IEI Technology ICE-BDE-T7 User Manual

ICE-BDE-T7 COM Express Module
Page i
COM Express R3.0 Module (Type 7) with Intel® Xeon®
GbE, 10G KR, NCSI, SATA 6Gb/s, PCIe Gen3 and RoHS
MODEL:
ICE-BDE-T7
Rev. 1.01 – February 2, 2018
User Manual
ICE-BDE-T7 COM Express Module
Page ii
Date Version Changes
Revision
February 2, 2018
December 13, 2017
1.01 Added a new SKU - ICE-BDE-T7-1508
1.00 Initial release
ICE-BDE-T7 COM Express Module
Page iii
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibil ity of such damages.
This document contains proprietary information protected by copyright. All rights are reserved. No part of this manual may be reproduced by any mechanical, electronic, or other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification purposes only and may be trademarks and/or registered trademarks of their respective owners.
ICE-BDE-T7 COM Express Module
Page iv
Manual Conventions
WARNING
Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously.
CAUTION
Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product.
NOTE
These messages inform the reader of essent ial but non-critical information. These messages should be read carefully as any directions or instructions contained therein can help avoid making mistakes.
ICE-BDE-T7 COM Express Module
Page v
Table of Contents
1 INTRODUCTION .......................................................................................................... 1
1.1 INTRODUCTION ........................................................................................................... 2
1.2 MODEL VARIATIONS ................................................................................................... 3
1.3 FEATURES ................................................................................................................... 3
1.4 BOARD OVERVIEW ..................................................................................................... 4
1.5 DIMENSIONS ............................................................................................................... 5
1.6 DATA FLOW ................................................................................................................ 6
1.7 TECHNICAL SPECIFICATIONS ...................................................................................... 7
2 PACKING LIST ............................................................................................................. 9
2.1 ANTI-STATIC PRECAUTIONS ...................................................................................... 10
2.2 UNPACKING PRECAUTIONS ....................................................................................... 10
2.3 PACKING LIST ............................................................................................................ 11
2.4 OPTIONAL ITEMS ...................................................................................................... 12
3 CONNECTORS ........................................................................................................... 13
3.1 PERIPHERAL INTERFACE CONNECTORS ..................................................................... 14
3.1.1 ICE-BDE-T7 Layout ........................................................................................ 14
3.1.2 Peripheral Interface Connectors ..................................................................... 15
3.2 INTERNAL PERIPHERAL CONNECTORS ...................................................................... 15
3.2.1 COM Express A-B Connector .......................................................................... 15
3.2.2 COM Express C-D Connector ......................................................................... 19
3.2.1 CPLD Programming Connector ...................................................................... 24
3.2.2 DDR4 SO-DIMM Connectors .......................................................................... 25
3.2.1 Debug Port, LPC ............................................................................................. 26
3.2.1 Debug Port, EC ................................................................................................ 27
3.2.1 SPI Flash Connector, BIOS .............................................................................. 28
3.2.1 SPI Flash Connector, EC ................................................................................. 29
4 INSTALLATION ......................................................................................................... 30
4.1 ANTI-STATIC PRECAUTIONS ...................................................................................... 31
ICE-BDE-T7 COM Express Module
Page vi
4.2 INSTALLATION CONSIDERATIONS .............................................................................. 31
4.3 SO-DIMM INSTALLATION ....................................................................................... 33
4.4 MOUNTING ICE-BDE-T7 TO BASEBOARD ................................................................. 34
5 BIOS .............................................................................................................................. 36
5.1 INTRODUCTION ......................................................................................................... 37
5.1.1 Starting Setup ................................................................................................... 37
5.1.2 Using Setup ...................................................................................................... 37
5.1.3 Getting Help ..................................................................................................... 38
5.1.4 Unable to Reboot after Configuration Changes .............................................. 38
5.1.5 BIOS Menu Bar ................................................................................................ 38
5.2 MAIN ........................................................................................................................ 39
5.3 ADVANCED ............................................................................................................... 39
5.3.1 T rusted Computing ........................................................................................... 41
5.3.2 iWDD H/W Monitor ......................................................................................... 42
5.3.2.1 Smart Fan Mode Configuration ................................................................ 43
5.3.3 iWDD Super IO Configuration ........................................................................ 45
5.3.3.1 Serial Port n Configuration ....................................................................... 46
5.3.4 RTC Wake Settings ........................................................................................... 48
5.3.5 Serial Port Console Redirection ...................................................................... 49
5.3.5.1 Legacy Console Redirection Settings ....................................................... 50
5.3.5.2 Console Redirection Settings .................................................................... 51
5.3.6 USB Configuration ........................................................................................... 53
5.3.7 IEI Feature ....................................................................................................... 54
5.4 INTELRCSETUP ........................................................................................................ 55
5.4.1 Processor Configuration .................................................................................. 56
5.4.2 IIO Configuration ............................................................................................ 58
5.4.2.1 IIO0 Configuration .................................................................................... 58
5.4.2.2 Intel VT for Directed I/O (VT-d) .............................................................. 59
5.4.2.3 IIO South Complex Configuration ............................................................ 60
5.4.3 PCH Configuration .......................................................................................... 61
5.4.3.1 PCI Express Configuration ....................................................................... 61
5.4.3.2 PCH SATA Configuration ......................................................................... 62
5.5 SERVER MANAGEMENT ............................................................................................ 64
5.5.1 System Event Log ............................................................................................. 64
ICE-BDE-T7 COM Express Module
Page vii
5.6 SECURITY ................................................................................................................. 66
5.7 BOOT ........................................................................................................................ 67
5.8 SAVE & EXIT ............................................................................................................ 69
6 SOFTWARE DRIVERS .............................................................................................. 71
6.1 SOFTWARE INSTALLATION ........................................................................................ 72
A REGULATORY COMPLIANCE .............................................................................. 73
B PRODUCT DISPOSAL .............................................................................................. 75
C BIOS OPTIONS .......................................................................................................... 77
D DIGITAL I/O INTERFACE ....................................................................................... 80
E WATCHDOG TIMER ................................................................................................. 83
F HAZARDOUS MATERIALS DISCLOSURE .......................................................... 86
ICE-BDE-T7 COM Express Module
Page viii
List of Figures
Figure 1-1: ICE-BDE-T7 .................................................................................................................. 2
Figure 1-2: On-board Components and Connectors .................................................................. 4
Figure 1-3: ICE-BDE-T7 Dimensions (without heatsink) (mm) ................................................... 5
Figure 1-4: ICE-BDE-T7 Dimensions (with heatsink) (mm) ........................................................ 5
Figure 1-5: Data Flow Diagram ...................................................................................................... 6
Figure 3-1: Connectors (Front Side) ........................................................................................... 14
Figure 3-2: Connectors (Solder Side) ......................................................................................... 14
Figure 3-3: COM Express A-B Connector Location .................................................................. 16
Figure 3-4: COM Express C-D Connector Location .................................................................. 20
Figure 3-5: CPLD Programming Connector Location ............................................................... 24
Figure 3-6: SO-DIMM Connector Locations ............................................................................... 25
Figure 3-7: LPC Debug Port Location ......................................................................................... 26
Figure 3-8: EC Debug Port Location ........................................................................................... 27
Figure 3-9: BIOS SPI Flash Connector Location ....................................................................... 28
Figure 3-10: EC SPI Flash Connector Location ......................................................................... 29
Figure 4-1: SO-DIMM Installation ................................................................................................ 33
Figure 4-2: Connect the COM Express Connectors .................................................................. 35
Figure 4-3: Secure the Heatsink .................................................................................................. 35
ICE-BDE-T7 COM Express Module
Page ix
List of Tables
Table 1-1: Model Variations ........................................................................................................... 3
Table 1-2: ICE-BDE-T7 Specifications .......................................................................................... 8
Table 2-1: Packing List ................................................................................................................. 11
Table 2-2: Optional Items ............................................................................................................. 12
Table 3-1: Peripheral Interface Connectors ............................................................................... 15
Table 3-2: COM Express A-B Connector Pin Definitions .......................................................... 19
Table 3-3: COM Express C-D Connector Pin Definitions .......................................................... 23
Table 3-4: CPLD Programming Connector Pin Definitions ...................................................... 24
Table 3-5: LPC Debug Port Pin Definitions ................................................................................ 26
Table 3-6: EC Debug Port Pin Definitions .................................................................................. 27
Table 3-7: BIOS SPI Flash Connector Pin Definitions .............................................................. 28
Table 3-8: EC SPI Flash Connector Pin Definitions .................................................................. 29
ICE-BDE-T7 COM Express Module
Page x
BIOS Menus
BIOS Menu 1: Main ....................................................................................................................... 39
BIOS Menu 2: Advanced .............................................................................................................. 40
BIOS Menu 3: Trusted Computing .............................................................................................. 41
BIOS Menu 4: iWDD H/W Monitor ............................................................................................... 42
BIOS Menu 5: Smart Fan Mode Configuration .......................................................................... 43
BIOS Menu 6: iWDD Super IO Configuration ............................................................................. 45
BIOS Menu 7: Serial Port n Configuration ................................................................................. 46
BIOS Menu 8: RTC Wake Settings .............................................................................................. 48
BIOS Menu 9: Serial Port Console Redirection ......................................................................... 49
BIOS Menu 10: Legacy Console Redirection Settings ............................................................. 50
BIOS Menu 11: Console Redirection Settings ........................................................................... 51
BIOS Menu 12: USB Configuration ............................................................................................. 53
BIOS Menu 13: IEI Feature ........................................................................................................... 54
BIOS Menu 14: IntelRCSetup ....................................................................................................... 55
BIOS Menu 15: Processor Configuration ................................................................................... 56
BIOS Menu 16: IIO Configuration ................................................................................................ 58
BIOS Menu 17: IIO0 Configuration .............................................................................................. 58
BIOS Menu 18: Intel VT for Directed I/O (VT-d) .......................................................................... 59
BIOS Menu 19: IIO South Complex Configuration .................................................................... 60
BIOS Menu 20: PCH Configuration ............................................................................................. 61
BIOS Menu 21: PCI Express Configuration ............................................................................... 61
BIOS Menu 22: PCH SATA Configuration .................................................................................. 62
BIOS Menu 23: Server Management ........................................................................................... 64
BIOS Menu 24: System Event Log .............................................................................................. 65
BIOS Menu 25: Security ............................................................................................................... 66
BIOS Menu 26: Boot ..................................................................................................................... 67
BIOS Menu 27: Save & Exit .......................................................................................................... 69
ICE-BDE-T7
ICE-BDE-T7 COM Express Module
Page 1
Chapter
1

1 Introduction

ICE-BDE-T7 COM Express Module
Page 2

1.1 Introduction

Figure 1-1: ICE-BDE-T7
The ICE-BDE-T7 COM Express Type 7 module provi des the main processing chips and i s connected to a compatible COM Express baseboard. The ICE-BDE-T7 is preinstalled with Intel® Xeon® D-1548, D-1518 or D-1508 processor. The COM Expres s standard allows the COM Express baseboard to be designed, while leaving the choice of processor till the later stages of design. The ICE-BDE-T7 provides a low power option with the full range of modern I/O options. The ICE-BDE-T7 embedded module is designed for flexible integration by system developers into customi zed platform devices.
ICE-BDE-T7 COM Express Module
Page 3

1.2 Model Variations

The model variations for the ICE-BDE-T7 series are listed in Table 1-1.
Model
ICE-BDE-T7-1548 Intel® Xeon® D-1548 2.0 GHz 8 12 MB 45 W ICE-BDE-T7-1518 Intel® Xeon® D-1518 2.2 GHz 4 6 MB 35 W ICE-BDE-T7-1508 Intel® Xeon® D-1508 2.2 GHz 2 3 MB 25 W
Table 1-1: Model Variations
On-board SoC Name Clock Speed # of Cores L2 Cache Max TDP

1.3 Features

Some of the ICE-BDE-T7 COM Express module features are listed below:
Complies with COM Express Type 7 form factor  On-board Intel® Xeon® D-1548, D-1518 or D-1508 processor  Two 260-pin 2133/1867 MHz dual-chan nel unbuffered DDR4 SDRAM
SO-DIMM slots support up to a total of 32 GB of memory and ECC memory
Two 10G Ethernet and NC-SI support  Up to 32 PCIe lanes (24 x Gen3, 8 x Gen2)  GbE, two SATA 6 Gb/s, four USB 3.0/2.0  RoHS compliant
ICE-BDE-T7 COM Express Module
Page 4

1.4 Board Overview

The on-board components and connectors of the ICE-BDE-T7 are shown in the figures below.
Figure 1-2: On-board Components and Connectors
ICE-BDE-T7 COM Express Module
Page 5

1.5 Dimensions

The main dimensions of the ICE-BDE-T7 are shown in the diagrams below.
Figure 1-3: ICE-BDE-T7 Dimensions (without heatsink) (mm)
Figure 1-4: ICE-BDE-T7 Dimensions (with heatsink) (mm)
ICE-BDE-T7 COM Express Module
Page 6

1.6 Data Flow

Figure 1-5 shows the data flow between the system chipset, the CPU and other
components installed on the motherboard.
Figure 1-5: Data Flow Diagram
ICE-BDE-T7 COM Express Module
Page 7

1.7 Technical Specifications

The ICE-BDE-T7 technical specifications are listed below.
ICE-BDE-T7 Form Factor
Processor
Memory
BIOS Watchdog Timer
Ethernet
Storage
PICMG COM Express R3.0 Type 7 Intel® Xeon® processor D-1548 (12 MB Cache, 2.00 GHz)
Intel® Xeon® processor D-1518 (6 MB Cache, 2.20 GHz) Intel® Xeon® Processor D-1508 (3 MB Cache, 2.20 GHz)
Two 260-pin 2133/1867 MHz dual-channel unbuffered DDR4 SDRAM SO-DIMM slots support up to a total of 32 GB of memory
Support ECC UEFI BIOS Software programmable supports 1~255 sec. system reset Intel® I210 Ethernet controller
10G Sideband Signals (10G_INT, 10G_PHY_MDC/MDIO, 10G_PHY_SEL, 10G_PHY_RST, 10G_LED_I2C, 10G_SFP_I2C, 10G_SDP)
Two SATA 6Gb/s (signal to baseboard)
Expansions (Signal to Baseboard)
I/O Interfaces (Signal to Baseboard)
Power Supply
1 x PCIe x16 Gen 3 (Bifurcatable to 2 x8, 1 x8 & 2 x4, or 4 x4) 1 x PCIe x8 Gen 3 (Bifurcatable to 1 x8 & 2 x4) 8 x PCIe x1 Gen 2 (Bifurcatable to 1 x8 or 2 x4 or 4 x1+1x4 or 8 x1)
4 x USB 2.0 4 x USB 3.0 2 x RS-232 (2-wire) 8-bit GPIO SMBus
2
I
C LPC TPM
12V: 12VSB±5%
ICE-BDE-T7 COM Express Module
Page 8
ICE-BDE-T7 Operating
Temperature Storage Temperature Operating Humidity Dimensions Weight (GW/NW) Table 1-2: ICE-BDE-T7 Specifications
-20ºC ~ 60ºC, with 0.7m/s air flow
-30ºC ~ 70ºC 5% ~ 95% (non-condensing) 125 mm x 95 mm 600 g / 300 g
ICE-BDE-T7 COM Express Module
Page 9
Chapter
2

2 Packing List

ICE-BDE-T7 COM Express Module
Page 10

2.1 Anti-static Precautions

WARNING!
Static electricity can destroy certain elect ronics. Make sur e to follow the ESD precautions to prevent damage to the product, and injury to the user.
Make sure to adhere to the following guidelines:
Wear an anti-static wristband: Wearing an anti-static wristband can prevent
electrostatic discharge.
Self-grounding: Touch a grounded conductor every few minutes to discharge
any excess static buildup.
Use an anti-static pad: When configuring any circui t board, place it on an
anti-static mat.
Only handle the edges of the PCB: Don't touch the surface of the
motherboard. Hold the motherboard by the edges when handling.

2.2 Unpacking Precautions

When the ICE-BDE-T7 is unpacked, please do the following:
Follow the antistatic guidelines above.  Make sure the packing box is facing up wards when opening.  Make sure all the packing list items are present.
ICE-BDE-T7 COM Express Module
Page 11
was purchased from or contact an IEI sales

2.3 Packing List

NOTE:
If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the ICE-BDE-T7 representative directly by sending an email to sales@ieiworld.com.
The ICE-BDE-T7 is shipped with the following components:
Quantity Item and Part Number Image
1 ICE-BDE-T7 COM Express Module
1 Heatsink
1 Utility CD
1 Quick Installation Guide
Table 2-1: Packing List
ICE-BDE-T7 COM Express Module
Page 12

2.4 Optional Items

The following are optional components which may be separately purchased:
Item and Part Number Image
Baseboard for COM Express Type 7 modules (P/N: ICE-DB-T7-i2-R10)
Table 2-2: Optional Items
ICE-BDE-T7 COM Express Module
Page 13
Chapter
3

3 Connectors

ICE-BDE-T7 COM Express Module
Page 14

3.1 Peripheral Interface Connectors

This chapter details all the connectors.

3.1.1 ICE-BDE-T7 Layout

The figures below show all the connectors on the front side and the solder side.
Figure 3-1: Connectors (Front Side)
Figure 3-2: Connectors (Solder Side)
ICE-BDE-T7 COM Express Module
Page 15

3.1.2 Peripheral Interface Connectors

The table below lists all the connectors on the ICE-BDE-T7.
Connector Type Label
COM Express A-B connector COM Express connector J1 COM Express C-D connector COM Express connector J2 Clear CMOS button Push button J_CMOS CPLD programming connector 8-pin header J_CPLD1 DDR4 SO-DIMM slot 260-pin SO-DIMM slot DIMM1, DIMM2 Debug port, LPC 12-pin wafer DBG_PORT1 Debug port, EC 20-pin FPC DBG_EC1 SPI flash connector, BIOS 6-pin wafer J_SPI1 SPI flash connector, EC 6-pin wafer J_EC1
Table 3-1: Peripheral Interface Connectors

3.2 Internal Peripheral Connectors

The section describes all of the connectors on the ICE-BDE-T7.

3.2.1 COM Express A-B Connector

CN Label: J1 CN Type: CN Location: CN Pinouts:
The standard COM Express A-B connector locati on and pinouts are shown below.
220-pin COM Express connector See Figure 3-3 See Table 3-2
ICE-BDE-T7 COM Express Module
Page 16
Figure 3-3: COM Express A-B Connector Location
Pin No. Description Pin No. Description
A1 A2 A3 A4 A5 A6 A7 A8 A9 A10 A11 A12 A13
GND GBE0_MDI3­GBE0_MDI3+ GBE0_LINK100# GBE0_LINK1000# GBE0_MDI2­GBE0_MDI2+ NC GBE0_MDI1­GBE0_MDI1+ GND GBE0_MDI0­GBE0_MDI0+
B1 B2 B3 B4 B5 B6 B7 B8 B9 B10 B11 B12 B13
GND GBE0_ACT# LPC_FRAME# LPC_AD0 LPC_AD1 LPC_AD2 LPC_AD3 LPC_DRQ#0 NC LPC_CLK GND PWRBTN# SMB_CK
A14 A15 A16 A17 A18 A19 A20 A21 A22 A23 A24
NC PM_SLP_S3# SATA0_TX+ SATA0_TX­PM_SLP_S4# SATA0_RX+ SATA0_RX­GND PE2_TX_DP_7 PE2_TX_DN_#7 PM_SLP_S5#
B14 B15 B16 B17 B18 B19 B20 B21 B22 B23 B24
SMB_DATA SMB_ALERT# SATA1_TX+ SATA1_TX­LPCPD_N SATA1_RX+ SATA1_RX­GND PE2_RX_DP_7 PE2_RX_DN_#7 PWR_OK
ICE-BDE-T7 COM Express Module
Page 17
Pin No. Description Pin No. Description
A25 A26 A27 A28 A29 A30 A31 A32 A33 A34 A35 A36 A37 A38 A39 A40
PE2_TX_DP_6 PE2_TX_DN_#6 NC SATA_LED# NC NC GND NC NC BIOS_DISABLE# NC PE2_TX_DP_5 PE2_TX_DN_#5 GND PE2_TX_DP_4 PE2_TX_DN_#4
B25 B26 B27 B28 B29 B30 B31 B32 B33 B34 B35 B36 B37 B38 B39 B40
PE2_RX_DP_6 PE2_RX_DN_#6 WDTRST# NC NC NC GND SPKR I2C_CLK I2C_DAT NC PE2_RX_DP_5 PE2_RX_DN_#5 GND PE2_RX_DP_4 PE2_RX_DN_#4
A41 A42 A43 A44 A45 A46 A47 A48 A49 A50 A51 A52 A53 A54 A55 A56
GND USB2­USB2+ USB_2_3_OC# USB0­USB0+ +V3.3A_RTC NC NC INT_SERIRQ GND PCIE_TX_DP_6 PCIE_TX_DN#_6 DIN0 PCIE_TX_DP_5 PCIE_TX_DN#_5
B41 B42 B43 B44 B45 B46 B47 B48 B49 B50 B51 B52 B53 B54 B55 B56
GND USB3­USB3+ USB_0_1_OC# USB1­USB1+ NC NC SYS_RESET# CB_RESET# GND PCIE_RX_DP_6 PCIE_RX_DN#_6 DOUT1 PCIE_RX_DP_5 PCIE_RX_DN#_5
ICE-BDE-T7 COM Express Module
Page 18
Pin No. Description Pin No. Description
A57 A58 A59 A60 A61 A62 A63 A64 A65 A66 A67 A68 A69 A70 A71 A72
GND PCIE_TX_DP_4 PCIE_TX_DN#_4 GND PCIE_TX_DP_3 PCIE_TX_DN#_3 DIN1 PCIE_TX_DP_2 PCIE_TX_DN#_2 GND DIN2 PCIE_TX_DP_1 PCIE_TX_DN#_1 GND PE2_TX_DP_0 PE2_TX_DN_#0
B57 B58 B59 B60 B61 B62 B63 B64 B65 B66 B67 B68 B69 B70 B71 B72
DOUT2 PCIE_RX_DP_4 PCIE_RX_DN#_4 GND PCIE_RX_DP_3 PCIE_RX_DN#_3 DOUT3 PCIE_RX_DP_2 PCIE_RX_DN#_2 WAKE0# NC PCIE_RX_DP_1 PCIE_RX_DN#_1 GND PE2_RX_DP_0 PE2_RX_DN_#0
A73 A74 A75 A76 A77 A78 A79 A80 A81 A82 A83 A84 A85 A86 A87 A88
GND PE2_TX_DP_1 PE2_TX_DN_#1 GND PE2_TX_DP_2 PE2_TX_DN_#2 GND GND PE2_TX_DP_3 PE2_TX_DN_#3 GND NCSI_TX_EN DIN3 NC NC CLK_PCIE_CLK_P
B73 B74 B75 B76 B77 B78 B79 B80 B81 B82 B83 B84 B85 B86 B87 B88
GND PE2_RX_DP_1 PE2_RX_DN_#1 GND PE2_RX_DP_2 PE2_RX_DN_#2 GND GND PE2_RX_DP_3 PE2_RX_DN_#3 GND +V5A +V5A +V5A +V5A NC
ICE-BDE-T7 COM Express Module
Page 19
Pin No. Description Pin No. Description
A89 A90 A91 A92 A93 A94 A95 A96 A97 A98 A99 A100 A101 A102 A103 A104
CLK_PCIE_CLK_N GND NC SPI_MISO DOUT0 SPI_CLK SPI_MOSI NC NC RS1_TX RS1_RX GND RS2_TX RS2_RX LID# VCC_12V
B89 B90 B91 B92 B93 B94 B95 B96 B97 B98 B99 B100 B101 B102 B103 B104
NC GND NCSI_CLK NCSI_RXD1 NCSI_RXD0 NCSI_CRS NCSI_TXD1 NCSI_TXD0 SPI_CS NC NC GND FAN_PWMOUT FAN_TACHIN SLEEP# VCC_12V
A105 A106 A107 A108 A109 A110
VCC_12V VCC_12V VCC_12V VCC_12V VCC_12V GND
B105 B106 B107 B108 B109 B110
VCC_12V VCC_12V VCC_12V VCC_12V VCC_12V GND
Table 3-2: COM Express A-B Connector Pin Definitions

3.2.2 COM Express C-D Connector

CN Label: J2 CN Type: CN Location: CN Pinouts:
The standard COM Express C-D connector location and pinouts are shown below.
220-pin COM Express connector See Figure 3-4 See Table 3-3
ICE-BDE-T7 COM Express Module
Page 20
Figure 3-4: COM Express C-D Connector Location
Pin No. Description Pin No. Description
C1 C2 C3 C4 C5 C6 C7 C8 C9 C10 C11 C12 C13 C14 C15 C16
GND GND USB3_RXN_0 USB3_RXP_0 GND USB3_RXN_1 USB3_RXP_1 GND USB3_RXN_2 USB3_RXP_2 GND USB3_RXN_3 USB3_RXP_3 GND NC NC
D1 D2 D3 D4 D5 D6 D7 D8 D9 D10 D11 D12 D13 D14 D15 D16
GND GND USB3_TXN_0 USB3_TXP_0 GND USB3_TXN_1 USB3_TXP_1 GND USB3_TXN_2 USB3_TXP_2 GND USB3_TXN_3 USB3_TXP_3 GND NC NC
C17 C18 C19 C20 C21 C22 C23 C24 C25
NC GND PCIE_RX_DP_7 PCIE_RX_DP#_7 GND PCIE_RX_DP_8 PCIE_RX_DP#_8 NC GND
D17 D18 D19 D20 D21 D22 D23 D24 D25
NC GND PCIE_TX_DP_7 PCIE_TX_DP#_7 GND PCIE_TX_DP_8 PCIE_TX_DP#_8 NC GND
ICE-BDE-T7 COM Express Module
Page 21
Pin No. Description Pin No. Description
C26 C27 C28 C29 C30 C31 C32 C33 C34 C35 C36 C37 C38 C39 C40 C41
NC NC GND NC NC GND D31 GND NC D32 LAN_FLSH_DI* NC D33 LAN_FLSH_CS_N* NC D34 NC NC D35 NC LAN_I2C_SDA* D36 10G_SFP+_Present_N* LAN_I2C_SCL* D37 10G_Baset_Present_N* LAN_MDC1_LED1_1* D38 LAN_FLSH_CLK* LAN_MDIO1_LED1_0* D39 LAN_FLSH_DO* LAN_SDP0_1* D40 LAN_SDP0_0* GND D41 GND
D26 D27 D28 D29 D30
NC NC GND NC NC
C42 C43 C44 C45 C46 C47 C48 C49 C50 C51 C52 C53 C54 C55 C56 C57
GBE_KR_RX1_P GBE_KR_RX1_N GND LAN_MDC0_LED0_1* LAN_MDIO0_ LED0_0* LAN_SDP1_1 GND GBE_KR_RX0_P GBE_KR_RX0_N GND PE1_RX_DP_0 PE1_RX_DN#_0 NC PE1_RX_DP_1 PE1_RX_DN#_1 NC
D42 D43 D44 D45 D46 D47 D48 D49 D50 D51 D52 D53 D54 D55 D56 D57
GBE_KR_TX1_P GBE_KR_TX1_N GND LAN_MDIO_DIR_CTL1 LAN_MDIO_DIR_CTL0 LAN_SDP1_0 GND GBE_KR_TX0_P GBE_KR_TX0_N GND PE1_TX_DP_0 PE1_TX_DN#_0 NC PE1_TX_DP_1 PE1_TX_DN#_1 NC
ICE-BDE-T7 COM Express Module
Page 22
Pin No. Description Pin No. Description
C58 C59 C60 C61 C62 C63 C64 C65 C66 C67 C68 C69 C70 C71 C72 C73
PE1_RX_DP_2 PE1_RX_DN#_2 GND PE1_RX_DP_3 PE1_RX_DN#_3 NC NC PE1_RX_DP_4 PE1_RX_DN#_4 NC PE1_RX_DP_5 PE1_RX_DN#_5 GND PE1_RX_DP_6 PE1_RX_DN#_6 GND
D58 D59 D60 D61 D62 D63 D64 D65 D66 D67 D68 D69 D70 D71 D72 D73
PE1_TX_DP_2 PE1_TX_DN#_2 GND21 PE1_TX_DP_3 PE1_TX_DN#_3 NC NC PE1_TX_DP_4 PE1_TX_DN#_4 GND PE1_TX_DP_5 PE1_TX_DN#_5 GND PE1_TX_DP_6 PE1_TX_DN#_6 GND
C74 C75 C76 C77 C78 C79 C80 C81 C82 C83 C84 C85 C86 C87 C88 C89
PE1_RX_DP_7 PE1_RX_DN#_7 GND NC PE1_RX_DP_8 PE1_RX_DN#_8 GND PE1_RX_DP_9 PE1_RX_DN#_9 NC GND PE1_RX_DP_10 PE1_RX_DN#_10 GND PE1_RX_DP_11 PE1_RX_DN#_11
D74 D75 D76 D77 D78 D79 D80 D81 D82 D83 D84 D85 D86 D87 D88 D89
PE1_TX_DP_7 PE1_TX_DN#_7 GND NC PE1_TX_DP_8 PE1_TX_DN#_8 GND PE1_TX_DP_9 PE1_TX_DN#_9 NC GND PE1_TX_DP_10 PE1_TX_DN#_10 GND PE1_TX_DP_11 PE1_TX_DN#_11
ICE-BDE-T7 COM Express Module
Page 23
Pin No. Description Pin No. Description
C90 C91 C92 C93 C94 C95 C96 C97 C98 C99 C100 C101 C102 C103 C104 C105
GND PE1_RX_DP_12 PE1_RX_DN#_12 GND PE1_RX_DP_13 PE1_RX_DN#_13 GND NC PE1_RX_DP_14 PE1_RX_DN#_14 GND PE1_RX_DP_15 PE1_RX_DN#_15 GND VCC_12V VCC_12V
D90 D91 D92 D93 D94 D95 D96 D97 D98 D99 D100 D101 D102 D103 D104 D105
GND PE1_TX_DP_12 PE1_TX_DN#_12 GND PE1_TX_DP_13 PE1_TX_DN#_13 GND NC PE1_TX_DP_14 PE1_TX_DN#_14 GND PE1_TX_DP_15 PE1_TX_DN#_15 GND VCC_12V VCC_12V
C106 C107 C108 C109 C110
VCC_12V VCC_12V VCC_12V VCC_12V GND
D106 D107 D108 D109 D110
VCC_12V VCC_12V VCC_12V VCC_12V GND
Table 3-3: COM Express C-D Connector Pin Definitions
ICE-BDE-T7 COM Express Module
Page 24

3.2.1 CPLD Programming Connector

CN Label: J_CPLD1 CN Type: CN Location: CN Pinouts:
8-pin header, p=2.5 4 mm See Figure 3-5 See Table 3-4
The CPLD programming connector location and pi nouts are shown below.
Figure 3-5: CPLD Programming Connector Location
Pin No. Description
1 2 3 4 5 6 7 8
VCC3.3SB CPLD_TDO CPLD_TDI NC NC CPLD_TMS GND CPLD_TCK
Table 3-4: CPLD Programming Connector Pin Definitions
ICE-BDE-T7 COM Express Module
Page 25
install two identical memory
, install it in the

3.2.2 DDR4 SO-DIMM Connectors

CN Label: DIMM1, DIMM2 CN Type: CN Location:
The SO-DIMM connectors are for installing DDR4 me m ory on the system.
260-pin DDR4 SO-DIMM connector See Figure 3-6
NOTE:
For dual channel configuration, always modules that feature the same capacity, timings, voltage, number of ranks and the same brand.
If there is only one memory module being installed
DIMM1 slot.
Figure 3-6: SO-DIMM Connector Locations
ICE-BDE-T7 COM Express Module
Page 26

3.2.1 Debug Port, LPC

CN Label: DBG_PORT1 CN Type: CN Location: CN Pinouts:
12-pin wafer , p=1.00 mm See Figure 3-7 See Table 3-5
The LPC debug port location and pinouts are shown below.
Figure 3-7: LPC Debug Port Location
Pin No. Description
1
NC
2 3 4 5 6 7 8 9 10 11 12
LPC_CLK_REF SYS_RESET# LPC_FRAME# LPC_AD0 LPC_AD1 LPC_AD2 LPC_AD3 INT_SERIRQ GND VCC3 NC
Table 3-5: LPC Debug Port Pin Definitions
ICE-BDE-T7 COM Express Module
Page 27

3.2.1 Debug Port, EC

CN Label: DBG_EC1 CN Type: CN Location: CN Pinouts:
The EC debug port location and pinouts are show n below.
Figure 3-8: EC Debug Port Location
Pin No. Description Pin No. Description
1 KSI0 11 KSO9
20-pin FPC, p=0.5 mm See Figure 3-8 See Table 3-6
2 KSO0 12 KSO10 3 KSO1 13 KSO12 4 KSO2 14 KSI1 5 KSO3 15 KSO11 6 KSO4 16 KSI2 7 KSO5 17 KSI3 8 KSO6 18 GND 9 KSO7 19 GND 10 KSO8 20 GND
Table 3-6: EC Debug Port Pin Definitions
ICE-BDE-T7 COM Express Module
Page 28

3.2.1 SPI Flash Connector, BIOS

CN Label: J_SPI1 CN Type: CN Location: CN Pinouts:
6-pin wafer, p=1. 25 m m See Figure 3-9 See Table 3-7
The BIOS SPI flash connector location and pinouts are shown below.
Figure 3-9: BIOS SPI Flash Connector Location
Pin No. Description
1 2 3 4 5 6
VCC1.8V CS MISO CLK MOSI GND
Table 3-7: BIOS SPI Flash Connector Pin Definitions
ICE-BDE-T7 COM Express Module
Page 29

3.2.1 SPI Flash Connector, EC

CN Label: J_EC1 CN Type: CN Location: CN Pinouts:
6-pin wafer, p=1. 25 m m See Figure 3-10 See Table 3-8
The EC SPI flash connector location and pinouts are shown below.
Figure 3-10: EC SPI Flash Connector Location
Pin No. Description
1 2 3 4 5 6
VCC3.3V CS MISO CLK MOSI GND
Table 3-8: EC SPI Flash Connector Pin Definitions
ICE-BDE-T7 COM Express Module
Page 30
Chapter
4

4 Installation

ICE-BDE-T7 COM Express Module
Page 31
Failure to take ESD precautions during the installation of the

4.1 Anti-static Precautions

WARNING:
ICE-BDE-T7 may result in permanent damage to the ICE-BDE-T7 and severe injury to the user.
Electrostatic discharge (ESD) can cause serious damage to electronic components, including the ICE-BDE-T7. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the ICE-BDE-T7 or any other electrical component is handled, the following anti-static precautions are strictly adhered to.
Wear an anti-static wristband: Wearing a simple anti-static wristband can
help to prevent ESD from damaging the board.
Self-grounding: Before handling the board, touch any grounded conducting
material. During the time the board is handled, f requently touch any conducting materials that are connected to the ground.
Use an anti-static pad: When configuring the ICE-BDE-T7, place it on an
antic-static pad. This reduces the possibility of ESD damaging the ICE-BDE-T7.
Only handle the edges of the PCB: When handling the PCB, hold the PCB
by the edges.

4.2 Installation Considerations

NOTE:
The following installation notices and installation considerations should be read and understood before installation. All instal l ation notices must be strictly adhered to. Failing to adhere to these precautions may lead to severe damage and injury to the person performing the installation.
ICE-BDE-T7 COM Express Module
Page 32
The installation instructions described in this manual should be
WARNING:
carefully followed in order to prevent damage to the components and injury to the user.
Before and during the installation please DO the following:
Read the user manual:
o The user manual provides a complete description of the ICE-BDE-T7
installation instructions and configuration opt i ons.
Wear an electrostatic discharge cuff (ESD):
o Electronic components are easily damaged by ESD. Wearing a n ESD cuff
removes ESD from the body and helps prevent ESD damage.
Place the ICE-BDE-T7 on an antistatic pad:
o When installing or configuring the motherboa rd, pl ace it on an antistatic
pad. This helps to prevent potential ESD damage.
Turn all power to t he ICE-BDE-T7 off:
o When working with the ICE-BDE-T7, make sure that it is disconnected
from all power supplies and that no elect ricity is b eing f ed into the sy stem.
Before and during the installation of the ICE-BDE-T7 DO NOT:
Remove any of the stickers on the PCB board. These st ickers a re required f or
warranty validation.
Use the product before verifying all the cables and power con nectors are
properly connected.
Allow screws to come in contact with t he PCB circuit, connector pins, or its
components.
ICE-BDE-T7 COM Express Module
Page 33
modules that feature the same capacity, timings, voltage, number of

4.3 SO-DIMM Installation

WARNING:
1. Using incorrectly specified SO-DIMM may cause permanent damage to the ICE-BDE-T7. Please make sure the purchased SO-DIMM complies with the memory specifications of t he ICE-BDE-T7. SO-DIMM specifications compliant with the ICE-BDE-T7 are listed in Chapter 1.
2. For dual channel configuration, always install two identical memory
ranks and the same brand.
To install a SO-DIMM into a SO-DIMM socket, please follow the steps below and refer to
Figure 4-1.
Figure 4-1: SO-DIMM Installation
Step 1: Locate the SO-DIMM socket. Place the ICE-BDE-T7 on an anti-static mat with
the front side facing up.
Step 2: Align the SO-DIMM with the socket. Align the notch on the memory with the
notch on the memory socket.
Step 3: Insert the SO-DIMM. Push the memory in at a 20º angle.
Step 4: Seat the SO-DIMM. Gently push downwards and the arms clip into place.
ICE-BDE-T7 COM Express Module
Page 34
Baseboard can be designed by the end user, customized by IEI, or
EI website
and a
must be installed on the

4.4 Mounting ICE-BDE-T7 to Baseboard

NOTE:
purchased from IEI. For more information visit the I (www.ieiworld.com) or contact an IEI sales representative.
WARNING:
Never run the COM Express module without the heatsink thermal pad. The thermal pad acts as a thermal interface between the module and the heatsink. The heatsink ICE-BDE-T7 to maintain proper operating temperatures. Make sure to maintain the heatsink temperature under 60°C i n operation.
Follow the steps below to install the ICE-BDE-T7 to the optional b aseboard.
Step 1: Align the two COM Express connector on the solder side of the ICE-BDE-T7
with the corresponding connector on the baseboard. Gently push the COM Express module down to ensure the connectors are properly connected (Figure 4-2).
ICE-BDE-T7 COM Express Module
Page 35
Figure 4-2: Connect the COM Express Connectors
Step 2: Ensure a thermal pad is placed on the CPU of the ICE-BDE-T7.
Step 3: Place the heatsink on the ICE-BDE-T7, aligning the retention screw holes
(Figure 4-3).
Step 4: Secure the heatsink to the ICE-BDE-T7 and the baseboard with the supplied
retention screws (Figure 4-3).
Figure 4-3: Secure the Heatsink
ICE-BDE-T7 COM Express Module
Page 36
Chapter
5

5 BIOS

ICE-BDE-T7 COM Express Module
Page 37
Some of the BIOS options may vary throughout the life cycle of the

5.1 Introduction

The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outli nes t he options that can be changed.
NOTE:
product and are subject to change without prior notice.

5.1.1 Starting Setup

The UEFI BIOS is activated when the computer is turned on. The setup program can be activated in one of two ways.
1. Press the D
2. Press the D appears on the screen. 0.
If the message disappears before the D and try again.
ELETE or F2 key as soon as the system is turned on or ELETE or F2 key when the “Press Del to enter SETUP” message
ELETE or F2 key is pressed, restart the computer

5.1.2 Using Setup

Use the arrow keys to highlight items, press ENTER to select, use the PageUp and PageDown keys to change entries, press F1 for help and press E keys are shown in.
Key Function
Up arrow Move to previous item Down arrow Move to next item Left arrow Move to the item on the left hand side
SC to quit. Navigation
Right arrow Move to the item on the right hand side + Increase the numeric value or make changes
ICE-BDE-T7 COM Express Module
Page 38
Key Function
- Decrease the numeric value or make change s F1 key General help, only for S t atus Page Set up Menu and Opt ion
F2 key Load previous values. F3 key Load optimized defaults F4 key Save changes and Exit BIOS Esc key Main Menu – Quit and not save changes into CMOS

5.1.3 Getting Help

Page Setup Menu
St atus Page Setup Menu and Option Page Setup Menu -­Exit current page and return to M ai n M enu
When F1 is pressed a small help window describing the appropriate keys to use and the possible selections for the highlighted item appears. To ex it the Help Window press E the F1 key again.

5.1.4 Unable to Reboot after Configuration Changes

If the computer cannot boot after changes to the system configuration is made, CMOS defaults.

5.1.5 BIOS Menu Bar

The menu bar on top of the BIOS screen has the foll owing main items:
Main – Changes the basic system configuration.  Advanced – Changes the advanced system settings.  Chipset – Changes the chip set settings.  Security – Sets User and Supervisor Passwords.  Boot – Changes the system boot configuration.
SC or
Save & Exit – Selects exit options and loads default set tings
The following sections completely describe the configuration options found in the menu items at the top of the BIOS screen and listed above.
ICE-BDE-T7 COM Express Module
Page 39
Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc.
Main
Advanced
IntelRCSetup
Server Mgmt
Security
Boot
Event Logs
Save & Exit
BIOS Information
ESC: Exit
Version 2.18.1260. Copyright (C) 2017 American Megatrends, Inc.

5.2 Main

The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered.
BIOS Vendor American Megatrends Core Version 5.11 Compliency UEFI 2.4; PI 1.3 Project Version B448AR10.ROM Build Date and Time 10/11/2017 18:57:13
iWDD Vendor iEi iWDD Version B448ET08.bin
Access Level Administrator
Memory Information Total Memory 16384 MB
System Date [Fri 01/01/2010] System Time [00:18:35]
BIOS Menu 1: Main
The System Overview field also has two user conf igurable fields:
System Date [xx/xx/xx]
Set the Date. Use Tab to switch between Data elements.
--------------------

: Select Screen
: Select Item Enter Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit
Use the System Date option to set the system date. Manually enter the day, month and year.
System Time [xx:xx:xx]
Use the System Time option to set the system time. Manually enter the hours, minutes and seconds.

5.3 Advanced

Use the Advanced menu (BIOS Menu 2) to configure the CPU and peripheral devices through the following sub-menus:
ICE-BDE-T7 COM Express Module
Page 40
Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc.
Main
Advanced
IntelRCSetup
Server Mgmt
Security
Boot
Event Logs
Save & Exit
ESC: Exit
Version 2.18.1260. Copyright (C) 2017 American Megatrends, Inc.
WARNING!
Setting the wrong values in the sections below may cause the system to malfunction. Make sure that the settings made are compatible with the hardware.
Auto Power Button Status [Disable (ATX)]
Restore AC Power Loss [Last State] > Trusted Computing > iWDD H/W Monitor > iWDD Super IO Configuration > RTC Wake Settings > Serial Port Console Redirection > USB Configuration > iEi Feature
BIOS Menu 2: Advanced
Restore AC Power Loss [Last State]
Use the Restore AC Power BIOS option to specify what state the system returns to if
Select AC power state when power is re-applied after a power failure.
--------------------

: Select Screen
: Select Item Enter Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit
there is a sudden loss of power to the system.
Power Off
Power On
Last State DEFAULT
The system remains turned off The system turns on The system returns to its previous state. If it was on, it
turns itself on. If it was off, it remains off.
ICE-BDE-T7 COM Express Module
Page 41
Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc.
Main
Advanced
IntelRCSetup
Server Mgmt
Security
Boot
Event Logs
Save & Exit
ESC: Exit
Version 2.18.1260. Copyright (C) 2017 American Megatrends, Inc.

5.3.1 Trusted Computing

Use the Trusted Computing menu (BIOS Menu 3) to configure settings related to the Trusted Computing Group (TCG) Trusted P l atform Module (TPM).
Configuration
Security Device Support [Disable]
No Security Device Found
BIOS Menu 3: Trusted Computing
Enables or Disables BIOS support for security device. O.S. will not show Security Device. TCG EFI protocol and INT1A interface will not be available.
--------------------

: Select Screen
: Select Item Enter Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit
Security Device Support [Disable]
Use the Security Device Support option to configu re support for the security device.
Disable D
Enable
EFAULT
Security device support is enabled.
Security device support is disabled.
ICE-BDE-T7 COM Express Module
Page 42
Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc.
Advanced
Version 2.18.1260. Copyright (C) 2017 American Megatrends, Inc.

5.3.2 iWDD H/W Monitor

The iWDD H/W Monitor menu (BIOS Menu 4) contains the fan configuration submenus and displays operating temperature, fan speeds and system voltages.
PC Health Status
CPU temperature :+43 °C System temperature :+33 °C
CPU_FAN1 Speed :2269 RPM
CPU_CORE :+1.791 V +5V :+5.023 V +12V :+11.806 V +DDR :+1.208 V +3.3V :+3.253 V +3.3VSB :+3.277 V
> Smart Fan Mode Configuration
BIOS Menu 4: iWDD H/W Monitor
PC Health St a tu s
The following system parameters and values are shown. The system parameters that are monitored are:
Smart Fan Mode Select
---------------------

: Select Screen
: Select Item Enter Select + - Change Opt. F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save & Exit ESC Exit
Temperature
o CPU temperature o System temperature
CPU Fan Speed  Voltages
o CPU_CORE o +5V o +12V o +DDR o +5VSB o +3.3V
ICE-BDE-T7 COM Express Module
Page 43
Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc.
Advanced
ESC Exit
Version 2.18.1260. Copyright (C) 2017 American Megatrends, Inc.
The fan adjusts its speed using these
o +3.3VSB
5.3.2.1 Smart Fan Mode Configuration
Use the Smart Fan Mode Configuration submenu (BIOS Menu 5) to configure fan temperature and speed settings.
Smart Fan Mode Configuration
CPU_FAN1 Smart Fan Control [Auto Mode] Auto mode fan start temperature 40 Auto mode fan off temperature 30 Auto mode fan start PWM 50 Auto mode fan slope PWM 2
BIOS Menu 5: Smart Fan Mode Configuration
CPU_FAN1 Smart Fan Control [Auto Mode]
Use the CPU_FAN1 Smart Fan Control BIOS option to configure the CPU Smart Fan.
Manual Mode
The fan spins at the speed set in the Manual
Smart Fan Mode Select
---------------------

: Select Screen
: Select Item Enter Select + - Change Opt. F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save & Exit
Auto Mode DEFAULT
Mode option
settings: Auto mode fan start temperature
Auto mode fan off temperature Auto mode fan start PWM
Auto mode fan slope PWM
ICE-BDE-T7 COM Express Module
Page 44
Auto mode fan start temperature [40]
WARNING:
Setting this value too high may cause the fan to rotate at full speed only when the CPU is at a very high temperature and therefore cause the system to be damaged.
The Auto mode fan start temperature option can only be set if the CPU_FAN1 Smart
Fan Control option is set to Auto Mode. If the system temperature is between Start Temperature and Off Temperature, the fan speed change to be Start PWM. To set a
value, select the Auto mode fan start temperature option and enter a decimal number between 1 and 100.
Auto mode fan off temperature [30]
WARNING:
Setting this value too high may cause the fan to speed up only when the CPU is at a very high temperature and therefore cause the system to be damaged.
The Auto mode fan off temperature o ption can onl y be set if t he CPU_FAN1 Smart Fan
control option is set to Auto Mode. If the system temperature is lower than Auto mode fan off temperature, the fan speed change to be lowest. To set a value, select the Auto mode fan off temperature option and enter a decimal number between 1 and 100.
Auto mode fan start PWM [50]
The Auto mode fan start PWM option can only be set if the CPU_FAN1 Smart Fan control option is set to Auto Mode. Use the Auto mode fan start PWM option to set the
PWM start value. To set a value, select the Auto m od e fan start PWM option and enter a decimal number between 1 and 100.
ICE-BDE-T7 COM Express Module
Page 45
Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc.
Advanced
Version 2.18.1260. Copyright (C) 2017 American Megatrends, Inc.
Auto mode fan slope PWM [2]
The Auto mode fan slope PWM option can only be set if the CPU_FAN1 Smart Fan control option is set to Auto Mode. Use the Auto mode fan slope PWM option to select
the linear rate at which the PWM mode increases with respect to an increase in temperature. To set a value, select the Auto mode fan slope PWM option and enter a decimal number between 1 and 8.

5.3.3 iWDD Super IO Configuration

Use the iWDD Super IO Configuration menu (BIOS Menu 6) to set or change the configurations for the serial ports.
iWDD Super IO Configuration
Super IO Chip iWDD
> Serial Port 1 Configuration > Serial Port 2 Configuration
BIOS Menu 6: iWDD Super IO Configuration
Set Parameters of Serial Port 1 (COMA)
---------------------

: Select Screen
: Select Item Enter Select F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save ESC Exit
ICE-BDE-T7 COM Express Module
Page 46
Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc.
Advanced
ESC Exit
Version 2.18.1260. Copyright (C) 2017 American Megatrends, Inc.
5.3.3.1 Serial Port n Configuration
Use the Serial Port n Configuration menu (BIOS Menu 7) to configure the serial port n.
Serial Port 1 Configuration
Serial Port [Enabled]
Device Settings IO=3F8h; IRQ=4
Change Settings [Auto]
BIOS Menu 7: Serial Port n Configuration
5.3.3.1.1 Serial Port 1 Configuration
Serial Port [Enabled]
Use the Serial Port option to enable or disable the serial port.
Enable or Disable Serial Port (COM)
---------------------

: Select Screen
: Select Item Enter Select F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save
Disabled
Enabled DEFAULT
Change Settings [Auto]
Use the Change Settings option to change the serial port IO port address and interrupt address.
Auto DEFAULT
IO=3F8h; IRQ=4
Disable the serial port
Enable the serial port
The serial port IO port address and interrupt address are automatically detected.
Serial Port I/O port address is 3F8h and the interrupt address is IRQ4
ICE-BDE-T7 COM Express Module
Page 47
IO=3F8h; IRQ=3,
IO=2F8h; IRQ=3,
8h; IRQ=3,
8h; IRQ=3,
IO=3F8h; IRQ=3,
IO=2F8h; IRQ=3,
8h; IRQ=3,
4,5,6,7,9,10,11,12
4,5,6,7,9,10,11,12
IO=3E 4,5,6,7,9,10,11,12
IO=2E 4,5,6,7,9,10,11,12
Serial Port I/O port address is 3F8h and the interrupt address is IRQ3,4,5,6,7,9,10,11,12
Serial Port I/O port address is 2F8h and the interrupt address is IRQ3,4,5,6,7,9,10,11,12
Serial Port I/O port address is 3E8h and the interrupt address is IRQ3,4,5,6,7,9,10,11,12
Serial Port I/O port address is 2E8h and the interrupt address is IRQ3,4,5,6,7,9,10,11,12
5.3.3.1.2 Serial Port 2 Configuration
Serial Port [Enabled]
Use the Serial Port option to enable or disable the serial port.
Disabled
Disable the serial port
Enabled DEFAULT
Change Settings [Auto]
Use the Change Settings option to change the serial port IO port address and interrupt address.
Auto DEFAULT
IO=2F8h; IRQ=3
4,5,6,7,9,10,11,12
4,5,6,7,9,10,11,12
IO=3E
Enable the serial port
The serial port IO port address and interrupt address are automatically detected.
Serial Port I/O port address is 2F8h and the interrupt address is IRQ3
Serial Port I/O port address is 3F8h and the interrupt address is IRQ3,4,5,6,7,9,10,11,12
Serial Port I/O port address is 2F8h and the interrupt address is IRQ3,4,5,6,7,9,10,11,12
Serial Port I/O port address is 3E8h and the
4,5,6,7,9,10,11,12
interrupt address is IRQ3,4,5,6,7,9,10,11,12
ICE-BDE-T7 COM Express Module
Page 48
8h; IRQ=3,
Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc.
Advanced
ESC Exit
Version 2.18.1260. Copyright (C) 2017 American Megatrends, Inc.
The real time clock (RTC) cannot generate a wake
appear with values that can be
IO=2E 4,5,6,7,9,10,11,12

5.3.4 RTC Wake Settings

The RTC Wake Settings menu (BIOS Menu 8) conf igure s RTC wake event .
Wake system with Fixed Time [Disabled]
Serial Port I/O port address is 2E8h and the interrupt address is IRQ3,4,5,6,7,9,10,11,12
Enable or disable System wake on alarm event. When enabled, System will wake on the date::hr::min::sec specified
----------------------

: Select Screen
: Select Item Enter Select F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save
BIOS Menu 8: RTC Wake Settings
Wake system with Fixed Time [Disabled]
Use the Wake system with Fixed Time option to enable or disable the system wake on alarm event.
Disabled D
Enabled
EFAULT
event If selected, the Wake up every day option appears
allowing you to enable to disable the sy st em t o wake every day at the specified time. Besides, the following options selected:
ICE-BDE-T7 COM Express Module
Page 49
After setting the alarm, the computer turns itself on
Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc.
Advanced
ESC Exit
Version 2.18.1260. Copyright (C) 2017 American Megatrends, Inc.

5.3.5 Serial Port Console Redirection

The Serial Port Console Redirection menu (BIOS Menu 9) allows the console redirection options to be configured. Console redirection allows users to maintain a system remotely by re-directing keyboard input and te xt output through the serial port.
Wake up date Wake up hour Wake up minute Wake up second
from a suspend state when the alarm g oes off.
COM1
Console Redirection [Disabled]
> Console Redirection Settings
COM2
Console Redirection [Disabled]
> Console Redirection Settings
Legacy Console Redirection
> Legacy Console Redirection Settings
BIOS Menu 9: Serial Port Console Redirection
Console Redirection Enable or Disable
---------------------

: Select Screen
: Select Item Enter Select F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save
ICE-BDE-T7 COM Express Module
Page 50
Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc.
Advanced
Version 2.17.1255. Copyright (C) 2016 American Megatrends, Inc.
Console Redirection [Disabled]
Use Console Redirection option to enable or disable the con sole redirection function.
Disabled DEFAULT
Enabled
Disabled the console redirection function Enabled the console redirection function
5.3.5.1 Legacy Console Redirection Settings
The Legacy Console Redirection Settings menu (BIOS Menu 10) allows the legacy console redirection options to be configured.
Legacy Serial Redirection Port [COM1]
Select a COM port to display redirection of Legacy OS and Legacy OPROM Messages
---------------------

: Select Screen
: Select Item Enter Select F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save ESC Exit
BIOS Menu 10: Legacy Console Redirection Settings
Legacy Serial Redirection Port [COM1]
Use the Legacy Serial Redirection Port option to specify a COM port to display redirection of legacy OS and legacy OPROM mes sages. The options include:
COM1 D COM2
EFAULT
ICE-BDE-T7 COM Express Module
Page 51
Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc.
Advanced
support color, function
Unicode chars onto 1 or
Version 2.17.1255. Copyright (C) 2016 American Megatrends, Inc.
5.3.5.2 Console Redirection Settings
The Console Redirection Settings menu (BIOS Menu 11) allows the console redirection options to be configured. The option is activ e when Console Redirection option is enabled.
COM1 Console Redirection Settings
Terminal Type [ANSI] Bits per second [115200] Data Bits [8] Parity [None] Stop Bits [1]
BIOS Menu 11: Console Redirection Settings
Emulation: ANSI: Extended ASCII char set. VT100: ASCII char set. VT100+: Extends VT100 to
keys, etc. VT-UTF8: Uses UTF8 encoding to map
more bytes.
---------------------

: Select Screen
: Select Item Enter Select F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save ESC Exit
Terminal Type [ANSI]
Use the Terminal Type option to specify the remote terminal type.
VT100
VT100+
VT-UTF8
ANSI DEFAULT
The target terminal type is VT100 The target terminal type is VT100+ The target terminal type is VT-UTF8 The target terminal type is ANSI
ICE-BDE-T7 COM Express Module
Page 52
This option does not
This option does not
Bits per second [115200]
Use the Bits per second option to specify the serial port transmission speed. The speed must match the other side. Long or noisy lines may require lower speeds.
9600
19200
38400
57600
115200 DEFAULT
Data Bits [8]
Use the Data Bits option to specify the number of data bits.
7
8 DEFAULT
Parity [None]
Use the Parity option to specify the parity bit that can be sent with the data bits for
Sets the serial port transmission speed at 9600. Sets the serial port transmission speed at 19200. Sets the serial port transmission speed at 38400. Sets the serial port transmission speed at 57600. Sets the serial port transmission speed at 115200.
Sets the data bits at 7. Sets the data bits at 8.
detecting the transmission errors.
None DEFAULT
Even
Odd
Mark
Space
No parity bit is sent with the data bits. The parity bit is 0 if the number of ones in the data
bits is even. The parity bit is 0 if the number of ones in the data
bits is odd. The parity bit is always 1.
provide error detection. The parity bit is always 0.
provide error detection.
ICE-BDE-T7 COM Express Module
Page 53
Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc.
Advanced
disables legacy support
ESC Exit
Version 2.18.1260. Copyright (C) 2017 American Megatrends, Inc.
Stop Bits [1]
Use the Stop Bits option to specify the number of stop bits used to indicate the end of a serial data packet. Communication with slo w devices may require more than 1 stop bit.
1 DEFAULT
2
Sets the number of stop bit s at 1. Sets the number of stop bit s at 2.

5.3.6 USB Configuration

Use the USB Configuration menu (BIOS Menu 12) to read USB configuration information and configure the USB settings.
USB Configuration
USB Controllers: 1 EHCI, 1 XHCI USB Devices: 1 Keyboard, 2 Hubs
Legacy USB Support [Enabled]
Enables Legacy USB support. AUTO option
if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications.
---------------------

: Select Screen
: Select Item Enter Select F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save
BIOS Menu 12: USB Configuration
USB Devices
The USB Devices Enabled field lists the USB devices that are enabled on the system
ICE-BDE-T7 COM Express Module
Page 54
Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc.
Advanced
crashes. Please install
g
ESC Exit
Version 2.18.1260. Copyright (C) 2017 American Megatrends, Inc.
Legacy USB Support [Enabled]
Use the Legacy USB Support BIOS option to enable USB mouse and USB keyboard support. Normally if this option is not enable d, any a t tached USB m ouse o r US B key board does not become available until a USB comp atible operat ing syst em is fully boot ed with all USB drivers loaded. When this option is enabled, any attached USB mouse or USB keyboard can control the system even when there is no USB driver loaded onto the system.

5.3.7 IEI Feature

Use the IEI Feature menu (BIOS Menu 13) to configure One Key Recovery function.
iEi Feature
Auto Recovery Function [Disabled]
Enabled DEFAULT
Disabled
Auto
Legacy USB support enabled Legacy USB support disabled Legacy USB support disabled if no USB devices are
connected
Auto Recovery Function Reboot and recover system automatically within 10 min, when OS
Auto Recovery API service before enablin this function
----------------------

: Select Screen
: Select Item Enter Select F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save
BIOS Menu 13: IEI Feature
ICE-BDE-T7 COM Express Module
Page 55
Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc.
Main
Advanced
IntelRCSetup
Server Mgmt
Security
Boot
Event Logs
Save & Exit
ESC: Exit
Version 2.18.1260. Copyright (C) 2017 American Megatrends, Inc.
Auto Recovery Function [Disabled]
Use the Auto Recovery Function BIOS option to enable or disable the auto recovery function of the IEI One Key Recovery.
Disabled DEFAULT
Enabled

5.4 IntelRCSetup

Use the IntelRCSetup menu (BIOS Menu 14) to configure the system processor and chipset.
> Processor Configuration > IIO Configuration > PCH Configuration
Auto recovery function disabled Auto recovery function enabled
Displays and provides option to change the Processor Settings
--------------------

: Select Screen
: Select Item Enter Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit
BIOS Menu 14: IntelRCSetup
ICE-BDE-T7 COM Express Module
Page 56
Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc.
IntelRCSetup
Version 2.18.1260. Copyright (C) 2017 American Megatrends, Inc.

5.4.1 Processor Configuration

Use the Processor Configuration menu (BIOS Menu 15) to view detailed CPU specifications and configure the CPU.
CPU Configuration
-------------------------------------------­Processor Socket Socket 0 Processor ID 00050663* Processor Frequency 2.200GHz Processor Max Ratio 16H Processor Min Ratio 08H Microcode Revision 0700000C L1 Cache RAM 256KB L2 Cache RAM 1024KB L3 Cache RAM 6144KB Processor 0 Version Intel(R) Xeon(R) D­ 1518 @ 2.20GHz
Hyper-Threading [Enable] Intel TXT [Disable] VMX [Disable] EIST [Enable] CPU C state [Disable]
BIOS Menu 15: Processor Configuration
Hyper-Threading [Enable]
Enable Hyper Threading (Software Method to Enable/Disable Logical Processor threads.)
---------------------

: Select Screen
: Select Item Enter Select + - Change Opt. F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save & Exit ESC Exit
Use the Hyper-Threading to enable or disable the CPU hyper t hreading function.
Disable
Enable DEFAULT
Disables the use of hyper threading technology Enables the use of hyper threading technology
ICE-BDE-T7 COM Express Module
Page 57
Trusted Execution
Intel TXT [Disable]
Use the Intel TXT BIOS option to enable or disable Intel® Trusted Execution Technology.
Disable DEFAULT
Enable
VMX [Disable]
Use the VMX option to enable or disable virtualization on the system. When combined with third party software, Intel same system at the same time.
Disable DEFAULT
Enable
EIST [Enable]
Use the EIST option to enable or disable the Intel® SpeedStep Technology.
®
Virtualization technology allows several OSs to run on the
Disables the use of Intel® technology
Enables the use of Intel technology
Disables Intel Enables Intel
®
Virtualization Technology.
®
Virtualization Technology.
®
Trusted Execution
Disable DEFAULT
Enable
CPU C State [Disable]
Use the CPU C State option to enable or disable CPU C state.
Disable DEFAULT
Enable
Disables the Intel Enables the Intel
Disables CPU C state. Enables CPU C state.
®
SpeedStep Technology .
®
SpeedStep Technology.
ICE-BDE-T7 COM Express Module
Page 58
Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc.
IntelRCsetup
ESC Exit
Version 2.18.1260. Copyright (C) 2017 American Megatrends, Inc.
Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc.
IntelRCsetup
ESC Exit
Version 2.18.1260. Copyright (C) 2017 American Megatrends, Inc.

5.4.2 IIO Configuration

Use the IIO Configuration menu (BIOS Menu 16) to configure the IIO parameters.
IIO Configuration
------------------------------------------
> IIO Configuration > Intel VT for Directed I/O (VT-d) > IIO South Complex Configuration
BIOS Menu 16: IIO Configuration
5.4.2.1 IIO0 Configuration
Use the IIO0 Configuration submenu (BIOS Menu 17) to configure the PCI Express slots from IIO.
---------------------

: Select Screen
: Select Item Enter Select + - Change Opt. F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save & Exit
> PCIEX8_1 > PCIEX16
BIOS Menu 17: IIO0 Configuration
Settings related to PCI Express Ports
---------------------

: Select Screen
: Select Item Enter Select + - Change Opt. F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save & Exit
ICE-BDE-T7 COM Express Module
Page 59
Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc.
IntelRCSetup
ESC Exit
Version 2.18.1260. Copyright (C) 2017 American Megatrends, Inc.
The PCIe slot submenus all contain the following options:
Link Speed [Auto]
Use the Link Speed option to configure the PCIe int erface speed.
Auto D Gen 1 (2.5 GT/s)  Gen 2 (5 GT/s)  Gen 3 (8 GT/s)
EFAULT
5.4.2.2 Intel VT for Directed I/O (VT-d)
Use the Intel VT for Directed I/O (VT-d) submenu (BIOS Menu 18) to configure the VT-d settings.
Intel VT for Directed I/O (VT-d)
---------------------------------------------
Intel VT for Directed I/O (VT-d) [Disable]
Enable/Disable Intel Virtualization Technology for Directed I/O (VT-d) by reporting the I/O device assignment to VMM through DMAR ACPI Tables.
---------------------

: Select Screen
: Select Item Enter Select + - Change Opt. F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save & Exit
BIOS Menu 18: Intel VT for Directed I/O (VT-d)
ICE-BDE-T7 COM Express Module
Page 60
Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc.
IntelRCSetup
Version 2.18.1260. Copyright (C) 2017 American Megatrends, Inc.
VT-d Intel VT for Directed I/O (VT-d) [Disable]
Use the Intel VT for Directed I/O (VT-d) option to enable or disable VT-d support.
Disable DEFAULT
Enable
Disable VT-d sup port. Enable VT-d support.
5.4.2.3 IIO South Complex Configuration
Use the IIO South Complex submenu (BIOS Menu 19) to configure South Complex settings.
IIO South Complex Configuration
---------------------------------------------
Disable SC GbE [Disable]
Disables South Complex GbE completely.
---------------------

: Select Screen
: Select Item Enter Select + - Change Opt. F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save & Exit ESC Exit
BIOS Menu 19: IIO South Complex Configuration
Disable SC GbE [Disable]
Use the Disable SC GbE option to completely enable or disable GbE.
Disable DEFAULT
Enable
Disable GbE completely. Enable GbE completely.
ICE-BDE-T7 COM Express Module
Page 61
Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc.
IntelRCSetup
ESC Exit
Version 2.18.1260. Copyright (C) 2017 American Megatrends, Inc.
Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc.
IntelRCsetup
ESC Exit
Version 2.18.1260. Copyright (C) 2017 American Megatrends, Inc.

5.4.3 PCH Configuration

Use the PCH Configuration menu (BIOS Menu 20) to configure the PCH chipset.
PCH Configuration
---------------------------------------------
> PCI Express Configuration > PCH SATA Configuration
BIOS Menu 20: PCH Configuration
5.4.3.1 PCI Express Configuration
Use the PCI Express Configuration submenu (BIOS Menu 21) to configure the PCI Express slots from PCH.
PCI Express Configuration settings
---------------------

: Select Screen
: Select Item Enter Select + - Change Opt. F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save & Exit
> PCIEX1 > PCIEX2 > PCIEX4_1
BIOS Menu 21: PCI Express Configuration
PCIE1 Settings
---------------------

: Select Screen
: Select Item Enter Select + - Change Opt. F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save & Exit
ICE-BDE-T7 COM Express Module
Page 62
Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc.
IntelRCsetup
ESC Exit
Version 2.18.1260. Copyright (C) 2017 American Megatrends, Inc.
The PCIe slot submenus all contain the following options:
PCIe Speed [Auto]
Use the PCIe Speed option to configure the PCIe interface speed.
Auto D Gen 1  Gen 2
EFAULT
5.4.3.2 PCH SATA Configuration
Use the PCH SATA Configuration menu (BIOS Menu 22) to change and/or set the configuration of the SATA devices installed in the sy stem.
PCH SATA Configuration
---------------------------------------------
STAT Controller [Enabled] Configure SATA as [AHCI]
SATA1 [Not Installed]
Hot Plug [Disabled]
SATA2 [Not Installed]
Hot Plug [Disabled]
Enable or Disable SATA Controller
---------------------

: Select Screen
: Select Item Enter Select + - Change Opt. F1 General Help F2 Previous Values F3 Optimized Defaults F4 Save & Exit
BIOS Menu 22: PCH SATA Configuration
STAT Controller [Enabled]
Use the STAT Controller option to enable or disable the SATA device.
Disabled
Enabled DEFAULT
Disables the SATA device. Enables the SATA device.
ICE-BDE-T7 COM Express Module
Page 63
Configure SATA as [AHCI]
Use the Configure SATA as option to configure SATA devices as IDE, AH CI or RAID devices.
IDE
AHCI DEFAULT
RAID
Configures SATA devices as IDE device. Configures SATA devices as AHCI device. Configures SATA devices as RAID device.
Hot Plug [Disabled]
Use the Hot Plug option to enable or disable the SATA device hot plug.
Disabled DEFAULT
Enabled
Disables the SATA device hot plug. Enables the SATA device hot plug
ICE-BDE-T7 COM Express Module
Page 64
Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc.
Main
Advanced
IntelRCSetup
Server Mgmt
Security
Boot
Event Logs
Save & Exit
ESC: Exit
Version 2.18.1260. Copyright (C) 2017 American Megatrends, Inc.

5.5 Server Management

Use the Server Management menu (BIOS Menu 23) to display the server management status and change the settings.
BMC Self Test Status FAILED BMC Firmware Revision Unknown
> System Event Log
BIOS Menu 23: Server Management

5.5.1 System Event Log

Use the System Event Log submenu (BIOS Menu 24) to configure the System Event
Press <Enter> to change the SEL event log configuration.
--------------------

: Select Screen
: Select Item Enter Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit
Log (SEL) options.
ICE-BDE-T7 COM Express Module
Page 65
Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc.
Server Mgmt
disable all features of
ESC: Exit
Version 2.18.1260. Copyright (C) 2017 American Megatrends, Inc.
Enabling/Disabling Options
SEL Components [Enabled]
Erase Settings
Erase SEL [No] When SEL is Full [Do Nothing]
NOTE: All values changed here do not take effect until computer is restarted.
BIOS Menu 24: System Event Log
SEL Components [Enabled]
Use the SEL Components option to enable or disable all feat ures of System Event Log.
Change this to enable or
System Event Logging during boot.
---------------------

: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit
Erase SEL [No]
Use the Erase SEL option to determine whether to erase SEL or not. The following options are available:
Disabled
Enabled DEFAULT
NOTE:
The following two items will be available to configure when the SEL Components is enabled.
No Default Yes, On next reset  Yes, On every reset
Disables SEL Enables SEL
ICE-BDE-T7 COM Express Module
Page 66
Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc.
Main
Advanced
IntelRCSetup
Server Mgmt
Security
Boot
Event Logs
Save & Exit
ESC: Exit
Version 2.18.1260. Copyright (C) 2017 American Megatrends, Inc.
When SEL is full [Do Nothing]
Use the When SEL is Full option to determine the action to be taken when SEL is full. The following options are available:
Do Nothing Default Erase Immediately

5.6 Security

Use the Security menu (BIOS Menu 25) to set system and user passwords.
Password Description
If ONLY the Administrator’s password is set, then this only limits access to Setup and is only asked for when entering Setup If ONLY the User’s password is set, then this is a power on password and must be entered to boot or enter Setup. In Setup the User will have Administrator rights. The password length must be: Minimum length 3 Maximum length 20
Administrator Password User Password
BIOS Menu 25: Security
Administrator Password
Use the Administrator Password to set or change a administrator password.
Set Administrator Password
--------------------

: Select Screen
: Select Item Enter Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit
User Password
Use the User Password to set or change a user pass word.
ICE-BDE-T7 COM Express Module
Page 67
Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc.
Main
Advanced
IntelRCSetup
Server Mgmt
Security
Boot
Event Logs
Save & Exit
ESC: Exit
Version 2.18.1260. Copyright (C) 2017 American Megatrends, Inc.
Allows the Number Lock on the keyboard to be enabled automatically when the computer system
iate use of the
the keyboard. To confirm this, the Number Lock LED

5.7 Boot

Use the Boot menu (BIOS Menu 26) to configure system boot options.
Boot Configuration
Bootup NumLock State [On] Quiet Boot [Enabled] UEFI Boot [Disabled]
Driver Option Riorities
Launch PXE OpROM [Disabled] Option ROM Messages [Force BIOS]
Boot Option Priorities
BIOS Menu 26: Boot
Bootup NumLock State [On]
Use the Bootup NumLock State BIOS option to specify if the number lock setting must be modified during boot up.
Select the keyboard NumLock state
--------------------

: Select Screen
: Select Item Enter Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit
On DEFAULT
boots up. This allows the immed 10-key numeric keypad located on the right side of
light on the keyboard is lit.
ICE-BDE-T7 COM Express Module
Page 68
Does not enable the keyboard Number Lock
e Number Lock key located on the upper
key pad. The Number
Lock LED on the keyboard lights up when the
Off
automatically. To use the 10-keys on the keyboard, press th left-hand corner of the 10-
Number Lock is engaged.
Quiet Boot [Enabled]
Use the Quiet Boot BIOS option to select the scre en display when the system boots.
Disabled
Enabled DEFAULT
UEFI Boot [Disabled]
Use the UEFI Boot option to enable or disable to boot from the UEFI devices.
Enabled
Disabled DEFAULT
Launch PXE OpROM [Disabled]
Use the Launch PXE OpROM option to enable or disable boot option for legacy network devices.
Disabled DEFAULT
Enabled
Normal POST messages displayed OEM Logo displayed instead of POST m essages
Boot from UEFI devices is enabled. Boot from UEFI devices is disabled.
Ignore all PXE Option ROMs Load PXE Option ROMs.
Option ROM Messages [Force BIOS]
Use the Option ROM Messages option to set the Option ROM display mode.
Force BIOS
DEFAULT
Sets display mode to force BIOS.
ICE-BDE-T7 COM Express Module
Page 69
Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc.
Main
Advanced
IntelRCSetup
Server Mgmt
Security
Boot
Event Logs
Save & Exit
ESC: Exit
Version 2.18.1260. Copyright (C) 2017 American Megatrends, Inc.
Keep Current
Boot Option Priority
Use the Boot Option Priority function to set the system boot sequence from the available devices. The drive sequence also depends on the boot sequence in the individual device section.

5.8 Save & Exit

Use the Save & Exit menu (BIOS Menu 27) to load default BIOS values, optimal failsafe values and to save configuration changes.
Save Changes and Reset Discard Changes and Reset
Restore Defaults Save as User Defaults Restore User Defaults
Sets display mode to current.
Reset the system after saving the changes.
--------------------

: Select Screen
: Select Item Enter Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit
BIOS Menu 27: Save & Exit
Save Changes and Reset
Use the Save Changes and Reset option to save the changes made to the BIOS options and to exit the BIOS configuration setup program.
ICE-BDE-T7 COM Express Module
Page 70
Discard Changes and Reset
Use the Discard Changes and Reset option to exit the system without saving the changes made to the BIOS configuration setup program.
Restore Defaults
Use the Restore Defaults option to load the optimal default values for each of the parameters on the Setup menus. F3 key can be used for this op eration.
Save as User Defaults
Use the Save as User Defaults option to save the changes done so far as user defaults.
Restore User Defaults
Use the Restore User Defaults option to restore the user defaults to all the setu p options.
ICE-BDE-T7 COM Express Module
Page 71
Chapter
6

6 Software Drivers

ICE-BDE-T7 COM Express Module
Page 72
NOTE:
The content of the CD may vary throughout the life cycle of the product and is subject to change without prior notice. Visit the IEI website or contact technical support for the latest updat es.

6.1 Software Installation

All the drivers for the ICE-BDE-T7 are on the CD that came with the system. To install the drivers, please follow the steps below.
Step 1: Insert the CD that came with the system into a CD drive connected to the
system.
NOTE:
If the installation program doesn't start a utomatically: Click "Start->Computer->CD Drive->autorun.exe"
Step 2: The driver main menu appears.
Step 3: Click ICE-BDE-T7.
Step 4: The list of drivers appears.
Step 5: Install all of the necessary drivers in the menu.
ICE-BDE-T7 COM Express Module
Page 73
Appendix
A

A Regulatory Compliance

ICE-BDE-T7 COM Express Module
Page 74
other devices in the equipment, the CE conformity
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
ent generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this
DECLARATION OF CONFORMITY
This equipment has been tested and f ound to com ply with specifi cations f or CE marking. If the user modifies and/or installs declaration may no longer apply.
FCC WARNING
This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
This device may not cause harmful interference, and This device must accept any interfer ence received, including interference
that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class A digital
reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipm
equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
ICE-BDE-T7 COM Express Module
Page 75
Appendix
B

B Product Disposal

ICE-BDE-T7 COM Express Module
Page 76
Dispose of used batteries according to instructions and local
CAUTION:
Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery.
regulations.
Outside the European UnionIf you wish to dispose of used electrical and
electronic products out sid e the European Union, please contact your local authority so as to comply with the correct dispo sal m ethod.
Within the European UnionThe device that produces less waste and is
easier to recycle is classified as electronic device in terms of the E uropean Directive 2012/19/EU (WEEE), and must not be disposed of as domestic garbage.
EU-wide legislation, as implemented in each Member State, requires that waste electrical and electronic products carrying the mark (left) must be disposed of separately from normal household waste. This includes monitors and electrical accessories, such as signal cables or power
cords. When you need to dispose of your device, please follow the guidance of your local authority, or ask the shop where you purchased the product. The mark on electrical and electronic products only applies to the current European Union Member States.
Please follow the national guidelines for elect rical and electronic product disposal.
ICE-BDE-T7 COM Express Module
Page 77
Appendix
C

C BIOS Options

ICE-BDE-T7 COM Express Module
Page 78
Below is a list of BIOS configuration options in the B IOS chapter.
System Date [xx/xx/ xx] ........................................................................................................ 39
System Time [xx:xx:xx] ....................................................................................................... 39
Restore AC Power Loss [Last State] ................................................................................. 40
Security Device Support [Disable] ..................................................................................... 41
PC Health Status .................................................................................................................. 42
CPU_FAN1 Smart Fan Control [Auto Mode] ..................................................................... 43
Auto mode fan start temperature [40] ................................................................................ 44
Auto mode fan off temperature [30] ................................................................................... 44
Auto mode fan start PWM [50] ............................................................................................ 44
Auto mode fan slope PWM [2] ............................................................................................ 45
Serial Port [Enabled] ............................................................................................................ 46
Change Settings [Auto] ....................................................................................................... 46
Serial Port [Enabled] ............................................................................................................ 47
Change Settings [Auto] ....................................................................................................... 47
Wake system with Fixed Time [Disabled] .......................................................................... 48
Console Redirection [Disabled] ......................................................................................... 50
Legacy Serial Redirection Port [COM1] ............................................................................. 50
Terminal Type [ANSI] ........................................................................................................... 51
Bits per second [115200] ..................................................................................................... 52
Data Bits [8] .......................................................................................................................... 52
Parity [None] ......................................................................................................................... 52
Stop Bits [1] .......................................................................................................................... 53
USB Devices ......................................................................................................................... 53
Legacy USB Support [Enabled] .......................................................................................... 54
Auto Recovery Function [Disabled] ................................................................................... 55
Hyper-Threading [Enable] ................................................................................................... 56
Intel TXT [Disable] ................................................................................................................ 57
VMX [Disable] ....................................................................................................................... 57
EIST [Enable] ........................................................................................................................ 57
CPU C State [Disable] .......................................................................................................... 57
Link Speed [Auto] ................................................................................................................ 59
VT-d Intel VT for Directed I/O (VT-d) [Disable] .................................................................. 60
Disable SC GbE [Disable] .................................................................................................... 60
ICE-BDE-T7 COM Express Module
Page 79
PCIe Speed [Auto] ................................................................................................................ 62
STAT Controller [Enabled] .................................................................................................. 62
Configure SATA as [AHCI] .................................................................................................. 63
Hot Plug [Disabled] .............................................................................................................. 63
SEL Components [Enabled] ................................................................................................ 65
Erase SEL [No] ..................................................................................................................... 65
When SEL is full [Do Nothing] ............................................................................................ 66
Administrator Password ..................................................................................................... 66
User Password ..................................................................................................................... 66
Bootup NumLock State [On] ............................................................................................... 67
Quiet Boot [Enabled] ........................................................................................................... 68
UEFI Boot [Disabled] ........................................................................................................... 68
Launch PXE OpROM [Disabled] ......................................................................................... 68
Option ROM Messages [Force BIOS] ................................................................................. 68
Boot Option Priority ............................................................................................................. 69
Save Changes and Reset .................................................................................................... 69
Discard Changes and Reset ............................................................................................... 70
Restore Defaults .................................................................................................................. 70
Save as User Defaults ......................................................................................................... 70
Restore User Defaults ......................................................................................................... 70
ICE-BDE-T7 COM Express Module
Page 80
Appendix
D

D Digital I/O Interface

ICE-BDE-T7 COM Express Module
Page 81
The DIO connector on the ICE-BDE-T7 is interfaced to GPIO ports on the Super I/O chipset. The DIO has both 8-bit digital inputs and 8-bit digital outputs. The digital inputs and digital outputs are generally control signals that control the on/off circuit of external devices or TTL devices. Data can be read or written to the selected address to enable the DIO functions.
NOTE:
For further information, please refer to the datasheet for the Super I/O chipset.
The BIOS interrupt call INT 15H controls the digital I/O .
INT 15H:
AH – 6FH
Sub-function:
AL – 8 :Set the digital port as INPUT AL :Digital I/O input value
Assembly Language Sample 1
MOV AX, 6F08H ;setting the digital port as input INT 15H ;
AL low byte = value
ICE-BDE-T7 COM Express Module
Page 82
AH – 6FH
Sub-function:
AL – 9 :Set the digital port as OUTPUT BL :Digital I/O output value
Assembly Language Sample 2
MOV AX, 6F09H ;setting the digital port as output MOV BL, 09H ;digital value is 09H INT 15H ;
Digital Output is 1001b
ICE-BDE-T7 COM Express Module
Page 83
Appendix
E

E Watchdog Timer

ICE-BDE-T7 COM Express Module
Page 84
NOTE:
The following discussion applies to DOS environment. Contact IEI support or visit the IEI website for specific drivers for other operating systems.
The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash. This condition may have occurred by external EMIs or a software bug. When the CPU stops working correctly, Watchdog Timer either performs a hardware re set (cold boot) o r a Non-Maskable I nterrupt (NMI) to bring the system back to a known state.
A BIOS function call (INT 15H) is used to control the Watchdog Timer.
INT 15H:
AH – 6FH Sub-function:
AL – 2: Sets the Watchdog Timer’s period. BL: Time-out value (Its unit-se cond is dependent on the item “Watchdo g
Timer unit select” in CMOS setup).
Table E-1: AH-6FH Sub-function
Call sub-function 2 to set the time-out period of Watchdog Timer first. If the time-out value is not zero, the Watchdog Timer starts counting down . When the timer val ue reaches zero, the system resets. To ensure that this reset condition does not occur, calling sub-function 2 must periodically refresh the Watchdog Timer. However, the watchdog timer is disabled if the time-out value is set to zero.
A tolerance of at least 10% must be maintained to avoid unknown routines within the operating system (DOS), such as disk I/O that can be very time-consuming.
ICE-BDE-T7 COM Express Module
Page 85
NOTE:
When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets.
EXAMPLE PROGRAM:
; INITIAL TIMER PERIOD COUNTER
; W_LOOP: ;
MOV AX, 6F02H ;setting the time-out value MOV BL, 30 ;time-out value is 48 seconds INT 15H
; ; ADD THE APPLICATION PROGRAM HERE ;
CMP EXIT_AP, 1 ;is the application over? JNE W_LOOP ;No, restart the application
MOV AX, 6F02H ;disable Watchdog Timer MOV BL, 0 ; INT 15H
; ; EXIT ;
ICE-BDE-T7 COM Express Module
Page 86
Appendix
F
F Hazardous Materials
Disclosure
ICE-BDE-T7 COM Express Module
Page 87
The details provided in this appendix are to ensure that the product is compliant with the People’s Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain material s in the product, and is applicable t o China RoHS only.
A label will be placed on each product to indicate the estimated “Environmentally Friendly Use Period” (EFUP). This is an estimate of the number of years that these substances would “not leak out or undergo abrupt change.” This product may contain replaceable sub-assemblies/components which have a shorter EFUP such as batteries and lamps. These components will be separately marked.
Please refer to the following table.
Part Name Toxic or Hazardous Substances and Elements
Lead (Pb)
Housing Display Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Power Supply Assemblies Battery O: This toxic or hazardous substance is contained in all of the homogeneous materials for the part is below the li mi t
requirement in SJ/T11363-2006 (now replaced by GB/T 26572-2011).
X: This toxic or hazardous substance is contained in at least one of the homogeneous materials for this part is above
O O O O O O O O O O O O O O O O O O
O O O O O O O O O O O O O O O O O O O O O O O O
O O O O O O
Mercury (Hg)
Cadmium (Cd)
Hexavalent Chromium (CR(VI))
Polybrominated Biphenyls (PBB)
Polybrominated Diphenyl Ethers (PBDE)
the limit requirement in SJ/T11363-2006 (now replaced by GB/T 26572-2011).
ICE-BDE-T7 COM Express Module
Page 88
部件名称
有毒有害物质或元素
六价铬
多溴联苯
多溴二苯
壳体
显示
印刷电路板
金属螺帽
电缆组装
风扇组装
电力供应组装
电池
此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。
本产品上会附有环境友好使用期限的标签,此期限是估算这些物质不会有泄漏或突变”的
年限。本产品可能包含有较短的环境友好使用期限的可替换元件,像是电池或灯管,这些元
件将会单独标示出来。
(Pb)
O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T 11363-2006 (现由 GB/T 26572-2011 取代) 标准规定的限量要求以下。
O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O
(Hg)
(Cd)
(CR(VI))
(PBB)
(PBDE)
X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T 11363-2006 (现由 GB/T 26572-2011 取代) 标准规定的限量要求。
