IMBA-9454G Motherboard
IEI Technology Corp.
IEI Technology Corp.
MODEL:
MODEL:
IMBA-9454G
IMBA-9454G
ATX SBC Supports Intel® LGA775 Core 2 Duo™
Intel® Pentium™ 4/D, Intel® Celeron™ D, FSB 533/800/1066 MHz
PCIe x16, PCIe GbE, USB 2.0, SATA II, Audio, RoHS
User Manual
User Manual
Rev. 1.00 - 10 November, 2011
Rev. 4.02 – November 2011
Page i
IMBA-9454G Motherboard
Revision
MODEL IMBA-9454G Motherboard
Revision Number Description Date of Issue
4.02 Updated Figure 5-11: COM2 Mode Selection
Jumper Location
4.01 Updated BIOS Chapter 6 to BIOS version
B188MR14 and Driver Installation Chapter 7
4.00 Changed LAN chipset from Broadcom to
Realtek solution
Added JSPI1 jumper setting
1.00 Initial release March 2007
November 2011
March 2011
December 2010
Page ii
IMBA-9454G Motherboard
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
Copyright
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
IBM PC is a registered trademark of International Business Machines Corporation. INTEL
is a registered trademark of INTEL Corporation. Other product names mentioned herein
are used for identification purposes only and may be trademarks and/or registered
trademarks of their respective owners.
Page iii
IMBA-9454G Motherboard
Packing List
NOTE:
If any of the components listed in the checklist below are missing, please do not
proceed with the installation. Contact the IEI reseller or vendor you purchased the
IMBA-9454G motherboard from or contact an IEI sales representative directly. To
contact an IEI sales representative, please send an email to sales@iei.com.tw
The items listed below should all be included in the IMBA-9454G motherboard package.
1 x IMBA-9454G Single Board Computer
1 x IDE Cable (P/N: 32200-000052-RS)
2 x Dual RS-232 Cable (P/N: 19800-000113-RS)
2 x SATA Cable (P/N: 32000-0628000-RS)
1 x SATA Power Cable (P/N: 32102-000100-100/200-RS)
1 x I/O Shielding (P/N: 45014-0017C0-00-RS)
1 x Mini Jumper Pack (P/N: 33100-000079-RS)
1 x Utility CD (P/N: IEI-7B000-000096-RS)
1 x One Key Recovery CD (P/N: IEI-7B000-000478-RS)
1 x QIG (Quick Installation Guide) (P/N: 51000-001083-RS)
Images of the above items are shown in Chapter 3.
.
