IEI Integration TRN3800T Users Manual

MODEL:
TRN-TABLET3
TRN-TABLET3
15.6" Tablet PC with Intel® Core™ i7-7820EQ CPU, 16 GB DDR4 SDRAM, USB 3.0, HDMI, 512 GB M.2 SSD, Wi-Fi, Bluetooth, 5-Megapixel Camera, RoHS Compliant
User Manual
Rev. 1.00 – January 22, 2019
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page i
Date Version Changes
January 22, 2019 1.00 Initial release
TRN-TABLET3
Revision
Page ii
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
COPYRIGHT NOTICE
In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are reserved. No part of this manual may be reproduced by any mechanical, electronic, or other means in any form without prior written permission of the manufacturer.
TRADEMARKS
Copyright
All registered trademarks and product names mentioned herein are used for identification purposes only and may be trademarks and/or registered trademarks of their respective owners.
CONTACT INFORMATION
Manufactured by: IEI Integration Corp.
Address: No. 29, Zongxing Rd., Xizhi Dist.,
New Taipei City 221, Taiwan Phone: +886-2-8691-6798 Fax: +886-2-6616-0028 Web Site: www.ieiworld.com Sales Email: sales@ieiworld.com.tw
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page iii
TRN-TABLET3
Manual Conventions
WARNING
Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously.
CAUTION
Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product.
NOTE
These messages inform the reader of essential but non-critical information. These messages should be read carefully as any directions or instructions contained therein can help avoid making mistakes.
Page iv
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
Table of Contents
1 INTRODUCTION .......................................................................................................... 1
1.1 OVERVIEW.................................................................................................................. 2
1.2 FEATURES ................................................................................................................... 3
1.3 FRONT PANEL ............................................................................................................. 3
1.4 REAR PANEL ............................................................................................................... 4
1.5 TOP PANEL ................................................................................................................. 4
1.6 SIDE PANEL ................................................................................................................ 5
1.7 TECHNICAL SPECIFICATIONS ...................................................................................... 6
1.8 DIMENSIONS ............................................................................................................... 8
2 UNPACKING ................................................................................................................. 9
3 INSTALLATION .......................................................................................................... 11
3.1 SAFETY PRECAUTIONS ............................................................................................. 12
3.2 ANTI-STATIC PRECAUTIONS ...................................................................................... 13
3.3 INSTALLATION PRECAUTIONS ................................................................................... 13
3.4 INSTALLING AND CHARGING THE BATTERY PACK ..................................................... 14
3.5 USING THE 2-IN-1 STAND ......................................................................................... 17
4 BIOS SETUP ................................................................................................................ 18
4.1 INTRODUCTION ......................................................................................................... 19
4.1.1 Starting Setup ................................................................................................... 19
4.1.2 Using Setup ...................................................................................................... 19
4.1.3 Getting Help ..................................................................................................... 20
4.1.4 BIOS Menu Bar ................................................................................................ 20
4.2 MAIN ........................................................................................................................ 21
4.3 ADVANCED ............................................................................................................... 22
4.3.1 CPU Configuration .......................................................................................... 23
4.3.2 SATA Configuration ......................................................................................... 25
4.3.3 Trusted Computing ........................................................................................... 26
4.3.4 ACPI Settings ................................................................................................... 27
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page v
4.3.5 iWDD H/W Monitor ......................................................................................... 28
4.3.5.1 Smart Fan Mode Configuration ................................................................ 29
4.3.6 USB Configuration ........................................................................................... 31
4.4 CHIPSET ................................................................................................................... 32
4.4.1 System Agent (SA) Configuration .................................................................... 33
4.4.1.1 Memory Configuration ............................................................................. 34
4.4.1.2 PEG Port Configuration ............................................................................ 34
4.4.2 PCH-IO Configuration .................................................................................... 35
4.5 SECURITY ................................................................................................................. 37
4.6 BOOT ........................................................................................................................ 38
4.7 SAVE & EXIT ............................................................................................................ 40
A REGULATORY COMPLIANCE .............................................................................. 42
B PRODUCT DISPOSAL .............................................................................................. 48
C MAINTENANCE AND CLEANING PRECAUTIONS .......................................... 50
TRN-TABLET3
C.1.1 Maintenance and Cleaning ............................................................................. 51
C.1.2 Cleaning Tools ................................................................................................. 52
D SYMBOL DEFINITIONS .......................................................................................... 53
E BIOS OPTIONS .......................................................................................................... 54
F HAZARDOUS MATERIALS DISCLOSURE .......................................................... 58
Page vi
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
List of Figures
Figure 1-1: TRN-TABLET3 .........................................................................................................2
Figure 1-2: Front Panel ..............................................................................................................3
Figure 1-3: Rear Panel ...............................................................................................................4
Figure 1-4: Top Panel ................................................................................................................4
Figure 1-5: Side Panel ...............................................................................................................5
Figure 1-6: Dimensions (units in mm) ......................................................................................8
Figure 3-1: Adjusting the 2-in-1 Stand Kit .............................................................................. 14
Figure 3-2: Battery Pack Installation....................................................................................... 15
Figure 3-3: Battery Capacity Indicators .................................................................................. 15
Figure 3-4: Battery Pack Removal .......................................................................................... 16
Figure 3-5: Tablet Stand .......................................................................................................... 17
Figure 3-6: Tablet Carrying Handle ......................................................................................... 17
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page vii
TRN-TABLET3
List of Tables
Table 1-1: Technical Specifications ..........................................................................................7
Table 2-1: Packing List ............................................................................................................ 10
Table 4-1: BIOS Navigation Keys ............................................................................................ 20
Page viii
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
BIOS Menus
BIOS Menu 1: Main .................................................................................................................. 21
BIOS Menu 2: Advanced ......................................................................................................... 22
BIOS Menu 3: CPU Configuration ........................................................................................... 23
BIOS Menu 4: SATA Configuration ......................................................................................... 25
BIOS Menu 5: Trusted Computing .......................................................................................... 26
BIOS Menu 6: ACPI Configuration .......................................................................................... 27
BIOS Menu 7: iWDD H/W Monitor ........................................................................................... 28
BIOS Menu 8: Smart Fan Mode Configuration ....................................................................... 29
BIOS Menu 9: USB Configuration ........................................................................................... 31
BIOS Menu 10: Chipset ........................................................................................................... 32
BIOS Menu 11: System Agent (SA) Configuration ................................................................. 33
BIOS Menu 12: Memory Configuration ................................................................................... 34
BIOS Menu 13: PEG Port Configuration ................................................................................. 34
BIOS Menu 14: PCH-IO Configuration .................................................................................... 35
BIOS Menu 15: Security .......................................................................................................... 37
BIOS Menu 16: Boot ................................................................................................................ 38
BIOS Menu 17:Exit ................................................................................................................... 40
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page ix
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
Chapter
1
1 Introduction
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 1
1.1 Overview
TRN-TABLET3
Figure 1-1: TRN-TABLET3
The TRN-TABLET3 is a 15.6" tablet PC with the Intel® Core™ i7-7820EQ processor and 16 GB DDR4 SDRAM. Its storage needs are met by the preinstalled 512 GB M.2 SSD. In addition, an NVIDIA® Quadro® P3000 MXM graphics card is installed to enhance graphics processing capability.
The TRN-TABLET3 is integrated with a selection of wireless communication technologies, including Wi-Fi and Bluetooth. There are four external USB 3.0 ports and one HDMI port for peripherals. The TRN-TABLET3 also features a 5-megapixel camera and digital microphone for video conferencing and data acquisition.
Page 2
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
1.2 Features
Some of the standard features of the TRN-TABLET3 tablet PC include:
§ Intel® Core™ i7-7820EQ processor platform
§ 16 GB DDR4 SDRAM
§ Pre-installed NVIDIA® Quadro® P3000 MXM graphics card
§ 5-point projected capacitive touchscreen
§ Built-in 5-megapixel camera
§ Built-in stereo speakers and digital microphone
§ 802.11a/b/g/n/ac wireless LAN
§ Bluetooth v4.0
§ One HDMI and four USB 3.0 ports (three Type-A and one Type-C) on the side
§ RoHS compliant
panel
1.3 Front Panel
The front panel of the TRN-TABLET3 is a 15.6" LCD with a 5-point capacitive touchscreen. A 5-megapixel camera and a digital microphone are also located on the front panel.
Figure 1-2: Front Panel
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 3
1.4 Rear Panel
The rear panel has a battery pack and a 2-in-1 stand that can turn into a carrying handle. The two speakers are also located on the rear panel.
TRN-TABLET3
Figure 1-3: Rear Panel
1.5 Top Panel
The power button (with power LED) is located on the top panel as shown in the following diagram. To power-up the system, short press the power button, and the power LED on the button lights up in blue.
Figure 1-4: Top Panel
Page 4
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
1.6 Side Panel
The right side panel contains several I/O interfaces as shown below.
Figure 1-5: Side Panel
NOTE:
The LED indication of the RJ-45 LAN port is listed below:
LED Status Link Speed
Orange LED 100 Mbps Green LED 1000 Mbps
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 5
1.7 Technical Specifications
The TRN-TABLET3 technical specifications are listed in the table below.
Display
TRN-TABLET3
LCD Size Brightness (cd/m2) Max. Resolution Viewing Angle Touchscreen System CPU
Memory OS Storage GPU Front Camera TPM Communication
15.6" 400 1920 (H) x 1080 (V) 88/88/88/88 degree (wide viewing angle, IPS) 5-point projected capacitive, Gorilla Glass
Intel® Core™ i7-7820EQ 16 GB DDR4 SDRAM
Windows 10 Pro 512 GB M.2 SSD (optional 1 TB) NVIDIA® Quadro® P3000 graphics card 5-megapixel webcam (front panel) Trusted Platform Module
Page 6
Wireless LAN Bluetooth I/O Interfaces
Audio
LAN HDMI
USB
802.11a/b/g/n/ac, diversity antenna design Bluetooth v4.0
2 x Stereo loudspeaker 1 x Headset jack (φ3.5mm) Built-in digital microphone
1 x RJ-45 (10/100/1000 Mbps) 1 x HDMI slot 4 x USB 3.0 (external, three Type-A, one Type-C)
1 x USB 3.0 (internal, for engine connection)
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
Power
Power Adapter
Battery
Environment Operation Temperature Storage Temperature Environment Protection Drop Survival
Mounting
Physical Characteristics Dimensions (W x H x D)
AC Input: 100 V AC ~ 240 V AC DC Output: 19 V @ 10.53 A, 200 W
External: 6500 mAH Li-ion battery pack with battery capacity LED indicators, 10.8 V, 3S2P (31603-000078-RS)
Internal: for backup
0ºC ~ 35ºC 0ºC ~ 60ºC IP 54 complaint front panel, wipe cleanable MIL SPEC 810: 1 meter 26 drops Built-in kick-stand
VESA mount (75 mm) for optional arm/stand/cart
396.66 mm x 260.06 mm x 52.29 mm
Net Weight Security Table 1-1: Technical Specifications
5 kg Kensington lock
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 7
1.8 Dimensions
TRN-TABLET3
Figure 1-6: Dimensions (units in mm)
Page 8
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
Chapter
2
2 Unpacking
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 9
To unpack the TRN-TABLET3, follow the steps below:
TRN-TABLET3
WARNING!
Only remove the protective plastic cover stuck to the front screen after installation. The plastic layer protects the monitor surface during installation process.
Step 1: Use sharp cutters to open the external and internal boxes.
Step 2: Lift the TRN-TABLET3 and the packing material out of the box.
Step 3: Make sure all the components listed in the packing list are present. Step 0:
The TRN-TABLET3 tablet PC is shipped with the following components. If any of these items are missing or damaged, contact the distributor or sales representative immediately.
Quantity Item Image
1 TRN-TABLET3
1 Power adapter
1 Battery pack
Table 2-1: Packing List
Page 10
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
Chapter
3
3 Installation
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 11
3.1 Safety Precautions
Please ensure the following safety precautions are adhered to at all times.
§ To prevent the risk of electric shock, make sure power cord is unplugged from wall socket. To fully disengage the power to the unit,
please disconnect the power cord from the ac outlet. Refer servicing to qualified service personnel. The AC outlet shall be readily available and accessible.
§ Follow the electrostatic precautions outlined below whenever the TRN-TABLET3 is opened.
§ Make sure the power is turned off and the power cord is disconnected whenever the TRN-TABLET3 is being installed, moved or modified.
§ Do not apply voltage levels that exceed the specified voltage range. Doing so may cause fire and/or an electrical shock. Use a power cord that
TRN-TABLET3
matches the voltage of the power outlet, which has been approved and complies with the safety standard of your particular country.
§ Electric shocks can occur if the TRN-TABLET3 chassis is opened when the TRN-TABLET3 is running. To avoid risk of electric shock, this equipment must only be connected to a supply mains with protective earth.
§ DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS BELOW 0°C (32°F) OR ABOVE 60°C (140°F). IT MAY DAMAGE THE EQUIPMENT.
§ Do not drop or insert any objects into the ventilation openings of the TRN-TABLET3.
§ If considerable amounts of dust, water, or fluids enter the TRN-TABLET3, turn off the power supply immediately, unplug the power cord, and contact the TRN-TABLET3 vendor.
§ DO NOT:
o Drop the TRN-TABLET3 against a hard surface. o Strike or exert excessive force onto the LCD panel. o Touch any of the LCD panels with a sharp object o In a site where the ambient temperature exceeds the rated temperature
Page 12
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
3.2 Anti-static Precautions
WARNING:
Failure to take ESD precautions during the maintenance of the TRN-TABLET3 may result in permanent damage to the TRN-TABLET3 and severe injury to the user.
Electrostatic discharge (ESD) can cause serious damage to electronic components, including the TRN-TABLET3. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the TRN-TABLET3 is accessed internally, or any other electrical component is handled, the following anti-static precautions are strictly adhered to.
§ Wear an anti-static wristband: - Wearing a simple anti-static wristband can help to prevent ESD from damaging the board.
§ Self-grounding: - Before handling the board touch any grounded conducting material. During the time the board is handled, frequently touch any conducting materials that are connected to the ground.
§ Use an anti-static pad: - When configuring the TRN-TABLET3, place it on an antic-static pad. This reduces the possibility of ESD damaging the TRN-TABLET3.
§ Only handle the edges of the PCB: - When handling the PCB, hold the PCB by the edges.
3.3 Installation Precautions
When installing the TRN-TABLET3, please follow the precautions listed below:
§ Power turned off: When installing the TRN-TABLET3, make sure the power is off. Failing to turn off the power may cause severe injury to the body and/or damage to the system.
§ Certified Engineers: Only certified engineers should install and modify onboard functionalities.
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 13
§ Anti-static Discharge: If a user open the rear panel of the TRN-TABLET3, to configure the jumpers or plug in added peripheral devices, ground themselves first and wear and anti-static wristband.
3.4 Installing and Charging the Battery Pack
CAUTION:
§ Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer.
§ Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, that can result in an explosion.
§ Leaving a battery in an extremely high temperature surrounding environment that can result in an explosion or the leakage of flammable liquid or gas.
§ A battery subjected to extremely low air pressure that may result in an
TRN-TABLET3
explosion or the leakage of flammable liquid or gas.
To install and charge the battery pack, please follow the steps below.
Step 1: Adjust the stand to a position that allows the installation of the battery pack
(Figure 3-1).
Figure 3-1: Adjusting the 2-in-1 Stand Kit
Page 14
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
Step 2: Install the battery pack as shown in 406H477HFigure 3-2.
Figure 3-2: Battery Pack Installation
Step 3: To charge the battery, connect the TRN-TABLET3 with a power source through
the supplied power adapter.
Step 4: To view the battery capacity, press the battery capacity button on the battery
(Figure 3-3).
Figure 3-3: Battery Capacity Indicators
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 15
Step 5: To remove the battery pack, press the two buttons indicated in the following
diagram at the same time to eject the battery jack.
TRN-TABLET3
Figure 3-4: Battery Pack Removal
Page 16
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
3.5 Using the 2-in-1 Stand
The 2-in-1 stand secured on the rear panel can stabilize the TRN-TABLET3 on a surface, and also can be turned into a carrying handle.
Stand
Adjust the 2-in-1 stand to have a best angle to operate the system (see Figure 3-5).
Figure 3-5: Tablet Stand
Carrying Handle
Adjust the 2-in-1 stand to the upright position to use it as a handle (see Figure 3-6).
Figure 3-6: Tablet Carrying Handle
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 17
TRN-TABLET3
Chapter
4
4 BIOS Setup
Page 18
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
4.1 Introduction
The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed.
NOTE:
Some of the BIOS options may vary throughout the life cycle of the product and are subject to change without prior notice.
4.1.1 Starting Setup
The UEFI BIOS is activated when the computer is turned on. The setup program can be activated in one of two ways.
1. Press the DEL or F2 key as soon as the system is turned on or
2. Press the DEL or F2 key when the Press DEL or F2 to enter SETUP message appears on the screen.
If the message disappears before the DEL or F2 key is pressed, restart the computer and try again.
4.1.2 Using Setup
Use the arrow keys to highlight items, press ENTER to select, use the PageUp and PageDown keys to change entries, press F1 for help and press ESC to quit. Navigation keys are shown in Table 4-1.
Key Function
Up arrow Move to previous item Down arrow Move to next item Left arrow Move to the item on the left hand side Right arrow Move to the item on the right hand side + Increase the numeric value or make changes
- Decrease the numeric value or make changes
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 19
Key Function
Page Up Move to the previous page Page Dn Move to the next page Esc Main Menu – Quit and not save changes into CMOS
Status Page Setup Menu and Option Page Setup Menu -- Exit current page and return to Main Menu
F1 General help, only for Status Page Setup Menu and Option Page
Setup Menu F2 Load previous values F3 Load optimized defaults F4 Save changes and Exit BIOS
Table 4-1: BIOS Navigation Keys
TRN-TABLET3
4.1.3 Getting Help
When F1 is pressed a small help window describing the appropriate keys to use and the possible selections for the highlighted item appears. To exit the Help Window press ESC or the F1 key again.
4.1.4 BIOS Menu Bar
The menu bar on top of the BIOS screen has the following main items:
§ Main – Changes the basic system configuration.
§ Advanced – Changes the advanced system settings.
§ Chipset – Changes the chipset settings.
§ Security – Sets User and Supervisor Passwords.
§ Boot – Changes the system boot configuration.
§ Save & Exit – Selects exit options and loads default settings
The following sections completely describe the configuration options found in the menu items at the top of the BIOS screen and listed above.
Page 20
PDF created with pdfFactory Pro trial version www.pdffactory.com
. Use Tab to
TRN-TABLET3
4.2 Main
The Main BIOS menu (430H510H804HBIOS Menu 1) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information.
Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc.
Main Advanced Chipset Security Boot Save & Exit
BIOS Information BIOS Vendor American Megatrends Core Version 5.12 Compliancy UEFI 2.6; PI 1.4 Project Version Z484AR01.ROM Build Date and Time 10/22/2018 09:53:30
iWDD Vendor iEi iWDD Version B487ET18.bin Access Level Administrator
Processor Information Name Kabylake Halo Type Intel(R) Core(TM) i7-7820EQ CPU @ 3.00GHz Speed 3000 MHz ID 0x906E9 Stepping B0/S0/M0 Number of Processors 4Core(s) / 8Thread(s) Microcode Revision 70 GT Info GT2 (0x591B) eDRAM Size N/A
Memory RC Version 3.0.0.0 Total Memory 16384 MB Memory Frequency 2133 MHz
ME FW Version 11.8.50.3434 ME Firmware SKU Consumer SKU
System Date [Tue 10/24/2018] System Time [14:20:27]
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
Set the Date switch between Date elements.
----------------------
àß
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit
BIOS Menu 1: Main
The Main menu has two user configurable fields:
è System Date [xx/xx/xx]
Use the System Date option to set the system date. Manually enter the day, month and year.
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 21
è System Time [xx:xx:xx]
Use the System Time option to set the system time. Manually enter the hours, minutes and seconds.
4.3 Advanced
Use the Advanced menu (431H511H805HBIOS Menu 2) to configure the CPU and peripheral devices through the following sub-menus:
WARNING!
Setting the wrong values in the sections below may cause the system to malfunction. Make sure that the settings made are compatible with the hardware.
TRN-TABLET3
Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc.
Main Advanced Chipset Security Boot Save & Exit
> CPU Configuration > SATA Configuration > Trusted Computing > ACPI Settings > iWDD H/M Monitor > USB Configuration
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
BIOS Menu 2: Advanced
System ACPI Parameters
----------------------
àß
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit
Page 22
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
4.3.1 CPU Configuration
Use the CPU Configuration menu (432H512H808HBIOS Menu 3) to view detailed CPU specifications and configure the CPU.
Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc.
Advanced
CPU Configuration
Type Intel(R) Core(TM)
i7-7820EQ CPU @ 3.00GHz ID 0x906E9 Speed 3000 MHz L1 Data Cache 32 KB x 4 L1 Instruction Cache 32 KB x 4 L2 Cache 256 KB x 4 L3 Cache 8 MB L4 Cache N/A VMX Supported SMX/TXT Supported
Active Processor Cores [All] Intel (VMX) Virtualization [Enabled] Technology Hyper-threading [Enabled] Intel(R) SpeedStep(tm) [Enabled]
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
Number of cores to enable in each processor package.
--------------------
--
àß
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit
BIOS Menu 3: CPU Configuration
è Active Processor Cores [All]
Use the Active Processor Cores BIOS option to enable numbers of cores in the processor package.
è
All DEFAULT Enable all cores in the processor package.
è
1 Enable one core in the processor package.
è
2 Enable two cores in the processor package.
è
3 Enable three cores in the processor package.
Page 23
PDF created with pdfFactory Pro trial version www.pdffactory.com
è Intel (VMX) Virtualization Technology [Enabled]
Use the Intel (VMX) Virtualization Technology option to enable or disable virtualization on the system. When combined with third party software, Intel® Virtualization technology allows several OSs to run on the same system at the same time.
è
Disabled Disables Intel Virtualization Technology.
è
Enabled DEFAULT Enables Intel Virtualization Technology.
è Hyper-threading [Enabled]
Use the Hyper-threading to enable or disable the CPU hyper threading function.
è
Disabled Disables the use of hyper threading technology
è
Enabled DEFAULT Enables the use of hyper threading technology
TRN-TABLET3
è Intel(R) SpeedStep(tm) [Enabled]
Use the Intel(R) SpeedStep(tm) option to enable or disable the Intel® SpeedStep Technology which allows more than two frequency ranges to be supported.
è
Disabled Disables Intel® SpeedStep Technology
è
Enabled DEFAULT Enables Intel® SpeedStep Technology
Page 24
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
4.3.2 SATA Configuration
Use the SATA Configuration menu (434H514H810HBIOS Menu 4) to change and/or set the configuration of the SATA devices installed in the system.
Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc.
Advanced
SATA Configuration
SATA Controller(s) [Enabled] SATA Mode Selection [AHCI]
M2_M1 Slot M.2 (S80) 3MG2 (496.1GB)
Enable/Disable SATA Device.
---------------------
àß
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
BIOS Menu 4: SATA Configuration
è SATA Controller(s) [Enabled]
Use the SATA Controller(s) option to configure the SATA controller(s).
è
Enabled DEFAULT Enables the on-board SATA controller(s).
è
Disabled Disables the on-board SATA controller(s).
è SATA Mode Selection [AHCI]
Use the SATA Mode Selection option to determine how SATA devices operate.
è
AHCI DEFAULT Configures SATA devices as AHCI device.
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 25
Enables or Disables BIOS
INT1A interface will not
4.3.3 Trusted Computing
Use the Trusted Computing menu (BIOS Menu 5) to configure settings related to the Trusted Computing Group (TCG) Trusted Platform Module (TPM).
Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc.
Advanced
TPM20 Device Found
Security Device Support [Enable] Pending Operation [None]
TRN-TABLET3
support for security device. O.S. will not show Security Device. TCG EFI protocol and
be available.
----------------------
àß
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
BIOS Menu 5: Trusted Computing
è Security Device Support [Enable]
Use the Security Device Support option to configure the BIOS support for the security device.
è
Disable BIOS support for the security device is disabled.
è
Enable DEFAULT BIOS support for the security device is enabled.
è Pending operation [None]
Use the Pending operation option to schedule an operation for the security device.
è
None DEFAULT No operation is scheduled.
è
TPM Clear Clears the TPM
Page 26
PDF created with pdfFactory Pro trial version www.pdffactory.com
ACPI
TRN-TABLET3
4.3.4 ACPI Settings
The ACPI Settings menu (873H806HBIOS Menu 6) configures the Advanced Configuration and Power Interface (ACPI) options.
Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc.
Advanced
ACPI Settings
ACPI Sleep State [S3 (Suspend to RAM)]
Select the highest sleep state the system will enter when the SUSPEND button is pressed.
----------------------
àß
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
BIOS Menu 6: ACPI Configuration
è ACPI Sleep State [S3 (Suspend to RAM)]
Use the ACPI Sleep State option to specify the sleep state the system enters when it is not being used.
è
S3 only (Suspend to RAM)
DEFAULT The caches are flushed and the CPU is powered
off. Power to the RAM is maintained. The computer returns slower to a working state, but more power is saved.
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 27
4.3.5 iWDD H/W Monitor
The iWDD H/W Monitor menu (436H516H814HBIOS Menu 7) shows the operating temperature.
Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc.
Advanced
PC Health Status
CPU temperature :+60 °C System temperature :+51 °C Ultrasound temperature :+0 °C
CPU_FAN1 Speed :1543 RPM SYS_FAN1 Speed :5528 RPM
CPU_CORE :+0.997 V +5V :+5.023 V VCCIO :+0.920 V +DDR :+1.190 V +5VSB :+5.038 V +3.3V :+3.310 V +3.3VSB :+3.282 V
> Smart Fan Mode Configuration
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
TRN-TABLET3
Smart Fan Mode Select.
---------------------
àß
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit
BIOS Menu 7: iWDD H/W Monitor
è PC Health Status
The following system parameters and values are shown. The system parameter that is monitored is:
§ System Temperatures:
o CPU Temperature o System Temperature o Ultrasound Temperature
§ Fan Speeds:
o CPU Fan Speed o System Fan Speed
§ Voltages:
o CPU_CORE o +5V
Page 28
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
o VCCIO o DDR o +5VSB o +3.3V o +3.3VSB
4.3.5.1 Smart Fan Mode Configuration
Use the Smart Fan Mode Configuration submenu (BIOS Menu 8) to configure the system fan temperature and speed settings.
Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc.
Advanced
Smart Fan Mode Configuration
CPU_FAN1 Smart Fan Control1 [Auto Mode] Auto mode fan start temperature 50 Auto mode fan off temperature 20 Auto mode fan start PWM 10 Auto mode fan slope PWM 3
SYS_FAN1 Smart Fan Control2 [Auto Mode] Auto mode fan start temperature 50 Auto mode fan off temperature 20 Auto mode fan start PWM 10 Auto mode fan slope PWM 3
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
Smart Fan Mode Select
---------------------
àß
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit
BIOS Menu 8: Smart Fan Mode Configuration
è CPU_FAN1 Smart Fan Control/SYS_FAN1 Smart Fan Control [Auto Mode]
Use the CPU_FAN1 Smart Fan Control/SYS_FAN1 Smart Fan Control option to configure the CPU/System Smart Fan.
è
Manual Mode The fan spins at the speed set in Manual Mode
settings.
è
Auto Mode DEFAULT The fan adjusts its speed using Auto Mode
settings.
Page 29
PDF created with pdfFactory Pro trial version www.pdffactory.com
The following options can only be set if the CPU/SYS Smart Fan Control option is set to Auto Mode.
è Auto mode fan start temperature
If the CPU temperature is between fan off and fan start, the fan speed change to fan start PWM. To set a value, Use the + or – key to change the value or enter a decimal number between 1 and 100.
è Auto mode fan off temperature
If the CPU temperature is lower than the value set this option, the fan speed change to be lowest. To set a value, Use the + or – key to change the value or enter a decimal number between 1 and 100.
è Auto mode fan start PWM
TRN-TABLET3
Use the Auto mode fan start PWM option to set the PWM start value. Use the + or – key to change the value or enter a decimal number between 1 and 100.
è Auto mode fan slope PWM
Use the Auto mode fan slope PWM option to select the linear rate at which the PWM mode increases with respect to an increase in temperature. Use the + or – key to change the value or enter a decimal number between 1 and 8.
Page 30
PDF created with pdfFactory Pro trial version www.pdffactory.com
disables legacy support
TRN-TABLET3
4.3.6 USB Configuration
Use the USB Configuration menu (435H515H811HBIOS Menu 9) to read USB configuration information and configure the USB settings.
Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc.
Advanced
USB Configuration
USB Devices: 1 Keyboard, 1 Mouse, 1 Point
Legacy USB Support [Enabled]
Enables Legacy USB support. AUTO option
if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications.
---------------------
àß
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
BIOS Menu 9: USB Configuration
è USB Devices
The USB Devices Enabled field lists the USB devices that are enabled on the system.
è Legacy USB Support [Enabled]
Use the Legacy USB Support BIOS option to enable USB mouse and USB keyboard support. Normally if this option is not enabled, any attached USB mouse or USB keyboard does not become available until a USB compatible operating system is fully booted with all USB drivers loaded. When this option is enabled, any attached USB mouse or USB keyboard can control the system even when there is no USB driver loaded onto the system.
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 31
ESC:
Exit
è
Enabled DEFAULT Legacy USB support enabled
è
Disabled Legacy USB support disabled
è
Auto Legacy USB support disabled if no USB devices are
4.4 Chipset
Use the Chipset menu (437H519H817H BIOS Menu 10) to access the PCH and System Agent (SA) configuration menus.
TRN-TABLET3
connected
WARNING!
Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction.
Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc.
Main Advanced Chipset Security Boot Save & Exit
> System Agent (SA) Configuration > PCH-IO Configuration
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
BIOS Menu 10: Chipset
System Agent (SA) Parameters
---------------------
àß
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit
Page 32
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
4.4.1 System Agent (SA) Configuration
Use the System Agent (SA) Configuration menu (BIOS Menu 11) to configure the System Agent (SA) parameters.
Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc.
Chipset
System Agent (SA) Configuration
VT-d Supported
> Memory Configuration > PEG Port Configuration
VT-d [Enabled]
Memory Configuration Parameters
---------------------
àß
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
BIOS Menu 11: System Agent (SA) Configuration
è VT-d [Enabled]
Use the VT-d option to enable or disable VT-d support.
è
Disabled Disables VT-d support.
è
Enabled DEFAULT Enables VT-d support.
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 33
4.4.1.1 Memory Configuration
Use the Memory Configuration menu (BIOS Menu 12) to display the memory information.
Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc.
Chipset
Total Memory 16384 MB
DIMM1 8192 MB (DDR4) DIMM2 8192 MB (DDR4)
TRN-TABLET3
---------------------
àß
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
BIOS Menu 12: Memory Configuration
4.4.1.2 PEG Port Configuration
Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc.
Chipset
PEG Port Configuration
MXM Graphic Card x16 Gen3
Enable Root Port [Auto] Max Link Speed [Auto]
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
BIOS Menu 13: PEG Port Configuration
Enable or Disable the Root Port
----------------------
àß
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit
Page 34
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
è Enable Root Port [Auto]
Use the Enable Root Port option to enable or disable the PCI Express (PEG) controller.
è
Disabled Disables the PCI Express (PEG) controller.
è
Enabled Enables the PCI Express (PEG) controller.
è
Auto DEFAULT PCI Express (PEG) controller is automatically
è Max Link Speed [Auto]
Use the Max Link Speed option to select the maximum link speed of the PCI Express slot. The following options are available:
§ Auto Default
§ Gen1
§ Gen2
detected and enabled.
§ Gen3
4.4.2 PCH-IO Configuration
Use the PCH-IO Configuration menu (520H818HBIOS Menu 14) to configure the PCH IO settings.
Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc.
Chipset
PCH-IO Configuration
PCI Express Configuration M2_A1 Slot
PCIe Speed [Auto] Detect Non-Compliance Device [Disabled]
HD Audio Subsystem Configuration Settings
HD Audio [Auto]
Power Saving Function(EUP) [Enabled]
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
Configure PCIe Speed
---------------------
àß
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit
BIOS Menu 14: PCH-IO Configuration
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 35
è PCIe Speed [Auto]
Use this option to select the support type of the PCI Express slot (M2_A1). The following options are available:
§ Auto Default
§ Gen1
§ Gen2
§ Gen3
è Detect Non-Compliance Device [Disabled]
Use the Detect Non-Compliance Device option to configure whether to detect if a non-compliance PCI Express device is connected to the PCI Express port.
è
Disabled DEFAULT Do not detect if a non-compliance PCI Express
TRN-TABLET3
device is connected to the PCI Express port.
è
Enabled Detect if a non-compliance PCI Express device is
connected to the PCI Express port.
è HD Audio [Auto]
The HD Audio option enables or disables the High Definition Audio controller.
è
Disabled The onboard HD Audio controller is disabled.
è
Enabled The onboard HD Audio controller is enabled.
è
Auto DEFAULT The onboard HD Audio controller is detected
automatically and enabled
è Power Saving Function(ERP) [Enabled]
Use the Power Saving Function BIOS option to enable or disable the power saving function.
è
Disabled Power saving function is disabled.
è
Enabled DEFAULT Power saving function is enabled. It will reduce power
consumption when the system is off.
Page 36
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
4.5 Security
Use the Security menu (440H523H821HBIOS Menu 15) to set system and user passwords.
Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc.
Main Advanced Chipset Security Boot Save & Exit
Password Description
If ONLY the Administrators password is set, then this only limits access to Setup and is only asked for when entering Setup If ONLY the Users password is set, then this is a power on password and must be entered to boot or enter Setup. In Setup the User will have Administrator rights. The password length must be in the following range: Minimum length 3 Maximum length 20
Administrator Password User Password
HDD Security Configuration:
PO:M.2 (S80) 3MG-P
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
Set Administrator Password
---------------------
àß
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit
BIOS Menu 15: Security
è Administrator Password
Use the Administrator Password to set or change a administrator password.
è User Password
Use the User Password to set or change a user password.
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 37
4.6 Boot
Use the Boot menu (439H522H820HBIOS Menu 16) to configure system boot options.
Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc.
Main Advanced Chipset Security Boot Save & Exit
Boot Configuration
Bootup NumLock State [On] Quiet Boot [Enabled]
Boot Option Priorities
Boot Option #1 [PO:M.2 (S80) 3MG-P]
Launch PXE OpROM [Disabled] Option ROM Messages [Force BIOS] UEFI Boot [Enabled]
Hard Drive BBS Priorities
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
TRN-TABLET3
Select the keyboard NumLock state
---------------------
àß
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit
BIOS Menu 16: Boot
è Bootup NumLock State [On]
Use the Bootup NumLock State BIOS option to specify if the number lock setting must be modified during boot up.
è
On DEFAULT Allows the Number Lock on the keyboard to be
enabled automatically when the computer system boots up. This allows the immediate use of the 10-key numeric keypad located on the right side of the keyboard. To confirm this, the Number Lock LED light on the keyboard is lit.
è
Off Does not enable the keyboard Number Lock
automatically. To use the 10-keys on the keyboard, press the Number Lock key located on the upper left-hand corner of the 10-key pad. The Number Lock LED on the keyboard lights up when the Number Lock is engaged.
Page 38
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
è Quiet Boot [Enabled]
Use the Quiet Boot BIOS option to select the screen display when the system boots.
è
Disabled Normal POST messages displayed
è
Enabled DEFAULT OEM Logo displayed instead of POST messages
è Launch PXE OpROM [Disabled]
Use the Launch PXE OpROM option to enable or disable boot option for legacy network devices.
è
Disabled DEFAULT Ignore all PXE Option ROMs
è
Enabled Load PXE Option ROMs.
è Option ROM Messages [Force BIOS]
Use the Option ROM Messages option to set the Option ROM display mode.
è
Force BIOS
è
Keep Current
è UEFI Boot [Enabled]
Use the UEFI Boot option to enable or disable to boot from the UEFI devices.
è
Enabled DEFAULT Boot from UEFI devices is enabled.
è
Disabled Boot from UEFI devices is disabled.
è Boot Option #1 [PO:M.2 (S80) 3MG-P]
Use the Boot Option #1 option to specify the boot priority from the available devices.
DEFAULT Sets display mode to force BIOS.
Sets display mode to current.
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 39
Exit system setup after
è Hard Drive BBS Priorities
Use the Hard Drive BBS Priorities option to set the order of the legacy devices in this group.
4.7 Save & Exit
Use the Save & Exit menu (441H524H822HBIOS Menu 17) to load default BIOS values, optimal failsafe values and to save configuration changes.
Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc.
Main Advanced Chipset Security Boot Save & Exit
Save Options
Save Changes and Reset Discard Changes and Reset
Default Options
Restore Defaults Save as User Defaults Restore User Defaults
saving the changes.
---------------------
àß
: Select Screen
: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit
TRN-TABLET3
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
BIOS Menu 17:Exit
è Save Changes and Reset
Use the Save Changes and Reset option to save the changes made to the BIOS options and to exit the BIOS configuration setup program.
è Discard Changes and Reset
Use the Discard Changes and Reset option to exit the system without saving the changes made to the BIOS configuration setup program.
è Restore Defaults
Use the Restore Defaults option to load the optimal default values for each of the parameters on the Setup menus. F3 key can be used for this operation.
Page 40
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
è Save as User Defaults
Use the Save as User Defaults option to save the changes done so far as user defaults.
è Restore User Defaults
Use the Restore User Defaults option to restore the user defaults to all the setup options.
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 41
TRN-TABLET3
Appendix
A
A Regulatory Compliance
Page 42
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
DECLARATION OF CONFORMITY
This equipment is in conformity with the following EU directives:
n EMC Directive (2014/30/EU) n Low-Voltage Directive (2014/35/EU) n RoHS II Directive (2011/65/EU, 2015/863/EU)
If the user modifies and/or install other devices in the equipment, the CE conformity declaration may no longer apply.
If this equipment has telecommunications functionality, it also complies with the requirements of the R&TTE Directive 1999/5/EC.
English IEI Integration Corp declares that this equipment is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
Български [Bulgarian] IEI Integration Corp. декларира, че този оборудване е в съответствие със
съществените изисквания и другите приложими правила на Директива 1999/5/ЕС. Česky [Czech]
IEI Integration Corp tímto prohlašuje, že tento zařízení je ve shodě se základními požadavky a dalšími příslušnými ustanoveními směrnice 1999/5/ES. Dansk [Danish] IEI Integration Corp erklærer herved, at følgende udstyr overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF.
Deutsch [German] IEI Integration Corp, erklärt dieses Gerät entspricht den grundlegenden Anforderungen und den weiteren entsprechenden Vorgaben der Richtlinie 1999/5/EU. Eesti [Estonian] IEI Integration Corp deklareerib seadme seadme vastavust direktiivi 1999/5/EÜ põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele.
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 43
Español [Spanish] IEI Integration Corp declara que el equipo cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE.
Ελληνική [Greek] IEI Integration Corp ΔΗΛΩΝΕΙ ΟΤΙ ΕΞΟΠΛΙΣΜΟΣ ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ. Français [French] IEI Integration Corp déclare que l'appareil est conforme aux exigences essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE. Italiano [Italian] IEI Integration Corp dichiara che questo apparecchio è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE.
Latviski [Latvian] IEI Integration Corp deklarē, ka iekārta atbilst būtiskajām prasībām un citiem ar to
TRN-TABLET3
saistītajiem noteikumiem Direktīvas 1999/5/EK. Lietuvių [Lithuanian] IEI Integration Corp deklaruoja, kad šis įranga atitinka esminius reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas. Nederlands [Dutch] IEI Integration Corp dat het toestel toestel in overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/EG. Malti [Maltese] IEI Integration Corp jiddikjara li dan prodott jikkonforma mal-ħtiġijiet essenzjali u ma provvedimenti oħrajn relevanti li hemm fid-Dirrettiva 1999/5/EC. Magyar [Hungarian] IEI Integration Corp nyilatkozom, hogy a berendezés megfelel a vonatkozó alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak. Polski [Polish] IEI Integration Corp oświadcza, że wyrobu jest zgodny z zasadniczymi wymogami oraz pozostałymi stosownymi postanowieniami Dyrektywy 1999/5/EC. Português [Portuguese] IEI Integration Corp declara que este equipamento está conforme com os requisitos essenciais e outras disposições da Directiva 1999/5/CE.
Page 44
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
Româna [Romanian] IEI Integration Corp declară că acest echipament este in conformitate cu cerinţele esenţiale şi cu celelalte prevederi relevante ale Directivei 1999/5/CE.
Slovensko [Slovenian] IEI Integration Corp izjavlja, da je ta opreme v skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive 1999/5/ES. Slovensky [Slovak] IEI Integration Corp týmto vyhlasuje, že zariadenia spĺňa základné požiadavky a všetky príslušné ustanovenia Smernice 1999/5/ES. Suomi [Finnish] IEI Integration Corp vakuuttaa täten että laitteet on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen.
Svenska [Swedish] IEI Integration Corp förklarar att denna utrustningstyp står I överensstämmelse med de väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG.
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 45
TRN-TABLET3
FCC WARNING
This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
n This device may not cause harmful interference, and n This device must accept any interference received, including interference that
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by
may cause undesired operation.
turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Page 46
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
Radiation Exposure Statement:
The product comply with the FCC portable RF exposure limit set forth for an uncontrolled environment and are safe for intended operation as described in this manual. The further RF exposure reduction can be achieved if the product can be kept as far as possible from the user body or set the device to lower output power if such function is available.
ROHS STATEMENT
The label on the product indicates this product conforms to European (EU) Restriction of Hazardous Substances (RoHS) that set maximum concentration limits on hazardous materials used in electrical and electronic equipment.
CHINA ROHS
The label on the product indicates the estimated Environmentally Friendly Use Period (EFUP). This is an estimate of the number of years that these substances would not leak out or undergo abrupt change. This product may contain replaceable sub-assemblies/components which have a shorter EFUP such as batteries and lamps. These components will be separately marked.
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 47
Appendix
B Product
TRN-TABLET3
B
Disposal
Page 48
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
CAUTION:
Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery.
Dispose of used batteries according to instructions and local regulations.
§ Outside the European Union - If you wish to dispose of used electrical and electronic products outside the European Union, please contact your local authority so as to comply with the correct disposal method.
§ Within the European Union–The device that produces less waste and is easier to recycle is classified as electronic device in terms of the European Directive 2012/19/EU (WEEE), and must not be disposed of as domestic garbage.
EU-wide legislation, as implemented in each Member State, requires that waste electrical and electronic products carrying the mark (left) must be disposed of separately from normal household waste. This includes monitors and electrical accessories, such as signal cables or power
cords. When you need to dispose of your display products, please follow the guidance of your local authority, or ask the shop where you purchased the product. The mark on electrical and electronic products only applies to the current European Union Member States.
Please follow the national guidelines for electrical and electronic product disposal.
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 49
TRN-TABLET3
C Maintenance and
Cleaning Precautions
Appendix
C
Page 50
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
When maintaining or cleaning the TRN-TABLET3, please follow the guidelines below.
WARNING:
If you dropped any material or liquid such as water onto the tablet when cleaning, unplug the power cable immediately and contact your dealer or the nearest service center. Always make sure your hands are dry when unplugging the power cable.
CAUTION:
§ For safety reasons, turn-off the power switch and unplug the tablet before cleaning.
§ Do not scratch or rub the screen with a hard object.
§ Never use any of the following solvents on the tablet. Harsh
chemicals may cause damage to the cabinet and the touch sensor.
Thinner Spray-type cleaner, Benzene, Wax, Abrasive cleaner, Acid or Alkaline solvent.
C.1.1 Maintenance and Cleaning
Prior to cleaning any part or component of the TRN-TABLET3, please read the details below.
§ To clean the TRN-TABLET3,
o remove dirt with a lightly moistened cloth. Then wipe the external chassis
with a soft dry cloth.
o use 75% ethanol alcohol to clean the external chassis.
§ Except for the LCD panel, never spray or squirt liquids directly onto any other components.
§ The interior of the TRN-TABLET3 does not require cleaning. Keep fluids away from the TRN-TABLET3 interior.
§ Never drop any objects or liquids through the openings of the TRN-TABLET3.
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 51
C.1.2 Cleaning Tools
Some components in the TRN-TABLET3 may only be cleaned using a product specifically designed for the purpose. In such case, the product will be explicitly mentioned in the cleaning tips. Below is a list of items to use when cleaning the TRN-TABLET3.
§ Cloth – Although paper towels or tissues can be used, a soft, clean piece of cloth is recommended when cleaning the TRN-TABLET3.
§ Water/Ethanol alcohol – A cloth moistened with water or 75% ethanol alcohol can be used to clean the TRN-TABLET3.
§ Using solvents – The use of solvents is not recommended when cleaning the TRN-TABLET3 as they may damage the plastic parts.
§ Cotton swabs - Cotton swaps moistened with water are excellent tools for wiping hard to reach areas.
§ Foam swabs - Whenever possible, it is best to use lint free swabs such as
TRN-TABLET3
foam swabs for cleaning.
Page 52
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
Appendix
D
D Symbol Definitions
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 53
The following symbols appear on the product, its labeling, or the product packing. Each symbol carries a special definition, as defined below:
This side up
Consult the operating instructions
Fragile, handle with care
Keep dry
Refer to instruction manual
Indicates the manufacturer
Indicates proof of conformity to applicable European Economic Community Council directives and to harmonized standards published in the official journal of the European Communities.
TRN-TABLET3
Tested to comply with FCC Class B standard.
This symbol indicates that the waste of electronic equipment must not be disposed as unsorted municipal waste and must be collected separately. Please contact the manufacturer or other authorized disposal company to decommission your equipment.
This product is recyclable.
Page 54
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
Appendix
E
E BIOS Options
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 55
Below is a list of BIOS configuration options in the BIOS chapter.
System Date [xx/xx/xx] .................................................................................................... 21
System Time [xx:xx:xx] ................................................................................................... 22
Active Processor Cores [All] .......................................................................................... 23
Intel (VMX) Virtualization Technology [Enabled] ........................................................... 24
Hyper-threading [Enabled] .............................................................................................. 24
Intel(R) SpeedStep(tm) [Enabled] ................................................................................... 24
SATA Controller(s) [Enabled] ......................................................................................... 25
SATA Mode Selection [AHCI] .......................................................................................... 25
Security Device Support [Enable] .................................................................................. 26
Pending operation [None] ............................................................................................... 26
ACPI Sleep State [S3 (Suspend to RAM)] ....................................................................... 27
PC Health Status ............................................................................................................. 28
CPU_FAN1 Smart Fan Control/SYS_FAN1 Smart Fan Control [Auto Mode] ................ 29
TRN-TABLET3
Auto mode fan start temperature ................................................................................... 30
Auto mode fan off temperature ...................................................................................... 30
Auto mode fan start PWM ............................................................................................... 30
Auto mode fan slope PWM ............................................................................................. 30
USB Devices .................................................................................................................... 31
Legacy USB Support [Enabled] ...................................................................................... 31
VT-d [Enabled] ................................................................................................................. 33
Enable Root Port [Auto] .................................................................................................. 35
Max Link Speed [Auto] .................................................................................................... 35
PCIe Speed [Auto] ........................................................................................................... 36
Detect Non-Compliance Device [Disabled] .................................................................... 36
HD Audio [Auto] .............................................................................................................. 36
Power Saving Function(ERP) [Enabled] ......................................................................... 36
Administrator Password ................................................................................................. 37
User Password ................................................................................................................ 37
Bootup NumLock State [On] ........................................................................................... 38
Quiet Boot [Enabled] ....................................................................................................... 39
Launch PXE OpROM [Disabled] ..................................................................................... 39
Option ROM Messages [Force BIOS] ............................................................................. 39
UEFI Boot [Enabled] ........................................................................................................ 39
Page 56
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
Boot Option #1 [PO:M.2 (S80) 3MG-P] ............................................................................ 39
Hard Drive BBS Priorities ............................................................................................... 40
Save Changes and Reset ................................................................................................ 40
Discard Changes and Reset ........................................................................................... 40
Restore Defaults .............................................................................................................. 40
Save as User Defaults ..................................................................................................... 41
Restore User Defaults ..................................................................................................... 41
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 57
TRN-TABLET3
Appendix
F
F Hazardous Materials
Disclosure
Page 58
PDF created with pdfFactory Pro trial version www.pdffactory.com
TRN-TABLET3
The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
A label will be placed on each product to indicate the estimated Environmentally Friendly Use Period (EFUP). This is an estimate of the number of years that these substances would not leak out or undergo abrupt change. This product may contain replaceable sub-assemblies/components which have a shorter EFUP such as batteries and lamps. These components will be separately marked.
Please refer to below table.
Part Name Toxic or Hazardous Substances and Elements
Lead (Pb)
Housing Display Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Power Supply Assemblies Battery O: This toxic or hazardous substance is contained in all of the homogeneous materials for the part is below the limit
requirement in SJ/T11363-2006 (now replaced by GB/T 26572-2011).
X: This toxic or hazardous substance is contained in at least one of the homogeneous materials for this part is above the
limit requirement in SJ/T11363-2006 (now replaced by GB/T 26572-2011).
O O O O O O O O O O O O O O O O O O
O O O O O O O O O O O O O O O O O O O O O O O O
O O O O O O
Mercury (Hg)
Cadmium (Cd)
Hexavalent Chromium (CR(VI))
Polybrominated Biphenyls (PBB)
Polybrominated Diphenyl Ethers (PBDE)
PDF created with pdfFactory Pro trial version www.pdffactory.com
Page 59
TRN-TABLET3
此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。
本产品上会附有环境友好使用期限的标签,此期限是估算这些物质不会有泄漏或突变
年限。本产品可能包含有较短的环境友好使用期限的可替换元件,像是电池或灯管,这些元
件将会单独标示出来。
部件名称
壳体 显示
印刷路板 金属螺帽 缆组装 风扇组装
力供应组装 电池
有毒有害物质或元素
(Pb)
(Hg)
(Cd)
六价铬
(CR(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O O
O: 表示有毒有害物质在部件有物质材料中的含量SJ/T11363-2006 (现由 GB/T 26572-2011 取代) 标准规定的限量要求以下。 X: 表示有毒有害物质至少部件的某一均材料中的含量出 SJ/T11363-2006 (现由 GB/T 26572-2011 取代) 标准规定的限量要求。
Page 60
PDF created with pdfFactory Pro trial version www.pdffactory.com
Loading...
