AC-KIT-888HD Audio Module

IEI Technology Corp.

MODEL:

AC-KIT-888HD

7.1 Channel High Definition Audio Module

User Manual

Rev. 1.00 – 15 June, 2011

Page i

AC-KIT-888HD Audio Module

Date Version Changes

Revision

15 June, 2011

1.00 Initial release

Page ii

AC-KIT-888HD Audio Module

Copyright

COPYRIGHT NOTICE

The information in this document is subject to change without prior notice in order to

improve reliability, design and function and does not represent a commitment on the part

of the manufacturer.

In no event will the manufacturer be liable for direct, indirect, special, incidental, or

consequential damages arising out of the use or inability to use the product or

documentation, even if advised of the possibility of such damages.

This document contains proprietary information protected by copyright. All rights are

reserved. No part of this manual may be reproduced by any mechanical, electronic, or

other means in any form without prior written permission of the manufacturer.

TRADEMARKS

All registered trademarks and product names mentioned herein are used for identification

purposes only and may be trademarks and/or registered trademarks of their respective

owners.

Page iii

AC-KIT-888HD Audio Module

Table of Contents

1 INTRODUCTION.......................................................................................................... 1

1.1 INTRODUCTION........................................................................................................... 2

1.2 F

EATURES................................................................................................................... 3

1.3 C

ONNECTORS ............................................................................................................. 3

1.4 DIMENSIONS............................................................................................................... 4

1.5 TECHNICAL SPECIFICATIONS ...................................................................................... 5

2 PACKING LIST............................................................................................................. 6

2.1 A

NTI-STATIC PRECAUTIONS........................................................................................ 7

2.2 UNPACKING PRECAUTIONS......................................................................................... 7

2.3 PACKING LIST............................................................................................................. 8

3 CONNECTORS ............................................................................................................. 9

3.1 P

ERIPHERAL INTERFACE CONNECTORS..................................................................... 10

3.1.1 AC-KIT-888HD Layout .................................................................................... 10

3.1.2 Peripheral Interface Connectors ..................................................................... 10

3.1.3 Audio Connector ...............................................................................................11

3.1.4 CD In Connector.............................................................................................. 12

3.1.5 Front Panel Connector .................................................................................... 13

3.2 E

XTERNAL PERIPHERAL INTERFACE CONNECTORS................................................... 14

4 INSTALLATION ......................................................................................................... 15

4.1 A

NTI-STATIC PRECAUTIONS...................................................................................... 16

4.2 INSTALLATION CONSIDERATIONS.............................................................................. 16

4.3 J

UMPER SETTINGS .................................................................................................... 18

4.3.1 AVDD Power-on Select Jumper....................................................................... 19

4.3.2 DVDD Power-on Select Jumper ...................................................................... 20

4.4 CHASSIS INSTALLATION............................................................................................ 20

4.5 R

EALTEK HD AUDIO DRIVER (ALC888) INSTALLATION ......................................... 23

5 7.1 SURROUND SOUND CONFIGURATION ........................................................ 24

5.1 I

NTRODUCTION......................................................................................................... 25

Page iv

AC-KIT-888HD Audio Module

RIVER INSTALLATION ............................................................................................. 25

5.2 D

5.3 7.1 S

URROUND SOUND CONFIGURATION.................................................................. 25

5.3.1 Accessing the Sound Effects Manager ............................................................. 25

5.3.2 7.1 Surround Sound Setup................................................................................ 27

5.3.3 Connect Devices to the Audio Module............................................................. 28

5.3.4 Testing Speaker Configuration......................................................................... 33

A HAZARDOUS MATERIALS DISCLOSURE ......................................................... 34

A.1 H

AZARDOUS MAT E R IA L S DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS

ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY ....................................... 35

Page v

AC-KIT-888HD Audio Module

List of Figures

Figure 1-1: AC-KIT-888HD..............................................................................................................2

Figure 1-2: Connectors ..................................................................................................................3

Figure 1-3: AC-KIT-888HD Dimensions (mm) ..............................................................................4

Figure 3-1: Connectors and Jumpers.........................................................................................10

Figure 3-2: Audio Connector Location.......................................................................................11

Figure 3-3: CD In Connector Location........................................................................................12

Figure 3-4: Front Panel Connector Location .............................................................................13

Figure 4-1: AVDD Power-on Select Jumper Location...............................................................19

Figure 4-2: DVDD Power-on Select Jumper Location...............................................................20

Figure 4-3: Connect Audio Module to Motherboard .................................................................21

Figure 4-4: Connect Audio Module to CD ..................................................................................22

Figure 5-1: Sound Effect Manager Icon [Task Bar] ...................................................................25

Figure 5-2: Sound Effects Manager (ALC888) ...........................................................................26

Figure 5-3: 8 Channel Speaker Option .......................................................................................27

Figure 5-4: 7.1 Surround Sound Speaker Layout......................................................................28

Figure 5-5: Connected Device Screen........................................................................................29

Figure 5-6: Front Speakers as Front Speaker Out ....................................................................30

Figure 5-7: Side Speakers as Side Speaker Out........................................................................31

Figure 5-8: Rear Speakers as Rear Speaker Out.......................................................................32

Figure 5-9: Center/Subwoofer Speakers as Center/Subwoofer Speaker Out ........................33

Page vi

AC-KIT-888HD Audio Module

List of Tables

Table 1-1: AC-KIT-888HD Specifications......................................................................................5

Table 2-1: Packing List...................................................................................................................8

Table 3-1: Peripheral Interface Connectors ...............................................................................10

Table 3-2: Audio Connector Pinouts ..........................................................................................11

Table 3-3: CD In Connector Pinouts ...........................................................................................12

Table 3-4: Front Panel Connector Pinouts.................................................................................14

Table 3-5: External Peripheral Interface Connectors................................................................14

Table 4-1: Jumpers.......................................................................................................................18

Table 4-2: AVDD Power-on Select Jumper Settings .................................................................19

Table 4-3: DVDD Power-on Select Jumper Settings .................................................................20

Page vii

AC-KIT-888HD Audio Module

Chapter

1

1 Introduction

Page 1

1.1 Introduction

Figure 1-1: AC-KIT-888HD

AC-KIT-888HD Audio Module

The AC-KIT-888HD audio module is an audio interface card equipped with 7.1 surround

sound capability. The AC-KIT-888HD audio module features a performance Realtek

ALC888 audio codec chip, five input/output audio jacks, direct CD in header connection

and optional I/O KIT multi-streaming pin header connection. With IEI’s leading-edge

technology and professionalism in industrial computing, the AC-KIT-888HD audio module

is designed with high stability and state-of-the-art functionality to fulfill your needs.

Page 2

AC-KIT-888HD Audio Module

1.2 Features

Some of the AC-KIT-888HD audio module features are listed below:

 Realtek ALC888 HD Audio Codec IC Supported

 Five audio jacks for microphone, 7.1+2 Channel High Definition Audio input

and output

 High-performance 7.1+2 Channel High Definition Audio board are providing

7.1 sound playback and multiple streaming through the front panel stereo

outputs

 Digital to Analog Converter (DAC) with 97dB signal to noise ratio (SNR)

 Analog to Digital Converter (ADC) with 90dB signal to noise ratio (SNR)

 All DACs support 44.1k/48k/96k/192kHz sample rate

 All ADCs support 44.1k/48k/96kHz sample rate

 Driver supports Windows 2000/2003/XP/VISTA/7 (32/64 bits),

Linux (Ubuntu or Debiant)

1.3 Connectors

The connectors on the AC-KIT-888HD are shown in the figure below.

Figure 1-2: Connectors

Page 3

1.4 Dimensions

The main dimensions of the AC-KIT-888HD are shown in the diagram below.

AC-KIT-888HD Audio Module

Figure 1-3: AC-KIT-888HD Dimensions (mm)

Page 4

AC-KIT-888HD Audio Module

1.5 Technical Specifications

AC-KIT-888HD technical specifications are listed below.

Specification/Model AC-KIT-888HD

Audio Codec IC

Audio Input

Sampling Rate

7.1 Surround Sound

Two Multi-streaming Channels

Device Driver

Table 1-1: AC-KIT-888HD Specifications

Realtek ALC888

Five Audio jacks

CD pin header connector on-board

DACs support 44.1k/48k/96k/192kHz

ADCs support 44.1k/48k/96kHz

16/20/24-bit S/PDIF-OUT supports 44.1k/48k/96k/192kHz

16/20/24-bit S/PDIF-IN supports 44.1k/48k/96kHz

Yes

Yes (with optional IO-KIT-MULTI-ST card)

Audio driver for Windows 2000/XP/Vista/7

Page 5

AC-KIT-888HD Audio Module

Chapter

2

2 Packing List

Page 6

AC-KIT-888HD Audio Module

2.1 Anti-static Precautions

WARNING!

Static electricity can destroy certain electronics. Make sure to follow the

ESD precautions to prevent damage to the product, and injury to the

user.

Make sure to adhere to the following guidelines:

 Wear an anti-static wristband: Wearing an anti-static wristband can prevent

electrostatic discharge.

 Self-grounding: Touch a grounded conductor every few minutes to discharge

any excess static buildup.

 Use an anti-static pad: When configuring any circuit board, place it on an

anti-static mat.

 Only handle the edges of the PCB: Don't touch the surface of the

motherboard. Hold the motherboard by the edges when handling.

2.2 Unpacking Precautions

When the AC-KIT-888HD is unpacked, please do the following:

 Follow the antistatic guidelines above.

 Make sure the packing box is facing upwards when opening.

 Make sure all the packing list items are present.

Page 7

2.3 Packing List

NOTE:

If any of the components listed in the checklist below are missing, do

not proceed with the installation. Contact the IEI reseller or vendor the

AC-KIT-888HD was purchased from or contact an IEI sales

representative directly by sending an email to [e-mail].

The AC-KIT-888HD is shipped with the following components:

Quantity Item and Part Number Image

1 AC-KIT-888HD audio module c/w slot bracket

AC-KIT-888HD Audio Module

1 Audio cable

(P/N: 32100-121100-RS)

1 Utility CD

1 Quick Installation Guide

Table 2-1: Packing List

Page 8

AC-KIT-888HD Audio Module

Chapter

3

3 Connectors

Page 9

3.1 Peripheral Interface Connectors

This chapter details all the jumpers and connectors.

3.1.1 AC-KIT-888HD Layout

The figures below show all the connectors and jumpers.

AC-KIT-888HD Audio Module

Figure 3-1: Connectors and Jumpers

3.1.2 Peripheral Interface Connectors

The table below lists all the connectors on the board.

Connector Type Label

Audio connector 10-pin box header HDA-1

CD In connector 4-pin header CDIN1

Front panel connector 10-pin header FRONT-PANEL

Table 3-1: Peripheral Interface Connectors

Page 10

AC-KIT-888HD Audio Module

3.1.3 Audio Connector

CN Label: HDA-1

CN Type:

CN Location:

CN Pinouts:

10-pin box header (2x5)

Figure 3-2

See

See Table 3-2

Use the audio connector to connect the module to a motherboard audio connector.

Figure 3-2: Audio Connector Location

PIN DESCRIPTION PIN DESCRIPTION

1 HDA_SYNC 2 HDA_BITCLK

3 HDA_SDOUT 4 HDA_PCBEEP

5 HDA_SDIN 6 HDA_RST#

7 HDA_VCC 8 HDA_GND

9 HDA_+12V 10 HDA_GND

Table 3-2: Audio Connector Pinouts

Page 11

3.1.4 CD In Connector

CN Label: CDIN1

AC-KIT-888HD Audio Module

CN Type:

CN Location:

CN Pinouts:

4-pin header (1x4)

Figure 3-3

See

See Table 3-3

Use the CD in connector to connect the module to a CD player.

Figure 3-3: CD In Connector Location

PIN DESCRIPTION

1 CD IN LEFT

2 CD-GND

3 CD-GND

4 CD IN RIGHT

Table 3-3: CD In Connector Pinouts

Page 12

AC-KIT-888HD Audio Module

3.1.5 Front Panel Connector

CN Label: FRONT-PANEL

CN Type:

CN Location:

CN Pinouts:

10-pin header (2x5)

Figure 3-4

See

See Table 3-4

NOTE:

Do not connect the front panel connector to the any motherboard or

chassis connectors.

The front panel connector is used to connect the module to IEI’s optional

IO-KIT-MULTI-ST audio module to enable multi-streaming audio.

Figure 3-4: Front Panel Connector Location

Page 13

AC-KIT-888HD Audio Module

PIN DESCRIPTION PIN DESCRIPTION

1 MIC2_LEFT 2 GND

3 MIC2_RIGHT 4 Presence

5 LINE 2_RIGHT 6 MIC2-JD

7 Sense 8 Key

9 LINE2_LEFT 10 LINE2-JD

Table 3-4: Front Panel Connector Pinouts

3.2 External Peripheral Interface Connectors

The table below lists the external peripheral interface connectors on the AC-KIT-888HD

audio module and their functions.

Connector Type Label Functions

Orange

Black

Pink

Blue

Audio jack C-SUB

Center/Subwoofer Out (Default), Line-in,

Front-out, Rear-out and Side-out

Rear-out (Default), Mic-in, Line-in,

Audio jack REAR

Center/Subwoofer Out, Front-out and Side-out

Mic-in (Default), Line-in and Front-out,

Audio jack MIC

Center/Subwoofer Out, Side-out and Rear-out

Line-in (Default), Mic-in, Front-out,

Audio jack IN

Center/Subwoofer Out, Side-out and Rear-out

Front-out (Default), Line-in, Rear-out,

Audio jack OUT

Center/Subwoofer Out and Side-out

Green

Table 3-5: External Peripheral Interface Connectors

Page 14

AC-KIT-888HD Audio Module

Chapter

4

4 Installation

Page 15

4.1 Anti-static Precautions

WARNING:

Failure to take ESD precautions during the installation of the

AC-KIT-888HD may result in permanent damage to the AC-KIT-888HD

and severe injury to the user.

Electrostatic discharge (ESD) can cause serious damage to electronic components,

including the AC-KIT-888HD. Dry climates are especially susceptible to ESD. It is

therefore critical that whenever the AC-KIT-888HD or any other electrical component is

handled, the following anti-static precautions are strictly adhered to.

 Wear an anti-static wristband: - Wearing a simple anti-static wristband can

AC-KIT-888HD Audio Module

help to prevent ESD from damaging the board.

 Self-grounding:- Before handling the board touch any grounded conducting

material. During the time the board is handled, frequently touch any

conducting materials that are connected to the ground.

 Use an anti-static pad: When configuring the AC-KIT-888HD, place it on an

antic-static pad. This reduces the possibility of ESD damaging the

AC-KIT-888HD.

 Only handle the edges of the PCB:-: When handling the PCB, hold the PCB

by the edges.

4.2 Installation Considerations

NOTE:

The following installation notices and installation considerations should

be read and understood before installation. All installation notices must

be strictly adhered to. Failing to adhere to these precautions may lead

to severe damage and injury to the person performing the installation.

Page 16

AC-KIT-888HD Audio Module

WARNING:

The installation instructions described in this manual should be

carefully followed in order to prevent damage to the components and

injury to the user.

Before and during the installation please DO the following:

 Read the user manual:

o The user manual provides a complete description of the AC-KIT-888HD

installation instructions and configuration options.

 Wear an electrostatic discharge cuff (ESD):

o Electronic components are easily damaged by ESD. Wearing an ESD cuff

removes ESD from the body and helps prevent ESD damage.

 Place the AC-KIT-888HD on an antistatic pad:

o When installing or configuring the motherboard, place it on an antistatic

pad. This helps to prevent potential ESD damage.

 Turn all power to the AC-KIT-888HD off:

o When working with the AC-KIT-888HD, make sure that it is disconnected

from all power supplies and that no electricity is being fed into the system.

Before and during the installation of the AC-KIT-888HD DO NOT:

 Remove any of the stickers on the PCB board. These stickers are required for

warranty validation.

 Use the product before verifying all the cables and power connectors are

properly connected.

 Allow screws to come in contact with the PCB circuit, connector pins, or its

components.

Page 17

4.3 Jumper Settings

NOTE:

A jumper is a metal bridge used to close

an electrical circuit. It consists of two or

three metal pins and a small metal clip

(often protected by a plastic cover) that

slides over the pins to connect them. To

CLOSE/SHORT a jumper means

connecting the pins of the jumper with

the plastic clip and to OPEN a jumper means removing the plastic clip

from a jumper.

AC-KIT-888HD Audio Module

The hardware jumpers must be set before installation. Jumpers are shown in Table 4-1.

Description Label Type

AVDD power-on select J1 3-pin header

DVDD power-on select J2 3-pin header

Table 4-1: Jumpers

Page 18

AC-KIT-888HD Audio Module

4.3.1 AVDD Power-on Select Jumper

Jumper Label: J1

Jumper Type:

Jumper Settings:

Jumper Location:

3-pin header

See Table 4-2

See Figure 4-1

This jumper allows the user to set the AVDD power for the audio module.

Setting Description

Short 1-2 Select AVDD power by +5V

Short 2-3 (Default) Select AVDD power by +12V to +5V

Table 4-2: AVDD Power-on Select Jumper Settings

Figure 4-1: AVDD Power-on Select Jumper Location

Page 19

4.3.2 DVDD Power-on Select Jumper

Jumper Label: J2

AC-KIT-888HD Audio Module

Jumper Type:

Jumper Settings:

Jumper Location:

This jumper allows the user to set the DVDD power for the audio module.

Setting Description

Short 1-2 Select DVDD power by +1.5V

Short 2-3 (Default) Select DVDD power by +3V

Table 4-3: DVDD Power-on Select Jumper Settings

3-pin header

See Table 4-3

See Figure 4-2

Figure 4-2: DVDD Power-on Select Jumper Location

4.4 Chassis Installation

Follow the steps below to install the AC-KIT-888HD audio module into a chassis.

Step 1: Turn off and disconnect the system from all power sources.

Step 2: Open the chassis to expose the rear panel slots.

Step 3: Remove the slot cover bracket from an unused slot on the chassis rear panel by

removing its retention screw.

Page 20

AC-KIT-888HD Audio Module

Step 4: Insert the AC-KIT-888HD audio module into the unused slot.

Step 5: Secure the AC-KIT-888HD audio module to the chassis with the previously

removed retention screw.

Step 6: Find the audio cable that came with the AC-KIT-888HD audio module.

Step 7: Connect one end of the audio cable to the HDA-1 box header connector on the

AC-KIT-888HD audio module.

Step 8: Connect the other end of the audio cable to the ten-pin audio connector on the

system motherboard (see

Figure 4-3).

Figure 4-3: Connect Audio Module to Motherboard

Page 21

AC-KIT-888HD Audio Module

Step 9: If applicable, connect the system CD drive to the CDIN1 4-pin header on the

AC-KIT-888HD audio module (see Figure 4-4).

Figure 4-4: Connect Audio Module to CD

Step 10: Close the chassis, reconnect the power and turn on the system.

Page 22

AC-KIT-888HD Audio Module

4.5 RealTek HD Audio Driver (ALC888) Installation

To install the Realtek High Definition (HD) Audio driver, please follow the steps below.

Step 1: Open Windows Control Panel.

Step 2: Double click the System icon.

Step 3: Double click the Device Manager tab.

Step 4: Double click the listed device that has question marks next to it. (This means

Windows does not recognize the device).

Step 5: The Device Driver Wizard appears. Click Next to continue.

Step 6: Select “Specify a Location” in the Locate Driver Files window. Click N

continue.

Step 7: Select “X:\4-AUDIO\AC-KIT888HD\WIN” directory in the location browsing

window, where “X:\” is the system CD drive.

Step 8: Click OK to continue. The driver is installed.

Step 9: A confirmation screen offers the option of restarting the computer now or later.

For the settings to take effect, the computer must be restarted. Click FINISH to

restart the computer.

EXT to

Page 23

AC-KIT-888HD Audio Module

Chapter

5

5 7.1 Surround Sound

Configuration

Page 24

AC-KIT-888HD Audio Module

5.1 Introduction

The AC-KIT-888HD audio module utilizes a Realtek ALC888 high definition audio chip and

driver to achieve full 7.1 surround sound functionality.

5.2 Driver Installation

The following configuration assumes a Realtek ALC888 high definition audio driver has

already been installed on the system. If a Realtek ALC888 high definition audio driver has

not been installed on the system, please refer to Section 4.5.

5.3 7.1 Surround Sound Configuration

5.3.1 Accessing the Sound Effects Manager

Follow the steps below to access the Realtek ALC888 Sound Effects Manager.

Step 1: Click either:

 The Sound Effect Manager icon in the Notification Area of the system task bar

(Figure 5-1), or

 The Sound Effect Manager icon in the Control Panel.

Figure 5-1: Sound Effect Manager Icon [Task Bar]

Page 25

AC-KIT-888HD Audio Module

Step 2: The sound effect manager appears (Figure 5-2).

Figure 5-2: Sound Effects Manager (ALC888)

Page 26

AC-KIT-888HD Audio Module

5.3.2 7.1 Surround Sound Setup

Follow the steps below to set up the Sound Effects Manager for 7.1 surround sound.

Step 1: Click the Audio I/O tab.

Step 2: From the dropdown list box, select 8CH Speaker (

Figure 5-3).

Figure 5-3: 8 Channel Speaker Option

Page 27

AC-KIT-888HD Audio Module

Step 3: The following screen appears (Figure 5-4) showing the 7.1 surround sound

speaker layout.

Figure 5-4: 7.1 Surround Sound Speaker Layout

5.3.3 Connect Devices to the Audio Module

The AC-KIT-888HD audio module has the ability to auto-detect devices plugged into the

jacks. Also, each jack supports multiple kinds of input and output devices. Therefore, it is

not always critical to note which kind of device should be plugged into any given jack.

NOTE:

Green and orange colored jacks do not support microphone functionality.

Page 28

AC-KIT-888HD Audio Module

This section describes only one of many possible device configuration options to simulate

the surround sound functionality of the audio module. Follow the steps below to connect

devices to the audio module for surround sound.

Step 1: Connect the front speakers of a 7.1 surround sound system to the green audio

jack of the AC-KIT-888HD audio module.

Step 2: The following screen appears (Figure 5-5) requesting identification of what was

plugged into the jack.

Figure 5-5: Connected Device Screen

Step 3: Select Front Speaker Out as the device type and click OK.

Page 29

AC-KIT-888HD Audio Module

Step 4: The following screen appears (Figure 5-6). In the Analog Back Panel section,

there are left and right speaker icons with a green arrow pointing to the green

jack icon. This indicates that speakers have been plugged into the green jack.

Figure 5-6: Front Speakers as Front Speaker Out

NOTE:

The jack icons in the Front Panel section of Figure 5-6 are identified with

other jacks when using multi-streaming audio channels.

Step 5: Connect the side speakers of a 7.1 surround sound system to the blue audio

jack of the AC-KIT-888HD audio module and select Side Speaker Out (see

Figure 5-5) as the device type and click OK

.

Page 30

AC-KIT-888HD Audio Module

Step 6: The following screen appears (Figure 5-7). In the Analog Back Panel section,

there are left and right speaker icons with a blue arrow pointing to the blue jack

icon. This indicates that speakers have been plugged into the blue jack.

Figure 5-7: Side Speakers as Side Speaker Out

Step 7: Connect the rear speakers of a 7.1 surround sound system to the black audio

jack of the AC-KIT-888HD audio module and select Rear Speaker Out (see

Figure 5-5) as the device type and click OK

.

Page 31

AC-KIT-888HD Audio Module

Step 8: The following screen appears (Figure 5-8). In the Analog Back Panel section,

there are left and right speaker icons with a black arrow pointing to the black jack

icon. This indicates that speakers have been plugged into the black jack.

Figure 5-8: Rear Speakers as Rear Speaker Out

Step 9: Connect the center speakers of a 7.1 surround sound system to the orange

audio jack of the AC-KIT-888HD audio module and select Center/Subwoofer

Speaker Out (see Figure 5-5) as the device type and click OK

Page 32

.

AC-KIT-888HD Audio Module

Step 10: The following screen appears (Figure 5-9). In the Analog Back Panel section,

there are center/subwoofer speaker icons with an orange arrow pointing to the

orange jack icon. This indicates that speakers have been plugged into the

orange jack.

Figure 5-9: Center/Subwoofer Speakers as Center/Subwoofer Speaker Out

5.3.4 Testing Speaker Configuration

Follow the steps below to test that the speakers have been connected to the audio module

and configured correctly.

Step 1: Click any speaker icon in the picture on the left of the Audio I/O tab. The driver

generates a sound through the corresponding speaker connected to the audio

module.

Step 2: Check the jack plug connections and speaker configurations if the speaker icon

does not match the actual speaker.

Page 33

AC-KIT-888HD Audio Module

Appendix

A

A Hazardous Materials

Disclosure

Page 34

AC-KIT-888HD Audio Module

A.1 Hazardous Materials Disclosure Table for IPB Products

Certified as RoHS Compliant Under 2002/95/EC Without
Mercury

The details provided in this appendix are to ensure that the product is compliant with the

Peoples Republic of China (China) RoHS standards. The table below acknowledges the

presences of small quantities of certain materials in the product, and is applicable to China

RoHS only.

A label will be placed on each product to indicate the estimated “Environmentally Friendly

Use Period” (EFUP). This is an estimate of the number of years that these substances

would “not leak out or undergo abrupt change.” This product may contain replaceable

sub-assemblies/components which have a shorter EFUP such as batteries and lamps.

These components will be separately marked.

Please refer to the table on the next page.

Page 35

AC-KIT-888HD Audio Module

Toxic or Hazardous Substances and Elements Part Name

Housing

Display

Printed Circuit

Board

Metal

Fasteners

Cable

Assembly

Fan Assembly

Power Supply

Assemblies

Lead

(Pb)

X O O O O X

X O O O O X

X O O O O X

X O O O O O

X O O O O X

X O O O O X

X O O O O X

Mercury

(Hg)

Cadmium

(Cd)

Hexavalent

Chromium

(CR(VI))

Polybrominated

Biphenyls

(PBB)

Polybrominated

Diphenyl

Ethers

(PBDE)

Battery

O: This toxic or hazardous substance is contained in all of the homogeneous materials for the part is

below the limit requirement in SJ/T11363-2006

X: This toxic or hazardous substance is contained in at least one of the homogeneous materials for

this part is above the limit requirement in SJ/T11363-2006

O O O O O O

Page 36

AC-KIT-888HD Audio Module

ڶڶ୭凝ࢨցై

ຝٙټ㲯

卋

ޤ

叏

ք᪔卲

ڍᄽ侶૖

ڍᄽԲ૖

ㅘ

㨆󰪠

䯲ق

ٱࠧ䶣ሁࣨ

㺉ᝅ༐

䶣佟伝僞

咾஛伝僞

䶣Ժࠎ䬗伝僞

䶣ۃ

ڼٙڱڇ┛অء䣈঴ฤٽխ㧺 RoHS 䰬଱ΖאՀ௑䰬قڼ䣈঴խڶ凝ܶၦฤ

ٽխ㧺 RoHS 䰬଱億ࡳૻၦ૞ޣΖ

ء䣈঴Ղ㢸ڶ”㩾ቼ֖ړࠌشཚૻ”䰬亜Δڼཚૻ۷ጩ㪤ࠄ凝”լ㢸ڶዥࢨડ䦣”

ڣૻΖء䣈঴ױ౨ץܶڶ剭࿍㩾ቼ֖ړࠌشཚૻױཙ䮨ցٙΔቝ䶣ۃࢨ㣼ጥΔ㪤ࠄց

ٙ㰒㢸㧧㭦䰬قנ䝢Ζ

O: ق具ڶڶ୭凝ڇ具ຝٙࢬڶ凝ޗறխܶၦ݁ڇ SJ/T11363-2006 䰬଱億ࡳૻၦ૞ޣאՀΖ

X: ق具ڶڶ୭凝۟֟ڇ具ຝٙԫ݁凝ޗறխܶၦ၌נ SJ/T11363-2006 䰬଱億ࡳૻၦ૞ޣΖ

(Pb)

X O O O O X

X O O O O X

X O O O O X

X O O O O O

X O O O O X

X O O O O X

X O O O O X

O O O O O O

(Hg)

(Cd)

(CR(VI))

(PBB)

(PBDE)

Page 37
