IBX-700 Integrated Service Computer
IBX-700 Series Integrated Service Computer
Page i
r
IBX-700 Integrated Service Compute
Revision
Date Version Changes
2008-03 1.01 Modified the ODD replacement procedures
2008-02 1.00 Initial Release
Page ii
IBX-700 Integrated Service Computer
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
Copyright
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.
Page iii
r
IBX-700 Integrated Service Compute
Manual Conventions
WARNING!
Warnings appear where overlooked details may cause damage to the equipment or result
in personal injury. Warnings should be taken seriously. Warnings are easy to recognize.
The word “warning” is written as “WARNING,” both capitalized and bold and is followed by
text. The text is the warning message. A warning message is shown below:
WARNING:
This is an example of a warning message. Failure to adhere to warning
messages may result in permanent damage to the IBX-700 Series or
personal injury to the user. Please take warning messages seriously.
CAUTION!
Cautionary messages should also be heeded to help reduce the chance of losing data or
damaging the IBX-700 Series. Cautions are easy to recognize. The word “caution” is
written as “CAUTION,” both capitalized and bold and is followed. The italicized text is the
cautionary message. A caution message is shown below:
Page iv
IBX-700 Integrated Service Computer
CAUTION:
This is an example of a caution message. Failure to adhere to cautions
messages may result in permanent damage to the IBX-700 Series.
Please take caution messages seriously.
NOTE:
These messages inform the reader of essential but non-critical information. These
messages should be read carefully as any directions or instructions contained therein can
help avoid making mistakes. Notes are easy to recognize. The word “note” is written as
“NOTE,” both capitalized and bold and is followed by text. The text is the cautionary
message. A note message is shown below:
NOTE:
This is an example of a note message. Notes should always be read.
Notes contain critical information about the IBX-700 Series. Please
take note messages seriously.
Page v
r
IBX-700 Integrated Service Compute
Packing List
NOTE:
If any of the components listed in the checklist below are missing, please do not
proceed with the installation. Contact the IEI reseller or vendor you purchased
the IBX-700 Series from or contact an IEI sales representative directly. To
contact an IEI sales representative, please send an email to
The items listed below should all be included in the IBX-700 Series package.
1 x IBX-700 Series Integrated Service Computer
1 x Power adaptor
1 x Power cord
1 x Screw set
1 x DVD-ROM SATA cable
4 x Foot pads
1 x Utility CD
1 x 1 GB CompactFlash® card with Windows WEPOS pre-installed (optional)
1 x 1 GB CompactFlash® card with Windows XPE pre-installed (optional)
1 x Riser card (optional)
Images of the above items are shown in Chapter 4.
sales@iei.com.tw.
Page vi
IBX-700 Integrated Service Computer
Table of Contents
1 INTRODUCTION..................................................................................................... 1
1.1 IBX-700 SERIES OVERVIEW ...................................................................................... 2
1.1.1 IBX-700 Series Benefits ..................................................................................... 2
1.1.2 IBX-700 Series Features.................................................................................... 3
1.2 IBX-700 SERIES MODEL VARIATIONS........................................................................ 3
1.3 TECHNICAL SPECIFICATIONS ...................................................................................... 6
1.4 POWER MODULE SPECIFICATIONS.............................................................................. 7
1.4.1 Power Module Options...................................................................................... 7
1.4.2 Power Module Specifications ............................................................................ 7
1.5 POWER ADAPTER....................................................................................................... 9
1.6 WIRELESS LAN MODULE (OPTIONAL).....................................................................11
2 MECHANICAL DESCRIPTION.......................................................................... 13
2.1 IBX-700 SERIES MECHANICAL OVERVIEW.............................................................. 14
2.2 IBX-700 SERIES PHYSICAL DIMENSIONS................................................................. 14
2.3 EXTERNAL OVERVIEW ............................................................................................. 15
2.3.1 Front Panel...................................................................................................... 15
2.3.2 Rear Panel Overview....................................................................................... 16
2.3.2.1 Rear Panel Connectors and Indicators...................................................... 17
2.4 INTERNAL OVERVIEW............................................................................................... 18
3 SYSTEM COMPONENTS .................................................................................... 19
3.1 IBX-700 SERIES MOTHERBOARD ............................................................................ 20
3.1.1 POS Motherboard Overview............................................................................ 20
3.1.2 CPU Support.................................................................................................... 21
3.1.2.1 Intel® Celeron® M Specifications ............................................................. 22
3.1.3 Onboard Chipsets ............................................................................................ 22
3.1.3.1 Northbridge and Southbridge Chipsets..................................................... 22
3.1.3.2 Intel® 910GMLE Northbridge Chipset..................................................... 23
3.1.3.3 Intel® 915GM Northbridge Chipset.......................................................... 23
Page vii
r
3.1.3.4 ICH6-M Southbridge Chipset................................................................... 23
3.1.4 Intel® 915GM Integrated Graphics Media Accelerator 900 .......................... 24
3.1.5 Ethernet Controller Specifications................................................................... 25
3.1.5.1 Overview................................................................................................... 25
3.1.5.2 PCI Express GbE Features........................................................................ 25
3.2 PERIPHERAL INTERFACE CONNECTORS .................................................................... 26
3.2.1 Peripheral Interface Connectors ..................................................................... 26
3.2.2 External Interface Panel Connectors............................................................... 27
3.3 ON-BOARD JUMPERS................................................................................................ 28
3.3.1 AT X Power Select Jumper Settings.................................................................. 28
3.3.2 FSB Select Jumper Settings ............................................................................. 29
3.3.3 Clear CMOS Jumper........................................................................................ 30
3.3.4 COM 1/2 Pin 9 Setting Jumper........................................................................ 32
3.3.5 COM 3/4 Pin 9 Setting Jumper........................................................................ 33
IBX-700 Integrated Service Compute
4 INSTALLATION .................................................................................................... 35
4.1 ANTI-STATIC PRECAUTIONS...................................................................................... 36
4.2 INSTALLATION PROCEDURE...................................................................................... 36
4.2.1 Installation Procedure Overview ..................................................................... 36
4.2.2 Unpacking........................................................................................................ 37
4.2.3 CompactFlash® Card Installation .................................................................. 38
4.2.4 Foot Pad Installation....................................................................................... 39
4.2.5 Cable Connections........................................................................................... 39
4.3 POWER-ON PROCEDURE .......................................................................................... 39
4.3.1 Installation Checklist....................................................................................... 39
4.3.2 Power-on Procedure ........................................................................................ 40
5 AMI BIOS................................................................................................................ 41
5.1 INTRODUCTION ........................................................................................................ 42
5.1.1 Starting Setup................................................................................................... 42
5.1.2 Using Setup...................................................................................................... 42
5.1.3 Getting Help..................................................................................................... 43
5.1.4 Unable to Reboot After Configuration Changes.............................................. 43
5.1.5 BIOS Menu Bar................................................................................................ 43
5.2 MAIN ....................................................................................................................... 44
Page viii
IBX-700 Integrated Service Computer
5.3 ADVANCED............................................................................................................... 45
5.3.1 CPU Configuration.......................................................................................... 46
5.3.2 IDE Configuration........................................................................................... 47
5.3.2.1 IDE Master, IDE Slave............................................................................. 49
5.3.3 Super IO Configuration.................................................................................... 54
5.3.4 Hardware Health Configuration...................................................................... 59
5.3.5 Remote Access Configuration.......................................................................... 61
5.3.6 USB Configuration........................................................................................... 63
5.3.6.1 USB Mass Storage Device Configuration................................................. 65
5.4 PCI/PNP .................................................................................................................. 68
5.5 BOOT ....................................................................................................................... 70
5.5.1 Boot Settings Configuration............................................................................. 71
5.5.2 Boot Device Priority........................................................................................ 74
5.5.3 Hard Disk Drives............................................................................................. 74
5.6 SECURITY................................................................................................................. 74
5.7 CHIPSET ................................................................................................................... 76
5.7.1 NorthBridge Configuration.............................................................................. 77
5.7.2 Southbridge Configuration .............................................................................. 78
5.8 POWER..................................................................................................................... 80
5.9 EXIT......................................................................................................................... 83
6 DRIVER INSTALLATION.................................................................................... 85
6.1 AVAILABLE SOFTWARE DRIVERS .............................................................................. 86
6.2 DRIVER CD.............................................................................................................. 86
6.3 REALTEK AC`97 AUDIO DRIVER INSTALLATION ...................................................... 87
6.3.1 BIOS Setup....................................................................................................... 87
6.3.2 Driver Installation ........................................................................................... 87
6.4 INTEL
®
GRAPHICS MEDIA ACCELERATOR DRIVER INSTALLATION............................ 90
6.5 BROADCOM LAN DRIVER (FOR GBE LAN) INSTALLATION .................................... 94
6.6 ATHEROS WIRELESS LAN DRIVER INSTALLATION ................................................... 98
7 SOFTW A RE APPLICA TION (ISMM)............................................................... 105
7.1 ISMM INTRODUCTION........................................................................................... 106
7.2 ISMM INSTALLATION ............................................................................................ 106
7.3 VOLTAGE PAGE ...................................................................................................... 108
Page ix
r
7.3.1 Refresh Time Setting....................................................................................... 109
7.3.2 High Limit Value and Low Limit Value Setting.............................................. 109
7.4 FAN PAGE................................................................................................................110
7.4.1 Refresh Time Setting........................................................................................111
7.4.2 High Limit Value and Low Limit Value Setting...............................................111
7.4.3 Smart Fan Setting ...........................................................................................112
7.4.3.1 On/Off Mode............................................................................................112
7.4.3.2 PWM Mode..............................................................................................112
7.4.3.3 Automatic Mode.......................................................................................113
7.5 TEMPERATURE PAGE ...............................................................................................114
7.5.1 Refresh Time Setting........................................................................................115
7.5.2 High Limit Value and Low Limit Value Setting...............................................116
7.6 CASH DRAWER PAGE...............................................................................................117
7.7 WATCHDOG TIMER PAGE.........................................................................................118
IBX-700 Integrated Service Compute
7.8 DIO PAGE ...............................................................................................................119
7.8.1 GPO Information Setting................................................................................119
7.9 LOAD/SAVE PAGE................................................................................................... 120
8 TROUBLESHOOTING AND MAINTENANCE .............................................. 121
8.1 IBX-700 SERIES SYSTEM MAINTENANCE OVERVIEW............................................ 122
8.2 SYSTEM TROUBLESHOOTING.................................................................................. 122
8.2.1 The System Doesn’t Turn On.......................................................................... 122
8.2.2 The System Doesn’t Boot Up.......................................................................... 123
8.3 JUMPER SETTING AND EXPANSION CARD INSTALLATION........................................ 124
8.3.1 Cover Case Removal...................................................................................... 124
8.3.2 Configure the Jumper Settings....................................................................... 124
8.3.3 Expansion Card Installation (Optional)........................................................ 125
8.4 COMPONENT REPLACEMENT PROCEDURE.............................................................. 126
8.4.1 HDD Replacement......................................................................................... 127
8.4.1.1 HDD Removal ........................................................................................ 127
8.4.1.2 HDD Installation..................................................................................... 128
8.4.2 Motherboard Replacement............................................................................. 129
8.4.2.1 Motherboard Removal............................................................................ 129
8.4.2.2 Motherboard Installation......................................................................... 131
8.4.3 Power Module Replacement.......................................................................... 132
Page x
IBX-700 Integrated Service Computer
8.4.3.1 Power Module Removal ......................................................................... 132
8.4.3.2 Power Module Installation...................................................................... 134
8.4.4 DIMM Replacement....................................................................................... 134
8.4.5 ODD Replacement (Optional) ....................................................................... 135
8.4.5.1 ODD Removal ........................................................................................ 135
8.4.5.2 ODD Installation..................................................................................... 137
8.4.6 Riser Card Replacement (Optional) .............................................................. 137
A SAFETY PRECAUTIONS................................................................................... 139
A.1 SAFETY PRECAUTIONS .......................................................................................... 140
A.1.1 General Safety Precautions........................................................................... 140
A.1.2 Anti-static Precautions.................................................................................. 141
A.2 MAINTENANCE AND CLEANING PRECAUTIONS...................................................... 141
A.2.1 Maintenance and Cleaning............................................................................ 141
A.2.2 Cleaning Tools............................................................................................... 142
B INTERFACE CONNECTORS............................................................................ 143
B.1 PERIPHERAL INTERFACE CONNECTORS.................................................................. 144
C BIOS MENU OPTIONS....................................................................................... 151
C.1 BIOS CONFIGURATION OPTIONS........................................................................... 152
D WA TCHDOG TIMER .......................................................................................... 155
E ADDRESS MAPPING.......................................................................................... 159
E.1 IO ADDRESS MAP.................................................................................................. 160
E.2 1ST MB MEMORY ADDRESS MAP.......................................................................... 161
E.3 IRQ MAPPING TABLE ............................................................................................ 161
E.4 DMA CHANNEL ASSIGNMENTS ............................................................................. 161
F HAZARDOUS MATERIALS DISCLOSURE................................................... 163
F.1 HAZARDOUS MATERIAL DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY..................................... 164
G JMICRO RAID..................................................................................................... 167
G.1 INTRODUCTION...................................................................................................... 168
G.1.1 Precautions.................................................................................................... 168
Page xi
r
G.2 FEA TURES AND BENEFITS ...................................................................................... 169
G.3 ACCESSING THE JMICRON RAID UTILITY............................................................. 169
G.4 CREA TING A RAID ARRA Y .................................................................................... 172
G.5 DELETING A RAID ARRAY .................................................................................... 179
G.6 REVERT A HARD DRIVE TO NON-RAID................................................................. 182
G.7 SOLVE MIRROR CONFLICT..................................................................................... 185
G.8 REBUILD MIRROR DRIVE....................................................................................... 187
G.9 SAVE AND EXIT SETUP........................................................................................... 190
G.10 EXIT WITHOUT SAVI NG ....................................................................................... 192
G.11 RAID OPTIONS.................................................................................................... 194
G.11.1 RAID 0 Striping – For Performance............................................................ 194
G.11.2 RAID 1 Mirror – For Redundancy............................................................... 194
G.11.3 JBOD ........................................................................................................... 195
9 INDEX.................................................................................................................... 197
IBX-700 Integrated Service Compute
Page xii
IBX-700 Integrated Service Computer
List of Figures
Figure 1-1: IBX-700 Series Integrated Service Computer .........................................2
Figure 1-2: Power Adapter ...........................................................................................9
Figure 2-1: IBX-700 Series Dimensions (mm) ..........................................................15
Figure 2-2: IBX-700 Series Front Panel.....................................................................16
Figure 2-3: IBX-700 Series Rear Panel......................................................................16
Figure 2-4: Internal Overview.....................................................................................18
Figure 3-1: POS-9103/POS-9153 Jumper and Connector Locations .....................21
Figure 3-2: Jumpers....................................................................................................28
Figure 3-3: ATX Power Select Jumper Location......................................................29
Figure 3-4: FSB Select Jumper Location..................................................................30
Figure 3-5: Clear CMOS Jumper................................................................................32
Figure 3-6: COM 1/2 Pin 9 Setting Jumper Location ...............................................33
Figure 3-7: COM 3/4 Pin 9 Setting Jumper Location ...............................................34
Figure 4-1: CF Card Slot Cover Retention Screw ....................................................38
Figure 4-2: Power Button and Power LED................................................................40
Figure 6-1: Available Drivers......................................................................................86
Figure 6-2: Locate the Setup Program Icon .............................................................87
Figure 6-3: Preparing Setup Screen..........................................................................88
Figure 6-4: InstallShield Wizard Welcome Screen...................................................88
Figure 6-5: Audio Driver Software Configuration....................................................89
Figure 6-6: Audio Driver Digital Signal .....................................................................89
Figure 6-7: Audio Driver Installation.........................................................................90
Figure 6-8: Restart the Computer..............................................................................90
Figure 6-9: VGA Driver................................................................................................91
Figure 6-10: Intel® Graphics Media Accelerator InstallShield Wizard...................91
Figure 6-11: InstallShield Wizard Extracting Files...................................................92
Figure 6-12: Intel® Graphics Media Accelerator Driver Welcome Screen ............92
Figure 6-13: Intel® Graphics Media Accelerator Driver License Agreement........93
Page xiii
r
Figure 6-14: Intel® Graphics Media Accelerator Driver Installing Notice..............93
Figure 6-15: Intel® Graphics Media Accelerator Installation Complete ................94
Figure 6-16: Windows Control Panel.........................................................................95
Figure 6-17: System Icon............................................................................................95
Figure 6-18: Device Manager Tab..............................................................................96
Figure 6-19: Device Manager List..............................................................................96
Figure 6-20: Search for Suitable Driver.....................................................................97
Figure 6-21: Locate Driver Files.................................................................................97
Figure 6-22: Location Browsing Window..................................................................98
Figure 6-23: Atheros Client Installation Program Screen.......................................99
Figure 6-24: Atheros Wireless LAN Driver License Agreement.............................99
Figure 6-25: Wireless LAN Driver Setup Type....................................................... 100
Figure 6-26: Driver Destination Location............................................................... 100
IBX-700 Integrated Service Compute
Figure 6-27: Wireless LAN Driver Important Notice ............................................. 101
Figure 6-28: Wireless LAN Configuration Tool Selection.................................... 101
Figure 6-29: Single Sign On Feature Selection..................................................... 102
Figure 6-30: Wireless LAN Driver Installation....................................................... 102
Figure 6-31: Wireless LAN Driver Install Wizard Completed............................... 103
Figure 7-1: iSMM Installation Welcome Screen .................................................... 106
Figure 7-2: iSMM Installation Customer Information............................................ 107
Figure 7-3: Ready to Install the Program Window................................................ 107
Figure 7-4: Voltage Page ......................................................................................... 108
Figure 7-5: Voltage Refresh Time Setting.............................................................. 109
Figure 7-6: Voltage Page – High Limit and Low Limit.......................................... 109
Figure 7-7: Fan Page................................................................................................ 110
Figure 7-8: Fan Speed Refresh Time Setting ........................................................ 111
Figure 7-9: Fan Page – High Limit and Low Limit................................................. 111
Figure 7-10: Smart Fan Setting – On/Off Mode..................................................... 112
Page xiv
Figure 7-11: Smart Fan Setting – PWM Mode........................................................ 113
Figure 7-12: Smart Fan Setting – Automatic Mode............................................... 114
Figure 7-13: Temperature Page .............................................................................. 115
Figure 7-14: Temperature Refresh Time Setting................................................... 115
IBX-700 Integrated Service Computer
Figure 7-15: Temperature Page – High Limit and Low Limit ............................... 116
Figure 7-16: Cash Drawer Page.............................................................................. 117
Figure 7-17: WDT Page............................................................................................ 118
Figure 7-18: DIO Page.............................................................................................. 119
Figure 7-19: Load/Save Page.................................................................................. 120
Figure 8-1: Cover Case Thumb Screws ................................................................. 124
Figure 8-2: Cover Case Removal............................................................................ 124
Figure 8-3: Expansion Slot Cover Retention Screws........................................... 125
Figure 8-4: Installed Expansion Card..................................................................... 126
Figure 8-5: HDD Bracket Retention Screws .......................................................... 127
Figure 8-6: HDD Connectors................................................................................... 128
Figure 8-7: HDD Retention Screws......................................................................... 128
Figure 8-8: Rear Panel Connector Retention Screws........................................... 130
Figure 8-9: Motherboard Connectors..................................................................... 130
Figure 8-10: Motherboard Retention Screws ........................................................ 131
Figure 8-11: Power Module Internal Connectors.................................................. 133
Figure 8-12: Power Module Retention Screws...................................................... 133
Figure 8-13: DIMM Installation................................................................................ 135
Figure 8-14: ODD Bracket Retention Screws........................................................ 136
Figure 8-15: ODD SATA Cable Retention Screws................................................. 136
Figure 8-16: ODD Retention Screws....................................................................... 137
Figure 8-17: Riser Card Retention Screws ............................................................ 138
Figure 8-18: Riser Card Location............................................................................ 138
Page xv
r
IBX-700 Integrated Service Compute
List of Tables
Table 1-1: Model Variations..........................................................................................5
Table 1-2: CF Card with Preinstalled OS ....................................................................5
Table 1-3: Technical Specifications ............................................................................7
Table 1-4: IBX-700 Series Power Module Options.....................................................7
Table 1-5: DC-to-DC Power Module Specifications...................................................8
Table 1-6: Power Adapter Specifications..................................................................10
Table 1-7: Wireless Module Specifications ..............................................................11
Table 3-1: Chipset Variations.....................................................................................22
Table 3-2: Peripheral Interface Connectors..............................................................27
Table 3-3: Rear Panel Connectors.............................................................................27
Table 3-4: Jumpers......................................................................................................28
Table 3-5: ATX Power Select Jumper Settings ........................................................29
Table 3-6: FSB Select Jumper Settings ....................................................................30
Table 3-7: Clear CMOS Jumper Settings ..................................................................31
Table 3-8: COM 1/2 Pin 9 Setting Jumper Settings..................................................32
Table 3-9: COM 3/4 Pin 9 Setting Jumper Settings..................................................34
Table 4-1: Package List Contents..............................................................................38
Table 5-1: BIOS Navigation Keys...............................................................................43
Page xvi
IBX-700 Integrated Service Computer
List of BIOS Menus
Menu 1: Main ....................................................................................................44
Menu 2: Advanced.......................................................................................................46
Menu 3: CPU Configuration .......................................................................................47
Menu 4: IDE Configuration.........................................................................................48
Menu 5: IDE Master and IDE Slave Configuration ...................................................50
Menu 6: Super IO Configuration................................................................................54
Menu 7: Hardware Health Configuration ..................................................................59
Menu 8: Remote Access Configuration [Advanced] ...............................................61
Menu 9: USB Configuration .......................................................................................64
Menu 10: USB Mass Storage Device Configuration.................................................66
Menu 11: PCI/PnP Configuration...............................................................................68
Menu 12: Boot..............................................................................................................71
Menu 13: Boot Settings Configuration......................................................................72
Menu 14: Security........................................................................................................75
Menu 15: Chipset.........................................................................................................76
Menu 16:Northbridge Chipset Configuration...........................................................77
Menu 17:Southbridge Chipset Configuration ..........................................................79
Menu 18:Power............................................................................................................80
Menu 19:Exit................................................................................................................83
Page xvii
r
IBX-700 Integrated Service Compute
THIS PAGE IS INTENTIONALLY LEFT BLANK
Page xviii
IBX-700 Integrated Service Computer
Chapter
1
1 Introduction
Page 1
r
1.1 IBX-700 Series Overview
Figure 1-1: IBX-700 Series Integrated Service Computer
The IBX-700 Series is an Intel® Celeron® M based integrated service solution that can be
IBX-700 Integrated Service Compute
applied in diverse operational environments and implemented in multi-faceted
point-of-sale (POS) applications. The IBX-700 Series comes fully kitted with a
high-performance motherboard and a host of other peripheral interface connectors. The
integrated GbE LAN ensures an uninterrupted network connection. The preinstalled 80GB
HDD and 1 GB DDR2 SDRAM make the IBX-700 a ready-to-use system. The flexible
PCI/PCIe expansion allows the IBX-700 series to meet multiple application requirements.
The IBX-700 Series is designed for ease of use and easy installation.
1.1.1 IBX-700 Series Benefits
The IBX-700 Series has the following benefits:
Easy installation and maintenance
Complete integration saves solution development time and cost
A full range of I/O interfaces compatible with most POS external devices
Quick access CF storage card interface
Powerful preinstalled Intel® Celeron® M CPU and motherboard ensures
Page 2
rigorous processing needs can be met
IBX-700 Integrated Service Computer
1.1.2 IBX-700 Series Features
The IBX-700 Series has the following features
RoHS compliant design
Intel® Celeron® M CPU preinstalled
1 GB DDR2 SDRAM DIMM preinstalled
One GbE RJ-45 connector supported
One CompactFlash® Type I or Type II card supported
Serial port 5 V or 12 V LED indicators on the rear panel
SATA RAID 0, 1 support
Optional 802.11b/g wireless LAN module
Support 9 V ~ 36 V power (optional)
1.2 IBX-700 Series Model Variations
The IBX-700 Series has one preinstalled 1 GB DDR2 memory module with different type
CPU. The model information is listed in
IBX-700D-9103-R10 CPU DVD Wireless Expansion Power
-WBOOC/CM373/1GB/80G 1.0 GHz ULV Intel® Celeron® M
with 512 KB L2 cache (BGA)
-WBIGC/CM373/1GB/80G 1.0 GHz ULV Intel® Celeron® M
with 512 KB L2 cache (BGA)
-WBEGC/CM373/1GB/80G 1.0 GHz ULV Intel® Celeron® M
with 512 KB L2 cache (BGA)
-WBOOO/CM373/1GB/80G 1.0 GHz ULV Intel® Celeron® M
with 512 KB L2 cache (BGA)
Table 1-1 below.
Yes No N/A 12 V
DC
Yes Yes PCI 12 V
DC
Yes Yes PCIe x1 12 V
DC
No No N/A 12 V
DC
-WBIGO/CM373/1GB/80G 1.0 GHz ULV Intel® Celeron® M
with 512 KB L2 cache (BGA)
-WBEGO/CM373/1GB/80G 1.0 GHz ULV Intel® Celeron® M
with 512 KB L2 cache (BGA)
No Yes PCI 12 V
DC
No Yes PCIe x1 12 V
DC
Page 3
r
IBX-700 Integrated Service Compute
IBX-700D-9153-R10 CPU DVD Wireless Expansion Power
-WSOOC/CM370/1GB/80G 1.5 GHz Intel® Celeron® M
with 1 MB L2 cache (PGA)
-WSIGC/CM370/1GB/80G 1.5 GHz Intel® Celeron® M
with 1 MB L2 cache (PGA)
-WSEGC/CM370/1GB/80G 1.5 GHz Intel® Celeron® M
with 1 MB L2 cache (PGA)
-WSOOO/CM370/1GB/80G 1.5 GHz Intel® Celeron® M
with 1 MB L2 cache (PGA)
-WSIGO/CM370/1GB/80G 1.5 GHz Intel® Celeron® M
with 1 MB L2 cache (PGA)
-WSEGO/CM370/1GB/80G 1.5 GHz Intel® Celeron® M
with 1 MB L2 cache (PGA)
Yes No N/A 12 V
DC
Yes Yes PCI 12 V
DC
Yes Yes PCIe x1 12 V
DC
No No N/A 12 V
DC
No Yes PCI 12 V
DC
No Yes PCIe x1 12 V
DC
IBX-700M-9103-R10 CPU DVD Wireless Expansion Power
-WBOOC/CM373/1GB/80G 1.0 GHz ULV Intel® Celeron® M
with 512 KB L2 cache (BGA)
-WBIGC/CM373/1GB/80G 1.0 GHz ULV Intel® Celeron® M
Yes No N/A 9~36 V
DC
Yes Yes PCI 9~36 V
with 512 KB L2 cache (BGA)
-WBEGC/CM373/1GB/80G 1.0 GHz ULV Intel® Celeron® M
with 512 KB L2 cache (BGA)
-WBOOO/CM373/1GB/80G 1.0 GHz ULV Intel® Celeron® M
with 512 KB L2 cache (BGA)
-WBIGO/CM373/1GB/80G 1.0 GHz ULV Intel® Celeron® M
with 512 KB L2 cache (BGA)
-WBEGO/CM373/1GB/80G 1.0 GHz ULV Intel® Celeron® M
with 512 KB L2 cache (BGA)
Yes Yes PCIe x1 9~36 V
No No N/A 9~36 V
No Yes PCI 9~36 V
No Yes PCIe x1 9~36 V
DC
DC
DC
DC
DC
IBX-700M-9153-R10 CPU DVD Wireless Expansion Power
-WSOOC/CM370/1GB/80G 1.5 GHz Intel® Celeron® M
with 1 MB L2 cache (PGA)
-WSIGC/CM370/1GB/80G 1.5 GHz Intel® Celeron® M
with 1 MB L2 cache (PGA)
-WSEGC/CM370/1GB/80G 1.5 GHz Intel® Celeron® M
with 1 MB L2 cache (PGA)
Yes No N/A 9~36 V
DC
Yes Yes PCI 9~36 V
DC
Yes Yes PCIe x1 9~36 V
DC
Page 4
IBX-700 Integrated Service Computer
-WSOOO/CM370/1GB/80G 1.5 GHz Intel® Celeron® M
with 1 MB L2 cache (PGA)
-WSIGO/CM370/1GB/80G 1.5 GHz Intel® Celeron® M
with 1 MB L2 cache (PGA)
-WSEGO/CM370/1GB/80G 1.5 GHz Intel® Celeron® M
with 1 MB L2 cache (PGA)
No No N/A 9~36 V
No Yes PCI 9~36 V
No Yes PCIe x1 9~36 V
Table 1-1: Model Variations
Optional 1 GB CF card pre-installed with Windows® WEPOS or Windows® XP Embedded
is also provided by IEI for the IBX-700 Series. The information of the optional CF card is
listed below.
S/N Model OS Image Capacity
IBXCF-P9103-WEPOS
IBX-700-9103 Windows® WEPOS 1 GB
DC
DC
DC
IBXCF-P9103-XPE
IBXCF-P9153-WEPOS
IBXCF-P9153-XPE
IBX-700-9103 Windows® XP Embedded 1 GB
IBX-700-9153 Windows® WEPOS 1 GB
IBX-700-9153 Windows® XP Embedded 1 GB
Table 1-2: CF Card with Preinstalled OS
Page 5
r
IBX-700 Integrated Service Compute
1.3 Technical Specifications
The specifications for the Intel® based IBX-700 are listed below.
IBX-700-9103 IBX-700-9153
CPU
System Chipset
System Memory
Ethernet
Display
USB
Serial Port
1 GHz ULV Intel® Celeron M
512 KB L2 Cache (BGA type)
Northbridge: Intel® 910GMLE
Southbridge: ICH6-M
One 240-pin 1 GB 400/533 MHz DDR2 SDRAM DIMM preinstalled
(Two 240-pin DDR2 DIMM sockets support up to 2 GB)
One RJ-45 for GbE
One VGA integrated in Intel®
910GMLE
Five USB 2.0 supported
4 x Standard USB 2.0 ports (two on the front, two on the rear)
1 x PoweredUSB port provides 12 V output
Six RS-232 serial ports
4 x RS-232 ports provide 5 V or 12 V power output via Pin 9
(indicated by LEDs on the rear panel)
2 x RS-232 ports
1.5 GHz Intel® Celeron M
1 MB L2 Cache (PGA type)
Northbridge: Intel® 915GM
Southbridge: ICH6-M
One VGA integrated in Intel®
915GM
Parallel Port
Digital I/O
Audio
Keyboard/Mouse
ODD
HDD
SSD
Page 6
One DB-25 parallel port
Two RJ-12 connectors for cash drawer
1 x Line-out
1 x Mic-in
1 x PS/2 Keyboard connector
1 x PS/2 Mouse connector
One optional DVD combo drive (supports CD-R/CD-RW/DVD-R)
One preinstalled 2.5” 80 GB HDD
(the system supports two 2.5” HDD drive bays)
One CompactFlash® Type II slot
IBX-700 Integrated Service Computer
Expansion Slot
Power Supply
Operating Temperature
Net Weight
Dimensions (W x D x H)
EMC/Safety
One PCI slot and one PCIe x4 slot support an optional PCI/PCIe riser
card including:
One PCIe mini slot (preinstalled with a wireless LAN module)
One PCI slot (or one PCIe x1)
External power adapter, input voltage:
90 V AC ~ 264 V AC @ 47 Hz ~ 63 Hz, 84 W
0ºC ~ 45ºC
3.6 kg
300 mm x 309 mm x 75 mm
CE, FCC class B, UL, CCC
Table 1-3: Technical Specifications
1.4 Power Module Specifications
1.4.1 Power Module Options
The IBX-700 Series supports either a 12 V DC input or a 9 V ~ 36 V DC input. The input
support depends on the power module installed in the system. The two power modules
are listed in
Table 1-4:
IBX-700 Series Power Module DC Input
IBX-700D
IBX-700M
IDD-12490A 12V DC input
IDD-9364120A 9V~36V DC input
Table 1-4: IBX-700 Series Power Module Options
1.4.2 Power Module Specifications
The specifications for the IDD-12490A and IDD-9364120A are shown in Table 1-5.
Page 7
r
Model Name: IDD-12490A IDD-9364120A
IBX-700 Integrated Service Compute
Input
Output:
12 V
5 V
3.3 V
-12 V
5 VSB
Max. Total Output:
Performance Characteristics:
Noise & Ripple:
Load Regulation
12 V DC 9 V DC~36 V DC
10 A (pass thru.) 4 A (Max.)
10 A (Max.) 10 A (Max.)
8 A (Max.) 8 A (Max.)
0.3 A (Max.) 0.3 A (Max.)
2 A (Max.) 2 A (Max.)
90 W + 120 W (12 V pass
thru.)
< 120 mV < 240 mV
< 60 mV < 100 mV
120 W
Efficiency:
Dimensions:
Weight:
Operating Temperature
Table 1-5: DC-to-DC Power Module Specifications
Up to 90% Up to 90%
45 mm x 160 mm 45 mm x 160 mm
82 g 104 g
-20°C~70°C -20°C~70°C
Page 8
IBX-700 Integrated Service Computer
1.5 Power Adapter
The IBX-700 Series models are shipped with an 84 W power adapter.
Figure 1-2: Power Adapter
The specifications for the adapter are listed in
Nominal
Regulation
Output
Protection
Ripple/Noise
Min.
Max.
Short Circuit
Over-Voltage
Over-Current
Table 1-6:
12.0 V
11.2 V – 12.6 V
200 mV
0 A
7.0 A
Output can be shorted without damage and
auto-recovery
Upper Trip Limit: 18 V DC
Output Voltage 11.2 V DC~12.6 V DC
Output current limit: 7.3 A ~ 8.8 A (max.) at C.C.
Mode
Time Hold Up
Input Min.
5 ms
90 V
Page 9
r
IBX-700 Integrated Service Compute
Environment
Nominal
Max.
Frequency
Steady AC Current
Efficiency
Temperature
Relative Humidity
115 V ~ 230 V
264 V
47 Hz ~ 63 Hz
1.5 A (rms Max.)@100 V AC
80% (typical)
Operating 6.0 A: 0ºC ~ 40ºC
7.0 A: 0ºC ~ 25ºC
Storage -30ºC ~ 60ºC
Operating
(non-condensing)
Storage
(non-condensing)
8% ~ 80%
8% ~ 80%
Vibration
Shock
MTBF
Reliability
Leakage Current
Table 1-6: Power Adapter Specifications
0.5 G, 10 Hz~100 Hz, random vibration,
10mins/axis, 3 direction
Operating: 50 to 90 in/sec in 10 in/sec increments
(all 6 sides)
Storage: 40 to 70 in/sec in 10 in/sec increments (all
sides except top panel)
50,000 hours of continuous operation at 25ºC
0.25 mA @254 V AC 50 Hz
Page 10
IBX-700 Integrated Service Computer
1.6 Wireless LAN Module (Optional)
An Azurewave AW-GE780 wireless 802.11b/g PCIe mini card is installed on the optional
PCI/PCIe riser card. The specifications for the wireless LAN module are listed in
Table 1-7:
AW-GE780
Standard
Interface
Connectors
Frequency Band
Modulation
Output Power
Receive Sensitivity
Operating Voltage
Dimensions
IEEE 802.11 b/g
PCIe mini card
2 x U.FL-R-SMT Antenna connectors
2412 MHz ~ 2472 MHz
802.11g: OFDM
802.11b: CCK (11, 5.5 Mbps), DQPSK (2 Mbps), BPSK (1 Mbps)
802.11b: typical 16 ± 1.5 dBm
802.11g: typical 13 ± 1.5 dBm
802.11b: typical -76 dBm at 11 Mbps
802.11g: typical -68 dBm at 54 Mbps
3.3 V
30.00 mm x 51 mm x 3.3 mm
Table 1-7: Wireless Module Specifications
Page 11
r
IBX-700 Integrated Service Compute
THIS PAGE IS INTENTIONALLY LEFT BLANK
Page 12
IBX-700 Integrated Service Computer
Chapter
2
2 Mechanical
Description
Page 13
r
IBX-700 Integrated Service Compute
2.1 IBX-700 Series Mechanical Overview
The IBX-700 Series RoHS compliant, Intel® Celeron® M Integrated Service Computer
features industrial grade components that offer longer operating life and endurance over a
wide temperature range. A preinstalled 80 GB 2.5” HDD and a drive bay for an optional
ODD drive are located in the right side of the IBX-700 chassis. The motherboard and the
power module are installed inside the bottom of the chassis.
Featuring one GbE, five USB, six serial communication ports, as well as audio, VGA,
parallel port and cash drawer connectors, the IBX-700 Series offers system integrators
and developers the best selection of robust and high performance integrated service
platforms. A CompactFlash® slot on the rear panel supports one Type I or Type II CF
card.
2.2 IBX-700 Series Physical Dimensions
The dimensions of the IBX-700 Series are listed below and shown in Figure 2-1.
Height: 75.00 mm
Width: 300.00 mm
Length: 309.00 mm
Page 14
IBX-700 Integrated Service Computer
Figure 2-1: IBX-700 Series Dimensions (mm)
2.3 External Overview
2.3.1 Front Panel
The front panel of the IBX-700 Series has two USB 2.0 ports, indicators and power button.
The optional DVD combo drive is also accessed from the front panel. An overview of the
rear panel is shown in Figure 2-3 below.
Page 15
r
Figure 2-2: IBX-700 Series Front Panel
2.3.2 Rear Panel Overview
IBX-700 Integrated Service Compute
The IBX-700 Series contains the external I/O interface connectors, power connectors,
serial port LEDs and a CF slot. An overview of the rear panel is shown in
below.
Figure 2-3
Page 16
Figure 2-3: IBX-700 Series Rear Panel
IBX-700 Integrated Service Computer
2.3.2.1 Rear Panel Connectors and Indicators
The connectors, indicators and switches listed in this section are shown in Figure 2-3
above. The rear panel I/O connectors are listed below:
1 x 12 V DC inlet
4 x RS-232 serial port connectors (COM1, COM2, COM3 and COM4 with
selectable voltage)
2 x RS-232 serial port connectors (COM5 and COM6)
1 x RJ-45 GbE connector
2 x USB 2.0 ports
1 x PoweredUSB port (12 V output supported)
1 x CF Type II slot
1 x Keyboard connector
1 x Mouse connector
1 x Parallel port
1 x VGA connector
2 x RJ-12 connector (for cash drawer)
1 x Line-out connector
1 x Mic-in connector
1 x 9 V ~ 36 V screw terminal (optional)
The rear panel also contains the following button:
1 x Reset button
Status indicator LEDs on the rear panel include:
2 x COM1 pin-9 voltage LED [5 V (default) or 12 V]
2 x COM2 pin-9 voltage LED [5 V (default) or 12 V]
2 x COM3 pin-9 voltage LED [5 V (default) or 12 V]
2 x COM4 pin-9 voltage LED [5 V (default) or 12 V]
All the rear panel items listed above are shown in
Figure 2-3 above.
Page 17
r
2.4 Internal Overview
The IBX-700 Series preinstalled internal components are listed below:
1 x IEI POS-9103/POS-9153 motherboard
1 x IEI IDD-12490A/IDD-9364120A power module
1 x 1 GB DDR2 DIMM module
1 x 80 GB 2.5” SATA HDD
1 x 2.5” DVD combo drive (optional)
1 x PCI/PCIe riser card (optional)
1 x Wireless LAN module (preinstalled on the optional PCI/PCIe riser card)
All the components are accessed by removing the cover case. The CF module is
accessed through the rear panel.
IBX-700 Integrated Service Compute
Figure 2-4: Internal Overview
Page 18
IBX-700 Integrated Service Computer
Chapter
3
3 System Components
Page 19
r
IBX-700 Integrated Service Compute
NOTE:
The jumpers and connectors shown in the section below are those jumpers
and connectors that are relevant to the configuration and installation of the
IBX-700. For a complete list of connectors on the IBX-700 Series
motherboard, please refer to the Appendix B.
3.1 IBX-700 Series Motherboard
The IBX-700 Series all has a POS-9103 or POS-9153 motherboard installed in the system.
The difference between these two motherboard is the preinstalled CPU. (See
The following sections describe the relevant connectors and jumpers on the motherboard.
Table 1-1)
3.1.1 POS Motherboard Overview
The locations of the POS-9103/POS-9153 jumpers and connectors used on the IBX-700
Series are shown in
Figure 3-1 below.
Page 20
IBX-700 Integrated Service Computer
Figure 3-1: POS-9103/POS-9153 Jumper and Connector Locations
3.1.2 CPU Support
NOTE:
The IBX-700-9103 has a preinstalled 1.0 GHz ULV Intel® Celeron® M
CPU on-board. If the CPU fails, the motherboard has to be replaced.
Please contact the IEI reseller or vendor you purchased the IBX-700-9103
from or contact an IEI sales representative directly. To contact an IEI sales
representative, please send an email to
The POS-9103 motherboard comes with a preinstalled 1.5 GHz Intel® Celeron® M CPU
while the POS-9153 motherboard comes with a preinstalled Socket 479 1.0 GHz ULV
sales@iei.com.tw.
Intel® Celeron® M CPU.
Page 21
r
IBX-700 Integrated Service Compute
3.1.2.1 Intel® Celeron® M Specifications
The specifications for the Intel® Celeron® M processor are listed below
Features a new microarchitecture designed from the ground up:
o Hardware control for improved stack management
o Micro-ops fusion for instruction execution
o Advanced branch prediction capability
o Level 2 Advanced Transfer Cache (ATC) delivers a high data throughput
channel between the Level 2 cache and processor core
Streaming SIMD Extensions 2 capability adds 144 new instructions, including
128-bit SIMD integer arithmetic and 128-bit SIMD double-precision
floating-point operation
Support for uni-processor designs
Compatible with Intel® architecture-based software
Embedded life cycle support
3.1.3 Onboard Chipsets
3.1.3.1 Northbridge and Southbridge Chipsets
The following chipsets are preinstalled on the board:
IBX-700-9103 IBX-700-9153
Northbridge
Southbridge
Table 3-1: Chipset Variations
The following three sections (Section 3.1.3.2, Section 3.1.3.2 and Section 3.1.3.4) list
some of the features of the Intel® 910GMLE, Intel® 915GM and the ICH6-M chipsets. For
Intel® 910GMLE Intel® 915GM
ICH6-M ICH6-M
Page 22
more information on these three chipsets please refer to the Intel website.
IBX-700 Integrated Service Computer
3.1.3.2 Intel® 910GMLE Northbridge Chipset
The Intel® 910GMLE Northbridge chipset comes with the following features:
400 MHz Front Side Bus
Supports dual-channel non-ECC DDR2 400 MHz memory technology
Intel® Stable Image Technology Supports a unified graphics driver. Enables
hardware changes without impact to IT software image stability.
With up to 2 GB/sec concurrent bandwidth, DMI provides up to 4 times faster
I/O bandwidth compared to previous Intel proprietary Hub link I/O interface.
Intel® Graphics Media Accelerator (GMA) 900
PCI Express Bus Architecture
3.1.3.3 Intel® 915GM Northbridge Chipset
The Intel® 915GM Northbridge chipset comes with the following features:
533 MHz Front Side Bus
Support for dual channel DDR2 400/533 MHz memory technology
Direct Media Interface (DMI) chip interconnect can be implemented x4 or x2
widths, and provides up to 1 GB/s in each direction in full duplex
Intel® Graphics Media Accelerator (GMA) 900
Analog display support
PCI Express 1.0a-compliant, and support for full 250 MB/s in each direction
Long-term system reliability over wide operating conditions
3.1.3.4 ICH6-M Southbridge Chipset
The Intel® ICH6-M Southbridge chipset is connected to the Northbridge GMCH through
the chip-to-chip Direct Media Interface (DMI). Some of the features of the Intel® ICH6-M
are listed below.
Complies with PCI Express Base Specification, Revision 1.0a
Complies with PCI Local Bus Specification, Revision 2.3 and supports 33MHz
PCI operations
Supports ACPI Power Management Logic
Contains:
Page 23
r
IBX-700 Integrated Service Compute
o Enhanced DMA controller
o Interrupt controller
o Timer functions
Integrated SATA host controller with DMA operations interfaced to two SATA
connectors on the POS-9153
Integrated IDE controller supports Ultra ATA 100/66/33
Supports the four USB 2.0 devices on the POS-9153 with four UHCI
controllers and one EHCI controller
Complies with System Management Bus (SMBus) Specification, Version 2.0
Supports Audio Codec ’97 (AC’97) Revision 2.3
Supports Intel® High Definition Audio
Contains Low Pin Count (LPC) interface
Supports Firmware Hub (FWH) interface
3.1.4 Intel® 915GM Integrated Graphics Media Accelerator 900
The Intel® 915GM has the Intel® GMA900 integrated into the chipset. Some of the features
of the GMA900 are listed below.
Third-generation Graphics Core
o 256-bit graphics core
o 8/16/32 bpp
o Up to 8.5 GB/sec memory bandwidth
o 1.3 GP/sec and 1.3 GT/sec fill rate
o 224MB maximum video memory
o 2048x1536 at 85 Hz maximum resolution
o Dynamic Display Modes for flat-panel and wide-screen support
o Operating systems supported: Microsoft Windows* XP,
Windows 2000, Linux-compatible (Xfree86 source available)
High-performance 3D
o Up to 4 pixels per clock rendering
o Microsoft DirectX* 9 Hardware Acceleration Features:
o Pixel Shader 2.0
Page 24
o Volumetric Textures
o Shadow Maps
IBX-700 Integrated Service Computer
o Slope Scale Depth Bias
o Two-Sided Stencil
o Microsoft DirectX* 9 Vertex Shader 2.0 and Transform and
Lighting supported in software through highly optimized
Processor Specific Geometry Pipeline (PSGP)
o DirectX Texture Decompression
o OpenGL* 1.4 support
Advanced Display Technology
o 400 MHz DAC frequency for up to 2048x1526 resolution for both analog
and digital displays
o Two Serial Digital Video Out (SDVO) ports for flat-panel monitors and/or
TV-out support via Advanced Digital
o Display 2 (ADD2) cards
o Multiple display types (DVI-I, DVI-D, CRT) for dual monitor capabilities
o Hardware motion compensation support for DVD playback
o HDTV 720p and 1080i display resolution support
o 16x9 Aspect Ratio for wide screen displays
High Quality Media Support
o Up and Down Scaling of Video Content
o High Definition Content Decode
o 5x3 Overlay Filtering
Hardware Motion Compensation support for DVD playback
3.1.5 Ethernet Controller Specifications
3.1.5.1 Overview
A highly integrated and cost-effective single-chip, fast Broadcom BCM5787M PCI Express
(PCIe) GbE Ethernet controller is interfaced through the PCIe bus to the CPU and system
chipset. The Broadcom BCM5787M controller provides 10Mbps, 100Mbps or 1000Mbps
Ethernet connectivity to the POS-9153.
3.1.5.2 PCI Express GbE Features
The Broadcom BCM5787M GbE controller combines a triple-speed IEEE 802.3 compliant
Media Access Controller (MAC) with a triple-speed Ethernet transceiver, a PCIe bus
Page 25
r
IBX-700 Integrated Service Compute
interface, and an on-chip buffer memory. Some of the BCM5787 controller features are
listed below:
Integrated 10/100/1000BASE-T transceiver
Automatic MDI crossover function
PCIe v1.0a
10/100/1000BASE-T full/half-duplex MAC
Wake on LAN support meeting the ACPI requirements
Statistics for SNMP MIB II, Ethernet-like MIB, and Ethernet MIB (802.3z,
clause 30)
Serial EEPROM or serial flash support
JTAG support
3.2 Peripheral Interface Connectors
Section 3.2.1 lists all the peripheral interface connectors seen in Section 3.1.1.
3.2.1 Peripheral Interface Connectors
Table 3-2 shows a list of the peripheral interface connectors on the POS motherboard
used for the IBX-700 Series.
Connector Type Label
ATX power connector 24-pin connector PW1
DIMM socket 240-pin connector DDR1
Front panel connector 18-pin header F_PANEL1
PCI socket 124-pin PCI socket PCI1
PCIe x1 socket 36-pin PCIe socket PCIE1
Serial ports (COM5, COM6) and indicators
26-pin header CN6
Page 26
(for COM1~COM4) connector
SATA connector 7-pin connector SATA1
SATA connector 7-pin connector SATA2
IBX-700 Integrated Service Computer
USB connector 8-pin header USB2
Table 3-2: Peripheral Interface Connectors
3.2.2 External Interface Panel Connectors
Table 3-3 lists the rear panel connectors on the POS motherboard.
Connector Type Label
Audio jacks (line-out, mic-in) Audio jack AUDIO1
Cash drawer connector (1) RJ-12 connector CN3
Cash drawer connector (2) RJ-12 connector CN4
CompactFlash® slot 50-pin connector CF1
Ethernet and USB combo connector RJ-45 connector LAN/USB1
Keyboard/mouse connector PS/2 connector KB/MS1
Parallel port DB-26 LPT1
Reset button Push-button RST_BN
RS-232 serial port (COM1, COM2) DB-9 connector CN1
RS-232 serial port (COM3, COM4) DB-9 connector CN2
USB port (PoweredUSB, 12 V) USB port POWERUSB1
VGA connector DB-15 connector VGA1
Table 3-3: Rear Panel Connectors
Page 27
r
A
3.3 On-board Jumpers
NOTE:
jumper is a metal bridge used to close
an electrical circuit. It consists of two or
three metal pins and a small metal clip
IBX-700 Integrated Service Compute
(often protected by a plastic cover) that
slides over the pins to connect them. To
CLOSE/SHORT a jumper means
connecting the pins of the jumper with
the plastic clip and to OPEN a jumper
means removing the plastic clip from a
jumper.
The POS motherboard has several onboard jumpers (Table 3-4).
Description Label Type
ATX power select JP1 3-pin header
Clear CMOS CLR_CMOS1 3-pin header
FSB select JP2 3-pin header
COM1/COM2 power select J_COM1 6-pin header
Figure 3-2: Jumpers
COM3/COM4 power select J_COM2 6-pin header
Table 3-4: Jumpers
3.3.1 ATX Power Select Jumper Settings
Jumper Label: JP1
Jumper Type:
Page 28
3-pin header
IBX-700 Integrated Service Computer
Jumper Settings: See Table 3-5
Jumper Location: See
The ATX Power Select jumper specifies the systems power mode as AT or ATX. ATX
Power Select jumper settings are shown in
ATX Power Select Description
Short 1-2 Use ATX power Default
Short 2-3 Use AT power
Table 3-5: ATX Power Select Jumper Settings
The location of the ATX Power Select jumper is shown in Figure 3-3 below.
Figure 3-3
Table 3-5.
Figure 3-3: ATX Power Select Jumper Location
3.3.2 FSB Select Jumper Settings
Jumper Label: JP2
Jumper Type:
3-pin header
Page 29
r
Jumper Settings: See Table 3-6
IBX-700 Integrated Service Compute
Jumper Location: See
The FSB Select jumper specifies the front side bus (FSB) as 400 MHz or 533 MHz. FSB
Select jumper settings are shown in
FSB Select Description
Short 1-2 400 MHz Default
Short 2-3 533 MHz
Table 3-6: FSB Select Jumper Settings
The location of the FSB Select jumper is shown in Figure 3-3 below.
Figure 3-4
Table 3-5.
Figure 3-4: FSB Select Jumper Location
3.3.3 Clear CMOS Jumper
Jumper Label: CLR_CMOS1
Jumper Type:
Jumper Settings: See
Jumper Location: See
Page 30
3-pin header
Table 3-7
Figure 3-5
IBX-700 Integrated Service Computer
If the IBX-700 Series fails to boot due to improper BIOS settings, the clear CMOS jumper
clears the CMOS data and resets the system BIOS information. To do this, use the jumper
cap to close pins 2 and 3 for a few seconds then reinstall the jumper clip back to pins 1
and 2.
If the “CMOS Settings Wrong” message is displayed during the boot up process, the fault
may be corrected by pressing the F1 to enter the CMOS Setup menu. Do one of the
following:
Enter the correct CMOS setting
Load Optimal Defaults
Load Failsafe Defaults.
After having done one of the above, save the changes and exit the CMOS Setup menu.
The clear CMOS jumper settings are shown in
Clear CMOS Description
Short 1 - 2 Keep CMOS Setup Default
Short 2 - 3 Clear CMOS Setup
Table 3-7.
Table 3-7: Clear CMOS Jumper Settings
The location of the clear CMOS jumper is shown in Figure 3-5 below.
Page 31
r
IBX-700 Integrated Service Compute
Figure 3-5: Clear CMOS Jumper
3.3.4 COM 1/2 Pin 9 Setting Jumper
Jumper Label: J_COM1
Jumper Type:
Jumper Settings: See
Jumper Location: See
The COM 1/2 Pin 9 Setting jumper configures pin 9 on COM 1 and COM 2 as either a +5 V,
or +12 V power source. The COM 1/2 Pin 9 Setting jumper selection options are shown in
Table 3-8.
COM 1/2 Voltage Description
Short 1 – 3 COM 1 Pin 9 use +5 V Default
Short 3 – 5 COM 1 Pin 9 use +12 V
Short 2 – 4 COM 2 Pin 9 use +5 V Default
6-pin header
Table 3-8
Figure 3-6
Page 32
Short 4 – 6 COM 2 Pin 9 use +12 V
Table 3-8: COM 1/2 Pin 9 Setting Jumper Settings
IBX-700 Integrated Service Computer
The COM 1/2 Pin 9 Setting jumper location is shown in Figure 3-6 below.
Figure 3-6: COM 1/2 Pin 9 Setting Jumper Location
3.3.5 COM 3/4 Pin 9 Setting Jumper
Jumper Label: J_COM2
Jumper Type:
Jumper Settings: See
Jumper Location: See
The COM 3/4 Pin 9 Setting jumper configures pin 9 on COM 3 and COM 4 as either a +5 V,
or +12 V power source. The COM 3/4 Pin 9 Setting jumper selection options are shown in
Table 3-9.
6-pin header
Table 3-9
Figure 3-7
Page 33
r
COM 3/4 Voltage Description
Short 1 – 3 COM 3 Pin 9 use +5 V Default
Short 3 – 5 COM 3 Pin 9 use +12 V
Short 2 – 4 COM 4 Pin 9 use +5 V Default
Short 4 – 6 COM 4 Pin 9 use +12 V
IBX-700 Integrated Service Compute
Table 3-9: COM 3/4 Pin 9 Setting Jumper Settings
The COM 3/4 Pin 9 Setting jumper location is shown in Figure 3-6 below.
Page 34
Figure 3-7: COM 3/4 Pin 9 Setting Jumper Location
IBX-700 Integrated Service Computer
Chapter
4
4 Installation
Page 35
r
4.1 Anti-static Precautions
WARNING:
If the following anti-static precautions are not followed, a user may be
injured and the system irreparably damaged.
Electrostatic discharge (ESD) can cause serious damage to electronic components,
including the POS motherboard and the power module. (Dry climates are especially
susceptible to ESD.) It is therefore critical that whenever the IBX-700 Series is opened
and any electrical component handled, the following anti-static precautions are strictly
adhered to.
IBX-700 Integrated Service Compute
Wear an anti-static wristband: Wearing a simple anti-static wristband can
help to prevent ESD from damaging the board.
Self-grounding: Before handling the board, touch any grounded conducting
material. During the time the board is handled, frequently touch any
conducting materials that are connected to the ground.
4.2 Installation Procedure
4.2.1 Installation Procedure Overview
To properly install the IBX-700 Series, the following steps must be followed. Detailed
descriptions of these instructions are listed in the sections that follow.
Step 1: Unpacking
Step 2: Install the CF card
Step 3: Install the four foot pads
Page 36
Step 4: Connect the rear panel peripheral connectors
Step 5: Power the system up Step 0:
IBX-700 Integrated Service Computer
4.2.2 Unpacking
After the IBX-700 Series is received make sure the following components are included in
the package. If any of these components are missing, please contact the IBX-700 Series
reseller or vendor where it was purchased or contact an IEI sales representative
immediately.
STANDARD
Quantity Item Image
1 IBX-700 Series Integrated Service Computer
1 Power adaptor
(P/N: 63000-FSP0841ADC11118-RS)
1 Power cord
(P/N: 32000-085000-RS for USA)
(P/N: 32000-089000-RS for EU)
1 Screw set
(P/N: 19600-000215-RS)
1 DVD-ROM SATA cable
(P/N: 32000-108900-RS)
4 Foot pads
(P/N: 46007-002200-RS)
1 Utility CD (manual, drivers and iSMM)
Page 37
r
OPTIONAL
IBX-700 Integrated Service Compute
1
1
1
1
Table 4-1: Package List Contents
1 GB CompactFlash® card with Windows
WEPOS pre-installed
(P/N: IBXCF-P9103-WEPOS for IBX-700-9103)
(P/N: IBXCF-P9153-WEPOS for IBX-700-9153)
1 GB CompactFlash® card with Windows XPE
pre-installed
(P/N: IBXCF-P9103-XPE for IBX-700-9103)
(P/N: IBXCF-P9153-XPE for IBX-700-9153)
Riser card with one PCI and one PCIe mini
(P/N: PCIR-700)
Riser card with one PCIe x1 and one PCIe mini
(P/N: PCIER-700)
4.2.3 CompactFlash® Card Installation
The IBX-700 Series has one CF slot on the rear panel. To install the CF card, follow the
instructions below.
Step 1: Locate the CF card slot plastic cover on the rear panel.
Step 2: Remove the CF card slot cover by removing the retention screw (
Figure 4-1).
Figure 4-1: CF Card Slot Cover Retention Screw
Page 38
IBX-700 Integrated Service Computer
Step 3: Insert the CF card into the slot.
Step 4: Replace the CF card slot cover. Step 0:
4.2.4 Foot Pad Installation
The IBX-700 Series is shipped with four foot pads. To install the foot pads, follow the
instructions below.
Step 1: Turn the IBX-700 over.
Step 2: Carefully mark the locations of the four foot pads on the bottom surface.
Step 3: Glue the foot pads at the marked locations on the bottom surface. Step 0:
4.2.5 Cable Connections
Once the system has been mounted on the wall, the following connectors can be
connected to the system.
Audio jacks
Keyboard/Mouse connectors
VGA cable connector
Parallel port connector
Serial port connectors
RJ-45 connector
USB and PoweredUSB™ devices can be connected to the system.
The cable connection locations are shown in
4.3 Power-On Procedure
4.3.1 Installation Checklist
Figure 2-3.
WARNING:
Make sure a power supply with the correct input voltage is being fed into
Page 39
r
the system. Incorrect voltages applied to the system may cause damage to
the internal electronic components and may also cause injury to the user.
To power on the IBX-700 please make sure of the following:
The memory module is installed
The wireless LAN module is installed
The CF module is installed
The cover case is installed
All peripheral devices (VGA monitor, serial communications devices etc.) are
connected
The power cables are plugged in
The system is securely mounted
IBX-700 Integrated Service Compute
4.3.2 Power-on Procedure
To power-on the IBX-700 Series please follow the steps below:
Step 1: Push the power button on the front panel.
Step 2: Once turned on, the blue power LED should be turned on. See
Step 0:
Figure 4-2.
Page 40
Figure 4-2: Power Button and Power LED
IBX-700 Integrated Service Computer
Chapter
5
5 AMI BIOS
Page 41
r
5.1 Introduction
A licensed copy of AMI BIOS is preprogrammed into the ROM BIOS. The BIOS setup
program allows users to modify the basic system configuration. This chapter describes
how to access the BIOS setup program and the configuration options that may be
changed.
5.1.1 Starting Setup
The AMI BIOS is activated when the computer is turned on. The setup program can be
activated in one of two ways.
IBX-700 Integrated Service Compute
1. Press the D
2. Press the D
message appears on the screen. 0.
If the message disappears before the D
again.
ELETE key as soon as the system is turned on or
ELETE key when the “Press Del to enter SETUP”
ELETE key is pressed, restart the computer and try
5.1.2 Using Setup
Use the arrow keys to highlight items, press ENTER to select, use the PageUp and
PageDown keys to change entries, press F1 for help and press E
keys are shown in.
Key Function
Up arrow Move to previous item
Down arrow Move to next item
Left arrow Move to the item on the left hand side
SC to quit. Navigation
Page 42
Right arrow Move to the item on the right hand side
Esc key Main Menu – Quit and not save changes into CMOS
Status Page Setup Menu and Option Page Setup Menu --
Exit current page and return to Main Menu
Page Up key Increase the numeric value or make changes
Page Dn key Decrease the numeric value or make changes
IBX-700 Integrated Service Computer
F1 key General help, only for Status Page Setup Menu and Option
Page Setup Menu
F2 /F3 key Change color from total 16 colors. F2 to select color
forward.
F10 key Save all the CMOS changes, only for Main Menu
Table 5-1: BIOS Navigation Keys
5.1.3 Getting Help
When F1 is pressed a small help window describing the appropriate keys to use and the
possible selections for the highlighted item appears. To exit the Help Window press E
SC or
the F1 key again.
5.1.4 Unable to Reboot After Configuration Changes
If the computer cannot boot after changes to the system configuration is made, CMOS
defaults. Use the jumper described in Section
3.3.3.
5.1.5 BIOS Menu Bar
The menu bar on top of the BIOS screen has the following main items:
Main Changes the basic system configuration.
Advanced Changes the advanced system settings.
PCIPnP Changes the advanced PCI/PnP Settings
Boot Changes the system boot configuration.
Security Sets User and Supervisor Passwords.
Chipset Changes the chipset settings.
Power Changes power management settings.
Exit Selects exit options and loads default settings
The following sections completely describe the configuration options found in the menu
items at the top of the BIOS screen and listed above.
Page 43
r
5.2 Main
The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered.
The Main menu gives an overview of the basic system information.
IBX-700 Integrated Service Compute
BIOS Menu 1: Main
System Overview
The System Overvie w lists a brief summary of different system components. The fields in
System Overview cannot be changed. The items shown in the system overview include:
AMI BIOS: Displays auto-detected BIOS information
Processor: Displays auto-detected CPU specifications
Page 44
o Version: Current BIOS version
o Build Date: Date the current BIOS version was made
o ID: Installed BIOS ID
o Type: Names the currently installed processor
o Speed: Lists the processor speed
IBX-700 Integrated Service Computer
o Count: The number of CPUs on the motherboard
System Memory: Displays the auto-detected system memory.
o Size: Lists memory size
The System Overview field also has two user configurable fields:
System Time [xx:xx:xx]
Use the System Time option to set the system time. Manually enter the hours, minutes
and seconds.
System Date [xx/xx/xx]
Use the System Date option to set the system date. Manually enter the day, month and
year.
5.3 Advanced
Use the Advanced menu (BIOS Menu 2) to configure the CPU and peripheral devices
through the following sub-menus:
Setting the wrong values in the sections below may cause the system to
malfunction. Make sure that the settings made are compatible with the
hardware.
CPU Configuration (see Section 5.3.1)
IDE Configuration (see Section 5.3.2)
Super IO Configuration (see Section 5.3.3)
Hardware Health Configuration (see Section 5.3.4)
Remote Access Configuration (see Section 5.3.5)
WARNING!
USB Configuration (see Section 5.3.6)
Page 45
r
IBX-700 Integrated Service Compute
BIOS Menu 2: Advanced
5.3.1 CPU Configuration
Use the CPU Configuration menu (BIOS Menu 3) to view detailed CPU specifications
and configure the CPU.
Page 46
IBX-700 Integrated Service Computer
BIOS Menu 3: CPU Configuration
The CPU Configuration menu (
Manufacturer: Lists the name of the CPU manufacturer
Brand String: Lists the brand name of the CPU being used
Frequency: Lists the CPU processing speed
FSB Speed: Lists the FSB speed
Cache L1: Lists the CPU L1 cache size
Cache L2: Lists the CPU L2 cache size
BIOS Menu 3) lists the following CPU details:
5.3.2 IDE Configuration
Use the IDE Configuration menu (BIOS Menu 4) to change and/or set the configuration
of the IDE devices installed in the system.
Page 47
r
IBX-700 Integrated Service Compute
BIOS Menu 4: IDE Configuration
ATA/IDE Configurations [Enhanced]
Use the ATA/IDE Configurations option to configure the ATA/IDE controller.
Disabled
Compatible
Enhanced D
Disables the on-board ATA/IDE controller.
Configures the on-board ATA/IDE controller to be in
compatible mode. In this mode, a SATA channel will
replace one of the IDE channels. This mode supports up
to 4 storage devices.
EFAULT
Configures the on-board ATA/IDE controller to be in
Enhanced mode. In this mode, IDE channels and SATA
channels are separated. This mode supports up to 6
Page 48
storage devices. Some legacy OS do not support this
mode.
IBX-700 Integrated Service Computer
IDE Master and IDE Slave
When entering setup, BIOS auto detects the presence of IDE devices. BIOS displays the
status of the auto detected IDE devices. The following IDE devices are detected and are
shown in the IDE Configuration menu:
Primary IDE Master
Primary IDE Slave
Secondary IDE Master
Secondary IDE Slave
Third IDE Master
Third IDE Slave
The IDE Configuration menu (
BIOS Menu 4) allows changes to the configurations for the
IDE devices installed in the system. If an IDE device is detected, and one of the above
listed four BIOS configuration options are selected, the IDE configuration options shown in
Section
5.3.2.1 appear.
SATA Controller Mode Select [IDE]
Use the SATA Controller Mode Select option to configure SATA devices as normal IDE
devices.
IDE D
RAID
AHCI
EFAULT
Configures SATA devices as normal IDE device.
Configures SATA devices as a RAID device.
Configures SATA devices as a AHCI device.
5.3.2.1 IDE Master, IDE Slave
Use the IDE Master and IDE Slave configuration menu to view both primary and
secondary IDE device details and configure the IDE devices connected to the system.
Page 49
r
IBX-700 Integrated Service Compute
BIOS Menu 5: IDE Master and IDE Slave Configuration
Auto-Detected Drive Parameters
The “grayed-out” items in the left frame are IDE disk drive parameters automatically
detected from the firmware of the selected IDE disk drive. The drive parameters are listed
as follows:
Device: Lists the device type (e.g. hard disk, CD-ROM etc.)
Type: Indicates the type of devices a user can manually select
Vendor: Lists the device manufacturer
Size: List the storage capacity of the device.
LBA Mode: Indicates whether the LBA (Logical Block Addressing) is a method
of addressing data on a disk drive is supported or not.
Block Mode: Block mode boosts IDE drive performance by increasing the
amount of data transferred. Only 512 bytes of data can be transferred per
Page 50
interrupt if block mode is not used. Block mode allows transfers of up to 64 KB
per interrupt.
PIO Mode: Indicates the PIO mode of the installed device.
IBX-700 Integrated Service Computer
Async DMA: Indicates the highest Asynchronous DMA Mode that is
supported.
Ultra DMA: Indicates the highest Synchronous DMA Mode that is supported.
S.M.A.R.T.: Indicates whether or not the Self-Monitoring Analysis and
Reporting Technology protocol is supported.
Type [Auto]
Use the Type BIOS option select the type of device the AMIBIOS attempts to boot from
after the Power-On Self-Test (POST) is complete.
Not Installed
Auto D
CD/DVD
ARMD
BIOS is prevented from searching for an IDE disk
drive on the specified channel.
EFAULT
The BIOS auto detects the IDE disk drive type
attached to the specified channel. This setting should
be used if an IDE hard disk drive is attached to the
specified channel.
The CD/DVD option specifies that an IDE CD-ROM
drive is attached to the specified IDE channel. The
BIOS does not attempt to search for other types of
IDE disk drives on the specified channel.
This option specifies an ATAPI Removable Media
Device. These include, but are not limited to:
LBA/Large Mode [Auto]
Use the LBA/Large Mode option to disable or enable BIOS to auto detects LBA (Logical
Block Addressing). LBA is a method of addressing data on a disk drive. In LBA mode, the
maximum drive capacity is 137 GB.
ZIP
LS-120
Page 51
r
IBX-700 Integrated Service Compute
Disabled
BIOS is prevented from using the LBA mode control on
the specified channel.
Auto D
EFAULT
BIOS auto detects the LBA mode control on the specified
channel.
Block (Multi Sector Transfer) [Auto]
Use the Block (Multi Sector Transfer) to disable or enable BIOS to auto detect if the
device supports multi-sector transfers.
Disabled
BIOS is prevented from using Multi-Sector Transfer on the
specified channel. The data to and from the device occurs
one sector at a time.
Auto D
EFAULT
BIOS auto detects Multi-Sector Transfer support on the
drive on the specified channel. If supported the data
transfer to and from the device occurs multiple sectors at
a time.
PIO Mode [Auto]
Use the PIO Mode option to select the IDE PIO (Programmable I/O) mode program timing
cycles between the IDE drive and the programmable IDE controller. As the PIO mode
increases, the cycle time decreases.
Auto D
EFAULT
BIOS auto detects the PIO mode. Use this value if the IDE disk
drive support cannot be determined.
0
1
2
PIO mode 0 selected with a maximum transfer rate of 3.3MBps
PIO mode 1 selected with a maximum transfer rate of 5.2MBps
PIO mode 2 selected with a maximum transfer rate of 8.3MBps
Page 52
3
PIO mode 3 selected with a maximum transfer rate of 11.1MBps
IBX-700 Integrated Service Computer
4
PIO mode 4 selected with a maximum transfer rate of 16.6MBps
(This setting generally works with all hard disk drives
manufactured after 1999. For other disk drives, such as IDE
CD-ROM drives, check the specifications of the drive.)
DMA Mode [Auto]
Use the DMA Mode BIOS selection to adjust the DMA mode options.
Auto D
EFAULT
BIOS auto detects the DMA mode. Use this value if the IDE
disk drive support cannot be determined.
S.M.A.R.T [Auto]
Use the S.M.A.R.T option to auto-detect, disable or enable Self-Monitoring Analysis and
Reporting Technology (SMART) on the drive on the specified channel. S.M.A.R.T predicts
impending drive failures. The S.M.A.R.T BIOS option enables or disables this function.
Auto D
Disabled
Enabled
EFAULT
Prevents BIOS from using the HDD SMART feature.
Allows BIOS to use the HDD SMART feature
32Bit Data Transfer [Enabled]
Use the 32Bit Data Transfer BIOS option to enables or disable 32-bit data transfers.
Disabled
Enabled D
Prevents the BIOS from using 32-bit data transfers.
EFAULT
BIOS auto detects HDD SMART support.
Allows BIOS to use 32-bit data transfers on supported
hard disk drives.
Page 53
r
5.3.3 Super IO Configuration
Use the Super IO Configuration menu (BIOS Menu 6) to set or change the
configurations for the FDD controllers, parallel ports and serial ports.
IBX-700 Integrated Service Compute
BIOS Menu 6: Super IO Configuration
Serial Port1 Address [3F8/IRQ4]
Use the Serial Port1 Address option to select the Serial Port 1 base address.
Page 54
Disabled
3F8/IRQ4 DEFAULT
3E8/IRQ4
No base address is assigned to Serial Port 1
Serial Port 1 I/O port address is 3E8 and the interrupt
Serial Port 1 I/O port address is 3F8 and the interrupt
address is IRQ4
address is IRQ4
IBX-700 Integrated Service Computer
2E8/IRQ3
Serial Port1 Mode [Normal]
Use the Serial Port1 Mode option to select the transmitting and receiving mode for the
first serial port.
Normal DEFAULT
IrDA
ASK IR
Serial Port2 Address [2F8/IRQ3]
Use the Serial Port2 Address option to select the Serial Port 2 base address.
Serial Port 1 I/O port address is 2E8 and the interrupt
address is IRQ3
Serial Port 1 mode is normal
Serial Port 1 mode is IrDA
Serial Port 1 mode is ASK IR
Disabled
2F8/IRQ3 D
3E8/IRQ4
2E8/IRQ3
Serial Port2 Mode [Normal]
Use the Serial Port2 Mode option to select the Serial Port2 operational mode.
Normal
IrDA
No base address is assigned to Serial Port 2
EFAULT
Serial Port 2 I/O port address is 3E8 and the interrupt
Serial Port 2 I/O port address is 2E8 and the interrupt
DEFAULT
Serial Port 2 mode is IrDA
Serial Port 2 I/O port address is 3F8 and the interrupt
address is IRQ3
address is IRQ4
address is IRQ3
Serial Port 2 mode is normal
ASK IR
Serial Port 2 mode is ASK IR
Page 55
r
Parallel Port Address [378]
Use the Parallel Port Address option to select the parallel port base address.
IBX-700 Integrated Service Compute
Disabled
378 D
278
3BC
Parallel Port Mode [Normal]
Use the Parallel Port Mode option to select the mode the parallel port operates in.
Normal D
EPP
EFAULT
Parallel Port I/O port address is 278
Parallel Port I/O port address is 3BC
No base address is assigned to the Parallel Port
Parallel Port I/O port address is 378
EFAULT
The parallel port operates in the enhanced parallel
The normal parallel port mode is the standard mode
for parallel port operation.
port mode (EPP). The EPP mode supports
bi-directional communication between the system
Page 56
ECP
ECP+EPP
and the parallel port device and the transmission
rates between the two are much faster than the
Normal mode.
The parallel port operates in the extended
capabilities port (ECP) mode. The ECP mode
supports bi-directional communication between the
system and the parallel port device and the
transmission rates between the two are much faster
than the Normal mode.
The parallel port operates in the extended
capabilities port (ECP) mode. The ECP mode
supports bi-directional communication between the
IBX-700 Integrated Service Computer
system and the parallel port device and the
transmission rates between the two are much faster
than the Normal mode
The parallel port is also be compatible with EPP
devices described above
Parallel Port IRQ [IRQ7]
Use the Parallel Port IRQ selection to set the parallel port interrupt address.
IRQ5
IRQ7 D
IRQ5 is assigned as the parallel port interrupt address
EFAULT
IRQ7 is assigned as the parallel port interrupt address
Serial Port3 Address [3E8]
Use the Serial Port3 Address option to select the base addresses for serial port 3
Disabled
3E8 D
2E8
No base address is assigned to serial port 3
EFAULT
Serial port 3 I/O port address is 3E8
Serial port 3 I/O port address is 2E8
Serial Port3 IRQ [10]
Use the Serial Port3 IRQ option to select the interrupt address for serial port 3.
10 D
EFAULT
Serial port 3 IRQ address is 10
Serial Port4 Address [2E8]
Use the Serial Port4 IRQ option to select the interrupt address for serial port 4.
Disabled
3E8
No base address is assigned to serial port 3
Serial port 4 I/O port address is 3E8
Page 57
r
IBX-700 Integrated Service Compute
2E8 D
EFAULT
Serial port 4 I/O port address is 2E8
Serial Port4 IRQ [10]
Use the Serial Port4 IRQ option to select the interrupt address for serial port 4.
10 D
EFAULT
Serial port 4 IRQ address is 10
Serial Port5 Address [2F0]
Use the Serial Port5 IRQ option to select the interrupt address for serial port 5.
Disabled
3E8
2E8
2F0 D
No base address is assigned to serial port 5
Serial port 5 I/O port address is 3E8
Serial port 5 I/O port address is 2E8
EFAULT
Serial port 5 I/O port address is 2F0
2E0
Serial port 5 I/O port address is 2E0
Serial Port5 IRQ [10]
Use the Serial Port5 IRQ option to select the interrupt address for serial port 5.
10 D
EFAULT
Serial port 5 IRQ address is 10
Serial Port6 Address [2E0]
Use the Serial Port6 IRQ option to select the interrupt address for serial port 6.
Disabled
3E8
2E8
2F0
No base address is assigned to serial port 6
Serial port 6 I/O port address is 3E8
Serial port 6 I/O port address is 2E8
Serial port 6I/O port address is 2F0
Page 58
IBX-700 Integrated Service Computer
2E0 D
Serial Port6 IRQ [10]
Use the Serial Port6 IRQ option to select the interrupt address for serial port 6.
10 D
EFAULT
EFAULT
Serial port 6I/O port address is 2E0
Serial port 6 IRQ address is 10
5.3.4 Hardware Health Configuration
The Hardware Health Configuration menu (BIOS Menu 7) shows the operating
temperature, fan speeds and system voltages.
BIOS Menu 7: Hardware Health Configuration
FAN Mode Setting [Full On Mode]
Use the FAN Mode Setting option to configure the second fan.
Page 59
r
IBX-700 Integrated Service Compute
Full On Mode D
Automatic mode
PWM Manual mode
When the FAN Mode Setting option is in the Automatic Mode, the following parameters
can be set.
Temp. Limit of OFF
Temp. Limit of Start
Temp. Limit of Full
Fan Start PWM
Slope PWM 1
When the CPU FAN Mode Setting option is in the PWM Manual Mode, the following
EFAULT
Fan is off when the temperature is low
Pulse width modulation set manually
Fan is on all the time
enough. Parameters must be set by the
user.
parameters can be set.
Fan PWM control
The following system parameters and values are shown. The system parameters that are
monitored are:
System Temperatures: The following system temperatures are monitored
o CPU Temperature
o System Temperature #1
o System Temperature #2
Fan Speeds: The CPU cooling fan speed is monitored.
o CPU Fan
o System Fan
Voltages: The following system voltages are monitored
o CPU Core
o +3.30Vin
Page 60
o +5.00Vin
IBX-700 Integrated Service Computer
o +12Vin
o 5VSB
o VBAT
5.3.5 Remote Access Configuration
Use the Remote Access Configuration menu (BIOS Menu 8) to configure remote
access parameters. The Remote Access Configuration is an AMIBIOS feature and
allows a remote host running a terminal program to display and configure the BIOS
settings.
BIOS Menu 8: Remote Access Configuration [Advanced]
Remote Access [Disabled]
Use the Remote Access option to enable or disable access to the remote functionalities
of the system.
Disabled D
EFAULT
Remote access is disabled.
Page 61
r
IBX-700 Integrated Service Compute
Enabled
Serial Port Number [COM1]
Use the Serial Port Number option allows to select the serial port used for remote
access.
COM1 D
Remote access configuration options shown below
appear:
Serial Port Number
Serial Port Mode
Redirection after BIOS POST
Terminal Type
These configuration options are discussed below.
EFAULT
System is remotely accessed through COM1
COM2
NOTE: Make sure the selected COM port is enabled through the Super I/O configuration
menu.
Base Address, IRQ [3F8h, 4]
The Base Address, IRQ option cannot be configured and only shows the interrupt
address of the serial port listed above.
Serial Port Mode [115200 8,n,1]
Use the Serial Port Mode option to select baud rate through which the console redirection
is made. The following configuration options are available
115200 8,n,1 DEFAULT
57600 8,n,1
38400 8,n,1
System is remotely accessed through COM2
Page 62
IBX-700 Integrated Service Computer
19200 8,n,1
09600 8,n,1
NOTE:
Identical baud rate setting musts be set on the host (a management
computer running a terminal software) and the slave
Redirection After BIOS POST [Always]
Use the Redirection After BIOS POST option to specify when console redirection should
occur.
Disabled
Boot Loader
Always D
Terminal Type [ANSI]
Use the Terminal Type BIOS option to specify the remote terminal type.
ANSI D
VT100
VT-UTF8
The console is not redirected after POST
Redirection is active during POST and during Boot
Loader
EFAULT
EFAULT
The target terminal type is VT100
The target terminal type is VT-UTF8
Redirection is always active (Some OSes may not
work if set to Always)
The target terminal type is ANSI
5.3.6 USB Configuration
Use the USB Configuration menu (BIOS Menu 9) to read USB configuration information
and configure the USB settings.
Page 63
r
IBX-700 Integrated Service Compute
BIOS Menu 9: USB Configuration
USB Configuration
The USB Configuration field shows the system USB configuration. The items listed are:
Module Version: x.xxxxx.xxxxx
USB Devices Enabled
The USB Devices Enabled field lists the USB devices that are enabled on the system
USB Function [Enabled]
Use the USB Function BIOS option to enable or disable USB function support.
Disabled
USB function support disabled
Page 64
Enabled D
EFAULT
USB function support enabled
IBX-700 Integrated Service Computer
USB 2.0 Controller [Enabled]
Use the USB 2.0 Controller BIOS option to enable or disable the USB 2.0 controller
Enabled D
Disabled
Legacy USB Support [Enabled]
Use the Legacy USB Support BIOS option to enable USB mouse and USB keyboard
support.
Normally if this option is not enabled, any attached USB mouse or USB keyboard does not
become available until a USB compatible operating system is fully booted with all USB
drivers loaded. When this option is enabled, any attached USB mouse or USB keyboard
can control the system even when there is no USB driver loaded onto the system.
Disabled
Enabled D
EFAULT
USB 2.0 controller disabled
Legacy USB support disabled
EFAULT
USB 2.0 controller enabled
Legacy USB support enabled
Auto
USB2.0 Controller Mode [HiSpeed]
Use the USB2.0 Controller Mode option to set the speed of the USB2.0 controller.
FullSpeed
HiSpeed D
The controller is capable of operating at 12Mb/s
EFAULT
Legacy USB support disabled if no USB devices are
connected
The controller is capable of operating at 480Mb/s
5.3.6.1 USB Mass Storage Device Configuration
Use the USB Mass Storage Device Con figuration menu (BIOS Menu 10) to configure
USB mass storage class devices.
Page 65
r
IBX-700 Integrated Service Compute
BIOS Menu 10: USB Mass Storage Device Configuration
USB Mass Storage Reset Delay [20 Sec]
Use the USB Mass Storage Reset Delay option to set the number of seconds POST
waits for the USB mass storage device after the start unit command.
10 Sec
20 Sec D
30 Sec
POST waits 10 seconds for the USB mass storage
device after the start unit command.
EFAULT
POST waits 30 seconds for the USB mass storage
POST waits 20 seconds for the USB mass storage
device after the start unit command.
device after the start unit command.
Page 66
40 Sec
POST waits 40 seconds for the USB mass storage
device after the start unit command.
IBX-700 Integrated Service Computer
Device ##
The Device## field lists the USB devices that are connected to the system.
Emulation Type [Auto]
Use the Emulation Type BIOS option to specify the type of emulation BIOS has to
provide for the USB device.
NOTE:
Please note that the device’s formatted type and the emulation type
provided by the BIOS must match for a device to boot properly. If both
types do not match then device’s behavior is undefined. To make sure both
types match, format the device using BIOS INT13h calls after selecting the
proper emulation option in BIOS setup. The FORMAT utility provided by
Microsoft® MS-DOS®, Microsoft® Windows® 95, and Microsoft®
Windows® 98 can be used for this purpose.
Auto D
Floppy
Forced FDD
Hard Disk
EFAULT
BIOS auto-detects the current USB.
The USB device will be emulated as a floppy drive.
The device can be either A: or B: responding to
INT13h calls that return DL = 0 or DL = 1
respectively.
Allows a hard disk image to be connected as a
floppy image. This option works only for drives
formatted with FAT12, FAT16 or FAT32.
Allows the USB device to be emulated as hard disk
responding to INT13h calls that return DL values of
80h or above.
Page 67
r
IBX-700 Integrated Service Compute
CDROM
5.4 PCI/PnP
Use the PCI/PnP menu (BIOS Menu 11) to configure advanced PCI and PnP settings.
WARNING!
Assumes the CD-ROM is formatted as bootable
media. All the devices that support block sizes
greater than 512 bytes can only be booted using this
option.
Setting wrong values for the BIOS selections in the PCIPnP BIOS menu
may cause the system to malfunction.
Page 68
BIOS Menu 11: PCI/PnP Configuration
IBX-700 Integrated Service Computer
IRQ# [Available]
Use the IRQ# address to specify what IRQs can be assigned to a particular peripheral
device.
Available DEFAULT
Reserved
The specified IRQ is reserved for use by Legacy ISA
Available IRQ addresses are:
IRQ3
IRQ4
IRQ5
IRQ7
IRQ9
IRQ10
IRQ 11
IRQ 14
IRQ 15
The specified IRQ is available to be used by
PCI/PnP devices
devices
DMA Channel# [Available]
Use the DMA Channel# option to assign a specific DMA channel to a particular PCI/PnP
device.
Available D
Reserved
Available DMA Channels are:
DM Channel 0
EFAULT
The specified DMA is available to be used by
PCI/PnP devices
The specified DMA is reserved for use by Legacy
ISA devices
Page 69
r
DM Channel 1
DM Channel 3
DM Channel 5
DM Channel 6
DM Channel 7
Reserved Memory Size [Disabled]
Use the Reserved Memory Size BIOS option to specify the amount of memory that
should be reserved for legacy ISA devices.
IBX-700 Integrated Service Compute
5.5 Boot
Use the Boot menu (BIOS Menu 12) to configure system boot options.
Disabled D
16K
32K
64K
EFAULT
16KB reserved for legacy ISA devices
32KB reserved for legacy ISA devices
54KB reserved for legacy ISA devices
No memory block reserved for legacy ISA devices
Page 70
IBX-700 Integrated Service Computer
BIOS Menu 12: Boot
5.5.1 Boot Settings Configuration
Use the Boot Settings Configuration menu (BIOS Menu 13) to configure advanced
system boot options.
Page 71
r
IBX-700 Integrated Service Compute
BIOS Menu 13: Boot Settings Configuration
Quick Boot [Enabled]
Use the Quick Boot BIOS option to make the computer speed up the boot process.
Disabled
Enabled D
Quiet Boot [Disabled]
Use the Quiet Boot BIOS option to select the screen display when the system boots.
Disabled D
No POST procedures are skipped
EFAULT
EFAULT
Some POST procedures are skipped to decrease
the system boot time
Normal POST messages displayed
Page 72
Enabled
OEM Logo displayed instead of POST messages
IBX-700 Integrated Service Computer
AddOn ROM Display Mode [Keep Current]
Use the AddOn ROM Display Mode option to allow add-on ROM (read-only memory)
messages to be displayed.
Force BIOS
The system forces third party BIOS to display
during system boot.
Keep Current D
EFAULT
The system displays normal information during
system boot.
Bootup Num-Lock [On]
Use the Bootup Num-Lock BIOS option to specify if the number lock setting must be
modified during boot up.
Does not enable the keyboard Number Lock automatically. To
Off
use the 10-keys on the keyboard, press the Number Lock key
located on the upper left-hand corner of the 10-key pad. The
Number Lock LED on the keyboard lights up when the Number
Lock is engaged.
On D
LAN Boot [Disabled]
Use the LAN Boot option to enable the system to be booted from a remote system.
Disabled D
EFAULT
Allows the Number Lock on the keyboard to be enabled
automatically when the computer system boots up. This allows
the immediate use of the 10-key numeric keypad located on
the right side of the keyboard. To confirm this, the Number
Lock LED light on the keyboard is lit.
EFAULT
Cannot be booted from a remote system through the
LAN
Page 73
r
IBX-700 Integrated Service Compute
Enabled D
EFAULT
Can be booted from a remote system through the
LAN
5.5.2 Boot Device Priority
Use the Boot Device Priority menu to specify the boot sequence from the available
devices. Possible boot devices may include:
HDD
st
1
FLOPPY DRIVE
CD/DVD
5.5.3 Hard Disk Drives
Use the Hard Disk Drives menu to specify the boot sequence of the available HDDs.
When the menu is opened, the HDDs connected to the system are listed as shown below:
1st Drive [HDD: PM-(part number)]
2nd Drive [HDD: PS-(part number)]
The boot sequence from the available devices is selected. If the “1st Drive” option is
selected a list of available HDDs is shown. Select the first HDD the system boots from. If
the “1st Drive” is not used for booting this option may be disabled.
5.6 Security
Use the Security menu (BIOS Menu 14) to set system and user passwords.
NOTE:
Only the drives connected to the system are shown. For example, if only
two HDDs are connected only “1st Drive” and “2nd Drive” are listed.
Page 74
IBX-700 Integrated Service Computer
BIOS Menu 14: Security
Change Supervisor Password
Use the Change Supervisor Password to set or change a supervisor password. The
default for this option is Not Installed. If a supervisor password must be installed, select
this field and enter the password. After the password has been added, Install appears
next to Change Supervisor Password.
Change User Password
Use the Change User Password to set or change a user password. The default for this
option is Not Installed. If a user password must be installed, select this field and enter the
password. After the password has been added, Install appears next to Change User
Password.
Page 75
r
Clear User Password
Use the Clear User Password to clear a user’s password. The default for this option is
Not Installed. If a user password must be cleared, use this option.
5.7 Chipset
Use the Chipset menu (BIOS Menu 15) to access the Northbridge and Southbridge
configuration menus
Setting the wrong values for the Chipset BIOS selections in the Chipset
BIOS menu may cause the system to malfunction.
IBX-700 Integrated Service Compute
WARNING!
Page 76
BIOS Menu 15: Chipset
IBX-700 Integrated Service Computer
5.7.1 NorthBridge Configuration
Use the Northbridge Chipset Configuration menu (BIOS Menu 16) to configure the
Northbridge chipset.
BIOS Menu 16:Northbridge Chipset Configuration
Memory Hole [Disabled]
Use the Memory Hole option to reserve memory space between 15MB and 16MB for ISA
expansion cards that require a specified area of memory to work properly. If an older ISA
expansion card is used, please refer to the documentation that came with the card to see if
it is necessary to reserve the space.
Disabled D
15MB – 16MB
EFAULT
Between 15MB and 16MB of memory is reserved for
Memory is not reserved for ISA expansion cards
ISA expansion cards
Page 77
r
Boots Graphics Adapter Priority [PEG/PCI]
Use the Boots Graphics Adapter Priority option to select the graphics controller used as
the primary boot device. Select either an integrated graphics controller (IGD) or a
combination of PCI graphics controller, a PCI express (PEG) controller or an IGD.
Configuration options are listed below:
IGD
PEG/IGD DEFAULT
Internal Graphics Mode Select [Enable, 8MB]
Use the Internal Graphic Mode Select option to specify the amount of system memory
that can be used by the Internal graphics device.
IBX-700 Integrated Service Compute
Disable
Enable, 1MB
Enable, 8MB D
Aperture Size Select [256MB]
Use the Aperture Size Select option to select the size of the AGP aperture and the size of
the GART (Graphics Address Relocation Table). The aperture is a portion on the PCI
memory address range dedicated for use as AGP memory address space and the GART
is a translation table that translates the AGP memory addresses into actual addresses.
The following options are available.
256MB DEFAULT
128MB
1MB of memory used by internal graphics device
EFAULT
8MB of memory used by internal graphics device
5.7.2 Southbridge Configuration
Page 78
The Southbridge Configuration menu (BIOS Menu 17) the Southbridge chipset to be
configured.
IBX-700 Integrated Service Computer
BIOS Menu 17:Southbridge Chipset Configuration
Spectrum [Disabled]
Use the Spectrum option to reduce the EMI. Excess EMI is generated when the system
clock generator pulses have extreme values. Spreading the pulse spectrum modulates
changes in the extreme values from spikes to flat curves, thus reducing the EMI. This
benefit may in some cases be outweighed by problems with timing-critical devices, such
as a clock-sensitive SCSI device.
Disabled D
Enabled
Azalia/AC97 Selection [Enabled]
EFAULT
EMI reduced
EMI not reduced
Use the Azalia/AC97 Selection option to select Azalia (HD Audio) or AC’97 as the audio
codec.
Auto
The audio codec automatically detected and enabled
Page 79
r
IBX-700 Integrated Service Compute
Azalia
AC’97 Audio D
Disabled
Cash drawer control [Enabled]
Use the Cash drawer control option to enable or disable the control of cash drawer
connected to the RJ-12 connectors.
Disabled
Enabled D
The Cash drawer control is disabled
EFAULT
5.8 Power
The Power menu (BIOS Menu 18) allows the advanced power management options to be
configured.
The Azalia (HD Audio) is enabled
EFAULT
The onboard audio controller is disabled
The onboard AC’97 automatically detected and enabled
The Cash drawer control is enabled
Page 80
BIOS Menu 18:Power
IBX-700 Integrated Service Computer
Power Button Mode [On/Off]
Use the Power Button Mode BIOS to specify how the power button functions.
On/Off D
EFAULT
When the power button is pressed the system is either
turned on or off
Suspend
When the power button is pressed the system goes into
suspend mode
Restore on AC Power Loss [Last State]
Use the Restore on AC Power Loss BIOS option to specify what state the system
returns to if there is a sudden loss of power to the system.
Power Off
Power On
Last State D
The system remains turned off
The system turns on
EFAULT
The system returns to its previous state. If it was on, it
turns itself on. If it was off, it remains off.
Power Type [by H/W]
Use the Power Type BIOS option to select the power supply that is connected to the
system.
AT
ATX
By H/W D
PME Resume on [Enabled]
Use the Resume on PME BIOS option to enable activity on the PCI PME (power
management event) controller to rouse the system from a suspend or standby state.
EFAULT
An AT power supply is connected to the system
An ATX power supply is connected to the system
The power type is selected by the jumper on the
motherboard
Page 81
r
IBX-700 Integrated Service Compute
Disabled D
Enabled
RTC Resume [Disabled]
Use the RTC Resume option to specify the time the system should be roused from a
suspended state.
Disabled D
Enabled
EFAULT
Wake event generated by PCI PME controller activity
EFAULT
If selected, the following appears with values that
Wake event not generated by PCI PME controller
activity
The real time clock (RTC) cannot generate a wake
event
can be selected:
RTC Alarm Date (Days)
System Time
After setting the alarm, the computer turns itself on
from a suspend state when the alarm goes off.
Resume on Keyboard/Mouse [Disabled]
The Resume on Keyboard/Mouse BIOS option specifies if the system is roused from a
suspended or standby state when there is activity on the PS/2 mouse.
Disabled DEFAULT
S3
S3/S4/S5
PS/2 keyboard/mouse activity rouses the system from
PS/2 keyboard/mouse activity rouses the system from
PS/2 keyboard/mouse activity cannot rouse the
system from a suspend stated.
an S3 Sleep state
an S3, S4 or S5 Sleep state
Page 82
