AFL M Series LCD Monitor
Page i
AFL M Series LCD Monitor
Revision
Date Version Changes
2009-09-29
2007-12-5 1.10 Added AFL-10M model information
2007-06-30 1.00 Initial release
1.11 Added screw torque warning
Added USB touch screen feature to 7” to 12.1” models
Added USB touch screen models for 15” to 19” models
Added smartOSD function and smartOSD appendix
Added 7” to 12.1” model driver installation procedures
Added screen calibration procedures
Page ii
AFL M Series LCD Monitor
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
Copyright
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
IBM PC is a registered trademark of International Business Machines Corporation. INTEL
is a registered trademark of INTEL Corporation. Other product names mentioned herein
are used for identification purposes only and may be trademarks and/or registered
trademarks of their respective owners.
Page iii
AFL M Series LCD Monitor
Manual Conventions
WARNING!
Warnings appear where overlooked details may cause damage to the equipment or result
in personal injury. Warnings should be taken seriously. Warnings are easy to recognize.
The word “warning” is written as “WARNING,” both capitalized and bold and is followed by
text. The text is the warning message. A warning message is shown below:
WARNING:
This is an example of a warning message. Failure to adhere to warning
messages may result in permanent damage to the AFL series monitor
or personal injury to the user. Please take warning messages seriously.
CAUTION!
Cautionary messages should also be heeded to help reduce the chance of losing data or
damaging the AFL series monitor. Cautions are easy to recognize. The word “caution” is
written as “CAUTION,” both capitalized and bold and is followed. The italicized text is the
cautionary message. A caution message is shown below:
Page iv
AFL M Series LCD Monitor
CAUTION:
This is an example of a caution message. Failure to adhere to cautions
messages may result in permanent damage to the AFL series monitor.
Please take caution messages seriously.
NOTE:
These messages inform the reader of essential but non-critical information. These
messages should be read carefully as any directions or instructions contained therein can
help avoid making mistakes. Notes are easy to recognize. The word “note” is written as
“NOTE,” both capitalized and bold and is followed by text. The text is the cautionary
message. A note message is shown below:
NOTE:
This is an example of a note message. Notes should always be read.
Notes contain critical information about the AFL series monitor. Please
take note messages seriously.
Page v
AFL M Series LCD Monitor
Packing List
NOTE:
If any of the components listed in the checklist below are missing,
please do not proceed with the installation. Contact the IEI reseller or
vendor you purchased the AFL M series from or contact an IEI sales
representative directly. To contact an IEI sales representative, please
send an email to
The items listed below should all be included in the AFL M series package.
1 x AFL M Series industrial LCD monitor
1 x Power adapter
1 x Power cord
1 x DVI cable
1 x VGA cable
1 x Component cable
1 x Audio cable
1 x User manual and driver CD
1 x Remote control
1 x Screw set
1 x Wire strain bands
sales@iei.com.tw.
Page vi
1 x Touch Panel RS-232 Cable / Touch Pen / Driver CD-ROM (T-R models only)
1 x Touch Panel USB Cable (for AFL-07M/T-R, AFL-08MH/T-R, AFL-10M/T-R,
and AFL-12M/T-R)
Images of the above items are shown in Chapter
5.2.3.
AFL M Series LCD Monitor
Table of Contents
1 INTRODUCTION..................................................................................................... 1
1.1 AFL M SERIES LCD MONITOR OVERVIEW ................................................................ 3
1.1.1 Added Features .................................................................................................. 3
1.1.2 Standard Features.............................................................................................. 3
1.1.3 IEI smartOSD..................................................................................................... 4
1.1.4 Model Variations................................................................................................ 4
1.2 EXTERNAL OVERVIEW................................................................................................ 5
1.2.1 Front View.......................................................................................................... 5
1.2.2 Rear View ........................................................................................................... 6
1.3 SERIES SPECIFICATIONS.............................................................................................. 7
1.4 CERTIFICATIONS......................................................................................................... 8
2 MECHANICAL OVERVIEW............................................................................... 10
2.1 INTRODUCTION......................................................................................................... 12
2.2 FRONT VIEW ............................................................................................................ 12
2.3 BOTTOM PANEL........................................................................................................ 14
2.3.1 AFL-07M/08MH/10M/12M Connectors.......................................................... 14
2.3.2 AFL-15M/17M/19M Connectors...................................................................... 14
2.4 PHYSICAL DIMENSIONS............................................................................................ 15
2.4.1 General Physical Dimensions.......................................................................... 15
2.4.2 AFL-07M Physical Dimensions....................................................................... 17
2.4.3 AFL-08MH Physical Dimensions.................................................................... 18
2.4.4 AFL-10M Physical Dimensions....................................................................... 19
2.4.5 AFL-12M Physical Dimensions....................................................................... 20
2.4.6 AFL-15M Physical Dimensions....................................................................... 21
2.4.7 AFL-17M Physical Dimensions....................................................................... 22
2.4.8 AFL-19M Physical Dimensions....................................................................... 23
2.5 MOUNTING KITS ...................................................................................................... 24
2.6 MOUNTING OPTIONS................................................................................................ 24
2.6.1 Panel Mounting................................................................................................ 24
2.6.2 Rack and Cabinet Mounting ............................................................................ 25
Page vii
2.6.3 Wall Mounting.................................................................................................. 25
2.6.4 Monitor Arm or Stand Mounting......................................................................26
3 LCD AND TOUCH PANEL SPECIFICATIONS ................................................ 27
3.1 LCD SPECIFICATIONS............................................................................................... 29
3.1.1 LCD Overview ................................................................................................. 29
3.1.2 AFL-07M LCD Specifications.......................................................................... 29
3.1.3 AFL-08MH LCD Specifications....................................................................... 30
3.1.4 AFL-10M LCD Specifications.......................................................................... 31
3.1.5 AFL-12M LCD Specifications.......................................................................... 32
3.1.6 AFL-15M LCD Specifications.......................................................................... 32
3.1.7 AFL-17M LCD Specifications.......................................................................... 33
3.1.8 AFL-19M LCD Specifications.......................................................................... 35
3.2 OPTIONAL TOUCH PANELS ....................................................................................... 36
3.2.1 Touch Panel Models......................................................................................... 36
AFL M Series LCD Monitor
3.2.2 Touch Panel Dimensions.................................................................................. 37
3.2.3 Touch Panel Specifications .............................................................................. 38
3.2.4 Touch Panel RS-232 Controller Specifications................................................ 39
3.2.5 Touch Panel USB Controller Specifications.................................................... 40
3.3 POWER ADAPTERS.................................................................................................... 41
4 AD BOARD ............................................................................................................. 42
4.1 AV-9962 AD BOARD OVERVIEW .............................................................................. 44
4.1.1 AV-9962 AD Board Connectors ....................................................................... 45
4.1.2 AV-9962 AD Board Layout............................................................................... 46
4.1.3 AV-9962 Peripheral Interface Connectors....................................................... 46
4.1.4 AV-9962 Rear Panel Connectors..................................................................... 47
4.1.5 AV-9962 On-board Jumpers............................................................................. 48
4.2 AV-9962 INTERNAL PERIPHERAL CONNECTORS....................................................... 48
4.2.1 Audio Output Connector.................................................................................. 48
4.2.2 Auto-Dimming Connector................................................................................ 49
4.2.3 Debug Port Connector..................................................................................... 50
4.2.4 OSD and LED Connector ................................................................................ 51
4.2.5 LED Indicator and Remote Sensor Connector ................................................ 52
4.2.6 Backlight Inverter Interface Connector........................................................... 53
Page viii
AFL M Series LCD Monitor
4.2.7 IR Sensor Connector........................................................................................ 54
4.2.8 LVDS Signal Output Connector (AFL-08MH/10M/12M only)........................ 55
4.2.9 Power Output Connector................................................................................. 56
4.2.10 Remote Control Connector............................................................................ 57
4.2.11 TTL Signal Output Connector (AFL-07M Model Only)................................. 58
4.2.12 Touch Panel Connector.................................................................................. 59
4.3 AV-9962 ON-BOARD JUMPERS ................................................................................. 61
4.3.1 LCD Panel Voltage Select Jumper................................................................... 62
4.3.2 Touch Screen Select Jumper............................................................................. 62
4.4 AV-9962 EXTERNAL (REAR PANEL) CONNECTORS................................................... 63
4.4.1 Audio Jack........................................................................................................ 63
4.4.2 Component Video Connector ........................................................................... 64
4.4.3 Composite Video Connector............................................................................. 65
4.4.4 DC 12V Connector........................................................................................... 65
4.4.5 RS-232 Touch Panel Connector....................................................................... 66
4.4.6 S-Video Connector........................................................................................... 66
4.4.7 USB Touch Panel Connector ........................................................................... 67
4.4.8 VGA Connector................................................................................................ 68
4.5 AV-6962 AD BOARD OVERVIEW .............................................................................. 69
4.5.1 AV-6962 AD Board Connectors ....................................................................... 71
4.5.2 AV-6962 AD Board Layout............................................................................... 72
4.5.3 AV-6962 Peripheral Interface Connectors....................................................... 73
4.5.4 AV-6962 Rear Panel Connectors..................................................................... 73
4.5.5 AV-6962 On-board Jumpers............................................................................. 74
4.6 AV-6962 INTERNAL PERIPHERAL CONNECTORS....................................................... 75
4.6.1 Audio Output Connector.................................................................................. 75
4.6.2 Auto-Dimming Connector................................................................................ 76
4.6.3 Debug Port Connector..................................................................................... 76
4.6.4 Backlight Inverter Interface Connector........................................................... 77
4.6.5 IR Sensor Connector........................................................................................ 78
4.6.6 LVDS Signal Output Connector....................................................................... 79
4.6.7 OSD and LED Connector ................................................................................ 80
4.6.8 Power Input Connector.................................................................................... 82
4.6.9 Power Output Connector................................................................................. 82
4.6.10 Remote Control Connector............................................................................ 83
Page ix
4.6.11 RS-232 Serial Port Connector........................................................................ 84
4.6.12 USB Connector .............................................................................................. 85
4.7 AV-6962 ON-BOARD JUMPERS ................................................................................. 86
4.7.1 LCD Panel Voltage Select Jumper................................................................... 87
4.8 AV-6962 EXTERNAL (REAR PANEL) CONNECTORS................................................... 88
4.8.1 Audio Jack........................................................................................................ 88
4.8.2 Component Video Connector ........................................................................... 89
4.8.3 Composite Video Connector............................................................................. 90
4.8.4 Digital Input Connector................................................................................... 91
4.8.5 DC 12V Connector........................................................................................... 92
4.8.6 RS-232 Touch Panel Connector....................................................................... 92
4.8.7 S-Video Connector........................................................................................... 93
4.8.8 USB Touch Panel Connector ........................................................................... 93
4.8.9 VGA Connector................................................................................................ 94
AFL M Series LCD Monitor
5 INSTALLATION .................................................................................................... 97
5.1 INSTALLATION PRECAUTIONS ................................................................................... 99
5.2 UNPACKING............................................................................................................ 100
5.2.1 Packaging ...................................................................................................... 100
5.2.2 Unpacking Procedure .................................................................................... 100
5.2.3 Packing List ................................................................................................... 102
5.3 PRE-INSTALLATION PREPARATION .......................................................................... 103
5.3.1 Tools ............................................................................................................... 103
5.4 CONNECTORS ......................................................................................................... 104
5.4.1 VGA Connector.............................................................................................. 104
5.4.2 12V Power Connector.................................................................................... 105
5.4.3 DVI-D Connector (AFL-15M/17M/19M Models Only)................................. 105
5.4.4 Optional RS-232 Touch Panel Connector...................................................... 106
5.4.5 Optional USB Touch Panel Connector .......................................................... 107
5.5 MOUNTING THE AFL SERIES INDUSTRIAL MONITOR.............................................. 107
5.5.1 Mounting Kits................................................................................................. 108
5.5.2 Panel Mounting.............................................................................................. 108
5.5.2.1 Standard Panel Mounting........................................................................ 108
5.5.3 Wall Mounting.................................................................................................111
5.5.4 AFL-07M/08MH/10M/12M Wall Mounting....................................................111
Page x
AFL M Series LCD Monitor
5.5.4.1 AFL-15M/17M/19M Wall Mounting.......................................................114
5.5.5 Monitor Stand Installation..............................................................................116
5.5.6 Arm Mounting .................................................................................................117
6 ON-SCREEN-DISPLAY (OSD) CONTROLS................................................ 121
6.1 USER MODE OSD STRUCTURE............................................................................... 123
6.1.1 OSD Buttons................................................................................................... 123
6.1.2 OSD Menu Structure...................................................................................... 124
6.2 USING THE OSD..................................................................................................... 126
6.2.1 Image Menu ................................................................................................... 126
6.2.2 Display Menu................................................................................................. 127
6.2.3 PiP Menu........................................................................................................ 128
6.2.4 Color Menu.................................................................................................... 129
6.2.5 System Menu .................................................................................................. 130
6.2.5.1 OSD Configuration................................................................................. 131
6.2.5.2 Auto-Brightness (Auto-Dimming) Configuration................................... 132
6.3 REMOTE CONTOL................................................................................................... 133
7 SOFTWARE DRIVERS....................................................................................... 134
7.1 INTRODUCTION....................................................................................................... 136
7.2 7-INCH TO 12.1-INCH DRIVER INSTALLATION AND CONFIG URATION....................... 136
7.2.1 RS-232 or USB Touch Screen......................................................................... 136
7.2.2 7-inch to 12.1-inch Touch Panel Driver Installation..................................... 137
7.2.3 Change the Touch Screen Interface................................................................ 145
7.2.4 7-inch to 12.1-inch Touch Panel Driver Configuration................................. 146
7.3 15-INCH TO 19-INCH DRIVER INSTALLATION AND CONFIG URATION........................ 147
7.3.1 RS-232 or USB Touch Screen......................................................................... 147
7.3.2 15-inch to 19-inch Touch Panel Driver Installation...................................... 147
7.3.3 15-inch to 19-inch Touch Panel Driver Configuration.................................. 154
7.4 CALIBRATING THE TOUCH SCREEN......................................................................... 154
8 GASKET REPLACEMENT................................................................................ 159
8.1 GASKET REPLACEMENT ......................................................................................... 161
A SAFETY PRECAUTIONS................................................................................... 164
A.1 SAFETY PRECAUTIONS .......................................................................................... 166
Page xi
AFL M Series LCD Monitor
A.1.1 General Safety Precautions........................................................................... 166
A.1.2 Anti-static Precautions.................................................................................. 167
A.2 MAINTENANCE AND CLEANING PRECAUTIONS...................................................... 167
A.2.1 Maintenance and Cleaning............................................................................ 167
A.2.2 Cleaning Tools............................................................................................... 168
B CERTIFICATIONS.............................................................................................. 169
B.1 ROHS COMPLIANT ................................................................................................ 171
B.2 IP 64 COMPLIANT FRONT PANEL ........................................................................... 171
C AUTO-DIMMING................................................................................................ 172
C.1 AUTO-DIMMING CONFIGURATIONS........................................................................ 174
C.1.1 Default Settings............................................................................................. 174
C.1.2 OSD Control.................................................................................................. 175
D SMARTOSD.......................................................................................................... 177
D.1 IEI SMARTOSD QUICK INSTALLATION GUIDE ....................................................... 179
D.2 PRE-INSTALLATION NOTICE................................................................................... 179
D.3 SOFTWARE ILLUSTRATION ..................................................................................... 179
D.3.1 EDID Page.................................................................................................... 181
D.3.2 Image Page ................................................................................................... 182
D.3.3 Display Page (for analog signal).................................................................. 183
D.3.4 Color Page.................................................................................................... 184
D.3.5 PIP Page (For MDM/AFLUX series)........................................................... 185
D.3.6 System Page .................................................................................................. 186
D.3.7 User Page...................................................................................................... 187
D.3.8 About Page.................................................................................................... 188
D.4 INSTALL SOFTWARE............................................................................................... 188
D.5 SMARTOSD FAQ................................................................................................... 194
E HAZARDOUS MATERIALS DISCLOSURE................................................... 198
E.1 HAZARDOUS MATERIAL DISCLOSURE TABLE FOR IPB PRODUCTS CER TIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY..................................... 200
F INDEX.................................................................................................................... 203
Page xii
AFL M Series LCD Monitor
Figure 1-1: AFL-12M Front View..................................................................................6
Figure 1-2: AFL-15M Front View..................................................................................6
Figure 1-3: AFL-12M Rear View ...................................................................................7
Figure 2-1: AFL-12M Front View................................................................................12
Figure 2-2: AFL-15M Front View................................................................................13
Figure 2-3: AFL-12M Bottom Panel View..................................................................15
Figure 2-4: AFL-15M Bottom Panel View..................................................................15
Figure 2-5: AFL-07M Physical Dimensions (millimeters)........................................17
Figure 2-6: AFL-08MH Physical Dimensions (millimeters) .....................................18
List of Figures
Figure 2-7: AFL-10M Physical Dimensions (millimeters)........................................19
Figure 2-8: AFL-12M Physical Dimensions (millimeters)........................................20
Figure 2-9: AFL-15M Physical Dimensions (millimeters)........................................21
Figure 2-10: AFL-17M Physical Dimensions (millimeters)......................................22
Figure 2-11: AFL-19M Physical Dimensions (millimeters)......................................23
Figure 2-12: Typical Wall Mounting...........................................................................26
Figure 4-1: AV-9962 AD Board Overview..................................................................44
Figure 4-2: AV-9962 Connector and Jumper Locations..........................................46
Figure 4-3: Audio Output Connector Location.........................................................49
Figure 4-4: Auto-dimming Connector Location.......................................................50
Figure 4-5: Debug Port Connector Location ............................................................51
Figure 4-6: OSD and LED Connector Location........................................................52
Figure 4-7: LED and Remote Sensor Connector Location......................................53
Figure 4-8: Backlight Inverter Connector Location.................................................54
Figure 4-9: IR Sensor Connector Location...............................................................55
Figure 4-10: LVDS Signal Output Connector Location ...........................................56
Figure 4-11: Power Output Connector Locations....................................................57
Figure 4-12: Remote Control Connector Location...................................................58
Figure 4-13: TTL Signal Output Connector Location ..............................................59
Page xiii
Figure 4-14: Touch Panel Connector Location........................................................60
Figure 4-15: Jumpers..................................................................................................61
Figure 4-16: AV-9962 Jumper Locations ..................................................................61
Figure 4-17: AV-9962 External (Rear Panel) Connectors........................................63
Figure 4-18: Component Video Connector Pinout Locations ................................64
Figure 4-19: S-Video Connector Pinout Locations..................................................67
Figure 4-20: USB Touch Panel Connector................................................................68
Figure 4-21: VGA Connector Pinout Locations........................................................69
Figure 4-22: AV-6962 AD Board Overview................................................................70
Figure 4-23: AV-6962 Connector and Jumper Locations........................................72
Figure 4-24: Audio Output Connector Location.......................................................75
Figure 4-25: Auto-dimming Connector Location.....................................................76
Figure 4-26: Debug Port Connector Location ..........................................................77
AFL M Series LCD Monitor
Figure 4-27: Backlight Inverter Connector Location...............................................78
Figure 4-28: IR Sensor Connector Location.............................................................79
Figure 4-29: LVDS Signal Output Connector Location ...........................................80
Figure 4-30: OSD and LED Connector Location......................................................81
Figure 4-31: Power Output Connector Locations....................................................82
Figure 4-32: Power Input Connector Locations.......................................................83
Figure 4-33: Remote Control Connector Location...................................................84
Figure 4-34: RS-232 Serial Port Connector Location ..............................................85
Figure 4-35: USB Connector Location......................................................................86
Figure 4-36: Jumpers..................................................................................................86
Figure 4-37: Jumper Locations..................................................................................87
Figure 4-38: AV-6962 External (Bottom Panel) Connectors....................................88
Figure 4-39: Component Video Connector Pinout Locations ................................90
Figure 4-40: DVI-D Connector Pinout Locations......................................................91
Figure 4-41: S-Video Connector Pinout Locations..................................................93
Page xiv
Figure 4-42: USB Touch Panel Connector................................................................94
Figure 4-43: VGA Connector Pinout Locations........................................................95
Figure 5-1: VGA Connector..................................................................................... 105
Figure 5-2: 12V Power Connector........................................................................... 105
AFL M Series LCD Monitor
Figure 5-3: DVI Connector....................................................................................... 106
Figure 5-4: Optional RS-232 Touch Panel Connector .......................................... 106
Figure 5-5: USB Touch Panel Connector............................................................... 107
Figure 5-6: AFL-07M Panel Opening ...................................................................... 109
Figure 5-7: AFL-08MH Panel Opening.................................................................... 109
Figure 5-8: AFL-12M Panel Opening ...................................................................... 109
Figure 5-9: Insert the Monitor ................................................................................. 110
Figure 5-10: Tighten the Panel Mounting Clamp Screws (AFL-12M).................. 111
Figure 5-11: Wall-mounting Bracket....................................................................... 112
Figure 5-12: Chassis Support Screws.................................................................... 113
Figure 5-13: Secure the Monitor............................................................................. 114
Figure 5-14: Wall-mounting Bracket....................................................................... 115
Figure 5-15: Chassis Support Screws.................................................................... 116
Figure 5-16: Monitor Stand Mounting .................................................................... 117
Figure 5-17: AFL-07M/AFL-08MH Arm Mounting Retention Screw Holes.......... 118
Figure 5-18: AFL-10M/12M Arm Mounting Retention Screw Holes..................... 118
Figure 5-19: AFL-15M/17M/19M Arm Mounting Retention Screw Holes............. 119
Figure 6-1: OSD Control Buttons............................................................................ 123
Figure 6-2: Image Menu........................................................................................... 126
Figure 6-3: Display Menu......................................................................................... 127
Figure 6-4: PiP Menu................................................................................................ 128
Figure 6-5: Color Menu............................................................................................ 129
Figure 6-6: System Menu......................................................................................... 130
Figure 6-7: OSD Configuration ............................................................................... 131
Figure 6-8: Auto Brightness Configuration........................................................... 132
Figure 6-9: Remote Control..................................................................................... 133
Figure 7-1: 7-inch to 12.1” Touch Screen Driver Installation Startup Screen.... 138
Figure 7-2: Available Drivers................................................................................... 139
Figure 7-3: Setup Icon.............................................................................................. 140
Figure 7-4: Welcome Screen................................................................................... 141
Figure 7-5: License Agreement............................................................................... 142
Figure 7-6: Initiate Install......................................................................................... 143
Page xv
Figure 7-7: Installation Starts.................................................................................. 144
Figure 7-8: Finish Installation................................................................................. 145
Figure 7-9: Control Panel ........................................................................................ 146
Figure 7-10: Remove Touch Screen Driver ........................................................... 146
Figure 7-11: Driver CD Pop Up Screen................................................................... 148
Figure 7-12: Install Shield Wizard Preparation...................................................... 149
Figure 7-13: Welcome Screen................................................................................. 149
Figure 7-14: Install PS/2 Interface Driver............................................................... 150
Figure 7-15: Install PS/2 Interface Driver............................................................... 151
Figure 7-16: Touch Monitor/USB Touch Controller Confirmation ...................... 151
Figure 7-17: Controller Installation Directory........................................................ 152
Figure 7-18: Program Icon Directory...................................................................... 153
Figure 7-19: Installing.............................................................................................. 153
AFL M Series LCD Monitor
Figure 7-20: Installation Complete ......................................................................... 154
Figure 7-21: PenMount Monitor Icon...................................................................... 155
Figure 7-22: PenMount Monitor Popup Menu ....................................................... 155
Figure 7-23: Configuration Screen......................................................................... 156
Figure 7-24: Calibration Initiation Screen.............................................................. 157
Figure 7-25: Calibration Screen.............................................................................. 157
Figure 8-1: Gasket Replacement ............................................................................ 161
Page xvi
AFL M Series LCD Monitor
Table 1-1: AFL Series Model Variants.........................................................................5
Table 1-2: AFL M Series Specifications......................................................................8
Table 2-1: General Physical Dimensions..................................................................16
Table 2-2: AFL Series Mounting Kits.........................................................................24
Table 2-3: Panel Mounting Clamps............................................................................25
Table 2-4: Rack Mounting Holes................................................................................25
Table 3-1: AFL-07M LCD Specifications ...................................................................30
Table 3-2: AFL-08MH LCD Specifications.................................................................31
Table 3-3: AFL-10M LCD Specifications ...................................................................31
List of Tables
Table 3-4: AFL-12M LCD Specifications ...................................................................32
Table 3-5: AFL-15M LCD Specifications ...................................................................33
Table 3-6: AFL-17M LCD Specifications ...................................................................34
Table 3-7: AFL-19M LCD Specifications ...................................................................35
Table 3-8: Touch Panel Models..................................................................................36
Table 3-9: Touch Panel Dimensions (mm)................................................................37
Table 3-10: Touch Panel Specifications....................................................................38
Table 3-11: Touch Panel RS-232 Controller Specifications....................................39
Table 3-12: Touch Panel USB Controller Specifications.........................................40
Table 3-13: Power Adapter Specifications ...............................................................41
Table 4-1: AV-9962 Peripheral Interface Connectors ..............................................47
Table 4-2: AV-9962 Rear Panel Connectors .............................................................47
Table 4-3: AV-9962 On-board Jumpers.....................................................................48
Table 4-4: Audio Output Connector Pinouts............................................................48
Table 4-5: Auto-dimming Connector Pinouts...........................................................49
Table 4-6: Debug Port Connector Pinouts................................................................50
Table 4-7: OSD and LED Connector Pinouts............................................................52
Table 4-8: LED and Remote Sensor Connector Pinouts.........................................53
Table 4-9: Backlight Inverter Connector Pinouts.....................................................54
Page xvii
Table 4-10: IR Sensor Connector Pinouts ................................................................55
Table 4-11: LVDS Signal Output Connector Pinouts...............................................56
Table 4-12: Power Output Connector Pinouts (CN15).............................................57
Table 4-13: Remote Control Connector Pinouts......................................................57
Table 4-14: TTL Signal Output Connector Pinouts..................................................59
Table 4-15: Touch Panel Connector Pinouts............................................................60
Table 4-16: LCD Panel Voltage Select Jumper Settings .........................................62
Table 4-17: LCD Panel Power Input Jumper Settings .............................................62
Table 4-18: Audio Jack Pinouts.................................................................................64
Table 4-19: Component Video Connector Pinouts..................................................64
Table 4-20: Composite Signal Input BNC Connector (J7) Pinouts ........................65
Table 4-21: Composite Signal Input Connector (J6) Pinouts .................................65
Table 4-22: DC 12V Connector Pinouts.....................................................................66
AFL M Series LCD Monitor
Table 4-23: RS-232 Touch Panel Connector Pinouts ..............................................66
Table 4-24: S-Video Connector Pinouts....................................................................67
Table 4-25: USB Touch Panel Connector Pinouts...................................................68
Table 4-26: VGA Connector Pinouts .........................................................................68
Table 4-27: AV-6962 Peripheral Interface Connectors ............................................73
Table 4-28: AV-6962 Rear Panel Connectors ...........................................................74
Table 4-29: AV-6962 On-board Jumpers...................................................................74
Table 4-30: Audio Output Connector Pinouts..........................................................75
Table 4-31: Auto-dimming Connector Pinouts.........................................................76
Table 4-32: Debug Port Connector Pinouts..............................................................77
Table 4-33: Backlight Inverter Connector Pinouts...................................................78
Table 4-34: IR Sensor Connector Pinouts ................................................................79
Table 4-35: LVDS Signal Output Connector Pinouts...............................................80
Table 4-36: OSD and LED Connector Pinouts..........................................................81
Table 4-37: Power Output Connector Pinouts (CN15).............................................82
Page xviii
Table 4-38: Power Input Connector Pinouts (CN15)................................................83
Table 4-39: Remote Control Connector Pinouts......................................................83
Table 4-40: RS-232 Serial Port Connector Pinouts..................................................84
Table 4-41: USB Connector Pinouts..........................................................................85
AFL M Series LCD Monitor
Table 4-42: LCD Panel Voltage Select Jumper Settings .........................................87
Table 4-43: Audio Jack Pinouts.................................................................................89
Table 4-44: Component Video Connector Pinouts..................................................89
Table 4-45: Composite Signal Input BNC Connector (J10) Pinouts ......................90
Table 4-46: Composite Signal Input Connector (J9) Pinouts .................................90
Table 4-47: DVI-D Connector Pinouts .......................................................................91
Table 4-48: DC 12V Connector Pinouts.....................................................................92
Table 4-49: RS-232 Touch Panel Connector Pinouts ..............................................93
Table 4-50: S-Video Connector Pinouts....................................................................93
Table 4-51: USB Touch Panel Connector Pinouts...................................................94
Table 4-52: VGA Connector Pinouts .........................................................................95
Table 5-1: External Peripheral Interface Connectors ........................................... 104
Table 5-2: Optional RS-232 Touch Panel Connector Pinouts.............................. 106
Table 5-3: USB Touch Panel Connector Pinouts.................................................. 107
Table 5-4: Mounting Kits ......................................................................................... 108
Table 5-5: AFL Series VESA Standard................................................................... 111
56 111
Table 6-1: OSD Menus ............................................................................................. 125
Page xix
AFL M Series LCD Monitor
THIS PAGE IS INTENTIONALLY LEFT BLANK
Page xx
AFL M Series LCD Monitor
Chapter
1
1 Introduction
Page 1
AFL M Series LCD Monitor
Page 2
AFL M Series LCD Monitor
1.1 AFL M Series LCD Monitor Overview
The AFL series industrial monitor is the latest member of IEI’s line of sophisticated LCD
designs, and it has been improved to be RoHS compliant. The AFL series is designed to
fit industrial automation, or any other applications that require minimum installation
space and flexible configuration. The flat front panel provides IP 64 protection, which
effectively wards off dust and water. Flexible analog or digital interfaces are provided for
ease of connection with a management computer. Resistive type touch panels are
optional. If remote/non-attentive control is preferred, RS-232 or USB interfaces can be
used with customized adapter cables.
1.1.1 Added Features
The following features have been added to the Revision 11 models described in this
manual:
7” to 12.1” models all have both RS-232 and USB touch screen options
integrated into a single system.
15” – 19” have both USB touch screen models and RS-232 touch screen
models.
New firmware for the IEI smartOSD function is integrated into all revision 11
(and above) AFOLUX monitors in the AFOLUX series.
1.1.2 Standard Features
Some of the features of the AFL series industrial monitor include:
7”/8.4”/10.4”/12.1”/15”/17”/19” TFT LCD
Picture in Picture (PiP) support
Fully functional OSD remote control
Built-in speakers
Multiple input interfaces including
o Analog VGA
o Audio line-in
o Component Video
o S-Video
o Composite
Page 3
Support wall/panel/rack/stand/arm mounting
Silver color
IP 64 compliant front panel
RoHS compliant
Integrated auto-dimming control sensor (AFL-15M/17M/19M models only)
Optional resistive type RS-232/USB touch panel
1.1.3 IEI smartOSD
IEI smartOSD is a proprietary On-Screen-Display (OSD) software solution from IEI that
enables easy monitor setting adjustments in a Windows environment. IEI smartOSD
delivers excellent performance and provides more flexibility for adjusting the monitor than
the typical OSD hardware solutions. smartOSD also allows monitor settings such as
brightness, contrast, screen position, size and color gain to be read and changed over a
AFL M Series LCD Monitor
o DVI-D (AFL-15M/17M/19M models only)
normal video cable (VGA or DVI).
1.1.4 Model Variations
The AFL Series has sixteen models variations listed in Table 1-1.
NOTE:
The smartOSD function is only supported by Revision 11 models and
above
Model Number LCD Size Max. Resolution Brightness Touch Screen
AFL-07M
AFL-07M/T-R
7” 800 x 480 350cd/m
7” 800 x 480 350cd/m
2
No
2
Yes (USB or RS-232)
Page 4
AFL-08MH
AFL-08MH/T-R
8.4” 800 x 600 450cd/m
8.4” 800 x 600 450cd/m
2
No
2
Yes (USB or RS-232)
AFL M Series LCD Monitor
AFL-10M
AFL-10M/T-R
AFL-12M
AFL-12M/T-R
AFL-15M
AFL-15M/T-R
AFL-15M-USB/T-R
AFL-17M
AFL-17M/T-R
AFL-17M-USB/T-R
AFL-19M
10.4” 800 x 600 400cd/m
10.4” 800 x 600 400cd/m
12.1” 1024 x 768 450cd/m
12.1” 1024 x 768 450cd/m
15” 1024 x 768 350cd/m
15” 1024 x 768 350cd/m
15” 1024 x 768 350cd/m
17” 1280 x 1024 300cd/m
17” 1280 x 1024 300cd/m
17” 1280 x 1024 300cd/m
19” 1280 x 1024 300cd/m
2
No
2
Yes (USB or RS-232)
2
No
2
Yes (USB or RS-232)
2
No
2
Yes (RS-232 only)
2
Yes (USB only)
2
No
2
Yes (RS-232 only)
2
Yes (USB only)
2
No
AFL-19M/T-R
AFL-19M-USB/T-R
19” 1280 x 1024 300cd/m
19” 1280 x 1024 300cd/m
Table 1-1: AFL Series Model Variants
1.2 External Overview
The AFL series industrial monitors are durable devices that can be used in multiple
industrial environments. The following sections describe the physical layout of the AFL
series industrial monitors.
1.2.1 Front View
The front of the AFL series industrial monitor is a flat panel TFT LCD screen surrounded
by an ABS/PC plastic frame.
of AFL-12M and AFL-15M.
2
Yes (RS-232 only)
2
Yes (USB only)
Figure 1-1 and Figure 1-2 shows the LCD monitor front view
Page 5
AFL M Series LCD Monitor
Figure 1-1: AFL-12M Front View
Figure 1-2: AFL-15M Front View
1.2.2 Rear View
The rear panel features fan ventilation holes and four retention screw holes that support a
wall-mounting bracket. The AFL-12M retention screw holes are shown in
Page 6
Figure 1-3.
AFL M Series LCD Monitor
Figure 1-3: AFL-12M Rear View
1.3 Series Specifications
Table 1-2 shows the AFL Series specifications.
Model AFL-07M AFL-08MH AFL-10M AFL-12M AFL-15M AFL-17M AFL-19M
LCD Size 7” 8.4" 10.4" 12.1" 15" 17" 19"
Composite
Input
Interface
Max.
Resolution
Brightness
(cd/m2)
Contrast 400:1 500:1 500:1 700:1 400:1 800:1 800:1
LCD Color 262K 262K 262K 262K 262K 16.7M 16.7M
Pixel Pitch (mm) 0.1905 0.213 0.264 0.240 0.297 0.264 0.294
View Angle
(H / V)
YPbPr
S-Video
VGA
800x480 800x600 800x600 1024x768
350 450 400 450 350 300 300
140/100 120/100 120/100 160/160 120/100 160/160 160/160
Composite
YPbPr
S-Video
VGA
Composite
YPbPr
S-Video
VGA
Composite
YPbPr
S-Video
VGA
Composite
YPbPr
S-Video
VGA
DVI-D
1024x768 1280x1024 1280x1024
Composite
YPbPr
S-Video
VGA
DVI-D
Composite
YPbPr
S-Video
VGA
DVI-D
Backlight MTBF 50000 50000 50000 50000 50000 50000 50000
Page 7
(Hrs)
Front Frame ABS/PC ABS/PC ABS/PC ABS/PC ABS/PC ABS/PC ABS/PC
AFL M Series LCD Monitor
Chassis Aluminum Aluminum Aluminum
Audio In AMP 1.5W + AMP 1.5W (internal speaker)
Power Adapter 36W 36W 36W 36W 60W 60W 60W
AD Board AV-9962 AV-9962 AV-9962 AV-9962 AV-6962 AV-6962 AV-6962
Panel
Rack
Mounting
OSD function Yes Yes Yes Yes Yes Yes Yes
OSD Keypad No No No No Yes Yes Yes
IR Sensor Yes Yes Yes Yes Yes Yes Yes
Ambient Light
Sensor
Dimension
(WxHxD) (mm)
Wall
Stand
Arm
No NO No No Yes Yes Yes
226 x
140 x
40.18
Panel
Rack
Wall
Stand
Arm
233.86 x
183.86 x
41.09
Panel
Rack
Wall
Stand
Arm
276 x
227 x
50.7
Aluminum Aluminum Aluminum Aluminum
AMP 3W + AMP 3W
(internal speaker)
Panel
Rack
Wall
Stand
Arm
304 x
246 x
49.5
Wall
Stand
Arm
393.06 x
308.06 x
61
Wall
Stand
Arm
428 x
350 x
65
Wall
Stand
Arm
469.94 x
382.46 x
67
Operation
Temperature
IP Level IP 64 IP 64 IP 64 IP 64 IP 64 IP 64 IP 64
N/G Weight 0.88kg 1.14kg 1.33kg 2.12kg 3.2kg 5.0kg 5.6kg
0°C ~50°C 0°C ~50°C 0°C ~50°C
0°C ~50°C 0°C ~50°C 0°C ~50°C 0°C ~50°C
Table 1-2: AFL M Series Specifications
1.4 Certifications
All AFL series industrial monitor models comply with the following international standards:
RoHS
IP 64
B.1 and B.2.
Page 8
For a more detailed description of these standards, please refer to Sections
AFL M Series LCD Monitor
THIS PAGE IS INTENTIONALLY LEFT BLANK
Page 9
AFL M Series LCD Monitor
Chapter
2
2 Mechanical Overview
Page 10
AFL M Series LCD Monitor
Page 11
2.1 Introduction
This chapter describes the general mechanical overview of the AFL series monitors
including front and rear panel, available interfaces and overall dimensions.
2.2 Front View
The front of the AFL series industrial monitor is a flat panel TFT LCD screen surrounded
by an ABS/PC plastic frame. The AFL series monitor also includes one sensor and one
LED on the front panel:
Infrared Sensor
This sensor receives the signal from the remote control.
Power LED lights up turned on in green when the LCD monitor is on.
AFL M Series LCD Monitor
Figure 2-1 shows the LCD monitor front view of AFL-12M.
Figure 2-1: AFL-12M Front View
Page 12
AFL M Series LCD Monitor
A control button panel (OSD) with the following control buttons is located horizontally on
the bottom of the front frame of AFL-15M/17M/19M monitors:
LCD On/Off
Auto
Left
Up
Down
Right
Menu
The AFL-15M/17M/19M monitors also provide auto-dimming function and include:
Ambient Light Sensor
The ambient light sensor detects the brightness of the ambient environment
when the auto-dimming function is turned on.
Auto-Dimming LED
The auto-dimming LED lights up in red when the auto-dimming function is on.
Figure 2-2 shows the LCD monitor front view of AFL-15M.
Figure 2-2: AFL-15M Front View
Page 13
2.3 Bottom Panel
All peripheral device connectors are located on the bottom panel of the AFL series
industrial monitor. The following sections describe the bottom panel variants and their
associated connectors.
2.3.1 AFL-07M/08MH/10M/12M Connectors
The following is a list of the bottom panel peripheral device connectors used on the
AFL-07M/08MH/10M/12M series industrial monitor.
12V power connector
Audio jack
Component video connector
Composite video connector
AFL M Series LCD Monitor
S-Video connector
VGA connector
RS-232 serial connector (T-R models only)
USB connector (T-R models only)
2.3.2 AFL-15M/17M/19M Connectors
The following is a list of the bottom panel peripheral device connectors used on the
AFL-15M/17M/19M series industrial monitor.
12V power connector
Audio jack
Component video connector
Composite BNC connector
DVI-D connector
S-Video connector
VGA connector
Page 14
RS-232 serial connector (T-R models only)
USB connector (T-R models only)
Figure 2-3 shows the bottom panel of the AFL-12M monitor and Figure 2-4 shows the
bottom panel of the AFL-15M monitor.
AFL M Series LCD Monitor
Figure 2-3: AFL-12M Bottom Panel View
Figure 2-4: AFL-15M Bottom Panel View
2.4 Physical Dimensions
The following sections describe the physical dimensions for the AFL series industrial
monitor.
2.4.1 General Physical Dimensions
General physical dimensions for the AFL series monitors are shown in Table 2-1.
Page 15
AFL M Series LCD Monitor
Model
Width
(mm)
AFL-07M 226.00 140.00 40.18
AFL-08MH 233.86 183.86 41.09
AFL-10M 276.00 227.00 50.70
AFL-12M 304.00 246.00 49.50
AFL-15M 393.04 308.06 61.00
AFL-17M 428.00 350.00 65.00
AFL-19M 469.94 382.46 66.85
Height
(mm)
Depth
(mm)
Table 2-1: General Physical Dimensions
Page 16
AFL M Series LCD Monitor
2.4.2 AFL-07M Physical Dimensions
The physical dimensions of the AFL-07M are shown in Figure 2-5.
Figure 2-5: AFL-07M Physical Dimensions (millimeters)
Page 17
2.4.3 AFL-08MH Physical Dimensions
The physical dimensions of the AFL-08MH are shown in Figure 2-6.
AFL M Series LCD Monitor
Figure 2-6: AFL-08MH Physical Dimensions (millimeters)
Page 18
AFL M Series LCD Monitor
2.4.4 AFL-10M Physical Dimensions
The physical dimensions of the AFL-10M are shown in Figure 2-7.
Figure 2-7: AFL-10M Physical Dimensions (millimeters)
Page 19
2.4.5 AFL-12M Physical Dimensions
The physical dimensions of the AFL-12M are shown in Figure 2-8.
AFL M Series LCD Monitor
Figure 2-8: AFL-12M Physical Dimensions (millimeters)
Page 20
AFL M Series LCD Monitor
2.4.6 AFL-15M Physical Dimensions
The physical dimensions of the AFL-15M are shown in Figure 2-9.
Figure 2-9: AFL-15M Physical Dimensions (millimeters)
Page 21
2.4.7 AFL-17M Physical Dimensions
The physical dimensions of the AFL-17M are shown in Figure 2-10.
AFL M Series LCD Monitor
Figure 2-10: AFL-17M Physical Dimensions (millimeters)
Page 22
AFL M Series LCD Monitor
2.4.8 AFL-19M Physical Dimensions
The physical dimensions of the AFL-19M are shown in Figure 2-11.
Figure 2-11: AFL-19M Physical Dimensions (millimeters)
Page 23
2.5 Mounting Kits
The following sections describe the various optional mounting kits available for each
AFL M Series LCD Monitor
model of the AFL series industrial monitor. Refer to Section
5.5 for detailed instructions
on the different mounting methods for the monitors.
Table 2-2 lists the mounting kits available for the AFL series monitor.
AFL-07M AFL-08MH AFL-10M AFL-12M AFL-15M AFL-17M AFL-19M
Panel Mounting kits
Wall Mounting kits AFLWK-12 AFLWK-19
Rack Mounting Kits AFLRK-07 AFLRK-08
LCD Monitor Stand STAND-A08 STAND-A12 STAND-A19/STAND-B19
AFLPK-08 AFLPK-12 AFLPK-15 AFLPK-17 AFLPK-19
AFLRK-10 AFLRK-12 AFLRK-15 AFLRK-17 N/A
Table 2-2: AFL Series Mounting Kits
2.6 Mounting Options
Each AFL series industrial monitor has a number of mounting holes or slots located on the
back side of the ABS/PC frame or on the rear panel for mounting the monitor to a rack,
panel, wall, arm or stand. The following sections describe the various mounting methods
or each model of the AFL series industrial monitor.
2.6.1 Panel Mounting
AFL-07M, AFL-08MH, AFL-10M and AFL-12M models of the AFL series industrial monitor
have a series of mounting slots located on the top and bottom panel for mounting the
monitor to a panel.
Table 2-3 lists the number of mounting clamps required to mount the monitor to a panel.
Model Mounting Clamps
AFL-07M 4
Page 24
AFL M Series LCD Monitor
AFL-08MH 6
AFL-10M 6
AFL-12M 6
Table 2-3: Panel Mounting Clamps
2.6.2 Rack and Cabinet Mounting
AFL-07M, AFL-08MH, AFL-10M and AFL-12M models of the AFL series industrial monitor
have a series of holes located on the rear of the top and bottom panel for securing the
monitor to the rack mounting kit.
Table 2-4 lists the number of holes each monitor has to secure the monitor to the rack
mounting kit.
Model Holes
AFL-07M 4
AFL-08MH 6
AFL-10M 6
AFL-12M 6
Table 2-4: Rack Mounting Holes
2.6.3 Wall Mounting
Each model of the AFL series industrial monitor has four holes located on the rear panel
for mounting the monitor to a wall.
Figure 2-12 shows the typical methods for wall mounting.
Page 25
Figure 2-12: Typical Wall Mounting
2.6.4 Monitor Arm or Stand Mounting
AFL M Series LCD Monitor
The AFL series industrial monitor has four mounting holes which are compatible with
VESA FDMI (MIS-D 75 and/or MIS-D 100) and located on the rear panel for mounting the
monitor to a monitor arm or stand.
Page 26
AFL M Series LCD Monitor
Chapter
3
3 LCD and Touch Panel
Specifications
Page 27
AFL M Series LCD Monitor
Page 28
AFL M Series LCD Monitor
3.1 LCD Specifications
3.1.1 LCD Overview
The AFL series industrial monitors use the following LCD panels.
AFL-07M: Data Image FG0700A1DSCWBGL1 7” WVGA TFT LCD
AFL-08MH: AUO G084SN05 8.4” SVGA TFT LCD
AFL-10M: TOSHIBA LTA104D182F 10.4" SVGA TFT LCD
AFL-12M: CMO G121X1-L01 12.1” XGA TFT LCD
AFL-15M: AUO G150XG01 15” XGA TFT LCD
AFL-17M: AUO M170EG01 17” SXGA TFT LCD
AFL-19M: AUO M190EG02 19” SXGA TFT LCD
Detailed specifications for the LCD screens are listed in the following sections.
3.1.2 AFL-07M LCD Specifications
Table 3-1 lists the LCD specifications of the AFL-07M.
Model AFL-07M
Size
MFR/Model Data Image FG0700A1DSCWBGL1
Resolution
Active Area (mm)
Pixel Pitch (mm)
Number of Colors
View Angle (H/V)
Brightness (cd/m2)
Contrast Ratio
Response Time (ms) (at 25C)
Power Consumption (W)
WVGA (800 x 480)
7”
152.4 x 91.44
0.1905
262K
140 / 100
350
400:1
15 (Tr)/20 (Tf)
2.7
Interface
Supply Voltage (V)
1ch TTL
3.3
Page 29
AFL M Series LCD Monitor
Backlight
Lamp Life (hrs)
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Shock (Non-Operating) 100G, 6ms, Half-sine wave
Vibration (Non-Operating) 2.9G, 33.3~400Hz, Sine wave 15mins/axis, 3 direction
1 CCFL
50,000
0℃~+50℃
8%~95%RH
-20℃~+60℃
5%~90%RH
Table 3-1: AFL-07M LCD Specifications
3.1.3 AFL-08MH LCD Specifications
Table 3-2 lists the LCD specifications of the AFL-08MH.
Model AFL-08MH
Size
8.4”
MFR/Model
Resolution
Active Area (mm)
Pixel Pitch (mm)
Number of Colors
Color Saturation (NTSC%)
View Angle (H/V)
Brightness (cd/m2)
Contrast Ratio
Response Time (ms) (at 25C)
Power Consumption (W)
Interface
Supply Voltage (V)
Backlight
Lamp Life (hrs)
AUO/G084SN05
SVGA (800 x 600)
170.4 x 127.8
0.213
262K
45
120 / 100
450
500:1
10 (Tr)/25 (Tf)
5.8
1ch LVDS
3.3
2 CCFL
50000
Page 30
Operating Temperature
0℃~+50℃
AFL M Series LCD Monitor
Operating Humidity
Storage Temperature
Storage Humidity
Shock (Non-Operating)
Vibration (Non-Operating) 1.5G, 10~200~10Hz, Sine wave 30mins/axis, 3 direction
8%~95%RH
-20℃~+60℃
5%~95%RH
50G, 20ms, Half-sine wave
Table 3-2: AFL-08MH LCD Specifications
3.1.4 AFL-10M LCD Specifications
Table 3-3 lists the LCD specifications of the AFL-10M.
Model AFL-10M
Size 10.4”
MFR/Model TOSHIBA/LTA104D182F
Resolution SVGA (800 x 600)
Active Area (mm) 211.1 x 158.4
Pixel Pitch (mm) 0.264 x 0.264
Number of Colors 262 K
View Angle (H/V) 120/100
Brightness (cd/m2) 400
Contrast Ratio 500:1
Interface 1ch LVDS
Supply Voltage (V) 3.3
Backlight 2 CCFL
Lamp Life (hrs) 50000
Operating Temperature -10
Storage Temperature -20
Storage Humidity 10%~90%RH
℃
~+70℃
℃
~+80℃
Table 3-3: AFL-10M LCD Specifications
Page 31
3.1.5 AFL-12M LCD Specifications
Table 3-4 lists the LCD specifications of the AFL-12M.
Model AFL-12M
Size 12.1”
MFR/Model CMO/G121X1-L01
Resolution XGA (1024 x 768)
Active Area (mm) 245.76 x 184.32
Pixel Pitch (mm) 0.240
Number of Colors 262K
View Angle (H/V) 160 / 160
Brightness (cd/m2) 450
Contrast Ratio 700:1
AFL M Series LCD Monitor
Response Time (ms) (at 25C) 6 (Tr)/17 (Tf)
Power Consumption (W) 4
Interface LVDS
Supply Voltage (V) 3.3
Backlight 2 CCFL
Lamp Life (hrs) 50000
Operating Temperature -30
Operating Humidity 8%~95%RH
Storage Temperature -40
Storage Humidity 5%~95%RH
Shock (Non-Operating) 220G, 2ms, Half-sine wave
Vibration (Non-Operating) 1.5G, 10~300Hz,
Sine wave 10mins/axis, 3 direction
℃
~+70℃
℃
~+80℃
Table 3-4: AFL-12M LCD Specifications
3.1.6 AFL-15M LCD Specifications
Table 3-5 lists the LCD specifications of the AFL-15M.
Page 32
AFL M Series LCD Monitor
Model AFL-15M
Size 15"
MFR/Model AUO/G150XG01
Resolution XGA (1024 x 768)
Active Area (mm) 304.1 x 228.1
Pixel Pitch (mm) 0.297
Number of Colors 262K
View Angle (H/V) 120/100
Brightness (cd/m2) 350
Contrast Ratio 400:1
Response Time (ms) (at 25C) 16 (Tr+Tf)
Power Consumption (W) 11.5
Interface LVDS
Supply Voltage (V) 3.3
Backlight 2 CCFL
Lamp Life (hrs) 50000
Operating Temperature 0
Operating Humidity 20%~85%RH
Storage Temperature -20
Storage Humidity 5%~95%RH
Shock (Non-Operating) 50G, 20ms, Half-sine wave
Vibration (Non-Operating) 1.5G, 10~200Hz,
Sine wave 30mins/axis, 3 direction
℃
~+50℃
℃
~+60℃
Table 3-5: AFL-15M LCD Specifications
3.1.7 AFL-17M LCD Specifications
Table 3-6 lists the LCD specifications of the AFL-17M.
Model AFL-17M
Size
MFR/Model
17”
AUO/M170EG01
Page 33
AFL M Series LCD Monitor
Resolution
Active Area (mm)
Pixel Pitch (mm)
Number of Colors
View Angle (H/V)
Brightness (cd/m2)
Contrast Ratio
Response Time (ms) (at 25C)
Power Consumption (W)
Interface
Supply Voltage (V)
Backlight
Lamp Life (hrs)
Operating Temperature 0
Operating Humidity 5%~90%RH
SXGA (1280 x 1024)
337.9 x 270.3
0.264
16.7M
160/160
300
800:1
5 (Tr+Tf)
25.8
2ch LVDS
5
4 CCFL
50,000
℃
~+50℃
Storage Temperature -20
Storage Humidity 5%~90%RH
Shock (Non-Operating) 50G, 20ms, Half-sine wave
Vibration (Non-Operating) 1.5G, 10~200~10Hz,
Sine wave 30mins/axis, 3 direction
℃
~+60℃
Table 3-6: AFL-17M LCD Specifications
Page 34
AFL M Series LCD Monitor
3.1.8 AFL-19M LCD Specifications
Table 3-7 lists the LCD specifications of the AFL-19M.
Model AFL-19M
Size
MFR/Model
Resolution
Active Area (mm)
Pixel Pitch (mm)
Number of Colors
View Angle (H/V)
Brightness (cd/m2)
Contrast Ratio
Response Time (ms) (at 25C)
Power Consumption (W)
Interface
Supply Voltage (V)
Backlight
Lamp Life (hrs)
19”
AUO/M190EG02
SXGA (1280 x 1024)
376.32 x 301.06
0.294
16.7M
160 / 160
300
800:1
5 (Tr+Tf)
24.71
2ch LVDS
5
4 CCFL
50,000
Operating Temperature 0
Operating Humidity 5%~90%RH
Storage Temperature -20
Storage Humidity 5%~90%RH
Shock (Non-Operating) 50G, 20ms, Half-sine wave
Vibration (Non-Operating) 1.5G, 10~200~10Hz,
Sine wave 30mins/axis, 3 direction
℃
~+50℃
℃
~+60℃
Table 3-7: AFL-19M LCD Specifications
Page 35
3.2 Optional Touch Panels
IEI offers optional touch panels for the AFL series industrial monitors with the following
features:
Small border customized design
All size touch panel design
Customized activation force and palm rejection
Customized optical characteristics
High reliability and durability in the field
3.2.1 Touch Panel Models
Table 3-8 lists the AFL series industrial monitors and their associated touch panels.
AFL M Series LCD Monitor
Model Touch Panel
AFL-19M PanJit 1190503A
AFL-17M PanJit 1171505A
AFL-15M PanJit 1150508B
AFL-12M PanJit 1121505B
AFL-10M PanJit 1104502A
AFL-08MH PanJit 1084403B
AFL-07M PanJit 1070404C
Table 3-8: Touch Panel Models
Page 36
AFL M Series LCD Monitor
3.2.2 Touch Panel Dimensions
Table 3-9 shows the touch panel dimensions in millimeters.
Model: Dimension
Dimensional Outline: 330 404.6 2.8
PanJit
1190503A
PanJit
1171505A
PanJit
1150508B
PanJit
1121505B
PanJit
1104502A
Viewing Area: 306.05 381.3 -
Active Area: 301.05 376.3 -
Key Area: 300.05 375.3 -
Dimensional Outline: 365 295.08 2.9
Viewing Area: 342.05 275.45 -
Active Area: 342.05 275.45 -
Key Area: 338.0 271.4 -
Dimensional Outline: 257.5 333.6 2.9
Viewing Area: 232.1 308.2 -
Active Area: 228.1 304.1 -
Dimensional Outline: 204 268 2.1
Viewing Area: 188 250 -
Active Area: 185 246 -
Dimensional Outline: 238.8 188.7 2.6
Viewing Area: 219.8 166.8 -
Active Area: 212.1 159.3 -
Width Length Thick
PanJit
1084403B
PanJit
1070404C
Dimensional Outline: 145.53 188.04 2.1
Viewing Area: 130.75 173.38 -
Active Area: 127.78 170.38 -
Dimensional Outline: 165.00 104.00 1.4
Viewing Area: 154.90 93.94 -
Active Area: 152.4 91.44 -
Table 3-9: Touch Panel Dimensions (mm)
Page 37
3.2.3 Touch Panel Specifications
Table 3-10 lists the touch panel specifications.
Type Analog Resistive Type Touch Panel
Input Method Finger, Stylus or gloved hand
Wire Type 5-wire/4-wire
Maximum Voltage and Currant DC7V
Position Accuracy Less than 1.5%
Isolation ≥20M ohm
Resolution 4096 x 4096 dpi based on controller resolution
Activation Force Typical: less than 100g
Controller Interface RS-232 or USB 1.1
AFL M Series LCD Monitor
Optional: custom activation force and palm rejection
Light Transmission Anti-glare type: 78% - 90%
Temperature (Typical) Operating: -10°C to 60°C
Storage: -20°C to 70°C
Relative Humidity Operating: 20% to 90%RH
Storage: 20% to 90%RH
Electrostatic Protection Touch Panel: 30KV (Contact/Air)
Controller: 20KV (Contact/Air)
Surface Hardness 3H and above per LIS K5400
Life (Hitting) More than 10 million for 5-wire touch panel
Life (Drawing) More than 300 K alphabets for 5-wire touch panel
OS Compatibility Windows: XP/XP Embedded
Windows 2000
Windows ME
Windows 98 SE
Windows CE.Net 4.2 (x86 and ARM)
WHQL certified
Page 38
Linux: Fedora Core I/II, Mandrake 10.0/10.1,
RedHat 9.0
Table 3-10: Touch Panel Specifications
AFL M Series LCD Monitor
3.2.4 Touch Panel RS-232 Controller Specifications
Table 3-11 lists the touch panel RS-232 controller specifications.
Circuit Board Dimension 20mm x 75mm (0.79inches x
2.95inches)----(5-Wire)
Power Requirements D.C.+5V (100mA typical, 50mV peak to peak
maximum ripple and noise)
Operating Temperature 0°C to 50°C
Storage Temperature -40°C to 80°C
Relative Humidity 95% at 60°C
Interface Bi-directional RS-232 serial communication
Protocol No parity, 8 data bits, 1 stop bit,
9600 baud (N,8,1,9600)
Resolution 2048x2048
Report Rate Max. 160 points/sec
Response Time Max. 35 ms
Attached Cable 6' shielded cable with 9-pin D-sub connector
Regulatory Approvals FCC-B, CE, Unaffected by EMI from other nearby
CRTs and other display devices
EMI Unaffected by environmental EMI
Panel Resistance 5 wire resistive model: 50 ~ 200 ohm
Table 3-11: Touch Panel RS-232 Controller Specifications
Page 39
3.2.5 Touch Panel USB Controller Specifications
Table 3-12 lists the touch panel USB controller specifications.
Circuit Board Dimension 20mm x 75mm (0.79inches x
2.95inches)----(5-Wire)
Power Requirements D.C.+5V (100mA typical, 50mV peak to peak
maximum ripple and noise)
Operating Temperature 0°C to 50°C
Storage Temperature -40°C to 80°C
Relative Humidity 95% at 60°C
Interface USB 1.1 Low Speed
Protocol No parity, 8 data bits, 1 stop bit,
9600 baud (N,8,1,9600)
AFL M Series LCD Monitor
Resolution 2048 x 2048
Report Rate Max. 160 points/sec
Response Time Max. 35 ms
Attached Cable 6' shielded cable with USB-A connector for USB port
Regulatory Approvals FCC-B, CE, Unaffected by EMI from other nearby
CRTs and other display devices
EMI Unaffected by environmental EMI
Panel Resistance 5 wire resistive model: 50 ~ 200 ohm
Table 3-12: Touch Panel USB Controller Specifications
Page 40
AFL M Series LCD Monitor
3.3 Power Adapters
Table 3-13 lists the AC/DC power adapter specifications.
Model AFL-07M, AFL-08MH, AFL-10M,
AFL-12M
Power 36 Watt AC/DC Adapter 60 Watt AC/DC Adapter
Output Voltage 12V 12V
Input Voltage Range 90-264VAC 90-264VAC
Input Frequency 47-63 Hz 47-63 Hz
Inrush Current 220V@100A 220V@100A
Hold-up Time 5mS 8mS
Leakage Current 3.5mA max. (at 240Vac 60Hz) 0.75mA max. (at 240Vac 60Hz)
Short Circuit Protection Continuous Continuous
Over-voltage Protection Yes Yes
MTBF 60000hrs 60000hrs
Efficiency 80% 80%
Operating Temperature 0°C ~40°C 0°C ~40°C
Storage Temperature -20°C ~65°C -20°C ~65°C
AFL-15M, AFL-17M, AFL-19M
Table 3-13: Power Adapter Specifications
Page 41
AFL M Series LCD Monitor
Chapter
4
4 AD Board
Page 42
AFL M Series LCD Monitor
Page 43
4.1 AV-9962 AD Board Overview
The AFL-07M, AFL-08MH, AFL-10M and AFL-12M industrial monitors are preinstalled
with AV-9962 AD board to provide a wide variety of control interfaces. The following
sections describe the AV-9962 AD board in detail.
AFL M Series LCD Monitor
Figure 4-1: AV-9962 AD Board Overview
Page 44
AFL M Series LCD Monitor
4.1.1 AV-9962 AD Board Connectors
The AV-9962 AD board has the following connectors on-board:
1 x Audio output connector
1 x Auto-dimming connector
1 x Debug port
1 x LED indicator and remote sensor connector
1 x Inverter interface connector
1 x IR sensor connector
1 x LVDS signal output connector (AFL-08MH/10M/12M only)
1 x OSD and LED connector
1 x Power output connector
1 x Remote control connector
1 x TTL signal output connector (AFL-07M only)
1 x Touch panel connector
The AV-9962 AD board has the following connectors on the board rear panel:
1 x Audio jack
1 x Component video connector
1 x Composite video connector
1 x Power input connector
1 x RS-232 connector
1 x S-Video connector
1 x USB connector
1 x VGA connector
The locations of the peripheral interface connectors for the AV-9962 AD board are shown
in Section
Section
4.1.2. A complete list of all the peripheral interface connectors can be seen in
4.1.3.
Page 45
4.1.2 AV-9962 AD Board Layout
Figure 4-2 shows the on-board peripheral connectors and on-board jumpers.
AFL M Series LCD Monitor
Figure 4-2: AV-9962 Connector and Jumper Locations
4.1.3 AV-9962 Peripheral Interface Connectors
Table 4-1 shows a list of the peripheral interface connectors on the AV-9962 AD board.
Detailed descriptions of these connectors can be found in Section
Connector Type Label
Audio output connector 4-pin wafer connector CN11
Auto-dimming connector 6-pin wafer connector CN3
Debug port 3-pin wafer connector CN12
LED indicator and remote sensor connector 6-pin header CN16
4.2.
Page 46
Inverter interface connector 6-pin wafer connector CN9
IR sensor connector 4-pin wafer connector CN10
AFL M Series LCD Monitor
LVDS signal output connector
(AFL-08MH/10M/12M only)
OSD and LED connector 16-pin wafer connector CN1
Power output connector 2-pin wafer connector CN15
Remote control connector 3-pin wafer connector CN4
TTL signal output connector (AFL-07M only) 40-pin connector CN8
Touch panel connector 9-pin wafer connector J10
Table 4-1: AV-9962 Peripheral Interface Connectors
4.1.4 AV-9962 Rear Panel Connectors
30-pin connector CN7
Table 4-2 lists the rear panel connectors on the AV-9962 AD board. Detailed descriptions
of these connectors can be found in Section
Connector Type Label
Audio jack Audio jack J3
Component video signal input jack mini-DIN 7 component connector J2
Composite signal input jack Composite video connector J6, J7
Power input connector DC 12V Jack J4
RS-232 connector DB-9 female connector J9
S-Video signal input jack mini-DIN 4 S-Video connector J5
USB connector USB port J8
VGA connector D-sub 15-pin female connector J1
Table 4-2: AV-9962 Rear Panel Connectors
4.4.
Page 47
4.1.5 AV-9962 On-board Jumpers
Table 4-3 lists the on-board jumpers. A detailed description of these jumpers can be found
AFL M Series LCD Monitor
in Section
Jumper Type Label
LCD Panel Voltage Select 6-pin header JP5
Touch screen select 2-pin header JP6
Table 4-3: AV-9962 On-board Jumpers
4.3.
4.2 AV-9962 Internal Peripheral Connectors
Internal peripheral connectors on the AV-9962 AD board are only accessible when the
board is outside of the monitor. This section has complete descriptions of all the internal,
peripheral connectors on the AV-9962 AD board.
4.2.1 Audio Output Connector
CN Label: CN11
CN Type: 4-pin wafer connector
CN Pinouts:
CN Location:
The audio output connector connects to two preinstalled speakers.
PIN DESCRIPTION
1 Audio_Output_Left
2 AGND
3 AGND
4 Audio_Output_Right
Table 4-4: Audio Output Connector Pinouts
Table 4-4
See
Figure 4-3
See
Page 48
AFL M Series LCD Monitor
Figure 4-3: Audio Output Connector Location
4.2.2 Auto-Dimming Connector
CN Label: CN3
CN Type: 6-pin wafer connector
CN Pinouts:
CN Location:
Table 4-5
See
Figure 4-4
See
The auto-dimming connector connects to an external auto-dimming sensor.
PIN DESCRIPTION
1 +3.3V
2 NC
3 GND
4 SCL
5 NC
6 SDA
Table 4-5: Auto-dimming Connector Pinouts
Page 49
Figure 4-4: Auto-dimming Connector Location
4.2.3 Debug Port Connector
CN Label: CN12
AFL M Series LCD Monitor
CN Type: 3-pin wafer connector
CN Pinouts:
CN Location:
Use the debug port connector to update the AD board BIOS.
PIN DESCRIPTION
1 RX
2 TX
3 GND
Table 4-6: Debug Port Connector Pinouts
Table 4-6
See
Figure 4-5
See
Page 50
AFL M Series LCD Monitor
Figure 4-5: Debug Port Connector Location
4.2.4 OSD and LED Connector
CN Label: CN1
CN Type: 16-pin wafer connector
CN Pinouts:
CN Location:
Table 4-7
See
Figure 4-6
See
The OSD and LED connector connects to an external OSD controller.
PIN DESCRIPTION
1 MENU/ENTER
2 DOWN
3 LEFT
4 UP
5 RIGHT
6 LED_SENSOR
7 SWAP
8 PIP
9 SOURCE
10 LCD ON/OFF
11 VIN1
12 VIN2
Page 51
13 AUTO/EXIT
14 LED_RED
15 LED_GREEN
16 GND
AFL M Series LCD Monitor
Table 4-7: OSD and LED Connector Pinouts
Figure 4-6: OSD and LED Connector Location
4.2.5 LED Indicator and Remote Sensor Connector
CN Label: CN16
CN Type: 6-pin header
CN Pinouts:
CN Location:
This connector connects to the LED indicator and remote sensor.
Table 4-8
See
Figure 4-7
See
Page 52
AFL M Series LCD Monitor
PIN DESCRIPTION
1 IR VCC
2 RED
3 IR OUT
4 GREEN
5 GND
6 GND
Table 4-8: LED and Remote Sensor Connector Pinouts
Figure 4-7: LED and Remote Sensor Connector Location
4.2.6 Backlight Inverter Interface Connector
CN Label: CN9
CN Type: 6-pin wafer connector
CN Pinouts:
CN Location:
The Inverter connector connects to the LCD backlight. Using the BKLT_EN signal to
control the inverter status (ON/OFF) and the BKLT_ADJ signal to adjust brightness of
inverter by OSD brightness function. The OSD brightness function can control a PWM
input and variable DC voltage to minimize flickering (due to the interference between
panel timing and inverter’s AC timing), and adjust LCD back light brightness.
Table 4-9
See
Figure 4-8
See
Page 53
PIN DESCRIPTION
1 +12V
2 +12V
3 BKLT_EN
4 BKLT_ADJ
5 GND
6 GND
AFL M Series LCD Monitor
Table 4-9: Backlight Inverter Connector Pinouts
Figure 4-8: Backlight Inverter Connector Location
4.2.7 IR Sensor Connector
CN Label: CN10
CN Type: 4-pin wafer connector
CN Pinouts:
CN Location:
The IR sensor connector connects to the body IR sensor.
PIN DESCRIPTION
1 +5V
2 38KHz
Table 4-10
See
Figure 4-9
See
Page 54
3 IRDET
AFL M Series LCD Monitor
4 GND
Table 4-10: IR Sensor Connector Pinouts
Figure 4-9: IR Sensor Connector Location
4.2.8 LVDS Signal Output Connector (AFL-08MH/10M/12M only)
CN Label: CN7
CN Type: 30-pin connector
CN Pinouts:
CN Location:
Use the LVDS signal output connector to connect the LCD panel to a system.
PIN DESCRIPTION PIN DESCRIPTION
1 GND 2 GND
3 TXO3+ 4 TXO3-
5 TXOC+ 6 TXOC-
7 TXO2+ 8 TXO2-
9 TXO1+ 10 TXO1-
11 TXO0+ 12 TXO0-
Table 4-11
See
Figure 4-10
See
13 GND 14 GND
15 TXE3+ 16 TXE3-
17 TXEC+ 18 TXEC-
Page 55
19 TXE2+ 20 TXE2-
21 TXE1+ 22 TXE1-
23 TXE0+ 24 TXE0-
25 GND 26 GND
27 VDD 28 VDD
29 VDD 30 VDD
Table 4-11: LVDS Signal Output Connector Pinouts
AFL M Series LCD Monitor
Figure 4-10: LVDS Signal Output Connector Location
NOTE:
The supply voltage (3.3V (Default), 5V or 12V) can be selected via JP5.
4.2.9 Power Output Connector
CN Label: CN15
CN Type: 2-pin wafer connector
CN Pinouts:
CN Location:
See
See
Table 4-12
Figure 4-11
Page 56
The AV-9962 supports one 5V power output connector.
AFL M Series LCD Monitor
PIN DESCRIPTION
1 +5V
2 GND
Table 4-12: Power Output Connector Pinouts (CN15)
Figure 4-11: Power Output Connector Locations
4.2.10 Remote Control Connector
CN Label: CN4
CN Type: 3-pin wafer connector
CN Pinouts:
CN Location:
The remote control connector supports remote control function.
PIN DESCRIPTION
1 GND
2 VCC
3 Remote Out
Table 4-13
See
Figure 4-12
See
Table 4-13: Remote Control Connector Pinouts
Page 57
AFL M Series LCD Monitor
Figure 4-12: Remote Control Connector Location
4.2.11 TTL Signal Output Connector (AFL-07M Model Only)
CN Label: CN8
CN Type: 40-pin connector
CN Pinouts:
CN Location:
Table 4-14
See
Figure 4-13
See
Use the TTL signal output connector to connect the TTL LCD panel to a system.
PIN DESCRIPTION PIN DESCRIPTION
1 GND 2 GND
3 TTLDCLK 4 GND
5 GND 6 TTLR0
7 TTLR1 8 TTLR2
9 GND 10 TTLR3
11 TTLR4 12 TTLR5
13 GND 14 TTLG0
Page 58
15 TTLG1 16 TTLG2
17 GND 18 TTLG3
19 TTLG4 20 TTLG5
21 GND 22 TTLB0
AFL M Series LCD Monitor
23 TTLB1 24 TTLB2
25 GND 26 TTLB3
27 TTLB4 28 TTLB5
29 GND 30 GND
31 GND 32 TTLDEN
33 TTLHS 34 VDD
35 VDD 36 VDD
37 VDD 38 TTLVS
39 GND 40 GND
Table 4-14: TTL Signal Output Connector Pinouts
Figure 4-13: TTL Signal Output Connector Location
4.2.12 Touch Panel Connector
CN Label: J10
CN Type: 9-pin wafer connector
CN Pinouts:
CN Location:
Use the touch panel connector to connect the optional touch panel to the AFL series
industrial monitor.
Table 4-15
See
Figure 4-14
See
Page 59
PIN DESCRIPTION
1 X+
2 X3 Y+
4 SENSE
5 X+
6 X7 Y+
8 Y9 GND
AFL M Series LCD Monitor
Table 4-15: Touch Panel Connector Pinouts
Figure 4-14: Touch Panel Connector Location
Page 60
p
AFL M Series LCD Monitor
4.3 AV-9962 On-board Jumpers
NOTE:
A jumper is a metal bridge used to close an
electrical circuit. It consists of two or three metal
pins and a small metal clip (often protected by a
lastic cover) that slides over the pins to
connect them. To CLOSE/SHORT a jumper
means connecting the pins of the jumper with
the plastic clip and to OPEN a jumper means
removing the plastic clip from a jumper.
The AV-9962 has two on-board jumpers (Table 4-3).
Figure 4-15: Jumpers
Figure 4-16: AV-9962 Jumper Locations
Page 61
4.3.1 LCD Panel Voltage Select Jumper
Jumper Label: JP5
Jumper Type: 6-pin header
AFL M Series LCD Monitor
Jumper Location:
Jumper Settings:
Figure 4-16
See
Table 4-16
See
The JP5 jumper sets the voltage to the LCD panel.
JP5 Description
1-2 Panel Voltage select 3.3V (Default)
3-4 Panel Voltage select 5V
5-6 Panel Voltage select 12V
Table 4-16: LCD Panel Voltage Select Jumper Settings
4.3.2 Touch Screen Select Jumper
Jumper Label: JP6
Jumper Type: 2-pin header
Page 62
Jumper Location:
Jumper Settings:
Figure 4-16
See
Table 4-17
See
The JP4 jumper sets the touch screen type.
JP6 Description
Short 4-wire/8-wire touch screen (Default)
Open 5-wire touch screen
Table 4-17: LCD Panel Power Input Jumper Settings
AFL M Series LCD Monitor
4.4 AV-9962 External (Rear Panel) Connectors
Figure 4-17 shows the AV-9962 external (rear panel) connectors. The peripheral
connectors on the back panel of the monitor can connect to external devices. The
peripheral connectors on the rear panel are:
1 x Audio jack
1 x Component video connector
1 x Composite video connector
1 x Power input connector
1 x RS-232 connector
1 x S-Video connector
1 x USB connector
1 x VGA connector
Figure 4-17: AV-9962 External (Rear Panel) Connectors
4.4.1 Audio Jack
CN Label: J3
CN Type: Audio jack
CN Pinouts:
CN Location:
Use the audio jack to connect audio input to the monitor.
PIN DESCRIPTION
1 AGND
2 Audio_Iutput_Left
Table 4-18
See
Figure 4-17
See
3 AGND
Page 63
4 AGND
5 Audio_Iutput_Right
Table 4-18: Audio Jack Pinouts
4.4.2 Component Video Connector
CN Label: J2
CN Type: mini-DIN 7 component video connector
AFL M Series LCD Monitor
CN Pinouts:
CN Location:
Table 4-19
See
Figure 4-17 and Figure 4-18
See
Use the mini-DIN 7 component video connector to connect to the system graphics
interface.
PIN DESCRIPTION PIN DESCRIPTION
1 VGND 5 VGND
2 Pb 6 Pr
3 VGND 7 VGND
4 Y
Table 4-19: Component Video Connector Pinouts
Page 64
Figure 4-18: Component Video Connector Pinout Locations
AFL M Series LCD Monitor
4.4.3 Composite Video Connector
CN Label: J6, J7
CN Type: Composite video connector
CN Pinouts:
CN Location:
Table 4-20 and Table 4-21
See
Figure 4-17
See
Use the composite video connector to connect to the system graphics interface.
PIN DESCRIPTION
1 VGND
2 CVBS-IN
Table 4-20: Composite Signal Input BNC Connector (J7) Pinouts
PIN DESCRIPTION
1 CVBS-IN
2 VGND
3 VGND
4 VGND
Table 4-21: Composite Signal Input Connector (J6) Pinouts
4.4.4 DC 12V Connector
CN Label: J4
CN Type: DC 12V Jack
CN Pinouts:
CN Location:
Use the DC 12V connector to power the monitor.
Table 4-22
See
Figure 4-17
See
Page 65
PIN DESCRIPTION
1 GND
2 GND
3 +12V
Table 4-22: DC 12V Connector Pinouts
4.4.5 RS-232 Touch Panel Connector
CN Label: J9
CN Type: DB-9 female connector
AFL M Series LCD Monitor
CN Pinouts:
CN Location:
Table 4-23
See
Figure 4-17
See
Use the rear panel standard RS-232 DB-9 female touch panel connector to connect the
monitor to the system graphics interface.
PIN DESCRIPTION PIN DESCRIPTION
1 NRLSD 7 NRTS
2 NRX 8 NCTS
3 NTX 9 NRI
4 NDTR 10 GND
5 GND 11 GND
6 NDSR
Table 4-23: RS-232 Touch Panel Connector Pinouts
4.4.6 S-Video Connector
Page 66
CN Label: J5
CN Type: mini-DIN 4 S-Video connector
CN Pinouts:
CN Location:
Table 4-24
See
Figure 4-17 and Figure 4-19
See
AFL M Series LCD Monitor
Use the mini-DIN 4 S-Video connector to connect to the system graphics interface.
PIN DESCRIPTION
1 VGND
2 VGND
3 Y-IN
4 C-IN
Table 4-24: S-Video Connector Pinouts
Figure 4-19: S-Video Connector Pinout Locations
4.4.7 USB Touch Panel Connector
CN Label: J8
CN Type: USB port
CN Pinouts:
CN Location:
Use the rear panel standard USB touch panel connector to connect the monitor to the
system graphics interface.
Table 4-25
See
Figure 4-17 and Figure 4-20
See
Page 67
PIN DESCRIPTION
1 VSB_VCC
2 USB3 USB+
4 GND
Table 4-25: USB Touch Panel Connector Pinouts
Figure 4-20: USB Touch Panel Connector
4.4.8 VGA Connector
AFL M Series LCD Monitor
CN Label: J1
CN Type: D-sub 15 female connector
CN Pinouts:
CN Location:
Table 4-26
See
Figure 4-17 and Figure 4-21
See
Use the standard D-sub 15-pin VGA connector to connect the monitor to a system.
PIN DESCRIPTION PIN DESCRIPTION
1 Red 9 No Connect
2 Green 10 Ground
3 Blue 11 No Connect
4 No Connect 12 DDC DAT
5 Ground 13 Horizontal Synchronization
6 Ground 14 Vertical Synchronization
7 Ground 15 DDC Clock
Page 68
8 Ground
Table 4-26: VGA Connector Pinouts
AFL M Series LCD Monitor
Figure 4-21: VGA Connector Pinout Locations
4.5 AV-6962 AD Board Overview
The AFL-15M, AFL-17M and AFL-19M industrial monitors are preinstalled with AV-6962
AD board to provide a wide variety of control interfaces. The following sections describe
the AV-6962 AD board in detail.
Page 69
AFL M Series LCD Monitor
Page 70
Figure 4-22: AV-6962 AD Board Overview
AFL M Series LCD Monitor
4.5.1 AV-6962 AD Board Connectors
The AV-6962 AD board has the following connectors on-board:
1 x Audio output connector
1 x Auto-dimming connector
1 x Debug port
1 x Inverter interface connector
1 x IR sensor connector
1 x LVDS signal output connector
1 x OSD and LED connector
1 x Power input connector
1 x Power output connector
1 x Remote control connector
1 x RS-232 Serial Port connector
1 x USB connector
The AV-6962 AD board has the following connectors on the board rear panel:
1 x Audio jack
1 x Component video connector
1 x Composite video connector
1 x Digital input connector
1 x Power input connector
1 x RS-232 connector
1 x S-Video connector
1 x USB connector
1 x VGA connector
The locations of the peripheral interface connectors for the AV-6962 AD board are shown
in Section
Section
4.5.2. A complete list of all the peripheral interface connectors can be seen in
4.5.3.
Page 71
4.5.2 AV-6962 AD Board Layout
Figure 4-23 shows the on-board peripheral connectors and on-board jumpers.
AFL M Series LCD Monitor
Figure 4-23: AV-6962 Connector and Jumper Locations
Page 72
AFL M Series LCD Monitor
4.5.3 AV-6962 Peripheral Interface Connectors
Table 4-27 shows a list of the peripheral interface connectors on the AV-6962 AD board.
Detailed descriptions of these connectors can be found in Section
Connector Type Label
Audio output connector 4-pin wafer connector CN11
Auto-dimming connector 6-pin wafer connector CN3
Debug port 3-pin wafer connector CN17
Inverter interface connector 6-pin wafer connector CN10
IR sensor connector 4-pin wafer connector CN9
LVDS signal output connector 30-pin connector CN7
OSD and LED connector 16-pin wafer connector CN1
Power input connector 2-pin wafer connector CN14
Power output connector 2-pin wafer connector CN15
4.6.
Remote control connector 3-pin wafer connector CN6
Serial port connector (RS-232) 10-pin box header COM1
USB connector 4-pin wafer connector USB1
Table 4-27: AV-6962 Peripheral Interface Connectors
4.5.4 AV-6962 Rear Panel Connectors
Table 4-28 lists the rear panel connectors on the AV-6962 AD board. Detailed
descriptions of these connectors can be found in Section
Connector Type Label
Audio jack Audio jack J7
Component video signal input jack mini-DIN 7 component J2
4.8.
Page 73
connector
Composite signal input BNC jack Composite BNC connector J9, J10
Digital input connector DVI-D connector J3
Power input connector DC 12V Jack J4
RS-232 connector DB-9 female connector J5
S-Video signal input jack mini-DIN 4 S-Video connector J8
USB connector USB port J6
VGA connector D-sub 15-pin female connector J1
Table 4-28: AV-6962 Rear Panel Connectors
AFL M Series LCD Monitor
4.5.5 AV-6962 On-board Jumpers
Table 4-29 lists the on-board jumper. A detailed description of the jumper can be found in
Section
Jumper Type Label
LCD Panel Voltage Select 6-pin header JP5
Table 4-29: AV-6962 On-board Jumpers
4.7.
Page 74
AFL M Series LCD Monitor
4.6 AV-6962 Internal Peripheral Connectors
Internal peripheral connectors on the AV-6962 AD board are only accessible when the
board is outside of the monitor. This section has complete descriptions of all the internal,
peripheral connectors on the AV-6962 AD board.
4.6.1 Audio Output Connector
CN Label: CN11
CN Type: 4-pin wafer connector
CN Pinouts:
CN Location:
The audio output connector connects to two preinstalled speakers.
PIN DESCRIPTION
1 Audio_Output_Left
2 AGND
3 AGND
4 Audio_Output_Right
Table 4-30: Audio Output Connector Pinouts
Table 4-30
See
Figure 4-24
See
Figure 4-24: Audio Output Connector Location
Page 75
4.6.2 Auto-Dimming Connector
CN Label: CN3
CN Type: 6-pin wafer connector
AFL M Series LCD Monitor
CN Pinouts:
CN Location:
The auto-dimming connector connects to an external auto-dimming sensor.
PIN DESCRIPTION
1 +3.3V
2 NC
3 GND
4 SCL
5 NC
6 SDA
Table 4-31: Auto-dimming Connector Pinouts
Table 4-31
See
Figure 4-25
See
Figure 4-25: Auto-dimming Connector Location
4.6.3 Debug Port Connector
CN Label: CN17
CN Type: 3-pin wafer connector
Page 76
AFL M Series LCD Monitor
CN Pinouts:
CN Location:
Table 4-32
See
Figure 4-26
See
Use the debug port connector to update the AD board BIOS.
PIN DESCRIPTION
1 RX
2 TX
3 GND
Table 4-32: Debug Port Connector Pinouts
Figure 4-26: Debug Port Connector Location
4.6.4 Backlight Inverter Interface Connector
CN Label: CN10
CN Type: 6-pin wafer connector
CN Pinouts:
CN Location:
Table 4-33
See
Figure 4-27
See
The Inverter connector connects to the LCD backlight. Using the BKLT_EN signal to
control the inverter status (ON/OFF) and the BKLT_ADJ signal to adjust brightness of
inverter by OSD brightness function. The OSD brightness function can control a PWM
Page 77
AFL M Series LCD Monitor
input and variable DC voltage to minimize flickering (due to the interference between
panel timing and inverter’s AC timing), and adjust LCD back light brightness.
PIN DESCRIPTION
1 +12V
2 +12V
3 BKLT_EN
4 BKLT_ADJ
5 GND
6 GND
Table 4-33: Backlight Inverter Connector Pinouts
Figure 4-27: Backlight Inverter Connector Location
4.6.5 IR Sensor Connector
CN Label: CN9
CN Type: 4-pin wafer connector
CN Pinouts:
CN Location:
The IR sensor connector connects to the body IR sensor.
PIN DESCRIPTION
1 +5V
2 38KHz
Table 4-34
See
Figure 4-28
See
Page 78
AFL M Series LCD Monitor
3 IRDET
4 GND
Table 4-34: IR Sensor Connector Pinouts
Figure 4-28: IR Sensor Connector Location
4.6.6 LVDS Signal Output Connector
CN Label: CN7
CN Type: 30-pin connector
CN Pinouts:
CN Location:
Use the LVDS signal output connector to connect the LCD panel to a system.
PIN DESCRIPTION PIN DESCRIPTION
1 GND 2 GND
3 TXO3+ 4 TXO3-
5 TXOC+ 6 TXOC-
Table 4-35
See
Figure 4-29
See
7 TXO2+ 8 TXO2-
9 TXO1+ 10 TXO1-
11 TXO0+ 12 TXO0-
Page 79
13 GND 14 GND
15 TXE3+ 16 TXE3-
17 TXEC+ 18 TXEC-
19 TXE2+ 20 TXE2-
21 TXE1+ 22 TXE1-
23 TXE0+ 24 TXE0-
25 GND 26 GND
27 VDD 28 VDD
29 VDD 30 VDD
AFL M Series LCD Monitor
Table 4-35: LVDS Signal Output Connector Pinouts
Figure 4-29: LVDS Signal Output Connector Location
NOTE:
The supply voltage (3.3V (Default), 5V or 12V) can be selected via JP5.
4.6.7 OSD and LED Connector
CN Label: CN1
CN Type: 16-pin wafer connector
Page 80
CN Pinouts:
See
Table 4-36
