MODEL:

AFOKAR-08A-RK39

8” In-Vehicle Android Panel PC with P-CAP Touchscreen,

Rev. 1.00 – October 8, 2018

Rockchip RK3399 on-board SoC, O BD-II, GPS, HDMI,

microSD, USB 2.0/3.0, RS-232, Wi-Fi, Bluetooth, Camera,

Digital I/O, RoHS Compliant, IP 54 Fr ont Panel

User Manual

AFOKAR-08A-RK39

Page II

Date Version Changes

October 8, 2018 1.00 Initial release

Revision

AFOKAR-08A-RK39

Page III

Copyright

COPYRIGHT NOTICE

The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.

In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibil ity of such damages.

This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.

TRADEMARKS

All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

AFOKAR-08A-RK39

Page IV

Manual Conventions

WARNING

Warnings appear where overlooked details may cause damage to the
equipment or result in personal injury. Warnings should be taken
seriously.

CAUTION

Cautionary messages should be heeded to help red uce the chance of
losing data or damaging the product.

NOTE

These messages inform the reader of essenti al but non-critical
information. These messages should be read carefully as any directions
or instructions contained therein can help avoid making mistakes.

AFOKAR-08A-RK39

Page V

Table of Contents

1 INTRODUCTION .......................................................................................................... 1

1.1 OVERVIEW .................................................................................................................. 2

1.2 FEATURES ................................................................................................................... 2

1.3 FRONT PANEL ............................................................................................................. 3

1.3.1 LED Indicators ................................................................................................... 4

1.4 REAR PANEL ............................................................................................................... 5

1.5 TOP & BOTTOM PANEL ............................................................................................... 6

1.6 SIDE PANEL ................................................................................................................ 6

1.7 DIMENSIONS ............................................................................................................... 7

1.8 SYSTEM SPECIFICATIONS ............................................................................................ 8

2 UNPACKING ............................................................................................................... 10

2.1 PACKING LIST ............................................................................................................ 11

2.2 OPTIONAL ITEMS ...................................................................................................... 12

3 INSTALLATION ......................................................................................................... 14

3.1 ANTI-STATIC PRECAUTIONS ...................................................................................... 15

3.2 INSTALLATION PRECAUTIONS ................................................................................... 15

3.3 MICROSD CARD INSTALLATION ................................................................................ 16

3.4 SIM CARD INSTALLATION (OPTIONAL) .................................................................... 17

3.5 MOUNTING THE SYSTEM .......................................................................................... 19

3.6 EXTERNAL I/O CONNECTORS ................................................................................... 20

3.6.1 I/O Connector 1 (20-pin) ................................................................................. 20

3.6.2 I/O Connector 2 (24-pin) ................................................................................. 22

3.6.3 HDMI Connector ............................................................................................. 23

3.6.4 Power Input Connection .................................................................................. 24

3.6.5 USB Connector ................................................................................................ 25

3.7 POWER-ON PROCEDURE ........................................................................................... 26

3.8 AVAILABLE DRIVERS ................................................................................................ 27

3.8.1 Driver Download ............................................................................................. 27

3.9 SYSTEM MAINTENANCE ........................................................................................... 29

AFOKAR-08A-RK39

Page VI

4 ANDROID OS .............................................................................................................. 30

4.1 HOME SCREEN ......................................................................................................... 31

4.1.1 Adding a Home Screen ..................................................................................... 31

4.1.2 Switching between Home Screens .................................................................... 32

4.1.3 Favorites Tray .................................................................................................. 32

4.1.4 Adding Shortcuts .............................................................................................. 33

4.1.5 Arranging the Home Screen ............................................................................. 35

4.2 NAVIGATION BUTTONS ............................................................................................. 36

4.3 STATUS BAR ............................................................................................................. 37

A REGULATORY COMPLIANCE .............................................................................. 39

B SAFETY PRECAUTIONS ......................................................................................... 44

B.1 SAFETY PRECAUTIONS ............................................................................................. 45

B.1.1 General Safety Precautions ............................................................................. 45

B.1.2 Anti-static Precautions .................................................................................... 46

B.1.3 Product Disposal ............................................................................................. 47

B.2 MAINTENANCE AND CLEANING PRECAUTIONS ........................................................ 48

B.2.1 Maintenance and Cleaning .............................................................................. 48

B.2.2 Cleaning Tools ................................................................................................. 48

C HAZARDOUS MATERIALS DISCLOSURE ......................................................... 50

AFOKAR-08A-RK39

Page VII

List of Figures

Figure 1-1: AFOKAR-08A-RK39 Panel PC .................................................................................... 2

Figure 1-2: Front View .................................................................................................................... 3

Figure 1-3: LED Indicators ............................................................................................................. 4

Figure 1-4: Rear Panel .................................................................................................................... 5

Figure 1-5: Top and Bottom Panels .............................................................................................. 6

Figure 1-6: Side Panel .................................................................................................................... 6

Figure 1-7: Dimensions (unit: mm) ............................................................................................... 7

Figure 3-1: microSD Card Slot Access Panel Retention Screw ............................................... 16

Figure 3-2: microSD Card Installation ........................................................................................ 16

Figure 3-3: SIM Card Slot Access Panel Retention S cr ew ....................................................... 17

Figure 3-4: SIM Card Installation ................................................................................................. 18

Figure 3-5: VESA Mount Retention Screw Holes ...................................................................... 19

Figure 3-6: IO 1 Connector Pinout Locations ............................................................................ 20

Figure 3-7: OBD-II Cable .............................................................................................................. 21

Figure 3-8: OBD-II Connector Pinouts ........................................................................................ 21

Figure 3-9: IO 2 Connector Pinout Locations ............................................................................ 22

Figure 3-10: HDMI Connector ...................................................................................................... 23

Figure 3-11: Power Input Connector ........................................................................................... 24

Figure 3-12: Optional ACC Power Cable .................................................................................... 24

Figure 3-13: Optional Cigarette Lighter Cable ........................................................................... 25

Figure 3-14: USB Connector ........................................................................................................ 25

Figure 3-15: IEI Resource Download Center .............................................................................. 27

Figure 4-1: Adding a Home Screen ............................................................................................. 31

Figure 4-2: Multiple Home Screens ............................................................................................. 32

Figure 4-3: Favorites Tray ............................................................................................................ 32

Figure 4-4: All Apps/WIDGETS Page .......................................................................................... 34

Figure 4-5: Trash an Item on Home Screen ............................................................................... 35

Figure 4-6: Navigation Buttons ................................................................................................... 36

Figure 4-7: Status Bar .................................................................................................................. 37

Figure 4-8: Notification List and System Status ........................................................................ 38

AFOKAR-08A-RK39

Page VIII

List of Tables

Table 1-1: LED Indicators .............................................................................................................. 4

Table 1-2: Technical Specifications .............................................................................................. 9

Table 2-1: Packing List ................................................................................................................. 12

Table 2-2: Optional Items ............................................................................................................. 13

Table 3-1: IO 1 Connector Pinouts .............................................................................................. 20

Table 3-2: IO 2 Connector Pinouts .............................................................................................. 22

Table 3-3: HDMI Connector Pinouts ........................................................................................... 23

Table 3-4: Power Input Connector Pinouts ................................................................................ 24

Table 4-1: Navigation Buttons ..................................................................................................... 36

AFOKAR-08A-RK39

Page 1

Chapter

1

1 Introduction

AFOKAR-08A-RK39

Page 2

1.1 Overview

Figure 1-1: AFOKAR-08A-RK39 Panel PC

The AFOKAR-08A-RK39 is an 8" Android panel PC designed for in-car use. At the heart of
the system is the Rockchip RK3399 on-board SoC, offering low power in a powerful
package.

The system also offers a multimedia exp erien ce wit h a built-in 5-megapixel camera, HDMI
port and speaker. The OBD-II connection and GPS functionality make the
AFOKAR-08A-RK39 an ideal system for in-vehicle applications.

Other peripherals include one USB 3.0 port, and two I/O connectors which support
RS-232, RS485, OBD-II/J1939, digital I/O, USB and audio output. Wireless networking
capabilities include Bluetooth 4.1 and 802.11a/b/g/n/ac.

1.2 Features

The AFOKAR-08A-RK39 features the following:

 Fanless design
 Projected capacitive touchscreen with AG coating
 Rockchip RK3399 on-board SoC
 On-board 1866 MHz 2 GB LPDDR3 memory
 16 GB eMMC NAND flash and one microSD slot

AFOKAR-08A-RK39

Page 3

 Support OBD-II/J1939, RS-232 and digital I/O
 GPS functionality with external antenna connector
 5-megapixel front-facing camera and speaker
 One HDMI output connector
 802.11a/b/g/n/ac and Bluetooth 4.1 wireless connection
 Optional WWAN connectivity with SIM slot and an external antenna
 IP 54 compliant front panel
 Android 7.1 OS pre-installed
 RoHS compliance

1.3 Front Panel

The front of the AFOKAR-08A-RK39 is a flat panel screen with a plastic frame. The
components on the front panel are listed below:

 5-megapixel camera
 Ambient light sensor
 RFID reader
 Digital microphones
 LED indicators (see Section 1.3.1)

Figure 1-2: Front View

AFOKAR-08A-RK39

Page 4

1.3.1 LED Indicators

The LED indicators on the front panel show the status of power, Bluetooth, Wi-Fi and
WWAN connection.

Figure 1-3: LED Indicators

Power LED

Bluetooth LED

Wi-Fi LED

WWAN LED

Table 1-1: LED Indicators

Off The system is turned off.
Blue The system is turned on.
Off Bluetooth is disabled.
Blue Bluetooth is enabled.
Off Wi-Fi is disabled.
Green Wi-Fi is enabled.
Off WWAN connection is disabled.
Green WWAN connection is enabled.

AFOKAR-08A-RK39

Page 5

1.4 Rear Panel

The rear panel has VESA mounting screw holes and an access panel for microSD card
and SIM card. The following I/O connectors can also be found on the rear panel.

 1 x 9 V~ 30 V DC input connector
 20-pin connector:

o 1 x OBD-II/J1939
o 1 x USB 2.0

 24-pin connector:

o 1 x Audio out
o 1 x RS-232
o 1 x RS-485
o 2-bit digital input and 2-bit digital output

 1 x HDMI output connector
 1 x GPS antenna connector
 1 x WWAN antenna connector

Figure 1-4: Rear Panel

AFOKAR-08A-RK39

Page 6

1.5 Top & Bottom Panel

The top panel has a power button. Press the power button for 4~6 seconds to power on
the system. The bottom panel has a 2 W speaker.

Figure 1-5: Top and Bottom Panels

1.6 Side Panel

The right side panel has one USB 3.0 port.

Figure 1-6: Side Panel

AFOKAR-08A-RK39

Page 7

1.7 Dimensions

The dimensions are shown below.

Figure 1-7: Dimensions (unit: mm)

AFOKAR-08A-RK39

Page 8

1.8 System Specifications

The technical specifications for the AFOKAR-08A-RK39 systems are listed in Table 1-2.

System
CPU Rockchip RK3399 on-board SoC

(dual-core Cortex-A72 + quad-core Cortex-A53, 64-bit)

Memory 2 GB 1866 MHz LPDDR3L on-board memory
Storage One microSD card slot

16 GB eMMC NAND flash

Audio One 2 W speaker and digital microphone
Camera 5-megapixel front-facing camera
Watchdog Timer Yes
Real-time Clock Battery backup RTC
OS Android 7.1
Display
LCD 8" TFT LCD with LED backli ght
Max. Resolution 800 x 1280
Brightness (cd/m2) 500
Contrast Ratio 800:1
Pixel Pitch (mm) 0.13455 (W) x 0.13455 (H)
Viewing Angle 170° (H)/170° (V)
Touchscreen Projected capacitive touchscreen with AG coating
Auto-dimming Ambient light sensor on the front panel
Communication
Wireless LAN 802.11a/b/g/n/ac
Bluetooth Bluetooth v4.1
WWAN Optional by full-size PCIe Mini LTE module
SIM On-board mini-SIM card (15 x 25 mm) slot
RFID 13.56 MHz ISO4443 A/B, read-write capable,

ISO 14443A (MIFARE), ISO 14443B (FeliCa)

GPS On-board GPS
Power
Power Input 9 V ~ 30 V DC input

AFOKAR-08A-RK39

Page 9

4-pin (2x2) Molex power connector (with ACC ignition)

Power Consumption 12 V @ 2 A
Physical Character
Construction Material ABS + PC plastic
Mounting VESA 75 mm x 75 mm
Dimensions (W x H x D ) 210 mm x 154 mm x 33.9 mm
Operation Temperature -10°C ~ 50°C with air flow
Storage Temperature -20°C ~ 60°C
Humidity 10% ~ 95%, non-condensing
Weight (Net) 0.77 kg
Operating Shock Half-sine wave shock 5 G, 11 ms, 3 shocks per axis
Operating Vibration MIL-STD-810F 514.5C-2
IP Level IP 54 compliant front panel
Certifications CE, FCC, e-MARK
Connectors, Buttons and Indicators
Antenna Connectors 1 x GPS antenna SMA female connector

1 x WWAN antenna SMA fem a le connector

I/O Connector 1 x 9 V~ 30 V DC input connector

1 x USB 3.0 Type-A port
1 x HDMI output connector

20-pin connector:

1 x OBD-II/J1939
1 x USB 2.0

24-pin connector:

1 x Audio out
1 x RS-232
1 x RS-485
2-bit digital input w ith is o la t io n
2-bit digital output with isolation

Button 1 x Power button
LED Indicators Power, Bluetooth, Wi-Fi and WWAN

Table 1-2: Technical Specifications

AFOKAR-08A-RK39

Page 10

Chapter

2

2 Unpacking

AFOKAR-08A-RK39

Page 11

has been

properly installed. This ensures the screen is protected during the

was purchased from or contact an IEI sales

To unpack the panel PC, follow the steps below:

WARNING!

The front side LCD screen has a protective plastic cover stuck to the
screen. Only remove the plastic cover after the system

installation process.

Step 1: Open the external box.

Step 2: Remove the two polystyrene strips t hat cover the system.

Step 3: Lift the AFOKAR-08A-RK39 out of the boxes.

Step 4: Take the AFOKAR-08A-RK39 out from the plastic bag.

Step 5: Pull the plastic cover off the AFOKAR-08A-RK39.

Step 6: Make sure all the components listed in t he packing list are present.

2.1 Packing List

NOTE:

If any of the components listed in the checklist below are missing, do
not proceed with the installation. Contact the IEI reseller or vendor the
AFOKAR-08A-RK39
representative directly by sending an email to [e-mail].

The AFOKAR-08A-RK39 is shipped with the following component:

AFOKAR-08A-RK39

Page 12

Quantity Item Image

1 AFOKAR-08A-RK39 in-vehicle panel PC

Table 2-1: Packing List

2.2 Optional Items

The following are optional components which may be separately purchased:

Item Image

Power adapter with transfer cable
(P/N: IVIPOWER-4PIN-R10)

ACC power cable
(P/N: 32002-001900-100-RS)

Cigarette lighter power cable
(P/N: 32002-004000-100-RS)

OBD-II cable
(P/N: 32025-003400-100-RS)

AFOKAR-08A-RK39

Page 13

Item Image

GPS/LTE antenna
(P/N: 32506-000400-100-RS)

I/O connector 1 cable (20-pin)
(P/N: 32024-003800-100-RS)

I/O connector 2 cable (24-pin)
(P/N: 32124-004400-100-RS)

VESA mount stand (138 mm)
(P/N: IVI-MK03-R10)

Table 2-2: Optional Items

If any of these items are missing or damaged, contact the distributor or sales
representative immediately.

AFOKAR-08A-RK39

Page 14

Chapter

3

3 Installation

AFOKAR-08A-RK39

Page 15

Failure to take ESD precautions during the maintenance of the

may result in permanent damage to the

3.1 Anti-static Precautions

WARNING:

AFOKAR-08A-RK39
AFOKAR-08A-RK39 and severe injury to the user.

Electrostatic discharge (ESD) can cause serious damage to electronic components,
including the AFOKAR-08A-RK39. Dry climates are especially susceptible to ESD. It is
therefore critical that whenever the AFOKAR-08A-RK39 is accessed internally, or any
other electrical component is handled, the following anti-static precautions are strictly
adhered to.

 Wear an anti-static wristband: Wearing a simple anti-static wristband can

help to prevent ESD from damaging the board.

 Self-grounding: Before handling the board, touch any grounded conducting

material. During the time the board is handled, f requently touch any
conducting materials that are connected to the ground.

 Use an anti-static pad: When configuring the AFOKAR-08A-RK39, place it

on an anti-static pad. This reduces the possibility of ESD damaging the
AFOKAR-08A-RK39.

 Only handle the edges of the PCB: When handling the PCB, hold the PCB

by the edges.

3.2 Installation Precautions

When installing the flat panel PC, please follow the precautions listed below:

 Power turned off: When installing the flat panel PC, make sure the power is

off. Failing to turn of f the power may cause severe injury to the body and/or
damage to the system.

 Certified Engineers: Only certified engineers should install and modify

onboard functionalities.

AFOKAR-08A-RK39

Page 16

 Anti-static Discharge: If a user open the rear panel of the flat panel PC, to

configure the jumpers or plug in added peripheral dev ices, ground themsel ves
first and wear an anti-static wristband.

3.3 microSD Card Installation

To install the microSD card, follow the instructions below.

Step 1: Remove the retention screw and lift the microSD card slot access panel.

Figure 3-1: microSD Card Slot Access Panel Retention Screw

Step 2: Locate the microSD card slot. Insert the microSD card into the slot to install it. To

remove the microSD card, push the microSD card inwards to release it.

Figure 3-2: microSD Card Installation

AFOKAR-08A-RK39

Page 17

SIM (3FF)

module is installed in the PCIe Mini card slot of the

Step 3: Replace the microSD card slot access panel. Step 0:

3.4 SIM Card Installation (Optional)

To install the SIM card, follow the instructions below.

WARNING:

The AFOKAR-08A-RK39 is not compatible with a micro­adapter or a nano-SIM (4FF) adapter. Please install a mini-SIM (2FF or
Standard SIM) card for proper network connection.

NOTE:

Before installing a SIM card for WWAN connection, please make sure a
WWAN
AFOKAR-08A-RK39.

Step 1: Remove the retention screw and lift the SIM card slot access panel.

Figure 3-3: SIM Card Slot Access Panel Retention Screw

AFOKAR-08A-RK39

Page 18

Step 2: Locate the push-push SIM card slot (Figure 3-4). Insert a SIM card into the slot

to install it. To remove the SIM card, push the SIM card to release it.

Figure 3-4: SIM Card Installation

Step 3: Replace and secure the S IM card slot acces s panel with the previously removed

retention screw .

AFOKAR-08A-RK39

Page 19

When purchasing the mounting device please ensure that it is VESA

mm interface pad. If the

mounting device is not VESA compliant it cannot be used to support

3.5 Mounting the System

The AFOKAR-08A-RK39 is VESA (Video Electronics Standards Association) compliant
and can be mounted on a mounting device with a 75 mm interface pad. The
AFOKAR-08A-RK39 VESA mount retention screw holes for fastening four M4*6 screws
are shown in Figure 3-5. Refer to the installation guide that came with the mounting
device to mount the AFOKAR-08A-RK39.

Figure 3-5: VESA Mount Retention Screw Holes

NOTE:

compliant and that the device has a 75

the AFOKAR-08A-RK39.

AFOKAR-08A-RK39

Page 20

3.6 External I/O Connectors

This section provides an overview of the external I/O connectors of the
AFOKAR-08A-RK39.

3.6.1 I/O Connector 1 (20-pin)

The 20-pin I/O connector (IO 1) supports the following external peripheral devices:

 1 x OBD-II/J1939
 1 x USB 2.0

The pinouts for the IO 1 connector are listed in the figure and table below.

Figure 3-6: IO 1 Connector Pinout Locations

Pin Description Pin Description

1 NC 11 NC
2 NC 12 NC
3 NC 13 USB VCC (+5V) USB 2.0
4 NC 14 U SB DATA-
5 NC 15 USB DATA+
OBD-II 6 J2850_BUS+ 16 GND
7 J2850_BUS- 17 NC
8 GND 18 GND OBD-II
9 OBD_CAN_H 19 ISO-9141-2-K
10 OBD_CAN_L 20 ISO-9141-2-L

Table 3-1: IO 1 Connector Pinouts

AFOKAR-08A-RK39

Page 21

User can purchase the optional OBD-II cable (Figure 3-7) to connect the
AFOKAR-08A-RK39 with the vehicle.

Figure 3-7: OBD-II Cable

The pinout locations of OBD-II cable connector a re shown below.

Figure 3-8: OBD-II Connector Pinouts

AFOKAR-08A-RK39

Page 22

3.6.2 I/O Connector 2 (24-pin)

The 24-pin I/O connector (IO 2) supports the following external peripheral devices:

 1 x Audio out
 1 x RS-232
 1 x RS-485
 2-bit digital input with isolation
 2-bit digital output with isolation

The pinouts for the IO 2 connector are listed in the figure and table below.

Figure 3-9: IO 2 Connector Pinout Locations

Pin Description Pin Description

RS-232 1 RS232_TXD 13 RS232_RXD RS-232
2 RS232_RTS 14 RS232_CTS
3 GND 15 GND
RS-485 4 RS485- 16 DIO_GND Digital Output
5 RS485+ 17 DIO_OUT_1
Digital Input 6 DIO_GND 18 DIO_GND
7 DIO_IN_1 19 DIO_OUT_2
8 DIO_GND 20 DIO_GND
9 DIO_IN_2 21 DIO_VCC
Audio Out 10 AUDIO_GND 22 NC Audio Out

11 LINE_OUT_L 23 AUDIO_GND
12 LINE_OUT_R 24 Reserved

Table 3-2: IO 2 Connector Pinouts

AFOKAR-08A-RK39

Page 23

3.6.3 HDMI Connector

The AFOKAR-08A-RK39 has one HDMI output connector on the rear panel. The pinouts
for the HDMI connector are listed in the figure and table below.

Figure 3-10: HDMI Connector

PIN NO. DESCRIPTION PIN NO. DESCRIPTION

1 HDMI_DATA2 2 GND
3 HDMI_DATA2# 4 HDMI_DATA1
5 GND 6 HDMI_DATA1#
7 HDMI_DATA0 8 GND
9 HDMI_DATA0# 10 HDMI_CLK
11 GND 12 HDMI_CLK#
13 N/C 14 N/C
15 HDMI_SCL 16 HDMI_SDA
17 GND 18 +5V
19 HDMI_HPD 20 HDMI_GND
21 HDMI_GND 22 HDMI_GND
23 HDMI_GND

Table 3-3: HDMI Connector Pinouts

AFOKAR-08A-RK39

Page 24

3.6.4 Power Input Connection

The AFOKAR-08A-RK39 has one 4-pin power input connector on the rear panel. The
pinouts for the power input connector are listed in t he figure and table below.

Figure 3-11: Power Input Connector

PIN NO. DESCRIPTION

1 GND
2 GND
3 POWER
4 ACC

Table 3-4: Power Input Connector Pinouts

[Optional Choice]

The AFOKAR-08A-RK39 can use either ACC po wer o r DC pow er fr om the v ehicle. To use
ACC power, connect the AFOKAR-08A-RK39 to the vehicle through the optional ACC
power cable. See Figure 3-12.

Figure 3-12: Optional ACC Power Cable

AFOKAR-08A-RK39

Page 25

To use DC power, connect the AFOKAR-08A-RK39 to the vehicle cigarette lighter
connector through the optional cigarette lighter cable. See Figure 3-13.

Figure 3-13: Optional Cigarette Lighter Cable

3.6.5 USB Connector

The AFOKAR-08A-RK39 has one USB 3.0 port on the right side panel. The USB port has
a screw on the side for securing the USB devices, such as barcode scanners and smart
card readers. The following diagram shows the USB 3.0 port and the screw on the side
panel.

Figure 3-14: USB Connector

AFOKAR-08A-RK39

Page 26

into the system. Incorrect voltages applied to the system may cause

internal electronic components and may also cause

3.7 Power-On Procedure

WARNING:

Make sure a power supply with the correct input voltage is being fed

damage to the
injury to the user.

To power-on the AFOKAR-08A-RK39, connect the AFOKAR-08A-RK39 to the vehicle
through a power cable, or connect the system to a power source through the optional
power adapter.

When the system is connected to power source, press the power button on the top panel
for 4–6 seconds to power on/off the system.

AFOKAR-08A-RK39

Page 27

Figure 3-15: IEI Resource Download Center

3.8 Available Drivers

All the drivers for the AFOKAR-08A-RK39 are available on IEI Reso urce Download Center
(https://download.ieiworld.com
relevant software, utilities, and documentation.

3.8.1 Driver Download

). Type AFOKAR-08A-RK39 and press Enter to find all the

To download drivers from IEI Resource Download Center, follow the steps below.

Step 4: Go to https://download.ieiworld.com

Step 5: All product-related software, uti li ties, and documentation will be listed. You can

choose Driver to filter the result.

. Type AFOKAR-08A-RK39 and press Enter .

AFOKAR-08A-RK39

Page 28

Step 6: Click the driver file name on the page and you will be prompted with the

following window. You can download the entire ISO file (
arrow to find an individual driver and click the file name to download (

), or click the small

).

AFOKAR-08A-RK39

Page 29

lease contact the system

3.9 System Maintenance

If the components of the AFOKAR-08A-RK39 fail, they must be replaced. Please contact
the system reseller or vendor to purchase the replacement parts.

NOTE:

A user cannot replace a motherboard. If the motherboard fails it must
be shipped back to IEI to be replaced. P
vendor, reseller or an IEI sales person directly .

AFOKAR-08A-RK39

Page 30

Chapter

4

4 Android OS

AFOKAR-08A-RK39

Page 31

The AFOKAR-08A-RK39 comes with Android OS pre-installed. This chapter introduces
the user interface and basic functions of A ndroid O S installed in the AFOKAR-08A-RK39.

4.1 Home Screen

Android OS supports multiple home screens allowing us ers to customize the screen with
widgets, apps and shortcuts. The following sections describe the basic technique to
manage the home screen.

4.1.1 Adding a Home Screen

To add a home screen, touch and hold an app/widget icon. The following screen appears,
indicating that a new home screen is available. Drag and relea se the icon to the new home
screen.

Figure 4-1: Adding a Home Screen

AFOKAR-08A-RK39

Page 32

4.1.2 Switching between Home Screens

Swipe right or left to switch between home screens.

Figure 4-2: Multiple Home Screens

4.1.3 Favorites Tray

The Favorites tray at the bottom of each home screen allows users to keep the most
important or frequently used shortcuts.

Figure 4-3: Favorites Tray

AFOKAR-08A-RK39

Page 33

4.1.4 Adding Shortcuts

To add app or widget shortcuts on the home s cr een, follow the steps below.

Step 1: To add an app shortcut, tap the up arrow on the home screen to access the

All Apps page.

To add a widget shortcut, touch and hold the background of a home screen, then
tap WIDGETS.

AFOKAR-08A-RK39

Page 34

Step 2: Touch and hold an app icon or a widget, and drag it to the home screen.

Figure 4-4: All Apps/WIDGETS Page

AFOKAR-08A-RK39

Page 35

4.1.5 Arranging the Home Screen

The items on the home screen can be moved and deleted. Touch and hold an item on the
home screen and drag it where you want. To trash the item on the screen, drag it to the
Remove icon. Release the icon when it turns gray.

Figure 4-5: Trash an Item on Home Screen

AFOKAR-08A-RK39

Page 36

4.2 Navigation Buttons

The navigation buttons shown in Figure 4-8 c an always be found at the bottom of every
screen.

Figure 4-6: Navigation Buttons

Buttons Description

Table 4-1: Navigation Buttons

Tap to turn the volume down.

Tap to return to the previous screen.

Tap to return to the home screen.

Tap to display all the recently used a p plications.

Tap to turn the volume up.

Tap to take a screenshot.

AFOKAR-08A-RK39

Page 37

4.3 Status Bar

The status bar on the top of the screen (Figure 4-9) displays system status, such as
battery level or signal strength.

Figure 4-7: Status Bar

Swipe down from the status bar to view notification and status details (Figure 4-10).

AFOKAR-08A-RK39

Page 38

Figure 4-8: Notification List and System Status

AFOKAR-08A-RK39

Page 39

Appendix

A

A Regulatory Compliance

AFOKAR-08A-RK39

Page 40

If the user modifies and/or install other devices in the equipment, the CE conformity

.

herved, at følgende udstyr overholder de væsentlig e krav o

DECLARATION OF CONFORMITY

This equipment is in conformity with the following EU directives:

 EMC Directive (2004/108/EC, 2014/30/EU)
 Low-Voltage Directive (2006/95/EC, 2014/35/EU)
 RoHS II Directive (2011/65/EU, 2015/863/EU)

declaration may no longer apply.

If this equipment has telecommunications functionality, it also complies with the
requirements of the Radio Equipment Directive 2014/53/EU.

English
IEI Integration Corp declares that this equi pm ent is in compliance with the essential
requirements and other relevant provisions of Directive 2014/53/EU.

Български [Bulgarian]

IEI Integration Corp. декларира, че този оборудване е в съответствие със

съществените изисквания и другите приложими правила на Директива 2014/53/EU
Česky [Czech]

IEI Integration Corp tímto prohlašuje, že tento zařízení je ve shodě se základními

požadavky a dalšími příslušnými ustanoveními směrnice 2014/53/EU.
Dansk [Danish]

IEI Integration Corp erklærer
øvrige relevante krav i direktiv 2014/53/ E U.
Deutsch [German]
IEI Integration Corp, erklärt dieses Gerät entspricht den grundlegenden Anforde rungen
und den weiteren entsprechenden Vorgaben der Richtlinie 2014/53/EU.

Eesti [Estonian]
IEI Integration Corp deklareerib seadme seadme vastavust direktiivi 2014/53/EÜ
põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele.

AFOKAR-08A-RK39

Page 41

Español [Spanish]
IEI Integration Corp declara que el equipo cumple con los requisitos esenciales y
cualesquiera otras disposiciones aplicabl es o exigibles de la Directiva 2014/53/EU.

Ελληνική [Greek]

IEI Integration Corp ΔΗΛΩΝΕΙ ΟΤΙ ΕΞΟΠΛΙΣΜΟΣ ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ
ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ

2014/53/EU.
Français [French]

IEI Integration Corp déclare que l'appar ei l est conforme aux exigences essentielles et aux
autres dispositions pertinentes de la directive 2014/53/EU.

Italiano [Italian]
IEI Integration Corp dichiara che questo apparecchio è conforme ai requisiti essenziali ed
alle altre disposizioni pertinenti stabilite dalla direttiva 2014/53/EU.
Latviski [Latvian]

IEI Integration Corp deklarē, ka iekārta atbilst būtiskajām prasībām un citiem ar to
saistītajiem noteikumiem Direktīvas 2014/53/EU.

Lietuvių [Lithuanian]
IEI Integration Corp deklaruoja, kad šis įranga atitinka esminius reikalavimus ir kitas

2014/53/EU Direktyvos nuostatas.
Nederlands [Dutch]

IEI Integration Corp dat het toestel toestel i n vereenstemming is met de essentiële eisen
en de andere relevante bepalingen van richtlijn 2014/53/EU.
Malti [Maltese]
IEI Integration Corp jiddikjara li dan prodott j i kko nforma mal-ħtiġijiet essenzjali u ma
provvedimenti oħrajn relevanti li hemm fid-Dirrettiva 2014/53/EU.

Magyar [Hungarian]
IEI Integration Corp nyilatkozom, hogy a beren dezés megfelel a vonatkozó alapvetõ
követelményeknek és az 2014/53/EU irányelv egyéb elõírásainak.

Polski [Polish]

IEI Integration Corp oświadcza, że wyrobu jest zgodny z zasadniczymi wymogami oraz
pozostałymi stosownymipostanowieniami Dyrekty wy 2014/53/EU.

Português [Portuguese]
IEI Integration Corp declara que este equipamento está conforme com os requisitos
essenciais e outras disposições da Directiva 2014/53/EU.

AFOKAR-08A-RK39

Page 42

Româna [Romanian]

IEI Integration Corp declară că acest echipament este in conformitate cu cerinţele
esenţiale şi cu celelalte prevederi relevante ale Directivei 2014/53/EU.

Slovensko [Slovenian]
IEI Integration Corp izjavlja, da je ta opreme v skladu z bistvenimi zahtevami in ostalimi
relevantnimi določili direktive 2014/53/EU.

Slovensky [Slovak]
IEI Integration Corp týmto vyhlasuje, že zariadenia spĺňa základné požiadavky a všetky
príslušné ustanovenia Smernice 2014/53/E U.

Suomi [Finnish]
IEI Interation Corp vakuuttaa täten että laitteet on direktiivin 2014/53/EU oleellisten
vaatimusten ja sitä koskevien direktiivin m ui den ehtojen mukainen.
Svenska [Swedish]
IEI Integration Corp förklarar att denna utrustningstyp står I överensstämmelse med de
väsentliga egenskapskrav och övriga relev anta bestämmelser som framgår av direktiv
2014/53/EU.

AFOKAR-08A-RK39

Page 43

with Part 15 of the FCC Rules. Operation is subject to the

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

cial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this

frequency energy and, if not

FCC WARNING

This equipment complies
following two conditions:

 This device may not cause harmful interference, and
 This device must accept any interference receiv ed, including interference

that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class A digital

reasonable protection against harmful interference when the equipment is operated in a
commer

equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.

Federal Communication Commission Interference Statement

This equipment has been assembled with components that comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limi ts are desi gned to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio
installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one of the followin g m easures:

 Reorient or relocate the receiving antenna.
 Increase the separation between the equipment and receiver.
 Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

 Consult the dealer or an experienced radio/ T V technician for help.

AFOKAR-08A-RK39

Page 44

B Safety Precautions

Appendix

B

AFOKAR-08A-RK39

Page 45

The precautions outlined in this chapter should be strictly followed.

WARNING:

Failure to follow these precautions may result in permanent damage to
the AFOKAR-08A-RK39.

B.1 Safety Precautions

Please follow the safety precautions out l i ned i n the sections that follow:

B.1.1 General Safety Precautions

Please ensure the following safety precautions are adhered to at all times.

 Follow the electrostatic precautions outlined below whenever the device is

opened.

 Make sure the power is turned off and the power cord is disconnected

whenever the AFOKAR-08A-RK39 is being installed, moved or modified.

 To prevent the risk of electric shock, make sure power cord is

unplugged from wall socket. To fully disengage the power to the unit,

please disconnect the power cord from the po wer outlet. Refer servicing to
qualified service personnel. The power outlet shall be readily available and
accessible.

 Do not apply voltage levels that exceed the specified voltage range.

Doing so may cause fire and/or an electrical shock. Use a power cord that
matches the voltage of the power outlet, which has been approved and
complies with the safety standard of your particular country.

 Electric shocks can occur if the AFOKAR-08A-RK39 chassis is opened

when it is running. To avoid risk of electric shock, this device must only be
connected to a supply mains with protective earth.

 Do not drop or insert any objects into the ventilation openings of the

AFOKAR-08A-RK39.

AFOKAR-08A-RK39

Page 46

Failure to take ESD precautions during the installation of the

may result in permanent damage to the

 If considerable amounts of dust, water, or fluids enter the device, turn off

the power supply immediately, unplug the power cord, and contact the
AFOKAR-08A-RK39 vendor.

 DO NOT:

o Drop the device against a hard surface.
o Strike or exert excessive force onto the LCD panel.
o Touch any of the LCD panels with a sharp object
o In a site where the ambient temperature exceeds the rated temperature

B.1.2 Anti-static Precautions

WARNING:

AFOKAR-08A-RK39
AFOKAR-08A-RK39 and severe injury to the user.

Electrostatic discharge (ESD) can cause serious damage to electronic components,
including the AFOKAR-08A-RK39. Dry climates are especially susceptible to ESD. It is
therefore critical that whenever the AFOKAR-08A-RK39 is opened and any of the
electrical components are handled, the following anti-static precautions are strictly
adhered to.

 Wear an anti-static wristband: Wearing a simple anti-static wristband can

help to prevent ESD from damaging any electrical component.

 Self-grounding: Before handling any electrical component , touch any

grounded conducting material. During the t im e the electrical component is
handled, frequently touch any conducting materials that are connected to the
ground.

 Use an anti-static pad: When configuring or worki ng with an electrical

component, place it on an anti-static pad. This reduces the possibility of ESD
damage.

 Only handle the edges of the electrical component: When handling the

electrical component, hold the electrical c om ponent by its edges.

AFOKAR-08A-RK39

Page 47

Dispose of used batteries according to instructions and local

B.1.3 Product Disposal

CAUTION:

Risk of explosion if battery is replaced by an incorrect type. Only
certified engineers should replace the on-board battery.

regulations.

 Outside the European Union–If you wish to dispose of used electrical and

electronic products outside the Europea n Union, please contact your local
authority so as to comply with the correct dispo sal m ethod.

 Within the European Union–The device that produc es less waste and is

easier to recycle is classified as electroni c device in terms of the European
Directive 2012/19/EU (WEEE), and must not be di sposed of as domestic
garbage.

EU-wide legislation, as implemented in each Membe r State, require s that
waste electrical and electronic products carrying the mark (left) must be
disposed of separately from normal household waste. This includes
monitors and electrical accessories, such as signal cables or power

cords. When you need to dispose of your display products, please follow
the guidance of your local authority, or ask the shop where you purchased the product.
The mark on electrical and electronic products only applies t o the curre nt E uropean Union
Member States.

Please follow the national guidelines for elect rical and electronic product disposal.

AFOKAR-08A-RK39

Page 48

B.2 Maintenance and Cleaning Precautions

When maintaining or cleaning the AFOKAR-08A-RK39, please follow the guidelines
below.

WARNING:

 For safety reasons, turn-off the power and unplug the panel PC

before cleaning.

 If you dropped any material or liquid such as water onto the panel

PC when cleaning, unplug the power cable immediately and contact
your dealer or the nearest service center. Alway s make sure your
hands are dry when unplugging the power cable.

B.2.1 Maintenance and Cleaning

Prior to cleaning any part or component of the AFOKAR-08A-RK39, please read the
details below.

 Except for the LCD panel, never spray or squirt li quids directly onto any other

components. To clean the LCD panel, gently wipe it with a piece of soft dry
cloth or a slightly moistened cloth.

 The interior of the device does not requi re cleaning. K eep fluids away from the

device interior.

 Be cautious of all small removable component s when vacuuming the device.
 Never drop any objects or liquids through the openings of the device.
 Be cautious of any possible allergic reactions t o solvents or chemicals used

when cleaning the device.

 Avoid eating, drinking and smoking within vicinity of the device.

B.2.2 Cleaning Tools

Some components in the AFOKAR-08A-RK39 may only be cleaned using a product
specifically designed for the purpose. In such case, the product will be explicitly mentioned
in the cleaning tips. Below is a list of items to use wh en cleaning the AFOKAR-08A-RK39.

 Cloth– Although paper towels or tissues can be used, a soft, clean piece of

AFOKAR-08A-RK39

Page 49

cloth is recommended when cleaning the device.

 Water or rubbing alcohol–A cloth moistened with water or rubbing alcohol

can be used to clean the device.

 Using solvents–The use of solvents is not recommended when cleaning the

device as they may damage the plastic parts.

 Vacuum cleaner–Usi ng a vacuum specifically designed for computers is one

of the best methods of cleaning the device. Dust and dirt can restrict the
airflow in the device and cause its circuitry to corr ode.

 Cotton swabs–Cotton swaps moistened with rubbing alcohol or water are

excellent tools for wiping hard to reach areas.

 Foam swabs–Whenever possible, it is best to use lint free swabs such as

foam swabs for cleaning.

AFOKAR-08A-RK39

Page 50

Appendix

C

C Hazardous Materials

Disclosure

AFOKAR-08A-RK39

Page 51

The details provided in this appendix are to ensure that the product is compliant with the
Peoples Republic of China (China) RoHS standards. The table below acknowledges the
presences of small quantities of certain material s in the product, and is appli cable to China
RoHS only.

A label will be placed on each product to indicate the estimated “Environmentally Friendly
Use Period” (EFUP). This is an estimate of the number of years that these substances
would “not leak out or undergo abrupt change.” This product may contain replaceable
sub-assemblies/components which have a shorter EFUP such as batteries and lamps.
These components will be separately marked.

Please refer to the following table.

Part Name Toxic or Hazardous Substances and Elements

Lead
(Pb)

Housing
Display
Printed Circuit
Board
Metal Fasteners
Cable Assembly
Fan Assembly
Power Supply
Assemblies
Battery
O: This toxic or ha zardous substance is contained in all of the homogeneous materials for the part is below the limit

requirement in SJ/T11363-2006 (now replaced by GB/T 26572-2011).

X: This toxic or hazardous substance is contained in at least one of the homogeneous mat erials for this part is above

O O O O O O
O O O O O O
O O O O O O

O O O O O O
O O O O O O
O O O O O O
O O O O O O

O O O O O O

Mercury
(Hg)

Cadmium
(Cd)

Hexavalent
Chromium
(CR(VI))

Polybrominated
Biphenyls
(PBB)

Polybrominated
Diphenyl Ethers
(PBDE)

the limit requirement in SJ/T11363-2006 (now replaced by GB/T 26572-2011).

AFOKAR-08A-RK39

Page 52

部件名称

有毒有害物质或元素

铅

汞

镉

六价铬

多溴联苯

多溴二苯

醚

壳体

显示

印刷电路板

金属螺帽

电缆组装

风扇组装

电力供应组装

电池

此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符
合中国 RoHS 标准规定的限量要求。

本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的

年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元

件将会单独标示出来。

(Pb)

O O O O O O

O O O O O O

O O O O O O

O O O O O O

O O O O O O

O O O O O O

O O O O O O

O O O O O O

(Hg)

(Cd)

(CR(VI))

(PBB)

(PBDE)

O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T 11363-2006 (现由 GB/T 26572-2011 取代)
标准规定的限量要求以下。

X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T 11363-2006 (现由 GB/T
26572-2011 取代) 标准规定的限量要求。
