IEI Integration TUS3400 1 User Manual

MODEL:

TUS3400

Panel PC

IEI Technology Corp.

TUS3400

User Manual

Rev. 1.01 – 15 March, 2017

Page 1

Date Version Changes

17 September, 2013 1.00 Initial release

11 November, 2016 1.01 USB port update

TUS3400

Revision

Page 2

TUS3400

Copyright

COPYRIGHT NOTICE

The information in this document is subject to change without prior notice in order
to improve reliability, design and function and does not represent a commitment on
the part of the manufacturer.

In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.

This document contains proprietary information protected by copyright. All rights
are reserved. No part of this manual may be reproduced by any mechanical,
electronic, or other means in any form without prior written permission of the
manufacturer.

TRADEMARKS

All registered trademarks and product names mentioned herein are used for
identification purposes only and may be trademarks and/or registered trademarks
of their respective owners.

Page 3

TUS3400

Table of Contents

1. INTRODUCTION

1.1 OVERVIEW……………………………………………………………………….6

1.2 DIMENSIONS…………………………………….……………………………….7

1.3 SPECIFICATIONS………………………………….…………………………….9

2 UNPACKING

2.1 UNPACKING…………………………………………………………………….12

2.2 PACKING LIST………………………………………………………………….13

3 INSTALLATION

3.1 ANTI-STATIC PRECAUTIONS…………….………………………………….15

3.2 INSTALLATION PRECAUTIONS…………………………………………….15

3.3 PREINSTALLED COMPONENTS…………………………………………….16

3.4 REMOVING THE BACK COVER……………………………………………..17

3.5 REMOVING THE CONSOLE………………………………………………….18

4 SYSTEM MAINTENANCE

4.1 SYSTEM MAINTENANCE INTRODUCTION….……………………………20

4.2 MOTHERBOARD REPLACEMENT………………………………………….20

4.3 BACK COVER REMOVAL…………………………………………………….20

………………………………………………………………...5

………………………………………………………………………11

…………………………………………………………………14

……………………………………………………19

4.4 CONSOLE REPLACEMENT…………………………………………………..21

4.5 SO-DIMM REPLACEMENT…………………………………………………...21

5 SAFETY PRECAUTIONS

A.1 SAFETY PRECAUTIONS……………………………………….......…………24

A.1.1 General Safety Precautions………………………………………..………...24
A.1.2 Anti-static Precautions……………………………………………..………...25
A.1.3 Product Disposal ……………………………………………………………26

A.2 MAINTENANCE AND CLEANING PRECAUTIONS………………………26

A.2.1 Maintenance and Cleaning..…………………………………………………26
A.2.2 Cleaning Tools…………………………………………………………..…….27
A.2.3 Federal Communication Commission Interference Statement……………28

6 HAZARDOUS MATERIALS DISCLOSURE

B.1 HAZARDOUS MATERIAL DISCLOSURE TABLE FOR IPB PRODUCTS
CERTIFIED AS ROHS COMPLIANT UNDER 2002/95/EC WITHOUT
MERCURY…………………………………………………………………………...30

Page 4

……………………………………………………...23

…………………...........…...29

TUS3400

Chapter

1

1 Introduction

Page 5

1.1 Overview

TUS3400

Figure 1-1: TUS3400 Portable Computer

The TUS3400 portable computer provides all the features of a PC. The TUS3400
provides wireless networking for integration into company/facility networks. The
major external device connections include USB 3.0/2.0 and serial port connectors.
Storage options include a 2.5” hard drive, allowing for flexibility in choosing solid
state drives or traditional hard drives. 2 HDMI outputs on the left side allow the
TUS3400 to connect to a second/third screen for duplicating the screen contents or
extending the user interface.

Page 6

TUS3400

1.2 Dimensions

Page 7

TUS3400

TUS3400 Dimensions (mm)

Page 8

TUS3400

1.3 Specifications

The technical specifications for the TUS3400 system are listed in below table.

Model Name TUS3400

SBC Model TRN-HM65-MB
CPU 2nd Generation Intel® Core™i7-3555LE processor

MB

Chipset Intel HM65
RAM 2 x 4G DDR3 1333 SO-DIMM (Support ECC)
LCD Size 15"

Max Resolution 1024x768
Brightness (cd/m2) minimum of 300 nits

Display

LED

Contrast Ratio 500:1
LCD Color 16.2M
Pixel Pitch (mm) 0.297(H) x 0.297(V)
Viewing Angle (H-V) 170(H)/ 170(V)

1x Power DC-JACK Connector
1x RJ-45 Connector For LAN
2x USB3.0 port, 2x USB2.0 port

I/O Port

Sleep LED Blue

Charging LED

Storage 1 x 2.5" 1T HDD

DVD

2 x HDMI connector
1xExt Power Switch connector
1xLine in Jack connector
1x Line out Jack connector

Bi-color, blue or amber. It is amber when
charging, and blue when fully charged and the power adapter is
connected.

1 x Slot-in DVD, 8x SuperDrive DVD +/‐ R DL/DVD +/‐RW, CD‐ RW

Main Module

Camera module

WiFi 1 x Wireless LAN 802.11a/b/g/n module by internal Mini PCIe interface
Speaker
Console 1 x Keyboard/Trackball Console

2 x stereo speakers + 1 x sub‐woofer (internal speaker)

Up to UXGA resolution (1600X1200) to take still image, support VGA
(640x480) resolution up to 30fps at YUY2 mode

Page 9

TUS3400

Construction
Material

Dimension (WxHxD) 388.3*395.6*88.45 (mm)

Physical

Environment

Power

OS Windows 7 32bit

Others

Weight 6.8kg

Magnetic Latch

Operation
Temperature
Storage
Temperature

Battery SANYO UR18650FK, 11.1V, 5400mah, 3S2P=59.94WH

Power Supply Power adapter: medical grade AC/DC adapter, Output: 19 VDC

Logo Terason, illuminated logo
Flip-down feet

PC+ABS

a. Magnet size：30mm x 8mm x 6mm.
b. Q'ty : 8pcs (B part*4, C part *4)
c. Open/Close Force : 2.0kgf ~ 2.5kgf.

0~35°C

0~60°C

Page 10
