIOS Menu 9: USB Configuration...............................................................................................59

BIOS Menu 10: iWDD Serial Ports Configuration......................................................................60

BIOS Menu 11: Serial Port 1 Configuration Menu.....................................................................61

BIOS Menu 12: Hardware Health Configuration........................................................................63

BIOS Menu 13: Serial Port Console Redirection.......................................................................64

BIOS Menu 14: IEI Feature...........................................................................................................65

BIOS Menu 15: Chipset................................................................................................................66

BIOS Menu 16: PCH-IO Configuration........................................................................................66

BIOS Menu 17: System Agent (SA) Configuration....................................................................69

BIOS Menu 18: Graphics Configuration.....................................................................................70

BIOS Menu 19: Memory Configuration.......................................................................................71

BIOS Menu 20: Boot.....................................................................................................................72

BIOS Menu 21: Security...............................................................................................................74

BIOS Menu 22: Exit.......................................................................................................................75

Page xi

ICECARE-10W Mobile Sales Assistant

1 Introduction

Chapter

Page 1

1.1 Overview

ICECARE-10W Mobile Sales Assistant

Figure 1-1: ICECARE-10W Series

The ICECARE-10W Series is a mobile sales assistant with a 10.1 inch touchscreen and

an IP 54 compliant front panel. The ICECARE-10W Series features an Intel® Celeron®

processor 1007U or Intel® Core™ i7-3517U processor with DDR3 SDRAM memory.

Storage needs are met by the preinstalled 32 GB mSATA PCIe Mini module with Windows

Embedded Standard 7 P operating system.

Wireless networking is enabled through an 802.11b/g/n wireless adapter. A Bluetooth v3.0

module provides a connection to Bluetooth devices. Two USB 2.0 ports and one Micro

HDMI port are available on the side panel for peripherals.

The ICECARE-10W Series also features an RFID reader, an optional barcode scanner, an

optional magnetic stripe card reader and an optional smart card reader for advanced data

acquisition.

Page 2

ICECARE-10W Mobile Sales Assistant

1.2 Features

Some of the standard features of the ICECARE-10W Series include:

 10.1” TFT XGA LCD

 Intel® Core™ i7-3517U processor or Intel® Celeron® processor 1007U

supported

 Support RFID reader

 Support Bluetooth and Wi-Fi wireless connection

 Optional 1D/2D barcode scanner, optional magnetic stripe reader and

optional smart card reader

 IP 54 compliant front panel protection

 Windows® Embedded Standard 7 P OS

 RoHS compliant

1.3 Model Variations

There are six models of the ICECARE-10W Series. All of the models support 802.11b/g/n

wireless and Bluetooth connection and are equipped with the multi-touch projected

capacitive touchscreen and a 32 GB SSD module. The model numbers and model

variations are listed below.

ICECARE-10W CPU Memory Barcode MSR SCR IPS Panel

-CE-R10 Intel® Celeron®

1007U 1.5GHz

-CE-ET-R10 Intel® Celeron® 1007U 1.5GHz

-I7-R10 Intel® Core i7-3517U 1.9GHz

-I7-ET-R10 Intel® Core i7-3517U 1.9GHz

Table 1-1: Model Variations

4.0 GB 1D/2D Yes Yes N/A

4.0 GB N/A N/A N/A N/A

4.0 GB 1D/2D Yes Yes Yes

4.0 GB N/A N/A N/A Yes

Page 3

1.4 Front Panel

The front panel of the ICECARE-10W Series has a 10.1” TFT LCD with a multi-touch

proected capacitive touchscreen. Four LED indicators are also located on the front panel.

ICECARE-10W Mobile Sales Assistant

Figure 1-2: Front Panel

1.4.1 Status Indicators

Figure 1-3: Front Panel LED Indicators

There are four LED indicators on the front panel of the ICECARE-10W Series as show in

the figure above. Following are descriptions of their functions:

Page 4

ICECARE-10W Mobile Sales Assistant

Status Indicator Description Power/Battery

RFID/Barcode

Storage

Bluetooth/Wi-Fi

Off: the system is off or the system is fully charged Solid red: the system is being charged. Blinking red: the battery is low (below 9%). Solid blue: the system is turned on. Solid purple: the system is turned on and being charged.

Off: the barcode scanner or the RFID reader is off Solid red: the barcode scanner is turned on Solid blue: the RFID reader is turned on Solid purple: the barcode scanner and the RFID reader are

both turned on Off: the hard drive is not accessed (when the system is on) or

the system is off without standby power (AC power off).

Solid red: the hard drive is accessed Solid blue: the system is off and being charged (or with

standby power) Blinking blue: The system suspends to RAM (S3)

Off: Bluetooth RF is off or Wi-Fi RF is not active Solid red: Bluetooth RF is turned on Solid blue: Wi-Fi RF is active

Table 1-2: Status Indicators

Solid purple: Bluetooth and Wi-Fi are both turned on

Page 5

1.5 Rear Panel

The rear panel has an RFID reader, a speaker and an optional barcode scanner.

Figure 1-4: Rear Panel

ICECARE-10W Mobile Sales Assistant

1.6 Side Panels

The side panels have connectors, button and readers as shown in 473Figure 1-5.

Figure 1-5: Side Panels

Page 6

The menu button has two functions:

 Short press: turn on the barcode scanner

 Long press: act as a Ctrl+ Alt+Del key combination

ICECARE-10W Mobile Sales Assistant

1.7 Top Panel

The power button is located on the top panel. To power-up the system, long press the

power button for few seconds until the power status LED on the front panel lights up in

blue.

Figure 1-6: Top Panel

1.8 Technical Specifications

The technical specifications for the ICECARE-10W Series are listed in the table below.

System ICECARE-10W Series

CPU and Chipset 1.5GHz Intel® Celeron® processor 1007U with Intel® HM76 chipset or

1.9GHz Intel® Core™ i7-3517U processor with Intel® HM76 chipset

Memory On-board 4.0 GB 1333 MHz DDR3 SDRAM (2.0 GB for N2600 models) OS Microsoft Windows Embedded Standard 7 P (WES7P) Storage 1 x 32 GB mSATA PCIe Mini module with 3Gb/s data transfer rate Audio 1 x Speaker Barcode Scanner 1D laser/2D imager barcode scanner (optional) MSR 1 x Magnetic stripe card reader with hardware encryption (optional) SCR 1 x Smart card reader (optional) Display LCD 10.1” TFT LCD with projected capacitive touchscreen Max. Resolution 1280 x 800 (WXGA) Brightness 250 cd/m2 (350 cd/m2 for I7 models) Viewing Angle (H/V) 150/145 Backlight LED backlight Touchscreen Multi-touch capacitive screen with five simultaneous-detection points Communication

Page 7

Wireless LAN 802.11b/g/n Bluetooth Bluetooth v3.0 RFID 13.56 MHz RFID compliant with 14443A and 14443B Power Power Input 19 V DC input Power Adapter Input AC: 100 V ~ 240 V

Output DC: 19 V DC, 2.1 A

Battery 14.8 V 3500 mAh Lithium Ion Battery (non-removable) Physical Character Construction Material Plastic Dimensions (W x H x D) 290.0 mm x 206.5 mm x 22.5 mm Operation Temperature 0ºC ~ 40ºC Storage Temperature -20ºC ~ 60ºC Humidity 5% ~ 95% non-condensing

ICECARE-10W Mobile Sales Assistant

Net weight 1.2 kg IP level (front panel) IP 54 Drop Survival 1.2 m with optional protective cover Safety CE, FCC Class B, FCC ID Connectors and Buttons I/O Ports and Buttons 1 x 19 V DC input connector

2 x USB 2.0 ports 1 x Micro HDMI port 1 x Headset jack 1 x Menu button 1 x Power button 1 x Magnetic stripe card reader (optional) 1 x Smart card reader (optional)

Front Panel LED Indicators

1 x Power/Battery status LED 1 x Barcode/RFID status LED 1 x Storage LED 1 x Wi-Fi LED

Table 1-3: Technical Specifications

Page 8

ICECARE-10W Mobile Sales Assistant

1.9 Dimensions

Figure 1-7: Dimensions (units in mm)

Page 9

ICECARE-10W Mobile Sales Assistant

Chapter

2 Unpacking

Page 10

ICECARE-10W Mobile Sales Assistant

2.1 Unpack the System

To unpack the ICECARE-10W Series, follow the steps below:

WARNING!

Only remove the protective plastic cover stuck to the front screen after

installation. The plastic layer protects the monitor surface during

installation process.

Step 1: Carefully cut the tape sealing the box. Only cut deep enough to break the tape.

Step 2: Open the box.

Step 3: Lift the ICECARE-10W Series out of the boxes.

Step 4: Remove the peripheral parts box from the main box. Step 0:

2.2 Packing List

NOTE:

If any of the components listed in the checklist below are missing, do

not proceed with the installation. Contact the IEI reseller or vendor the

ICECARE-10W Series was purchased from or contact an IEI sales

representative directly by sending an email to

The ICECARE-10W Series is shipped with the following components:

31sales@ieiworld.com.

Page 11

Quantity Item Image

1 ICECARE-10W Series mobile sales

assistant

1 Power adapter

1 Utility CD

ICECARE-10W Mobile Sales Assistant

1 Recovery CD

Table 2-1: Packing List

Page 12

ICECARE-10W Mobile Sales Assistant

3 Hardware Installation

Chapter

Page 13

3.1 Installation Considerations

NOTE:

The following installation notices and installation considerations should

be read and understood before installation. All installation notices must

be strictly adhered to. Failing to adhere to these precautions may lead

to severe damage and injury to the person performing the installation.

WARNING:

The installation instructions described in this manual should be

ICECARE-10W Mobile Sales Assistant

carefully followed in order to prevent damage to the components and

injury to the user.

Before and during the installation please DO the following:

 Read the user manual:

The user manual provides a complete description of the ICECARE-10W

Series installation instructions and configuration options.

 Wear an electrostatic discharge cuff (ESD):

Electronic components are easily damaged by ESD. Wearing an ESD cuff

removes ESD from the body and helps prevent ESD damage.

 Place the ICECARE-10W Series on an antistatic pad:

When installing or configuring the motherboard, place it on an antistatic pad.

This helps to prevent potential ESD damage.

 Turn all power to the ICECARE-10W Series off:

When working with the ICECARE-10W Series, make sure that it is

Page 14

disconnected from all power supplies and that no electricity is being fed into

the system.

Before and during the installation of the ICECARE-10W Series DO NOT:

ICECARE-10W Mobile Sales Assistant

 Remove any of the stickers on the PCB board. These stickers are required for

warranty validation.

 Use the product before verifying all the cables and power connectors are

properly connected.

 Allow screws to come in contact with the PCB circuit, connector pins, or its

components.

3.2 Charge the Sytem

To charge the ICECARE-10W Series, follow the steps below.

Step 1: Connect the ICECARE-10W Series with a power source through the power

adapter came with the package.

Step 2: The system starts to charge the battery and the power status LED lights up in

red indicating the battery is being charged. When the battery is fully charged, the

power status LED turns off.

Figure 3-1: Power Input Connector and Power LED Indicator

Step 3: The user can also turn on the system to check the battery capacity via the

Windows Embedded 7 power management screen (

73Figure 3-2).

Page 15

Figure 3-2: Windows Embedded 7 Power Management Screen

3.3 Power-up the System

To power-up the system, push the power button on the top panel for few seconds until the

ICECARE-10W Mobile Sales Assistant

power status LED on the front panel lights up in blue.

Figure 3-3: Power Button and Power LED Location

Page 16

ICECARE-10W Mobile Sales Assistant

NOTE:

When the battery is low (below 9%), the power status LED blinks in red.

Please refer to the instruction described in Section 3.1 to charge the

tem.

3.4 Using RFID Reader

There is a RFID reader on the rear panel. To use the RFID reader, follow the steps below.

Step 1: Check the RFID status indicator on the front panel to make sure the RFID

function is enabled (see Section 1.4.1). in the BIOS menu. If the RFID reader is disabled, please go to Chipset 

PCH-IO Configuration BIOS menu to enable it (refer to Section 5.4.1).

Step 2: Follow the in

Step 3: Double click the PcscTool icon in the RFID folder in the driver CD.

struction described in Section 4.7 to ins

The RFID function is enabled by default

tall the RFID driver.

Page 17

ICECARE-10W Mobile Sales Assistant

Figure 3-4: PcscTool Location

Step 4: The NXP PCSC Tool window appears (

3Figure 3-5).

Page 18

Figure 3-5: NXP PCSC Tool Screen

ICECARE-10W Mobile Sales Assistant

Step 5: Select Automatic from the Mode menu (3Figure 3-6).

Figure 3-6: NXP PCSC Tool – Mode Selection

Step 6: Choose Select a Reader from the Reader menu (

3Figure 3-7).

Figure 3-7: NXP PCSC Tool – Reader Selection

Step 7: The Select the reader window prompts. Select a RFID reader and click OK. See

Figure 3-8.

Figure 3-8: NXP PCSC Tool – Select the Reader

Page 19

Step 8: Click the Arrow button shown in Figure 3-9 to read RFID card.

Figure 3-9: NXP PCSC Tool – Read RFID Card

Step 9: Use the RFID reader to read a RFID card. The RFID reader is located on the

ICECARE-10W Mobile Sales Assistant

rear panel as shown in Figure 3-10.

Scenario and Logs columns of the PCSC Tool.

Figure 3-10: RFID Reader Location

3.5 Using Barcode Scanner

The card information will be shown in the

Page 20

Some models of the ICECARE-10W Series have a barcode scanner on the rear panel. To

use the barcode scanner, follow the steps below.

Step 1: Check the barcode status indicator on the front panel to make sure the barcode

function is enabled (see Section 1.4.1).

default in the BIOS menu. If the barcode scanner is disabled, please go to

The barcode function is enabled by

ICECARE-10W Mobile Sales Assistant

Chipset  PCH-IO Configuration BIOS menu to enable it (refer to Section

5.4.1).

Step 2: Inst

the driver CD as shown in

all EasySet barcode scanner program. Select 4.BARCODE from the list of

573Figure 3-11.

Figure 3-11: Barcode Scanner Program Location

Step 3: Double click the setup file in the folder. The Easyset InstallShield Wizard screen

appears (Figure 3-12). Fol

low the step-by-step instruction of the installation

wizard to install the EasySet barcode scanner program

Page 21

ICECARE-10W Mobile Sales Assistant

Figure 3-12: EasySet InstallShield Wizard

Step 4: Push the Menu button on the right side panel to turn on the barcode scanner.

The barcode status indicator on the front panel lights up in red (if the RFID

reader is enabled at the same time, the indicator will turns from blue to purple).

Figure 3-13: Menu Button and Barcode Status Indicator

Page 22

Step 5: Double click the EasySet icon on the desktop. The EasySet window appears

3Figure 3-14).

(

ICECARE-10W Mobile Sales Assistant

Figure 3-14: EasySet Window

Step 6: Click Communication on the tool bar and click Select communication

interface from the drop-down menu (

3Figure 3-15).

Figure 3-15: EasySet – Communication

Step 7: The Device Selection window appears (

3Figure 3-16). Select Communication

Port (COM2) and click OK.

Page 23

ICECARE-10W Mobile Sales Assistant

Figure 3-16: Device Selection Window

Step 8: To check if the barcode scanner is connected to the EasySet, click

Communication again and see if the original option (Connect) has been changed to Disconnect.

Figure 3-17: Communication – Disconnect

Step 9: Scan a barcode and the barcode number will be displayed on the right side

Page 24

3Figure 3-18). Step 0:

(

ICECARE-10W Mobile Sales Assistant

Figure 3-18: Barcode Information Display Area

3.5.1 Barcode Setting

All of the barcode parameters can be modified through EasySet. To be able to modify the

parameters, please make sure to connect the EasySet with the barcode scanner (refer to

Section

Step 1: The left side of the EasySet window (

33.5). Follow the steps below to modify the parameters.

3Figure 3-19) displays all parameters that

can be configured.

Page 25

ICECARE-10W Mobile Sales Assistant

Figure 3-19: Barcode Parameters

Step 2: Use the Symbologies section to setup the format that can be read by the

barcode scanner (EA15). In the default setting, only the PDF417 format of 2-D

barcodes is enabled. If other formats are needed, the user must enable them

here. Take Aztec as an example. The Aztec is disabled (the Disable option is

checked). Double click the Enable option to enable Aztec format. See

3Figure

3-20.

Page 26

ICECARE-10W Mobile Sales Assistant

Figure 3-20: Symbologies

Step 3: Use the Operating settings section to configure barcode triggering modes,

decoding security and beeps, etc.

Figure 3-21: Operating Settings

Step 4: In the Scanning/Triggering section of operating settings, the user can set the

triggering mode, continuous, level, etc.

Page 27

ICECARE-10W Mobile Sales Assistant

Figure 3-22: Scanning/Triggering

Step 5: In the Beeps/LEDs section of operating settings, the user can configure the

beep sound of the barcode scanner. Step 0:

Page 28

Figure 3-23: Beeps/Green Indicator LED

ICECARE-10W Mobile Sales Assistant

NOTE:

If no beep sound, please check if the “rtkhdaud.dat” file is in

C:\windows\system32\drivers

3.6 Using Magnetic Stripe Reader

Some models of the ICECARE-10W Series have a magnetic stripe reader (MSR) on the

left panel. To test the magnetic stripe reader, follow the steps below.

Step 1: Check which COM port is used for the MSR connection. Right click

“Computer” from the start menu and select “Manage” (Figure 3-24). The

uter Management window appears. Select “Device Manager” from the left

Comp

panel and look for the COM port information on the right panel.

Page 29

Figure 3-24: Check COM Port Information for MSR

ICECARE-10W Mobile Sales Assistant

Step 2: Launch the 3DesHeadV1.3 demo program. Select 6.MSR from the list of the

driver CD. Double click the 3DesHeadV1.3 icon from the 3DesHeadV1.3 folder to launch it (Figure 3-25).

Page 30

Figure 3-25: 3DesHeadV1.3 Demo Program Location

ICECARE-10W Mobile Sales Assistant

Step 3: Select the COM port connected to the MSR according to the information gained

from Step 2. Then, click the Open Com button. See Figure 3-26.

Figure 3-26: 3DesHeadV1.3 – Open COM

Step 4: Click the Data Read button to start reading the card information from the MSR.

Figure 3-27: 3DesHeadV1.3 – Data Read

Page 31

Step 5: Swipe a magnetic stripe card through the MSR (Figure 3-28).

Figure 3-28: Swipe a Magnetic Stripe Card

ICECARE-10W Mobile Sales Assistant

Step 6: The card information is shown in the bottom fields (Figure 3-29).

Figure 3-29: Magnetic Stripe Card Information

Page 32

ICECARE-10W Mobile Sales Assistant

3.7 Testing Smart Card Reader

Some models of the ICECARE-10W Series have a smart card reader on the left panel.To

test the optional smart card reader, please follow the steps below.

Step 1: Inset a smart card into the smart card reader on the side panel (Figure 3-30).

Figure 3-30: Insert Smart Card

Step 2: Select 8.SCR from the list of the driver CD. Locate the sixslot.exe icon in the

folder and double click the icon to launch the STD100 testing program.

Step 3: The STD100 testing program appears. Select COM1 from the drop down menu

as shown in Figure 3-31.

Figure 3-31: Smart Card Reader Testing 1

Page 33

Step 4: The following screen appears. Check Slot1 to test (all of the slots will be

checked by default) and click the Slot1 testing button to start testing. The testing

result will be shown (PASS or FAIL). See Figure 3-32.

ICECARE-10W Mobile Sales Assistant

Figure 3-32: Smart Card Reader Testing 2

Page 34

ICECARE-10W Mobile Sales Assistant

4 Driver Installation

Chapter

Page 35

4.1 Available Software Drivers

NOTE:

The contents of the driver folder may vary throughout the life cycle of

the product and is subject to change without prior notice. Visit the IEI

website or contact technical support for the latest updates.

The following drivers can be installed on the system:

 Chipset driver

 Graphics driver

 Audio driver

 Bluetooth driver

ICECARE-10W Mobile Sales Assistant

 Wireless LAN driver

 RFID driver

Connect the Utility CD came with the ICECARE-10W Series to the system and follow the

installation instructions given below to install the drivers.

4.2 Intel® Chipset Driver

To install the chipset driver, please follow the steps below.

Step 1: Select 1.Chipset from the list of the driver CD shown in

3Figure 4-1.

Page 36

ICECARE-10W Mobile Sales Assistant

Figure 4-1: Chipset Driver Location

Step 2: Double click the setup file in the folder. The Intel® Chipset Dev i ce Software

welcome screen appears (

3Figure 4-2).

Figure 4-2: Intel® Chipset Device Software

Page 37

Step 3: Follow the step-by-step instruction of the installation wizard to install the

graphics driver.

4.3 Intel® Graphics Driver

To install the graphics driver, please follow the steps below.

ICECARE-10W Mobile Sales Assistant

Step 1: Select 2.VGA from the list of the driver CD shown in

473Figure 4-3.

Page 38

Figure 4-3: Graphics Driver Location

Step 2: Select the folder corresponding to the operating system.

Step 3: Double click the setup file in the folder. The Intel® Graphics Driver

InstallShield Wizard appears (

473Figure 4-4).

ICECARE-10W Mobile Sales Assistant

Figure 4-4: Intel® Graphics Driver InstallShield Wizard

Step 4: Follow the step-by-step instruction of the installation wizard to install the

graphics driver.

4.4 Audio Driver

To install the driver for the speaker and the microphone, please follow the steps below.

Step 1: Select 3.Audio from the list of the driver CD shown in

473Figure 4-5.

Page 39

ICECARE-10W Mobile Sales Assistant

Figure 4-5: Speaker and Microphone Driver Location

Step 2: Double click the setup file in the folder. The InstallShield Wizard screen

appears (

3Figure 4-6).

Page 40

ICECARE-10W Mobile Sales Assistant

Figure 4-6: Realtek HD Audio Driver InstallShield Wizard

Step 3: Follow the step-by-step instruction of the installation wizard to install the HD

Audio driver.

4.5 Bluetooth Driver

To install the Bluetooth driver, please follow the steps below.

Step 1: Select 5.Wireless LAN & Bluetooth from the list of the driver CD shown in

3Figure 4-7. Select the Bluetooth folder.

Page 41

ICECARE-10W Mobile Sales Assistant

Figure 4-7: Bluetooth Driver Location

Step 2: Double click the setup file in the folder. The InstallShield Wizard screen appears.

Page 42

ICECARE-10W Mobile Sales Assistant

Figure 4-8: Bluetooth Driver InstallShield Wizard

Step 3: Follow the step-by-step instruction of the installation wizard to install the

Bluetooth driver.

4.6 Wireless LAN Driver

To install the wireless LAN driver, please follow the steps below.

Step 1: Select 5.Wireless LAN & Bluetooth from the list of the driver CD shown in

573Figure 4-9. Select the Wireless folder.

Page 43

ICECARE-10W Mobile Sales Assistant

Figure 4-9: Wireless LAN Driver Location

Step 2: Double click the setup file in the folder. The InstallShield Wizard screen appears.

Page 44

ICECARE-10W Mobile Sales Assistant

Figure 4-10: Bluetooth Driver InstallShield Wizard

Step 3: Follow the step-by-step instruction of the installation wizard to install the

Wireless LAN driver.

4.7 RFID Driver

To install the RFID driver, please follow the steps below.

Step 1: Select 7.RFID from the list of the driver CD shown in

473Figure 4-11.

Page 45

ICECARE-10W Mobile Sales Assistant

Figure 4-11: RFID Driver Location

Step 2: Double click the setup file in the WIN7 Driver folder to install the RFID driver

473Figure 4-13).

(

Page 46

Figure 4-12: RFID Driver Folder

ICECARE-10W Mobile Sales Assistant

Step 3: Follow the step-by-step instruction of the installation wizard to install the RFID

driver.

Figure 4-13: RFID Driver Installation

Page 47

ICECARE-10W Mobile Sales Assistant

Chapter

5 BIOS Setup

Page 48

ICECARE-10W Mobile Sales Assistant

5.1 Introduction

The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to

certain system settings. This chapter outlines the options that can be changed.

NOTE:

Some of the BIOS options may vary throughout the life cycle of the

product and are subject to change without prior notice.

5.1.1 Starting Setup

The UEFI BIOS is activated when the computer is turned on. The setup program can be

activated in one of two ways.

1. Press the DELETE

2. Press the DELETE key when the “Press DELETE to enter SETUP” message

appears on the screen. 0.

If the message disappears before the DELETE key is pressed, restart the computer and

try again.

key as soon as the system is turned on or

5.1.2 Using Setup

Use the arrow keys to highlight items, press ENTER to select, use the PageUp and PageDown keys to change entries, press F1 for help and press E

keys are shown in.

Key Function

Up arrow Move to the item above

SC to quit. Navigation

Down arrow Move to the item below

Left arrow Move to the item on the left hand side

Right arrow Move to the item on the right hand side

Page 49

Key Function

+ Increase the numeric value or make changes

- Decrease the numeric value or make changes

Page up Move to the next page

Page down Move to the previous page

Esc Main Menu – Quit and do not save changes into CMOS

Status Page Setup Menu and Option Page Setup Menu --

Exit current page and return to Main Menu

F1 key General help, only for Status Page Setup Menu and Option

Page Setup Menu

F2 key Load previous values

F3 key Load optimized defaults

ICECARE-10W Mobile Sales Assistant

F4 key Save changes and Exit BIOS

Table 5-1: BIOS Navigation Keys

5.1.3 Getting Help

When F1 is pressed a small help window describing the appropriate keys to use and the possible selections for the highlighted item appears. To exit the Help Window press E the F1 key again.

5.1.4 BIOS Menu Bar

The menu bar on top of the BIOS screen has the following main items:

 Main – Changes the basic system configuration.

 Advanced – Changes the advanced system settings.

 Chipset – Changes the chipset settings.

 Boot – Changes the system boot configuration.

 Security – Sets User and Supervisor Passwords.

SC or

Page 50

 Save & Exit – Selects exit options and loads default settings

The following sections completely describe the configuration options found in the menu

items at the top of the BIOS screen and listed above.

ICECARE-10W Mobile Sales Assistant

5.2 Main

The Main BIOS menu (583BIOS Menu 1) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information.

Main Advanced Chipset Boot Security Save & Exit

BIOS Information BIOS Vendor American Megatrends Core Version 4.6.5.3 Compliency UEFI 2.3; PI 1.2 Project Version B263AR06.ROM Build Date 12/02/2013 13:48:19 iWDD Vendor IEI iWDD Version B2441024.bin

Processor Information Name SandyBridge Brand String Intel(R) Celeron(R) CPU Frequency 1400MHz Processor ID 206a7 Stepping D2 Number of Processors 1Core(s) / 1Thread(s) Microcode Revision 28 GT Info GT2 (800MHz)

IGFX VBIOS Version 2143 Memory RC Version 1.2.2.0 Total Memory 4096 MB (DDR3) Memory Frequency 1333 Mhz

PCH Information Name PantherPoint Stepping 04/C1 LAN PHY Revision N/A

ME FW Version 8.1.2.1318 ME Firmware SKU 1.5MB

SPI Clock Frequency DOFR Support Unsupported Read Status Clock Frequency 33 MHz Write Status Clock Frequency 33 MHz Fast Read Status Clock 33 MHz

System Date [Tue 12/11/2013] System Time [15:10:27]

Access Level Administrator

et the Time. Use Tab to switch between Time elements.

----------------------



: Select Screen

 : Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

BIOS Menu 1: Main

Page 51

 System Date [xx/xx/xx]

Use the System Date option to set the system date. Manually enter the day, month and year.

 System Time [xx:xx:xx]

Use the System Time option to set the system time. Manually enter the hours, minutes

and seconds.

5.3 Advanced

Use the Advanced menu (583BIOS Menu 2) to configure the CPU and peripheral devices

through the following sub-menus:

WARNING!

ICECARE-10W Mobile Sales Assistant

Setting the wrong values in the sections below may cause the system

to malfunction. Make sure that the settings made are compatible with

the hardware.

Main Advanced Chipset Boot Security Save & Exit

> ACPI Settings > RTC Wake Settings > Trusted Computing > CPU Configuration > SATA Configuration > Intel(R) Rapid Start Technology > USB Configuration > iWDD Serial Ports Configuration > H/M Monitor > Serial Port Console Redirection > iEi Feature

System ACPI Parameters

----------------------



 : Select Item Enter Select F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save ESC Exit

: Select Screen

Page 52

BIOS Menu 2: Advanced

ICECARE-10W Mobile Sales Assistant

5.3.1 ACPI Settings

The ACPI Settings menu (83BIOS Menu 3) configures the Advanced Configuration and

Power Interface (ACPI) options.

Advanced

ACPI Settings

ACPI Sleep State [S1 (CPU Stop Clock)]

elect the highest ACPI sleep state the system will enter, when the SUSPEND button is pressed.

----------------------



: Select Screen

 : Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

BIOS Menu 3: ACPI Configuration

 ACPI Sleep State [S1 (CPU Stop Clo ck)]

Use the ACPI Sleep State option to specify the sleep state the system enters when it is

not being used.



S1 (CPU Stop Clock)



S3 (Suspend to RAM)

DEFAULT

The system enters S1 (POS) sleep state. The

system appears off. The CPU is stopped; RAM is

refreshed; the system is running in a low power

mode.

The caches are flushed and the CPU is powered

off. Power to the RAM is maintained. The

computer returns slower to a working state, but

more power is saved.

Page 53

ICECARE-10W Mobile Sales Assistant

5.3.2 RTC Wake Settings

The RTC Wake Settings menu (3BIOS Menu 4) configures RTC wake event.

Advanced

Wake system with Fixed Time [Disabled]

nable or disable System

ake on alarm event. When enabled, System will wake on the dat::hr::min::sec specified

----------------------



: Select Screen

 : Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

BIOS Menu 4: RTC Wake Settings

 Wake System with Fixed Time [Disabled]

Use the Wake System with Fixed Time option to specify the time the system should be

roused from a suspended state.



Disabled DEFAULT

The real time clock (RTC) cannot generate a wake

event

Page 54

ICECARE-10W Mobile Sales Assistant



Enabled

If selected, the following appears with values that

can be selected:

*Wake up every day

*Wake up date

*Wake up hour

*Wake up minute

*Wake up second

After setting the alarm, the computer turns itself on

from a suspend state when the alarm goes off.

5.3.3 Trusted Computing

Use the Trusted Computing menu (BIOS Menu 5) to configure settings related to the

Trusted Computing Group (TCG) Trusted Platform Module (TPM).

Advanced

Configuration Security Device Support [Disable]

Current Status Information

NO Security Device Found

nables or Disables BIOS support for security device. O.S. will not show Security Device. TCG EFI protocol and INT1A interface will not be available.

----------------------



: Select Screen

 : Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

BIOS Menu 5: Trusted Computing

 Security Device Support [Disable]

Use the Security Device Support option to configure support for the TPM.

Page 55

ICECARE-10W Mobile Sales Assistant



Disable DEFAULT



Enable

TPM support is disabled.

TPM support is enabled.

5.3.4 CPU Configuration

Use the CPU Configuration menu (583BIOS Menu 6) to view detailed CPU specifications

and configure the CPU.

Advanced

CPU Configuration

Intel(R) Celeron(R) CPU 1007U @ 1.50GHz CPU Signature 206a7 Microcode Patch 28 Max CPU Speed 1400 MHz Min CPU Speed 800 MHz CPU Speed 1400 MHz Processor Cores 1 Intel HT Technology Not Supported Intel VT-x Technology Supported Intel SMX Technology Not Supported 64-bit Supported

L1 Data Cache 32 kB x 1 L1 Code Cache 32 kB x 1 L2 Cache 256 kB x 1 L3 Cache 1536 kB

Intel Virtualization Technology [Disabled]

When enabled, a VMM can utilize the additional hardware capabilities provided by Vanderpool Technology

----------------------



: Select Screen

 : Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

BIOS Menu 6: CPU Configuration

 Intel Virtualization Technology [Enabled]

Use the Intel Virtualization Technology to enable or disable the Intel® Hyper-Threading

Technology.



Disabled



Enabled DEFAULT

Page 56

Disables the Intel® Hyper-Threading Technology.

Enables the Intel® Hyper-Threading Technology.

ICECARE-10W Mobile Sales Assistant

5.3.5 SATA Configuration

Use the SATA Configuration menu (583BIOS Menu 7) to change and/or set the

configuration of the SATA devices installed in the system.

Advanced

SATA Controller(s) [Enabled] SATA Mode Selection [IDE]

mSATA(M_PCIE3) Port MRMAJ5A032GC2M (30.0GB)

Enable or disable SATA Device.

---------------------



: Select Screen

 : Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

BIOS Menu 7: SATA Configuration

 SATA Controller(s) [Enabled]

Use the SATA Controller(s) option to configure the serial ATA controller.



Enabled D



Disabled

 Configure SATA as [AHCI]

Use the Configure SATA as option to configure SATA devices as normal IDE devices.



IDE



AHCI DEFAULT

EFAULT

Disables the on-board SATA controller.

Enables the on-board SATA controller.

Configures SATA devices as normal IDE device.

Configures SATA devices as AHCI device.

Page 57

ICECARE-10W Mobile Sales Assistant

5.3.6 Intel(R) Rapid Start Technology

Use the Intel(R) Rapid Start Technology (BIOS Menu 8) menu to configure Intel® Rapid

Start Technology support.

Advanced

Intel(R) Rapid Start Technology [Disabled]

---------------------



: Select Screen

 : Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

BIOS Menu 8: Intel(R) Rapid Start Technology

Page 58

ICECARE-10W Mobile Sales Assistant

5.3.7 USB Configuration

Use the USB Configuration menu (583BIOS Menu 9) to read USB configuration information

and configure the USB settings.

Advanced

USB Configuration

USB Devices: 1 Keyboard

Legacy USB Support [Enabled]

Mass Storage Devices:

Generic STORAGE DEVICE 0207 [Auto]

Enables Legacy USB support. AUTO option

isables legacy support if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications.

---------------------



: Select Screen

 : Select Item Enter Select F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save ESC Exit

BIOS Menu 9: USB Configuration

 USB Devices

The USB Devices Enabled field lists the USB devices that are enabled on the system

 Legacy USB Support [Enabled]

Use the Legacy USB Support BIOS option to enable USB mouse and USB keyboard

support. Normally if this option is not enabled, any attached USB mouse or USB keyboard

does not become available until a USB compatible operating system is fully booted with all

USB drivers loaded. When this option is enabled, any attached USB mouse or USB

keyboard can control the system even when there is no USB driver loaded onto the

system.



Enabled DEFAULT

Legacy USB support enabled

Page 59

ICECARE-10W Mobile Sales Assistant



Disabled



Auto

Legacy USB support disabled

Legacy USB support disabled if no USB devices are

connected

5.3.8 iWDD Serial Ports Configuration

Use the iWDD Serial Ports Configuration menu (4BIOS Menu 10) to set or change the

configurations for the serial ports.

Advanced

iWDD Serial Ports Configuration

Super IO Chip iWDD

> Serial Port 1 Configuration > Serial Port 2 Configuration

Serial Port 1 can be used only when you are using DOCKING board.

---------------------



: Select Screen

 : Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Page 60

BIOS Menu 10: iWDD Serial Ports Configuration

ICECARE-10W Mobile Sales Assistant

5.3.8.1 Serial Port 1 Configuration

Use the Serial Port n Configuration menu (4BIOS Menu 11) to configure the serial port 1

on the docking station.

Advanced

Serial Port 1 Configuration

Serial Port [Enabled]

Device Settings IO=3F8h; IRQ=4;

Change Settings [Auto]

Enable or Disable Serial Port (COM)

---------------------



: Select Screen

 : Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

BIOS Menu 11: Serial Port 1 Configuration Menu

 Serial Port [Enabled]

Use the Serial Port option to enable or disable the serial port.



Disabled



Enabled DEFAULT

 Change Settings [Auto]

Use the Change Settings option to change the serial port IO port address and interrupt

address.



Auto DEFAULT



IO=3F8h;

Disable the serial port

Enable the serial port

The serial port IO port address and interrupt address

are automatically detected.

Serial Port I/O port address is 3F8h and the interrupt

IRQ=4

address is IRQ4

Page 61

ICECARE-10W Mobile Sales Assistant



IO=3F8h; IRQ=3, 4

IO=2F8h; IRQ=3, 4

IO=3E8h; IRQ=3, 4

IO=2E8h; IRQ=3, 4

5.3.8.2 Serial Port 2 Configuration

 Serial Port [Enabled]

Use the Serial Port option to enable or disable the serial port.



Disabled

Serial Port I/O port address is 3F8h and the interrupt

address is IRQ3, 4

Serial Port I/O port address is 2F8h and the interrupt

address is IRQ3, 4

Serial Port I/O port address is 3E8h and the interrupt

address is IRQ3, 4

Serial Port I/O port address is 2E8h and the interrupt

address is IRQ3, 4

Disable the serial port



Enabled DEFAULT

 Change Settings [Auto]

Use the Change Settings option to change the serial port IO port address and interrupt

address.



Auto DEFAULT



IO=2F8h; IRQ=3

IO=3F8h; IRQ=3, 4

IO=2F8h; IRQ=3, 4

Enable the serial port

The serial port IO port address and interrupt address

are automatically detected.

Serial Port I/O port address is 2F8h and the interrupt

address is IRQ3

Serial Port I/O port address is 3F8h and the interrupt

address is IRQ3, 4

Serial Port I/O port address is 2F8h and the interrupt

address is IRQ3, 4

Page 62

ICECARE-10W Mobile Sales Assistant



IO=3E8h; IRQ=3, 4

IO=2E8h; IRQ=3, 4

Serial Port I/O port address is 3E8h and the interrupt

address is IRQ3, 4

Serial Port I/O port address is 2E8h and the interrupt

address is IRQ3, 4

5.3.9 H/W Monitor

The H/W Monitor menu (584BIOS Menu 12) shows the operating temperature.

Advanced

H/W Monitor CPU Temperature : +59 C FAN Speed N/A

---------------------



: Select Screen

 : Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

BIOS Menu 12: Hardware Health Configuration

5.3.10 Serial Port Console Redirection

The Serial Port Console Redirection menu (4BIOS Menu 13) allows the console

redirection options to be configured. Console redirection allows users to maintain a

system remotely by re-directing keyboard input and text output through the serial port.

Page 63

Advanced

COM1

Console Redirection [Disabled]

> Console Redirection Settings

BIOS Menu 13: Serial Port Console Redirection

 Console Redirection [Disabled]

ICECARE-10W Mobile Sales Assistant

Console Redirection Enable or Disable

---------------------



: Select Screen

 : Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Use Console Redirection option to enable or disable the console redirection function.



Disabled DEFAULT



Enabled

Disabled the console redirection function

Enabled the console redirection function

5.3.11 IEI Feature

Use the IEI Feature menu (84BIOS Menu 14) to configure One Key Recovery function.

Page 64

ICECARE-10W Mobile Sales Assistant

Advanced

iEi Feature

Auto Recovery Function [Disabled]

Auto Recovery Function Reboot and recover system automatically within 10 min, when OS

rashes. Please install Auto Recovery API

ervice before enabling this function

---------------------



: Select Screen

 : Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

BIOS Menu 14: IEI Feature

 Auto Recovery Function [Disabled]

Use the Auto Recovery Function BIOS option to enable or disable the auto recovery

function of the IEI One Key Recovery.



Disabled DEFAULT



Enabled

5.4 Chipset

Use the Chipset menu (584BIOS Menu 15) to access the PCH-IO and System Agent (SA)

configuration menus

WARNING!

Auto recovery function disabled

Auto recovery function enabled

Setting the wrong values for the Chipset BIOS selections in the Chipset

BIOS menu may cause the system to malfunction.

Page 65

ICECARE-10W Mobile Sales Assistant

Main Advanced Chipset Boot Security Save & Exit

> PCH-IO Configuration > System Agent (SA) Configuration

BIOS Menu 15: Chipset

North Bridge Parameters

---------------------



 : Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

: Select Screen

5.4.1 PCH-IO Configuration

Use the PCH-IO Configuration menu (584BIOS Menu 16) to configure the Southbridge

chipset.

Chipset

PCH-IO Configuration

M_PCIE1 Port Speed [Auto] M_PCIE2 Port Speed [Auto] Azalia [Enabled] Azalia Internal HDMI Codec [Enabled]

Barcode Function [Enabled] RFID Function [Enabled] Micro-SD Function [Enabled] 3G Radio Function [Enabled] WIFI Radio Function [Enabled] Bluetooth Function [Enabled]

Select Mini PCIE port (M_PCIE1) speed.

---------------------



: Select Screen

 : Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Page 66

BIOS Menu 16: PCH-IO Configuration

ICECARE-10W Mobile Sales Assistant

 M_PCIE# Port Speed [Auto]

Use the M_PCIE# Port Speed option to select the support type of the PCIe Mini card slot.

The following options are available:

 Auto Default

 Gen1

 Gen2

 Azalia [Enabled]

Use the Azalia option to enable or disable the High Definition Audio controller.



Disabled



Enabled DEFAULT

 Azalia internal HDMI codec [Enabled]

Use the Azalia internal HDMI codec option to enable or disable the internal HDMI codec

for High Definition Audio.



Disabled



Enabled DEFAULT

 Barcode Function [Enabled]

Use the Barcode Function option to enable or disable the optional barcode function. Not

The onboard High Definition Audio controller is disabled

The onboard High Definition Audio controller is detected

automatically and enabled

Disables the internal HDMI codec for High Definition

Audio

Enables the internal HDMI codec for High Definition

Audio

every model is preinstalled with a Barcode module. Make sure the Bluetooth function is

supported in the system before enable this BIOS option.



Disabled



Enabled DEFAULT

Barcode function disabled

Barcode function enabled

Page 67

 RFID Function [Enabled]

Use the RFID Function option to enable or disable the RFID function.

ICECARE-10W Mobile Sales Assistant



Disabled



Enabled DEFAULT

 Micro-SD Function [Enabled]

Use the Micro-SD Function option to enable or disable the microSD card.



Disabled



Enabled DEFAULT

 3G Radio Function [Enabled]

Use the 3G Radio Function option to enable or disable the 3G function. Not every model

is preinstalled with a 3G module. Make sure the 3G connection is supported in the system

before enable this BIOS option.



Disabled

RFID function disabled

RFID function enabled

microSD card disabled

microSD card enabled

3G function disabled



Enabled DEFAULT

 WIFI Radio Function [Enabled]

Use the WIFI Radio Function option to enable or disable the Wi-Fi function.



Disabled



Enabled DEFAULT

 Bluetooth Function [Enabled]

Use the Bluetooth Function option to enable or disable the bluetooth function.



Disabled



Enabled DEFAULT

3G function enabled

Wi-Fi function disabled

Wi-Fi function enabled

Bluetooth function disabled

Bluetooth function enabled

Page 68

ICECARE-10W Mobile Sales Assistant

5.4.2 System Agent (SA) Configuration

Use the System Agent (SA) Configuration menu (84BIOS Menu 17) to configure the

System Agent (SA) parameters.

Chipset

> Graphics Configuration > Memory Configuration

Config Intel IGD Settings.

---------------------



: Select Screen

 : Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

BIOS Menu 17: System Agent (SA) Configuration

5.4.2.1 Graphics Configuration

Use the Graphics Configuration (BIOS Menu 18) menu to configure the video device

connected to the system.

Page 69

Chipset

Graphics Configuration

Primary Display [Auto] DVMT Pre-Allocated [256M] DVMT Total Gfx Mem [MAX]

Primary IGFX Boot Display [VBIOS Default]

Current LCD Panel Type 12800x800 24BIT

BIOS Menu 18: Graphics Configuration

ICECARE-10W Mobile Sales Assistant

Select which of IGFX/PEG/PCI Graphics

evice should be Primary Display Or select SG for Switchable Gfx.

----------------------



: Select Screen

 : Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

 Primary Display [Auto]

Use the Primary Display option to select the primary graphics controller the system uses.

The following options are available:

 Auto Default

 IGFX

 PEG

 DVMT Pre-Allocated [256M]

Use the DVMT Pre-Allocated option to set the amount of system memory allocated to the

integrated graphics processor when the system boots. The system memory allocated can

then only be used as graphics memory, and is no longer available to applications or the

operating system. Configuration options are listed below:

 32M

 64M

 128M  256M Default

 512M

Page 70

ICECARE-10W Mobile Sales Assistant

 DVMT Total Gfx Mem [MAX]

Use the DVMT Total Gfx Mem option to select DVMT5.0 total graphic memory size used

by the internal graphic device. The following options are available:

 128M

 256M  MAX Default

 Primary IGFX Boot Display [VBIOS Default]

Use the Primary IGFX Boot Display option to select the display device used by the

system when it boots. Configuration options are listed below.

 VBIOS Default

 CRT

 LVD S  HDMI

DEFAULT

5.4.2.2 Memory Configuration

Use the Memory Configuration submenu (BIOS Menu 19) to view memory information.

Chipset

Memory Information

Memory Frequency 1333 MHz Total Memory 4096 MB (DDR3)

On Board Memory 4096 MB (DDR3) Memory Slot Not Present

---------------------



: Select Screen

 : Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

BIOS Menu 19: Memory Configuration

Page 71

ICECARE-10W Mobile Sales Assistant

5.5 Boot

Use the Boot menu (584BIOS Menu 20) to configure system boot options.

Main Advanced Chipset Boot Security Save & Exit

Boot Configuration

Boot NumLock State [On] Quiet Boot [Enabled] Option ROM Messages [Force BIOS] UEFI Boot [Disabled]

Boot Option Priorities

Boot Option #1 [SATA PM: MRMAJ5A03…]

Hard Drive BBS Priorities

Enables/Disables Quiet Boot option

---------------------



 : Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

: Select Screen

BIOS Menu 20: Boot

 Bootup NumLock State [On]

Use the Bootup NumLock State BIOS option to specify if the number lock setting must

be modified during boot up.



On DEFAULT



Off

Allows the Number Lock on the keyboard to be

enabled automatically when the computer system

boots up. This allows the immediate use of the

10-key numeric keypad located on the right side of

the keyboard. To confirm this, the Number Lock LED

light on the keyboard is lit.

Does not enable the keyboard Number Lock

automatically. To use the 10-keys on the keyboard,

press the Number Lock key located on the upper

left-hand corner of the 10-key pad. The Number

Page 72

Lock LED on the keyboard lights up when the

Number Lock is engaged.

ICECARE-10W Mobile Sales Assistant

 Quiet Boot [Enabled]

Use the Quiet Boot BIOS option to select the screen display when the system boots.



Disabled



Enabled DEFAULT

 Option ROM Messages [Force BIOS]

Use the Option ROM Messages option to set the Option ROM display mode.



Force BIOS



Keep Current

 UEFI Boot [Disabled]

Use the UEFI Boot option to enable or disable to boot from the UEFI devices.



Enabled

DEFAULT

Normal POST messages displayed

OEM Logo displayed instead of POST messages

Sets display mode to force BIOS.

Sets display mode to current.

Boot from UEFI devices is enabled.



Disabled DEFAULT

 Boot Option #1 [SATA PM: MRMAJ5A03…]

Use the Boot Option #1 option to specify the boot priority from the available devices.

 Hard Drive BBS Priorities

Use the Hard Drive BBS Priorities option to set the order of the legacy devices in this

group.

Boot from UEFI devices is disabled.

Page 73

ICECARE-10W Mobile Sales Assistant

5.6 Security

Use the Security menu (584BIOS Menu 21) to set system and user passwords.

Main Advanced Chipset Boot Security Save & Exit

Password Description

If ONLY the Administrator’s password is set, then this only limits access to Setup and is only asked for when entering Setup If ONLY the User’s password is set, then this is a power on password and must be entered to boot or enter Setup. In Setup the User will have Administrator rights.

Administrator Password User Password

HDD Security Configuration:

HDD0:MRMAJ5A032GC

Password

---------------------



 : Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

et Setup Administrator

: Select Screen

BIOS Menu 21: Security

 Administrator Password

Use the Administrator Password to set or change a administrator password.

 User Password

Use the User Password to set or change a user password.

5.7 Exit

Use the Exit menu (584BIOS Menu 22) to load default BIOS values, optimal failsafe values

and to save configuration changes.

Page 74

ICECARE-10W Mobile Sales Assistant

Main Advanced Chipset Boot Security Save & Exit

Save Changes and Reset Discard Changes and Reset

Restore Defaults Save as User Defaults Restore User Defaults

BIOS Menu 22: Exit

Exit system setup after saving the changes.

---------------------



 : Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

: Select Screen

 Save Changes and Reset

Use the Save Changes and Reset option to save the changes made to the BIOS options

and to exit the BIOS configuration setup program.

 Discard Changes and Reset

Use the Discard Changes and Reset option to exit the system without saving the

changes made to the BIOS configuration setup program.

 Restore Defaults

Use the Restore Defaults option to load the optimal default values for each of the parameters on the Setup menus. F3 key can be used for this operation.

 Save as User Defaults

Use the Save as User Defaults option to save the changes done so far as user defaults.

 Restore User Defaults

Use the Restore User Defaults option to restore the user defaults to all the setup options.

Page 75

ICECARE-10W Mobile Sales Assistant

Appendix

A Safety Precautions

Page 76

ICECARE-10W Mobile Sales Assistant

WARNING:

The precautions outlined in this chapter should be strictly followed.

Failure to follow these precautions may result in permanent damage to

the ICECARE-10W Series.

A.1 Safety Precautions

Please follow the safety precautions outlined in the sections that follow:

A.1.1 General Safety Precautions

Please ensure the following safety precautions are adhered to at all times.

 Follow the electrostatic precautions outlined below whenever the

ICECARE-10W Series is opened.

 Make sure the power is turned off and the power cord is disco nnected

whenever the ICECARE-10W Series is being installed, moved or modified.

 Do not apply voltage levels that exceed the specified voltage range.

Doing so may cause fire and/or an electrical shock.

 Electric shocks can occur if the ICECARE-10W Series chassis is opened

when the ICECARE-10W Series is running.

 Do not drop or insert any objects into the ventilation openings of the

ICECARE-10W Series.

 If considerable amounts of dust, water , or fluids enter the ICECARE-10W

Series, turn off the power supply immediately, unplug the power cord, and

contact the ICECARE-10W Series vendor.

 DO NOT:

o Drop the ICECARE-10W Series against a hard surface. o Strike or exert excessive force onto the LCD panel. o Touch any of the LCD panels with a sharp object o In a site where the ambient temperature exceeds the rated temperature

Page 77

A.1.2 Anti-static Precautions

WARNING:

Failure to take ESD precautions during the installation of the

ICECARE-10W Series may result in permanent damage to the

ICECARE-10W Series and severe injury to the user.

Electrostatic discharge (ESD) can cause serious damage to electronic components,

including the ICECARE-10W Series. Dry climates are especially susceptible to ESD. It is

therefore critical that whenever the ICECARE-10W Series is opened and any of the

electrical components are handled, the following anti-static precautions are strictly

adhered to.

ICECARE-10W Mobile Sales Assistant

 Wear an anti-static wristband: Wearing a simple anti-static wristband can

help to prevent ESD from damaging any electrical component.

 Self-grounding: Before handling any electrical component, touch any

grounded conducting material. During the time the electrical component is

handled, frequently touch any conducting materials that are connected to the

ground.

 Use an anti-static pad: When configuring or working with an electrical

component, place it on an anti-static pad. This reduces the possibility of ESD

damage.

 Only handle the edges of the electrical component: When handling the

electrical component, hold the electrical component by its edges.

Page 78

ICECARE-10W Mobile Sales Assistant

A.1.3 Product Disposal

CAUTION:

Risk of explosion if battery is replaced by and incorrect type. Only

certified engineers should replace the on-board battery.

Dispose of used batteries according to instructions and local

regulations.

 Outside the European Union - If you wish to dispose of used electrical and

electronic products outside the European Union, please contact your local

authority so as to comply with the correct disposal method.

 Within the European Union:

EU-wide legislation, as implemented in each Member State, requires that

waste electrical and electronic products carrying the mark (left) must be

disposed of separately from normal household waste. This includes

monitors and electrical accessories, such as signal cables or power cords.

When you need to dispose of your display products, please follow the

guidance of your local authority, or ask the shop where you purchased the product. The

mark on electrical and electronic products only applies to the current European Union

Member States.

Please follow the national guidelines for electrical and electronic product disposal.

A.2 Maintenance and Cleaning Precautions

When maintaining or cleaning the ICECARE-10W Series, please follow the guidelines

below.

A.2.1 Maintenance and Cleaning

Prior to cleaning any part or component of the ICECARE-10W Series, please read the

details below.

Page 79

 Except for the LCD panel, never spray or squirt liquids directly onto any other

components. To clean the LCD panel, gently wipe it with a piece of soft dry

cloth or a slightly moistened cloth.

 The interior of the ICECARE-10W Series does not require cleaning. Keep

fluids away from the ICECARE-10W Series interior.

 Be cautious of all small removable components when vacuuming the

ICECARE-10W Series.

 Turn the ICECARE-10W Series off before cleaning the ICECARE-10W

Series.

 Never drop any objects or liquids through the openings of the ICECARE-10W

Series.

 Be cautious of any possible allergic reactions to solvents or chemicals used

when cleaning the ICECARE-10W Series.

 Avoid eating, drinking and smoking within vicinity of the ICECARE-10W

ICECARE-10W Mobile Sales Assistant

Series.

A.2.2 Cleaning Tools

Some components in the ICECARE-10W Series may only be cleaned using a product

specifically designed for the purpose. In such case, the product will be explicitly mentioned

in the cleaning tips. Below is a list of items to use when cleaning the ICECARE-10W

Series.

 Cloth – Although paper towels or tissues can be used, a soft, clean piece of

cloth is recommended when cleaning the ICECARE-10W Series.

 Water or rubbing alcohol – A cloth moistened with water or rubbing alcohol

can be used to clean the ICECARE-10W Series.

 Using solvents – The use of solvents is not recommended when cleaning the

ICECARE-10W Series as they may damage the plastic parts.

 Vacuum cleaner – Using a vacuum specifically designed for computers is

one of the best methods of cleaning the ICECARE-10W Series. Dust and dirt

can restrict the airflow in the ICECARE-10W Series and cause its circuitry to

Page 80

corrode.

 Cotton swabs - Cotton swaps moistened with rubbing alcohol or water are

excellent tools for wiping hard to reach areas.

ICECARE-10W Mobile Sales Assistant

 Foam swabs - Whenever possible, it is best to use lint free swabs such as

foam swabs for cleaning.

Page 81

ICECARE-10W Mobile Sales Assistant

Appendix

B BIOS Options

Page 82

ICECARE-10W Mobile Sales Assistant

Below is a list of BIOS configuration options in the BIOS chapter.

System Date [xx/xx/xx]........................................................................................................52

　 System Time [xx:xx:xx].......................................................................................................52

　 ACPI Sleep State [S1 (CPU Stop Clock)] ...........................................................................53

　 Wake System with Fixed Time [Disabled] .........................................................................54

　 Security Device Support [Disable].....................................................................................55

　 Intel Virtualization Technology [Enabled] .........................................................................56

　 SATA Controller(s) [Enabled] .............................................................................................57

　 Configure SATA as [AHCI]..................................................................................................57

　 USB Devices.........................................................................................................................59

　 Legacy USB Support [Enabled]..........................................................................................59

　 Serial Port [Enabled]............................................................................................................61

　 Change Settings [Auto].......................................................................................................61

　 Serial Port [Enabled]............................................................................................................62

　 Change Settings [Auto].......................................................................................................62

　 Console Redirection [Disabled] .........................................................................................64

　 Auto Recovery Function [Disabled]...................................................................................65

　 M_PCIE# Port Speed [Auto]................................................................................................67

　 Azalia [Enabled] ...................................................................................................................67

　 Azalia internal HDMI codec [Enabled] ...............................................................................67

　 Barcode Function [Enabled]...............................................................................................67

　 RFID Function [Enabled].....................................................................................................68

　 Micro-SD Function [Enabled]..............................................................................................68

　 3G Radio Function [Enabled]..............................................................................................68

　 WIFI Radio Function [Enabled]...........................................................................................68

　 Bluetooth Function [Enabled].............................................................................................68

　 Primary Display [Auto] ........................................................................................................70

　 DVMT Pre-Allocated [256M] ................................................................................................70

　 DVMT Total Gfx Mem [MAX]................................................................................................71

　 Primary IGFX Boot Display [VBIOS Default] .....................................................................71

　 Bootup NumLock State [On]...............................................................................................72

　 Quiet Boot [Enabled] ...........................................................................................................73

　 Option ROM Messages [Force BIOS].................................................................................73

　 UEFI Boot [Disabled] ...........................................................................................................73

Page 83

　 Boot Option #1 [SATA PM: MRMAJ5A03…]......................................................................73

　 Hard Drive BBS Priorities....................................................................................................73

　 Administrator Password .....................................................................................................74

　 User Password.....................................................................................................................74

　 Save Changes and Reset ....................................................................................................75

　 Discard Changes and Reset ...............................................................................................75

　 Restore Defaults ..................................................................................................................75

　 Save as User Defaults .........................................................................................................75

　 Restore User Defaults .........................................................................................................75

ICECARE-10W Mobile Sales Assistant

Page 84

ICECARE-10W Mobile Sales Assistant

C Terminology

Appendix

Page 85

ICECARE-10W Mobile Sales Assistant

AC ’97

ACPI

AHCI

ATA

ARMD

ASKIR

BIOS

Audio Codec 97 (AC’97) refers to a codec standard developed by Intel®

in 1997.

Advanced Configuration and Power Interface (ACPI) is an OS-directed

configuration, power management, and thermal management interface.

Advanced Host Controller Interface (AHCI) is a SATA Host controller

The Advanced Technology Attachment (ATA) interface connects storage

devices including hard disks and CD-ROM drives to a computer.

An ATAPI Removable Media Device (ARMD) is any ATAPI device that

supports removable media, besides CD and DVD drives.

Amplitude Shift Keyed Infrared (ASKIR) is a form of modulation that

represents a digital signal by varying the amplitude (“volume”) of the

signal. A low amplitude signal represents a binary 0, while a high

amplitude signal represents a binary 1.

The Basic Input/Output System (BIOS) is firmware that is first run when

CODEC

CompactFlash®

CMOS

COM

DAC

DDR

the computer is turned on and can be configured by the end user

The Compressor-Decompressor (CODEC) encodes and decodes digital

audio data on the system.

CompactFlash® is a solid-state storage device. CompactFlash® devices

use flash memory in a standard size enclosure. Type II is thicker than

Type I, but a Type II slot can support both types.

Complimentary metal-oxide-conductor is an integrated circuit used in

chips like static RAM and microprocessors.

COM refers to serial ports. Serial ports offer serial communication to

expansion devices. The serial port on a personal computer is usually a

male DB-9 connector.

The Digital-to-Analog Converter (DAC) converts digital signals to analog

signals.

Double Data Rate refers to a data bus transferring data on both the rising

and falling edges of the clock signal.

Page 86

ICECARE-10W Mobile Sales Assistant

DMA

DIMM

DIO

EHCI

EIDE

EIST

Direct Memory Access (DMA) enables some peripheral devices to

bypass the system processor and communicate directly with the system

memory.

Dual Inline Memory Modules are a type of RAM that offer a 64-bit data

bus and have separate electrical contacts on each side of the module.

The digital inputs and digital outputs are general control signals that

control the on/off circuit of external devices or TTL devices. Data can be

read or written to the selected address to enable the DIO functions.

The Enhanced Host Controller Interface (EHCI) specification is a

Enhanced IDE (EIDE) is a newer IDE interface standard that has data

transfer rates between 4.0 MBps and 16.6 MBps.

Enhanced Intel® SpeedStep Technology (EIST) allows users to modify

the power consumption levels and processor performance through

application software. The application software changes the bus-to-core

FSB

GbE

GPIO HDD

ICH IrDA

L1 Cache

L2 Cache

frequency ratio and the processor core voltage.

The Front Side Bus (FSB) is the bi-directional communication channel

between the processor and the Northbridge chipset.

Gigabit Ethernet (GbE) is an Ethernet version that transfers data at 1.0

Gbps and complies with the

231IEEE 802.3-2005 standard.

General purpose input

Hard disk drive (HDD) is a type of magnetic, non-volatile computer

storage device that stores digitally encoded data.

The Input/Ouput Control Hub (ICH) is an Intel® Southbridge chipset.

Infrared Data Association (IrDA) specify infrared data transmission

protocols used to enable electronic devices to wirelessly communicate

with each other.

The Level 1 Cache (L1 Cache) is a small memory cache built into the

system processor.

The Level 2 Cache (L2 Cache) is an external processor memory cache.

Page 87

ICECARE-10W Mobile Sales Assistant

LCD

LVDS

POST

RAM

SATA

S.M.A.R.T

Liquid crystal display (LCD) is a flat, low-power display device that

consists of two polarizing plates with a liquid crystal panel in between.

Low-voltage differential signaling (LVDS) is a dual-wire, high-speed

differential electrical signaling system commonly used to connect LCD

displays to a computer.

The Power-on Self Test (POST) is the pre-boot actions the system

performs when the system is turned-on.

Random Access Memory (RAM) is volatile memory that loses data when

power is lost. RAM has very fast data transfer rates compared to other

storage like hard drives.

Serial ATA (SATA) is a serial communications bus designed for data

transfers between storage devices and the computer chipsets. The SATA

bus has transfer speeds up to 1.5 Gbps and the SATA II bus has data

transfer speeds of up to 3.0 Gbps.

Self Monitoring Analysis and Reporting Technology (S.M.A.R.T) refers to

UART

UHCI

USB

VGA

automatic status checking technology implemented on hard disk drives.

Universal Asynchronous Receiver-transmitter (UART) is responsible for

asynchronous communications on the system and manages the system’s

serial communication (COM) ports.

The Universal Host Controller Interface (UHCI) specification is a

The Universal Serial Bus (USB) is an external bus standard for

interfacing devices. USB 1.1 supports 12Mbps data transfer rates and

USB 2.0 supports 480Mbps data transfer rates.

The Video Graphics Array (VGA) is a graphics display system developed

by IBM.

Page 88

IEI Technology ICECARE-10W, ICECARE-10W-CE-R10, ICECARE-10W-CE-ET-R10, ICECARE-10W-17-R10, ICECARE-10W-17-ET-R10 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Revision

Copyright

Table of Contents

List of Figures

List of Tables

BIOS Menus

1 Introduction

1.1 Overview

1.2 Features

1.3 Model Variations

1.4 Front Panel

1.4.1 Status Indicators

1.5 Rear Panel

1.6 Side Panels

1.7 Top Panel

1.8 Technical Specifications

1.9 Dimensions

2 Unpacking

2.1 Unpack the System

2.2 Packing List

3 Hardware Installation

3.1 Installation Considerations

3.2 Charge the Sytem

3.3 Power-up the System

3.4 Using RFID Reader

3.5 Using Barcode Scanner

3.5.1 Barcode Setting

3.6 Using Magnetic Stripe Reader

3.7 Testing Smart Card Reader

4 Driver Installation

4.1 Available Software Drivers

4.2 Intel® Chipset Driver

4.3 Intel® Graphics Driver

4.4 Audio Driver

4.5 Bluetooth Driver

4.6 Wireless LAN Driver

4.7 RFID Driver

5 BIOS Setup

5.1 Introduction

5.1.1 Starting Setup

5.1.2 Using Setup

5.1.3 Getting Help

5.1.4 BIOS Menu Bar

5.2 Main

5.3 Advanced

5.3.1 ACPI Settings

5.3.2 RTC Wake Settings

5.3.3 Trusted Computing

5.3.4 CPU Configuration

5.3.5 SATA Configuration

5.3.6 Intel(R) Rapid Start Technology

5.3.7 USB Configuration

5.3.8 iWDD Serial Ports Configuration

5.3.8.1 Serial Port 1 Configuration

5.3.8.2 Serial Port 2 Configuration

5.3.9 H/W Monitor

5.3.10 Serial Port Console Redirection

5.3.11 IEI Feature

5.4 Chipset

5.4.1 PCH-IO Configuration

5.4.2 System Agent (SA) Configuration

5.4.2.1 Graphics Configuration

5.4.2.2 Memory Configuration

5.5 Boot

5.6 Security

5.7 Exit

A Safety Precautions

A.1 Safety Precautions

A.1.1 General Safety Precautions

A.1.2 Anti-static Precautions

A.1.3 Product Disposal

A.2 Maintenance and Cleaning Precautions

A.2.1 Maintenance and Cleaning

A.2.2 Cleaning Tools

B BIOS Options

C Terminology
