ICE-BT-T6 COM Express Module
MODEL:
ICE-BT-T6
COM Express R2.1 Module (Type 6),
22nm Intel® Atom™ or Celeron® Processor
2 GB DDR3, EEPROM and RoHS Compliant
User Manual
Rev. 1.00 – September 23, 2014
Page i
ICE-BT-T6 COM Express Module
Revision
Date Version Changes
September 23, 2014
1.00 Initial release
Page ii
ICE-BT-T6 COM Express Module
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
Copyright
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.
Page iii
ICE-BT-T6 COM Express Module
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 INTRODUCTION........................................................................................................... 2
1.2 MODEL VARIATIONS ................................................................................................... 3
1.3 FEATURES................................................................................................................... 3
1.4 BOARD OVERVIEW..................................................................................................... 4
1.5 DIMENSIONS............................................................................................................... 5
1.6 DATA FLOW................................................................................................................6
1.7 TECHNICAL SPECIFICATIONS ...................................................................................... 7
2 PACKING LIST.............................................................................................................9
2.1 ANTI-STATIC PRECAUTIONS...................................................................................... 10
2.2 UNPACKING PRECAUTIONS....................................................................................... 10
2.3 PACKING LIST............................................................................................................11
2.4 OPTIONAL ITEMS...................................................................................................... 12
3 CONNECTORS ........................................................................................................... 13
3.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 14
3.1.1 ICE-BT-T6 Layout............................................................................................ 14
3.1.2 Peripheral Interface Connectors ..................................................................... 15
INTERNAL PERIPHERAL CONNECTORS...................................................................... 16
3.2
3.2.1 COM Express Connector AB........................................................................... 16
3.2.2 COM Express Connector CD........................................................................... 20
3.2.3 SO-DIMM Connectors..................................................................................... 24
4 INSTALLATION ......................................................................................................... 26
4.1
ANTI-STATIC PRECAUTIONS...................................................................................... 27
4.2 INSTALLATION CONSIDERATIONS.............................................................................. 27
4.3 SO-DIMM INSTALLATION ....................................................................................... 29
4.4 JUMPER SETTINGS ..................................................................................................... 30
4.4.1 LVDS Panel Type Selection.............................................................................. 30
4.5 MOUNTING ICE-BT-T6 TO BASEBOARD..................................................................... 31
Page iv
ICE-BT-T6 COM Express Module
5 BIOS.............................................................................................................................. 33
INTRODUCTION......................................................................................................... 34
5.1
5.1.1 Starting Setup................................................................................................... 34
5.1.2 Using Setup...................................................................................................... 34
5.1.3 Getting Help..................................................................................................... 35
5.1.4 Unable to Reboot after Configuration Changes.............................................. 35
5.1.5 BIOS Menu Bar................................................................................................ 35
5.2 MAIN........................................................................................................................ 36
5.3 ADVANCED ............................................................................................................... 37
5.3.1 ACPI Settings................................................................................................... 38
5.3.2 Super IO Configuration ................................................................................... 39
5.3.2.1 Serial Port n Configuration....................................................................... 39
5.3.3 Hardware Monitor ........................................................................................... 42
5.3.3.1 Smart Fan Function................................................................................... 43
5.3.4 IT8518 Super IO Configuration....................................................................... 44
5.3.4.1 Serial Port n Configuration....................................................................... 44
5.3.5 RTC Wake Settings........................................................................................... 48
5.3.6 Serial Port Console Redirection...................................................................... 49
5.3.7 CPU Configuration.......................................................................................... 52
5.3.8 Thermal Configuration .................................................................................... 54
5.3.9 IDE Configuration........................................................................................... 56
5.3.10 T rusted Com
puting......................................................................................... 58
5.3.11 USB Configuration......................................................................................... 59
CHIPSET ................................................................................................................... 60
5.4
5.4.1 North Bridge .................................................................................................... 61
5.4.1.1 Intel IGD Configuration............................................................................ 61
5.4.2 South Bridge Configuration............................................................................. 63
5.4.2.1 Azalia HD Audio....................................................................................... 64
5.4.2.2 PCI Express Configuration....................................................................... 65
5.5 SECURITY................................................................................................................. 66
5.6 BOOT........................................................................................................................ 67
5.7 SAVE & EXIT............................................................................................................ 69
6 SOFTWARE DRIVERS.............................................................................................. 71
6.1 AVAILABLE SOFTWARE DRIVERS .............................................................................. 72
Page v
ST ARTING THE DRIVER PROGRAM ............................................................................ 72
6.2
ICE-BT-T6 COM Express Module
6.3 CHIPSET DRIVER INSTALLATION............................................................................... 74
6.4 GRAPHICS DRIVER INSTALLATION............................................................................ 77
6.5 LAN DRIVER INSTALLATION.................................................................................... 80
A BIOS OPTIONS .......................................................................................................... 85
B TERMINOLOGY........................................................................................................ 88
C DIGITAL I/O INTERFACE....................................................................................... 92
C.1 INTRODUCTION........................................................................................................ 93
C.2 ASSEMBLY LANGUAGE SAMPLE 1............................................................................ 94
C.3
ASSEMBLY LANGUAGE SAMPLE 2............................................................................ 94
D WA TCHDOG TIMER ................................................................................................ 95
E HAZARDOUS MATERIALS DISCLOSURE ......................................................... 98
E.1 HAZARDOUS MATERIALS DISCLOSURE TABLE FOR IPB PRODUCTS CER TIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY....................................... 99
Page vi
ICE-BT-T6 COM Express Module
List of Figures
Figure 1-1: ICE-BT-T6.....................................................................................................................2
Figure 1-2: On-board Components and Connectors ..................................................................4
Figure 1-3: ICE-BT-T6 Dimensions (mm) .....................................................................................5
Figure 1-4: Data Flow Diagram......................................................................................................6
Figure 3-1: Connectors (Front Side)...........................................................................................14
Figure 3-2: Connectors (Solder Side).........................................................................................14
Figure 3-3: COM Express Connector AB Location ...................................................................16
Figure 3-4: COM Express Connector CD Location ...................................................................20
Figure 3-5: SO-DIMM Connector Locations...............................................................................25
Figure 4-1: SO-DIMM Installation................................................................................................29
Figure 4-2: LVDS Panel Type Selection Switch Location.........................................................31
Figure 4-3: Connect the COM Express Connectors..................................................................32
Figure 4-4: Secure the Heatsink..................................................................................................32
Figure 6-1: Start Up Screen .........................................................................................................73
Figure 6-2: Drivers........................................................................................................................73
Figure 6-3: Chipset Driver Welcome Screen..............................................................................74
Figure 6-4: Chipset Driver License Agreement.........................................................................75
Figure 6-5: Chipset Driver Read Me File ....................................................................................75
Figure 6-6: Chipset Driver Setup Operations ............................................................................76
Figure 6-7: Chipset Driver Installation Finish Screen...............................................................76
Figure 6-8: Graphics Driver License Agreement.......................................................................78
Figure 6-9: Graphics Driver Read Me File..................................................................................78
Figure 6-10: Graphics Driver Setup Operations........................................................................79
Figure 6-11: Graphics Driver Installation Finish Screen ..........................................................79
Figure 6-12: Graphics Driver Installation Finish Screen ..........................................................80
Figure 6-13: Windows Control Panel..........................................................................................81
Figure 6-14: System Control Panel.............................................................................................81
Figure 6-15: Device Manager List ...............................................................................................82
Figure 6-16: Update Driver Software Window ...........................................................................83
Figure 6-17: Locate Driver Files..................................................................................................83
Page vii
ICE-BT-T6 COM Express Module
List of Tables
Table 1-1: Model Variations...........................................................................................................3
Table 1-2: ICE-BT-T6 Specifications.............................................................................................8
Table 2-1: Packing List.................................................................................................................11
Table 2-2: Optional Items.............................................................................................................12
Table 3-1: Peripheral Interface Connectors...............................................................................15
Table 3-2: COM Express Connector Pin Definitions.................................................................20
Table 3-3: COM Express Connector CD Pin Definitions...........................................................24
Table 4-1: LVDS Panel Type Selection.......................................................................................30
Table 5-1: BIOS Navigation Keys................................................................................................35
Page viii
ICE-BT-T6 COM Express Module
BIOS Menus
BIOS Menu 1: Main.......................................................................................................................36
BIOS Menu 2: Advanced..............................................................................................................37
BIOS Menu 3: ACPI Settings .......................................................................................................38
BIOS Menu 4: IT8528 Super IO Configuration...........................................................................39
BIOS Menu 5: Serial Port n Configuration Menu.......................................................................39
BIOS Menu 6: Hardware Monitor.................................................................................................42
BIOS Menu 7: Smar Fan Function...............................................................................................43
BIOS Menu 8: IT8518 Super IO Configuration...........................................................................44
BIOS Menu 9: Serial Port n Configuration Menu.......................................................................44
BIOS Menu 10: RTC Wake Settings............................................................................................48
BIOS Menu 11: Serial Port Console Redirection.......................................................................49
BIOS Menu 12: CPU Configuration.............................................................................................52
BIOS Menu 13: Thermal Configuration.......................................................................................54
BIOS Menu 14: SATA Configuration...........................................................................................56
BIOS Menu 15: Trusted Computing............................................................................................58
BIOS Menu 16: USB Configuration.............................................................................................59
BIOS Menu 17: Chipset................................................................................................................60
BIOS Menu 18: North Bridge Configuration ..............................................................................61
BIOS Menu 19: Intel IGD Configuration......................................................................................61
BIOS Menu 20: Sorth Bridge Configuration...............................................................................63
BIOS Menu 21: Azalia HD Audio .................................................................................................64
BIOS Menu 22: PCI Express Configuration ...............................................................................65
BIOS Menu 23: Security...............................................................................................................66
BIOS Menu 24: Boot.....................................................................................................................67
BIOS Menu 25: Save & Exit..........................................................................................................69
ICE-BT-T6
Page ix
ICE-BT-T6 COM Express Module
Chapter
1
1 Introduction
Page 1
1.1 Introduction
Figure 1-1: ICE-BT-T6
ICE-BT-T6 COM Express Module
The ICE-BT-T6 COM Express Type 6 module provides the main processing chips and is
connected to a compatible COM Express baseboard. The ICE-BT-T6 is preinstalled with
th
4
generation Intel® Atom or Celeron® processor. The COM Express standard allows
the COM Express baseboard to be designed, while leaving the choice of processor till the
later stages of design. The ICE-BT-T6 provides a low power option with the full range of
modern I/O options. The ICE-BT-T6 embedded module is designed for flexible integration
by system developers into customized platform devices.
Page 2
ICE-BT-T6 COM Express Module
1.2 Model Variations
The model variations for the ICE-BT-T6 series are listed in Table 1-1.
Model
ICE-BT-T6-J19001 Intel® Celeron® J1900 2.0 GHz 4 2 MB 10 W Two
ICE-BT-T6-N29301 Intel® Celeron® N2930 1.83 GHz 4 2 MB 7.5 W Two
ICE-BT-T6-N28071 Intel® Celeron® N2807 1.58 GHz 2 2 MB 4.3 W One
ICE-BT-T6-E38451 Intel® Atom™ E3845 1.91 GHz 4 2 MB 10 W Two
ICE-BT-T6-E38271 Intel® Atom™ E3827 1.75 GHz 2 1 MB 8 W Two
ICE-BT-T6-E38261 Intel® Atom™ E3826 1.46 GHz 2 1 MB 7 W Two
ICE-BT-T6-E38251 Intel® Atom™ E3825 1.33 GHz 2 1 MB 6 W One
ICE-BT-T6-E38151 Intel® Atom™ E3815 1.46 GHz 1 512 KB 5 W One
Table 1-1: Model Variations
On-board SoC Memory
Name Clock Speed # of Cores L2 Cache Max TDP Slot #
1.3 Features
Some of the ICE-BT-T6 COM Express module features are listed below:
Complies with COM Express Type 6 form factor
On-board 22nm Intel® Atom or Celeron® processor
Two/One 204 -pin 1066/1333 MHz dual-channel unbuffered DDR3L SDRAM
DIMM slots support up to a total of 8 GB of memory
Optional on-board 4 GB SSD
Supports analog CRT (VGA ), DisplayPort, HDMI and LVDS
Supports USB 3.0, SATA 3Gb/s and GbE
RoHS compliant
Page 3
1.4 Board Overview
The on-board components and connectors of the ICE-BT-T6 are shown in the figures
below.
ICE-BT-T6 COM Express Module
Figure 1-2: On-board Components and Connectors
Page 4
ICE-BT-T6 COM Express Module
1.5 Dimensions
The main dimensions of the ICE-BT-T6 are shown in the diagram below.
Figure 1-3: ICE-BT-T6 Dimensions (mm)
Page 5
1.6 Data Flow
Figure 1-4 shows the data flow between the system chipset, the CPU and other
components installed on the motherboard.
ICE-BT-T6 COM Express Module
Page 6
Figure 1-4: Data Flow Diagram
ICE-BT-T6 COM Express Module
1.7 Technical Specifications
The ICE-BT-T6 technical specifications are listed below.
ICE-BT-T6
Form Factor
On-board SoC
PICMG COM Express R2.1 Type 6
Standard
o Intel® Celeron® processor J1900
(2GHz, quad-core, 2MB cache, TDP=10W)
o Intel® Celeron® processor N2930
(1.83GHz, quad-core, 2MB cache, TDP=7.5W)
o Intel® Celeron® processor N2807
(1.58GHz, dual-core, 2MB cache, TDP=4.5W)
By request
o Intel® Atom™ processor E3845
(1.91GHz, quad-core, 2MB cache, TDP=10W)
o Intel® Atom™ processor E3827
(1.75GHz, dual-core, 1MB cache, TDP=8W)
o Intel® Atom™ processor E3826
(1.46GHz, dual-core, 1MB cache, TDP=7W)
o Intel® Atom™ processor E3825
Memory
Internal Storage
Graphics Engine
Ethernet
BIOS
Embedded Controller
(1.33GHz, dual-core, 1MB cache, TDP=6W)
o Intel® Atom™ processor E3815
(1.46GHz, single-core, 512KB cache, TDP=5W)
Two 204-pin 1066/1333 MHz dual-channel unbuffered DDR3L
SDRAM DIMM slots support up to a total of 8 GB of memory
2-Kb serial I
Intel® HD Graphics Gen 7 with four execution units
Supports DirectX 11.1, OpenGL 4.2 and OpenCL 1.2
Intel® I210 Ethernet Controller
UEFI BIOS
ITE IT8528E/FX
2
C bus EEPROM supports EAPI Rev. 1.0
Page 7
ICE-BT-T6
ICE-BT-T6 COM Express Module
Watchdog Timer
Storage
Display
(Signal to Baseboard)
Expansions
(Signal to Baseboard)
I/O Interfaces
(Signal to Baseboard)
Software programmable supports 1~2 55 sec. system reset
Two SATA 3Gb/s (signal to baseboard)
Optional on-board 4 GB SSD (SATA port1)
One VGA (up to 2560 x 1600)
One DDI 1 (DP/HDMI, max. resolution: 2560x1600/1920x1080)
One DDI 2 (24-bit dual-channel LVDS, optional via CH7511B)
One LVDS: 18/24-bit dual-channel LVDS by CH7511B DP to LVDS
converter (up to 1920x1200 @ 60Hz)
Five PCIe x1 (two from SoC, three from PLX PEX8605 switch IC)
Seven USB 2.0
Four USB 3.0 (via one-to-four USB 3.0 hub)
Two RS-232 (TX and RX from EC)
HD Audio
8-bit GPIO
SMBus
2
I
C
LPC
SPI
Power Consumption
Operating
Temperature
Storage Temperature
Operating Humidity
Dimensions
Weight (GW/NW)
Table 1-2: ICE-BT-T6 Specifications
Page 8
+12V @ 0.54 A , Vcore_12V @ 0.95 A (2.0 GHz Intel® Celeron®
J1900 CPU with one 8 GB 1333 MHz DDR3L memory)
-20ºC ~ 60ºC
-30ºC ~ 70ºC
5% ~ 95% (non-condensing)
125 mm x 95 mm
600 g/200 g
ICE-BT-T6 COM Express Module
Chapter
2
2 Packing List
Page 9
2.1 Anti-static Precautions
WARNING!
Static electricity can destroy certain electronics. Make sure to follow the
ESD precautions to prevent damage to the product, and injury to the
user.
Make sure to adhere to the following guidelines:
Wear an anti-static wristband: Wearing an anti-static wristband can prevent
electrostatic discharge.
Self-grounding: Touch a grounded conductor every few minutes to discharge
any excess static buildup.
ICE-BT-T6 COM Express Module
Use an anti-static pad: When configuring any circuit board, place it on an
anti-static mat.
Only handle the edges of the PCB: Don't touch the surface of the
motherboard. Hold the motherboard by the edges when handling.
2.2 Unpacking Precautions
When the ICE-BT-T6 is unpacked, please do the following:
Follow the antistatic guidelines above.
Make sure the packing box is facing upwards when opening.
Make sure all the packing list items are present.
Page 10
ICE-BT-T6 COM Express Module
2.3 Packing List
NOTE:
If any of the components listed in the checklist below are missing, do
not proceed with the installation. Contact the IEI reseller or vendor the
ICE-BT-T6 was purchased from or contact an IEI sales representative
directly by sending an email to 31sales@ieiworld.com.
The ICE-BT-T6 is shipped with the following components:
Quantity Item and Part Number Image
1 ICE-BT-T6 COM Express Module
1 Heatsink
1 Utility CD
1 Quick Installation Guide
Table 2-1: Packing List
Page 11
2.4 Optional Items
The following are optional components which may be separately purchased:
Item and Part Number Image
Baseboard for COM Express Type 6 modules
(P/N: ICE-DB-T6R-R10)
Table 2-2: Optional Items
ICE-BT-T6 COM Express Module
Page 12
ICE-BT-T6 COM Express Module
Chapter
3
3 Connectors
Page 13
3.1 Peripheral Interface Connectors
This chapter details all the connectors.
3.1.1 ICE-BT-T6 Layout
The figure below shows all the connectors.
ICE-BT-T6 COM Express Module
Figure 3-1: Connectors (Front Side)
Figure 3-2: Connectors (Solder Side)
Page 14
ICE-BT-T6 COM Express Module
3.1.2 Peripheral Interface Connectors
The table below lists all the connectors on the ICE-BT-T6.
Connector Type Label
COM Express connector AB COM Express connector J1
COM Express connector CD COM Express connector J2
DDR3 SO-DIMM slot 204-pin SO-DIMM slot DIMM1, DIMM2
Table 3-1: Peripheral Interface Connectors
Page 15
3.2 Internal Peripheral Connectors
The section describes all of the connectors on the ICE-BT-T6.
3.2.1 COM Express Connector AB
CN Label: J1
ICE-BT-T6 COM Express Module
CN Type:
CN Location:
CN Pinouts:
220-pin COM Express connector
See Figure 3-3
See Table 3-2
The standard COM Express connector AB location and pinout s are shown below.
Page 16
Figure 3-3: COM Express Connector AB Location
Pin No. Description Pin No. Description
A1
A2
A3
A4
A5
A6
A7
A8
GND
GBE0_MDI3GBE0_MDI3+
GBE0_LINK100#
GBE0_LINK1000#
GBE0_MDI2GBE0_MDI2+
RSVD
B1
B2
B3
B4
B5
B6
B7
B8
GND15
GBE0_ACT#
LPC_FRAME#
LPC_AD0
LPC_AD1
LPC_AD2
LPC_AD3
LPC_DRQ0#
ICE-BT-T6 COM Express Module
Pin No. Description Pin No. Description
A9
A10
A11
A12
A13
A14
A15
A16
A17
A18
A19
A20
A21
A22
A23
A24
GBE0_MDI1GBE0_MDI1+
GND1
GBE0_MDI0GBE0_MDI0+
GBE0_CTREF
SUS_S3#
SATA0_TX+
SATA0_TXSUS_S4#
SATA0_RX+
SATA0_RXGND2
RSVD
RSVD
SUS_S5#
B9
B10
B11
B12
B13
B14
B15
B16
B17
B18
B19
B20
B21
B22
B23
B24
LPC_DRQ1#
LPC_CLK
GND16
PWRBTN#
SMB_CK
SMB_DAT
SMB_ALERT#
SATA1_TX+
SATA1_TXSUS_STAT#
SATA1_RX+
SATA1_RXGND17
RSVD
RSVD
PWR_OK
A25
A26
A27
A28
A29
A30
A31
A32
A33
A34
A35
A36
A37
A38
A39
A40
RSVD
RSVD
BATLOW#
ATA_ACT#
AC/HD_SYNC
AC/HD_RST#
GND3
AC/HD_BITCLK
AC/HD_SDOUT
BIOS_DISABLE#
RSVD
USB6USB6+
USB_6_7_OC#
USB4USB4+
B25
B26
B27
B28
B29
B30
B31
B32
B33
B34
B35
B36
B37
B38
B39
B40
RSVD
RSVD
WDT
RSVD
AC/HD_SDIN1
AC/HD_SDIN0
GND18
SPKR
I2C_CK
I2C_DAT
RSVD
RSVD
RSVD
USB_4_5_OC#
USB5USB5+
Page 17
Pin No. Description Pin No. Description
ICE-BT-T6 COM Express Module
A41
A42
A43
A44
A45
A46
A47
A48
A49
A50
A51
A52
A53
A54
A55
A56
GND4
USB2USB2+
USB_2_3_OC#
USB0USB0+
VCC_RTC
RSVD
RSVD
LPC_SERIRQ
GND5
RSVD
RSVD
GPI0
PCIE_TX4+
PCIE_TX4-
B41
B42
B43
B44
B45
B46
B47
B48
B49
B50
B51
B52
B53
B54
B55
B56
GND
USB3USB3+
USB_0_1_OC#
USB1USB1+
RSVD
RSVD
SYS_RESET#
CB_RESET#
GND20
RSVD
RSVD
GPO1
PCIE_RX4+
PCIE_RX4-
A57
A58
A59
A60
A61
A62
A63
A64
A65
A66
A67
A68
A69
A70
A71
A72
GND6
PCIE_TX3+
PCIE_TX3GND7
PCIE_TX2+
PCIE_TX2GPI1
PCIE_TX1+
PCIE_TX1GND8
GPI2
PCIE_TX0+
PCIE_TX0GND9
LVDS_A0+
LVDS_A0-
B57
B58
B59
B60
B61
B62
B63
B64
B65
B66
B67
B68
B69
B70
B71
B72
GPO2
PCIE_RX3+
PCIE_RX3GND
PCIE_RX2+
PCIE_RX2GPO3
PCIE_RX1+
PCIE_RX1WAKE0#
RSVD
PCIE_RX0+
PCIE_RX0GND22
LVDS_B0+
LVDS_B0-
Page 18
ICE-BT-T6 COM Express Module
Pin No. Description Pin No. Description
A73
A74
A75
A76
A77
A78
A79
A80
A81
A82
A83
A84
A85
A86
A87
A88
LVDS_A1+
LVDS_A1LVDS_A2+
LVDS_A2LVDS_VDD_EN
LVDS_A3+
LVDS_A3GND10
LVDS_A_CK+
LVDS_A_CKLVDS_I2C_CK
LVDS_I2C_DAT
GPI3
RSVD
RSVD
PCIE0_CK_REF+
B73
B74
B75
B76
B77
B78
B79
B80
B81
B82
B83
B84
B85
B86
B87
B88
LVDS_B1+
LVDS_B1LVDS_B2+
LVDS_B2LVDS_B3+
LVDS_B3LVDS_BKLT_EN
GND23
LVDS_B_CK+
LVDS_B_CKLVDS_BKLT_CTRL
VCC5SBY1
VCC5SBY2
VCC5SBY3
VCC5SBY4
BIOS_DIS1#
A89
A90
A91
A92
A93
A94
A95
A96
A97
A98
A99
A100
A101
A102
A103
A104
PCIE0_CK_REFGND11
SPI_VCC
SPI_MISO
GPO0
SPI_CLK
SPI_MOSI
RSVD
RSVD (TYPE 10#)
RS1_TX
RS1_RX
GND13
RS2_TX
RS2_RX
LID#
VCC_12V7
B89
B90
B91
B92
B93
B94
B95
B96
B97
B98
B99
B100
B101
B102
B103
B104
VGA_RED
GND24
VGA_GRN
VGA_BLU
VGA_HSYNC
VGA_VSYNC
VGA_I2C_CK
VGA_I2C_DAT
SPI_CS#
RSVD
RSVD
GND25
FAN_PWMOUT
FAN_TACHIN
SLEEP#
VCC_12V16
Page 19
Pin No. Description Pin No. Description
ICE-BT-T6 COM Express Module
A105
A106
A107
A108
A109
A110
VCC_12V8
VCC_12V9
VCC_12V10
VCC_12V11
VCC_12V12
GND14
Table 3-2: COM Express Connector Pin Definitions
3.2.2 COM Express Connector CD
CN Label: J2
CN Type:
CN Location:
CN Pinou
The sta
ts:
ndard COM Express connector CD location and pinouts are sho wn below.
220-pin COM Express connector
See Figure 3-4
See Table 3-3
B105
B106
B107
B108
B109
B110
VCC_12V17
VCC_12V18
VCC_12V19
VCC_12V20
VCC_12V21
GND26
Page 20
Figure 3-4: COM Express Connector CD Location
ICE-BT-T6 COM Express Module
Pin No. Description Pin No. Description
C1
C2
C3
C4
C5
C6
C7
C8
C9
C10
C11
C12
C13
C14
C15
GND0
GND
USB_SSRX0USB_SSRX0+
GND
USB_SSRX1USB_SSRX1+
GND
USB_SSRX2USB_SSRX2+
GND1
USB_SSRX3USB_SSRX3+
GND
RSVD
D1
D2
D3
D4
D5
D6
D7
D8
D9
D10
D11
D12
D13
D14
D15
GND15
GND
USB_SSTX0USB_SSTX0+
GND
USB_SSTX1USB_SSTX1+
GND
USB_SSTX2USB_SSTX2+
GND16
USB_SSTX3USB_SSTX3+
GND
DDI1_CTRLCLK_AUX+
(by request*)
C16
C17
C18
C19
C20
C21
C22
C23
C24
C25
C26
C27
C28
C29
C30
RSVD
RSVD
RSVD
RSVD
RSVD
GND2
RSVD
RSVD
DDI1_HPD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
D16
D17
D18
D19
D20
D21
D22
D23
D24
D25
D26
D27
D28
D29
D30
DDI1_CTRLDATA_AUX-
(by request*)
RSVD
RSVD
RSVD
RSVD
GND17
RSVD
RSVD
RSVD
RSVD
DDI1_PAIR0+ (by request*)
DDI1_PAIR0- (by request*)
RSVD
DDI1_PAIR1+ (by request*)
DDI1_PAIR1- (by request*)
C31
GND3 D31 GND18
Page 21
Pin No. Description Pin No. Description
ICE-BT-T6 COM Express Module
C32
C33
C34
C35
C36
C37
C38
C39
C40
C41
C42
C43
C44
C45
C46
DDI2_CTRLCLK_AUX+ D32 DDI1_PAIR2+ (by request*)
DDI2_CTRLDATA_AUX- D33 DDI1_PAIR2- (by request*)
DDI2_DDC_AUX_SEL D34
RSVD D35 RSVD
RSVD D36 DDI1_PAIR3+ (by request*)
RSVD D37 DDI1_PAIR3- (by request*)
RSVD D38 RSVD
RSVD D39 DDI2_PAIR0+
RSVD D40 DDI2_PAIR0GND4 D41 GND19
RSVD
RSVD
RSVD
RSVD
RSVD
D42
D43
D44
D45
D46
DDI1_DDC_AUX_SEL
(by request*)
DDI2_PAIR1+
DDI2_PAIR1DDI2_HPD
RSVD
DDI2_PAIR2+
C47
C48
C49
C50
C51
C52
C53
C54
C55
C56
C57
C58
C59
C60
C61
C62
RSVD
RSVD
RSVD
RSVD
GND5
RSVD
RSVD
RSVD (TYPE0#)
RSVD
RSVD
RSVD (TYPE1#)
RSVD
RSVD
GND7
RSVD
RSVD
D47
D48
D49
D50
D51
D52
D53
D54
D55
D56
D57
D58
D59
D60
D61
D62
DDI2_PAIR2RSVD
DDI2_PAIR3+
DDI2_PAIR3GND20
RSVD
RSVD
RSVD
RSVD
RSVD
GND (TYPE2#)
RSVD
RSVD
GND21
RSVD
RSVD
Page 22
ICE-BT-T6 COM Express Module
Pin No. Description Pin No. Description
C63
C64
C65
C66
C67
C68
C69
C70
C71
C72
C73
C74
C75
C76
C77
C78
RSVD1
RSVD2
RSVD
RSVD
RSVD3
RSVD
RSVD
GND9
RSVD
RSVD
RSVD
RSVD
RSVD
GND8
RSVD4
RSVD
D63
D64
D65
D66
D67
D68
D69
D70
D71
D72
D73
D74
D75
D76
D77
D78
RSVD10
RSVD9
RSVD
RSVD
GND28
RSVD
RSVD
GND22
RSVD
RSVD
RSVD
RSVD
RSVD
GND29
RSVD
RSVD
C79
C80
C81
C82
C83
C84
C85
C86
C87
C88
C89
C90
C91
C92
C93
C94
RSVD
GND10
RSVD
RSVD
RSVD5
GND6
RSVD
RSVD
GND35
RSVD
RSVD
GND27
RSVD
RSVD
GND11
RSVD
D79
D80
D81
D82
D83
D84
D85
D86
D87
D88
D89
D90
D91
D92
D93
D94
RSVD
GND23
RSVD
RSVD
RSVD8
GND30
RSVD
RSVD
GND31
RSVD
RSVD
GND24
RSVD
RSVD
GND32
RSVD
Page 23
Pin No. Description Pin No. Description
ICE-BT-T6 COM Express Module
C95
C96
C97
C98
C99
C100
C101
C102
C103
C104
C105
C106
C107
C108
C109
C110
RSVD
GND12
RSVD6
RSVD
RSVD
GND13
RSVD
RSVD
GND
VCC_12V1
VCC_12V2
VCC_12V3
VCC_12V4
VCC_12V5
VCC_12V6
GND14
D95
D96
D97
D98
D99
D100
D101
D102
D103
D104
D105
D106
D107
D108
D109
D110
RSVD
GND33
RSVD
RSVD
RSVD
GND25
RSVD
RSVD
GND34
VCC_12V7
VCC_12V8
VCC_12V9
VCC_12V10
VCC_12V11
VCC_12V12
GND26
* DDI 1 signals (D15, D16, D26, D27, D29, D30 D32, D33, D34, D36 and D37) are
only available upon special order request. These pins are reserved on the standard
ICE-BT-T6 module.
Table 3-3: COM Express Connector CD Pin Definitions
3.2.3 SO-DIMM Connectors
CN Label: DIMM1, DIMM2
CN Type:
CN Location:
The SO-DIM
M connectors are for installing DDR3L memory on the system.
204-pin DDR3 SO-DIMM connector
See Figure 3-5
Page 24
ICE-BT-T6 COM Express Module
NOTE:
If there is only one memory module being installed, install it in the
DIMM1 slot.
Some of the ICE-BT-T6 models only have one SO-DIMM slot. Please
refer to Table 1-1: Model Variations for detailed information.
Figure 3-5: SO-DIMM Connector Locations
Page 25
ICE-BT-T6 COM Express Module
Chapter
4
4 Installation
Page 26
ICE-BT-T6 COM Express Module
4.1 Anti-static Precautions
WARNING:
Failure to take ESD precautions during the installation of the
ICE-BT-T6 may result in permanent damage to the ICE-BT-T6 and
severe injury to the user.
Electrostatic discharge (ESD) can cause serious damage to electronic components,
including the ICE-BT-T6. Dry climates are especially susceptible to ESD. It is therefore
critical that whenever the ICE-BT-T6 or any other electrical component is handled, the
following anti-static precautions are strictly adhered to.
Wear an anti-static wristband: Wearing a simple anti-static wristband can
help to prevent ESD from damaging the board.
Self-grounding: Before handling the board, touch any grounded conducting
material. During the time the board is handled, frequently touch any
conducting materials that are connected to the ground.
Use an anti-static pad: When configuring the ICE-BT-T6, place it on an
antic-static pad. This reduces the po ssi bi lity of ESD damaging the ICE-BT-T6.
Only handle the edges of the PCB: When handling the PCB, hold the PCB
by the edges.
4.2 Installation Considerations
NOTE:
The following installation notices and installation considerations should
be read and understood before installation. All installation notices must
be strictly adhered to. Failing to adhere to these precautions may lead
to severe damage and injury to the person performing the installation.
Page 27
ICE-BT-T6 COM Express Module
WARNING:
The installation instructions described in this manual should be
carefully followed in order to prevent damage to the components and
injury to the user.
Before and during the installation please DO the following:
Read the user manual:
o The user manual provides a complete description of the ICE-BT-T6
installation instructions and configuration options.
Wear an electrostatic discharge cuff (ESD):
o Electronic components are easily damaged by ESD. Wearing an ESD cuff
removes ESD from the body and helps prevent ESD damage.
Place the ICE-BT-T6 on an antistatic pad:
o When installing or configuring the motherboard, place it on an antistatic
pad. This helps to prevent potential ESD damage.
Turn all power to the ICE-BT-T6 off:
o When working with the ICE-BT-T6, make sure that it is disconnected from
all power supplies and that no electricity is being fed into the system.
Before and during the installation of the ICE-BT-T6 DO NOT:
Remove any of the stickers on the PCB board. These stickers are required for
warranty validation.
Use the product before verifying all the cables and power connectors are
properly connected.
Allow screws to come in contact with the PCB circuit, connector pins, or its
components.
Page 28
ICE-BT-T6 COM Express Module
4.3 SO-DIMM Installation
WARNING:
Using incorrectly specified SO-DIMM may cause permanent damage to
the ICE-BT-T6. Please make sure the purchased SO-DIMM complies
with the memory specifications of the ICE-BT-T6. SO-DIMM
specifications compliant with the ICE-BT-T6 are listed in Chapter 1.
To install a SO-DIMM into a SO-DIMM socket, please follow the steps below and refer to
Figure 4-1.
Figure 4-1: SO-DIMM Installation
Step 1: Locate the SO-DIMM socket. Place the ICE-BT-T6 on an anti-static pad with
the solder side facing up.
Step 2: Align the SO-DIMM with the socket. The SO-DIMM must be orient ed in such a
way that the notch in the middle of the SO-DIMM must be aligned with the
plastic bridge in the socket.
Step 3: Insert the SO-DIMM. Push the SO-DIMM chip into the socket at an angle. (See
Figure 4-1)
Step 4: Open th
out and push the rear of the SO-DIMM down. (See Figure 4-1)
e SO-DIMM socket arms. Gently pull the arms of the SO-DIMM socket
Page 29
Step 5: Secure the SO-DIMM. Release the arms on the SO-DIMM socket. They clip into
place and secure the SO-DIMM in the socket.
4.4 Jumper Settings
4.4.1 LVDS Panel Type Selection
Jumper Label: SW1
ICE-BT-T6 COM Express Module
Jumper Type:
Jumper Settings:
Jumper Loc
ation:
This switch sets the re
listed in the first column of Table 4-1 is
SW1 EDID Resolution Color Depth Channel
0000 800X600 18-bit Single
0001 1024X768 18-bit Single
0010 1024X768 24-bit Single
0011 1280X768 18-bit Single
0100 1280X800 18-bit Single
0101 1280X960 18-bit Single
0110 1280X1024 24-bit Dual
0111 1366X768 18-bit Single
DIP switch
See Table 4-1
See Figure 4-2
solution of the panel attached to the LVDS output. The pin order
: 4 3 2 1. (ON=0, OFF=1)
Page 30
1000 1366X768 24-bit Single
1001 1440X960 24-bit Dual
1010 1400X1050 24-bit Dual
1011 1600X900 24-bit Dual
1100 1680X1050 24-bit Dual
1101 1600X1200 24-bit Dual
1110 1920X1080 24-bit Dual
1111 1920X1200 24-bit Dual
Table 4-1: LVDS Panel Type Selection
ICE-BT-T6 COM Express Module
Figure 4-2: LVDS Panel Type Selection Switch Location
4.5 Mounting ICE-BT -T6 to Baseboard
NOTE:
Baseboard can be designed by the end user, customized by IEI, or
purchased from IEI. For more information visit the IEI website
(www.ieiworld.com
) or contact an IEI sales representative.
WARNING:
Never run the COM Express module without the heatsink and a
thermal pad. The thermal pad acts as a thermal interface between the
module and the heatsink. The heatsink must be installed on the
ICE-BT-T6 to maintain proper operating temperatures. Make sure to
maintain the heatsink temperature under 60C in operation.
Follow the steps below to install the ICE-BT-T6 to the optional baseboard.
Step 1: Align the two COM Express connector on the solder side of the ICE-BT-T6 with
the corresponding connector on the baseboard. Gently push the COM Express
module down to ensure the connectors are properly connected (Figure 4-3).
Page 31
Loading...
